USER GUIDE
SMART LIGHTING DEVICE
Model: SH - D3
Bkav SmartHome technology company limited
by Bka v
Copyright © 2014 Bkav SmartHome Co., Ltd. All rights reserved. UGD3/V1.0/1014
www.smarthome.bkav.com
Mfr Code: 893604393UGD3
USER GUIDE
SMART LIGHTING DEVICE
Model: SH - D3
Warning
User Guide SH - D3
Thank you for choosing smart lighting device SH - D3 of Bkav SmartHome. For
selecting Bkav SmartHome’s products, you will get the best warranty service and
installation support from our technicians.
This document gives useful information during installation and usage time. You
should read and keep the manual carefully in case of need.
Electric shock may cause injuries or threats to life. Before installing,
repairing or cleaning the device, you should check whether the
device’s power is disconnected.
This work should be done by technicians or Customer Contact
Center to avoid electric related accidents.
Environmental regulations must be complied when discarding or
recycling the device or its wrapping.
User Guide SH - D3
The smart lighting device SH - D3 is the product of Bkav SmartHome and has
been registered regarding design, utility solutions and quality certification. All
violations such as copies of design and product idea are subject to the current
copyright law of the Socialist Republic of Vietnam.
Copyright © 2014 Bkav SmartHome Co., Ltd. All rights reserved.
Warning
User Guide
Safety instruction
SH - D3
Do not use voltage which is different from the one stated in the
device’s specifications.
Safety instruction should be complied during the device usage.
Disconnect the device’s power prior to any installation, disassembly
or repair.
Do not leave the device in high-temperature environment.
Do not disassemble the device if not necessary.
Do not clean the device with corrosive chemicals.
Contents
Introduction
1. General introduction
2. Product package
3. Sensor area
4. Specifications
Features
1. Auto lighting
2. Forcible lighting
3. Use remote control SH - RM6
4. Light sensor
5. Preferred light level settings
6. Indicator light
Settings
1. Default mode
2. Switch mode settings (switch S203)
3. Time settings
Installation
1. Wiring diagram
2. Installation steps
Problems during usage
Contact
05
05
06
07
08
09
10
10
11
12
13
13
15
15
15
16
19
20
21
23
28
SH - D3
Introduction
1. General introduction
Introduction
SH - D3
The smart lighting device uses pyroelectric infrared radial sensor technology.
When users are in the sensor area, the light will automatically turn on. The
device is integrated with light sensor and has ability to flexibly adjust the pending
time to turn off the light when users leave the sensor area. The product’s smart
feature brings comfort, power saving and absolute safety to its users.
Remote control device SH - RM6 supports turning on/off remotely and sched-
ules turn-off time.
The device is suitable for:
Office, smart house.
Living room, bedroom, kitchen, dining room.
Restroom, stairs, corridor, courtyard, garage, warehouse, etc.
Introduction
User guide (book)
SH - D3 and remote control SH - RM6
2. Product package
SH - D3
SET
Set of hook, screws, anchors and molly bolts
for plaster ceiling
USER GUIDE
SMART LIGHT DEVICE
Model: SH - D3
Bkav SmartHome technology company limited
by Bkav
Notice
Introduction
Above the ceiling
Below the ceiling
3. Sensor area
SH - D3
Within the above distances, it is the best operation condition for the
device. In case the device fails to detect users, please contact
Customer Contact Center.
Loading...
