SmartTrunk Systems ST-1000D, ST-1000C, ST-1000V User Manual
UHF FM DIGITAL TRANSCEIVER
ST-1000D
ST-1000C
VHF FM DIGITAL TRANSCEIVER
ST-1000V
SmarTrunk Systems, INC.
ST-1000UM R1.0a
Printed in Malaysia
PN: AL1000010A
Page 2
FEDERAL COMMUNICATIONS COMMISSION
INTERFERENCE STATEMENT
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and
receiver.
--Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV
technician for help.
FCC NOTICE
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
Page 3
THANK YOU!
We are grateful you chose SmarTrunk for your land mobile radio
applications. We believe this powerful, flexible and easy-to-use
transceiver will provide dependable and reliable communications to
keep personnel operating at peak efficiency.
SmarTrunk transceivers incorporate the latest in advanced SDR
technology. As a result, we feel strongly that you will be pleased with
the quality and features of this product.
NOTICES TO THE USER
GOVERNMENT LAW PROHIBITS THE OPERATION OF
UNLICENSED RADIO TRANSMITTERS WITHIN THE
TERRITORIES UNDER GOVERNMENT CONTROL.
ILLEGAL OPERATION IS PUNISHABLE BY FINE,
IMPRISONMENT, OR BOTH.
REFER SERVICE TO QUALIFIED TECHNICIANS ONLY.
SAFETY: It is important that the operator is aware of and understands
hazards common to the operation of any transceiver.
WARNING:
EXPLOSIVE ATMOSPHERES (GASES, DUST, FUMES, etc.)
Turn off your transceiver while taking on fuel, or while parked in
gasoline service stations.
Page 4
ATTENTION (U.S.A. Only):
The RBRC Recycle seal found on Smartrunk lithium-ion (LiIon) battery packs indicates Smartrunk‘s voluntary
participation in an industry program to collect and recycle
Li-Io batteries after their operating life has expired. The
RBRC program is an alternative to disposing Li-Io batteries
with your regular refuse or in municipal waste streams,
which is illegal in some areas.
For information on Li-Ion battery recycling in your area,
call (toll free) 1-800-8-BATTERY (1-800-822-8837).
Smartrunk’s involvement in this program is part of our
commitment to preserve our environment and conserve
PRECAUTIONS
Observe the following precautions to prevent fire, personal
injury, and transceiver damage.
- Do not modify this transceiver for any reason.
- Do not expose the transceiver to long periods of direct
sunlight, nor place it close to heating appliances.
- Do not place the transceiver in excessively dusty, humid,
and/or wet areas, or on unstable surfaces.
- If an abnormal odor or smoke is detected coming from the
transceiver, switch OFF the power immediately and remove
the optional battery pack from the transceiver. Contact
your SmarTrunk dealer.
Page 5
CONTENTS
Contents Page
APPENDIX I: DEALER PROGRAMMED FUNCTIONS ….19
BATTERY CHARGER....................................................................... 9
GETTING ACQUAINTED .............................................................. 13
Installing the Antenna ST-FA0X ................................................. 12
Installing the Belt Clip ................................................................ 12
Installing/ Removing the LI-Ion Battery Pack ........................... 12
LED INDICATOR ........................................................................... 16
MAKING A CALL .......................................................................... 14
PROGRAMMABLE BUTTONS FUNCTIONS ................................. 16
ROTARY FUNCTIONS .................................................................. 15
SMARTRUNK ST-SBP18 ................................................................ 7
SWITCH ON/OFF AND VOLUME SELECTOR .............................. 16
UNPACKING AND CHECKING EQUIPMENT ................................. 6
Page 6
UNPACKING AND CHECKING EQUIPMENT
Note: The following unpacking instructions are for use by your
SmarTrunk dealer, an authorized SmarTrunk service facility, or the
factory.
Carefully unpack the transceiver. We recommend that you identify the
items listed in the following table before discarding the packing
material. If any items are missing, or have been damaged during
shipment, file a claim with the carrier immediately.
Supplied Accessories
Item
Part number
Quantity
Battery pack
ST-B16
1
Belt clip
ST-BH02
1
Screw set
ST-1000BCS
1
Instruction manual
ST-1000UM
1
Smartrunk ST-1000 Transceiver
ST-1000X
1
Desktop Battery Charger
ST-BC-02
1
AC Power adaptor
ST-AC02
1
Antenna
ST-FAC02
1
Before to start, you must read carefully about the battery and the
battery charger operation, then assembly the radio as per the
instructions bellow.
