Smart Technologies SMART Board 3000i Specification Sheet

Download

Page 1

Physical Specifications

Size

Weight

Shipping Weight

Shipping Size

Standard Features

Cabinet

Portability

Wireless Keyboard

Front Projector Controls Audio Power Requirements Power Consumption

Warranty

Integrated Projector

Display Type Display Technology Brightness Contrast Ratio Lamp (Life) Scanning Rates Video Compatibility Computer Compatibility RGB Signal Compatibility Projector Support

Interactive Whiteboard Features

SMART Pen Tray

Resolution SMART Super Screen

Screen Surface Material Digitizing Technology

Discontinued –

Newer

Rear Projection SMART Board Interactive Whiteboard 57 3/8" W x 79" H x 29 1/4" D (145.8 cm x 200.7 cm x 74.3 cm) Active Screen Area

ear Projection SMART Board Interactive Whiteboard (with Projector) Fully Assembled – Cardboard Crate

Knockdown – Cardboard Crate Fully Assembled – Cardboard Crate Knockdown – Cardboard Crate

Secure, fully enclosed cabinet with locking front doors Easy access to multimedia equipment Streamlite™ design with tapered shape and metal and plastic composite construction

Roll-about, self-contained unit

Easy to move through 80" x 32" (203.2 cm x 81.3 cm) door openings

Model

3" (7.6 cm) locking casters U.S. English Windows® operating system with built-in trackball (all regions except Japan)

Holder provided on side of cabinet Built-in projector controls on front of cabinet Stereo amplified speakers (total of 30 W)

Switching power supply, 100–250V AC, 47–63 Hz, 12V DC 4.2A, 72" (182.9 cm) power cord Approximately 500 watts for the projector, audio and controller electronics. This 500-watt estimate does not include the

internal computer, guest computer and other optional components such as a VCR or DVD player. One-year limited equipment warranty on screen and cabinet. Two-year limited equipment warranty on projector.

True XGA (1024 x 768) NEC® MT1060 with short-throw lens

0.99" (2.51 cm) x 3 Polysilicon LCD panels 2500 ANSI Lumens 800:1 275 W, 2000-hour lamp life (user changeable) H-sync 15–100 kHz; V-sync 50–120 Hz NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM Windows operating system and Macintosh computer (UNIX® and Linux® available upon request) SXGA, XGA, SVGA, VGA, MAC, IBM, VESA, SUN, SGI, HP Replacement projector shipped within one business day

Upon request, original projector repaired and returned within five business days Available free of charge for two years

Optical sensors in the Pen Tray detect when a pen or the eraser is lifted from the tray. Four Whisper-tip included (black, blue, red and green) along with a round eraser.

Touch resolution approximately 2000 x 2000

Diffusion screen with 0.95 peak gain and 48° horizontal half-gain angle Bright image with uniform light distribution Suitable for high ambient lighting, specifically meeting rooms or videoconferencing rooms

Extremely durable, low-reflection (matte) finish reduces glare from overhead lights Two resistive sheets separated by an air gap

Available

–

Specifications – Model 3000i

53 5/8" W x 40 1/4" H (136.2 cm x 102.2 cm) 67" (170.2 cm) diagonal (4:3 aspect ratio)

375 lb. (170 kg)

658 lb. (299 kg) 631 lb. (287 kg) 62" W x 88" H x 43" D (157 cm x 224 cm x 109 cm) 63" W x 60" H x 46" D (160 cm x 152 cm x 117 cm)

vailable

Available

All dimensions +/ - 1/8"

. All weights +/- 5 lb.

(0.3 cm)

Discontinued –

Newer Model

–

Available

™

(2 kg)

styluses are

Accessories Included

• Infrared remote control with a mouse control for the projector, two AA batteries and a cable for the remote control unit included

• Wireless keyboard (English Windows operating system), two AA batteries included

• Rear Projection SMART Board 3000i Installation Guide and SMART Board™ User’s Guide

• NEC MT1060 User’s Manual

• Network connection panel and cables for laptop computers including a J-hook for cable management

Discontinued

Newer Model A

Discontinued

Newer Model

Page 2

Integration Features

SMART X-Port Switch

Side Shelf

Video Camera Platform Rear Connection Panel Input Terminals

Computer Requirements

Windows Operating System

Macintosh Computer



Discontinued –

Automatically switches the audio, video and serial connections to an alternate computer (Windows operating system or Macintosh computer) Comes wired with power, audio, video and serial cables

16" W x 11" D (41 cm x 28 cm) shelf for portable computers, can be mounted on either side of the cabinet

Top of cabinet can hold a video camera

Printer: parallel port Network: RJ45 x 1 Video: RCA x 1 Video/audio: stereo RCA x 2

Output Terminals

Audio: stereo mini jack x 1 RGB: mini D-sub 15-pin x 1

486DX 66 MHz or higher processor (Pentium® processor recommended) 16 MB RAM required (24 MB RAM recommended) Windows 95, 98, 2000, ME, XP or Windows NT® 4.0 (SP-4) operating system 50 MB of free hard-disk space for complete installation An available serial or USB port

Model

Power Macintosh computer 32 MB RAM required Macintosh OS 8.5 through OS X operating systems 10 MB of free hard-disk space for complete installation An available serial or USB port

Specifications – Model 3000i

Available

Discontinued –

SMART Board Software

Windows Operating System

Macintosh Computer

Storage and Operating Specifications (includes projector)

Storage Operating

Optional Accessories

01-00128 03-00037-00 3000i-VC1-00 3000i-VC2-00 3000i-RCM MT60LPS

USB-ADP

SMART Order Number

RPSB 3000i

Newer

SMART Board driver 7.1.2 and SMART Notebook

SMART Board driver 6.0.3 and SMART Notebook 1.3.3

14ºF to 95ºF (-10ºC to 35ºC) with up to 80% humidity non-condensing 41ºF to 85ºF (5ºC to 29ºC) with up to 80% humidity non-condensing

Replacement projector lamp and air filter for NEC MT1060 (Part No. MT60LP) Replacement projector (NEC MT1060 with short throw lens) Large Video Conferencing Shelf Small Video Conferencing Shelf Room Control Module Extended-life projector lamp (4000 lamp hours at 1600 ANSI Lumens)

USB Adaptor

Rear Projection SMART Board interactive whiteboard

–

vailable



2.5.2 software

software

Newer Model

–

Available

SMART Technologies Inc.

Suite 600, 1177 – 11th Avenue SW Calgary, AB CANADA T2R 1K9 Support: 1.866.518.6791 (Canada/U.S.) or +1.403.228.5940 in all other countries Main Switchboard: 1.888.42.SMART (Canada/U.S.) or +1.403.245.0333 in all other countries

Fax: +1.403.245.0366 [email protected] www.smarttech.com

2002 SMART Technologies Inc. All rights reserv ed.



Windows and Wi ndows NT are registered trademarks of M icrosoft Corporati on in the U.S. and other countr ies. NEC is a trademark of NEC Corporation. Penti um is a registered tradem ark of Intel Corporat ion or its subsidiaries in t he U.S. and other countries. Macint osh, Power Macintosh and Mac are trademark s of Apple Computer, I nc., registered in the U. S. and other countries. UNI X is a registered trademark of The Open Group. Linux ® is a registered trademark of Linus Torvalds. Speci fications are subject to change without notice. U. S. Patent Nos. 5,448,263 and 6,141,000. Canadian Patent No. 2,058, 219. Other U.S. and for eign patents pending. Nov ember 2002.

Discontinued

Rear Projection

SMART Board, Stream lite, W hisper-tip, X-Port, S MART Board, Notebook and "

Newer Model A

Discontinued

Bringing people and ideas together.

Bringing people and ideas together

." are trademarks of SMART Technologies Inc.

Newer Model

Page 3

Discontinued –

Newer Model Available

Discontinued –

Newer Model Available

Discontinued –

Newer Model Available

Discontinued –

Newer Model Available

U.S. Patent #5,448,263 and #6,141,000. Other U.S. and foreign patents pending. November 2002.

79"

(200.7 cm)

35"

(88.9 cm)

3" (7.6 cm)

57 3/8" (145.8 cm)

Front View

44"

(111.8 cm)

Active Screen Area

53 5/8" W x 40 1/4" H

(136.2 cm x 102.2 cm)

Diagonal

67"

(170.2 cm)

31 1/4"

(79.4 cm)

34"

(86.4 cm)

11 3/4"

(29.7 cm)

4 3/4"

(11.9 cm)

11 1/2"

(29.2 cm)

1 1/2"

(3.8 cm)

Top View

29 1/4" (74.3 cm)

47 1/8"

(119.7 cm)

32 5/8"

(82.9 cm)

16 1/2"

(41.9 cm)

Side View

ISO 9001

48" (121.9 cm)

All dimensions +/- 1/8" (0.3 cm)

Specifications – Model 3000i

Interactive Whiteboard
