Smarthome SH-S8 User Manual

USER GUIDE

URINAL SENSOR FLUSH VALVE

Model: SH - S8

Bkav SmartHome technology company limited

www.smarthome.bkav.com

All rights reserved.
Copyright © 2015 Bkav SmartHome Co., Ltd.

UGS8/V2.3/0815

893604393UGS8Mfr Code:

USER GUIDE

URINAL SENSOR FLUSH VALVE

SH - S8

Bkav SmartHome technology company limited

1

Usage notice

Thank you for choosing urinal sensor valve SH - S8 of Bkav
SmartHome. By selecting Bkav SmartHome’s products, you
will get the best warranty service and installation support
from our technicians.

This document gives useful information during installation
and usage time. You should read and keep the manual care­fully in case of need.

Electric shock may cause injuries or threats to
life. Before installing, repairing or cleaning the
device, you should check whether the device’s
power is disconnected.

This work should be done by technicians or
Customer Contact Center to avoid electric
related accidents.

Environmental regulations must be complied
when discarding or recycling the device or its
wrapping.

Warning

Copyright © 2015 Bkav SmartHome Co., Ltd.

All rights reserved.

The urinal sensor flush valve SH - S8 is the product of Bkav

SmartHome and has been registered regarding design,

utility solutions and quality certification. All violations such as

copies of design and product idea are subject to the current
copyright law of the Socialist Republic of Vietnam.

2

Safety instruction

Safety instruction should be complied during the
device usage.

Do not leave the device in high-temperature
environment.

Do not disassemble the device if not necessary.

Disconnect the device’s battery prior to any
installation, disassembly or repair.

Do not clean the device with corrosive chemicals.

0

C

6V Alkaline

Do not use voltage which is different from the one

stated in the device’s specifications.

Warning

3

Table of contents

1
2
3
4
4
4
6
7
7
8
8

9
13
13
14
15
15
17
17
17
18
18
19
20

Usage notice
Safety instruction
Table of contents
Introduction
General introduction
Product package

Specifications

Device components
Sensing range
Installation instruction
Installation dimensions
Installation steps
Usage and maintenance
Usage steps
Maintenance
Operation cycle
Cycle explanation
Problem and Solution
Problem 1
Problem 2
Problem 3
Problem 4
Problem 5
Contact

4

Introduction

General introduction

SH - S8

Product package

User guide (book)

The urinal sensor flush valve SH - S8 uses infrared sensor

technology. When a user is in the sensor area, the device will

flush water automatically to clean a urinal. The automatic

feature of the device brings comfort, water saving and abso­lute safety for users.

With the modern and luxurious design, the device is suitable
for hotels, trade centers, airports, train stations, public
restrooms, etc.

USER GUIDE

URINAL SENSOR FLUSH VALVE

Model: SH - S8

Bkav SmartHome technology company limited

5

4 sets of screws and anchors

Notice

Please check to ensure that all accessories
are attached to the device. If there is any
missing accessory, please contact the shop
from which you purchased.

1 set of pipe fittings

1 battery box
(6V - 4 AA Alkaline Batteries)

1 solenoid valve - 6V

6

Specifications

6V - 4 Pin AA Alkaline Battery

Voltage

Water consumption

Sensing range

The device can detect person within
default sensing range of 45cm
(adjustable, from 30 - 80 cm).

Water supply pressure

0.7 - 7.6 Kgf/cm

2

Clean flush time 8 seconds

Automatic wet flush time 12 hours

Water temperature 5

0

C - 500C

Used water

Clean water without sediment

Dimensions

Operating temperature 60

0

C max

103 x 162 x 82 mm

Weight 0.8 kg

Chú thích

2 years with 100 usage times/day (*)Lifespan

2 ~ 3 liters/time

3 secondsWet flush time

(*) The period of using the device can be short­er or longer depending on the usage conditions
and environment. The period above is tested in
standard conditions.

Note

Device components

Sensing range

Effective range for receiving

reflected signal

Effective range for

transmitting infrared signal

450 mm

250 mm

350 mm

15

o

82 mm

Indicator light:

Has notification

function, when the

light flashes it

means that the
device is detecting
a user in its
sensor area.

Transmits and
receives the

reflected infrared

signal from users
in the sensor
area, then sends

notification to the

central processor.

Infrared sensing
component:

7

The sensing range can be adjusted from 30
cm - 80 cm, depending on installation conditions
and user demands.

Note

8

Installation dimensions

Installation

180 mm

150 mm

The device’s back cover

Screw hole

Ready-to-install pipe

1050 mm

30 mm

77 mm

64 mm

68 mm

129 mm

These dimensions apply to most types of
wall-hung urinals. For the most accuracy, please
measure on-site or consult the manufacturer.

Warning

9

Installation steps

Step 1: Remove the back and the front cover of the device.

Step 2: Hold the device still and drill screw holes.

10

Step 3: Mount the back cover onto the wall.

Step 4: Connect the solenoid valve to water supply source.

11

Step 5: Mount the battery box onto the back cover.

Step 6: Connect a water pipe to the solenoid valve.

12

Step 7: Connect the battery power cable to solenoid valve wire.

Step 8: Mount the front cover onto the back one and screw

to fix the device.

Power cable

Valve wire

Step 1: A user goes into the device’s sensor area, the

indicator light will flash to notify detection of the user.

Step 2: If it still detects the user after 3 seconds, the

device will automatically open the valve to perform wet flush
for 3 seconds. Within 45 seconds from this flush, if there
is another user, the device will not perform the wet flush.

This is a smart feature to help save water.

Step 3: The device will wait so that as soon as the user

leaves the sensor area, it will flush automatically to clean the

urinal for 8 seconds.

Urinal sensor flush valve is designed and manufactured

based on infrared sensor principle, thus it is very safe to use.
With its smart features, the urinal sensor valve will bring to
its users a more convenient, modern and comfortable life.

3321

13

Usage and maintenance

Usage steps

14

Maintenance

The valve should be twisted gently while remov­ing. Soft fabric should be used to avoid too much
pressure which can make the valve deformed.

Soft fabric made by cotton (or soft paper) should
be used to clean the device. Do not use chemi­cals or rough materials to clean the device.

High quality batteries with anti-leak protection
should be used for replacement to avoid any
damage to the device.

Notice

Cover maintenance

After operating in moist and dusty environment for a period,
the device’s cover may be foul, it is necessary to clean the
cover to keep the device always clean.

Solenoid valve maintenance

After using for a period, if flushing water becomes weak or
valve leak occurs, it means the device’s flushing valve needs

to be cleaned. This work should be done by technicians.

How to clean the solenoid valve:
Step 1: Remove the cover from the device and disconnect

batteries.
Step 2: Remove the valve wire, place the device’s front cover
at a dry place.

Step 3: Lock the valve’s water supply source.
Step 4: Disconnect the water pipe from the solenoid valve.
Step 5: Use specialized pliers to remove the valve from the

water pipe.

Step 6: Clean the valve filter.
Step 7: Reassemble the device and check its features.

Replace battery for the device

When the indicator light flashes twice for 1 second, it is the

time to replace batteries. The device uses 4 Alkaline

1.5V-AA batteries.

When the infrared sensing component detects a user in
front of the device within the sensing range, the device will
calculate the setting time of 3 seconds (for user stability)
to avoid false detection.

Wet flush

3s

Clean flush

8s

Wet flush

3s

Start

Detect user(s)

Indicator

flashing

Pending time

> 12h

Detection time

> 3s

Interval

from previous user

> 45s

Detect no user

(user left)

True

True

False

False

False

True

True

True

False

15

Operation cycle

Cycle explanation

16

After the setting time, the device will perform wet flush for

3 seconds. When detecting user leaving the device’s

sensor area, the device will continue clean flush for 8

seconds. Within the next 45 seconds, if the device detects

another user, it only performs clean flush for 8 seconds

after detecting the user leaving the sensor area.

If the device does not detect any use more than 45
seconds from the last use, it will automatically return to
original process. The smart feature of the device helps
save water during use.

If the device does not detect any use after 12 hours from

the last use, it will automatically flush water to rinse the

urinal for 3 seconds. Its smart feature will make the urinal
absolutely clean.

17

Problem and Solution

Problem 1

If the valve is installed in the opposite direction and the water
supply has a lot of sediment.
If the solenoid valve has not been connected to the controller.
If the problem is not mentioned above.

Check the valve installation based on installation steps of the
user guide.
Connect the solenoid valve to the controller.
Please contact Customer Contact Center or the shop from
which you purchased.

The device does not flush or flushes water continuously.

Checking

Solution

Problem 2

If there is any obstacle in the device’s sensor area.
If the device is installed on the opposite of a mirror within 2.5m.
The problem is not mentioned above.

Take the obstacle away from the sensor area.

Move the mirror because it reflects the infrared signal in the

device’s sensing component.
Please contact Customer Contact Center or the shop from
which you purchased.

Indicator light flashes or the device does not work properly.

Checking

Solution

When there is a user in the sensor area, the indicator light

does not flash.

18

Problem 3

If the power cable is not connected correctly.
If a user wears full black coat or shirt, etc.

Connect the power cable properly based on the steps of the
user guide.
Since black color completely absorbs infrared signals, it is
recommended to put your hands in front of the transceiver

eye so that the device flushes water.

Please contact Customer Contact Center or the shop from
which you purchased.

Checking

Solution

Problem 4

If technicians misplaced the distance between the valve and the

urinal (too far or too close), it is difficult to install the water pipe.

If the joints start leaking.

If it is difficult to screw from the bottom because the

performance scale is small.

You can buy hoses at sanitary equipment stores such as the type
used for sink, then measure suitable distance, cut and install.

Please check the rubber gaskets, wrap thread seal tape (teflon

tape) at the points of screws and the rubber stopper’s slots, etc.
Short screwdrivers should be used. This type of screwdriver
is sold at mechanical appliances shops.

Other problems.

Checking

Solution

19

Problem 5

The device still operates (it is recommended to replace
batteries for the device)

The device stops operating and it is necessary to replace
batteries for the device.

The device’s indicator light flashes every 1 second.

Solution

Problem 6

The device’s indicator light flashes twice for 1 second.

Solution

The device uses 4 Alkaline 1.5V – AA batteries. High
quality batteries with anti-leak protection should be used
for replacement.

Before calling Customer Contact Center,
please read the information in this section to
solve problems.

If assistance is required, please contact the
shop from which you purchased or the nearest
Customer Contact Center.

The product‘s serial numbers should be
noted down before calling Customer Contact
Center since the warranty staffs will need
such information.

Notice

20

Contact

Customer Contact Center: ([phone]
Email: [e-mail]

If there is any problem related to the product, please contact
Customer Contact Center:

The new home standard !
