Smc 9712G Key Information Guide

TigerChassis 10/100/1000

14-Slot Multilayer Chassis Switch

◆ IP routing with RIP and OSPF support

◆ Optional blades include 10BASE-T/100BASE-TX, 100BASE-FX,

1000BASE-SX/LX, 10/100/1000BASE-T, GBIC

◆ 12 slots available for media expansion

◆ 24 Gbps switch fabric for non-blocking switching performance

◆ Security features to prevent intruder access and ensure a safe network

environment

◆ Full support for IEEE 802.1Q VLANs with GVRP

◆ QoS support for IEEE 802.1p priority

◆ IGMP and DVMRP multicast support

◆ Optional redundant power, fan, and switch fabric failover support

◆ Manageable via console, web, SNMP/RMON

◆ Supports CIDR, multinetting

Key Information Guide

SMC9712G

TigerChassis 10/100/1000
Key Information Guide

From SMC’s Tiger line of feature-rich workgroup LAN solutions

38 Tesla
Irvine, CA 92618
Phone: [phone]

January 2001

Pub. # 150200008800AR01

Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is
assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its
use. No license is granted by implication or otherwise under any patent or patent rights of SMC. SMC reserves the right to
change specifications at any time without notice.

Copyright © 2002 by

SMC Networks, Inc.

38 Tesla

Irvine, CA 92618

All rights reserved. Printed in Taiwan

Trademarks:

SMC is a registered trademark; and EZ Switch, Tigerchassis, TigerStack and TigerSwitch are trademarks of SMC Networks, Inc. Other
product and company names are trademarks or registered trademarks of their respective holders.

L

IMITED

Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products to be free from defects in workmanship
and materials, under normal use and service, for the applicable warranty term. All SMC products carry a standard 90-day
limited warranty from the date of purchase from SMC or its Authorized Reseller. SMC may, at its own discretion, repair or
replace any product not operating as warranted with a similar or functionally equivalent product, during the applicable
warranty term. SMC will endeavor to repair or replace any product returned under warranty within 30 days of receipt of the
product.

The standard limited warranty can be upgraded to a Limited Lifetime* warranty by registering new products within 30 days
of purchase from SMC or its Authorized Reseller. Registration can be accomplished via the enclosed product registration
card or online via the SMC web site. Failure to register will not affect the standard limited warranty. The Limited Lifetime
warranty covers a product during the Life of that Product, which is defined as the period of time during which the product is
an “Active” SMC product. A product is considered to be “Active” while it is listed on the current SMC price list. As new
technologies emerge, older technologies become obsolete and SMC will, at its discretion, replace an older product in its
product line with one that incorporates these newer technologies. At that point, the obsolete product is discontinued and is
no longer an “Active” SMC product. A list of discontinued products with their respective dates of discontinuance can be
found at:

http://www.smc.com/smc/pages_html/support.html.

All products that are replaced become the property of SMC. Replacement products may be either new or reconditioned. Any
replaced or repaired product carries either a 30-day limited warranty or the remainder of the initial warranty, whichever is
longer. SMC is not responsible for any custom software or firmware, configuration information, or memory data of
Customer contained in, stored on, or integrated with any products returned to SMC pursuant to any warranty. Products
returned to SMC should have any customer-installed accessory or add-on components, such as expansion modules, removed
prior to returning the product for replacement. SMC is not responsible for these items if they are returned with the product.

Customers must contact SMC for a Return Material Authorization number prior to returning any product to SMC. Proof of
purchase may be required. Any product returned to SMC without a valid Return Material Authorization (RMA) number
clearly marked on the outside of the package will be returned to customers at customer’s expense. For warranty claims within
North America, please call our toll-free customer support number at [phone]. Customers are responsible for all
shipping charges from their facility to SMC. SMC is responsible for return shipping charges from SMC to customer.

WARRANTIES EXCLUSIVE: IF AN SMC PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE,
CUSTOMER’S SOLE REMEDY SHALL BE REPAIR OR REPLACEMENT OF THE PRODUCT IN QUESTION, AT
SMC’S OPTION. THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF
ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, EITHER IN FACT OR BY OPERATION
OF LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OR CONDITIONS OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. SMC NEITHER ASSUMES NOR
AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH
THE SALE, INSTALLATION, MAINTENANCE OR USE OF ITS PRODUCTS. SMC SHALL NOT BE LIABLE
UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THE ALLEGED DEFECT IN
THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE,
NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR, OR ANY
OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR
OTHER HAZARD.

LIMITATION OF LIABILITY: IN NO EVENT, WHETHER BASED IN CONTRACT OR TORT (INCLUDING
NEGLIGENCE), SHALL SMC BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR
PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE, LOSS OF BUSINESS, OR OTHER
FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION,

W

ARRANTY

i

L

IMITED WARRANTY

MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF ITS PRODUCTS, EVEN IF SMC OR
ITS AUTHORIZED RESELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES OR THE LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR CONSUMER PRODUCTS, SO THE ABOVE LIMITATIONS
AND EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,
WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS WARRANTY SHALL BE TAKEN TO AFFECT
YOUR STATUTORY RIGHTS.

* SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited
lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date
of purchase.

SMC Networks, Inc.

38 Tesla

Irvine, CA 92618

ii

CONTENTS

ABOUT THIS GUIDE

Audience Definition 5
Conventions 6
Related Documentation 6

1 UNPACKING INSTRUCTIONS

Unpacking a Chassis 8
Unpacking a Module 11
Unpacking a Power Supply 13
Unpacking a Fan Tray 14

2 DOCUMENTATION AND INCLUDED SERVICES

Key Information Guide 15

Printed Copies 15

Installation and Maintenance Guide 16

Printed Copies 16

Software Configuration Guide 16

Printed Copies 16

Included Services 17

Telephone Support 17
SMC Web Site Services 17

Software Updates 17

3 END USER SOFTWARE LICENSE AGREEMENT

License 21
Assignment; No Reverse Engineering 22
Export Restrictions 22
Trade Secrets; Title 23
United States Government Legends 23

Ter m a nd Ter mi na t i o n 2 3
Limited Warranties and Limitation of Liability 23
Governing Law 24
Severability 24
Entire Agreement 24

4 PRODUCT COMPLIANCE

Emissions Compliance Statements for Class A Products 25

Federal Communications Commission Notice 25
Canadian Emissions Requirements 25

VCCI Class A Compliance 26
EMC Directive Statement 27
Low Voltage Directive Statement 27
General Approval Statement for UK 27
Australian EMC Frameworks Statement 27

ABOUT THIS GUIDE

This SMC9712G Key Information Guide provides instructions on how to
unpack the SMC9712G chassis and other components, describes the
documentation set, and provides information on included services, the
software license agreement, and compliance to country and regional
standards for electrical emissions and safety.

Audience Definition This guide is intended for the network administrator who is responsible

for unpacking and installing the network hardware. This guide assumes
that the network administrator has a working knowledge of local area
network (LAN) operations, but it does not assume prior knowledge of
SMC9712G high performance networking equipment. Furthermore, this
guide assumes that the network administrator has obtained the
appropriate technical training and experience to perform tasks in service
access areas of network equipment, to be aware of electrical hazards or
other hazards that exist in performing these tasks, and to take steps that
minimize the danger to themselves or other persons.

6 ABOUT THIS GUIDE

Conventions Table 1 and Table 2 list conventions that are used throughout this guide.

Tab le 1 Notice Icons

Icon Notice Type Description

Information note Information that describes important features or

instructions.

Caution Information that alerts you to potential loss of data or

potential damage to an application, system, or device.

Warning Information that alerts you to potential personal

injury.

Tab le 2 Text Conventions

Convention Description

Words in italics Italics are used to:

■ Emphasize a point

■ Denote a new term at the place where it is defined in the

text

Related

Documentation

The SMC9712G documentation set includes the following documents:

■ SMC9712G Key Information Guide (this guide)

■ SMC9712G Installation and Maintenance Guide

■ SMC9712G Software Configuration Guide

■ SMC9712G Release Notes

To read a brief description of each document, to understand how each
document is distributed in paper or electronic format, or to learn how to
order additional paper copies or to download electronic copies, see
Chapter 2 in this guide.

1

UNPACKING INSTRUCTIONS

This chapter contains important instructions and information about the
shipping box that you have opened.

Because this guide is included in the shipping box of every item in the
SMC9712G product set, this guide may contain more information than
you need. However, you should be able to easily locate the information
that applies to the box that you have opened.

This chapter includes the following sections:

■ Unpacking a Chassis — see page 8

■ Unpacking a Module — see page 11

■ Unpacking a Power Supply — see page 13

■ Unpacking a Fan Tray — see page 14

8 CHAPTER 1: UNPACKING INSTRUCTIONS

Unpacking a
Chassis

Your chassis will have the following preinstalled components:

■ One power supply

■ Two fan trays

To unpack your SMC9712G chassis, follow these steps:

1 Before you continue to unpack the shipping box or install the product,

carefully examine the box for signs of external damage. If the shipping
box shows any signs of damage, replace any items that you have already
removed, reseal the shipping box, and contact your network supplier (the
company from which you purchased the product) immediately.

If you cannot contact your supplier, contact SMC Customer Service:

■ If you are located in the United States or Canada, call

1-800-SMC-YOU and select the numeric option to reach customer

service and the product repair departments.

■ If you are located in another country, find the appropriate telephone

number from the SMC Web site:

http://www.smc.com/

2 If there is no or superficial external damage, use a sufficient number of

people to move the heavy shipping box. Place it near the rack, table, or
shelf where you plan to install the chassis.

WARNING: To minimize the risk of personal injury or equipment
damage, have at least two people transport the shipping box.

WARNING: Safety regulations require that the rack, table, or shelf must
be able to support at least three times the weight of a fully loaded
chassis. A fully loaded SMC9712G chassis weighs approximately 17.68 kg
(39.05 lb) fully loaded. Therefore, the selected rack, table, or shelf must
support at least 61.8 kg (136.5 lb).

Unpacking a Chassis 9

3 By the time you read these instructions, you will have already opened the

shipping box. If you followed the instructions that are printed on the
outside of the shipping box, you turned the box 90 degrees from its
shipment position before you opened it. This position allows you to easily
pull and slide the contents out of the box laterally, rather than to lift them
vertically out of the box.

4 When you first opened the box, you should have seen:

■ The chassis wrapped in a plastic bag.

The chassis is held securely in place by foam supports on two sides
and it is protected from dust and scratches by a plastic bag. One side
of the chassis will be facing you.

■ The cardboard accessories tray located on top of the chassis.

5 Pull the accessories tray out of the shipping box.

6 Verify that the following items are included in the accessories tray:

■ One power cord that is appropriate for your country.

■ One hardware kit in a plastic bag that contains:

■ Two rack-mount flanges

■ Fourteen screws

■ Four rubber feet

■ One cable management device

■ Fourteen plastic ties

■ One standard null modem RS-232 console cable

■ Three printed manuals:

■ SMC9712G Key Information Guide (this guide)

■ SMC9712G Installation and Maintenance Guide

■ SMC9712G Software Configuration Guide

7 Grasp the top and bottom of the chassis and slide it laterally out of the

box. The foam supports should stay attached to the chassis.

8 Save the foam supports and plastic bag in case you need to pack up and

move the chassis to a different site, or in case you need to return the
chassis to your network supplier or to SMC.

9 Inspect the chassis and verify that it contains:

■ One power supply (front, bottom left or right)

10 CHAPTER 1: UNPACKING INSTRUCTIONS

■ Two fan trays (front, top left and right)

■ One Switch Fabric Management Module in slot M1 or M2 (front)

■ All unoccupied module slots and the second power bay should be

covered with blank faceplates.

If the shipping box does not contain the correct components (including
the accessories listed in step 6), follow the instructions in step 1.

10 If you are not prepared to install the chassis, replace it in the shipping box

with the plastic bag and foam supports in their original positions to
prvent damage to the chassis.

11 Read the SMC9712G Installation and Maintenance Guide to verify that

you have met prerequisite installation conditions, to acknowledge
important safety information, and to follow the installation procedures.

A printed copy of this guide is included in all chassis shipping boxes.

Unpacking a Module 11

Unpacking a
Module

SMC offers individual SMC9712G modules for purchase so that you can:

■ Add modules to the empty slots in a chassis.

■ Have spare modules in storage at your site to meet service

requirements or network expansion.

See the SMC9712G Installation and Maintenance Guide for slot
restrictions for Switch Fabric Management Modules, Fast Ethernet
Interface Modules, or Gigabit Ethernet Interface Modules.

This section contains basic instructions and cautions to follow when
unpacking a module shipping box.

1 Before you remove the module from its shipping box, carefully examine

the shipping box for signs of damage.

If the shipping box shows any signs of damage, replace any items that
you have already removed, reseal the shipping box, and contact your
network supplier (the company from which you purchased the product)
immediately.

If you cannot contact your supplier, contact SMC Customer Service:

■ If you are located in the United States or Canada, call

1-800-SMC-YOU and select the numeric option to reach the customer
service and product repair departments.

■ If you are located in another country, find the appropriate telephone

number from the SMC Web site:

http://www.smc.com/

2 Attach a wrist strap to yourself and a proper ground.

CAUTION: When you handle a module, SMC recommends that you
always use a wrist strap that is connected to a proper ground. This
precaution helps prevent electrostatic discharge from damaging the
module.

12 CHAPTER 1: UNPACKING INSTRUCTIONS

3 As shown in Figure 1, remove the module from its antistatic bag by

grasping it on the faceplate. Do not touch traces, chips, or other
components on the circuit board at any time.

Figure 1 Unpacking a Module Carefully

4 Examine the module for obvious signs of damage.

If damage is apparent, follow the instructions in step 1.

If no damage is apparent, replace the module in its antistatic bag.

5 Leave the module in its antistatic bag until you are ready to install it.

6 Read the SMC9712G Installation and Maintenance Guide for important

safety information and instructions for installing and removing modules.

Unpacking a Power Supply 13

Unpacking a Power
Supply

The SMC9712G can hold two power supplies. Only one power supply is
required for operation. If installed, a second power supply provides
complete redundancy if the other power supply fails.

If the power source to the SMC9712G fails, the power supplies in the
switch do not function as battery backups.

The SMC9712G chassis ships from the manufacturing center with one
power supply preinstalled. However, you can purchase a second power
supply separately and install it at your site.

This section contains instructions and cautions to be aware of when
unpacking an individual power supply (Model Number SMC9712P).

1 Before you continue to unpack the shipping box, carefully examine it for

signs of damage.

If the shipping box shows any signs of damage, replace any items that
you have already removed, reseal the shipping box, and contact your
network supplier (the company from which you purchased the product)
immediately.

If you cannot contact your supplier, contact SMC Customer Service:

■ If you are located in the United States or Canada, call

1-800-SMC-YOU and select the numeric option to reach customer
service and the product repair departments.

■ If you are located in another country, find the appropriate telephone

number from the SMC Web site:

http://www.SMC.com/

2 Remove the protective wrap and inspect the power supply for damage. If

damage exists, follow the instructions in step 1.

3 Replace the protective wrap and return the power supply to its shipping

box until you are ready to install it.

4 Read the SMC9712G Installation and Maintenance Guide for important

safety information and instructions for removing and installing power
supplies.

A printed copy of this guide is included in all chassis shipping boxes.

14 CHAPTER 1: UNPACKING INSTRUCTIONS

Unpacking a
Fan Tray

The SMC9712G chassis houses two fan trays. Each fan tray contains two
fans. All four fans are required for normal operation.

The SMC9712G chassis ships from the manufacturing center with two
fan trays preinstalled. You do not have to order or install a fan tray in a
SMC9712G chassis unless one or both fans in a fan tray fail.

This section contains instructions and cautions when unpacking an
individual fan tray (order number SMC9712F).

1 Before you continue to unpack the shipping box, carefully examine it for

signs of damage.

If the shipping box shows any signs of damage, replace any items that
you have already removed, reseal the shipping box, and contact your
network supplier (the company from which you purchased the product)
immediately.

If you cannot contact your supplier, contact SMC Customer Service:

■ If you are located in the United States or Canada, call

1-800-SMC-4-YOU and select the numeric option to reach customer

service and the product repair departments.

■ If you are located in another country, find the appropriate telephone

number from the SMC Web site:

http://www.SMC.com/

2 Remove the protective wrap and inspect the fan tray supply for damage.

If damage exists, follow the instructions in step 1.

3 Replace the protective wrap and return the fan tray to its shipping box

until you are ready to install it.

4 Read the SMC9712G Installation and Maintenance Guide for important

safety information and instructions for removing and installing fan trays.

2

DOCUMENTATION AND
INCLUDED SERVICES

This chapter provides brief descriptions of the following documentation
titles and how you can obtain them:

■ SMC9712G Key Information Guide (this document)

■ SMC9712G Installation and Maintenance Guide

■ SMC9712G Software Configuration Guide

■ SMC9712G Release Notes

In addition, this chapter describes the SMC Network Supervisor software
that can be obtained from SMC’s Web site, as well as the support services
that are included with the purchase of your SMC9712G.

Key Information
Guide

Printed Copies A printed copy of this guide is included with every item in the SMC9712G

This guide that you are reading contains a variety of important
information, as shown in the Table of Contents.

product set.

After you unpack shipping boxes, keep this guide in a safe place for
future reference, along with your sales paperwork. For example, you may
need to review the warranty terms at some point.

16 CHAPTER 2: DOCUMENTATION AND INCLUDED SERVICES

Installation and
Maintenance Guide

Printed Copies A printed copy of this guide is included with all SMC9712G chassis. For

Software
Configuration
Guide

Printed Copies A printed copy of this guide is included with all SMC9712G chassis. For

The SMC9712G Installation and Maintenance Guide provides the
information you need to install or replace a chassis, module, power
supply, or fan tray. It includes site requirements, product specifications,
important safety information, and installation and removal procedures.

your convenience, a wired binding allows the document to lay flat from
any page.

After you install a new chassis, keep this guide in a safe place for future
reference when you install or replace components such as modules, fan
trays, and power supplies.

The SMC9712G Software Configuration Guide provides information
about the switch architecture, the management interfaces, the default
software configuration that exists when you first power up the system,
and how to customize the software features.

your convenience, a wired binding allows the document to lay flat from
any page.

Included Services 17

Included Services The purchase of this SMC9712G includes the following services:

■ Telephone Support

■ SMC Web Site Services

■ Software Updates

These services are not part of the product warranty. SMC reserves the
right to modify or cancel these included services at any time without
advance notice. These services are not available where prohibited or
restricted by law.

Telephone Support For SMC technical support contact numbers around the world, see the

back cover of this guide, or visit the SMC Web site.

SMC Web Site

Services

Information from the SMC Web site services around the world is available
at no charge. These resources provide electronic manuals, technical tips,
and other information about SMC products.

From the SMC Web site, you c an search the FAQ for information on
particular problems or questions.

If you have a technical support case open with SMC, you can access the
latest information about your case from the SMC Web site.

Software Updates Soft upgrades are from SMC’s website in the Drivers and Downloads

section.

18 CHAPTER 2: DOCUMENTATION AND INCLUDED SERVICES

3

END USER SOFTWARE LICENSE
AGREEMENT

IMPORTANT: READ BEFORE USING OR INSTALLING THE SMC9712G
SOFTWARE

YOU SHOULD CAREFULLY READ THE FOLLOWING TERMS AND
CONDITIONS BEFORE INSTALLING AND USING THIS PRODUCT, THE USE
OF WHICH IS LICENSED BY SMC CORPORATION (“SMC”) TO ITS
CUSTOMERS FOR THEIR USE ONLY AS SET FORTH BELOW.

DOWNLOADING, INSTALLING OR OTHERWISE USING ANY PART OF THE
SOFTWARE OR DOCUMENTATION INDICATES THAT YOU ACCEPT THESE
TERMS AND CONDITIONS. IF YOU DO NOT AGREE TO THE TERMS AND
CONDITIONS OF THIS AGREEMENT, DO NOT DOWNLOAD, INSTALL OR
OTHERWISE USE THE SOFTWARE OR DOCUMENTATION, DO NOT CLICK
ON THE “I AGREE” OR SIMILAR BUTTON. AND IF YOU HAVE RECEIVED
THE SOFTWARE AND DOCUMENTATION ON PHYSICAL MEDIA, RETURN
THE ENTIRE PRODUCT WITH THE SOFTWARE AND DOCUMENTATION
UNUSED TO THE SUPPLIER WHERE YOU OBTAINED IT.

License SMC grants you a nonexclusive, nontransferable (except as specified

herein) license to use the accompanying software program(s) in
executable form (the “Software”) and accompanying documentation (the
“Documentation”), subject to the terms and restrictions set forth in this
Agreement. You are not permitted to lease, rent, distribute or sublicense
(except as specified herein) the Software or Documentation or to use the
Software or Documentation in a time-sharing arrangement or in any
other unauthorized manner. Further, no license is granted to you in the
human readable code of the Software (source code). Except as provided
below, this Agreement does not grant you any rights to patents,
copyrights, trade secrets, trademarks, or any other rights with respect to
the Software or Documentation.

22 CHAPTER 3: END USER SOFTWARE LICENSE AGREEMENT

Subject to the restrictions set forth herein, the Software is licensed to be
used by one (1) user on any personal computer owned by or leased to
you, for your internal use. You may reproduce one (1) copy of the
Software and Documentation for backup or archive purposes. Any copy
of the Software and Documentation must contain SMC's and its
licensors' proprietary rights and copyright notices in the same form as on
the original. You agree not to remove or deface any portion of any legend
provided on any licensed program or documentation delivered to you
under this Agreement.

Assignment; No

Reverse Engineering

You may transfer the Software, Documentation and the licenses granted
herein to another party in the same country in which you obtained the
Software and Documentation if the other party agrees in writing to
accept and be bound by the terms and conditions of this Agreement. If
you transfer the Software and Documentation, you must at the same
time either transfer all copies of the Software and Documentation to the
party or you must destroy any copies not transferred. Except as set forth
above, you may not assign or transfer your rights under this Agreement.

Modification, reverse engineering, reverse compiling, or disassembly of
the Software is expressly prohibited. However, if you are a European
Union (“EU”) resident, information necessary to achieve interoperability
of the Software with other programs within the meaning of the EU
Directive on the Legal Protection of Computer Programs is available to
you from SMC upon written request.

Export Restrictions The Software, including the Documentation and all related technical data

(and any copies thereof) (collectively “Technical Data”), is subject to
United States Export control laws and may be subject to export or import
regulations in other countries. In addition, the Technical Data covered

by this Agreement may contain data encryption code which is
unlawful to export or transfer from the United States or country
where you legally obtained it without an approved U.S.
Department of Commerce export license and appropriate foreign
export or import license, as required. You agree that you will not

export or re-export the Technical Data (or any copies thereof) or any
products utilizing the Technical Data in violation of any applicable laws or
regulations of the United States or the country where you legally
obtained it.

You are responsible for obtaining any licenses to export, re-export or
import the Technical Data. In addition to the above, the Product may not
be used, exported or re-exported (i) into or to a national or resident of
any country to which the U.S. has embargoed; or (ii) to any one on the
U.S. Commerce Department's Table of Denial Orders or the U.S. Treasury
Department's list of Specially Designated Nationals.

Trade Secrets; Title You acknowledge and agree that the structure, sequence and

organization of the Software are the valuable trade secrets of SMC and
its suppliers. You agree to hold such trade secrets in confidence. You
further acknowledge and agree that ownership of, and title to, the
Software and Documentation and all subsequent copies thereof
regardless of the form or media are held by SMC and its suppliers.

23

United States

Government Legends

The Software, Documentation and any other technical data provided
hereunder is commercial in nature and developed solely at private
expense. The Software is delivered as “Commercial Computer Software”
as defined in DFARS 252.227-7014 (June 1995) or as a commercial item
as defined in FAR 2.101(a) and as such is provided with only such rights
as are provided in this Agreement, which is our standard commercial
license for the Software. Technical data is provided with limited rights
only as provided in DFAR 252.227-7015 (Nov. 1995) or FAR 52.227-14
(June 1987), whichever is applicable.

Term and Termination The licenses granted hereunder are perpetual unless terminated earlier as

specified below. You may terminate the licenses and this Agreement at
any time by destroying the Software and Documentation together with
all copies and merged portions in any form. The licenses and this
Agreement will also terminate immediately if you fail to comply with any
term or condition of this Agreement. Upon such termination you agree to
destroy the Software and Documentation, together with all copies and
merged portions in any form.

Limited Warranties

and Limitation of

Liability

All warranties and limitations of liability applicable to the Software are as
stated on the Limited Warranty Card or in the product manual, whether
in paper or electronic form, accompanying the Software. Such warranties
and limitations of liability are incorporated herein in their entirety by this
reference.

24 CHAPTER 3: END USER SOFTWARE LICENSE AGREEMENT

Governing Law This Agreement shall be governed by the laws of the State of California,

U.S.A. excluding its conflicts of laws principles and excluding the United
Nations Convention on Contracts for the International Sale of Goods.

Severability In the event any provision of this Agreement is found to be invalid, illegal

or unenforceable, the validity, legality and enforceability of any of the
remaining provisions shall not in any way be affected or impaired and a
valid, legal and enforceable provision of similar intent and economic
impact shall be substituted therefor.

Entire Agreement This Agreement sets forth the entire understanding and agreement

between you and SMC and supersedes all prior agreements, whether
written or oral, with respect to the Software and Documentation, and
may be amended only in a writing signed by both parties.

Should you have any questions concerning this Agreement or if you
desire to contact SMC for any reason, please contact the SMC subsidiary
serving your country, or write:

38 Tesla
Irvine, CA 92618
Phone: [phone]

Copyright © 2002 SMC Corporation. All rights reserved. SMC is a
registered trademark of SMC Corporation.

4

Emissions
Compliance
Statements for
Class A Products

PRODUCT COMPLIANCE

Country or regional standards exist for certain physical and safety issues.
The SMC9712G complies with the standards noted in this chapter.

Product specifications and additional standards compliance information
are noted in the SMC9712G Installation and Maintenance Guide.

Federal

Communications

Commission Notice

Canadian Emissions

Requirements

This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case the user will be required to
correct the interference at his or her own expense.

This Class A digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.

Cet appareil numérique de la classe A respecte toutes les exigences du
Règlement sur le matériel brouilleur du Canada.

26 CHAPTER 4: PRODUCT COMPLIANCE

VCCI Class A

Compliance

This is a Class A product based on the standard of the Voluntary Control
Council for Interference by Information Technology Equipment (VCCI). If
this equipment is used in a domestic environment, radio disturbance may
arise. When such trouble occurs, the user may be required to take
corrective actions.

EMC Directive Statement 27

EMC Directive
Statement

EMC Directive Compliance This equipment was tested and found to conform to the Council Directive

89/336/EEC for electromagnetic compatibility. Conformity with this
Directive is based upon compliance with the following harmonized
standards:

EN 55022 Limits and Methods of Measurement of Radio Interference

EN 50082-1 Electromagnetic Compatibility Generic Immunity Standard:

Residential, Commercial, and Light Industry

Warning: This is a Class A product. In a domestic environment, this
product may cause radio interference, in which case you may be required
to take adequate measures.

Low Voltage
Directive Statement

Low Voltage Directive Compliance This equipment was tested and found to conform to the Council Directive

72/23/EEC for safety of electrical equipment. Conformity with this
Directive is based upon compliance with the following harmonized
standard:

EN 60950 Safety of Information Technology Equipment

General Approval
Statement for UK

UK General Approval Statement This equipment is manufactured to the international Safety Standard

EN60950 and is approved in the UK under the General Approval Number
NS/G/12345/J/100003 for indirect connection to the public
telecommunication network.

Australian EMC
Frameworks
Statement

Australian EMC Frameworks

Compliance

This product conforms to the EMC Frameworks and meets the Class A
limits of AS3548.

28 CHAPTER 4: PRODUCT COMPLIANCE

FOR TECHNICAL SUPPORT, CALL:

From U.S.A. and Canada (24 hours a day, 7 days a week)

(800) SMC-4-YOU; [phone]; Fax: [phone]

From Europe (8:00 AM - 5:30 PM UK Time)

44 (0) 118 974 8700; Fax: [phone]

INTERNET

E-mail addresses:

[e-mail]
[e-mail]

Driver updates:

http://www.smc.com/index.cfm?action=tech support drivers downloads

World Wide Web:

http://www.smc.com/
http://www.smc-europe.com/

FOR LITERATURE OR ADVERTISING RESPONSE, CALL:

U.S.A. and Canada: (800) SMC-4-YOU; Fax [phone]
Spain: 34-93-477-4935; Fax [phone]
UK: 44 (0) 118 974 8700; Fax [phone]
France: 33 (0) 41 38 32 32; Fax [phone]
Italy: 39 02 739 12 33; Fax [phone]
Benelux: 31 33 455 72 88; Fax [phone]
Central Europe: 49 (0) 89 92861-0; Fax [phone]
Switzerland: 41 (0) 1 9409971; Fax [phone]
Nordic: 46 (0) 868 70700; Fax [phone]
Northern Europe: 44 (0) 118 974 8700; Fax [phone]
Eastern Europe: 34 -93-477-4920; Fax [phone]
Sub Saharan Africa: 27-11 314 1133; Fax [phone]
North Africa: 34 93 477 4920; Fax [phone]
Russia: 7 (095) 290 29 96; Fax [phone]
PRC: 86-10-6235-4958; Fax [phone]
Taiwan: 886-2-2659-9669; Fax [phone]
Asia Pacific: (65) 238 6556; Fax [phone]
Korea: 82-2-553-0860; Fax [phone]
Japan: 81-45-224-2332; Fax [phone]
Australia: 61-2-9416-0437; Fax [phone]
India: 91-22-8204437; Fax [phone]

If you are looking for further contact information, please visit www.smc.com or www.smc-europe.com.

38 Tesla
Irvine, CA 92618
Phone: [phone]

Model Numbers: SMC9712G
Publication Number: 150200008800A
Revision Number: F1.1 E012002-R01
