PIR-TH-01 User Manual
App Setup
PIR sensor overview
To install SmartiBlue app
Step 1:
Download the SmartiBlue app from App Store® or Google Play™.
Step 2: Log into your SmartiBlue account, or sign up a new account by following the instruction in
the app.
PIR install
Step 1: Insert 3xAAA battery to battery box
Step 2: The small LED indicator at the front will blink steadily, waiting to be associated with your
mobile device.
Step3: Open the “SmartiBlue app” and complete the association process. The light becomes solid red
when the sensor associated successfully. The notice would be popped out to indicate that the
association process is finished.
Step4: Turn on the motion detect, a push notice will be provided if someone pass by the sensor.
PIR Specification
Model No: PIR-TH-01
Input: DC 4.5V by battery
Temperature: 0 to 40 (Operating), -20 to 65 (Storage) Humidity: 1
0% to 90% Non-condensing (Operating), 5% to 90% Non-condensing (Storage)
Operating frequency: 2402-2480MHz
Note
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—
Reorient or relocate the receiving antenna.
—
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
—
receiver is connected.
—
Consult the dealer or an experienced radio/TV technician for help.
Note: The Grantee is not responsible for any changes or modifications not expressly
approved by the party responsible for compliance. such modifications could void the
user's authority to operate the equipment.
To maintain compliance with FCC’s RF exposure guidelines, this equipment should be
installed and operated with a minimum distance of 20cm between the radiator and your
body.
