SMARTDocument Camera™ 330

User’s guide

Scan the following QR code to read this guide on your smart phone or other mobile device.

Product registration

If you register your SMART product, we’ll notify you of new features and software upgrades.

Keep the following information available in case you need to contact SMARTSupport.

Serial number:

Date of purchase:

FCC warning

This equipment has been tested and found to comply w ith the limits for a Class B digital device, pursuant to Part 15 of the FC C Rules. These lim its are designed to provide reasonable protection against harmful interference i n a residential installation. This equipment generates, uses, and can radiater adiofrequency energy and, if not installed and usedi n accordance w ith the instructions, may causeharmful interference to r adio or television reception. However, there is no guarantee that interference w ill not occur in a particular install ation. If this equipment does cause interference to r adio and televisionr eception, which can be determined by turning the equipment off andon, the user is encouraged to try to corr ect the interference by one or more of the followingm easures.

• Reorientor r elocate ther eceivingantenna.

• Increase theseparation between the equipment and receiver.

• Connect theequipment into an outlet on a ci rcuit different from that to which ther eceiver is connected.

• Consult the dealer or an experienced r adio/TV technician for help. User installer caution: Your authority to operate this FC C verified equipment could be voided if you make changes or m odifications not expressly approved by the party responsible for complianceto Part 15 of the FC C rules.

Trademark notice

SMARTDocumentCamera, SMARTBoard, SMARTNotebook, SMARTExchange, smarttech, theSMART logoand all SMART taglines are trademarks or registered trademarks of SMARTTechnologiesULC in the U.S. and/or other countr ies. Image Mate is a trademark or registered trademark of ELMO CO., LTD. Google andSketchUp are trademar ks of Google Inc. Adobe, Reader and Acrobat are r egistered trademarks or trademarks of AdobeSystems Incorporated in theU nited States and/or other countries. W indows, WindowsVista and DirectX are either r egistered trademarks or trademarks of M icrosoft Corporation in the U .S. and/or other countries. All other thirdpar ty product andcompany names may be trademarks of their respective owners.

©2010–2012SMARTTechnologiesULC. All ri ghts reserved. No part of this publication may be reproduced, transmitted, tr anscr ibed, storedin a retrieval system or translated into any language in any form by any m eans without the prior wri ttenconsent of SMARTTechnologiesULC. Infor mation in this manual is subject to change without notice and does not represent a commitment on the part of SMART.

Patents pending.

02/2012

Important information

W A R N I N G

l Failure to follow the installation instructions shipped with your SMART product could result in

personal injury and damage to the product.

l Ensure that any cables extending across the floor to your SMART product are properly

bundled and marked to avoid a trip hazard.

l Do not push foreign objects into the openings on your SMART product.

l Do not open or disassemble the SMART product. You risk electrical shock from the high

voltage inside the casing. Opening the casing also voids your warranty.

l The camera arm on your SMART product has joints that present a pinch hazard when you

move the camera arm. Keep clear of the pinch points.

l Do not stare into the lamp or shine the lamp directly into someone’s eyes. Turn off the lamp

when displaying or capturing images of people.

l Do not overload power outlets or extension cords as this can result in a fire or electric shock.

l Turn off and disconnect your SMART product before a thunderstorm. During a thunderstorm,

do not touch your SMART product or the power plug, because there is a risk of electrical

shock.

l To reduce the risk of fire or electric shock, do not expose the SMART product to rain or

moisture.

C A U T I O N

l Place your SMART product on a solid surface to prevent it from falling.

l If you have a security cable attached to your SMART product, do not carry or swing your

SMART product by the security cable.

l Do not connect non-shielded interface cables to your SMART product and do not leave

cables connected to unused connectors, because this can cause interference levels that

exceed FCC regulations.

l Avoid setting up and using the SMART product in an area with excessive levels of dust,

humidity and smoke.

I M P O R T A N T I N F O R M A T I O N

l Do not block or cover the openings or slots on your SMART product. These slots provide

ventilation, ensure reliable operation and protect your SMART product from overheating.

l Do not carry your SMART product by the camera arm. Carry it by the base of the unit.

l Disconnect your SMART product from the power outlet before cleaning it. Use a clean damp

cloth and do not use liquid or aerosol cleaners or solvents when cleaning your SMART

product.

l Only use your SMART product with the type of power source that is written on the power

supply and do not modify the plug.

l Do not aim the camera lens at the sun.

l If your SMART product requires replacement parts, make sure the service technician uses

replacement parts specified by SMARTTechnologies or parts with the same characteristics

as the original.

Important information i

Chapter 1: Overview 1

Document camera features 2 Document camera views 3 Parts of the document camera 3 Document camera software 6

Chapter 2: Setting up your SMARTDocumentCamera 9

Basic connection 9 Setup configurations for Camera view and SDCard view 11 Connecting your document camera to an externaldisplay 13 Downloading software 15 Activating SMARTNotebook 3DTools and MixedRealityTools 16

Chapter 3: Using your SMARTDocumentCamera 19

Understanding Computer, Camera and SD Card views 19 Performing basic operations 21 Using your document camera with SMARTNotebook software 24

Chapter 4: Using your SMARTDocumentCamera in Computer view 27

Setting Computer view 27 Using Computer view 28

Chapter 5: Using your SMARTDocumentCamera in Camera view 29

Setting Camera view 30 Using Microscope mode 31 Using the Camera view’s on-screen display menu 31 Saving images to a memory card 40

Chapter 6: Using your SMARTDocumentCamera in SD Card view 43

Setting your document camera to SD Card view 43 Using the SD Card view display 44 Using the SD Card view on-screen display menu 44

Chapter 7: Using SMARTNotebook 3DTools and Mixed Reality Tools 51

Incorporating 3D content into your lessons 52 Getting started 52 Using the mixed reality mat 53 Inserting and manipulating 3Dmodels 56

iii

C O N T E N T S

Using Mixed Reality Tools 62 Using SketchUp sketching software and Google3DWarehouse 65

Chapter 8: Troubleshooting 69

Document camera issues 69 SD Card view issues 70

Appendix A: Hardware environmental compliance 71

Waste Electrical and Electronic Equipment regulations (WEEE directive) 71 Restriction of Certain Hazardous Substances (RoHS directive) 71 Packaging 71 China’s Electronic Information Products regulations 72

Index 73

Chapter 1

Document camera features 2

Camera 2 Output 2 Physical construction 2 Software 2

Image storage 2 Document camera views 3 Parts of the document camera 3

Adjustable camera arm and camera head 3

Control panel 4

Rear connection panel 4

Side connection panel 5

NTSC/PAL switch 5

Mixed reality cube 5

Power supply 5

USB cable 5

VGA cable 6

Anti-glare sheet 6 Document camera software 6

SMARTNotebook software and SMARTProductDrivers 6

Image Mate software (Windows only) 7

Your SMARTDocumentCamera™ 330 enables you to display 3D objects, printed documents and

microscope slides on your computer, projector or television. You can capture images and save them

to a SMARTNotebook™ collaborative learning software file or to an SD or SDHC memory card.

Your document camera integrates with SMARTNotebook software and SMARTBoard® interactive

whiteboards, creating an interactive presentation environment.

If you have a mixed reality cube and SMARTNotebook software 10.8 or later, you can use the cube

with your document camera to manipulate 3D models in SMARTNotebook files.

C H A P T E R 1

Overview

Document camera features

Camera

l High resolution 1.3 MP CMOS sensor

l 5.2× optical zoom, 8× digital zoom

l Up to 30 frames per second

l Automatic or manual focus

l Microscope mode that doesn’t require adapters

Output

l SXGA, WXGA, 720p or XGA resolution

l DVI-D output

Physical construction

l Security lock slot

l Collapsible design for easy transport and storage

l Bright LED camera lamp

Software

l SMARTNotebook software, including SMARTNotebook 3DTools and MixedRealityTools

software

l SMARTProductDrivers

l Image Mate® software

Image storage

l Supports memory cards with a built-in SD slot

l Supports USB memory sticks with a built in USB hub

l Supports image storage on connected computer

C H A P T E R 1

Overview

Document camera views

Your document camera has three views you can use to control how it sends data to a computer,

projector or television.

l Computer view displays images from your document camera in a SMARTNotebook file on

your computer.

l Camera view controls your document camera from the camera’s control panel and displays

images on a projector or television. You can also view images through SMARTNotebook

software.

l SD Card view controls your document camera from the camera’s control panel and displays

images from a memory card on a connected projector or television.

See Understanding Computer, Camera and SD Card views on page 19 for more information on these

views.

Parts of the document camera

Adjustable camera arm and camera head

You can unfold and adjust the camera arm. You can also rotate the camera head to display objects at

a range of angles. The camera head has a zoom dial, an auto focus button and an LED light with a

light switch.

C H A P T E R 1

Overview

Control panel

You can use the control panel to switch between Computer, Camera and SD Card view, capture an

image to a memory card and adjust brightness settings. You can also use it to control features and

settings in the Camera view or the SD Card view’s on-screen display menu.

N O T E

On some cameras, Camera view is represented by a symbol.

For information on views, see Understanding Computer, Camera and SD Card views on page 19.

Rear connection panel

The rear connection panel has 12V DC, DVI-D Out, VGA Out, VGAIn, Composite video out and

USB-B connectors.

C H A P T E R 1

Overview

Side connection panel

The side connection panel has a security lock slot, an SD or SDHC memory card slot, a USB-A

connector, a switch for selecting VGA DVI-D or composite video output, and a switch to select either

SXGA, WXGA, 720p or XGA resolution.

NTSC/PAL switch

The NTSC/PAL switch is on the bottom of your document camera. This switch enables you to

change the format of composite video output for your television. See Switching between NTSC and

PAL on page 15.

Mixed reality cube

With a mixed reality cube, you can interact with 3D models in SMARTNotebook

software using Mixed Reality Tools. See Using SMARTNotebook 3DTools and Mixed

Reality Tools on page 51.

Power supply

Your document camera comes with a power supply and a country-specific

power cable.

USB cable

Use the USB cable to connect your document camera to your computer. You can

display objects, capture images to SMARTNotebook files and control your

document camera from SMARTNotebook software.

C H A P T E R 1

Overview

VGA cable

Use the VGA cable to connect your document camera to a projector or display. You

can display objects, capture images to a memory card and use the features in the

on-screen display menus.

Anti-glare sheet

Place the anti-glare sheet over printed documents to reduce glare.

Document camera software

Your document camera includes software downloads that will help you present images from your

document camera.

SMARTNotebook software and SMARTProductDrivers

Your document camera uses SMARTNotebook software and

SMARTProductDrivers. SMARTNotebook software is presentation software

designed to work with SMARTDocumentCameras and the touch features of

SMARTBoard interactive whiteboards. In addition, if you have a mixed reality cube,

you can manipulate 3D models in SMARTNotebook files using Mixed Reality Tools

(see Using SMARTNotebook 3DTools and Mixed Reality Tools on page 51).

You can download SMARTNotebook software and SMARTProductDrivers at

smarttech.com/software.

You can find system requirements for your computer in the SMARTNotebook software 10.8 release

notes (smarttech.com/kb/158853).

I M P O R T A N T

You need SMARTNotebook software 10.8 or later to use SMARTNotebook 3DTools and Mixed

Reality Tools.

C H A P T E R 1

Overview

Image Mate software (Windows only)

You can use your document camera with Image Mate software. Visit the SMART download page at

smarttech.com/software to download Image Mate software.

Chapter 2

SMARTDocumentCamera

Basic connection 9 Setup configurations for Camera view and SDCard view 11

Connecting your document camera and computer to different displays 12

Connecting your document camera and computer to a shared display 12 Connecting your document camera to an externaldisplay 13

Connecting to a projector or flat-panel display 13

Switching between VGA DVI-D and Composite output 13 Connecting to a digital projector or HD display with DVI-D 14 Connecting to a television 14

Switching between NTSC and PAL 15 Setting output resolution 15

Downloading software 15 Activating SMARTNotebook 3DTools and MixedRealityTools 16

Basic connection

Connect your SMARTDocumentCamera to a power supply and your computer to use your

document camera with SMARTNotebook software.

I M P O R T A N T

This configuration requires SMARTNotebook software. To use Camera view or SD Card view,

connect your document camera directly to an external display.

C H A P T E R 2

Setting up your SMARTDocumentCamera

g To connect the power supply

1. Connect the power supply cable to the 12V DC receptacle on the rear connection panel.

C A U T I O N

Ensure you connect the power cable to the power supply before connecting the power plug to

a power outlet.

2. Connect a country-specific power cable to the power supply, and then connect the plug to a

power outlet.

C H A P T E R 2

Setting up your SMARTDocumentCamera

g To connect your document camera to your computer

Connect the USB-B plug of your USB cable to your document camera, and then connect the USB-A

plug to your computer.

Setup configurations for Camera view and SDCard view

After you complete the basic connection procedure (see page 9), you can connect your document

camera to an external display. This enables you to use the document camera in Camera view and SD

Card view (see page 19).

You can connect your computer and your document camera to different displays or they can share a

display.

C H A P T E R 2

Setting up your SMARTDocumentCamera

Connecting your document camera and computer to different displays

In this configuration your document camera images appear on one display, and your computer’s

desktop appears on the other display. You can also access document camera images through

SMARTNotebook software on your computer.

g To connect your document camera and computer to different displays

1. Complete the basic connection steps (see page 9).

2. Connect your computer or laptop to the projector of an interactive display.

N O T E

This is the normal configuration for using interactive whiteboards.

3. Connect your document camera to another external display (see page 13).

Connecting your document camera and computer to a shared display

In this configuration your document camera is connected to your computer with both a USB and a

VGA cable. Your document camera is connected to an external display.

g To connect your document camera and computer to a shared display

1. Complete the basic connection steps (see page 9).

2. Connect your computer’s VGA Out port to your document camera’s VGA In port with a VGA

cable.

3. Connect your document camera to an external display with a VGA cable (see page 13).

N O T E

DVI-D or composite video displays will not display your computer view. A VGA display is

required.

This configuration makes it easy to transition from Computer view to Camera view or SD Card

view using the same projector or display for all three views.

C H A P T E R 2

Setting up your SMARTDocumentCamera

Connecting your document camera to an externaldisplay

You can connect your document camera directly to an external display to enable the following

functions:

l Use Camera view to view the camera image in full-screen on the external display.

l Use SD Card view to view a full-screen slide show on the external display.

l Access the Camera view’s or SD Card view’s on-screen display menu.

Connecting to a projector or flat-panel display

You can connect your document camera to a projector or a display with the VGA cable.

C A U T I O N

Ensure your projector or display is not connected to a power outlet when connecting it to your

document camera.

g To connect to a projector or display

1. Connect the VGA cable to the VGA Out connector on the back of your document camera.

2. Connect the other end of the VGA cable to the VGA In connector on your projector or display.

Switching between VGA DVI-D and Composite output

If you’re using a projector or computer display with a VGA or DVI-D cable, switch your document

camera to VGA DVI-D mode. If you’re using a television with the Composite video cable, switch your

document camera to Composite mode.

g To switch to VGA DVI-D mode

Switch the VGA DVI-D/Composite switch on the side panel to VGA DVI-D.

g To switch to composite mode

Switch the VGA DVI-D/Composite switch on the side panel to Composite.

C H A P T E R 2

Setting up your SMARTDocumentCamera

Connecting to a digital projector or HD display with DVI-D

You can connect your document camera to a digital projector or high-definition display using a DVI-D

single link cable.

C A U T I O N

Ensure your digital projector or display is not connected to a power outlet when connecting it to your

document camera.

N O T E S

l Don’t use a DVI-I or DVI-A cable.

l You can use a DVI-D dual link cable, but it will function as a single link DVI-D.

l If you connect your document camera directly to a projector or high-definition display with a

DVI-D cable, you display only the camera image, and not your computer desktop or SMART

Notebook presentation.

g To connect to a digital projector or display

1. Connect a DVI cable from the DVI-DOut connector on your document camera to the DVI-DIn

connector of your digital projector or high-definition display.

2. Switch to VGA DVI-D mode (see page 13).

Connecting to a television

You can connect your document camera to a television with a Composite video cable.

C A U T I O N

Ensure your television is not connected to a power outlet when connecting it to your document

camera.

g To connect to a television

1. Connect a Composite video cable from the Composite Out connector on your document

camera to the Video In connector on your television.

2. Switch to Composite mode. See Switching between VGA DVI-D and Composite output on the

previous page.

C H A P T E R 2

Setting up your SMARTDocumentCamera

Switching between NTSC and PAL

When you connect your document camera to a television, switch it to your television’s encoding

system (either NTSC or PAL).

g To switch between NTSC and PAL

Switch the NTSC/PAL switch on the bottom of your document camera to NTSC if your television

uses NTSC encoding, or to PAL if your television uses PAL encoding.

Setting output resolution

You can set your document camera’s output resolution to match the projector or display you’re using.

g To set the output resolution

Set the SXGA/WXGA/720p/XGA switch to match the resolution of your display. Refer to the chart

below to determine the output resolution you need.

Setting Resolution

SXGA 1280 × 1024

WXGA 1280 × 800

720p 1280 × 720

XGA 1024 × 768

Downloading software

Your document camera includes software downloads that you can use to create more effective

presentations.

g To install SMARTNotebook software and SMARTProductDrivers

1. Go to smarttech.com/software.

2. Scroll to SMARTNotebook collaborative learning software.

3. Under Choose a version, select the latest version of SMARTNotebook software for

Windows® or Mac, and then follow the on-screen instructions.

C H A P T E R 2

Setting up your SMARTDocumentCamera

g To download and install Image Mate software

1. Visit the SMART download page at smarttech.com/software.

2. Scroll to Image Mate software for SMARTDocumentCameras.

3. Under Choose a version, select Image Mate 2.0 software for SMART Document Camera

330, and then follow the on-screen instructions.

Activating SMARTNotebook 3DTools and MixedRealityTools

SMARTNotebook 3DTools and Mixed Reality Tools provide an intuitive way for students and

teachers to explore digital content with the SMARTDocumentCamera.

When you connect your document camera to your computer, SMARTNotebook 3DTools and Mixed

Reality Tools activate automatically. If you want to use SMARTNotebook 3DTools on a computer

that has never been connected to a document camera, you can activate SMARTNotebook 3DTools

by obtaining a product key and following the procedure below.

N O T E

You can obtain a product key for SMARTNotebook 3DTools by registering your document

camera’s serial number at smarttech.com/register.

g To activate SMARTNotebook 3DTools

1. For Windows operating systems, select Start > All Programs > SMART Technologies >

SMARTTools > SMART Product Update.

For MacOSX operating system software, browse to and double-click

Applications\SMARTTechnologies\SMARTTools\SMARTProduct Update.

The SMART Product Update window appears.

2. Click Activate in the SMART Notebook row.

The SMART Software Activation dialog box appears.

3. Click Add.

4. Type the product key you received from SMART in the Product Key box, and then click Add.

5. Click license agreement, review the license agreement, and then click Close.

C H A P T E R 2

Setting up your SMARTDocumentCamera

6. If you accept the license agreement, select the I accept the terms in the license agreement

check box.

7. Click Next.

SMARTNotebook 3DTools activates.

8. Click Finish, and then close the SMART Product Update window.

Chapter 3

SMARTDocumentCamera

Understanding Computer, Camera and SD Card views 19

Identifying view features 20 Setting document camera views 21

Performing basic operations 21

Positioning your document camera 21 Turning you document camera on and off 22 Using the LED light 22 Displaying printed documents 22 Inserting and removing a memory card 23

Using your document camera with SMARTNotebook software 24

Understanding Computer, Camera and SD Card views

You can use your SMARTDocumentCamera in Computer, Camera and SD Card views. Each view

enables you to do different things and requires a specific connection to either a display, projector or

computer.

l Computer view

Connect your document camera to your computer with the included USB 2.0 cable, and then

set your document camera to Computer view to view document camera images only in

SMARTNotebook software.

You can then save images to your SMARTNotebook file for later presentation, or if your

computer is connected to an interactive whiteboard, projector or television, you can deliver your

SMARTNotebook presentation with live images from your document camera.

See Using your SMARTDocumentCamera in Computer view on page 27.

C H A P T E R 3

Using your SMARTDocumentCamera

l Camera view

Connect your document camera to a projector or television, and then set your document

camera to Camera view. You can then view full-screen images from your document camera

using a projector or high-definition display, even without a computer. You can still view images

through SMARTNotebook software.

You can use the Camera view on-screen display menu for greater control of the image, using

Microscope mode, highlight boxes, screen masks and more.

See Using your SMARTDocumentCamera in Camera view on page 29.

l SD Card view

Connect your document camera to a projector or television, place an SD or SDHC memory

card in your document camera, and then set your document camera to SDCard view. You can

then view full-screen images and slide shows from the memory card directly on a projector or

high-definition display, even without a computer.

You can use the SD Card view’s on-screen display menu for greater control of the image, using

highlight boxes, screen masks and more.

See Using your SMARTDocumentCamera in SD Card view on page 43.

Identifying view features

The following table describes the differences between each view:

Feature description Computer

view

View computer input (VGA In) Yes (VGA

Out only)

View document camera image Yes (DVI-D

Out only)

View pictures from a memory card No No Yes

Access memory card from computer with a USB cable Yes

Control document camera from computer Yes

Capture to SMARTNotebook or Image Mate software Yes

Capture to a memory card Yes

Access related on-screen display menu No Yes Yes

Camera view

SD Card view

No No

Yes No

Yes

1. Only when USB-B mode is set to SD Storage. See Setting USB-B SD Storage mode on page 40.

2. Only when USB-B mode is set to Application. See Setting USB-B Application mode on page 39.

C H A P T E R 3

Using your SMARTDocumentCamera

The following table describes outputs when your document camera is connected to a display with

VGA DVI-D or Composite Video Out:

Feature description Computer

view

Connect to projector or display (VGA Out) VGA In Camera

Connect to high-definition projector or display (DVI-D Out)

Connect to television (Composite Video Out) N/A Camera

Camera image

Camera view


Camera image


Setting document camera views

g To set Computer view

Press the Computer view button on the control panel. For more information, see page 27.

g To set Camera view

Press the Camera view button on the control panel. For more information, see page 30.

SD Card view

Memory card images

g To set SD Card view

Press the SD Card view button on the control panel. For more information, see Setting your document camera to SD Card view on page 43.

Performing basic operations

Use the following operations when your document camera is in any view.

Positioning your document camera

The camera arm unfolds and the camera head rotates so you can position your document camera to

display objects.

C H A P T E R 3

Using your SMARTDocumentCamera

g To unfold and position your document camera

1. Place a hand on the base of the document camera to stabilize it, and then pull the camera arm

upward and forward.

2. Rotate the camera head and aim the lens at your subject.

Turning you document camera on and off

g To turn your document camera on

Press the Power button on the control panel.

The power light turns from amber to flashing green. When the light becomes solid green, your

document camera is operational.

g To turn your document camera off

Press the Power button on the control panel.

The power light turns from green to amber.

Using the LED light

You can use the LED light on the camera head to illuminate your subject.

g To turn the LED light on

Switch the LED light switch to the left. See Parts of the document camera on page 3.

C A U T I O N

Do not stare into the lamp or shine the lamp directly into someone’s eyes. Turn the light off when

displaying or capturing images of people.

Displaying printed documents

When you set your document camera to Computer view or Camera view, you can display printed

documents, use the anti-glare sheet to reduce glare, optimize the image for text documents with Text

modes and optimize the image for documents with graphics with Graphics modes.

C H A P T E R 3

Using your SMARTDocumentCamera

g To display printed documents

1. Place your documents on the table.

2. Adjust the document camera and aim its lens at your documents.

3. Rotate the zoom dial to adjust the zoom magnification.

Press the Auto Focus button to adjust the focus.

g To reduce glare with the anti-glare sheet

If glare makes it difficult for you to read printed documents that you’re displaying, place the anti-glare

sheet on top of the printed materials.

g To optimize the image for text documents

1. When your document camera is in Camera view, press Menu on the control panel.

The on-screen display menu appears.

2. Select Image Setting, and then press Enter .

3. Select Image mode, and then press Enter .

4. Select either Text 1, Text 2 or Text 3, and then press Enter . See Camera view Image

Settings on-screen display menu on page 32 for an explanation of the settings.

g To optimize the image for documents with graphics

1. When your document camera is in Camera view, press Menu on the control panel.

The on-screen display menu appears.

2. Select Image Setting, and then press Enter .

3. Select Image mode, and then press Enter .

4. Select either Graphics 1 or Graphics 2, and then press Enter . See Camera view Image

Settings on-screen display menu on page 32 for an explanation of the settings.

Inserting and removing a memory card

Your document camera has a memory card slot, enabling you to save document camera images

(when your document camera is in Computer view or Camera view) or to display previously captured

images (when your document camera is in SD Card view).

C H A P T E R 3

Using your SMARTDocumentCamera

C A U T I O N

Avoid static electricity near a memory card because it can damage the card.

g To insert a memory card

Press the Camera view button on the control panel.

2. Insert a memory card into the card slot on the side panel.

I M P O R T A N T

Set your document camera to Application mode (see Setting USB-B Application mode

on page 39) if you want to capture images to the memory card.

Ensure the label on the memory card is facing up.

g To remove a memory card

Press the Camera view button on the control panel and wait until your document camera

1. displays a live image.

2. Push in the memory card to eject it, and then remove the card.

C A U T I O N

To prevent memory card damage, do not remove the memory card while capturing or deleting

images.

Using your document camera with SMARTNotebook software

Your SMARTDocumentCamera integrates with SMARTNotebook software, enabling you to control

your document camera from your computer or from a SMARTBoard interactive whiteboard or display.

You can display objects, capture an image and your annotations on an image to a SMARTNotebook

page, zoom, focus and adjust brightness settings.

N O T E

For information on using SMARTNotebook 3DTools and Mixed Reality Tools, see Using

SMARTNotebook 3DTools and Mixed Reality Tools on page 51.

C H A P T E R 3

Using your SMARTDocumentCamera

g To open a SMARTDocumentCamera window

1. Connect your SMARTDocumentCamera to your computer and turn on the document camera.

2. Place the object or objects you want to display under the camera.

Press SMARTDocumentCamera .

A SMARTDocumentCamera window appears.

N O T E

Alternatively, you can open the SMARTDocumentCamera window by pressing Capture

on the SMARTDocumentCamera control panel.

4. Do any of the following:

Press Zoom In to zoom in.

Press Zoom Out to zoom out.

Press Increase Brightness to brighten the image.

Press Decrease Brightness to darken the image.

Press Focus In or Focus Out to change the focus manually.

Press Autofocus to change the focus automatically.

5. Press Close when you’re done.

C H A P T E R 3

Using your SMARTDocumentCamera

g To convert the image

1. Open a SMARTDocumentCamera window.

Press Additional Settings .

3. Do any of the following:

Select Rotate 180 Degrees to rotate the image 180°.

Select Convert to Color to convert a black and white image to color.

Select Convert to Black and White to convert a color image to black and white.

Select Convert to Positive to convert a negative image to positive.

Select Convert to Negative to convert a positive image to negative.

g To use Microscope mode

1. Open a SMARTDocumentCamera window.

Press Additional Settings , and then select Start Microscope Mode.

When you’re done, press Additional Settings , and then select Stop Microscope Mode.

g To take a screen capture

1. Open a SMARTDocumentCamera window.

Press Capture and Close to insert a screen capture on the current page and close the window.

Press Capture to New Page to insert a screen capture on a new page and keep the window open.

g To take a series of screen captures

1. Open a SMARTDocumentCamera window.

Press Capture with Time-Lapse , and then select a period of time. (For example, if you

2. want to take a screen capture every 15 seconds, select 15 Seconds.)

3. Press when you’re done.

Chapter 4

SMARTDocumentCamera in Computer view

Setting Computer view 27 Using Computer view 28

This view is for presenting images from your SMARTDocumentCamera through your

SMARTNotebook software or Image Mate software. Connect your computer to both your document

camera and your projector, and then set your document camera to Computer view.

The interactive whiteboard or projector displays your computer desktop or SMARTNotebook file, and

you can view or capture images from the camera.

Computer view is accessible in all computer, projector and document camera setup configurations.

Setting Computer view

I M P O R T A N T

Your document camera must be in Application mode. See Setting USB-B Application mode on

page 39.

g To set Computer view

1. Ensure your document camera is connected to your computer with the included USB 2.0 cable.

2. Ensure your computer is connected to a projector or a display.

Press the Computer view button on the control panel.

C H A P T E R 4

Using your SMARTDocumentCamera in Computer view

Using Computer view

Computer view enables you to bring images from your document camera into SMARTNotebook

software.

g To use Computer view

Refer to Using your document camera with SMARTNotebook software on page 24.

Chapter 5

SMARTDocumentCamera in Camera view

Setting Camera view 30 Using Microscope mode 31 Using the Camera view’s on-screen display menu 31

Camera view Image Settings on-screen display menu 32 Camera view Special Tools on-screen display menu 34

Using the highlight feature 34 Using image masks 36 Using the scroll feature 36 Using the Picture in Picture (PiP) feature 37

Camera view Function Settings on-screen display menu 38

Setting USB-B mode 39 Setting USB-B Application mode 39 Setting USB-B SD Storage mode 40

Saving images to a memory card 40

Capturing images to a memory card 40 Transferring images from a memory card to your computer 41

Connect your SMARTDocumentCamera to an external display to see a full-screen image from your

document camera.

You can use your document camera in Camera view to perform the following tasks:

l Display objects

l Capture images to an SD or SDHC memory card

l Capture images to SMARTNotebook or Image Mate software

l Use the features and settings in the on-screen display menu

C H A P T E R 5

Using your SMARTDocumentCamera in Camera view

l Use Microscope mode to use your document camera with a standard microscope eyepiece

without additional adapters

Setting Camera view

Switch your document camera to Camera view to display images on a projector, flat-panel display or

television.

I M P O R T A N T

Your document camera must be connected directly to an external display. See Connecting your

document camera to an externaldisplay on page 13.

g To switch to Camera view

1. Connect your document camera to a projector or flat-panel display with the appropriate cable

(see Connecting your document camera to an externaldisplay on page 13).

Press the Camera view button on the control panel.

g To display objects

Press the Power button on the control panel.

Press the Camera view button on the control panel.

3. Place the object you want to display under the camera.

4. Rotate the camera head to aim the lens at your subject.

g To adjust the zoom magnification

Rotate the zoom dial on the camera head to increase or decrease the zoom magnification.

g To automatically adjust the focus

Press the Auto Focus button on the camera head to automatically focus the image.

g To adjust brightness settings

Press the Brighten or the Darken button on the control panel.

C H A P T E R 5

Using your SMARTDocumentCamera in Camera view

Using Microscope mode

The SMART Document Camera enables you to view the microscope stage through the document

camera without additional attachments.

g To display a microscope slide

1. Place a slide or object on the stage of the microscope.

2. Focus the microscope so that the subject is in sharp focus.

3. Position the microscope under your document camera so the camera lens is aligned with the

microscope eyepiece.

C A U T I O N

Ensure you do not hit your document camera lens with the microscope. This could damage

your document camera’s lens.

Press the Camera view button on the control panel.

5. Press Menu on the control panel.

6. Select the Image Setting menu.

7. Use the up and down arrow buttons to select Microscope mode, and then press Enter .

8. Use the up and down arrow buttons to select On, and then press Enter .

Using the Camera view’s on-screen display menu

You use the on-screen display menu to adjust several settings for your document camera.

g To open the Camera view’s on-screen display menu

1. Set your document camera to Camera view.

2. Press the Menu button on the control panel.

The on-screen display menu appears.

3. Press the up and down arrow buttons on the control panel to navigate to a menu item.

4. Press the left and right arrow buttons to navigate forward or backward through menu items.

5. Press Enter to select a menu item.

C H A P T E R 5

Using your SMARTDocumentCamera in Camera view

To return to the previous menu level, use the down arrow button to navigate to Back , and

then press Enter .

To exit the menu, press Menu.

The following on-screen display menu options are available when your document camera is in

Camera view:

Menu Options

Image Settings Brightness, Reset Brightness, Auto focus, Focus, Shutter

Speed, White Balance, R/B-Gain, Image mode, Edge Effect, Gamma, Image Rotation, Microscope mode, Color/B&W and Positive/Negative. See Camera view Image Settings on-screen display menu below.

Special Tools Highlight, Mask, Scroll and Picture in Picture. See Camera view

Special Tools on-screen display menu on page 34.

Function Settings USB-B mode, Frequency, Save Settings, Load Settings, Menu

Display and Language. See Camera view Function Settings on- screen display menu on page 38.

Camera view Image Settings on-screen display menu

g To access the Image Settings menu

Select Camera view > Menu > Image Settings .

Image Settings menu options Description

Brightness

Auto Adjusts image brightness automatically

Manual Allows you to manually adjust image brightness

Reset Brightness

Yes Resets image brightness

No Cancels resetting

AF mode

Push

Zoom Sync Automatically sets the focus when you adjust the zoom

Focus

Sets the focus when you press the Auto Focus button

Allows you to manually adjust focus

C H A P T E R 5

Using your SMARTDocumentCamera in Camera view

Image Settings menu options Description

Shutter Speed

Slow Sets a slow shutter speed, resulting in a brighter image, but with

more blur

Fast Sets a fast shutter speed, resulting in a darker image, but with

less blur

White Balance

Auto Sets white balance automatically

One-Push

Sets white balance when you press the Auto Focus button

Manual Allows you to manually set the White Balance, using red grain

and blue grain

R-Grain

B-Grain

Manually sets red grain

Manually sets blue grain

Image mode

Text 1

Optimizes image for displaying text documents by emphasizing contrast. Setting is low at Text 1 and high at Text 3.

Text 2

Text 3

Graphics 1 Optimizes image for displaying graphics. Displays Edge Effect

and Gamma icons.

Graphics 2 Optimizes image from DLP projector

Edge Effect

Gamma

Emphasizes image outlines. Set to Low, Middle or High.

Sets Gamma for the image. Set to Low, Middle or High.

Image Rotation

Off Displays normal image rotation

On Rotates image 180°

Microscope mode

On Turns on Microscope mode

Off Turns off Microscope mode

Color/B&W

Color Displays color images

B&W Displays black and white images

Positive/Negative

Positive Displays normal image

Negative Displays film negative image

C H A P T E R 5

Using your SMARTDocumentCamera in Camera view

1. Visible only when Brightness is set to Auto

2. Visible only when White Balance is set to Manual

3. Visible only when Image mode is set to Graphics 1

Camera view Special Tools on-screen display menu

g To access the Special Tools menu

Select Camera view > Menu > Special Tools .

Special Tools menu options Description

Highlight

Highlight On

Adjust Transparency

Highlights a center square on the displayed image

Adjust Size

Mask

Mask On

Adjust Transparency

Covers the displayed image with an adjustable screen mask

Scroll

Scroll on

Zooms in on the displayed images and enables you to move the zoomed area with the up, down, left and right arrow buttons on

×2

PiP

×3

×4

the control panel

Takes a picture, and then displays that picture in a corner of the screen while you move or zoom the camera

Using the highlight feature

When you use the highlight feature, a square in the center of the displayed image highlights your

subject. You can change the size, transparency and position of the highlight square.

N O T E

The highlight feature is for display purposes only. If you capture an image while the highlight square

is on, the image doesn’t include the highlight.

C H A P T E R 5

Using your SMARTDocumentCamera in Camera view

g To use the highlight feature

1. Display an object in Camera view, and then press Menu on the control panel.

The on-screen display menu appears.

Press the up and down arrow buttons to select Special Tools , and then press Enter .

3. Use the up and down arrow buttons to select Highlight > Highlight On, and then press Enter

Your document camera highlights a square in the center of the image and obscures the edges

of the image.

g To move the highlight square

Use the up, down, right and left arrow buttons to move the highlight square.

g To change highlight transparency

1. Press Menu.

The on-screen display menu appears.

Press the up and down arrow buttons to select Special Tools , and then press Enter .

3. Press the up and down arrow buttons to select Highlight On, and then press Enter .

4. Press the up and down arrows to select Highlight transparency.

5. Press Enter to save your settings.

g To change the highlight area size

1. Press the Menu button on the control panel.

The on-screen display menu appears.

Press the up and down arrow buttons to select Special Tools , and then press Enter .

3. Press the up and down arrow buttons to select Highlight, and then press Enter .

4. Select Adjust size, and then press Enter .

5. Press the up, down, left and right arrow buttons to change the highlight area size.

6. Press Enter to save your settings.

g To turn off the highlight feature

Press Enter .

C H A P T E R 5

Using your SMARTDocumentCamera in Camera view

Using image masks

Image masks obscure most of the image. You can resize or move the mask to reveal more of the

image.

N O T E

The image mask feature is for display purposes only. If you capture an image while the imagemask

is on, the image doesn’t include the image mask.

g To use an image mask

1. Display an object in Camera view, and then press Menu on the control panel.

The on-screen display menu appears.

Press the up and down arrow buttons to select Special Tools , and then press Enter .

3. Press the up and down arrow buttons to select Mask on, and then press Enter .

An image mask appears on the image.

g To move the image mask

Press the up, down, right and left arrow buttons to move the mask area.

g To change image mask transparency

1. Press Menu.

The on-screen display menu appears.

Press the up and down arrow buttons to select Special Tools , and then press Enter .

3. Press the up and down arrow buttons to select Image Mask Transparency, and then press

Enter .

4. Press the up and down arrows to select Adjust transparency.

5. Press Enter to save your settings.

g To turn off an image mask

Press Enter .

Using the scroll feature

The scroll feature zooms in on the image and allows you to move the zoomed area with the arrow

buttons.

C H A P T E R 5

Using your SMARTDocumentCamera in Camera view

N O T E

The scroll feature is for display purposes only. If you capture an image while the scroll is on, the

captured image is the unscrolled image.

g To display the scroll feature

1. Display an object in Camera view, and then press Menu on the control panel.

The on-screen display menu appears.

2. Press the up and down arrow buttons to select Special Tools, and then press Enter .

3. Press the up and down arrow buttons to select Scroll, and then press Enter .

4. Press the up and down arrow buttons to select Scroll On, and then press Enter .

Your document camera displays a zoomed area of the image.

g To move the zoomed scroll area

Use the up, down, right and left arrows to move the zoomed scroll area.

g To change the scroll area magnification

When setting the scroll feature, select either ×2, ×3 or ×4, and then press Enter .

Using the Picture in Picture (PiP) feature

The Picture in Picture (PiP) feature captures a temporary image from your document camera, and

then displays it in one corner of the display. You can then change what is under the camera without

the temporary image changing.

N O T E

The PiP feature is for display purposes only. If you capture an image while the PiP is on, the image

doesn’t include the PiP.

g To display the PiP image

1. Display an object in Camera view, and then press Menu on the control panel.

The on-screen display menu appears.

2. Press the up and down arrow buttons to select Special Tools, and then press Enter .

3. Press the up and down arrow buttons to select PiP, and then press Enter .

Your document camera displays a picture in picture image.

C H A P T E R 5

Using your SMARTDocumentCamera in Camera view

g To move the PiP image

When displaying the PiP image, press the up, down, left and right arrow buttons on the control panel

to move the image.

g To turn off the PiP setting

Press Enter on the control panel.

Camera view Function Settings on-screen display menu

g To access the Functions Settings menu

Select Camera view > Menu > Function Settings .

Function Settings menu

Description

options

USB-B mode

SD Storage Allows you to copy or view your memory card from your

computer. See Setting USB-B SD Storage mode on page 40.

Application Use SMARTNotebook software to control your document

camera, and more. See Setting USB-B Application mode on the next page.

Frequency

60 Hz Sets frequency at 60 Hz

50 Hz Sets frequency at 50 Hz

Save Setting

1 Saves presets for setting 1

2 Saves presets for setting 2

3 Saves presets for setting 3

4 [Power On] Saves presets for when you turn your document camera on

Cancel Cancels preset save

Load Setting

1 Loads preset 1

2 Loads preset 2

3 Loads preset 3

Default Loads default settings

C H A P T E R 5

Using your SMARTDocumentCamera in Camera view

Function Settings menu

Description

options

4 [Power On] Loads preset for when you turn your document camera on

Cancel Cancels load setting

Menu Display

On Turns on menu display

Off Turns off menu display

Language

English Sets language to English

Français Sets language to French

Deutch Sets language to German

Español Sets language to Spanish

Setting USB-B mode

USB-B mode sets how your document camera, your computer and a memory card interact.

g To access the USB-B mode setting

Select Camera view > Menu > Function Settings > USB-B mode .

Action SD Storage

mode

Application mode

See the memory card from your computer Yes No

View and use your document camera from

No Yes

SMARTNotebook or Image Mate software

Capture image to the memory card in both Computer view

No Yes

and Camera view

SD Card view menu includes SD Settings No Yes

Setting USB-B Application mode

To use your document camera with your computer, you must set it to Application mode in the Camera

view on-screen display menu.

I M P O R T A N T

Your document camera must be in Camera view to set it to Application mode. It cannot be in

Computer view or SD Card view.

C H A P T E R 5

Using your SMARTDocumentCamera in Camera view

g To set your document camera to Application mode

1. Connect your document camera to a projector or flat-panel display with the VGA cable (see

page 13).

2. Turn on your computer, and set it to Camera view.

3. Press Menu on the control panel.

The on-screen display menu appears.

4. Press the up and down arrow buttons on the control panel to select Function Setting, and then

press Enter .

5. Select USB-B mode, and then press Enter .

6. Select Application and then press Enter .

Setting USB-B SD Storage mode

This mode enables you to see the contents of your memory card from your computer.

g To set SD Storage mode

1. Connect your document camera to a projector, flat-panel display or television (see page 13).

2. Press Menu on the control panel.

The on-screen display menu appears.

3. Press the up and down arrow buttons on the control panel to select Function Setting, and then

press Enter .

4. Select USB-B mode, and then press Enter .

5. Select SD Storage and then press Enter .

Saving images to a memory card

You can capture images to a memory card when your document camera is in Camera view.

Capturing images to a memory card

g To capture images to a memory card

1. Set your document camera to Camera view. See Setting Camera view on page 30.

2. Position your document camera.

C H A P T E R 5

Using your SMARTDocumentCamera in Camera view

3. Make any camera settings you require using the Camera view’s on-screen display menu.

Press the Capture button on the document camera control panel.

The camera capture icon appears, indicating that a photo is being taken.

I M P O R T A N T

If you do not see the camera capture icon, ensure your document camera’s USB-B mode is

set to Application. See Setting USB-B Application mode on page 39.

Transferring images from a memory card to your computer

You can transfer images from a memory card to your computer.

g To transfer images to your computer

1. Set your document camera to SD Storage mode. See Setting USB-B SD Storage mode on the

previous page.

2. Connect your document camera to your computer with the USB cable (see Basic connection

on page 9).

Your computer recognizes your document camera and memory card as a removable disk.

3. Browse to the removable disk on your computer, and then transfer the images to your

computer.

Chapter 6

SMARTDocumentCamera in SD Card view

Setting your document camera to SD Card view 43 Using the SD Card view display 44 Using the SD Card view on-screen display menu 44

SD Card view’s on-screen display menu options 44 SD Settings on-screen display menu 45

Deleting images from a memory card 46

Locking and unlocking images 46 Special Tools on-screen display menu 48 Slideshow Settings on-screen display menu 49

Showing slideshows 49

Displaying specific images in a slideshow 50

When you set your SMARTDocumentCamera to SD Card view, your document camera acts as an

SD or SDHC memory card reader, displaying previously captured images either individually or as a

slide show. Your computer isn’t used in an SD Card presentation.

Setting your document camera to SD Card view

g To set SD Card view

1. Ensure your document camera is connected directly to a projector or another display. For

connection information, see page 11.

2. Insert a memory card in your document camera.

Press the SD Card view button on the control panel.

C H A P T E R 6

Using your SMARTDocumentCamera in SD Card view

Using the SD Card view display

g To display images

Press the SD Card view button on the control panel.

2. Use the left and right arrow buttons on the control panel to scroll through images on the memory

card.

g To display and select thumbnail images

Press the SD Card view button on the control panel.

2. Press Enter to display up to 16 thumbnail-sized images.

g To return to displaying single images

Press Enter to display a single image.

Using the SD Card view on-screen display menu

The SD Card view’s on-screen display’s menu enables you to use the document camera as a

memory card reader.

SD Card view’s on-screen display menu options

The following on-screen display menu options are available when your document camera is in SD

Card view.

Menu Options

SD Settings Delete, Lock, Unlock and Format Media. See Setting USB-B

Application mode on page 39.

Your document camera’s USB-B mode must be set to Application to see this menu. See SD Settings on-screen display menu on the next page.

Special Tools Highlight, Mask and Scroll. See Special Tools on-screen display

menu on page 48.

Slide Show Start Slideshow, Interval, Select, Repeat and Order. See Slideshow

Settings on-screen display menu on page 49.

C H A P T E R 6

Using your SMARTDocumentCamera in SD Card view

SD Settings on-screen display menu

g To access the SD Settings menu

Select SD Card view > Menu > SD Settings .

I M P O R T A N T

The SD Settings are available only if you have your document camera set to Application mode in

the Camera view on-screen display menu. See Setting USB-B Application mode on page 39.

SD Settings menu options Description

Delete

Current Deletes current image

All Deletes all images in the current folder

Cancel Cancels image delete

Lock

Current Locks current image

All Locks all images

Cancel Cancels image lock

Unlock

Current Unlocks current image

All Unlocks all images

Cancel Exits Unlock settings

Format Media

No Cancels memory card formatting

Yes Formats memory card

C H A P T E R 6

Using your SMARTDocumentCamera in SD Card view

Deleting images from a memory card

You can delete images from a memory card in your document camera using the on-screen display

menu.

I M P O R T A N T

l Your document camera must be set to Application mode. See Setting USB-B Application

mode on page 39.

l You are unable to delete images from your computer, only from the document camera’s

memory card.

g To delete images

Press the SD Card view button on the control panel.

You see the current saved image from the memory card.

2. Use the left and right arrow buttons on the control panel to select the image you want to delete.

3. Press Menu on the control panel.

The on-screen display menu appears.

4. Select SD, and then press Enter .

5. Select Delete, and then press Enter .

6. Select Current, and then press Enter to delete the current image.

Select All, and then press Enter to delete all images in the viewed folder.

The deleting image icon displays briefly while your document camera deletes images.

Locking and unlocking images You can lock images to include them in slideshows set to Select > Lock in the Slideshow menu.

I M P O R T A N T

If you are unable to access the SD Menu, you must set your document camera’s USB-B mode to

Application. This is a Camera view menu setting. See Setting USB-B Application mode on page

39.

C H A P T E R 6

Using your SMARTDocumentCamera in SD Card view

g To lock images for a slideshow

Press the SD Card view button on the control panel.

2. Use the arrow buttons on the control panel to select the image you want to lock, and then press

the Menu button.

The on-screen display menu appears.

3. Select SD > Lock, and then press Enter .

4. Select Current, and then press Enter .

Select All to lock all images.

Repeat steps 1 to 3 to lock other images for your slideshow.

g To unlock images for a slideshow

1. In SD Card view, use the arrow buttons on the control panel to select the image you want to

unlock, and press the Menu button.

The on-screen display menu appears.

2. Select SD > Unlock, and then press Enter .

3. Select Current, and then press Enter .

Select All to unlock all images.

Repeat steps 1 to 3 to unlock other images for your slideshow.

C H A P T E R 6

Using your SMARTDocumentCamera in SD Card view

Special Tools on-screen display menu

g To access the Special Tools menu

Select SD Card view > Menu > Special Tools .

Special Tools menu options Description

Highlight

Highlight On

Adjust Transparency

Adjust Size

Mask

Mask On

Highlights a center square on the displayed image

Covers the displayed image with an adjustable screen mask

Adjust Transparency

Scroll

Scroll on

Zooms in on the displayed images and enables you to move the zoomed area with the up, down, left and right arrow buttons on

×2

×3

×4

the control panel

The SD Card view’s Special Tools menu includes the same tools as the Camera view’s Special

Tools menu, except that the SD Card view doesn’t have the Picture in Picture (PiP) feature.

l For information on how to use the Highlight feature, see Using the highlight feature on page 34.

l For information on how to use the Mask feature, see Using image masks on page 36.

l For information on how to use the Scroll feature, see Using the scroll feature on page 36.

C H A P T E R 6

Using your SMARTDocumentCamera in SD Card view

Slideshow Settings on-screen display menu

g To access the Slideshow Settings menu

Select SD Card view > Menu > Slideshow .

Slideshow menu options Description

Start Slideshow

Interval

5 sec Sets image interval to 5 seconds

10 sec Sets image interval to 10 seconds

15 sec Sets image interval to 15 seconds

30 sec Sets image interval to 30 seconds

Select

All Selects all images for slideshow

Starts a slideshow of images

Lock Sets so only locked images display in a slideshow

Repeat

Off Turns off slideshow repeat

On Turns on slideshow repeat

Order

Forward Sets slideshow order to forward

Backward Sets slideshow order to backward

Showing slideshows

g To start a slideshow

1. Access the Slideshow menu.

2. Select Slideshow, and then press Enter .

3. Select Start Slideshow, and press Enter .

Your document camera displays a slideshow of images on the memory card.

g To stop a slideshow

Press Enter or any of the arrow buttons on the control panel.

The image slideshow stops and the on-screen display menu appears.

C H A P T E R 6

Using your SMARTDocumentCamera in SD Card view

Displaying specific images in a slideshow

You can set your document camera to display only images that you select.

g To set SD settings to display selected images only

1. In SD Card view, press Menu on the control panel.

The on-screen display menu appears.

2. Select Slideshow > Select, and then press Enter .

3. Select Lock, and then press Enter so that only locked images display in a slideshow.

I M P O R T A N T

When you set the slideshow to Lock, it will include only images that are locked. You lock

images in the SD Card view’s SD menu, not the Slideshow menu.

g To lock images

See Locking and unlocking images on page 46.

g To unlock images

See Locking and unlocking images on page 46.

Chapter 7

3DTools and Mixed Reality Tools

Incorporating 3D content into your lessons 52 Getting started 52

Hardware and software requirements 52 Lighting requirements 53

Using the mixed reality mat 53 Inserting and manipulating 3Dmodels 56

Inserting 3D models 56 Manipulating 3D models 57

Rotating a 3Dmodel 57

Pausing, playing and restarting animation 58

Adding labels 59 Navigating 3D scenes 60

Using Mixed Reality Tools 62

Manipulating 3D models using Mixed Reality Tools 62 Disguising 3D models before presenting them 64

Using SketchUp sketching software and Google3DWarehouse 65

Using SketchUp sketching software 65 Using Google 3D Warehouse 66

Your SMARTDocumentCamera can transform any classroom or lecture hall into a spontaneous and

interactive learning environment. It uses a high-resolution video camera to display clear and detailed

images of written material or any physical object.

SMARTNotebook 3DTools and Mixed Reality Tools take this experience to a new level by providing

teachers and students with a new way to engage with digital 3D content.

This chapter provides the information you need to begin using SMARTNotebook 3DTools and Mixed

Reality Tools with your SMARTDocumentCamera as well as SketchUp™ sketching software and

Google™ 3DWarehouse.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

SMARTNotebook 3DTools and Mixed Reality Tools provide an intuitive way for students and

teachers to explore digital content with the document camera. This technology is integrated with

SMARTNotebook software.

Incorporating 3D content into your lessons

You can incorporate 3D content into your SMARTNotebook software lessons. The following are

examples of how to do this:

l If you’re teaching a biology lesson, insert a 3D model of a heart into your .notebook file. Rotate

and change the size of the 3D model to present the different parts of the heart.

l If you’re teaching an English lesson, insert a 3D model of a city that is referenced in a novel the

class is reading. Enter the 3Dscene to navigate streets and interiors of buildings.

l If you’re teaching a primary lesson, insert multiple 3D models and use the Disguise feature to

reveal answers as a memory exercise.

Getting started

Hardware and software requirements

To get started with Mixed Reality Tools, you need the following:

l SMARTNotebook software 11

l SMARTDocumentCamera 330

l A mixed reality cube

l A Windows computer meeting the following requirements:

Pentium® 4 processor or better

512 MB of RAM (1GBrecommended)

2 GB of free hard disk space

Windows XP SP3, WindowsVista® SP2 or Windows 7 operatingsystem

DirectX® 9 compatible graphics hardware

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

l A Mac computer meeting the following requirements:

1.5 GHz Intel® processor or better

1 GB of RAM

1 GB of free hard disk space for minimum installation (2 GB for full installation with

Gallery collections)

MacOSX 10.6 operating system software or later

Lighting requirements

Mixed Reality Tools works best in a bright room where the work surface doesn’t have any noticeable

shadows or glare.

The light must be as uniform as possible, shining on the cube and background. You can achieve this

by setting up the document camera so that the camera is facing directly down, perpendicular to a

uniform, neutral work surface. The work surface should not be darker than the black elements on the

mixed reality cube or lighter than the white elements on the cube.

N O T E S

l In very bright rooms, the work surface can appear whiter than the white elements on the

cube.

l You can print a mixed reality mat and place it under the document camera to increase

contrast between the cube and the background (see Using the mixed reality mat below).

A typical projector room is usually quite dark. For Mixed Reality Tools to work properly, the document

camera’s light should be turned on. Don’t manipulate the cube more than 14" (35 cm) from the

document camera.

N O T E

If SMARTNotebook software doesn’t enter MixedReality mode when you hold the cube under the

camera, shake the cube under the camera. If the issue persists, press and hold the brighten button

on the document camera to maximize the brightness.

Using the mixed reality mat

To increase the contrast between the mixed reality cube and background, you can use the mixed

reality mat available from the SMARTSupport website. The mat includes marks that indicate the area

in which you can move the cube while in MixedReality mode.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

To print the mixed reality mat, you need the following items:

l A computer with Internet access and Adobe®Reader® or Acrobat® software.

l A printer

l Tape

g To print the mixed reality mat

1. Open the appropriate mixed reality mat file in AdobeReader or Acrobat.

Region Page size Link

U.S. and Canada Letter (8 1/2" × 11") smarttech.com/kb/160487

Elsewhere A4 smarttech.com/kb/160488

2. Select File > Print.

The Print dialog box appears.

3. Select None in the Page Scaling drop-down list, clear the Auto-Rotate and Center check

box, and then press OK.

4. Arrange the pages:

Page 1 is top left.

Page 2 is top right.

Page 3 is bottom left.

Page 4 is bottom right.

Set page 1 as the bottom page in your stack.

5. Overlap, orient and align the pages according to the guidelines, and then tape the pages

together.

N O T E

Due to different page sizes and printing options, your pages may not align perfectly onto the

guidelines. If that is the case, align the pages to the central crosshairs.

T I P S

Use a light table or a tablet device set to a white background as an aid when aligning

the pages.

To make the mat last longer, consider printing it on heavy cardstock.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

g To use the mixed reality mat

1. Place the mixed reality mat on your work surface.

2. Place the document camera over the darkened area on the mat.

3. Rotate the bottom arm of the document camera so that it’s 90° from your work surface.

4. Rotate the upper arm of the document camera upward until it’s at its highest spot, ensuring the

bottom arm is still set to 90°.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

5. Turn on the document camera.

N O T E S

The document camera image should show the target area in the center. You can adjust

the mat slightly if necessary.

The lines on the mat indicate where you can position the mixed reality cube while in

Mixed Reality mode (see Manipulating 3D models using Mixed Reality Tools on page

62).

Inserting and manipulating 3Dmodels

To use SMARTNotebook 3DTools software, you need to insert a 3D model in your .notebook file.

After you insert a 3D model, you can manipulate it in the same way you manipulate other objects in

SMARTNotebook software.

N O T E

You can insert 2D images and 3D models on the same page and manipulate them the same way

you manipulate other objects in SMARTNotebook software.

Inserting 3D models

3D models are available from the 3D Objects folder in Lesson Activity Examples and the

SMARTExchange™ website (exchange.smarttech.com) as well as the Google 3D Warehouse (see

Using Google 3D Warehouse on page 66). You can also insert your own 3D models if they are in one

of the following formats:

l COLLADA (.dae)

l 3D Object (.obj)

l FBX (.fbx)

N O T E

Textures and other information for some 3D models are stored in separate files and folders. When

you insert these 3D models, ensure the 3D model file is located in the correct folder structure with

the supporting files and folders.

g To insert a 3D model

1. Select Insert > 3D File.

The Insert 3D File dialog box appears.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

2. Browse to and select the 3D model you want to insert.

3. Press Open.

The 3D model appears on the page.

Manipulating 3D models

After inserting a 3D model, you can manipulate it in the same way you manipulate other objects in

SMARTNotebook software. In particular, you can do the following:

l Cut, copy and paste

l Clone

l Move

l Scale

l Lock

l Attach links and sounds

l Add to the Gallery tab

N O T E S

l For information on these basic options, see the Help for SMARTNotebook software.

l When you add a 3D model to the Gallery tab, it appears in the 3D Objects category.

In addition to these basic options, you can do the following:

l Rotate the 3D model

l Pause, resume, play and restart animation

l Add labels

Rotating a 3Dmodel

You can rotate a 3D model along multiple axes. After rotating a 3D model, you can reset it to its

original orientation.

g To rotate a 3D model along a single axis

1. Select the 3D model.

2. Press and hold one of the side rotation handles.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

3. Drag your finger around the center of the 3Dmodel, and then release your finger when done.

g To rotate a 3D model along multiple axes

1. Select the 3D model.

2. Press and hold the center rotation handle.

3. Drag your finger in the direction you want to rotate the 3D model, and then release your finger

when done.

g To reset a 3D model to its original orientation

1. Select the 3D model.

2. Press the 3D model’s menu arrow, and then select Reset Rotation.

Pausing, playing and restarting animation

If a 3D model contains animation, you can pause, resume and restart the animation.

N O T E

If a 3D model doesn’t contain animation, the Animation menu documented in the following

procedures is disabled.

g To pause animation

1. Select the 3D model.

2. Press the 3D model’s menu arrow, and then select Animation > Play/Pause Animation.

g To resume playing animation

1. Select the 3D model.

2. Press the 3D model’s menu arrow, and then select Animation > Play/Pause Animation.

g To restart animation

1. Select the 3D model.

2. Press the 3D model’s menu arrow, and then select Animation > Restart Animation.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

Adding labels

You can use labels to highlight different components of a 3D model. Labels can be text, shapes or

other 2D objects.

g To add a label

1. Select the 3D model.

2. Right-click the 3D model where you want to connect the label, and then select Add Label.

A label appears.

3. To use text in the label, double-click the label’s default text and then type your own text.

To use a shape or other 2D object in the label, create the object and then drag it into the label.

4. Optionally, drag the label’s connection point to a different location on the 3D model.

g To hide and display a label

1. Press the label’s connection point on the 3D model.

The label is hidden.

2. Press the label’s connection point to display the label.

g To remove a label

1. Select the label.

Press Close .

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

Navigating 3D scenes

Large 3D models that contain internal details are called 3D scenes. You can navigate 3D scenes

using controls in SMARTNotebook software.

N O T E S

l You can use the navigation controls to navigate any 3D model. However, not all 3D models

contain internal details. If you enter a 3D model that doesn’t contain internal details, the

interior appears empty or dark.

l If you’re using MacOSX operating system software, you’re unable to enter a 3D scene while

in Full Screen mode. To enter a 3D scene, first exit Full Screen mode and then complete the

following procedure.

g To navigate a 3D scene

1. Select a 3D model.

2. Press the 3D model’s menu arrow, and then select Enter 3D Scene.

SMARTNotebook software displays the 3D scene in Full Screen mode. A map of the 3D

scene, navigation controls and the Close button appear.

T I P S

You can press the gray border of the map to drag it to another area of the page if it’s

covering materials you want to present. You can also resize the map by pressing and

dragging the gray border in the lower-right corner.

You can press the gray background or center icon of a navigation control to drag it to

another area of the page if it’s covering materials you want to present.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

3. Navigate the 3D scene using the navigation controls.

Button Use to:

A Change your orientation upward.

B Change your orientation to the left.

C Change your orientation to the right.

D Change your orientation downward.

E Raise elevation.

F Move forward in the scene.

G Move to the left in the scene.

H Move to the right in the scene.

I Move backward in the scene.

J Lower elevation.

Alternatively, you can use keyboard buttons to navigate the 3D scene.

Keyboard button Use to:

W Change your orientation upward.

A Change your orientation to the left.

D Change your orientation to the right.

S Change your orientation downward.

PAGEUP Raise elevation.

UPARROW Move forward in the scene.

LEFTARROW Move to the left in the scene.

RIGHTARROW Move to the right in the scene.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

Keyboard button Use to:

DOWNARROW Move backward in the scene.

PAGEDOWN Lower elevation.

ESC Close

N O T E

As you navigate the 3D scene, a red indicator in the map displays where you are in the scene

and the direction you are viewing. The arrow in the center indicates orientation. The arrow

becomes a circle when you’re facing directly up or down.

Level Incline Decline

Off-screen (level) Upward Downward

4. Press Close when you’re done.

Using Mixed Reality Tools

After inserting 3D models in your .notebook files using SMARTNotebook 3DTools, you can

manipulate those models using MixedReality Tools.

Manipulating 3D models using Mixed Reality Tools

You manipulate 3D models using your SMARTDocumentCamera and the mixed reality cube.

g To manipulate a 3D model using the mixed reality cube

1. Connect your SMARTDocumentCamera to your computer and turn on the document camera.

2. Open the .notebook file, and then display the page containing the 3D model.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

3. Place the mixed reality cube under the SMARTDocumentCamera, showing one side of the

cube to the camera.

SMARTNotebook software enters Mixed Reality mode and assigns the 3D model to the cube.

If there is more than one 3D model on the page, move the cube until the animation on the page

indicates that the cube is connected to the 3Dmodel you want to manipulate.

N O T E

SMARTNotebook software enters Mixed Reality mode in this situation only if a 3D model is

on the page. Alternatively, you can enter Mixed Reality mode by pressing SMART

Document Camera in the toolbar, and then pressing Start Mixed Reality in the SMARTDocumentCamera window.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

4. Do any of the following:

To move the 3D model on the screen, move the cube.

To rotate the 3D model on the screen, rotate the cube in your hand.

To unassign the 3D model from the cube, cover the cube’s markings with your hand.

N O T E

If you experience any of the following symptoms, the cause may be issues with tracking:

The 3D model doesn’t connect to the cube.

The 3D model shakes when it’s connected to the cube.

The 3D model sporadically disconnects from the cube.

SMARTNotebook software enters Mixed Reality mode when the cube is under the

camera even if you aren’t moving the cube.

To address tracking issues, see Lighting requirements on page 53.

T I P S

As you move and rotate the cube in your hand, ensure you don’t cover the symbols on

the cube’s surface.

To hide the image from the SMARTDocumentCamera and show only the 3D model,

move the transparency slider to the left.

5. If you’ve purchased a second cube from SMART and there is more than one 3D model on the

page, manipulate another 3D model by completing steps 3 and 4 with the other cube.

N O T E

The two cubes must have different patterns if you want to use them both at the same time.

6. When you’re done, move the cube (or cubes) away from the camera.

SMARTNotebook software exits Mixed Reality mode after a few seconds.

Disguising 3D models before presenting them

If you want to hide 3D models in your .notebook file before presenting them, you can use the Disguise

feature to hide the 3D models with a magic hat.

When you use Mixed Reality Tools, the magic hat disappears after Mixed Reality Tools assigns the

3D model to the cube, revealing the 3D model.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

N O T E

If you hide multiple 3D models on the same page with magic hats, each magic hat has a different

colored ribbon.

g To hide a 3D model with a magic hat

1. Select the 3D model.

2. Press the 3D model’s menu arrow, and then select Disguise > Disguised.

g To change the magic hat’s color

1. Select the magic hat.

2. Press the magic hat’s menu arrow, and then select Disguise > Change Color.

g To reveal a 3D model under a magic hat

Use Mixed Reality Tools as described in Manipulating 3D models using Mixed Reality Tools on page

62.

After Mixed Reality Tools assigns the 3D model to the cube, stars swirl around the magic hat, and

then the magic hat disappears, revealing the 3D model behind it.

T I P

You can also reveal the 3D model by pressing the hat icon in the lower-left corner.

Using SketchUp sketching software and Google3DWarehouse

Google offers two 3D tools that you can use with SMARTNotebook 3DTools and Mixed Reality

Tools:

l SketchUp sketching software

l Google 3D Warehouse

Using SketchUp sketching software

You can use SketchUp sketching software to create 3D models. You can save these 3D models in

COLLADA (.dae) format and then insert them in SMARTNotebook software.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

g To save a 3D model in .dae format

1. Open the 3D model in SketchUp sketching software.

2. Select File > Export > 3D Model.

The Export Model dialog box appears.

3. Browse to where you want to save the file.

4. Type a name for the file in the File name box.

5. Select COLLADA File (*.dae) in the Export type drop-down list.

6. Press Export.

g To insert the 3D model in SMARTNotebook software

See Inserting 3D models on page 56.

Using Google 3D Warehouse

Google 3D Warehouse is an online repository of 3D models. The Gallery tab in SMARTNotebook

software includes a link to Google 3D Warehouse. Using this link, you can search for 3D models and

download them to your computer. You can then insert the 3D models into your .notebook files.

g To download 3D models from Google 3D Warehouse

Press the Gallery tab.

2. Press Google 3D Warehouse.

Google 3D Warehouse appears in the bottom section of the Gallery tab.

3. Search or browse for a 3D model that you want to download.

Select the model.

4. Press Download Model, and then press the Download link beside Collada (.zip).

N O T E S

When you first download a 3D model, Google 3D Warehouse could prompt you for a

nickname.

If you’re using MacOSX operating system software and you cancel the download, the

3D model still saves to the Downloads folder.

5. Save the .zip file to your computer.

6. Extract the contents of the .zip file to a folder on your computer.

C H A P T E R 7

Using SMARTNotebook 3DToolsand Mixed RealityTools

g To insert a 3D model downloaded from Google 3D Warehouse

See Inserting 3D models on page 56.

Chapter 8

Document camera issues 69 SD Card view issues 70

This chapter includes troubleshooting information for your SMARTDocumentCamera.

Document camera issues

Use the following table to troubleshoot issues with your document camera.

Issue Solution

No image displays.

Turn off your document camera (see page 22). Securely

connect all cables and connect the camera’s AC adapter to a power outlet. Turn on your document camera.

Adjust the zoom dial. The camera may be on a blank section of

your document.

Ensure the output switches on the side panel are set to the

proper image output:

VGA DVI-D or Composite on the side panel

NTSC or PAL on the bottom of your document camera

No image displays after you restart your computer when your document camera is connected through a USB hub.

The image is out of focus.

The image is scrambled or black and white when a television is the display device.

Turn off your document camera, and then wait several

1. seconds.

Turn on your document camera again.

Press the Auto Focus button.

Use the manual focus.

Move the camera further away from the object.

Ensure the NTSC/PAL switch on the bottom of the document camera is set correctly. See Switching between NTSC and PAL on page 15.

C H A P T E R 8

Troubleshooting

Issue Solution

The image is too dark.

The image is broken apart by lines.

Press the brightness buttons on your document camera.

If the object isn’t well lit, turn on your document camera LED.

Adjust the shutter speed. See Camera view Image Settings on-screen display menu on page 32.

Adjust the distance between the object and the camera.

Adjust your projector settings.

SMARTNotebook software enters Mixed Reality mode accidentally.

Press SMART Document Camera in the toolbar.

Press Additional Settings , and then clear the selection of

Automatically Start Mixed Reality Tools.

N O T E

To enable the automatic detection of Mixed Reality again, press

Additional Settings , and then select Automatically Start Mixed Reality Tools.

SD Card view issues

Use the following table to troubleshoot issues with SD Card view.

Issue Solution

No image appears when you press the SD Card view button.

A crossed out, red SDCard icon appears when you press the SD Card view button.

The SD Card view menu does not include

SDSettings .

Slideshow doesn’t start, and there are images in the memory card.

Check the connection between your document camera and the

projector, television or display. See Setup configurations for Camera view and SDCard view on page 11.

Ensure your document camera, projector or television is turned

on.

Place a SD or SDHC memory card in your document camera SD card slot.

There are no images on the memory card.

In Camera view, set USB-B mode to Application. See Setting USB-B Application mode on page 39.

Your slideshow is set to Lock, and you don’t have any locked images.

Set the slideshow to All. See Slideshow Settings on-screen display menu on page 49.

Lock some or all of the images in the memory card. SeeLocking and unlocking images on page 46.

Appendix A

compliance

SMARTTechnologies supports global efforts to ensure that electronic equipment is manufactured,

sold and disposed of in a safe and environmentally friendly manner.

Waste Electrical and Electronic Equipment regulations (WEEE directive)

Waste Electrical and Electronic Equipment regulations apply to all electrical and electronic equipment

sold within the European Union.

When you dispose of any electrical or electronic equipment, including SMARTTechnologies

products, we strongly encourage you to properly recycle the electronic product when it has reached

the end of its life. If you require further information, please contact your reseller or

SMARTTechnologies for information on which recycling agency to contact.

Restriction of Certain Hazardous Substances (RoHS directive)

This product meets the requirements of the European Union’s Restriction of Certain Hazardous

Substances (RoHS) directive 2002/95/EC.

Consequently, this product also complies with other regulations that have arisen in various

geographical areas, and that reference the European Union’s RoHS directive.

Packaging

Many countries have regulations restricting the use of certain heavy metals in product packaging. The

packaging used by SMARTTechnologies to ship products complies with applicable packaging laws.

A P P E N D I X A

Hardware environmental compliance

China’s Electronic Information Products regulations

China regulates products that are classified as EIP (Electronic Information Products).

SMARTTechnologies products fall under this classification and meet the requirements for China’s

EIP regulations.

Index

3D models

disguising 64 inserting 56 manipulating 57 manipulating with Mixed Reality Tools 62 revealing 65 rotating 57

textures 56 3D Object files 56 3D scenes 60

map 62

Computer view 27 connections 4, 9 control panel 4

DAE files 56, 65-66 disguises 64 document camera

about 2 parts of 3 positioning 21 turning on and off 22

using with SMART Notebook software 24 downloads 15 DVI cables 14

activation 16 animation 58

pausing 58 playing 58

restarting 58 anti-glare sheet 6 arm 3

button

navigation control 61

Camera view 11, 29 cautions i Chinese regulations 72 COLLADA files 56, 65-66

EIP regulations 72 European Union regulations 71

FBX files 56 features 2 flat-panel displays 13

Gallery 57 Google 3D Warehouse 65-66

downloading 66

Google SketchUp 65

I N D E X

on-screen display menu 31 output resolutions 15

HD displays 14 head 3

Image Mate software 7, 15 important information i

keyboard controls 61

labels 59

adding 59

removing 59 LED light 22

magic hats 64

changing color 65 menu (Camera view on-screen display) 31 Microscope mode 31 mixed reality mat 53 Mixed Reality Tools 5, 16

packaging 71 PAL encoding system 5, 15 power 5, 22 printed documents, displaying 22 projectors 13-14

rear connection panel 4 resolutions 15 RoHS directive 71

scenes 60 SD and SDHC memory cards 23, 40 SD Card view 11, 43, 70 setup 11 side connection panel 5 SketchUp sketching software 65 SMART Notebook software 6, 15, 24

televisions 14 troubleshooting 69

navigation controls 61 Notebook

software

NTSC encoding system 5, 15

SeeSMART Notebook

software

OBJ files 56

USB cables 5

VGA cables 6, 13 views

about 3 Camera 11, 29

I N D E X

Computer 27

SD Card 11, 43, 70

Warehouse 66 warnings i WEEE directive 71

SMARTTechnologies

smarttech.com/support

smarttech.com/cont actsupport

SMART Camera 330 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Important information

Contents

Document camera features

Camera

Output

Physical construction

Software

Image storage

Document camera views

Parts of the document camera

Adjustable camera arm and camera head

Control panel

Rear connection panel

Side connection panel

NTSC/PAL switch

Mixed reality cube

Power supply

USB cable

VGA cable

Anti-glare sheet

Document camera software

Image Mate software (Windows only)

Basic connection

Connecting your document camera and computer to different displays

Connecting your document camera and computer to a shared display

Connecting to a projector or flat-panel display

Switching between VGA DVI-D and Composite output

Connecting to a digital projector or HD display with DVI-D

Connecting to a television

Switching between NTSC and PAL

Setting output resolution

Downloading software

Understanding Computer, Camera and SD Card views

Identifying view features

Setting document camera views

Performing basic operations

Positioning your document camera

Turning you document camera on and off

Using the LED light

Displaying printed documents

Inserting and removing a memory card

Setting Computer view

Using Computer view

Setting Camera view

Using Microscope mode

Using the Camera view’s on-screen display menu

Camera view Image Settings on-screen display menu

Camera view Special Tools on-screen display menu

Using the highlight feature

Using image masks

Using the scroll feature

Using the Picture in Picture (PiP) feature

Camera view Function Settings on-screen display menu

Setting USB-B mode

Setting USB-B Application mode

Setting USB-B SD Storage mode

Saving images to a memory card

Capturing images to a memory card

Transferring images from a memory card to your computer

Setting your document camera to SD Card view

Using the SD Card view display

Using the SD Card view on-screen display menu

SD Card view’s on-screen display menu options

SD Settings on-screen display menu

Deleting images from a memory card

Locking and unlocking images You can lock images to include them in slideshows set to Select > Lock in the Slideshow menu.

Special Tools on-screen display menu

Slideshow Settings on-screen display menu

Showing slideshows

Displaying specific images in a slideshow

Incorporating 3D content into your lessons

Getting started

Hardware and software requirements

Lighting requirements

Using the mixed reality mat

Inserting 3D models
