Smart Avi SMCYPB2VGA User Manual

What’s in the Box?

PART NO. QTY DESCRIPTION

SMCYPB2VGA 1 YPbPr to VGA active Converter Includes:

[CYPPB2VGA & (PS5VD2A)]

Power Supply 1 PS5VDC2A

User Manual 1

Technical Specications

VGA VIDEO

Format VGA RGB Analog (75Ω, 0.7Vp-p)

Resolution Up to UXGA (1600x1200)

Input Interface (1) HD-15 Female

Output Interface (1) HD-15 Female

Sync H/V Separated (TTL)

COMPONENT VIDEO

Format (RCA) Y (75Ω, 1.0Vp-p), PbPr (75Ω, 0.7Vp-p)

Resolution 480i, 480p, 576i, 576p, 720p, 1080i, 1080p

(24/25/30Hz)

© Copyright 2010 Smart-AVI, All Rights Reserved

NOTICE

The information contained in this document
is subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for any particular purpose.

Smart-AVI will not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance or use of this material.

No part of this document may be photocopied, reproduced or
translated into another language without prior written consent
from Smart-AVI.

For more information, visit www.smartavi.com.

Installation

Manual

AUDIO

Analog Input RCA R/L x 1 (10KΩ), 3.5mm x 1 (10KΩ)

Analog Output 3.5mm x 1 (10KΩ)

Digital Input Optical x 2

Digital Output Optical x 1

OTHER

Power External 5VDC2A @ 10W

Dimensions 5.5”W x 1.75”H x 3.5”D

Weight 0.6 lbs.

Approvals Device: CE, ROHS

Power Supply: C-UL US, CE

SmartAVI, Inc. / Twitter: smartavi

2840 N. Naomi Ave. Burbank, CA 91504

Tel: [phone] Fax: [phone]

http://www.SmartAVI.com

SMCYPB2VGA

Component Video YPbPr

to VGA Converter

2-Port Switch with Audio

www.smartavi.com

Introduction

The SMCYPB2VGA automatically detects the YPbPr
video input resolution and converts it to VGA . It also
features a 2-port switch that allows one LCD monitor to
share the output of a computer and a component video
device such as a DVD player. Based on the input selected,
the output will be either a decoded TV or buered PC
video signal. It is capable of handling SDTV, HDTV, XGA,
SXGA, and UXGA (1900x1200) video formats. It supports
components ranging from LCD monitors, to set-top
boxes, to projectors.

Features

• Convert Component Video (YPbPr) signal to RGBHV
(VGA) signal

• Inputs: Component Video (YPbPr) x1 , D-SUB HDx1 , RCA
stereo audio x1, 3.5mm stereo phone jack x 1, 2 x digital
audio (coax)

• Outputs: D-SUB HD x 1, 3.5mm stereo phone jack x 1, 1
x digital audio(optical)

• Video bandwidth: component video up to 70Mhz,
RGBHV up to 400Mhz

• Supports high denition video inputs 480i, 480P, 576i,
576p, 720P, 1080i and 1080p at 24/25/30Hz

• RGBHV input support hi resolution up to 1600 x
1200@75Hz

Applications

• Corporate or Educational Presentations

• Financial (Remote Servers/User Control)

• Call Centers

• Industrial (Long-Range Workstation Isolation)

• Information Terminals/Kiosks

• Airport Installations (Air Trac/Passenger Info)

• Educational Environments with remote displays

VGA/AUDIO

PC

VGA/AUDIO

SMCYPB2VGA

Connecting the SMCYPB2VGA

1. Power o all devices.

2. Connect the component video source to the rear

of the SMCYPB2VGA using a component cable (Y,
Pb, Pr, L, R) or optional optical audio.

3. Connect the VGA source (computer) to the PC port

on the rear of the SMCYPB2VGA.

4. Connect an audio source (computer) to the

LINE IN port on the rear of the SMCYPB2VGA.
(optionally connect an optical audio source)

5. Connect a VGA monitor to the MONITOR port on

the rear of the SMCYPB2VGA.

6. Connect speakers to the LINE OUT port on the

rear of the SMCYPB2VGA. (optionally connect an
optical audio device)

7. Connect the power supply to the SMCYPB2VGA.

8. Power on the SMCYPB2VGA using the front switch.

9. Power on the computer, monitor and speakers.

Product - Installation Diagram

COMPONENT

Using the SMCYPB2VGA

1. To switch between component source and VGA

source, simply press the INPUT SELECT button on
the front of the SMCYPB2VGA.

2. The selected source will be indicated by the LED

lights on the front panel.

COMPONENT VIDEO PLAYER

SMCYPB2VGA Front

SMCYPB2VGA Rear
