Shanghai Smarfid Security Equipment Co., Ltd
Desktop Mini USB Reader
MW4621/ MW4631 (based on LEGIC Technology)
Logo lit up
New P/N MW4621/MW4631
Model MW4621/ MW4631 is a compact credit card size
USB smart card reader. MW4621 can read the UID
(Unique Identification Number) of Mifare card. MW4631
is designed to read the UID as well as the card sector
information from all different kinds of Mifare card. The
LED logo can be customized.
Flashing outlook and Customization
The mini USB reader can be configured to read and output different information from the card. The Logo area can
be customized with different Company logo. The back lit color of the logo will change from green to blue as standard
when the card read is success and can also be specified an d customiz ed. T he mini USB r ead er equi pped with built
in buzzer to notify the user when the card read is success.
Flexible Applications
With Enrollment Software, the Mini USB r eader is configured to read the card information and transmit the card
information to the Enrollment Software, which runs at the background. The software will simulate the key stroke, and
input the card number into the cursor position on the screen.
With Log-on Software*, the Mini USB reader act like a log-on reader, which allow the user to log on to the PC when
it first start up or reactivate after screen saver.
In addition, a set “Library Command” is also available for 3
supports card reading, LED status control, buzzer control and 3DES communication setup in bet ween the software
and reader. A test program is available for simple command and test.
Environmental protection
In order to support environment control, all the components being used inside the reader are “LEAD FREE” – RoHS
complied.
Note: “*” the software will available mid of 2010.
rd
party software to integrate with Mini USB reader. It
http://www.smarfid.com
Shanghai Smarfid Security Equipment Co., Ltd
Operating Specification:
Operating Voltage
Operating current
Frequency
Host Interface
Operating
Temperature
Operating
Humidity
USB Powered （5V）
150mA
13.56MHz
USB2.0
(also compliant with USB 1.1)
32°~131°F
(0°~55°C)
10% - 90%
Typical read range
Standard Color
RFID Technology
Transmission
speed
Exterior
dimension
Material
(USB 2.0 full speed)
4-6cm
Black
Mifare
12 Mbps
85.8*54*12mm
PC+ABS
Part Number:
Read Information;
2=CSN/UID/ID Reading
3=Sector Reading
MW46X1
Physical Dimension:
Add: Rm.206, 4th Bldg., No. 471 Guiping Road, Shanghai, Chin a 200233
Tel: (86-21) 54260103, 54260132
Fax: (86-21) 54260132 ext.222
Email：OS@Smarfid.com
http://www.smarfid.com
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interfe rence will no t occ ur in a particular installa t ion . If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
