74" (188 cm)

35 3/4"

(90.7 cm)

82 1/2" (209.5 cm)

6 1/2"

(16.5 cm)

46 1/4" (117.5 cm)

77" (195.6 cm)

Versions 1 and 2: 51" (129.5 c m)

Version 3: 49 3/8" (125.3 cm )

> 5/8"

(1.6 cm)

> 6 1/8"

(15.6 cm)

smar ttech.com/docfeedback/170863

Specifications

SMARTBoard® interactive whiteboard

Dimensions and weights

Dimensions

2

1

Leave at least 5/8" (1.6 cm) headroom to wall mount the SB885. The distance from the

bottom of the wall mount bracket to the t op of an installed interactive whiteboard is 6

1/8" (15.6 cm)

SMART Board 885 interactive

whiteboard

Weight

55 lb. (25 kg)

Shipping dimensions

One unit

88 1/2" × 55 7/8" ×4 1/2"
(224.8 cm × 142 cm × 11.4 cm)

10 units on a pallet

45 1/2" × 93" ×56 3/4"
(115.6 cm × 236.2 cm × 144 cm)

Shipping weight

One unit on a pa llet

68.3 lb. (31 kg)

10 units on a pallet

683 lb. (310 kg)

Accessory Kit (includes pen tray)

Weight

12 lb. (5.5 kg)

Shipping dimensions

40 1/8" × 7" × 3 7/8"
(102 cm × 17.7 cm × 9.8 cm)

1

All dimensions ± 1/8" (0.3 cm). All weights ± 2 lb. (0.9 kg).

2

The height of SMART Board 800 series interact ive whiteboards m anufactured before June 2015 is 53 3/8" (135.6 cm ).

smarttech.com/kb/170863 1

Specifications

SMARTBoardinteractive whiteboard – Model X885

Standard features

Software SMART Product Drivers and SMART Ink®

SMART Notebook® basic version
Bonus one-year subscription to SMART Learning Suite (including SMART Notebook software)

Touch and gestures Perform mouse functions with your finger, and write and erase digital ink with a pen tray pen or

the eraser. The Object Awareness feature enables you to pick up a pen, and then write, select

or erase without replacing the pen. This interactive whiteboard also features gesture capability,

providing a natural and flexible way to interact with content.

Multitouch capabilities l Users can interact with the interactive whiteboard using the included pens or other

objects, or by using their fingers to write and perform gestures.

l Support for four simultaneous touches enables up to four users to interact with t he

interactive whiteboard.

SMARTInk™ Smoothes out the appearance of the digital ink, improving the legibility of your handwriting. The

ink becomes an object you can move and manipulate.

Lockable pen option Hold down a pen color button on the pen tray until its light flashes to lock the interactive

whit eboard in pen mode. In this mode you can use any device as a pen. Early education

students and students with special needs can use an object like a tennis ball to write more

easily on the surface.

Pen tray l Optical sensors in the pen tray detect when you lift a pen or eraser from the tray. Color

buttons on the pen tray enable you to select pen color.

l Removable end caps for optional accessories

Pen and eraser Two ergonomic pens with a comfort grip and a rectangular eraser

Touch resolution Approximately 4000 × 4000.

Screen surface The hard-coated steel surface is durable, optimized for projection, compatible with dry-erase

markers and easily cleaned.

Digitizing technology Four-camera DViT® (DigitalVisionTouch) technology

Aspect ratio 16:10

Frame finish Light gray (approximates PANTONE Cool Gray 6C)

Wall-mount bracket Two 32" (81.3 cm) wide brackets with 10 screws and toggle bolt anchors to support a

wall-mounted interactive whiteboard

Power connection 6' (1.8 m) power cable

Power requirements Power consumption is less than 7 W (100V to 240V AC, 50/60 Hz, 5V DC 2.0A)

Computer requirements

SBX885 A computer or laptop with either a Windows® operating system or Mac operating system

software and SMARTNotebook software installed. For a complete list of computer requirements,

go to smarttech.com/downloads and browse to the latest SMARTNotebook release not es

applicable to your operating system.

smarttech.com/kb/170863 2

Specifications

SMARTBoardinteractive whiteboard – Model X885

Storage and operating specifications

Storage temperature -40°F to 120°F (-40°C to 50°C)

Operating temperature 41°F to 95°F (5°C to 35°C) with up to 80% humidity, non-condensing

Certification and compliance

Regulatory certification CE, CSA (U.S./Canada) and FCC

Environmental compliance

China EIP

European Union REACH, RoHS, WEEE and Packaging

U.S. Packaging

Warranty

Interactive whiteboard Your interactive whiteboard has a two year limited equipment warranty. See

smarttech.com/ support/warranty-information for details.

Accessories The accessories have a one-year warranty.

Purchasing information

NOTE

A digital projector isn’t included with this model of SMARTBoard interactive whiteboard. To t ake advantage of all

interactive features, you must integrate a digital projector.

Order numbers

SBX885 87" (221 cm) diagonal SMARTBoard interactive whiteboard.

Optional accessories See smarttech.com/accessories

smar ttech.com/support
smar ttech.com/contactsupport

© 2 010– 2020S MARTTechnolo gie sULC. All r ights re ser ved . SMARTBo ard, s marttech, the SMART log o and all SMART tagli nes are trademarks o r re gi stere d trade marks of
SMARTTe chnologi esU LC in the U.S . and/or o ther countries. All third-party pro duct and co mpany names may be trad emarks of their r es pe ctive o wners. This p rod uct and/or use thereo f
cove re d by o ne or more of the follo wing U.S . patents. www. smarttech.com/patents. Contents are subje ct to change wi thout notice. N ove mber 2 0, 202 0.

smarttech.com/kb/170863 3
