USER MANUAL
Longo programmable controller
LPC-2.IR2V
Multisensor
Version 5
SMARTEH d.o.o. / Poljubinj 114 / 5220 Tolmin / Slovenia / Tel.: +386(0) 388 44 00 / e-mail: info@smarteh.si / www.smarteh.si
Longo programmable controller LPC-2.IR2V
Written by SMARTEH d.o.o.
Copyright © 2019, SMARTEH d.o.o.
User Manual
Document Version: 5
April, 2019
i
Longo programmable controller LPC-2.IR2V
STANDARDS AND PROVISIONS: Standards, recommendations,
regulations and provisions of the country in which the devices will
operate, must be considered while planning and setting up electrical
devices. Work on 100 .. 240 V AC network is allowed for authorized
personnel only.
DANGER WARNINGS: Devices or modules must be protected from
moisture, dirt and damage during transport, storing and operation.
WARRANTY CONDITIONS: For all modules LONGO LPC-2 – if no
modifications are performed upon and are correctly connected by
authorized personnel – in consideration of maximum allowed
connecting power, warranty of 24 months is valid from the date of
sale to the end buyer, but not more than 36 months after delivery
from Smarteh. In case of claims within warranty time, which are based
on material malfunctions the producer offers free replacement. The
method of return of malfunctioned module, together with description,
can be arranged with our authorized representative. Warranty does
not include damage due to transport or because of unconsidered
corresponding regulations of the country, where the module is
installed.
This device must be connected properly by the provided connection
scheme in this manual. Misconnections may result in device damage,
fire or personal injury.
Hazardous voltage in the device can cause electric shock and may
result in personal injury or death.
NEVER SERVICE THIS PRODUCT YOURSELF!
This device must not be installed in the systems critical for life (e.g.
medical devices, aircrafts, etc.).
If the device is used in a manner not specified by the manufacturer,
the degree of protection provided by the equipment may be impaired.
Waste electrical and electronic equipment (WEEE) must be collected
separately!
LONGO LPC-2 complies to the following standards:
•EMC: EN 61000-6-3:2007 + A1:2011, EN 61000-6-1:2007, EN 61000-3-
2:2006 + A1:2009 + A2: 2009, EN 61000-3-3:2013
•LVD: IEC 61010-1:2010 (3
rd
Ed.), IEC 61010-2-201:2013 (1st Ed.)
Smarteh d.o.o. operates a policy of continuous development.
Therefore we reserve the right to make changes and improvements to
any of the products described in this manual without any prior notice.
MANUFACTURER:
SMARTEH d.o.o.
Poljubinj 114
5220 Tolmin
Slovenia
ii
Longo programmable controller LPC-2.IR2V
Longo programmable controller LPC-2.IR2V
1 ABBREVIATIONS................................................................................1
2 DESCRIPTION...................................................................................2
3 FEATURES.......................................................................................3
4 OPERATION.....................................................................................4
4.1 Operational modes.....................................................................4
4.2 Parameters..............................................................................4
4.3 IR learn, receive and transmit.......................................................7
5 INSTALLATION..................................................................................8
5.1 Connection scheme....................................................................8
5.2 Mounting frame selection...........................................................10
5.3 Mounting instructions................................................................11
5.4 Module labeling.......................................................................12
6 TECHNICAL SPECIFICATIONS................................................................13
7 SPARE PARTS..................................................................................14
8 CHANGES......................................................................................15
9 NOTES..........................................................................................16
iii
Longo programmable controller LPC-2.IR2V
1 ABBREVIATIONS
Sorted by order of appearance in document:
IR Infrared
LED Light emitting diode
PWR Power
ERR Error
DIP Dual in-line package
SEL Selector
1
Longo programmable controller LPC-2.IR2V
2 DESCRIPTION
The LPC-2.IR2V is a sensor which consists of the lux sensor for light intensity measurements,
temperature sensor, relative humidity sensor and IR receive/transmit for IR communication.
Measuring light intensity, temperature and relative humidity provides the information needed for
achieving good work conditions. IR transmit feature can be used for remote controller substitution,
for example air conditioning can be controlled from Smarteh main module via LPC-2.IR2V in parallel
with remote controller. On the other hand, IR receive feature can be used for receiving commands
to the main module from Smarteh remote controller, smartphone or other remote controller.
LPC-2.IR2V is controlled and powered from the main module (e.g., LPC-2.MC8, LPC-2.MC9) via
Smarteh bus.
2
Longo programmable controller LPC-2.IR2V
3 FEATURES
Figure 1: LPC-2.IR2V sensor
Table 1: Features
Room temperature and relative humidity measurement
Lux sensor for light intensity measurement
IR receive/transmit
Programmable IR transceiver
RC-5 IR protocol receiver
Daikin, Toshiba, Hitachi, Panasonic, Mitsubishi IR protocol transmitter
2 diagnose LED
Modular frame mounting
NOTE: In case of usage Daikin, Toshiba, Hitachi, Panasonic or Mitsubishi IR protocol transmitter, due
to various sub protocols, consult with Smarteh.
3
Longo programmable controller LPC-2.IR2V
4 OPERATION
LPC-2.IR2V can be in one of two operational modes - normal or error. When LPC-2.IR2V is in normal
mode, module parameters can be read or written via Smarteh IDE software.
4.1 Operational modes
Normal
Communication with the main module is working. Only green “PWR” LED2 is turned on.
Error
In case of communication fault, red “ERR” LED1 will turn on.
4.2 Parameters
If parameter is set to logical “1”, is considered to be active, enabled or set. If parameter has logical
value “0” is considered to be inactive, disabled or cleared.
Parameter can be a command or feedback. When parameter is marked as feedback it means that
LPC-2.IR2V is sending information to the main module. On the other hand, command represents
request from the main module to the LPC-2.IR2V.
Command:
IR command number selection for transmit [oIrCmdSendNum]: This parameter is used to
select the IR learned command which will be used for transmit.
Type: WORD
Raw to engineering data: 1 .. 15 IR transmit command 1 .. IR transmit command 15→
IR command transmit control bit [oIrCmdSend]: When this bit goes to "1", selected IR
command in oIrCmdSendNum is transmitted.
Type: BOOL
Raw to engineering data: “0” No transmit→
“1” Transmit selected IR command→
IR protocol selector [oIrProtocolSel]: Selector for IR protocol.
Type: WORD
Raw to engineering data: 0 Learned IR commands (Receive and transmit)→
1 RC-5 IR protocol (Receive only)→
2 Daikin (Transmit only)→
3 Toshiba (Transmit only)→
4 Hitachi (Transmit only)→
5 Panasonic (Transmit only)→
6 Mitsubishi (Transmit only)→
IR Off/On command [oIrOffOn]: IR command for Off or On is transmitted when oIrCmdSend
is set. Applicable only when protocol selector is set to 2 .. 6.
Type: BOOL
Raw to engineering data: “0” IR set Off command→
“1” IR set On command→
4
Longo programmable controller LPC-2.IR2V
IR set temp. setpoint [oIrTSet]: IR command for temperature setpoint. Applicable only
when protocol selector is set to 2 .. 6.
Type: WORD
Raw to engineering data: 10 .. 32 10°C .. 32°C→
IR set fan speed [oIrFanSet]: IR command for fan speed. Applicable only when protocol
selector is set to 2 .. 6.
Type: WORD
Raw to engineering data: 0 .. 65535 Fan speed 0 .. Fan speed 65535→
1
IR set mode [oIrModeSet]: IR command for air-conditioning mode. Applicable only when
protocol selector is set to 2 .. 6.
Type: WORD
Raw to engineering data: 0 .. 65535 Mode 0 .. Mode 65535→
1
LED Off/On [oLed]: Command to set LED3 Off or On.
Type: BOOL
Raw to engineering data: “0” LED3 Off→
“1” LED3 On→
Feedback:
Actual light intensity value [iLight]: Actual measured light intensity value.
Type: WORD
Raw to engineering data: 0 .. 2990 0 .. 2990 lux→
Act. Room temp. [iTAct]: Actual room temperature measured by wireless panel.
Type: WORD
Raw to engineering data: 0 .. 5000 0.00°C .. 50.00°C→
Act. Room RH [iRhAct]: Room humidity measured by wireless panel.
Type: WORD
Raw to engineering data: 0 .. 100 0 .. 100 %→
Toggle communication bit [iComm]: At each valid Rx packet from main module, this bit is
toggled.
Type: BOOL
IR command number received value [iIrCmdRecNum]: This parameter depends on the
oIrProtocolSel parameter. Latency between touched button on the remote controller and
reception on the main module is max. 1 s.
Type: WORD
If oIrProtocolSel
is "0":
When LPC-2.IR2V receives an IR command, value of iIrCmdRecNum corresponds to
the number of the IR learned command. Value is set back to 0 after next
communication cycle with main module or after approximately two seconds
regardless communication.
Raw to engineering data: 1 .. 15 IR receive learned command 1 .. IR receive →
learned command 15
1 Range depends on the air-conditioner.
5
Longo programmable controller LPC-2.IR2V
is "1":
When LPC-2.IR2V receives an IR command, value of iIrCmdRecNum corresponds to
the number described below in binary code which includes toggle bit, address code
and data code of the RC-5 protocol. When button is released, value gets to 0 after
next communication cycle with main module or after approximately two seconds
regardless communication.
Raw to engineering data:
In case that oIrProtocolSel is set to 2 .. 6, variable iIrCmdRecNum is not applicable,
because protocols are transmit only.
6
Longo programmable controller LPC-2.IR2V
4.3 IR learn, receive and transmit
LPC-2.IR2V module can be learned to recognize 15 different IR commands. Module enters IR learning
mode as soon as the left pair of DIP switches (S1) are not in position for "No learning - receive only" –
see table 4.
IR learn is demonstrated on the example on how to learn LPC-2.IR2V the IR command "power ON"
from third-party IR remote controller for air conditioning and store it under command 15 in the LPC-
2.IR2V internal memory. IR receive and transmit is demonstrated on the example how to verify
stored IR commands.
IR learn
Set the S1 DIP switches to the setting than corresponds to the number under which IR command will
be stored. In this example, switches must be set to setting "learning mode for command 15". Once
this is done, LPC-2.IR2V is ready to receive the IR command from the remote controller and store it
to internal memory under command 15.
Press the button on the IR remote controller which you want it to be stored under command that is
set with DIP switches on LPC-2.IR2V. In this example, press "power ON" button on the IR remote
controller. Once the button has been pressed, the LPC-2.IR2V stores the IR command to internal
memory, in this example under command 15. LPC-2.IR2V will not store any other command under
command 15, unless S1 DIP switches has been changed to other setting and back to the setting
"learning mode for command 15".
IR receive
Which protocol should be used for IR receive, user can select with IrProtocolSel parameter. To check
if the IR command has been learned and stored correctly IrProtocolSel parameter must be "0".
Set the DIP switches to the setting "No learning - receive only" and than press button "power ON" on
the IR remote controller. If the received IR command corresponds to any of the IR commands stored
in the LPC-2.IR2V internal memory, the command number under which the received IR command has
been stored will be shown in the feedback parameter iIrCmdRecNum. In this example, number 15
should be shown.
If IrProtocolSel is set to "0" and DIP switches to the setting "No learning - receive only" than LPC-
2.IR2V will receive learned IR commands only.
If IrProtocolSel is set to "1" and DIP switches to the setting "No learning - receive only" than LPC-
2.IR2V will receive RC-5 IR protocol only.
Be advised that during IR transmit, IR receive is blocked.
IR transmit
In order to check if the IR command that was stored can also be transmitted correctly, the LPC-
2.IR2V should be used as a substitution of the IR remote controller. On the main module, number 15
should be written to the LPC-2.IR2V command oIrCmdSendNum. This command selects IR command
which is stored under number 15 for transmit. IR transmit is executed once oIrCmdSend is set to
logical “1”. In this example, air conditioning should be turned ON.
Procedure for IR learn can be repeated for 15 different IR commands. DIP switch setting corresponds
to learning mode for one of 15 commands and IR receive only mode – see table 4.
The IR commands may also be learned during manufacturing process - consult with Smarteh.
7
Longo programmable controller LPC-2.IR2V
5 INSTALLATION
5.1 Connection scheme
Figure 2: Connection scheme
8
Longo programmable controller LPC-2.IR2V
Table 2: K1
K1.1 GND Ground
K1.2 7 .. 30 V DC Power supply input
K1.3 Standard RS-485 A Data receive/send line A
K1.4 Standard RS-485 B Data receive/send line B
Table 3: LEDs
LED1: red Communication
ON: RS-485 communication fault
OFF: RS-485 communication OK
LED2: green Power supply
ON: power supply OK
OFF: power supply missing or power off
LED3: orange Signalization Programmable
Table 4: S1
SEL for IR Switch 1 Switch 2 Switch 3 Switch 4
No learning - IR
receive only
OFF OFF OFF OFF
Learning mode for
command 1
OFF OFF OFF ON
.. .. .. .. ..
.. .. .. .. ..
Learning mode for
command 14
ON ON ON OFF
Learning mode for
command 15
ON ON ON ON
Table 5: S2
RS-485
ADDRESS
Switch 1 Switch 2
0 OFF OFF
1 OFF ON
2 ON OFF
3 ON ON
9
Longo programmable controller LPC-2.IR2V
5.2 Mounting frame selection
Frame, suitable for IR2V module insertion, should be modular one at least 1 gang wide. Be careful to
have corresponding flush-mounting box provided on the place where module will be positioned.
Smarteh has verified following lines to be compatible with LPC-2.IR2V module:
● Bticino – Living, Light
● Gewiss – Playbus, System
● Vimar – Plana, Idea
● Tem
● Master
Frames of other vendors most probably suits as well, but they were not verified by Smarteh. Before
installation verify compatibility of non listed frames.
Module housing has a fin on each side, which can be easily removed with knife cutter or pliers. This
adaptation enables housing to be inserted in various frame formats. With regard to frame used you
may remove fin for housing to fit in.
Figure 3: Fin removing
10
Longo programmable controller LPC-2.IR2V
5.3 Mounting instructions
Figure 4: Housing dimensions
Dimensions in millimetres.
All connections, module attachments and assembling must be done
while module is not connected to the main power supply.
Module should be positioned in the wall inside of the room. Avoid
direct sunlight, positioning near heating/cooling source object or
under high luminance lights for best performance of the on-board
sensors. Junction box and tubes in the wall must be sealed to prevent
airflow. Displayed temperature is adequate to temperature approx. 10
cm below module and 1 cm off the wall. Recommended installation
height is 1.5 m above floor level.
Mounting instructions:
1. Set the correct RS-485 address (S2 switch) for LPC-2.IR2V (table 5).
2. Connect interconnection cable to the connector K1. Max. allowed tensile force is 30 N.
3. Put the LPC-2.IR2V in mounting frames, with ventilation slots positioning downwards.
4. Cover LPC-2.IR2V with cover plate.
LPC-2.IR2V is connected to main module with interconnection cable (e.g. SSK, ICM-7) which must be
ordered together with LPC-2.IR2V. When more modules (e.g. LPC-2.CR1, LPC-2. CH1, LPC-2.DP1,..)
are connected to main module, splitter (e.g. SPL-2) is required (figure figure 2).
NOTE: Signal wires must be installed separately from power and high voltage wires in accordance
with general industry electrical installation standard.
11
Longo programmable controller LPC-2.IR2V
5.4 Module labeling
Figure 5: Labels
Label 1 (sample): Label 2 (sample):
Label 1 descriptions:
1. LPC-2.IR2V is the full product name.
2. P/N: 225IR218V01002 is the part number.
• 225 – general code for product family,
• IR2V – short product name,
• 18V01 – sequence code,
• 18 – year of code opening,
• V01 – derivation code,
• 002 – version code (reserved for future HW and/or SW firmware upgrades).
3. D/C: 01/19 is the date code.
• 01 – week and
• 19 – year of production.
Label 2 descriptions:
1. S/N: IR2V-S9-1900000003 is the serial number.
• IR2V – short product name,
• S9 – user code (test procedure, e.g. Smarteh person xxx),
• 1900000003 – year and current stack code,
• 19 – year (last two cyphers),
• 00000003 – current stack number; previous module would have the stack number
00000002 and the next one 00000004.
12
S/N: IR2V-S9-1900000003
LPC-2.IR2V
P/N:225IR218V01002
D/C: 01/19
Longo programmable controller LPC-2.IR2V
6 TECHNICAL SPECIFICATIONS
Table 6: Technical specifications
Power supply from main module
Interconnection connector type RJ-12 6/6
Power consumption 0.5 W
Light intensity measurement range 0 .. 2990 lux
2
IR frequency carrier 38 kHz
IR max. pulse length in protocol used for
learning
16 ms
IR min. pulse length in protocol used for
learning
250 us
IR max. number of pulses for learning
single IR command
550
Dimensions (W x H x D) 24 x 48 x 52 mm
Weight 20 g
Maximum altitude 2000 m
Mounting position any
Ambient temperature 0 to 50 °C
Ambient humidity max. 95 %, no condensation
Transport and storage temperature -20 to 60 °C
Protection class IP 20
2 Due to various spectral sensitivity of the various lux sensors on the market, the actual light intensity may vary.
If LED3 is turned on, it may influence light intensity measurement.
13
Longo programmable controller LPC-2.IR2V
7 SPARE PARTS
For ordering spare parts following Part Numbers should be used:
LPC-2.IR2V Infrared transceiver and light sensor
LPC-2.IR2V P/N: 225IR218V01002
LPC-2.RC1S remote control
LPC-2.RC1S P/N: 225RC116001001
Interconnection cable
ICM-x P/N: 203ICMxxxxxxxx
Splitter
SPL-2 (1/8) P/N: 206SPL04002001
14
Longo programmable controller LPC-2.IR2V
8 CHANGES
The following table describes all the changes to the document.
Date V. Description
12.04.19 5 Technical update.
29.03.19 4 Technical update.
18.01.17 3 Technical update.
16.11.16 2 Added IR data.
30.10.16 1 The initial version, issued as LPC-2.IR2V User Manual.
15
Longo programmable controller LPC-2.IR2V
9 NOTES
16
Loading...
