SmartPeak Technology P500 User Manual

Android POS Terminal Model-P500

Quick start guide

Thanks for your purchase of Product Descrption.
Please read this guide first before you use the
device,and it will ensure your safety and the proper
use of equipment.About the equipment
configuration, please check with the relevant
contracts of the device or consult the seller who sells
the equipment to you.
The pictures in this guide are for reference only, if
some pictures do not match the physical
product,please in kind prevail.Many network function
which is described in this manual is the specific
service by the network service providers. Whether
use these functions,it depends on the Internet service
provider who services for you.
Without the company's permission, anyone should
not use any forms or any ways to
copy, excerpts,backup,modify,spread,translated into
other languages,all or partly used for commercial.

Indicator icon

Warning: may hurt themselves or others
Caution: may damage your equipment

or other devices
Note: the annotations, use hints

or additional information

To know the product

Contactless
sensing area

Charging indicator

Earphone jack

FUN button

Volume button

Microphone jack

Speaker output hole

Rear camera

POGO Pin

Contactless
indicator

Magnetic card
swipe area

Charging
interface

FUN button

On/Off key

USB interface

IC Card slot

Flashlight

Battery cover

Back cover: install and uninstall

Install back cover:step1 to step2.

step 1

step 2

Battery: install and uninstall

Install battery:step1 to step2.
Uninstall battery:opposite operation.

step 1

step 2

USIM(PSAM) card:install and uninstall

Install USIM/PSAM/T card:
Uninstall USIM/PSAM/T card:Uninstall back cover:opposite operation.

USIM/PSAM card slot

TF card slot

USIM/PSAM card slot

Charging for the battery

Before using the device for the first time or the battery is not
used for a long time,you must first to charge the battery.
In the state of the power on or off, please ensure that close
the battery cover when you charge the battery.

Only use the company matching chargers, battery
and data cables.Using the charger or data cable
without permission will cause the battery explosion
or will damage the equipment.In the condition of
charging, LED light shows red;When the LED light
shows green,it expresses that the battery has been
completed;When the battery insufficient, the screen
will show a warning message;
When the power is too low, the device will shut
down automatically.

Boot/Shutdown/Sleep/Wake up the device

Long press the switch to turn on or off the device.
Short press the switch to wake or sleep the device.

POS terminal base (optional)

Front view

POGO PIN

Code scan
window

Paper roll
warehouse

POS terminal base (optional)

Back view

RJ11 interface
(optional)

USB interface
(optional)

RS232 interface
(optional)

Lan port
(optional)

Charging
interface

USB
interface
(optional)

Troubleshooting

After pressing the power button,the device is not on.

When the battery has run out and it is unable to charge,
please replace it.
When the battery power is too low, please charge it.

The device shows network or service error message

When you're in the place where the signal is weak or receiving
badly, it may be lost the absorptive capacity.So please try again
after moving to other places.

Touch screen response slowly or is not correct

If the device has a touch screen but the touch screen response is
not correct, please try the following:
Remove the touch screen of any protective film.
Please make sure that your fingers are dry and clean when you
click the touch screen.
To remove any temporary software error,please restart the device.
If the touch screen is scratched or damaged, please contact seller.

Device is frozen or severe mistake

If the device is frozen or hang, it may need to shut down the
program or restart to regain the function.If the device is frozen or
slow, hold down the power button for 6 seconds, then it will
automatically restart.

Standby time is short

Use the functions such as Bluetooth /WA /LAN/GPS/automatic
rotating/data business, it will use more power,so we recommend
you to close the functions when it is not in use.
If there are some programs in the background, close some not to

Can't find another Bluetooth device

To ensure that the device has started the Bluetooth wireless
function.
Make sure that the distance between the two device is within the
largest Bluetooth range(10m).

Use Notes

The operating environment

Please do not use this device in the thunderstorm weather,
because the thunderstorm weather may result in the equipment
failure, or click the danger.
Please put the equipment from rain, moisture and liquids
containing acidic substances, or it will make the electronic circuit
boards corrosion.
Don’t store the device in overheating, high temperature,or it will
shorten the life of electronic devices.
Don't store the device in a too cold place, because when the
device’s temperature rises, moisture can form inside, and it
might damage the circuit board.
Do not attempt to disassemble the device, non-professional
personnel handling can damage it.
Do not throw, beat or intense crash the device, because rough
treatment will destroy the device’s parts, and it may cause the
device failure.

Children's health

Please put the device, its components and accessories in the
place where children can't touch.
This device is not toys, so children should be under adult
supervision to use it.

The charger security

When charging the device, power sockets should be installed near
the device and should be easy to hit.And the areas must be far
away from the debris, flammable or chemicals.
Please do not fall or crash the charger.When the charger shell
damaged, please ask the vendor for replacement.
If the charger or the power cord is damaged, please do not
continue to use, so as to avoid electric shock or fire.

Please do not fall or crash the charger.When the charger shell
damaged, please ask the vendor for replacement.
Please do not use wet hand to touch the power cord, or with
power supply cable way out the charger.
The charger must meet the "2.5 restricted power" in the request of
the standard <GB4943.1 information technology equipment safety
IF the device needs to connect USB port, please make sure the
SUB contains USB port - IF logo and its performance is in
accordance with the relevant specification of the USB - IF.

The battery safety

Do not use the battery short circuit, or use a metal or other
conductive objects to contact with the battery terminal.
Please do not disassemble, squeeze, twist, pierce or cut the
battery.
Please do not insert foreign body in the battery,contact the battery
with water or other liquid, make the cells exposed to fire,
explosion or other risk sources.
Do not put or store the battery in high temperature environment.
Please do not put the battery in a microwave or in the dryer
Please do not throw the battery into the fire
If there is a battery leak, do not let the liquid on the skin or eyes,
and if accidentally touched, please rinse with plenty of water, and
seek for medical advice immediately.
When a device in standby time obviously shorter than in the
normal time, please replace the battery

Repair and Maintenance

Don't use strong chemicals or powerful detergent to clean the
device.If it is dirty, please use a soft cloth to clean the surface with
a very dilute solution of glass cleaner.
Screen can be wiped with alcohol cloth, but be careful not to let
the fluid accumulate around the screen. Dry the display with a soft
non-woven cloth immediately, in order to prevent the screen from
leaving the strip traces.
