SMART-AVI AVRouter AV08X08 Quick Start User Manual
Quick Start
User Manual
AVRouter 8X8
Routes up to 8 XVGA and Stereo Audio Sources to 8
Remote Location at Distances up to 100 feet Away
SmartAVI’s AVRouter 8x8 gives you the power to pull content from up to 8
separate computers and display it on up to 8 monitors individually or at the
same time. As you will soon nd, this dynamic hardware/software solution
makes even the most “complicated” content delivery challenge a snap.
Whether you’ve purchased the AVRouter8x8 for a retail, recording studio
or even mass-transit location, we encourage you to broaden your vision –
explore your creativity and use this dynamic piece of hardware to your fullest
advantage.
This matrix switch is a powerful tool that you will now use to convey your own
message to clients, guests and/or employees the way you need it and want it
to be displayed.
Getting Started
Hardware Installation
Controlling the AVRouter 8x8
There are multiple ways to control the AVRouter 8x8. You can operate the router via:
Input/Output Control
By using the Input/Output Select buttons on the front panel of the AVRouter 8x8, you
can select which input port goes to which output port(s) of the device. This will have
your digital signage up and running quickly and easily. If the router is powered off, you
will need to manually set up the input/output settings again to your specications.
Note: If you use Mac rather than PC, or do not wish to install the CD-ROM software,
the AVRouter 8x8 hardware can be programmed and controlled without it.
Connect a serial cable from the AVRouter 8x8 to the control computer. If you
have installed the CD-ROM on a laptop, you can use a serial-to-USB adapter to
make this connection.
Connect up to 8 computers containing your video content to the “video in”
ports of the AVRouter 8x8, using VGA male to male extension cables. (same
for the audio cables using 3.5mm stereo jack)
Connect up to 8 display monitors to the “video out” ports of the AVRouter 8x8,
using XVGAI male extension cables.
Plug the power cord to the AVRouter 8x8 and turn the device on.
Turn on all computers and monitors being used.
Front panel LCD display input
RS-232 queries
SmartAVI’s Windows
®
-based software (included on CD-ROM)
Optional IR or TCP/IP (Internet control possible using SmartAVI’s SMTCP
device)
1.
2.
3.
4.
5.
•
•
•
•
1
Installation Diagram
What’s in the Box
2
PART NO. QT Y. DESCRIPTION
AV08X08 1 UXGA 8X8 Matrix Switch
PS5VD4A-WLLMT
1 Power Supply 5V DC 4A Wall mount
CCRS232MF06
1 RS232 cable 6ft Male/Female
SM-CSW
1 Smart control application software provid-
ing source/destination selection, name
editing, and messaging. Included in all
SNX and SNV investments.
