LED Indicators
Insert Battery
Quick Start User Guide
• Before using your Smart PowerCharger™,
be sure to read this guide along with safety
precautions.
• Familiarize yourself with how to use the charger
properly.
• For future reference, keep this guide handy.
SPC4000
4. The charger’s LED’s indicators on
top of the unit will cycle from RED
to Green. Once the LED’s are static
Green, the unit is in CHARGE MODE.
1. Unpack the
charger and place
in a DRY area for
operation.
2. Connect the POWER
CORD to the side of
the charger labeled AC
Power Connection
(AC 100V – 240V).
3. Turn “ON”
the Power
Switch.
In your box:
a. SPC4000
b. Power Cord
*Note: For extended life of your batteries, it is recommended
that you DEEP CYCLE your batteries following 5 to 10 flight
cycles. DEEP CYCLE your batteries when it is 30% capacity or
below. The best time to DEEP CYCLE your batteries is overnight.
1. Insert the battery into the charging slot. The
SPC4000 will communicate with the battery and
send the battery into CHARGE MODE automatically.
3. Remove the battery and turn
OFF the SPC4000.
1. Insert the battery
into the charging slot.
The SPC4000 will
communicate with the
battery and send the
battery into CHARGE
MODE automatically.
The battery’s green LED
will be blinking until
fully charged.
2. When the battery’s green LED’s
are OFF, it is fully charged.
QUICK START USER GUIDE
CHARGING YOUR BATTERIES
DEEP CYCLE DISCHARGING
When the SPC4000 is in DEEP CYCLE MODE,
the DC FAN will turn ON automatically. If the
SPC4000 is over 40C, the DC FAN will turn ON
automatically. Once the SPC4000 is below 35C,
the DC FAN will turn OFF automatically.
FINAL NOTE:
You can CHARGE and DEEP CYCLE 4 DJI Smart
Batteries plus CHARGE your WIFI EXTENDER and
iPHONE simultaneously.
OTHER INFORMATION ABOUT THE SPC4000
AUTOMATIC THERMAL FAN CONTROL
When the SPC4000 power supply output is less
than 8.4v or greater than 13.7v, the charger’s
LED’s will all flash at the same time thus turning
OFF CHARGE MODE AUTOMATICALLY. This is
to protect the battery and the charger. Please
REMOVE the power cord and check battery to see
if there is a circuit short or damage.
Hold Down
Remove Battery
CHARGING YOUR iPHONE or iPAD
1. Turn ON the SPC4000.
5. Turn OFF the
SCP4000.
2. Connect your
iPHONE or iPAD to the
USB port using the cable supplied by APPLE.
3. When your iPHONE or iPAD shows 100%, it is fully charged.
4. Remove the cable
from the SPC4000.
3. When both LED’s
on the WIFI Extender
are GREEN, it is fully
charged.
4. Remove the cable from the SPC4000.
5. Turn OFF the SCP4000.
LEDs
5. When the battery’s
GREEN LED’s are OFF,
the battery has been
DEEP CYCLED and
charged to full capacity.
2. Hold down the RED
DEEP CYCLE BUTTON
until the LED turns RED.
3. The SPC4000 will
activate the battery and
discharge it to below 5%.
4. Once discharged to below 5%, the SPC4000 will
automatically send the battery into CHARGE MODE.
6. Remove the battery and turn OFF the
SPC4000
1. Turn ON the SPC4000.
CHARGING YOUR WIFI EXTENDER
2. Connect your WIFI
Extender to the USB port
using the cable supplied
by DJI.
