SMAR PSI302P Installation Manual

INSTALLATION MANUAL
FIELDBUS POWER
SUPPLY IMPEDANCE
PSI302P
PSI302P
JUL / 02
PSI302P
VERSION 1
TM
FOUNDATION
web: www.smar.com
Specifications and information are subject to change without notice.
smar
BRAZIL Smar Equipamentos Ind. Ltda.
Rua Dr. Antonio Furlan Jr., 1028 Sertãozinho SP 14170-480 Tel.: +55 16 3946-3510 Fax: +55 16 3946-3554 e-mail: smarinfo@smar.com
GERMANY Smar GmbH
Rheingaustrasse 9 55545 Bad Kreuznach Germany Tel: + 49 671-794680 Fax: + 49 671-7946829 e-mail: infoservice@smar.de
USA Smar International Corporation
6001 Stonington Street, Suite 100 Houston, TX 77040 Tel.: +1 713 849-2021 Fax: +1 713 849-2022 e-mail: sales@smar.com
ARGENTINA Smar Argentina
Soldado de La Independencia, 1259 (1429) Capital Federal – Argentina Telefax: 00 (5411) 4776 -1300 / 3131 e-mail: smarinfo@smarperifericos.com
MEXICO Smar México
Cerro de las Campanas #3 desp 119 Col. San Andrés Atenco Tlalnepantla Edo. Del Méx - C.P. 54040 Tel.: +53 78 46 00 al 02 Fax: +53 78 46 03 e-mail: ventas@smar.com
Smar Laboratories Corporation
10960 Millridge North, Suite 107 Houston, TX 77070 Tel.: +1 281 807-1501 Fax: +1 281 807-1506 e-mail: smarlabs@swbell.net
For the latest updates, please visit the SMAR website above.
CHINA Smar China Corp.
3 Baishiqiao Road, Suite 30233 Beijing 100873, P.R.C. Tel.: +86 10 6849-8643 Fax: +86-10-6894-0898 e-mail: info@smar.com.cn
SINGAPORE Smar Singapore Pte. Ltd.
315 Outram Road #06-07, Tan Boon Liat Building Singapore 169074 Tel.: +65 6324-0182 Fax: +65 6324-0183 e-mail: info@smar.com.sg
Smar Research Corporation
4250 Veterans Memorial Hwy. Suite 156 Holbrook , NY 11741 Tel: +1-631-737-3111 Fax: +1-631-737-3892 e-mail: sales@smarresearch.com
FRANCE Smar France S. A. R. L.
42, rue du Pavé des Gardes F-92370 Chaville Tel.: +33 1 41 15-0220 Fax: +33 1 41 15-0219 e-mail: smar.am@wanadoo.fr
PSI302P – Instalation and Maintenance Manual
INTRODUCTION
The function of impedance in a power supply is to implement a circuit output impedance greater
than 3 K wich, in a parallel with the two terminators of 100 ± 2% each, results in a line impedance if
about 50. This impedance can be implement in a passive mode (50 resistance in series with a 100
mH inductance) or in an active mode, through a impedance control circuit.
DEFINITION
The fieldbus Power Supply Impedance is a non-isolated, active impedance control device, in
accordance with Standard IEC 1158-2. This device presents an output impedance wich, in parallel
3
with the two bus terminators (a 100W resistor in series with a 1 mF capacitor) required by the
standard, results in a purely resistive line impedance for a broad frequency range.
The PSI302P, (because of the power supplied, cannot be used directly in areas requiring intrinsic
safety specifications.
Figure 1 shows the Device Block Diagram. The PSI302P can be used in redundancy, connecting
their output (+ E -) in parallel. When this configuration is used, use external terminator (BT302) to
allow PSI302P change in case of failure, without Fieldbus interruption (See fig. 2).
As to its external physical characteristics, the PSI302P presents power supply and overcurrent
indication LEDs. The input terminal block has two terminals (1A e 2A), wich are connected to the
external 24 Vdc. The power supply indication LED is green and is must be energized while there is
external 24 Vdc power supply.
4
PSI302P – Manual de Instrução e Manutenção
The overcurrent indication LED is red and it must be energized only in case of overcurrent caused by a short circuit in
the plant or by an excessive number of connected deviced. Figure 3 and 4 shows a layout of device PSI302P.
Fig.1 - PSI302P Block Diagram
Fig. 2 – Redundancy of PSI302P
Fig 3 – Frontal View PSI302P-2 Fig 4 – Front View PSI302P-4
PSI302P-4: Eight terminals (3A to 10A) to implementation of 4 switches for interlinked of the internal terminador of the PSI302P-4. The Figure 4 shows a layout of device; to verify that 4 Leds of flaw exists, one for each PSI302P.
independent Fieldbus channels and a Dip Switch with 4
PSI302P – Instalation and Maintenance Manual
PSI302P-4: Eight terminals (3A to 10A) to implementation of 4 independent Fieldbus channels and a Dip Switch with 4
switches for interlinked of the internal terminador of the PSI302P-4. The Figure 4 shows a layout of device; to verify that 4 Leds of flaw exists, one for each PSI302P.
5
PSI302P-2: Four terminals (3A to 6A) to implementation of 2
independent Fieldbus channels and a Dip Switch with 2
switches for interlinked of the internal terminador of the PSI302P-2. The Figure 3 shows a layout of device; to verify that 2 Leds of flaw exists, one for each PSI302P. Obs: So much for the model PSI302P-2 as for the PSI302P-4, the terminals and Dip Switch they are the same, even
so for the model PSI302-2 only the connections are enabled for 2 channels. The key 1 in the position ON enables the internal terminator (BT302) for the channel 1.
The energization indication LED is of green color, should be energized while there is external 24 Vdc power supply and the overcurrent indication LED it is red color, being just activated when it happens current excess due to short circuit in the plant or excess of connected equipaments.
INSTALLATION
The PSI302P – Fieldbus Power Supply Impedance is a device specially designed for panel installation and it can not
be installed in unshetered locations, as it can not be exposed to the weather.
Due to its great thermal dissipation capacity, the device may be installed in environments where the maximum temperature reaches up to 50 °C, without requiring cooloing facilities. Connections to the panel may be done directly by means of screws and nuts, or by means of a DIN rail in supports supplied with the device.
It can be fixed, the PSI302P through the rack or for the auxiliary support (optional)(Fig. 5) with the device:
To fixing the PSI302P through the rack::
1- To fix the rack in DIN rail or directly by means of screws;
2- It fits for PSI302P in the rack. To fixing the PSI302P through the auxiliary support::
3- To fix the supplied suports directly by means of screws;
4- It fits for PSI302P in the auxiliary support.
MAINTENANCE
The PSI302P - Fieldbus Power Supply Impedance is a rugged device wich practcally requires no type of preventive
maintenace. It is simply recommended to protect it from excessive dust accumulation and from excessively humid environments wich might affects its output impedance.
Fig 5 – Dimensional Drawing
6
PSI302P – Manual de Instrução e Manutenção
As for troubleshooting, the PSI302P has five indication LEDs and PSI302P-2 has three indication LEDs wich inform its operation status. A green power supply LED informs that the PSI302P is appropriately powered. A red overcurrent LED
for each channel, will be lit should any abnormal condition occurs in the field wiring. These LEDs are able to detect most problems wich may occur in a Fieldbus installation. However, other problems which are not detectable by the LEDs may occur. Such problems should be: excessive noise introduced by the external power supply; impedance lower than 20 in the communication line (consider that such impedance may not be purely resistive and, therefore not detectable by the overcurrent circuit); and a DC voltage higher than 18 Vdc in the communication line. Such abnormal conditions may be easily detected by measurement instruments.
Because the PSI302P is a simply and compact device, it is recommended that repair services be done by replacing faulty modules instead of electronic components. Some eletronic components used in the PSI302P are highly accurate and in the state-of-art, being therefore not easily found in ordinary retail stores. This is the reason why the PSI302P –
Fieldbus Power Supply Impedance ha been designed in modules, in order to simplify repair services and the maintenance of spare parts.
TECHNICAL CHARACTERISTICS Electrical Characteristics:
Power Supply:
24 to 32 Vdc ±10%
Output Current:
340 mA (máx).
Mechanical Characteristics:
Dimensions (LxPxH): 40x142x126 mm Enclosure: Metallic box for panel mounting. Mounting: With screws or by means of DIN rail. DIN rail: TS35-DIN EN 50022 or TS32-DIN EN50035
or TS15-DIN EN50045.
Ambient Conditions:
Operation:
T
-20°C to 50°C @RH 10% a 95%, without
AMB
condensing.
Storage:
T
-50°C to 70°C @RH 5% a 95%, without
AMB
condensing.
Functional Characteristics:
Input Filter:
Attenuation of 10dB in the input power ripple @60 Hz.
Impedance Control:
Active impedance control.
Terminator:
Fieldbus terminator.
Safety Characteristics:
Output Overcurrente:
Limitated in 500 mA
Input Fuser:
2,5 A.
Atmospherics Discharges:
Inpout and output protected for surge suppressor.
Intrinsic Safety:
Cannot be used directly.
Aproximately Weight: 230g
