Installation
Manual
FDX-M2P
Dual DVI-D Extender, with Audio
and USB Keyboard and Mouse
Extends 2 DVI-D Signals, Audio and USB
Keyboard and Mouse up to 1,400 feet over
2 Fiber Optic Cables
www.smartavi.com
Introduction
The FDX-M2P consists of a transmitter and receiver that extend
two DVI-D outputs, with audio, USB 1.1 keyboard and mouse, and
transparent RS-232. For exceptional quality and security, ber optic
extension is the best solution. The FDX-M2P can go the distance with
multi-mode ber optic cabling with a reach of up to 1,400 feet.
The system includes a transmitter and receiver, which are connected by
two ber optic cables. The transmitter connects to the user’s computer
with the necessary cables, while the receiver connects to the remote
interface devices up to 1,400 feet away.
What’s in the Box?
PART NO. QTY DESCRIPTION
FDX-M2PS 1 Point to Point Dual DVI-D, USB Keyboard & Mouse, Audio and RS232
Multimode Fiber Extender. Includes: [FDX-TX2MP, FDX-RX2MP]
User
Manual
1
2
www.smartavi.com
Features
• Dual channel DVI-D, audio, USB keyboard and mouse, and
transparent RS-232
• Top Signal Quality over Multimode Fiber (up to 1,400 feet)
• Video Resolutions up to 1920 x 1200 WUXGA at 60Hz
• Customizable/Programmable DDC Table for Mac/PC
• Supports all USB 1.1 Keyboards and Mice
• Fiber Plug Type LC
• Compatible With all Major KVM Switches
• Supports Mac, PC, and Linux DVI
• Uses universal DVI Single Link connectors
• Zero pixel loss with TMDS signal correction
• Rack Mountable Solution
• Plug-and-play
www.smartavi.com
3
Product - Installation Diagram
2 DVI-D Displays
Computer
Up to 1,400 feet
FDX-M2P
Transmitter
(400 m) over 2
ber optic cables
FDX-M2P
Receiver
Installation
1. Power o the computer, displays and speakers.
2. Connect the DVI Video, Audio and USB cables from the computer to
the FDX-M2P transmitter.
3. Connect the FDX-M2P transmitter to the FDX-M2P receiver using 2
ber optic cables.
4. Connect the DVI displays, speakers and USB keyboard and mouse to
the FDX-M2P receiver.
5. Power on the FDX-M2P transmitter and receiver.
6. Power on the computer, displays and speakers.
4
www.smartavi.com
Stereo Speakers
USB Mouse
USB Keyboard
Fiber Optic Cable Specications
• Multimode: Two bers 50μm or 62.5μm. For example: I-V(ZN)H 2G50 (In house patch
cable)or I-V(ZN)HH 2G62,5 (In house Breakout cable) or I/AD(ZN)H 4G50 (in
house OR outdoor Breakout cable, stress resistant) or A/DQ(ZN)B2Y 4G62,5
(outdoor cable, stress resistant with protection against animal biting) All notations
acc. VDE specication.
•Singlemode: Two bers 9μm. For example: I-V (ZN)H 2E9 (In house patch cable) or IV(
ZN)HH 2E9 (In house Breakout cable) or I/AD(ZN)H 4E9 (in house OR outdoor
Breakout cable, stress resistant) or A/DQ(ZN)B2Y 4G9 (outdoor cable, stress
resistant with protection against animal biting) All notations acc. VDE specication.
A point to point connection is required. Having one or more patch panels in the
line is possible and allowed. Telecommunications or network equipment may not be
connected to the ber optic connectors, doing so may cause damage to the device.
www.smartavi.com
5
Applications
• Home Theater Integration
• Digital Signage Deployment
• Information Kiosks/Displays
• Film/Recording Studios
In the medical or industrial eld, where it may not be practical (or safe) to
have one or more CPUs in the general vicinity, the FDX-M2P is the perfect
solution, allowing for either PC or Mac signals to be extended up to 1,400
feet.
Another practical use for the FDX-M2P would be for media recording
studios, where soundproong and space issues come into play. Using an
extender eliminates the inherent “hum” of a powered CPU and gives you
the freedom of using your keyboard, mouse and monitor without having
to nd room for the computer itself in the same workspace.
6
www.smartavi.com
Technical Specications
VIDEO
Format DVI-D Single Link
Maximum Pixel Clock 165 MHz
Input Interface (TX) (2) DVI-D 29-pin female
Output Interface (RX) (2) DVI-D 29-pin female
Resolution Upto1920x1200@60Hz
DDC
Input Equalization Automatic
Input Cable Length Up to 20 ft.
Output Cable Length Up to 20 ft.
Programmable Internal Table
5 volts p-p(TTL)
AUDIO
Signal Type Stereo Audio
Bandwidth 15MHz, 0dB
Impedance 10K Ohm
Connector 3.5mm Stereo Mini Female
USB
Signal Type USB 1.1
Input Interface (TX) (1) USB Type B (Female)
Output Interface (RX) (2) USB Type A (Female) Keyboard/Mouse
OTHER
RS-232 Data up to 115,000bps
Fiber Extender Fiber
•225m@Multimode62,5μ
•450m@Multimode50μ
Fiber-Plug type LC
Power Internal 110-240 VAC
Dimensions 17 in W x 7 in H x 1.75 in D
Weight 8 lb
Operating Temp. 0-55 °C (32-131°F)
Storage Temp. -20-85 °C (-4-185 °F)
Humidity Up to 95%
www.smartavi.com
7
© Copyright 2010 Smart-AVI, All Rights Reserved
NOTICE
The information contained in this document
is subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for any particular purpose.
Smart-AVI will not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance or use of this material.
No part of this document may be photocopied, reproduced or
translated into another language without prior written consent
from Smart-AVI.
For more information, visit www.smartavi.com.
