SmartLabs 2440A User Manual
June 21, 2011
On-Line Owner’s Manual Containing
Cautionary FCC & IC Statements
Handheld Wireless Remote Control
Model: 2440
FCC ID: SBP2440A IC: 5202A-2440A
The owner’s manual below may be accessed freely via the Internet
with any web browser and supports the PDF format.
http://www.smarthome.com/2440/RemoteLinc-INSTEON-Wireless-
Remote-Control-Silver/p.aspx
Complies with Section 5 of FCC document 784748 D01 Labeling Part 15 18 Guidelines v07
cautionary statements in the user manual may be provided over the Internet.
where
RemoteLinc™
INSTEON® Wireless Remote Control
Model : 2440
RemoteLinc Owner’s Manual
TABLE OF CONTENTS
ABOUT REMOTELINC................................................................................................................................. 3
Key RemoteLinc Features ......................................................................................................................... 3
What is Included with RemoteLinc ............................................................................................................ 3
WHAT IS INSTEON?....................................................................................................................................4
INSTALLATION............................................................................................................................................ 4
Installing RemoteLinc ................................................................................................................................4
USING REMOTELINC .................................................................................................................................. 5
Using the RemoteLinc Buttons.................................................................................................................. 5
Creating a Custom RemoteLinc Label ...................................................................................................... 5
CONTROLLING INSTEON RESPONDERS FROM SWITCHLINC DIMMER ............................................. 6
Linking RemoteLinc to an INSTEON Responder...................................................................................... 6
Unlinking an INSTEON Responder from RemoteLinc .............................................................................. 6
CREATING AN INSTEON SCENE............................................................................................................... 7
ADVANCED FEATURES ............................................................................................................................. 7
Multi-Linking and Multi-Unlinking............................................................................................................... 7
Enabling / Disabling the Beeper ................................................................................................................ 8
Enabling / Disabling the Status LED .........................................................................................................8
Stuck Button Feature................................................................................................................................. 9
Restoring Power to RemoteLinc................................................................................................................ 9
Resetting RemoteLinc to its Factory Default Settings............................................................................... 9
ABOUT INSTEON ......................................................................................................................................10
Using Dual-Band INSTEON Devices to Upgrade Your Network.............................................................10
Important Note about INSTEON Networks; Split Single-Phase vs. 3-Phase Installation .......................10
Further Enhancing Reliability ..................................................................................................................10
ADDITIONAL RESOURCES ...................................................................................................................... 10
TROUBLESHOOTING................................................................................................................................11
SPECIFICATIONS, CERTIFICATION, AND WARRANTY ........................................................................ 12
Specifications ..........................................................................................................................................12
FCC & Industry Canada Compliance Statement..................................................................................... 12
Limited Warranty .....................................................................................................................................13
RemoteLinc Owner’s Manual
ABOUT REMOTELINC
Congratulations on purchasing the INSTEON RemoteLinc. With its sleek, handheld design, RemoteLinc
allows you to use the power of INSTEON to control your home with the convenience of a wireless radio
frequency (RF) controller.
Customizable
label insert
On/Off button
pairs
Status LED
Dedicated
Dedicated
Dim/Bright buttons
simultaneous-
control buttons
Key RemoteLinc Features
• Setup is easy – install four AAA batteries (included), and then Link to other devices in minutes
• Six individual On/Off button pairs, plus dedicated Dim, Bright, All On and All Off buttons
• Shows command transmission activity with a Status LED and beeper (both features easily
disabled/re-enabled)
• Stores setup state in memory so settings aren’t lost when batteries are removed
• Smart circuitry detects abnormally long button presses (like those occurring when the remote falls
between couch cushions) and puts RemoteLinc into sleep mode to preserve battery life
• Two-year warranty
What is Included with RemoteLinc
• RemoteLinc – INSTEON Wireless Remote Control
• Four (4) AAA batteries
• Quick-Start Guide
Page 3 of 13
RemoteLinc Owner’s Manual
WHAT IS INSTEON?
Since its inception in 2005, INSTEON has become a best-selling home-control networking technology,
offering more reliability and flexibility than any other home management system on the market. INSTEON
systems are simple, reliable, and affordable. Simple, because each device takes mere minutes to install.
Reliable, because every INSTEON device works as a network repeater, ensuring your commands will not
be lost. Affordable, because INSTEON can be integrated into any number of devices easily and at a very
low cost. An INSTEON home grows in value with each added INSTEON device, making life more
convenient, safe, and fun.
How Does INSTEON Work?
What makes INSTEON the most reliable home automation network is its dual-mesh network. INSTEON
devices use both radio frequency (RF) signals and the home’s existing wiring to talk to each other. In an
INSTEON network, every INSTEON device also acts as a repeater, receiving and sending every message to all
other devices in the network. So by integrating more INSTEON devices you will strengthen the network and
ensure no commands will be lost.
No central controller or networking setup is required with an INSTEON network. Simply install your devices and
then use a series of button presses or taps to Link your devices together. Throughout this Owner’s Manual, you
may see the terms “Controller” or “Responder”. These generic INSTEON terms refer to the components of an
INSTEON scene, and are used on a scene-by-scene basis.
• Controller – sends INSTEON commands to other devices
• Responder – reacts to commands sent out by another INSTEON device
An INSTEON device may act as a Controller, Responder, or sometimes both.
INSTEON networks are also extremely secure. Each INSTEON device is assigned a unique INSTEON ID, so
unless neighbors or would-be hackers have access to your particular device’s INSTEON ID, they won’t be able
to control your home, even if they are using similar products.
INSTALLATION
Installing RemoteLinc
1) RF-only devices require at least one Access Point (#2443) or dual-band INSTEON device for
communication. For the best INSTEON network performance, be sure you have properly installed at
least two dual-band INSTEON devices.
Search for dual-band INSTEON devices at: www.smarthome.com/dualband
2) Remove the battery compartment from the rear
of RemoteLinc
3) Observe the polarity markings, and then install
four AAA batteries (included) accordingly
NOTE: Use alkaline batteries, or high quality
rechargeable batteries. A fully-charged set of
alkaline batteries will provide approximately
1,500-2,000 button taps.
4) Replace the battery compartment door before
use
Page 4 of 13
