Introduction
IS400P – Power Distributor and Isolator
IS400P- POWER DISTRIBUTOR AND
ISOLATOR
The signal Isolator Distributor Module model IS400P is an auxiliary device projected to isolate
galvanically a transmitted signal (current or voltage) of a receiver device, typically a register or
controller. Besides, the power supply of the module is isolated from the input and output.
The signal Isolator Distributor Module - IS400P - solves the problem of the distortion in the signal
transfer due to potentials of different ground.
It can also be used in the power supply of two-wire transmitters.
The figure 1 shows the terminals of the IS400P.
ORDERING CODE
Fig 1 – Frontal View IS400P
IS400P POWER DISTRIBUTOR AND ISOLATOR
CODE INPUT
0 4-20 mA
1 1-5 Vdc
CODE OUTPUT
0 1
IS400P 1 2
2
4-20 mA (
integral power supply for two-wire transmitter)
4-20 mA/ 4-20 mA
1-5 Vdc/ 4-20 mA
1-5 Vdc/ 1-5 Vdc
2
3
IS400 – Installation Manual
General Characteristics
The Power Distributor and Isolator, model IS400P, can be used in two ways:
• Power supply for two-wire transmitters, providing isolation between input and outputs.
• Isolate a 4-20 mA or 1-5 Vdc signal between the input and outputs.
How to Configure the Inputs and Outputs of the Circuit Board
Inputs
For inputs of 4-20 mA
• Insert jumpers W2, W4 and W11.
For inputs of 1-5 Vdc
• Insert jumpers W2, W4 and W10.
For two-wire transmitters
• Insert jumpers W1, W3 and W11.
Fig 2 – Jumpers W1, W2, W3, W4, W10 and W11
Outputs
For output A 4-20 mA/output B 4-20mA
• Insert jumper W5, and put the jumpers W8 in ON and W9 in OFF.
For output A 1-5 Vdc /output B 4-20 mA
• Insert jumper W6, and put the jumpers W8 and W9 in ON.
For output A 1-5 Vdc/output B 1-5 Vdc
• Insert jumpers W6, W7, and put the jumpers W8 in OFF and W9 in ON.
Fig 3 – Jumpers W5, W6, W7, W8 and W9
4
Technical Specifications
General
• Power supply: 24 Vdc ±10%
• Accuracy: 0.15% of span
• Maximum current consumption: 120 mA
• Insulation resistance from power supply to input and outputs: 1000 MΩ (minimum) at 500 Vdc.
• Dielectric strength: Between every terminal: 500 Vac for 1 minute (among all points).
• Operation temperature range: 0 a 60 ºC.
Input
• 4-20 mA using the integral power supply for two-wire transmitters.
• 4-20 mA
• 1-5 Vdc
Inputs for 0 to 20 mA and 0 to 5 Vdc can also be used, with the outputs being respectively 0 to 20
mA and/or 0 to 5 Vdc.
• Integral Power Supply (when used).
• Maximum External Load: 300 Ω (when used with LD290, LD300, LD301, TT300 and TT301
Transmitters Series).
• Short-Circuit Current: approximately 40 mA.
Outputs A/B
• 4-20 mA/4-20 mA
• 1-5 Vdc/4-20 mA
• 1-5 Vdc/1-5 Vdc
• The output negative terminals are interconnected.
• Maximum load (current output): 750 Ω with power supply of 24 Vdc.
• Minimum load (voltage output): 5 kΩ.
In case of the outputs A or B is not used, it should be jumped, or the other, the positive is to be
connected to the negative.
IS400P – Power Distributor and Isolator
NOTE
NOTE
5
IS400 – Installation Manual
Dimensions
Fig 4 – Dimensions
6
