Introduction

1.1 Overview

The MVME2500 Single Board Computer (SBC) is a VMEbus board, which features a single-core P2010 or the dual-core P2020 NXP® QorIQ® processors.
VxWorks 6.8 Asymmetric Multiprocessing (AMP) allows the independent instances of the VxWorks operating system to run on the individual CPUs of a multi-core processor.
This document describes the procedure to boot the VxWorks 6.8 AMP on the MVME25000 board.

1.2 Deliverables

The following table lists the MVME2500 deliverables.
Table 1-1 List of Deliverables
Name Description
Chapter 1
vxWorks_00.st VxWorks boot image file for Core 0
vxWorks_01.st VxWorks boot image file for Core 1
mvme2500_AMP_rel1.0.tar.gz
VxWorks 6.8 AMP Board Support Package (BSP) for MVME2500
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 9
Introduction
Introduction
10 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)

Booting VxWorks

2.1 Introduction

You can boot VxWorks AMP on the MVME2500 board using any of the following methods:
Network Boot
Disk Boot
USB Boot

2.2 Network Boot

2.2.1 Prerequisites

You should have Connectivity to the TFTP server

2.2.2 Booting Procedure

Chapter 2
The TFTP server should be configured and started in the connected PC. The VxWorks boot Image file, vxWorks_00.st, should be made available at the standard TFTP boot image path /tftpboot.
To boot VxWorks AMP through network, perform the following steps:
1. Power up the MVME2500 board. By default, it provides the U-Boot prompt.
2. Set the environmental variables at the U-Boot prompt.
setenv ipaddr <Board ip address> setenv serverip <TFTP server ip address> setenv gatewayip <Gateway ip address> setenv netmask <Netmask>
Example:
setenv ipaddr 10.130.101.206 setenv serverip 10.130.101.216 setenv gatewayip 10.130.101.254 setenv netmask 255.255.255.0
3. Set the VxWorks boot image file name.
setenv vxbootfile vxWorks_00.st
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 11
Booting VxWorks
4. Set the VxWorks bootline arguments.
setenv vxbootargs 'motetsec(0,0)10.130.101.216:vxWorks h=10.130.101.216 e=10.130.101.206:ffffff00 u=vxworks pw=vxworks f=0x80’
Parameters description:
motetsec(0,0) : ethernet interface 0 on cpu 0
10.130.101.216 : Host Machine IP
10.130.101.206 : Board IP ffffff00 : Netmask u=vxworks : Username on host machine p=vxworks : Password for the above user in host machine f=0x80 : File Transfer Protocol (FTP)
5. Set the VxWorks network boot command.
setenv vxboot 'tftpboot $vxbootfile && setenv bootargs $vxbootargs && bootvx'
6. Save your current environmental variables.
saveenv
7. Boot VxWorks on Core 0 through network.
run vxboot
This will boot the VxWorks on Core 0 only. For sample output of VxWorks booting on Core 0 through network, refer to Section
A.1.1, VxWorks Booting on Core 0 on page 27.
Booting VxWorks
8. Boot VxWorks Image on Core 1, execute wrload command. Example: wrload "-file <image dir>/vxWorks -cpu 1"
To access the Core1 Console use the tip utility. Example: tip "dev=/ttyMsd0#tag=green". For more information refer the tip utility documentation.
For sample output of VxWorks booting on Core 1 through network, refer to Section
A.1.2, VxWorks Booting on Core 1 on page 29.
12 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)

2.3 Disk Boot

2.3.1 Prerequisites

You should have Serial Advanced Technology Attachment (SATA) hard disk with ext2 file system loaded, and VxWorks image loaded to the ext2 file system

2.3.2 Booting Procedure

To boot VxWorks AMP using disk, perform the following steps:
1. Power up the MVME2500 board. By default, it provides the U-Boot prompt.
2. Set the environmental variables at the U-Boot prompt.
setenv ipaddr <Board ip address> setenv serverip <TFTP server ip address> setenv gatewayip <Gateway ip address> setenv netmask <Netmask>
Booting VxWorks
Example:
setenv ipaddr 10.130.101.206 setenv serverip 10.130.101.216 setenv gatewayip 10.130.101.254 setenv netmask 255.255.255.0
3. Set the VxWorks boot image file name.
setenv vxbootfile vxWorks_00.st
4. Set the VxWorks bootline arguments.
setenv vxbootargs 'motetsec(0,0)10.130.101.216:vxWorks h=10.130.101.216 e=10.130.101.206:ffffff00 u=vxworks pw=vxworks f=0x80’
Parameters description:
motetsec(0,0) : ethernet interface 0 on cpu 0
10.130.101.216 : Host Machine IP
10.130.101.206 : Board IP ffffff00 : Netmask u=vxworks : Username on host machine p=vxworks : Password for the above user in host machine f=0x80 : File Transfer Protocol (FTP)
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 13
Booting VxWorks
5. Set the VxWorks disk boot command.
setenv vxdiskboot 'ext2load scsi 0:1 0x1000000 $vxbootfile && setenv bootargs $vxbootargs && bootvx'
6. Save your current environmental variables.
saveenv
7. To boot VxWorks on Core 0 through hard disk, execute the following command:
run vxdiskboot
This will boot VxWorks on Core 0 only. For sample output of VxWorks booting on Core 0 through hard disk, refer to Section
A.2.1, VxWorks Booting on Core 0 on page 30.
8. Boot VxWorks Image on Core 1, execute wrload command. Example: wrload "-file <image dir>/vxWorks -cpu 1"
To access the core1 Console use the tip utility Example: tip "dev=/ttyMsd0#tag=green". For more information refer the tip utility documentation.
For sample output of VxWorks booting on Core 1 through hard disk, refer to
Section A.2.2, VxWorks Booting on Core 1 on page 31.
Booting VxWorks
14 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)

2.4 USB Boot

2.4.1 Prerequisites

You should have USB pen drive with VxWorks image, and vfat or ext2fs file system

2.4.2 Booting Procedure

To boot VxWorks AMP using USB, perform the following steps:
1. Power up the MVME2500 board. By default, it provides the U-Boot prompt.
2. Set the environmental variables.
setenv ipaddr <Board IP address> setenv serverip <TFTP server IP address> setenv gatewayip <Gateway IP address> setenv netmask <Netmask>
Example:
setenv ipaddr 10.130.101.206 setenv serverip 10.130.101.216 setenv gatewayip 10.130.101.254 setenv netmask 255.255.255.0
Booting VxWorks
3. Set the VxWorks boot image file name.
setenv vxbootfile vxWorks_00.st
4. Set the VxWorks bootline arguments.
setenv vxbootargs 'motetsec(0,0)10.130.101.216:vxWorks h=10.130.101.216 e=10.130.101.206:ffffff00 u=vxworks pw=vxworks f=0x80’
Parameters description:
motetsec(0,0) : ethernet interface 0 on cpu 0
10.130.101.216 : Host Machine IP
10.130.101.206 : Board IP ffffff00 : Netmask u=vxworks : Username on host machine p=vxworks : Password for the above user in host machine f=0x80 : File Transfer Protocol (FTP)
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 15
Booting VxWorks
5. Set the VxWorks USB boot command.
setenv vxusbboot 'usb reset && fatload usb 0:1 0x1000000 $vxbootfile && setenv bootargs $vxbootargs && bootvx'
6. Save your current environmental variables.
saveenv
7. To boot VxWorks on Core 0 through USB, execute the following command:
run vxusbboot
This will boot VxWorks on Core 0 only. For sample output of VxWorks booting on Core 0 through USB, refer to Section A.3.1,
VxWorks Booting on Core 0 on page 33.
8. Boot VxWorks Image on Core 1, execute wrload command. Example: wrload "-file <image dir>/vxWorks -cpu 1"
To access the Core1 Console use the tip utility Example: tip "dev=/ttyMsd0#tag=green". For more information refer the tip utility documentation.
For sample output of VxWorks booting on Core 1 through USB, refer to Section
A.3.2, VxWorks Booting on Core 1 on page 34.
Booting VxWorks
16 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)

Building Board Support Package

3.1 Building Procedure

The mvme2500_AMP_rel1.0.tar.gz contains VxWorks 6.8 AMP BSP source files for the MVME2500 board.
Perform the following steps to build the BSP:
1. Extract the mvme2500_AMP_rel1.0.tar.gz to any working directory.
2. Start the Wind River VxWorks Workbench by executing the following command:
<VxWorks Installation Directory>/startWorkbench.sh
3. Create a new project for Core 0:
Open the Wind River VxWorks Workbench. Select File -> New -> VxWorks Image
Project.
Chapter 3
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 17
Building Board Support Package
Give a project name and then click Next.
Building Board Support Package
18 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)
Building Board Support Package
Go to BSP and select mvme2500_AMP from the drop down list. Click Browse and
point to the location where you have extracted the BSP. Click Next.
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 19
Building Board Support Package
Select any configuration profile.
Building Board Support Package
Click Finish.
20 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)
Building Board Support Package
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 21
Building Board Support Package
Once the Project is created, click Kernel Configuration and perform the following:
Enable Multi-OS IPC serial device
Building Board Support Package
22 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)
Building Board Support Package
Enable INCLUDE_AMP_CPU and INCLUDE_AMP_CPU_00
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 23
Building Board Support Package
Enable INCLUD_WRLOAD
Building Board Support Package
24 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)
Building Board Support Package
Save the Kernel configuration. Right-click the project name which you have
created, and select Build Project.
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 25
Building Board Support Package
4. Create a new project for Core 1:
Follow the first five sub-steps in Step 3.
Enable the following Kernel Configuration parameters:
Enable Multi-OS IPC Serial Device.
Modify MFD_CFG_STR, change "#dev=/ttyMsd0 node=0 instance=0
console=n bus=main" to "#dev=/ttyMsd0 node=0 instance=0 console=y bus=main"
Enable INCLUDE_AMP and INCLUDE_AMP_CPU_01
Enable INCLUDE_WRLOAD_IMAGE_BUILD
Save the Kernel Configuration. Right-click the project name which you have
created, and select Build Project.
Building Board Support Package
26 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)

Sample Output

A.1 Network Boot

A.1.1 VxWorks Booting on Core 0

MVME-2500 (Mon 1.0) => run vxboot Speed: 100, full duplex Using eTSEC1 device TFTP from server 10.130.101.216; our IP address is 10.130.101.206 Filename 'vxWorks_00.st'. Load address: 0x1000000 Loading: ################################################################# ################################################################# ################################################################# ######################################### done Bytes transferred = 3326700 (32c2ec hex) ## Ethernet MAC address not copied to NV RAM ## Using bootline (@ 0x4200): motetsec(0,0)10.130.101.216:vxWorks h=10.130.101.216 e=10.130.101.206:ffffff00 u=vxworks pw=vxworks f=0x80 ## Starting vxWorks at 0x00100000 ... Target Name: vxTarget 0x2541220 (devConnect): vxbIntelAhciInstConnect pDev 0x3888a8
Appendix A
Adding 8307 symbols for standalone.
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 27
Sample Outpu
t
]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]] ]]]] ]]]]]]]]]] ]] ]]]] (R) ] ]]]]]]]]] ]]]]]] ]]]]]]]] ]] ]]]] ]] ]]]]]]] ]]]]]]]] ]]]]]] ] ]] ]]]] ]]] ]]]]] ] ]]] ] ]]]] ]]] ]]]]]]]]] ]]]] ]] ]]]] ]] ]]]]] ]]]] ]]] ]] ] ]]] ]] ]]]]] ]]]]]] ]] ]]]]]]] ]]]] ]] ]]]] ]]]]] ] ]]]] ]]]]] ]]]]]]]] ]]]] ]] ]]]] ]]]]]]] ]]]] ]]]]]] ]]]]] ]]]]]] ] ]]]]] ]]]] ]] ]]]] ]]]]]]]] ]]]] ]]]]]]] ]]]]] ] ]]]]]] ] ]]] ]]]] ]] ]]]] ]]]] ]]]] ]]]] ]]]]]]]] ]]]]] ]]] ]]]]]]] ] ]]]]]]] ]]]] ]]]] ]]]] ]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]] Development System ]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]] VxWorks 6.8 ]]]]]]]]]]]]]]]]]]]]]]]]]] KERNEL: WIND version 2.13 ]]]]]]]]]]]]]]]]]]]]]]]]] Copyright Wind River Systems, Inc., 1984-2009
CPU: Freescale P2020E - Security Engine. Processor #0. Memory Size: 0x20000000. BSP version 2.0/2. Created: Apr 14 2011, 11:01:52 ED&R Policy Mode: Deployed WDB Comm Type: WDB_COMM_END WDB: Ready.
-> 0x2541220 (devConnect): ahciDrv called 0x253f430 0xa4100000
Instantiating /ahci00:2 as rawFs, device = 0x30001
28 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)

A.1.2 VxWorks Booting on Core 1

=> wrload "-f vxWorks_01.st" Loading...
0x21000000 - 0x21200670 loaded 0x21200670 - 0x212007b4 loaded 0x212007b4 - 0x212008a8 loaded 0x21240000 - 0x21277ef8 loaded 0x21277ef8 - 0x212a283c zeroed value = 0 = 0x0
-> tip "dev=/ttyMsd0" Connected to /ttyMsd0. Press ~? for the list of available commands. [Now listening to session 1 (/ttyMsd0)] [Input wired to session 1 (/ttyMsd0)] Target Name: vxTarget
Adding 8240 symbols for standalone
]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]] ]]]] ]]]]]]]]]] ]] ]]]] (R) ] ]]]]]]]]] ]]]]]] ]]]]]]]] ]] ]]]] ]] ]]]]]]] ]]]]]]]] ]]]]]] ] ]] ]]]] ]]] ]]]]] ] ]]] ] ]]]] ]]] ]]]]]]]]] ]]]] ]] ]]]] ]] ]]]]] ]]]] ]]] ]] ] ]]] ]] ]]]]] ]]]]]] ]] ]]]]]]] ]]]] ]] ]]]] ]]]]] ] ]]]] ]]]]] ]]]]]]]] ]]]] ]] ]]]] ]]]]]]] ]]]] ]]]]]] ]]]]] ]]]]]] ] ]]]]] ]]]] ]] ]]]] ]]]]]]]] ]]]] ]]]]]]] ]]]]] ] ]]]]]] ] ]]] ]]]] ]] ]]]] ]]]] ]]]] ]]]] ]]]]]]]] ]]]]] ]]] ]]]]]]] ] ]]]]]]] ]]]] ]]]] ]]]] ]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]] Development System ]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]] VxWorks 6.8 ]]]]]]]]]]]]]]]]]]]]]]]]]] KERNEL: WIND version 2.13 ]]]]]]]]]]]]]]]]]]]]]]]]] Copyright Wind River Systems, Inc., 1984-2009
CPU: Freescale P2020E - Security Engine. Processor #1. Memory Size: 0x20000000. BSP version 2.0/2. Created: Apr 14 2011, 11:04:22 ED&R Policy Mode: Deployed WDB Comm Type: WDB_COMM_END WDB: Ready
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 29
t

A.2 Disk Boot

A.2.1 VxWorks Booting on Core 0

MVME-2500 (Mon 1.0)=> run vxdiskboot Loading file "vxWorks_00.st" from scsi device 0:1 (sda1)
3824532 bytes read
## Ethernet MAC address not copied to NV RAM ## Using bootline (@ 0x4200): motetsec(0,0)10.130.101.216:vxWorks h=10.130.101.216 e=10.130.101.206:ffffff00 u=vxworks pw=vxworks f=0x80
## Starting vxWorks at 0x00100000 ...
Target Name: vxTarget 0x2585430 (devConnect): vxbIntelAhciInstConnect pDev 0x3d0d40
Adding 8784 symbols for standalone.
]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]] ]]]] ]]]]]]]]]] ]] ]]]] (R) ] ]]]]]]]]] ]]]]]] ]]]]]]]] ]] ]]]] ]] ]]]]]]] ]]]]]]]] ]]]]]] ] ]] ]]]] ]]] ]]]]] ] ]]] ] ]]]] ]]] ]]]]]]]]] ]]]] ]] ]]]] ]] ]]]]] ]]]] ]]] ]] ] ]]] ]] ]]]]] ]]]]]] ]] ]]]]]]] ]]]] ]] ]]]] ]]]]] ] ]]]] ]]]]] ]]]]]]]] ]]]] ]] ]]]] ]]]]]]] ]]]] ]]]]]] ]]]]] ]]]]]] ] ]]]]] ]]]] ]] ]]]] ]]]]]]]] ]]]] ]]]]]]] ]]]]] ] ]]]]]] ] ]]] ]]]] ]] ]]]] ]]]] ]]]] ]]]] ]]]]]]]] ]]]]] ]]] ]]]]]]] ] ]]]]]]] ]]]] ]]]] ]]]] ]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]] Development System ]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]] VxWorks 6.8 ]]]]]]]]]]]]]]]]]]]]]]]]]] KERNEL: WIND version 2.13 ]]]]]]]]]]]]]]]]]]]]]]]]] Copyright Wind River Systems, Inc., 1984-2009
Sample Outpu
CPU: Freescale P2020E - Security Engine. Processor #0. Memory Size: 0x20000000. BSP version 2.0/2. Created: Apr 14 2011, 17:53:10 ED&R Policy Mode: Deployed WDB Comm Type: WDB_COMM_END WDB: Ready
30 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)
-> 0x2585430 (devConnect): ahciDrv called 0x2583640 0xa4100000 0x25a5a90 (BusM A): INFO: usb2Msc - Storage driver got a device attach notification. 0x25a5a90 (BusM A): INFO: usb2Msc - Mounting device (PDT 0x0 PQ 0x0 RMB 0x1) VID = JetFlash : PID = Transcend 8GB : REV = 1100
0x25a5a90 (BusM A): INFO: usb2Msc - Device 0x2 LUN 0 of 7925760 (KB) will be mounted with base name /bd0 Instantiating /ahci00:2 as rawFs, device = 0x30001
0x259b770 (tErfTask): INFO: usb2Msc - Device /bd0 has been claimed by filesystem NOTIFY: hDevice 0x2 lun 0 medium changed (mediumInsert = 1)
->

A.2.2 VxWorks Booting on Core 1

=> wrload "-f vxWorks_01.st" Loading...
0x21000000 - 0x21200670 loaded 0x21200670 - 0x212007b4 loaded 0x212007b4 - 0x212008a8 loaded
0x21240000 - 0x21277ef8 loaded 0x21277ef8 - 0x212a283c zeroed value = 0 = 0x0
-> tip "dev=/ttyMsd0" Connected to /ttyMsd0.
Press ~? for the list of available commands. [Now listening to session 1 (/ttyMsd0)] [Input wired to session 1 (/ttyMsd0)]
Target Name: vxTarget Adding 8240 symbols for standalone.
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 31
Sample Outpu
t
]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]] ]]]] ]]]]]]]]]] ]] ]]]] (R) ] ]]]]]]]]] ]]]]]] ]]]]]]]] ]] ]]]] ]] ]]]]]]] ]]]]]]]] ]]]]]] ] ]] ]]]] ]]] ]]]]] ] ]]] ] ]]]] ]]] ]]]]]]]]] ]]]] ]] ]]]] ]] ]]]]] ]]]] ]]] ]] ] ]]] ]] ]]]]] ]]]]]] ]] ]]]]]]] ]]]] ]] ]]]] ]]]]] ] ]]]] ]]]]] ]]]]]]]] ]]]] ]] ]]]] ]]]]]]] ]]]] ]]]]]] ]]]]] ]]]]]] ] ]]]]] ]]]] ]] ]]]] ]]]]]]]] ]]]] ]]]]]]] ]]]]] ] ]]]]]] ] ]]] ]]]] ]] ]]]] ]]]] ]]]] ]]]] ]]]]]]]] ]]]]] ]]] ]]]]]]] ] ]]]]]]] ]]]] ]]]] ]]]] ]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]] Development System ]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]] VxWorks 6.8 ]]]]]]]]]]]]]]]]]]]]]]]]]] KERNEL: WIND version 2.13 ]]]]]]]]]]]]]]]]]]]]]]]]] Copyright Wind River Systems, Inc., 1984-2009
CPU: Freescale P2020E - Security Engine. Processor #1. Memory Size: 0x20000000. BSP version 2.0/2. Created: Apr 14 2011, 11:04:22 ED&R Policy Mode: Deployed WDB Comm Type: WDB_COMM_END WDB: Ready.
32 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)

A.3 USB Boot

A.3.1 VxWorks Booting on Core 0

MVME-2500 (Mon 1.0) =>run vxusbboot (Re)start USB...
USB: Register 10011 NbrPorts 1 USB EHCI 1.00 scanning bus for devices... 2 USB Device(s) found scanning bus for storage devices... 1 Storage Device(s) found reading vxWorks_00.st
........................................................................
........................................................................
........................................................................
........................................................................
....................
3824532 bytes read ## Ethernet MAC address not copied to NV RAM ## Using bootline (@ 0x4200): motetsec(0,0)10.130.101.216:vxWorks h=10.130.101.216 e=10.130.101.206:ffffff00 u=vxworks pw=vxworks f=0x80
## Starting vxWorks at 0x00100000 ... Target Name: vxTarget 0x2585430 (devConnect): vxbIntelAhciInstConnect pDev 0x3d0d40 Adding 8784 symbols for standalone.
]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]] ]]]] ]]]]]]]]]] ]] ]]]] (R) ] ]]]]]]]]] ]]]]]] ]]]]]]]] ]] ]]]] ]] ]]]]]]] ]]]]]]]] ]]]]]] ] ]] ]]]] ]]] ]]]]] ] ]]] ] ]]]] ]]] ]]]]]]]]] ]]]] ]] ]]]] ]] ]]]]] ]]]] ]]] ]] ] ]]] ]] ]]]]] ]]]]]] ]] ]]]]]]] ]]]] ]] ]]]] ]]]]] ] ]]]] ]]]]] ]]]]]]]] ]]]] ]] ]]]] ]]]]]]] ]]]] ]]]]]] ]]]]] ]]]]]] ] ]]]]] ]]]] ]] ]]]] ]]]]]]]] ]]]] ]]]]]]] ]]]]] ] ]]]]]] ] ]]] ]]]] ]] ]]]] ]]]] ]]]] ]]]] ]]]]]]]] ]]]]] ]]] ]]]]]]] ] ]]]]]]] ]]]] ]]]] ]]]] ]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]] Development System ]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]] VxWorks 6.8 ]]]]]]]]]]]]]]]]]]]]]]]]]] KERNEL: WIND version 2.13 ]]]]]]]]]]]]]]]]]]]]]]]]] Copyright Wind River Systems, Inc., 1984-2009
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 33
Sample Outpu
t
CPU: Freescale P2020E - Security Engine. Processor #0. Memory Size: 0x20000000. BSP version 2.0/2. Created: Apr 14 2011, 17:53:10 ED&R Policy Mode: Deployed WDB Comm Type: WDB_COMM_END WDB: Ready
->0x2585430 (devConnect): ahciDrv called 0x2583640 0xa4100000
0x25a5a90 (BusM A): INFO: usb2Msc - Storage driver got a device attach notification.
0x25a5a90 (BusM A): INFO: usb2Msc - Mounting device (PDT 0x0 PQ 0x0 RMB 0x1) VID = JetFlash : PID = Transcend 8GB : REV = 1100 0x25a5a90 (BusM A): INFO: usb2Msc - Device 0x2 LUN 0 of 7925760 (KB) will be mounted with base name /bd0 Instantiating /ahci00:2 as rawFs, device = 0x30001 0x259b770 (tErfTask): INFO: usb2Msc - Device /bd0 has been claimed by filesystem NOTIFY: hDevice 0x2 lun 0 medium changed (mediumInsert = 1)
->

A.3.2 VxWorks Booting on Core 1

=> wrload "-f vxWorks_01.st" Loading...
0x21000000 - 0x21200670 loaded 0x21200670 - 0x212007b4 loaded 0x212007b4 - 0x212008a8 loaded
0x21240000 - 0x21277ef8 loaded 0x21277ef8 - 0x212a283c zeroed value = 0 = 0x0
-> tip "dev=/ttyMsd0"
Connected to /ttyMsd0. Press ~? for the list of available commands. [Now listening to session 1 (/ttyMsd0)] [Input wired to session 1 (/ttyMsd0)]
Target Name: vxTarget
Adding 8240 symbols for standalone.
34 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)
]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]] ]]]] ]]]]]]]]]] ]] ]]]] (R) ] ]]]]]]]]] ]]]]]] ]]]]]]]] ]] ]]]] ]] ]]]]]]] ]]]]]]]] ]]]]]] ] ]] ]]]] ]]] ]]]]] ] ]]] ] ]]]] ]]] ]]]]]]]]] ]]]] ]] ]]]] ]] ]]]]] ]]]] ]]] ]] ] ]]] ]] ]]]]] ]]]]]] ]] ]]]]]]] ]]]] ]] ]]]] ]]]]] ] ]]]] ]]]]] ]]]]]]]] ]]]] ]] ]]]] ]]]]]]] ]]]] ]]]]]] ]]]]] ]]]]]] ] ]]]]] ]]]] ]] ]]]] ]]]]]]]] ]]]] ]]]]]]] ]]]]] ] ]]]]]] ] ]]] ]]]] ]] ]]]] ]]]] ]]]] ]]]] ]]]]]]]] ]]]]] ]]] ]]]]]]] ] ]]]]]]] ]]]] ]]]] ]]]] ]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]]]] Development System ]]]]]]]]]]]]]]]]]]]]]]]]]]]] ]]]]]]]]]]]]]]]]]]]]]]]]]]] VxWorks 6.8 ]]]]]]]]]]]]]]]]]]]]]]]]]] KERNEL: WIND version 2.13 ]]]]]]]]]]]]]]]]]]]]]]]]] Copyright Wind River Systems, Inc., 1984-2009
CPU: Freescale P2020E - Security Engine. Processor #1. Memory Size: 0x20000000. BSP version 2.0/2. Created: Apr 14 2011, 11:04:22 ED&R Policy Mode: Deployed WDB Comm Type: WDB_COMM_END WDB: Ready.
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 35
Sample Outpu
t
36 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)
Appendix B

Related Documentation

B.1 SMART Embedded Computing Documentation

The documentation listed is referenced in this manual. Technical documentation can be found by using the Documentation Search at https://www.smartembedded.com/ec/support/ or you can obtain electronic copies of SMART EC documentation by contacting your local sales representative.
Table B-1 SMART EC Documentation
Document Title Publication Number
MVME2500 Installation and Use 6806800L01
MVME2500 Quick Start Guide 6806800L03
MVME2500 Safety Notes Summary 6806800L13
MVME2500-ECC Installation and Use 6806800N30
MVME2500 VxWorks 6.8 User Guide 6806800M27
MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C) 37
Related Documentation
38 MVME2500 VxWorks 6.8 AMP User Guide (6806800M27C)
1
© 2019 SMART Embedded Computing™, Inc. All rights reserved. The stylized “S” and “SMART” is a registered trademark of SMART Modular Technologies, Inc. and “SMART Embedded Computing” and the SMART Embedded Computing logo are trademarks of SMART Modular Technologies, Inc. All other names and logos referred to are trade names, trademarks, or registered trademarks of their respective owners.
Loading...
