Smartwares RM218, 10.006.74 User guide [ml]

RM218 - 10.006.74

Users manual 4 - 140

GB

Gebrauchsanweisung 15 - 26

DE

NL

Gebruikershandleiding 27 - 37

1

Activate - Aktivieren - Activar = 5sec.

Test - Prüfung - Prueba = 1x

LED

-1-

2

3

4

a

b

5

Lock - Fixierstift

Fijación pin

-2-

0cm

10

Test - Prüfung - Prueba

MINIMUM

MINIMUM

EXTRA

ATTIC/BODEN/ZOLDER/MANSARD/PODDASZE/ÁTICO

GROUND/ERDGESCHOSS/BEGANEGROND/Pr.ETAGE/PARTER/PLANTA BAJA

EXTRA

50cm

Entree

Test - Prüfung - Prueba

-3-

GB

1. General product information:
The smoke alarm device, if properly installed and maintained,
sounds the alarm at an early stage of the fire. This can give
you those extra valuable seconds to evacuate your home and
call the fire department. The smoke alarm device works with
an 3V lithium battery. Under normal conditions the service life
of the battery is up to 10 years. When the battery is (almost)
empty, the smoke detector indicates this by an audible “beep”.
This indicator sounds every 30-40 seconds during minimum 30
days. End of life, replace complete smoke alarm device!

2. Make/model number: Smartwares RM218

3. Power supply: 3V DC CR123A Lithium
(not replaceable battery)

4. Certification marks:

5. Scope of application: Smoke alarm device for buildings with
residential function.

SMOKE ALARM DEVICE

IMPORTANT INFORMATION

0786
RM218-001CPR
14
EN14604:2005/AC:2008
Smartwares RM218

-4-

G214064

6. Function: Gives a warning when smoke caused by a fire is
detected.

7. Description: Smoke alarm device based on the photocell
principle, which means that the alarm monitors the air for
smoke caused by fire. smoke alarm device does not detect
heat, gas or fire.

8. Advice: Keep these instructions in a safe,
easily accessible place.

9. Caution: The alarm is designed in order to detect smoke; it
cannot prevent a fire.

10.Caution: The smoke alarm device should not be painted.
Protect the smoke alarm device from dust during renovation

work.

11.Caution: The smoke alarm device should not be
taped/covered (this causes loss of functionality).

12.Caution: Keep the smoke alarm device out of the reach of
children.

Press test button (1) and hold it for above 5 seconds until LED
lights, and release it within 1 second, the unit will generate a
“beep” indicates that it is activated and goes into work status.
CAUTION: Activate smoke alarm first or else there is no function
for this unit.

Test the unit to ensure proper operation by pressing the test
button, this will sound the alarm if the electronic circuitry, horn,
and battery are working. If no alarm sounds, there is a defective
battery or other failure.

ACTIVATION

TESTING

-5-

NOTE: WEEKLY TESTING IS REQUIERED
DO NOT: Use an open flame to test your alarm, you could

damage the alarm or ignite combustible materials and start a fire.
CAUTION: Due to the loudness (85 decibels) of the alarm.

Always stand an arms-length always from the unit when testing.
Test the alarm weekly to ensure proper operation. Erratic or low
sound coming from your alarm may indicate a defective alarm.

1. What is the best place to mount a smoke alarm device

* In the middle of the ceiling but at least 50cm from every edge.
* At least one on each floor.
* In every bedroom.
* In the hallway and stairwell.
* On the landing.
* In the living room.
* In the storage room or rooms with electrical appliances.

2. The alarm should not be installed in:

* A space where the temperature can drop below 4

and above 40°C
* In humid areas.
* Right next to doors or windows and not near a fan or radiator.

Do not install smoke alarm device on the Wall !

INSTALATION

-6-

Do not install the alarm in a place with difficult access, which could
make it difficult to operate the test button and maintenance. The
alarm can be installed quickly and easily. Install the base plate on the
selected location using the provided screws.

3. Mounting
* Take the fixation pin out of the ground plate
* Screw the mounting plate with 2 screws on the celling
* Activate the smoke alarm device before mounting
* Fix the smoke alarm device on the mounting plate by turning,

till you hear a “click”
* Put the fixation pin in the hole
* Test the smoke alarm device by pushing the test button

4. Caution
* Do not cover the smoke alarm device with tape! When SMOKE

is detected, you will hear a loud intermittent sound (85dB).

5. Recommendation
* Increase the detection area by installing several smoke alarm

devices

During the smoke alarm is alarming, you push the test button, it will
be paused the smoke alarm alarming for approx. 10 minutes. The
red LED will flash every 8 seconds, it indicates the smoke alarm
device is running into the hush mode. >>>

ALARM SILENCE (hush mode)

-7-

Smoke alarm devices are designed to minimize nuisance alarms.
Combustion particles from cooking may set off the alarm if the alarm
is located close to the cooking area. Large quantities of combustible
particles are generated from spills or when grilling/frying. Using the
fan on a range hood that vents to outside (non-recirculating type)
will also help remove these combustible particles from the kitchen.
The alarm silence (test button) is extremely useful in a kitchen area
or other areas prone to nuisance. The hush feature is to be used only
when a known alarm condition, such as smoke from cooking
activates the alarm. The smoke alarm device is desensitized by push
the alarm silence (hush mode) on the smoke alarm device cover, if
the smoke is not too dense, the alarm will silence to indicate that the
alarm is in a temporarily desensitized condition. The smoke alarm
device will automatically reset after approximately 10 minutes, if
after this period, particles of combustion are still present, the alarm
will sound again. The alarm silencer (hush mode) can be repeatedly
until the air has been cleared of the condition causing the alarm.

NOTE: Dense smoke will override the alarm silencer and sound a
continuous alarm, the smoke alarm goes back to normal work
status from hush mode

CAUTION: Before using the alarm silence (hush), identify the
source of the smoke and be certain a safe condition exists.

-8-

PREVENTIVE MAINTENANCE

Testing

The smoke alarm device is provided with a test button. Push it in
until the alarm sounds. The signal stops when the button is
released. Test the alarm at least once a week.

Cleaning

For the best performance, the smoke alarm device must be
dusted once a month and vacuumed every 6 months. Remove the
detector from the ceiling plate and carefully vacuum the detector.
Do not touch the inside with the nozzle of the vacuum cleaner.
Then test the alarm.

Caution : The smoke detector loses its effectiveness if it is

Warning : The smoke alarm device should not be painted /

IMPORTANT INSTRUCTIONS IN CASE OF FIRE ALARM

A smoke alarm device is part of your fire protection together with fire
extinguishers, escape ladders, ropes as well as your choice of
building materials during renovations. Also make sure that there is
an escape route; discuss this with your children, make sure any room
can be evacuated without opening the door, >>>

covered.

taped. Do not test the smoke alarm device with
candles, flames, cigarettes, etc.

-9-

for example through a window. If the smoke alarm device is not
working properly, consult the instructions of the supplier. Keep the
manual within reach. The local fire department can provide more
information about fire prevention. Keep the smoke detector away
from children.

Warning

If there is any doubt about the cause of the alarm, assume that there
really is a fire and carry out your emergency plan. Please do not
assume that it is a false alarm. Dust can cause excessive sensitivity.
Vacuum as indicated above. Do not paint the smoke alarm device.

False alarm

Unusual atmospheric conditions may be the cause that the very
sensitive smoke detector gives a false alarm. If there is no fire,
ventilate the room and / or blow clean air in the smoke alarm device,
for example, by waving a newspaper under the smoke alarm device
until the alarm stops. Once it is clean, there is an automatic reset.

Recommendation

We recommend that you do not use smoke alarm devices that are
older than 10 years in order to limit the risk of defects. The smoke
alarm device is not a substitute for insurance for furniture, home,
life, or other form of insurance.

-10-

SMARTWARES SAFETY & LIGHTING

Can never be held liable for loss and / or damages of any kind,
including incidental and / or consequential damages arising out of
the fact that the signal from the smoke alarm device is not triggered
by smoke or fire.

Errors are indicated by the following:

1. The alarm does not sound when pressing the test button.
* Carefully vacuum the smoke alarm device (see Cleaning), test

afterwards. Still no reaction; replace smoke detector

2. The smoke alarm device “chirp” with red LED flashes once

every 40 sec.
* The battery is under low battery status, please replace the

smoke alarm device; battery is not replaceable.

3. Smoke alarm device “chirp” occurs every 40 seconds

(alarm goes into fault mode)
* Clean smoke alarm device. Please refer to maintenance

section. When problem is not solved replace smoke alarm

device.

4. Smoke alarm device sounds unwanted alarms intermittently or

when resident are cooking or taking showers.
* Press test button to pause alarm.
* Clean smoke alarm device (maintenance section)
* Move smoke alarm device to other place and press test button
>>>

TROUBLESHOOTING
