Smc 8748L2 INSTALLATION GUIDE

Download

TigerSwitch 1000

L2 Gigabit Standalone Switch

◆ 48 auto-MDI/MDI-X 10/100/1000BASE-T ports

◆ 4 ports shared with 4 SFP transceiver slots

◆ Non-blocking switching architecture

◆ Support for a redundant power unit

◆ Spanning Tree Protocol, and Rapid STP

◆ Up to six LACP or static 8-port trunks

◆ CoS support for four-level priority

◆ Full support for VLANs with GVRP

◆ IGMP multicast filtering and snooping

◆ Support for jumbo frames up to 9 KB

◆ Manageable via console, Web, and SNMP/RMON

Installation Guide

SMC8748L2

TigerSwitch 1000 Installation Guide

From SMC’s Tiger line of feature-rich workgroup LAN solutions

38 Tesla Irvine, CA 92618 Phone: (949) 679-8000

October 2005

Pub. # 150200053300A

Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC. SMC reserves the right to change specifications at any time without notice.

SMC Networks, Inc.

38 Tesla

Irvine, CA 92618

Trademarks:

SMC is a registered trademark; and EZ Switch, TigerStack and TigerSwitch are trademarks of SMC Networks, Inc. Other product and company names are trademarks or registered trademarks of their respective holders.

IMITED

Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products to be free from defects in workmanship and materials, under normal use and service, for the applicable warranty term. All SMC products carry a standard 90-day limited warranty from the date of purchase from SMC or its Authorized Reseller. SMC may, at its own discretion, repair or replace any product not operating as warranted with a similar or functionally equivalent product, during the applicable warranty term. SMC will endeavor to repair or replace any product returned under warranty within 30 days of receipt of the product.

The standard limited warranty can be upgraded to a Limited Lifetime* warranty by registering new products within 30 days of purchase from SMC or its Authorized Reseller. Registration can be accomplished via the enclosed product registration card or online via the SMC web site. Failure to register will not affect the standard limited warranty. The Limited Lifetime warranty covers a product during the Life of that Product, which is defined as the period of time during which the product is an “Active” SMC product. A product is considered to be “Active” while it is listed on the current SMC price list. As new technologies emerge, older technologies become obsolete and SMC will, at its discretion, replace an older product in its product line with one that incorporates these newer technologies. At that point, the obsolete product is discontinued and is no longer an “Active” SMC product. A list of discontinued products with their respective dates of discontinuance can be found at: http://www.smc.com/index.cfm?action=customer_service_warranty.

All products that are replaced become the property of SMC. Replacement products may be either new or reconditioned. Any replaced or repaired product carries either a 30-day limited warranty or the remainder of the initial warranty, whichever is longer. SMC is not responsible for any custom software or firmware, configuration information, or memory data of Customer contained in, stored on, or integrated with any products returned to SMC pursuant to any warranty. Products returned to SMC should have any customer-installed accessory or add-on components, such as expansion modules, removed prior to returning the product for replacement. SMC is not responsible for these items if they are returned with the product.

Customers must contact SMC for a Return Material Authorization number prior to returning any product to SMC. Proof of purchase may be required. Any product returned to SMC without a valid Return Material Authorization (RMA) number clearly marked on the outside of the package will be returned to customer at customer’s expense. For warranty claims within North America, please call our toll-free customer support number at (800) 762-4968. Customers are responsible for all shipping charges from their facility to SMC. SMC is responsible for return shipping charges from SMC to customer.

ARRANTY

IMITED WARRANTY

WARRANTIES EXCLUSIVE: IF AN SMC PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, CUSTOMER’S SOLE REMEDY SHALL BE REPAIR OR REPLACEMENT OF THE PRODUCT IN QUESTION, AT SMC’S OPTION. THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. SMC NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF ITS PRODUCTS. SMC SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: IN NO EVENT, WHETHER BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), SHALL SMC BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE, LOSS OF BUSINESS, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF ITS PRODUCTS, EVEN IF SMC OR ITS AUTHORIZED RESELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES OR THE LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR CONSUMER PRODUCTS, SO THE ABOVE LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS.

* SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase.

SMC Networks, Inc.

38 Tesla

Irvine, CA 92618

OMPLIANCES

FCC - Class A

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.

You may use unshielded twisted-pair (UTP) for RJ-45 connections - Category 3 or better for 10 Mbps connections, Category 5 or better for 100 Mbps connections, Category 5, 5e, or 6 for 1000 Mbps connections. For fiber optic connections, you may use 50/125 or 62.5/125 micron multimode fiber or 9/125 micron single-mode fiber.

Industry Canada - Class A

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the Department of Communications.

Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe A prescrites dans la norme sur le matériel brouilleur: “Appareils Numériques,” NMB-003 édictée par le ministère des Communications.

Japan VCCI Class A

iii

OMPLIANCES

CE Mark Declaration of Conformance for EMI and Safety (EEC)

SMC contact for these products in Europe is:

SMC Networks Europe, Edificio Conata II, Calle Fructuós Gelabert 6-8, 2 08970 - Sant Joan Despí, Barcelona, Spain.

This information technology equipment complies with the requirements of the Council Directive 89/336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the Amendment Directive 93/68/EEC. For the evaluation of the compliance with these Directives, the following standards were applied:

RFI Emission:

Immunity:

LVD:

• Limit class A according to EN 55022:1998

• Limit class A for harmonic current emission according to EN 61000-3-2/ 1995

• Limitation of voltage fluctuation and flicker in low-voltage supply system according to EN 61000-3-3/1995

• Product family standard according to EN 55024:1998

• Electrostatic Discharge according to EN 61000-4-2:1995 (Contact Discharge: ±4 kV, Air Discharge: ±8 kV)

• Radio-frequency electromagnetic field according to EN 61000-4-3:1996 (80 - 1000 MHz with 1 kHz AM 80% Modulation: 3 V/m)

• Electrical fast transient/burst according to EN 61000-4-4:1995 (AC/DC power supply: ±1 kV, Data/Signal lines: ±0.5 kV)

• Surge immunity test according to EN 61000-4-5:1995 (AC/DC Line to Line: ±1 kV, AC/DC Line to Earth: ±2 kV)

• Immunity to conducted disturbances, Induced by radio-frequency fields: EN 61000-4-6:1996 (0.15 - 80 MHz with 1 kHz AM 80% Modulation: 3 V/m)

• Power frequency magnetic field immunity test according to EN 61000-4-8:1993 (1 A/m at frequency 50 Hz)

• Voltage dips, short interruptions and voltage variations immunity test according to EN 61000-4-11:1994 (>95% Reduction @10 ms, 30% Reduction @500 ms, >95% Reduction @5000 ms)

• EN 60950-1:2001

, 4a,

War ni ng :

Attention: Les raccordeurs ne sont pas utilisés pour le système téléphonique!

Do not plug a phone jack connector in the RJ-45 port. This may damage this device.

OMPLIANCES

Safety Compliance

Warning: Fiber Optic Port Safety

CLASS I

LASER DEVICE

When using a fiber optic port, never look at the transmit laser while it is powered on. Also, never look directly at the fiber TX port and fiber cable ends when they are powered on.

Avertissment: Ports pour fibres optiques - sécurité sur le plan optique

DISPOSITIF LASER

DE CLASSE I

Ne regardez jamais le laser tant qu’il est sous tension. Ne regardez jamais directement le port TX (Transmission) à fibres optiques et les embouts de câbles à fibres optiques tant qu’ils sont sous tension.

Warnhinweis: Faseroptikanschlüsse - Optische Sicherheit

LASERGER DER KLASSE I

Niemals ein Übertragungslaser betrachten, während dieses

ÄT

eingeschaltet ist. Niemals direkt auf den Faser-TX-Anschluß und auf die Faserkabelenden schauen, während diese eingeschaltet sind.

Power Cord Safety

Please read the following safety information carefully before installing the switch:

WA RN IN G

• The unit must be connected to an earthed (grounded) outlet to comply with international safety standards.

• Do not connect the unit to an A.C. outlet (power supply) without an earth (ground) connection.

• The appliance coupler (the connector to the unit and not the wall plug) must have a configuration for mating with an EN 60320/IEC 320 appliance inlet.

• The socket outlet must be near to the unit and easily accessible. You can only remove power from the unit by disconnecting the power cord from the outlet.

• This unit operates under SELV (Safety Extra Low Voltage) conditions according to IEC 60950. The conditions are only maintained if the equipment to which it is connected also operates under SELV conditions.

Installation and removal of the unit must be carried out by qualified personnel only.

France and Peru only

This unit cannot be powered from IT† supplies. If your supplies are of IT type, this unit must be powered by 230 V (2P+T) via an isolation transformer ratio 1:1, with the secondary connection point labelled Neutral, connected directly to earth (ground).

†

Impédance à la terre

OMPLIANCES

Important!

label on the cable) against the following:

Power Cord Set

U.S.A. and Canada The cord set must be UL-approved and CSA certified.

Denmark The supply plug must comply with Section 107-2-D1, Standard

Switzerland The supply plug must comply with SEV/ASE 1011.

U.K. The supply plug must comply with BS1363 (3-pin 13 A) and be fitted

Europe The supply plug must comply with CEE7/7 (“SCHUKO”).

Before making connections, make sure you have the correct cord set. Check it (read the

The minimum specifications for the flexible cord are:

- No. 18 AWG - not longer than 2 meters, or 16 AWG.

- Type SV or SJ

- 3-conductor

The cord set must have a rated current capacity of at least 10 A

The attachment plug must be an earth-grounding type with NEMA 5-15P (15 A, 125 V) or NEMA 6-15P (15 A, 250 V) configuration.

DK2-1a or DK2-5a.

with a 5 A fuse which complies with BS1362.

The mains cord must be <HAR> or <BASEC> marked and be of type HO3VVF3GO.75 (minimum).

IEC-320 socket.

Veuillez lire à fond l'information de la sécurité suivante avant d'installer le Switch:

AVERTISSEMENT:

qualifié.

• Ne branchez pas votre appareil sur une prise secteur (alimentation électrique) lorsqu'il n'y a pas de connexion de mise à la terre (mise à la masse).

• Vous devez raccorder ce groupe à une sortie mise à la terre (mise à la masse) afin de respecter les normes internationales de sécurité.

• Le coupleur d’appareil (le connecteur du groupe et non pas la prise murale) doit respecter configuration qui permet un branchement sur une entrée d’appareil EN 60320/IEC

• La prise secteur doit se trouver à proximité de l’appareil et son accès doit être facile. Vous ne pouvez mettre l’appareil hors circuit qu’en débranchant son cordon électrique au niveau de cette prise.

• L’appareil fonctionne à une tension extrêmement basse de sécurité qui est conforme à la norme IEC 60950. Ces conditions ne sont maintenues que si l’équipement auquel il est raccordé fonctionne dans les mêmes conditions.

L’installation et la dépose de ce groupe doivent être confiés à un personnel

une

320.

OMPLIANCES

France et Pérou uniquement:

Ce groupe ne peut pas être alimenté par un dispositif à impédance à la terre. Si vos alimentations sont du type impédance à la terre, ce groupe doit être alimenté par une tension de 230 V (2 P+T) par le biais d’un transformateur d’isolement à rapport 1:1, avec un point secondaire de connexion portant l’appellation Neutre et avec raccordement direct à la terre (masse).

Cordon électrique - Il doit être agréé dans le pays d’utilisation

Etats-Unis et Canada:

Danemark: La prise mâle d’alimentation doit respecter la section 107-2 D1 de la

Suisse: La prise mâle d’alimentation doit respecter la norme SEV/ASE 1011.

Europe La prise secteur doit être conforme aux normes CEE 7/7

Le cordon doit avoir reçu l’homologation des UL et un certificat de la CSA.

Les spécifications minimales pour un cable flexible sont AWG No. 18, ouAWG No. 16 pour un cable de longueur inférieure

- type SV ou SJ

- 3 conducteurs

Le cordon doit être en mesure d’acheminer un courant nominal d’au moins 10 A.

La prise femelle de branchement doit être du type à mise à la terre (mise à la masse) et respecter la configuration NEMA 5-15P (15 A, 125 V) ou NEMA 6-15P (15 A, 250 V).

norme DK2 1a ou DK2 5a.

(“SCHUKO”) LE cordon secteur doit porter la mention <HAR> ou <BASEC> et

doit être de type HO3VVF3GO.75 (minimum).

2 métres.

Bitte unbedingt vor dem Einbauen des Switches die folgenden Sicherheitsanweisungen durchlesen:

WARNUNG:

• Das Gerät sollte nicht an eine ungeerdete Wechselstromsteckdose angeschlossen werden.

• Das Gerät muß an eine geerdete Steckdose angeschlossen werden, welche die internationalen Sicherheitsnormen erfüllt.

• Der Gerätestecker (der Anschluß an das Gerät, nicht der Wandsteckdosenstecker) muß einen gemäß EN 60320/IEC 320 konfigurierten Geräteeingang haben.

• Die Netzsteckdose muß in der Nähe des Geräts und leicht zugänglich sein. Die Stromversorgung des Geräts kann nur durch Herausziehen des Gerätenetzkabels aus der Netzsteckdose unterbrochen werden.

• Der Betrieb dieses Geräts erfolgt unter den SELV-Bedingungen (Sicherheitskleinstspannung) gemäß IEC 60950. Diese Bedingungen sind nur gegeben, wenn auch die an das Gerät angeschlossenen Geräte unter SELV-Bedingungen betrieben werden.

Die Installation und der Ausbau des Geräts darf nur durch Fachpersonal erfolgen.

vii

OMPLIANCES

Stromkabel. Dies muss von dem Land, in dem es benutzt wird geprüft werden:

Schweiz Dieser Stromstecker muß die SEV/ASE 1011Bestimmungen

Europe Das Netzkabel muß vom Typ HO3VVF3GO.75

einhalten.

(Mindestanforderung) sein und die Aufschrift <HAR> oder <BASEC> tragen.

Der Netzstecker muß die Norm CEE 7/7 erfüllen (”SCHUKO”).

Warnings and Cautionary Messages

Warning: This product does not contain any serviceable user parts.

Warning: Installation and removal of the unit must be carried out by qualified personnel

Warning: When connecting this device to a power outlet, connect the field ground lead

Warning: This switch uses lasers to transmit signals over fiber optic cable. The lasers are

Caution: Wear an anti-static wrist strap or take other suitable measures to prevent

Caution: Do not plug a phone jack connector in the RJ-45 port. This may damage this

Caution: Use only twisted-pair cables with RJ-45 connectors that conform to FCC

only.

on the tri-pole power plug to a valid earth ground line to prevent electrical hazards.

compliant with the requirements of a Class 1 Laser Product and are inherently eye safe in normal operation. However, you should never look directly at a transmit port when it is powered on.

electrostatic discharge when handling this equipment.

device. Les raccordeurs ne sont pas utilisé pour le système téléphonique!

standards.

Warnings (in German)

Achtung: Dieses Produkt enthält keine Teile, die eine Wartung vom Benutzer benötigen.

Achtung: Installation und Deinstallation des Gerätes müssen von qualifiziertem

Achtung: Wenn das Gerät an eine Steckdose angeschlossen wird, muß der Masseanschluß

Achtung: Dieses Gerät nutzt Laser zur Signalübertragung über Glasfasern. Die Laser

Servicepersonal durchgeführt werden.

am dreipoligen Netzstecker mit Schutzerde verbunden werden, um elektrische Gefahren zu vermeiden.

entsprechen den Anforderungen an eine Lasereinrichtung der Klasse 1 und sind durch ihre Bauart im normalen Betrieb sicher für die Augen. Trotzdem sollte niemals direkt in den einen Übertragungskanal geblickt werden, wenn er eingeschaltet ist.

viii

OMPLIANCES

Environmental Statement

The manufacturer of this product endeavours to sustain an environmentally-friendly policy throughout the entire production process. This is achieved though the following means:

• Adherence to national legislation and regulations on environmental production standards.

• Conservation of operational resources.

• Waste reduction and safe disposal of all harmful un-recyclable by-products.

• Recycling of all reusable waste content.

• Design of products to maximize recyclables at the end of the product’s life span.

• Continual monitoring of safety standards.

End of Product Life Span

This product is manufactured in such a way as to allow for the recovery and disposal of all included electrical components once the product has reached the end of its life.

Manufacturing Materials

There are no hazardous nor ozone-depleting materials in this product.

Documentation

All printed documentation for this product uses biodegradable paper that originates from sustained and managed forests. The inks used in the printing process are non-toxic.

Purpose

This guide details the hardware features of the switch, including its physical and performance-related characteristics, and how to install the switch.

Audience

The guide is intended for use by network administrators who are responsible for installing and setting up network equipment; consequently, it assumes a basic working knowledge of LANs (Local Area Networks).

Diese Anleitung ist f Installation und das einstellen von Netzwerkkomponenten verantwortlich sind; sie setzt Erfahrung bei der Arbeit mit LANs (Local Area Networks) voraus.

ür die Benutzung durch Netzwerkadministratoren vorgesehen, die für die

Related Publications

The following publication gives specific information on how to operate and use the management functions of the switch:

The SMC8748L2 Management Guide

Also, as part of the switch’s firmware, there is an online web-based help that describes all management related features.

OMPLIANCES

ABLE OF

ONTENTS

1 About the TigerSwitch . . . . . . . . . . . . . . . . . . . . . . . . .1-1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Switch Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Network Management Options . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Description of Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

10/100/1000BASE-T Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

SFP Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

10-Gigabit Ethernet Module Slots . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Port and System Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Optional Redundant Power Unit . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Power Supply Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Optional Media Extender Module . . . . . . . . . . . . . . . . . . . . . . . . 1-7

Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8

Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8

Expandability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8

Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9

Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9

2 Network Planning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Introduction to Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Application Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Collapsed Backbone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Network Aggregation Plan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Remote Connections with Fiber Cable . . . . . . . . . . . . . . . . . . . . 2-4

10GBASE Fiber Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Making VLAN Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Application Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

3 Installing the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Selecting a Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Ethernet Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Equipment Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Optional Rack-Mounting Equipment . . . . . . . . . . . . . . . . . . . . . 3-3

Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

ABLE OF CONTENTS

Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Desktop or Shelf Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Installing an Optional SFP Transceiver . . . . . . . . . . . . . . . . . . . . . . . . . 3-7

Installing an Optional Module into the Switch . . . . . . . . . . . . . . . . . . . . 3-8

Connecting to a Power Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

Connecting to the Console Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10

Wiring Map for Serial Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10

4 Making Network Connections . . . . . . . . . . . . . . . . . . . 4-1

Connecting Network Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Twisted-Pair Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Cabling Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Connecting to PCs, Servers, Hubs and Switches . . . . . . . . . . . . 4-2

Network Wiring Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Fiber Optic SFP and XFP Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

Connectivity Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6

1000BASE-T Cable Requirements . . . . . . . . . . . . . . . . . . . . . . . 4-6

10 Gbps Ethernet Collision Domain . . . . . . . . . . . . . . . . . . . . . . 4-7

1000 Mbps Gigabit Ethernet Collision Domain . . . . . . . . . . . . . 4-7

100 Mbps Fast Ethernet Collision Domain . . . . . . . . . . . . . . . . 4-8

10 Mbps Ethernet Collision Domain . . . . . . . . . . . . . . . . . . . . . 4-8

Cable Labeling and Connection Records . . . . . . . . . . . . . . . . . . . . . . . . 4-9

A Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1

Diagnosing Switch Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1

Diagnosing Power Problems with the LEDs . . . . . . . . . . . . . . .A-2

Power and Cooling Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

In-Band Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3

B Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-1

Twisted-Pair Cable and Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . B-1

10BASE-T/100BASE-TX Pin Assignments . . . . . . . . . . . . . . . . B-2

Straight-Through Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3

Crossover Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4

1000BASE-T Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . B-5

Cable Testing for Existing Category 5 Cable . . . . . . . . . . . . . . . B-5

xii

ABLE OF CONTENTS

Fiber Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-6

C Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1

Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1

Switch Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2

Management Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3

Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3

Compliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3

10GBASE Extender Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4

D German Instructions . . . . . . . . . . . . . . . . . . . . . . . . . .D-1

Eine Site auswahlen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1

Montage (Rack Mounting Instructions - German) . . . . . . . . . . . . . . . . D-2

Rack-Montage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-2

Glossary

Index

xiii

ABLES

Table 1-2 System Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Table 1-1 Port Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Table 1-3 Module LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

Table 3-1 Serial Cable Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10

Table 4-1 Maximum 10GBASE-SR 10 Gigabit Ethernet Cable Length 4-7 Table 4-2 Maximum 10GBASE-ER 10 Gigabit Ethernet Cable Length 4-7 Table 4-3 Maximum 10GBASE-LR 10 Gigabit Ethernet Cable Length 4-7 Table 4-4 Maximum 1000BASE-T Gigabit Ethernet Cable Length . . 4-7

Table 4-8 Maximum Fast Ethernet Cable Length . . . . . . . . . . . . . . . . 4-8

Table 4-9 Maximum Ethernet Cable Length . . . . . . . . . . . . . . . . . . . . 4-8

Table 4-5 Maximum 1000BASE-SX Gigabit Ethernet Cable Lengths 4-8 Table 4-6 Maximum 1000BASE-LX Gigabit Ethernet Cable Length 4-8 Table 4-7 Maximum 1000BASE-LH Gigabit Ethernet Cable Length 4-8

Table A-1 Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1

Table A-2 Power/RPU LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2

Table B-1 10/100BASE-TX MDI and MDI-X Port Pinouts . . . . . . . B-2

Table B-2 1000BASE-T MDI and MDI-X Port Pinouts . . . . . . . . . . . B-5

xiv

IGURES

Figure 1-1 Front and Rear Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Figure 1-2 Port LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

Figure 1-3 System LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

Figure 1-4 Power Supply Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

Figure 1-5 Single-Port 10GBASE Module . . . . . . . . . . . . . . . . . . . . . 1-7

Figure 2-1 Collapsed Backbone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Figure 2-2 Network Aggregation Plan . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Figure 2-3 Remote Connections with Fiber Cable . . . . . . . . . . . . . . 2-4

Figure 2-4 10GBASE Fiber Connections . . . . . . . . . . . . . . . . . . . . . 2-5

Figure 2-5 Making VLAN Connections . . . . . . . . . . . . . . . . . . . . . . . 2-6

Figure 3-1 RJ-45 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Figure 3-2 Attaching the Brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Figure 3-3 Installing the Switch in a Rack . . . . . . . . . . . . . . . . . . . . . 3-5

Figure 3-4 Attaching the Adhesive Feet . . . . . . . . . . . . . . . . . . . . . . . 3-6

Figure 3-5 Installing an SFP Transceiver into a Slot . . . . . . . . . . . . . 3-7

Figure 3-6 Installing an Optional Module . . . . . . . . . . . . . . . . . . . . . 3-8

Figure 3-7 Power Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

Figure 3-8 Serial Port (DB-9 DTE) Pin-Out . . . . . . . . . . . . . . . . . . 3-10

Figure 4-1 Making Twisted-Pair Connections . . . . . . . . . . . . . . . . . . 4-2

Figure 4-2 Network Wiring Connections . . . . . . . . . . . . . . . . . . . . . . 4-3

Figure 4-3 Making Fiber Port Connections . . . . . . . . . . . . . . . . . . . . 4-5

Figure B-1 RJ-45 Connector Pin Numbers . . . . . . . . . . . . . . . . . . . . B-1

Figure B-2 Straight-through Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . B-3

Figure B-3 Crossover Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4

IGURES

xvi

HAPTER

BOUT THE

IGERSWITCH

Overview

SMC’s TigerSwitch SMC8748L2 is an intelligent switch with 48 10/100/

1000BASE-T ports, four of which are combination ports with four Small Form Factor Pluggable (SFP) transceiver slots (see Figure 1-1, Ports 45-48), and 2 optional expansion slots on the rear panel for 10GBASE modules.

The switch includes an SNMP-based management agent embedded on the main board, which supports both in-band and out-of-band access for managing the switch.

The switch provides a broad range of powerful features for Layer 2 switching, delivering reliability and consistent performance for your network traffic. It brings order to poorly performing networks by segregating them into separate broadcast domains with IEEE 802.1Q compliant VLANs, and empowers multimedia applications with multicast switching and CoS services.

that are shared

1. RJ-45 ports 45-48 shared with a SFP tranceiver slots. If an SFP transceiver is plugged in, the corresponding RJ-45 port is disabled.

1-1

BOUT THE TIGERSWITCH

SFP Slots

Console Port

System Indicators

Power Socket

Module Slots

Port Status Indicators

10/100/1000 Mbps RJ-45 Ports

Redundant Power Socket

Figure 1-1 Front and Rear Panels

Switch Architecture

The SMC8748L2 switch employs a wire-speed, non-blocking switching fabric. This permits simultaneous wire-speed transport of multiple packets at low latency on all ports. The switch also features full-duplex capability on all ports, which effectively doubles the bandwidth of each connection.

The switch uses store-and-forward switching to ensure maximum data integrity. With store-and-forward switching, the entire packet must be received into a buffer and checked for validity before being forwarded. This prevents errors from being propagated throughout the network.

The switch also includes two slots on the rear panel for slide-in single-port 10GBASE modules that support XFP transceivers.

1-2

ESCRIPTION OF HARDWARE

Network Management Options

The SMC8748L2 switch contains a comprehensive array of LEDs for “at-a-glance” monitoring of network and port status. It also includes a management agent that allows you to configure or monitor the switch using its embedded management software, or via SNMP applications.

To manage the switch, you can make a direct connection to the RS-232 console port (out-of-band), or you can manage it through a network connection (in-band) using Telnet, the on-board Web agent, or SNMP-based network management software.

For a detailed description of the advanced features, refer to the Management Guide.

Description of Hardware

10/100/1000BASE-T Ports

The SMC8748L2 contains 48 10/100/1000BASE-T RJ-45 ports that operate at 10 Mbps or 100 Mbps, half or full duplex, or at 1000 Mbps, full duplex. Because all RJ-45 ports on this switch support automatic MDI/MDI-X operation, you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs. (See “1000BASE-T Pin Assignments” on page B-5.)

Each of these ports support auto-negotiation, so the optimum transmission mode (half or full duplex), and data rate (10, 100, or 1000 Mbps) can be selected automatically. If a device connected to one of these ports does not support auto-negotiation, the communication mode of that port can be configured manually.

Each port also supports IEEE 802.3x auto-negotiation of flow control, so the switch can automatically prevent port buffers from becoming saturated.

1-3

BOUT THE TIGERSWITCH

SFP Slots

The SMC8748L2 contains four combination Gigabit RJ-45 ports that are shared with Small Form Factor Pluggable (SFP) transceiver slots (Ports 45-48,

Figure 1-1 on page 1-2). If an SFP transceiver (purchased separately) is installed in a slot, the associated RJ-45 port is disabled. The switch can be configured to force the use of an RJ-45 port or SFP slot, as required.

10-Gigabit Ethernet Module Slots

The SMC8748L2 include two slots on the rear panel for hot-swappable single-port 10GBASE modules with XFP transceivers. Refer to “Optional Media Extender Module” on page 1-7 for more information on this module.

Port and System Status LEDs

The SMC8748L2 includes a display panel for key system and port indications that simplify installation and network troubleshooting. The LEDs, which are located on the front panel for easy viewing, are shown below and described in the following tables.

1-4

Port Status LEDs

SFP Port Status LEDs

Figure 1-2 Port LEDs

Table 1-1 Port Status LEDs

LED Condition Status

RJ-45/SFP Ports

ESCRIPTION OF HARDWARE

Link/ Activity

Note: The SFP status LEDs are only active when the SFP port (45-48) has a valid

On/Flashing Amber

On/Flashing Green

Off There is no valid link on the port.

link.

The port has a valid 10 or 100 Mbps link. Flashing indicates activity.

The port has a valid 1000 Mbps link. Flashing indicates activity.

System LEDs

Figure 1-3 System LEDs

Table 1-2 System Status LEDs

LED Condition Status

Power On Green Internal power supply is operating normally.

On Amber Internal power supply has failed.

Off Power off or failure.

Diag Flashing Amber System self-diagnostic test has failed.

On Amber System self-diagnostic test in progress.

On Green System self-diagnostic test successfully

completed.

1-5

BOUT THE TIGERSWITCH

Table 1-2 System Status LEDs (Continued)

LED Condition Status

RPU On Green Redundant power available.

Flashing Green Operating on redundant power.

On Amber Fault in redundant power unit.

Off There is no redundant power unit currently

attached.

Module 1 / Module 2

On Green Module present and operating normally.

On Amber Module present but cannot be accessed or has

failed.

Off Module not present.

Optional Redundant Power Unit

The switch supports an optional Redundant Power Unit (RPU) that can supply power to the switch in the event of failure of the internal power supply.

Power Supply Sockets

There are two power sockets on the rear panel of the switch. The standard power socket is for the AC power cord. The socket labeled “RPU” is for the optional Redundant Power Unit

Redundant Power Socket

(RPU).

Power Socket

Figure 1-4 Power Supply Sockets

1-6

ESCRIPTION OF HARDWARE

Optional Media Extender Module

10GBASE Module

Figure 1-5 Single-Port 10GBASE Module

The 10GBASE module supports 10-Gigabit Ethernet XFP transceivers. Using multimode fiber cable, a 10GBASE-SR XFP transceiver can connect to another device up to 300 meters away. Using single-mode fiber cable, a 10GBASE-LR XFP transceiver can connect to a remote site up to 10 km (6.2 miles) away, and a 10GBASE-ER XFP transceiver can reach a site up to 40 km (24.9 miles) away. All 10GBASE XFP transceivers operate at 10 Gbps full duplex.

Table 1-3 Module LED

LED Condition Status

Link/ Activity

On/Flashing Green

Off There is no valid link on the port

The port has a valid 10 Gbps link. Flashing indicates activity.

1-7

BOUT THE TIGERSWITCH

Features and Benefits

Connectivity

• 44-port 10/100/100BASE-T plus 4 gigabit combo ports (RJ45/SFP) on

the front panel.

• Auto-negotiation enables each RJ-45 port to automatically select the

optimum speed (10, 100 or 1000 Mbps), and the communication mode (half or full duplex) if this feature is supported by the attached device; otherwise the port can be configured manually.

• Independent RJ-45 10/100/1000BASE-T ports with auto MDI/MDI-X

pinout selection.

• Unshielded (UTP) cable supported on all RJ-45 ports: Category 3 or

better for 10 connections, and Category 5, 5e or 6 for 1000 Mbps connections.

• IEEE 802.3-2002 Ethernet, Fast Ethernet, Gigabit Ethernet compliance

ensures compatibility with standards-based hubs, network cards and switches from any vendor.

Mbps connections, Category 5 or better for 100 Mbps

Expandability

• 4 Small Form Factor Pluggable (SFP) transceiver slots (shared with

1000BASE-T ports)

• Supports 1000BASE-SX, 1000BASE-LX, and 1000BASE-LH SFP

transceivers.

• Optional 10GBASE module that supports 10GBASE-SR,

10GBASE-LR, and 10GBASE-ER XFP transceivers.

1-8

EATURES AND BENEFITS

Performance

• Transparent bridging

• Switching table with a total of 8K MAC address entries

• Provides store-and-forward switching

• Supports wire-speed filtering and forwarding

• Supports flow control, using back pressure for half duplex and

IEEE

802.3x for full duplex

• Broadcast storm control

Management

• “At-a-glance” LEDs for easy troubleshooting

• Network management agent:

- Manages switch in-band or out-of-band

- Supports console, Telnet, SSH, SNMP, RMON 4 groups and web-based interface

1-9

BOUT THE TIGERSWITCH

1-10

HAPTER

ETWORK

LANNING

Introduction to Switching

A network switch allows simultaneous transmission of multiple packets via non-crossbar switching. This means that it can partition a network more efficiently than bridges or routers. The switch has, therefore, been recognized as one of the most important building blocks for today’s networking technology.

When performance bottlenecks are caused by congestion at the network access point (such as the network card for a high-volume file server), the device experiencing congestion (server, power user, or hub) can be attached directly to a switched port. And, by using full-duplex mode, the bandwidth of the dedicated segment can be doubled to maximize throughput.

When networks are based on repeater (hub) technology, the distance between end stations is limited by a maximum hop count. However, a switch turns the hop count back to zero. So subdividing the network into smaller and more manageable segments, and linking them to the larger network by means of a switch, removes this limitation.

A switch can be easily configured in any Ethernet, Fast Ethernet, Gigabit Ethernet, or 10-Gigabit Ethernet network to significantly boost bandwidth while using conventional cabling and network cards.

2-1

ETWORK PLANNING

Application Examples

The SMC8748L2 is not only designed to segment your network, but also to provide a wide range of options in setting up network connections. Some typical applications are described below.

Collapsed Backbone

The SMC8748L2 is an excellent choice for mixed Ethernet, Fast Ethernet, Gigabit Ethernet, and 10-Gigabit Ethernet installations where significant growth is expected in the near future. In a basic stand-alone configuration, it can provide direct full-duplex connections to workstations or servers. You can easily build on this basic configuration, adding direct full-duplex connections to workstations or servers. When the time comes for further expansion, just connect to another switch using one of the Gigabit Ethernet ports built into the front panel, a Gigabit Ethernet port on a plug-in SFP transceiver, or a 10G XFP transceiver on an optional module.

In the figure below, the switch is operating as a collapsed backbone for a small LAN. It is providing dedicated 100 workstations, 1000

Mbps full-duplex connections to power users and servers.

Mbps full-duplex connections to

2-2

Figure 2-1 Collapsed Backbone

PPLICATION EXAMPLES

Network Aggregation Plan

This switch provides 48 parallel bridging ports (i.e., 48 distinct collision domains), which can be used to collapse a complex network down into a single efficient bridged node, increasing overall bandwidth and throughput.

In the figure below, the 10/100/1000BASE-T ports are providing 1000

Mbps connectivity through layer 2 switches. In addition, the switch is

also connecting several servers at 1000 Mbps.

Figure 2-2 Network Aggregation Plan

2-3

ETWORK PLANNING

Remote Connections with Fiber Cable

Fiber optic technology allows for longer cabling than any other media type. A 1000BASE-SX (MMF) link can connect to a site up to 550 meters away, a 1000BASE-LX (SMF) link up to 5 km, and a 1000BASE-LH link up to 70

km. This allows a switch to serve as a collapsed backbone, providing

direct connectivity for a widespread LAN.

A 1000BASE-SX SFP transceiver can be used for a high-speed connection between floors in the same building and a 1000BASE-LX SFP transceiver can be used for core connections between buildings in a campus setting. And for long-haul connections, a 1000BASE-LH SFP transceiver can be used to reach another site up to 70 kilometers away.

The figure below illustrates the switch connecting multiple segments with fiber cable.

2-4

Figure 2-3 Remote Connections with Fiber Cable

PPLICATION EXAMPLES

10GBASE Fiber Connections

The switch's 10GBASE modules provide a cost-effective way to build a 10

Gbps Ethernet network. A 10GBASE-SR (MMF) link can connect to a device up to 300 10GBASE-ER (SMF) link up to 40 scale their Ethernet networks from 10, 100, or 1000

A 10GBASE-SR XFP transceiver can be used for a high-speed connection between floors in the same building and a 10GBASE-LR XFP transceiver can be used for core connections between buildings in a campus setting. And for long-haul connections, a 10GBASE-ER XFP transceiver can be used to reach another site up to 40

The figure below illustrates a connection between two sites and to their remote switches.

meters away, a 10GBASE-LR (SMF) link up to 10 km, and a

km. This allows network managers to

Mbps to 10 Gbps.

km away.

Figure 2-4 10GBASE Fiber Connections

2-5

ETWORK PLANNING

Making VLAN Connections

This switch supports VLANs which can be used to organize any group of network nodes into separate broadcast domains. VLANs confine broadcast traffic to the originating group, and can eliminate broadcast storms in large networks. This provides a more secure and cleaner network environment.

VLANs can be based on untagged port groups, or traffic can be explicitly tagged to identify the VLAN group to which it belongs. Untagged VLANs can be used for small networks attached to a single switch. However, tagged VLANs should be used for larger networks, and all the VLANs assigned to the inter-switch links.

The switch also support multiple spanning trees which allow VLANs groups to maintain a more stable path between all VLAN members. This can reduce the overall amount of protocol traffic crossing the network, and provide a shorter reconfiguration time if any link in the spanning tree fails.

Figure 2-5 Making VLAN Connections

Note: When connecting to a switch that does not support IEEE 802.1Q VLAN

tags, use untagged ports.

2-6

PPLICATION NOTES

Application Notes

1. Full-duplex operation only applies to point-to-point access (such as

when a switch is attached to a workstation, server or another switch). When the switch is connected to a hub, both devices must operate in half-duplex mode.

2. Avoid using flow control on a port connected to a hub unless it is

actually required to solve a problem. Otherwise back pressure jamming signals may degrade overall performance for the segment attached to the hub.

3. As a general rule the length of fiber optic cable for a single switched link

should not exceed:

• 1000BASE-SX: 550 m (1805 ft) for multimode fiber.

• 1000BASE-LX: 5 km (3.1 miles) for single-mode fiber.

• 1000BASE-LH: 70 km (43 miles) for single-mode fiber.

• 10GBASE-SR: 300 m (984 ft) for multimode fiber.

• 10GBASE-LR: 10 km (6.2 miles) for single-mode fiber.

• 10GBASE-ER: 40 km (24.9 miles) for single-mode fiber.

However, power budget constraints must also be considered when calculating the maximum cable length for your specific environment.

2-7

ETWORK PLANNING

2-8

HAPTER

NSTALLING THE

WITCH

Selecting a Site

TigerSwitch units can be mounted in a standard 19-inch equipment rack or

on a flat surface. Be sure to follow the guidelines below when choosing a

location.

• The site should:

- be at the center of all the devices you want to link and near a power outlet.

- be able to maintain its temperature within 0 to 50 °C (32 to 122 °F) and its humidity within 5% to 95%, non-condensing

- provide adequate space (approximately five centimeters or two inches) on all sides for proper air flow

- be accessible for installing, cabling and maintaining the devices

- allow the status LEDs to be clearly visible

• Make sure twisted-pair cable is always routed away from power lines, fluorescent lighting fixtures and other sources of electrical interference, such as radios and transmitters.

• Make sure that the unit is connected to a separate grounded power outlet that provides 100 to 240 VAC, 50 to 60 Hz, is within 2.44 m (8 each device and is powered from an independent circuit breaker. As with any equipment, using a filter or surge suppressor is recommended.

feet) of

3-1

NSTALLING THE SWITCH

Ethernet Cabling

To ensure proper operation when installing the switch into a network, make sure that the current cables are suitable for 10BASE-T, 100BASE-TX or 1000BASE-T operation. Check the following criteria against the current installation of your network:

• Cable type: Unshielded twisted pair (UTP) or shielded twisted pair (STP) cables with RJ-45 connectors; Category 3 or better for 10BASE-T, Category 5 or better for 100BASE-TX, and Category 5, 5e or 6 for 1000BASE-T.

• Protection from radio frequency interference emissions

• Electrical surge suppression

• Separation of electrical wires (switch related or other) and electromagnetic fields from data based network wiring

• Safe connections with no damaged cables, connectors or shields

RJ-45 Connector

3-2

Figure 3-1 RJ-45 Connections

QUIPMENT CHECKLIST

Equipment Checklist

After unpacking the TigerSwitch, check the contents to be sure you have received all the components. Then, before beginning the installation, be sure you have all other necessary installation equipment.

Package Contents

• TigerSwitch 1000, SMC8748L2

• Four adhesive foot pads

• Bracket Mounting Kit containing two brackets and eight screws for

attaching the brackets to the switch

•Power Cord

• RS-232 console cable

• This Installation Guide

• Installation and Management Guide CD

• SMC Warranty Registration Card—be sure to complete and return to

SMC

Optional Rack-Mounting Equipment

If you plan to rack-mount the switch, be sure to have the following equipment available:

• Four mounting screws for each device you plan to install in a rack—these

are not included

• A screwdriver (Phillips or flathead, depending on the type of screws used)

3-3

NSTALLING THE SWITCH

Mounting

This switch can be mounted in a standard 19-inch equipment rack or on a desktop or shelf. Mounting instructions for each type of site follow.

Rack Mounting

Before rack mounting the switch, pay particular attention to the following factors:

• Temperature: Since the temperature within a rack assembly may be higher than the ambient room temperature, check that the rack-environment temperature is within the specified operating temperature range. (

• Mechanical Loading: Do not place any equipment on top of a rack-mounted unit.

• Circuit Overloading: Be sure that the supply circuit to the rack assembly is not overloaded.

• Grounding: Rack-mounted equipment should be properly grounded. Particular attention should be given to supply connections other than direct connections to the mains.

See page C-2.)

3-4

OUNTING

To rack-mount devices:

1. Attach the brackets to the device using the screws provided in the

Bracket Mounting Kit.

Figure 3-2 Attaching the Brackets

2. Mount the device in the rack, using four rack-mounting screws (not

provided).

Figure 3-3 Installing the Switch in a Rack

3-5

NSTALLING THE SWITCH

3. If installing a single switch only, turn to “Installing an Optional

Module into the Switch” at the end of this chapter.

4. If installing multiple switches, mount them in the rack, one below the

other, in any order.

5. If also installing RPUs, mount them in the rack below the other

devices.

Desktop or Shelf Mounting

1. Attach the four adhesive feet to the bottom of the first switch.

Figure 3-4 Attaching the Adhesive Feet

2. Set the device on a flat surface near an AC power source, making sure

there are at least two inches of space on all sides for proper air flow.

3. If installing a single switch only, go to “Installing an Optional Module

into the Switch” at the end of this chapter.

4. If installing multiple switches, attach four adhesive feet to each one.

Place each device squarely on top of the one below, in any order.

5. If also installing RPUs, place them close to the stack.

3-6

NSTALLING AN OPTIONAL

SFP T

Installing an Optional SFP Transceiver

Figure 3-5 Installing an SFP Transceiver into a Slot

The SFP slots support the following optional SFP transceivers:

• 1000BASE-SX

• 1000BASE-LX

• 1000BASE-LH

RANSCEIVER

To install an SFP transceiver, do the following:

1. Consider network and cabling requirements to select an appropriate

SFP transceiver type.

2. Insert the transceiver with the optical connector facing outward and

the slot connector facing down. Note that SFP transceivers are keyed so they can only be installed in one orientation.

3. Slide the SFP transceiver into the slot until it clicks into place.

Note: SFP transceivers are hot-swappable. The switch does not need to

be powered off before installing or removing a transceiver. However, always first disconnect the network cable before removing a transceiver.

Note: SFP transceivers are not provided in the switch package.

3-7

NSTALLING THE SWITCH

Installing an Optional Module into the Switch

Figure 3-6 Installing an Optional Module

Caution: DO NOT install slide-in modules with the switch powered on.

Be sure you power off the switch before installing any module.

To install an optional module into the switch, do the following:

1. Disconnect power to the switch.

2. Remove the blank metal plate (or a previously installed module) from

the appropriate port by removing the two screws with a flat-head screwdriver.

3. With the module still in the anti-static bag, touch the metal frame of

the switch to prevent damage caused by static electricity discharge. Also, it is recommended to use an ESD wrist strap during installation.

4. Remove the module from the anti-static shielded bag.

5. Holding the module level, guide it into the carrier rails on each side

and gently push it all the way into the port, ensuring that it firmly engages with the connector.

3-8

ONNECTING TO A POWER SOURCE

Connecting to a Power Source

To connect a switch to a power source:

1. Insert the power cable plug directly into the AC socket located at the

back of the switch.

Figure 3-7 Power Sockets

2. Plug the other end of the cable into a grounded, 3-pin, AC power

source.

Note: For International use, you may need to change the AC line

cord. You must use a line cord set that has been approved for the socket type in your country.

3. Check the front-panel LEDs as the device is powered on to be sure

the PWR LED is lit. If not, check that the power cable is correctly plugged in.

4. If you have purchased a Redundant Power Unit, connect it to the

switch and to an AC power source now, following the instructions included with the package.

3-9

NSTALLING THE SWITCH

Connecting to the Console Port

The DB-9 serial port on the switch’s front panel is used to connect to the switch for out-of-band console configuration. The command-line-driven configuration program can be accessed from a terminal or a PC running a terminal emulation program. The pin assignments used to connect to the serial port are provided in the following table.

Figure 3-8 Serial Port (DB-9 DTE) Pin-Out

6 9

Wiring Map for Serial Cable

Table 3-1 Serial Cable Wiring

Switch’s 9-Pin

Serial Port

2 RXD (receive data) <---------------------------- 3 TXD (transmit data)

3 TXD (transmit data) ----------------------------> 2 RXD (receive data)

5 SGND (signal ground) ------------------------------ 5 SGND (signal ground)

No other pins are used.

The serial port’s configuration requirements are as follows:

• Default Baud rate—9,600 bps

• Character Size—8 Characters

• Parity—None

• Stop bit—One

•Data bits—8

• Flow control—none

Null Modem PC’s 9-Pin

DTE Port

3-10

HAPTER

AKING

ETWORK

ONNECTIONS

Connecting Network Devices

The SMC8748L2 switch is designed to interconnect multiple segments (or collision domains). It can be connected to network cards in PCs and servers, as well as to hubs, switches or routers. It may also be connected to remote devices using the optional SFP tranceivers or optional 10GBASE module with XFP transceivers.

Twisted-Pair Devices

Each device requires an unshielded twisted pair (UTP) cable with RJ-45 connectors at both ends. Use Category 5, 5e or 6 cable for 1000BASE-T connections, Category 5 or better for 100BASE-TX connections, and Category 3 or better for 10BASE-T connections.

Cabling Guidelines

The RJ-45 ports on the switch support automatic MDI/MDI-X pinout configuration, so you can use standard straight-through twisted-pair cables to connect to any other network device (PCs, servers, switches, routers, or hubs).

See Appendix B for further information on cabling.

Caution: Do not plug a phone jack connector into an RJ-45 port. This will damage the switch. Use only twisted-pair cables with RJ-45 connectors that conform to FCC standards.

4-1

AKING NETWORK CONNECTIONS

Connecting to PCs, Servers, Hubs and Switches

1. Attach one end of a twisted-pair cable segment to the device’s RJ-45

connector.

Figure 4-1 Making Twisted-Pair Connections

2. If the device is a network card and the switch is in the wiring closet,

attach the other end of the cable segment to a modular wall outlet that is connected to the wiring closet. (See on page 4-3) Otherwise, attach the other end to an available port on the switch.

“Network Wiring Connections”

Make sure each twisted pair cable does not exceed 100 meters (328 ft) in length.

3. As each connection is made, the Link LED (on the switch)

corresponding to each port will light to indicate that the connection is valid.

Note: Avoid using flow control on a port connected to a hub unless it is

actually required to solve a problem. Otherwise back pressure jamming signals may degrade overall performance for the segment attached to the hub.

4-2

WISTED-PAIR DEVICES

Network Wiring Connections

Today, the punch-down block is an integral part of many of the newer equipment racks. It is actually part of the patch panel. Instructions for making connections in the wiring closet with this type of equipment follows.

1. Attach one end of a patch cable to an available port on the switch, and

the other end to the patch panel.

2. If not already in place, attach one end of a cable segment to the back

of the patch panel where the punch-down block is located, and the other end to a modular wall outlet.

3. Label the cables to simplify future troubleshooting. See “Cable

Labeling and Connection Records” on page 4-9.

Figure 4-2 Network Wiring Connections

4-3

AKING NETWORK CONNECTIONS

Fiber Optic SFP and XFP Devices

An optional Gigabit SFP transceiver (1000BASE-SX, 1000BASE-LX, or 1000BASE-LH) or an optional 10-Gigabit Ethernet module with XFP transceiver (10GBASE-SR, 10GBASE-LR, or 10GBASE-ER) can be used for a backbone connection between switches, or for connecting to a high-speed server.

Each single-mode fiber port requires 9/125 micron single-mode fiber optic cable with an LC connector at both ends. Each multimode fiber optic port requires 50/125 or 62.5/125 micron multimode fiber optic cabling with an LC connector at both ends.

Warning: This switch uses lasers to transmit signals over fiber optic

cable. The lasers are compliant with the requirements of a Class 1 Laser Product and are inherently eye safe in normal operation. However, you should never look directly at a transmit port when it is powered on.

Note: When selecting a fiber SFP device, considering safety, please make

sure that it can function at a temperature that is not less than the recommended maximum operational temperature of the product. You must also use an approved Laser Class 1 SFP transceiver.

Hinweis: Bei der Wahl eines Glasfasertransceivers muß für die

Beurteilung der Gesamtsicherheit beachtet werden, das die maximale Umgebungstemperatur des Transceivers für den Betrieb nicht niedriger ist als die für dieses Produkts. Der Glasfasertransceiver muß auch ein überprüftes Gerät der Laser Klasse 1 sein.

1. Remove and keep the LC port’s rubber plug. When not connected to a

fiber cable, the rubber plug should be replaced to protect the optics.

4-4

IBER OPTIC

2. Check that the fiber terminators are clean. You can clean the cable

plugs by wiping them gently with a clean tissue or cotton ball moistened with a little ethanol. Dirty fiber terminators on fiber optic cables will impair the quality of the light transmitted through the cable and lead to degraded performance on the port.

3. Connect one end of the cable to the LC port on the switch and the

other end to the LC port on the other device. Since LC connectors are keyed, the cable can be attached in only one orientation.

SFP

AND

XFP D

EVICES

Figure 4-3 Making Fiber Port Connections

4. As a connection is made, check the Link LED on the switch

corresponding to the port to be sure that the connection is valid.

The 1000BASE-SX, 1000BASE-LX, 1000BASE-LH fiber optic ports operate at 1 Gbps, full duplex, with auto-negotiation of flow control. The maximum length for fiber optic cable operating at Gigabit speed will depend on the fiber type as listed under “10 Gbps Ethernet Collision Domain” on page 4-7.

4-5

AKING NETWORK CONNECTIONS

The optional 10GBASE module operates at 10 Gbps full duplex. The maximum length for fiber optic cable operating at 10 Gbps speed will depend on the fiber type as listed under “10 Gbps Ethernet Collision Domain” on page 4-7

Connectivity Rules

When adding hubs (repeaters) to your network, please follow the connectivity rules listed in the manuals for these products. However, note that because switches break up the path for connected devices into separate collision domains, you should not include the switch or connected cabling in your calculations for cascade length involving other devices.

1000BASE-T Cable Requirements

All Category 5 UTP cables that are used for 100BASE-TX connections should also work for 1000BASE-T, providing that all four wire pairs are connected. However, it is recommended that for all critical connections, or any new cable installations, Category 5e (enhanced Category 5) or Category 6 cable should be used. The Category 5e and 6 specifications include test parameters that are only recommendations for Category 5. Therefore, the first step in preparing existing Category 5 cabling for running 1000BASE-T is a simple test of the cable installation to be sure that it complies with the IEEE 802.3-2002 standards.

4-6

10 Gbps Ethernet Collision Domain

Table 4-1 Maximum 10GBASE-SR 10 Gigabit Ethernet Cable Length

Fiber Size Fiber

62.5/125 micron single-mode fiber

50/125 micron single-mode fiber

Table 4-2 Maximum 10GBASE-ER 10 Gigabit Ethernet Cable Length

Fiber Size Fiber

9/125 micron single-mode fiber

Table 4-3 Maximum 10GBASE-LR 10 Gigabit Ethernet Cable Length

Fiber Size Fiber

9/125 micron single-mode fiber

Bandwidth

160 MHz/km 2-26 m

200 MHz/km 2-33 m

400 MHz/km 2-66 m

500 MHz/km 2-82 m

2000 MHz/km 2-300 m

Bandwidth

N/A 40 km

Bandwidth

N/A 10 km (6.2 miles) LC

ONNECTIVITY RULES

Maximum Cable Length

(6.56-85.3 ft.)

(6.56-108.26 ft.)

(6.56-216.54 ft.)

(6.56-269 ft.)

(6.56-984.25 ft.)

Maximum Cable Length

(24.85 miles)

Maximum Cable Length

Connector

1000 Mbps Gigabit Ethernet Collision Domain

Table 4-4 Maximum 1000BASE-T Gigabit Ethernet Cable Length

Cable Type Maximum Cable

Length

Category 5, 5e, or 6 100-ohm UTP or STP 100 m (328 ft) RJ-45

Connector

4-7

AKING NETWORK CONNECTIONS

Table 4-5 Maximum 1000BASE-SX Gigabit Ethernet Cable Lengths

Fiber Size Fiber

62.5/125 micron multimode fiber

50/125 micron multimode fiber

Table 4-6 Maximum 1000BASE-LX Gigabit Ethernet Cable Length

Fiber Size Fiber

9/125 micron single-mode fiber

Table 4-7 Maximum 1000BASE-LH Gigabit Ethernet Cable Length

Fiber Size Fiber

9/125 micron single-mode fiber

Bandwidth

160 MHz/km 2-220 m (7-722 ft) LC

200 MHz/km 2-275 m (7-902 ft) LC

400 MHz/km 2-500 m (7-1641 ft) LC

500 MHz/km 2-550 m (7-1805 ft) LC

Bandwidth

N/A 2 m - 5 km

Bandwidth

N/A 2 - 70 km

Maximum Cable Length

(7 ft - 3.2 miles)

Maximum Cable Length

(7 - 43.5 miles)

100 Mbps Fast Ethernet Collision Domain

Connector

Table 4-8 Maximum Fast Ethernet Cable Length

Type Cable Type Max. Cable Length Connector

100BASE-TX Category 5 or better

100-ohm UTP or STP

100 m (328 ft) RJ-45

10 Mbps Ethernet Collision Domain

Table 4-9 Maximum Ethernet Cable Length

Type Cable Type Maximum Length Connector

10BASE-T Categories 3, 4, 5 or

better 100-ohm UTP

100 m (328 ft) RJ-45

4-8

ABLE LABELING AND CONNECTION RECORDS

Cable Labeling and Connection Records

When planning a network installation, it is essential to label the opposing ends of cables and to record where each cable is connected. Doing so will enable you to easily locate inter-connected devices, isolate faults and change your topology without need for unnecessary time consumption.

To best manage the physical implementations of your network, follow these guidelines:

• Clearly label the opposing ends of each cable.

• Using your building’s floor plans, draw a map of the location of all

network-connected equipment. For each piece of equipment, identify the devices to which it is connected.

• Note the length of each cable and the maximum cable length supported

by the switch ports.

• For ease of understanding, use a location-based key when assigning

prefixes to your cable labeling.

• Use sequential numbers for cables that originate from the same

equipment.

• Differentiate between racks by naming accordingly.

• Label each separate piece of equipment.

• Display a copy of your equipment map, including keys to all

abbreviations at each equipment rack.

4-9

AKING NETWORK CONNECTIONS

4-10

PPENDIX

ROUBLESHOOTING

Diagnosing Switch Indicators

Table A-1 Troubleshooting Chart

Symptom Action

PWR LED is Off

PWR LED is Amber • Internal power supply has failed.

Diag LED is Flashing Amber

Link LED is Off • Verify that the switch and attached device are powered on.

• Check connections between the switch, the power cord and the wall outlet.

•Contact your dealer for assistance.

• Contact your local dealer for assistance.

• Power cycle the switch to try and clear the condition

• If the condition does not clear, contact your dealer for assistance

• Be sure the cable is plugged into both the switch and corresponding device.

• If the switch is installed in a rack, check the connections to the punch-down block and patch panel.

• Verify that the proper cable type is used and its length does not exceed specified limits.

• Check the adapter on the attached device and cable connections for possible defects. Replace the defective adapter or cable if necessary.

A-1

ROUBLESHOOTING

Diagnosing Power Problems with the LEDs

The Power and RPU LEDs work in combination to indicate power status as follows.

Table A-2 Power/RPU LEDs

Power LED RPU LED Status

Green Green Internal power functioning normally; RPU is present.

Green Amber Internal power functioning normally; RPU plugged in but

faulty.

Green Off Internal power functioning normally; RPU not plugged in.

Amber Green Internal power faulty; RPU delivering power.

Off Off Both internal power and RPU unplugged or not functioning.

Power and Cooling Problems

If the power indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply. However, if the unit powers off after running for a while, check for loose power connections, power losses or surges at the power outlet. If you still cannot isolate the problem, the internal power supply may be defective.

Installation

Verify that all system components have been properly installed. If one or more components appear to be malfunctioning (such as the power cord or network cabling), test them in an alternate environment where you are sure that all the other components are functioning properly.

A-2

IN-B

In-Band Access

You can access the management agent in the switch from anywhere within the attached network using Telnet, a web browser, or other network management software tools. However, you must first configure the switch with a valid IP address, subnet mask, and default gateway. If you have trouble establishing a link to the management agent, check to see if you have a valid network connection. Then verify that you entered the correct IP address. Also, be sure the port through which you are connecting to the switch has not been disabled. If it has not been disabled, then check the network cabling that runs between your remote location and the switch.

Note: The management agent accepts up to four simultaneous Telnet

sessions. If the maximum number of sessions already exists, an additional Telnet connection will not be able to log into the system.

AND ACCESS

A-3

ROUBLESHOOTING

A-4

PPENDIX

ABLES

Twisted-Pair Cable and Pin Assignments

For 10/100BASE-TX connections, a twisted-pair cable must have two pairs of wires. For 1000BASE-T connections the twisted-pair cable must have four pairs of wires. Each wire pair is identified by two different colors. For example, one wire might be green and the other, green with white stripes. Also, an RJ-45 connector must be attached to both ends of the cable.

Caution: Each wire pair must be attached to the RJ-45 connectors in a

specific orientation.

Caution: DO NOT plug a phone jack connector into any RJ-45 port.

This will damage the switch. Use only twisted-pair cables with RJ-45 connectors that conform with FCC standards.

The figure below illustrates how the pins on the RJ-45 connector are numbered. Be sure to hold the connectors in the same orientation when attaching the wires to the pins.

Figure B-1 RJ-45 Connector Pin Numbers

B-1

ABLES

10BASE-T/100BASE-TX Pin Assignments

Use unshielded twisted-pair (UTP) or shielded twisted-pair (STP) cable for RJ-45 connections: 100-ohm Category 3 or better cable for 10 Mbps connections, or 100-ohm Category 5 or better cable for 100 Mbps connections. Also be sure that the length of any twisted-pair connection does not exceed 100 meters (328 feet).

The RJ-45 ports on the switch base unit support automatic MDI/MDI-X operation, you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs. In straight-through cable, pins 1, 2, 3, and 6, at one end of the cable, are connected straight through to pins 1, 2, 3, and 6 at the other end of the cable. When using any RJ-45 port on this switch, you can use either straight-through or crossover cable.

Table B-1 10/100BASE-TX MDI and MDI-X Port Pinouts

Pin MDI Signal Name MDI-X Signal Name

1 Transmit Data (TD+) Receive Data (RD+)

2 Transmit Data (TD-) Receive Data (RD-)

4,5,7,8

Note: The “+” and “-” signs represent the polarity of the wires that

Receive Data (RD+) Transmit Data (TD+)

Receive Data (RD-) Transmit Data (TD-)

Not used Not used

make up each wire pair.

B-2

WISTED-PAIR CABLE AND PIN ASSIGNMENTS

Straight-Through Wiring

If the twisted-pair cable is to join two ports and only one of the ports has an internal crossover (MDI-X), the two pairs of wires must be straight-through. (When auto-negotiation is enabled for any RJ-45 port on this switch, you can use either straight-through or crossover cable to connect to any device type.)

You must connect all four wire pairs as shown in the following diagram to support Gigabit Ethernet connections.

EIA/TIA 568B RJ-45 Wiring Standard

10/100BASE-TX Straight-through Cable

White/Orange Stripe

Orange

End A

1 2 3 4 5 6 7 8

White/Green Stripe

Blue

White/Blue Stripe

Green

White/Brown Stripe

Brown

1 2 3 4 5 6 7 8

End B

Figure B-2 Straight-through Wiring

B-3

ABLES

Crossover Wiring

If the twisted-pair cable is to join two ports and either both ports are labeled with an “X” (indicating MDI-X) or neither port is labeled with an “X” (which indicates MDI), a crossover must be implemented in the wiring. (When auto-negotiation is enabled for any RJ-45 port on this switch, you can use either straight-through or crossover cable to connect to any device type.)

You must connect all four wire pairs as shown in the following diagram to support Gigabit Ethernet connections.

EIA/TIA 568B RJ-45 WiringStandard

10/100BASE-TX Crossover Cable

White/Orange Stripe

Orange

End A

1 2 3 4 5 6 7 8

White/Green Stripe

Blue

White/Blue Stripe

Green

White/Brown Stripe

Brown

1 2 3 4 5 6 7 8

End B

B-4

Figure B-3 Crossover Wiring

WISTED-PAIR CABLE AND PIN ASSIGNMENTS

1000BASE-T Pin Assignments

All 1000BASE-T ports support automatic MDI/MDI-X operation, so you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs.

The table below shows the 1000BASE-T MDI and MDI-X port pinouts. These ports require that all four pairs of wires be connected. Note that for 1000BASE-T operation, all four pairs of wires are used for both transmit and receive.

Use 100-ohm Category 5, 5e or 6 unshielded twisted-pair (UTP) or shielded twisted-pair (STP) cable for 1000BASE-T connections. Also be sure that the length of any twisted-pair connection does not exceed 100 meters (328 feet).

Table B-2 1000BASE-T MDI and MDI-X Port Pinouts

Pin MDI Signal Name MDI-X Signal Name

1 Bi-directional Data One Plus (BI_D1+) Bi-directional Data Two Plus (BI_D2+)

2 Bi-directional Data One Minus (BI_D1-) Bi-directional Data Two Minus (BI_D2-)

3 Bi-directional Data Two Plus (BI_D2+) Bi-directional Data One Plus (BI_D1+)

4 Bi-directional Data Three Plus (BI_D3+) Bi-directional Data Four Plus (BI_D4+)

5 Bi-directional Data Three Minus (BI_D3-) Bi-directional Data Four Minus (BI_D4-)

6 Bi-directional Data Two Minus (BI_D2-) Bi-directional Data One Minus (BI_D1-)

7 Bi-directional Data Four Plus (BI_D4+) Bi-directional Data Three Plus (BI_D3+)

8 Bi-directional Data Four Minus (BI_D4-) Bi-directional Data Three Minus (BI_D3-)

Cable Testing for Existing Category 5 Cable

Installed Category 5 cabling must pass tests for Attenuation, Near-End Crosstalk (NEXT), and Far-End Crosstalk (FEXT). This cable testing information is specified in the ANSI/TIA/EIA-TSB-67 standard. Additionally, cables must also pass test parameters for Return Loss and Equal-Level Far-End Crosstalk (ELFEXT). These tests are specified in the ANSI/TIA/EIA-TSB-95 Bulletin, “The Additional Transmission Performance Guidelines for 100 Ohm 4-Pair Category 5 Cabling.”

B-5

ABLES

Note that when testing your cable installation, be sure to include all patch cables between switches and end devices.

Adjusting Existing Category 5 Cabling to Run 1000BASE-T

If your existing Category 5 installation does not meet one of the test parameters for 1000BASE-T, there are basically three measures that can be applied to try and correct the problem:

1. Replace any Category 5 patch cables with high-performance Category 5e or Category 6 cables.

2. Reduce the number of connectors used in the link.

3. Reconnect some of the connectors in the link.

Fiber Standards

The current TIA (Telecommunications Industry Association) 568-A specification on optical fiber cabling consists of one recognized cable type for horizontal subsystems and two cable types for backbone subsystems.

Horizontal 62.5/125 micron multimode (two fibers per outlet). Backbone 62.5/125 micron multimode or single-mode.

TIA 568-B will allow the use of 50/125 micron multimode optical fiber in both the horizontal and backbone in addition to the types listed above. All optical fiber components and installation practices must meet applicable building and safety codes.

B-6

PPENDIX

PECIFICATIONS

Physical Characteristics

Ports

48 10/100/1000BASE-T, with auto-negotiation 4 Combination Ports (RJ-45/SFP)

Media Slots

2 slots for optional 10GBASE modules that support XFP transceivers

Network Interface

Ports 1-48: RJ-45 connector, auto MDI/X

10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better) 100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better) 1000BASE-T: RJ-45 (100-ohm, UTP or STP cable; Category 5, 5e or 6)

Buffer Architecture

1.5 Mbyte

Aggregate Bandwidth

136 Gbps

Switching Database

8K MAC address entries

LEDs

System: PWR (Power Supply), Diag (Diagnostic),

RPU (Redundant Power Unit), M1 (Module 1), M2 (Module 2)

Port: Link/Act (Link/Activity)

Weight

5.05 kg (11.13 lbs.)

C-1

PECIFICATIONS

Size

44.0 x 41.5 x 4.4 cm (17.4 x 16.4 x 1.8 in.)

Temp er at ur e

Operating: 0 °C to 50 °C (32 °F to 122 °F) Storage: -40°C to 70°C (-40°F to 158°F)

Humidity

Operating: 5% to 95% (non-condensing)

AC Input

100 to 240 V, 50-60 Hz, 2A

Power Supply

Internal, auto-ranging transformer: 100 to 240 VAC, 50 to 60 Hz, 2A External, supports a 14-pin connection for a redundant power supply

Power Consumption

105 Watts maximum

Maximum Current

1.6 A @ 110 VAC

0.6 A @ 230 VAC

Switch Features

Forwarding Mode

Store-and-forward

Throughput

Wire speed

Flow Control

Full Duplex: IEEE 802.3-2002 Half Duplex: Back pressure

C-2

Management Features

In-Band Management

Web, Telnet, SSH, or SNMP manager

Out-of-Band Management

RS-232 DB-9 console port

Software Loading

TFTP in-band, or XModem out-of-band

Standards

IEEE 802.3-2002

Ethernet, Fast Ethernet, Gigabit Ethernet Full-duplex flow control

IEEE 802.3ae 10-Gigabit Ethernet IEEE 802.1D Spanning Tree Protocol IEEE 802.1w Rapid Spanning Tree Protocol ISO/IEC 8802-3

ANAGEMENT FEATURES

Compliances

CE Mark

Emissions

FCC Class A Industry Canada Class A EN55022 (CISPR 22) Class A EN 61000-3-2/3 VCCI Class A C-Tick - AS/NZS 3548 (1995) Class A

Immunity

EN 61000-4-2/3/4/5/6/8/11

C-3

PECIFICATIONS

Safety

CSA/CUS (UL60950-1, CSA22.2 NO60950-1) CB (IEC 60950-1)

Warr anty

Limited Lifetime

10GBASE Extender Module

Ports

1 port for XFP transceivers

Communication Speed

10 Gbps

Communication Mode

Full duplex

Network Interface

Single-mode transceiver: 9/125 micron single-mode fiber cable Multimode transceiver: 50/125 or 62.5/125 micron multimode fiber cable

Standards

IEEE 802.3ae 10-Gigabit Ethernet

C-4

PPENDIX

ERMAN INSTRUCTIONS

Eine Site auswahlen

Die Schalter konnen in ein Standard-19-Zoll-Ausrustungsgestell oder auf eine flache Ebene montiert werden.

Zum Auswahlen eines Standortes beachten Sie bitte die nachstehenden Richtlinien.

• Die Site sollte:

- sich in der Mitte aller anzuschliesenden Gerate sowie in der Nahe einer Netzsteckdose befinden;

- imstande sein, eine Temperatur zwischen 0 und 50 °C (32 und 122 °F) und eine Feuchtigkeit innerhalb von 5% bis 95% (nichtkondensierend) beizubehalten;

- in einem genugend weiten Abstand (ungefahr 5 cm oder zwei Zoll) von allen Seiten fur eine ausreichende Beluftung aufgestellt werden;

- fur das Installieren, die Kabelverlegung und fur Wartungen und Reparaturen leicht zuganglich sein;

- die LED-Statusanzeigedioden mussen stets klar und leicht sichtbar sein.

• Sicherstellen, dass das verdrehte Kabel stets weg von anderen Stromkabeln, Neonleuchteinrihtungen und anderen Quellen von moglichen elektrischen Storungen verlegt wird, wie z. B. von Radios und Transmittern.

D-1

ERMAN INSTRUCTIONS

• Sicherstellen, dass das Gerat an eine separate Stromquelle mit Erdanschlus mit einer Netzspannung von 100 bis 240 V AC (Wechselstromspannung), 50 bis 60 Hz, und innerhalb in einem Abstand von 2,44 m (8 Fus) zu jedem Gerat installiert wird und on einem separaten Trennschalter bzw. Leistungsschalter mit Strom versorgt wird. Fur alle Gerate wird empfohlen, einen Filter oder einen

Montage (Rack Mounting Instructions - German)

SMC8748L2 Switch-Einheiten können an ein standardmäßiges 19-Zoll Einrichtungsrack, einen Arbeitstisch oder ein Regal montiert werden. Folgend finden Sie die Montageanweisungen für jeden Positionstyp.

Rack-Montage

Beachten Sie die folgenden Faktoren, bevor Sie die Rack-Montage beginnen:

• Temperatur: Da die Temperatur innerhalb einer Rackeinheit höher als die Raumumgebungstemperatur sein kann, stellen Sie bitte sicher, dass die Rackumgebungstemperatur innerhalb des angegebenen Betriebstemperaturbereichs liegt. (Siehe "Temperatur" auf Seite C-2.)

• Mechanische Last: Stellen Sie kein Gerät auf eine Rack-Montageeinheit.

• Stromüberlastung: Stellen Sie sicher, dass der Netzkreis der Rackeinheit nicht überlastet wird.

• Erdung: Die Rack-Montageeinheit muss richtig geerdet werden. Besondere Acht sollten Sie bei Verbindungen geben, die nicht direkt zum Netz führen.

D-2

ONTAGE

So montieren Sie Geräte an ein Rack:

1. Befestigen Sie die Metallwinkel mit den im Metallwinkel-Montageset

erhältlichen Schrauben an dem Gerät.

2. Befestigen Sie das Gerät mit vier Rackmontageschrauben (nicht

beigelegt) an dem Rack.

3. Wenn Sie nur einen Switch installieren, dann springen Sie bitte über zu

"Verbinden mit einer Stromquelle" auf Seite 3-8 am Ende dieses Kapitels.

4. Wenn Sie mehrere Switches installieren möchten, dann montieren Sie

sie untereinander in einer beliebigen Reihenfolge.

ACK MOUNTING INSTRUCTIONS

- G

ERMAN

)

D-3

ERMAN INSTRUCTIONS

D-4

LOSSARY

10BASE-T

IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3, 4, or 5 UTP cable.

100BASE-TX

IEEE 802.3u specification for 100 Mbps Ethernet over two pairs of Category 5 UTP cable.

1000BASE-LH

Specification for long-haul Gigabit Ethernet over two strands of 9/125 micron core fiber cable.

1000BASE-LX

IEEE 802.3z specification for Gigabit Ethernet over two strands of 50/ 125, 62.5/125 or 9/125 micron core fiber cable.

1000BASE-SX

IEEE 802.3z specification for Gigabit Ethernet over two strands of 50/ 125 or 62.5/125 micron core fiber cable.

1000BASE-T

IEEE 802.3ab specification for Gigabit Ethernet over 100-ohm Category 5, 5e or 6 twisted-pair cable (using all four wire pairs).

10GBASE

IEEE 802.3ae specification for 10-Gigabit Ethernet over two strands of 50/125, 62.5/125 or 9/125 micron core fiber cable.

Glossary-1

Auto-Negotiation

Signalling method allowing each node to select its optimum operational mode (e.g., 10, 100 or 1000 Mbps, and half or full duplex) based on the capabilities of the node to which it is connected.

Bandwidth

The difference between the highest and lowest frequencies available for network signals. Also synonymous with wire speed, the actual speed of the data transmission along the cable.

Collision

A condition in which packets transmitted over the cable interfere other. Their interference makes both signals unintelligible.

Collision Domain

Single CSMA/CD LAN segment.

CSMA/CD

CSMA/CD (Carrier Sense Multiple Access/Collision Detect) is the communication method employed by Ethernet, Fast Ethernet, and Gigabit Ethernet.

with each

End Station

A workstation, server, or other device that does not forward traffic.

Ethernet

A network communication system developed and standardized by DEC, Intel, and Xerox, using baseband transmission, CSMA/CD access, logical bus topology, and coaxial cable. The successor IEEE 802.3 standard provides for integration into the OSI model and extends the physical layer and media with repeaters and implementations that operate on fiber, thin coax and twisted-pair cable.

Glossary-2

Fast Ethernet

A 100 Mbps network communication system based on Ethernet and the CSMA/CD access method.

Full Duplex

Transmission method that allows two network devices to transmit and receive concurrently, effectively doubling the bandwidth of that link.

Gigabit Ethernet

A 1000 Mbps network communication system based on Ethernet and the CSMA/CD access method.

IEEE

Institute of Electrical and Electronic Engineers.

IEEE 802.3

Defines carrier sense multiple access with collision detection (CSMA/CD) access method and physical layer specifications.

IEEE 802.3ab

Defines CSMA/CD access method and physical layer specifications for 1000BASE-T Gigabit Ethernet. (Now incorporated in IEEE 802.3-2002.)

IEEE 802.3ae

Defines the access method and physical layer specifications for 10GBASE 10-Gigabit Ethernet.

IEEE 802.3u

Defines CSMA/CD access method and physical layer specifications for 100BASE-TX Fast Ethernet. (Now incorporated in IEEE 802.3-2002.)

Glossary-3

IEEE 802.3x

Defines Ethernet frame start/stop requests and timers used for flow control on full-duplex links. (Now incorporated in IEEE 802.3-2002.)

IEEE 802.3z

Defines CSMA/CD access method and physical layer specifications for 1000BASE Gigabit Ethernet. (Now incorporated in IEEE 802.3-2002.)

LAN Segment

Separate LAN or collision domain.

LED

Light emitting diode used for monitoring a device or network condition.

Local Area Network (LAN)

A group of interconnected computer and support devices.

Media Access Control (MAC)

A portion of the networking protocol that governs access to the transmission medium, facilitating the exchange of data between network nodes.

MIB

An acronym for Management Information Base. It is a set of database objects that contains information about the device.

Modal Bandwidth

Bandwidth for multimode fiber is referred to as modal bandwidth because it varies with the modal field (or core diameter) of the fiber. Modal bandwidth is specified in units of MHz per km, which indicates the amount of bandwidth supported by the fiber for a one km distance.

Glossary-4

Network Diameter

Wire distance between two end stations in the same collision domain.

Redundant Power Supply (RPS)

A backup power supply unit that automatically supplies power should the primary power supply fail.

RJ-45 Connector

A connector for twisted-pair wiring.

Switched Ports

Ports that are on separate collision domains or LAN segments.

TIA

Telecommunications Industry Association

Transmission Control Protocol/Internet Protocol (TCP/IP)

Protocol suite that includes TCP as the primary transport protocol, and IP as the network layer protocol.

UTP

Unshielded twisted-pair cable.

Virtual LAN (VLAN)

A Virtual LAN is a collection of network nodes that share the same collision domain regardless of their physical location or connection point in the network. A VLAN serves as a logical workgroup with no physical barriers, allowing users to share information and resources as though located on the same LAN.

Glossary-5

Glossary-6

NDEX

Numerics

10 Gbps connectivity rules 4-7 10 Mbps connectivity rules 4-8 100 Mbps connectivity rules 4-8 1000 Mbps connectivity rules 4-7 1000BASE-LX fiber cable lengths 4-8 1000BASE-SX fiber cable lengths 4-8 1000BASE-ZX fiber cable lengths 4-8 100BASE cable lengths 4-8 100BASE-TX ports 1-3, 1-4 10BASE-T ports 1-3, 1-4 10GBASE-ER fiber cable length 4-7 10GBASE-LR fiber cable length 4-7 10GBASE-SR fiber cable length 4-7

adhesive feet, attaching 3-6 air flow requirements 3-1 applications

central wiring closet 2-3 collapsed backbone 2-2 remote connections with fiber 2-4 VLAN connections 2-5

cleaning fiber terminators 4-5 compliances

EMC C-3 safety C-4

connectivity rules

10 Gbps 4-7 10 Mbps 4-8 100 Mbps 4-8 1000 Mbps 4-7

console port

pin assignments 3-10 contents of package 3-3 cooling problems A-2 cord sets, international 3-9

desktop mounting 3-6 device connections 4-1

electrical interference, avoiding 3-1 equipment checklist 3-3 Ethernet connectivity rules 4-7, 4-8

brackets, attaching 3-5 buffer size C-1 buffers, saturation of 1-3

cable

Ethernet cable compatibility 3-2 fiber standards B-6 labeling and connection records 4-9 lengths 4-8

Fast Ethernet connectivity rules 4-8 features C-3

management 1-9

switch 1-8 fiber cables 4-4 flow control, IEEE 802.3x 1-3 front panel of switch 1-2 full duplex connectivity 2-1

Index-1

NDEX

Gigabit Ethernet cable lengths 4-7 grounding for racks 3-4

IEEE 802.3 Ethernet 1-8 IEEE 802.3ae 10 Gigabit Ethernet 1-8 IEEE 802.3u Fast Ethernet 1-8 IEEE 802.3x flow control 1-3 IEEE 802.3z Gigabit Ethernet 1-8 indicators, LED 1-4 installation

connecting devices to the switch 4-2 desktop or shelf mounting 3-6 network wiring connections 4-3 port connections 4-1, 4-4 power requirements 3-1 problems A-2 site requirements 3-1, D-1 wiring closest connections 4-3

laser safety 4-4 LC port connections 4-4 LED indicators

Diag 1-5 Link 1-5, 1-7 problems A-1 RPU 1-6

location requirements 3-1, D-1

management

agent 1-3 features 1-9, C-3 SNMP 1-3

mounting the switch

on a desktop or shelf 3-6

multimode fiber optic cables 4-4

network

connections 4-1, 4-4

package contents 3-3 pin assignments B-1

1000BASE-T B-5 10BASE-T/100BASE-TX B-2 console port 3-10 DB-9 3-10

port saturation 1-3 ports, connecting to 4-1, 4-4 power, connecting to 3-9 problems, troubleshooting A-1

rear panel of switch 1-2 rear panel receptacles 1-6 RJ-45 port 1-3, 1-4

connections 4-1 pinouts B-5

RPU

connecting 3-9 installing in a rack 3-6 installing on a desktop 3-6

rubber foot pads, attaching 3-6

screws for rack mounting 3-3 single-mode fiber optic cables 4-4 site selelction 3-1

Index-2

NDEX

SNMP agent 1-3 specifications

compliances C-3 environmental C-2 physical C-1 power C-2

standards

compliance C-3

IEEE C-3, C-4 status LEDs 1-4 switch architecture 1-2 switching

introduction to 2-1 method 1-2

Telnet A-3 temperature within a rack 3-4 troubleshooting

in-band access A-3 power and cooling problems A-2 switch indicators A-1

twisted-pair connections 4-1

Index-3

NDEX

Index-4

FOR TECHNICAL SUPPORT, CALL:

From U.S.A. and Canada (24 hours a day, 7 days a week)

(800) SMC-4-YOU; Phn: (949) 679-8000; Fax: (949) 679-1481

From Europe: Contact details can be found on www.smc.com

INTERNET

E-mail addresses:

techsupport@smc.com

Driver updates:

http://www.smc.com/index.cfm?action=tech support drivers downloads

World Wide Web:

http://www.smc.com/

FOR LITERATURE OR ADVERTISING RESPONSE, CALL:

U.S.A. and Canada: (800) SMC-4-YOU Fax (949) 679-1481 Spain: 34-91-352-00-40 Fax 34-93-477-3774 UK: 44 (0) 871 277 98 02 Fax 44 (0) 1234 831 413 France: 33 (0) 1 55 64 04 55 Fax 33 (0) 45 34 68 58 Italy: 39 02 739 12 68 Fax 39 02 739 14 17 Benelux: 31 (0) 654 776 790 Fax 31 (0) 172 242 393 Central Europe: 49 (0) 89 92861-0 Fax 49 (0) 89 92861-230 Nordic and Baltics: 46 (0) 566 622 83 Fax 45 (0) 566 622 86 Eastern Europe: 420 266 794 421 Fax 420 266 794 423 Sub-Saharian Africa: 27 012 661 0232 Fax 34 93 471 3374 North West Africa: 34 93 477 4920 Fax 34 93 477 3774 CIS: 34 93 477 4920 Fax 34 93 477 3774 PRC: 86-10-6235-4958 Fax 86-10-6235-4962 Taiwan: 886-2-8797-8006 Fax 886-2-8797-6288 Asia Pacific: (65) 238 6556 Fax (65) 238 6466 Korea: 82-2-553-0860 Fax 82-2-553-7202 Japan: 81-45-224-2332 Fax 81-45-224-2331 Australia: 61-2-8875-7887 Fax 61-2-8875-7777 India: 91-22-8204437 Fax 91-22-8204443

If you are looking for further contact information, please visit www.smc.com.

38 Tesla Irvine, CA 92618 Phone: (949) 679-8000

Model Numbers: SMC8748L2 Publication Number: 150200053300A E102005-R01

Smc 8748L2 INSTALLATION GUIDE
