Smart S120 User Manual

S120 USB-C SMART BATTERY CHARGER

S120 USB-C LADEGERÄT FÜR SMART-AKKUS

CHARGEUR DE BATTERIE S120 USB-C SMART

CARICABATTERIE SMART USB-C S120

EN

NOTICE

All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For
up-to-date product literature, visit horizonhobby.com or towerhobbies.com and click on the support or resources tab for this product.

Meaning of Special Language

The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR
create a high probability of superficial injury.

CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury.
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury.

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product
before operating. Failure to operate the product correctly can result in damage to the product,
personal property and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution and common sense and requires
some basic mechanical ability. Failure to operate this Product in a safe and responsible manner could result
in injury or damage to the product or other property. This product is not intended for use by children without
direct adult supervision. Do not attempt disassembly, use with incompatible components or augment product
in any way without the approval of Horizon Hobby, LLC. This manual contains instructions for safety, operation
and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to
assembly, setup or use, in order to operate correctly and avoid damage or serious injury.

Age Recommendation: Not for children under 14 years. This is not a toy.

WARNING AGAINST COUNTERFEIT PRODUCTS

Always purchase from a Horizon Hobby, LLC authorized dealer to ensure authentic high-quality

Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with regards, but not
limited to, compatibility and performance of counterfeit products or products claiming compatibility with
DSM or Spektrum technology.

NOTICE: This product is only intended for use with unmanned, hobby-grade, remote-controlled
vehicles and aircraft. Horizon Hobby disclaims all liability outside of the intended purpose and will not
provide warranty service related thereto.

WARRANTY REGISTRATION

Visit www.spektrumrc.com/registration today to register your product.

BATTERY CHARGER WARNINGS

NOTICE: This appliance is not intended for use by persons with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.

WARNING: Failure to exercise caution while using this product and comply with the following
warnings could result in product malfunction, electrical issues, excessive heat, FIRE, and
ultimately injury and property damage.

EN

EN

• NEVER LEAVE CHARGING BATTERIES UNATTENDED.

• NEVER CHARGE BATTERIES OVERNIGHT.

• Never attempt to charge dead, damaged or wet battery packs.

• Never attempt to charge a battery pack containing different types of batteries.

• Never allow children under 14 years of age to charge battery packs.

• Never charge batteries in extremely hot or cold places or place in direct sunlight.

• Never charge a battery if the cable has been pinched or shorted.

• Never connect the charger if the power cable has been pinched or shorted.

• Never attempt to dismantle the charger or use a damaged charger.

• Always use only rechargeable batteries designed for use with this type of charger.

• Always inspect the battery before charging.

• Always keep the battery away from any material that could be affected by heat.

• Always monitor the charging area and have a  re extinguisher available at all times.

• Always end the charging process if the battery becomes hot to the touch or starts to change form (swell)

during the charge process.

• Always connect the positive leads (+) and negative leads (–) correctly.

• Always disconnect the battery after charging, and let the charger cool between charges.

• Always charge in a well-ventilated area.

• Always terminate all processes and contact Horizon Hobby if the product malfunctions.

• Charge only rechargeable batteries. Charging non-rechargeable batteries may cause the batteries to

burst, resulting in injury to persons and/or damage to property.

• The USB outlet shall be installed near the equipment and shall be easily accessible.

CAUTION: Always ensure the battery you are charging meets the specifications of this

D

charger. Not doing so can result in excessive heat and other related product malfunctions,
which can lead to user injury or property damage.

Please contact Horizon Hobby or an authorized retailer with compatibility questions.

CAUTION: If at any time during the charge process the battery pack becomes hot or begins
to puff, disconnect the battery immediately and discontinue the charge process as batteries
can cause fire, collateral damage and injuries.

Spektrum™ S120 SMART Battery Charger Diagram

A

C

EN

E

A. Spektrum S120 Charger

B

B. Spektrum IC3 Battery connector
C. Battery balance lead (LiPo Only)
D. USB Cable
E. USB power supply (not included)

D
