SUNNY BOY

User Manual

SUNNY BOY 3.0-US / 3.8-US / 5.0-US /

6.0-US / 7.0-US / 7.7-US

SBxx-US-1XP-41-BA-en-11 | Version 1.1ENGLISH

Page 2

Legal Provisions

SMA Solar Technology AG

Legal Provisions

The information contained in these documents is the property of SMA Solar Technology AG. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, be it electronic, mechanical, photographic, magnetic or otherwise, without the prior written permission of SMA Solar Technology AG. Internal reproduction used solely for the purpose of product evaluation or other proper use is allowed and does not require prior approval.

SMA Solar Technology AG makes no representations or warranties, express or implied, with respect to this documentation or any of the equipment and/or software it may describe, including (with no limitation) any implied warranties of utility, merchantability, or fitness for any particular purpose. All such representations or warranties are expressly disclaimed. Neither SMA Solar Technology AG nor its distributors or dealers shall be liable for any indirect, incidental, or consequential damages under any circumstances.

The exclusion of implied warranties may not apply in all cases under some statutes, and thus the above exclusion may not apply.

Specifications are subject to change without notice. Every attempt has been made to make this document complete, accurate and up-to-date. Readers are cautioned, however, that product improvements and field usage experience may cause SMA Solar Technology AG to make changes to these specifications without advance notice, or per contract provisions in those cases where a supply agreement requires advance notice. SMA Solar Technology AG shall not be responsible for any damages, including indirect, incidental or consequential damages, caused by reliance on the material presented, including, but not limited to, omissions, typographical errors, arithmetical errors or listing errors in the content material.

SMA Warranty

You can download the current warranty conditions from the Internet at www.SMA-Solar.com.

Software Licenses

The licenses for the installed software modules (open source) can be found in the user interface of the product.

Trademarks

All trademarks are recognized, even if not explicitly identified as such. Missing designations do not mean that a product or brand is not a registered trademark.

SMA Solar Technology AG

User ManualSBxx-US-1XP-41-BA-en-112

Page 3

SMA Solar Technology AG

Table of Contents

1 Information on this Document................................................. 5

1.1 Validity........................................................................................................................ 5

1.2 Target Group.............................................................................................................. 5

1.3 Content and Structure of this Document ................................................................... 5

1.4 Levels of Warning Messages .................................................................................... 5

1.5 Symbols in the Document .......................................................................................... 6

1.6 Typographies in the Document.................................................................................. 6

1.7 Designation in the document..................................................................................... 6

1.8 Additional Information ............................................................................................... 7

2 Safety ........................................................................................ 8

2.1 Intended Use .............................................................................................................. 8

2.2 IMPORTANT SAFETY INSTRUCTIONS.................................................................... 9

3 Product Overview .................................................................... 13

3.1 Product Description .................................................................................................... 13

3.2 Symbols on the Product ............................................................................................. 14

3.3 Interfaces and Functions ............................................................................................ 15

3.4 LED Signals................................................................................................................. 21

3.5 Display messages....................................................................................................... 22

4 Operation ................................................................................. 24

4.1 Activating and Operating the Display...................................................................... 24

4.2 Establishing a connection to the user interface ........................................................ 24

4.2.1 Establishing a Direct Connection via Ethernet ...................................... 24

4.2.2 Establishing a direct connection via WLAN ......................................... 25

4.2.3 Establishing a Connection via Ethernet in the local network ............... 26

4.2.4 Establishing a Connection via WLAN in the Local Network ............... 27

4.3 Logging In and Out of the User Interface................................................................. 28

4.4 Start Page Design of the User Interface.................................................................... 30

4.5 Displaying and Downloading the Stored Data........................................................ 33

4.6 Activating the Smart Inverter Screen......................................................................... 33

4.7 Starting the Installation Assistant............................................................................... 34

4.8 Secure power supply operation................................................................................ 35

4.8.1 Enable secure power supply operation ................................................ 35

4.8.2 Disable secure power supply operation ............................................... 36

4.9 Activate WPS Function............................................................................................... 36

4.10 Switching WLAN On and Off................................................................................... 37

4.11 Switching the Dynamic Power Display Off............................................................... 38

User Manual SBxx-US-1XP-41-BA-en-11 3

Page 4

Table of Contents

4.12 Changing the Password............................................................................................. 38

4.13 Changing Operating Parameters.............................................................................. 38

4.14 Configuring the Country Data Set............................................................................. 39

4.15 Configuring the Rapid Shutdown Function............................................................... 40

4.16 Changing the Operating Mode of the Multifunction Relay.................................... 41

4.17 Configuring the Modbus Function............................................................................. 42

4.18 Setting SMA ShadeFix............................................................................................... 43

4.19 Deactivating the Arc-Fault Circuit Interrupter (AFCI)................................................ 43

4.20 Saving the Configuration in a File............................................................................. 44

4.21 Adopting a Configuration from a File....................................................................... 44

4.22 Updating the Firmware.............................................................................................. 44

SMA Solar Technology AG

5 Cleaning the Inverter ............................................................... 47

6 Troubleshooting........................................................................ 48

6.1 Forgotten Password.................................................................................................... 48

6.2 Event Messages ......................................................................................................... 49

6.3 Checking the PV System for Ground Faults.............................................................. 67

7 Accessories ............................................................................... 72

8 Compliance Information .......................................................... 73

9 Contact ...................................................................................... 74

User ManualSBxx-US-1XP-41-BA-en-114

Page 5

SMA Solar Technology AG

1 Information on this Document

1.1 Validity

This document is valid for:

• SB3.0-1SP-US-41 (SunnyBoy 3.0-US) from firmware version 03.01.00.R

• SB3.8-1SP-US-41 (SunnyBoy 3.8-US) from firmware version 03.01.00.R

• SB5.0-1SP-US-41 (SunnyBoy 5.0-US) from firmware version 03.01.00.R

• SB6.0-1SP-US-41 (SunnyBoy 6.0-US) from firmware version 03.01.00.R

• SB7.0-1SP-US-41 (SunnyBoy 7.0-US) from firmware version 03.01.00.R

• SB7.7-1SP-US-41 (SunnyBoy 7.7-US) from firmware version 03.01.00.R

1.2 Target Group

This document is intended for qualified persons and end users. Only qualified persons are allowed to perform the activities marked in this document with a warning symbol and the caption "Qualifiedperson". Tasks that do not require any particular qualification are not marked and can also be performed by end users. Qualified persons must have the following skills:

• Knowledge of how an inverter works and is operated

• Training in how to deal with the dangers and risks associated with installing, repairing and using electrical devices and installations

• Training in the installation and commissioning of electrical devices and installations

• Knowledge of all applicable laws, standards and directives

• Knowledge of and compliance with this document and all safety information

1.3 Content and Structure of this Document

This document describes the configuration, operation and troubleshooting of the product as well as the operation of the product user interface.

You will find the latest version of this document and further information on the product in PDF format and as eManual at www.SMA-Solar.com. You can also call up the eManual via the user interface of the product.

Illustrations in this document are reduced to the essential information and may deviate from the real product.

1.4 Levels of Warning Messages

The following levels of warning messages may occur when handling the product.

DANGER

Indicates a hazardous situation which, if not avoided, will result in death or serious injury.

WARNING

Indicates a hazardous situation which, if not avoided, could result in death or serious injury.

User Manual SBxx-US-1XP-41-BA-en-11 5

Page 6

1 Information on this Document

☐

☑

✖

SMA Solar Technology AG

CAUTION

Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

NOTICE

Indicates a situation which, if not avoided, can result in property damage.

1.5 Symbols in the Document

Symbol Explanation

Information that is important for a specific topic or goal, but is not safety-relevant

Indicates a requirement for meeting a specific goal

Desired result

A problem that might occur

Example

1.6 Typographies in the Document

Typography Use Example

bold

[Button] [Key]

# • Placeholder for variable

• Messages

• Terminals

• Elements on a user interface

• Elements to be selected

• Elements to be entered

• Connects several elements to be selected

• Button or key to be selected or pressed

components (e.g., parameter names)

• Connect the insulated conductors to the terminals X703:1 to X703:6.

• Enter 10 in the field Minutes.

• Select Settings > Date.

• Select [Enter].

• Parameter WCtlHz.Hz#

1.7 Designation in the document

Complete designation Designation in this document

SunnyBoy Inverter, product

User ManualSBxx-US-1XP-41-BA-en-116

Page 7

SMA Solar Technology AG

1 Information on this Document

1.8 Additional Information

For more information, please go to www.SMA-Solar.com.

Title and information content Type of information

Mounting, installation, commissioning and decommissioning Installation manual

"Application for SMAGridGuard Code" Form

"PUBLIC CYBER SECURITY - Guidelines for a Secure PV System Communication"

"Grid Support Utility Interactive Inverters" Information about how to activate and to set the grid supporting fea-

tures according to UL1741SA

"Efficiency and Derating" Efficiency and derating behavior of the SMA inverters

"Parameters and Measured Values" Overview of all inverter operating parameters and their configura-

tion options

"SMA and SunSpec Modbus® Interface" Information on the Modbus interface

"Modbus® parameters and measured values" Device-specific register HTML file

"SMASPEEDWIRE FIELDBUS" Technical information

Technical information

Technical Information

User Manual SBxx-US-1XP-41-BA-en-11 7

Page 8

2 Safety

SMA Solar Technology AG

2 Safety

2.1 Intended Use

The Sunny Boy is a transformerless PV inverter which converts the direct current of the PV array to grid-compliant alternating current and feeds it into the utility grid.

The product is suitable for indoor and outdoor use. The product must only be operated with PV arrays (PV modules and cabling) that are approved by

the electrical standards applicable on-site and the NationalElectricalCode® ANSI/NFPA 70 or the CanadianElectricalCode® CSA C22.1.

No galvanic isolation

The product is not equipped with a transformer and therefore has no galvanic isolation.

• Do not operate grounded PV modules together with the product. If grounded PV modules are connected to the product, an event will occur which will appear on the product display. The event will also be displayed, along with the associated message, in the event list on the user interface of the product.

• Only ground the mounting frames of the PV modules.

• The neutral conductor of the AC output is not bonded to ground within the product.

• The neutral conductor of the AC output for secure power supply operation is bonded to ground within the product.

PV modules with a high capacity to ground may only be used if their coupling capacity does not exceed 2.5μF.

To protect the PV system against excessive reverse currents under fault conditions, a DC-side overcurrent protective device must be connected in accordance with the National Electrical Code to prevent any short-circuit currents that exceed the ampacity of the DC electric circuit or the maximum series fuse rating of the PV modules. Typically, string fuses are used if more than two strings are connected in parallel.

All components must remain within their permitted operating ranges and their installation requirements at all times.

The product is approved for the US and Canadian market. Use SMA products only in accordance with the information provided in the enclosed

documentation and with the locally applicable laws, regulations, standards and directives. Any other application may cause personal injury or property damage.

Alterations to the SMA products, e.g., changes or modifications, are only permitted with the express written permission of SMA Solar Technology AG. Unauthorized alterations will void guarantee and warranty claims and in most cases terminate the operating license. SMA Solar Technology AG shall not be held liable for any damage caused by such changes.

Any use of the product other than that described in the Intended Use section does not qualify as the intended use.

The enclosed documentation is an integral part of this product. Keep the documentation in a convenient, dry place for future reference and observe all instructions contained therein.

User ManualSBxx-US-1XP-41-BA-en-118

Page 9

SMA Solar Technology AG

This document does not replace and is not intended to replace any local, state, provincial, federal or national laws, regulations or codes applicable to the installation, electrical safety and use of the product. SMA Solar Technology AG assumes no responsibility for the compliance or noncompliance with such laws or codes in connection with the installation of the product.

The type label must remain permanently attached to the product.

2 Safety

2.2 IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS This section contains safety information that must be observed at all times when working. The product has been designed and tested in accordance with international safety requirements. As

with all electrical or electronical devices, there are residual risks despite careful construction. To prevent personal injury and property damage and to ensure long-term operation of the product, read this section carefully and observe all safety information at all times.

DANGER

Danger to life due to electric shock when live components or DC conductors are touched

When exposed to light, the PV modules generate high DC voltage which is present in the DC conductors. Touching live DC conductors results in death or lethal injuries due to electric shock.

• Disconnect the product from voltage sources and make sure it cannot be reconnected before working on the device.

• Do not touch non-insulated parts or cables.

• Do not remove the terminal block with the connected DC conductors from the slot under load.

• Wear suitable personal protective equipment for all work on the product.

DANGER

Danger to life due to electric shock when touching live system components in case of a ground fault

If a ground fault occurs, parts of the system may still be live. Touching live parts and cables results in death or lethal injuries due to electric shock.

• Disconnect the product from voltage sources and make sure it cannot be reconnected before working on the device.

• Touch the cables of the PV array on the insulation only.

• Do not touch any parts of the substructure or frame of the PV array.

• Do not connect PV strings with ground faults to the inverter.

• Ensure that no voltage is present and wait five minutes before touching any parts of the PV system or the product.

User Manual SBxx-US-1XP-41-BA-en-11 9

Page 10

2 Safety

SMA Solar Technology AG

DANGER

Danger to life due to electric shock in case of overvoltages and if surge protection is missing

Overvoltages (e.g. in the event of a flash of lightning) can be further conducted into the building and to other connected devices in the same network via the network cables or other data cables if there is no surge protection. Touching live parts and cables results in death or lethal injuries due to electric shock.

• Ensure that all devices in the same network are integrated in the existing overvoltage protection.

• When laying the network cable outdoors, ensure that there is suitable surge protection at the network cable transition from the product outdoors to the network inside the building.

• The Ethernet interface of the inverter is classified as "TNV-1" and offers protection against overvoltages of up to 1.5kV.

WARNING

Danger to life due to fire or explosion

In rare cases, an explosive gas mixture can be generated inside the inverter under fault conditions. In this state, switching operations can cause a fire inside the inverter or explosion. Death or lethal injuries due to hot or flying debris can result.

• Do not operate the DC load-break switch on the inverter in the event of ground fault

• Disconnect the PV array from the inverter via an external disconnection device. If there is no disconnecting device present, wait until no more DC power is applied to the inverter.

• Disconnect the AC circuit breaker, or keep it disconnected in case it has already tripped, and secure it against reconnection.

WARNING

Risk of injury due to toxic substances, gases and dusts.

In rare cases, damages to electronic components can result in the formation of toxic substances, gases or dusts inside the inverter. Touching toxic substances and inhaling toxic gases and dusts can cause skin irritation, burns or poisoning, trouble breathing and nausea.

WARNING

Danger to life due to electric shock from destruction of the measuring device due to overvoltage

Overvoltage can damage a measuring device and result in voltage being present in the enclosure of the measuring device. Touching the live enclosure of the measuring device results in death or lethal injuries due to electric shock.

• Only use measuring devices with a DC input voltage range of 600V or higher.

User ManualSBxx-US-1XP-41-BA-en-1110

Page 11

SMA Solar Technology AG

CAUTION

Risk of burns from hot surfaces

The surface of the inverter can get very hot. Touching the surface can result in burns.

• Mount the inverter in such a way that it cannot be touched inadvertently.

• Do not touch hot surfaces.

• Wait 30 minutes for the surface to cool sufficiently.

• Observe the safety messages on the inverter.

CAUTION

Risk of injury due to weight of product

Injuries may result if the product is lifted incorrectly or dropped while being transported or mounted.

• Transport and lift the product carefully. Take the weight of the product into account.

• Wear suitable personal protective equipment for all work on the product.

NOTICE

Damage to the enclosure seal in subfreezing conditions

If you open the product or disconnect the PowerUnit and ConnectionUnit when temperatures are below freezing, the enclosure seals can be damaged. Moisture can penetrate the product and damage it.

• If a layer of ice has formed on the enclosure seal when temperatures are below freezing, remove it prior to opening the product (e.g. by melting the ice with warm air).

• Do not disassemble the PowerUnit and ConnectionUnit unless the ambient temperature is at least 0°C (32°F) and conditions are frost-free.

2 Safety

NOTICE

Damage to the product due to sand, dust and moisture ingress

Sand, dust and moisture penetration can damage the product and impair its functionality.

• Only open the product if the humidity is within the thresholds and the environment is free of sand and dust.

• Do not open the product during a dust storm or precipitation.

• Close tightly all enclosure openings.

• Only use listed rain-tight or liquid-tight conduit fittings to attach the conduits to the product.

NOTICE

Damage to the inverter due to electrostatic discharge

Touching electronic components can cause damage to or destroy the inverter through electrostatic discharge.

• Ground yourself before touching any component.

User Manual SBxx-US-1XP-41-BA-en-11 11

Page 12

2 Safety

SMA Solar Technology AG

NOTICE

High costs due to inappropriate Internet tariff

Depending on use, the data volume of the product transferred via the Internet may vary in size. The data volume depends, for example, on the number of inverters in the system, the frequency of device updates, the frequency of data transfer to SunnyPortal or the use of FTP push. High costs for the Internet connection can be the result.

• SMA Solar Technology AG recommends using an Internet flat rate.

NOTICE

Damage to the product due to cleaning agents

The use of cleaning agents may cause damage to the product and its components.

• Clean the product and all its components only with a cloth moistened with clear water.

Electrical installations (for North America)

All installations must conform with the laws, regulations, codes and standards applicable in the jurisdiction of installation (e.g. National Electrical Code® ANSI/NFPA 70 or Canadian

Electrical Code® CSA-C22.1.).

• Before connecting the product to the utility grid, contact your local grid operator. The electrical connection of the product must be carried out by qualified persons only.

• Ensure that the cables or conductors used for electrical connection are not damaged.

User ManualSBxx-US-1XP-41-BA-en-1112

Page 13

SMA Solar Technology AG

SUNNY BO

3 Product Overview

3.1 Product Description

Figure 1: Design of the inverter

Position Designation

A Power Unit

B Enclosure lid of the Power Unit

C Enclosure lid for the Connection Unit

D Connection Unit

E Warning label with compliance information

F DC load-break switch

G Type label

The type label uniquely identifies the inverter. The type label must remain per-

H Fan (only with Sunny Boy 7.0 and 7.7)

manently attached to the product. You will find the following information on the type label:

• Inverter device type (Model)

• Serial number of the PowerUnit (Serial No. Power Unit or S/N Power Unit)

• Date of manufacture

• Device-specific characteristics

3 Product Overview

User Manual SBxx-US-1XP-41-BA-en-11 13

Page 14

3 Product Overview

Position Designation

I Additional type label

The additional type label must remain permanently attached to the product. You will find the following information on the additional type label:

• Device type (Model)

• Inverter serial number (Serial number device or S/N device)

• Identification key (PIC) for registration in Sunny Portal

• Registration ID (RID) for registration in Sunny Portal

• WLAN password (WPA2-PSK) for the direct connection to the user interface of the inverter via WLAN

J Display

The display shows the current operating data and events or errors.

K LEDs

The LEDs indicate the operating state of the product.

3.2 Symbols on the Product

Symbol Explanation

Beware of electrical voltage The product operates at high voltages.

SMA Solar Technology AG

Beware of hot surface The product can get hot during operation.

Observe the documentation Observe all documentation supplied with the product.

Observe the documentation Together with the red LED, this symbol indicates an error.

Inverter Together with the green LED, this symbol indicates the operating state of the in-

verter.

Data transmission Together with the blue LED, this symbol indicates the status of the network con-

nection.

User ManualSBxx-US-1XP-41-BA-en-1114

Page 15

SMA Solar Technology AG

Symbol Explanation

Equipment Grounding Terminal This symbol indicates the position for the connection of an equipment ground-

ing conductor.

UL1741 and CSA C22.2 No. 107.1 are the standards applied by Underwriters Laboratories to the product to certify that it meets the requirements of the National Electrical Code®, the Canadian Electrical Code® and IEEE1547.

3 Product Overview

3.3 Interfaces and Functions

The inverter can be equipped or retrofitted with the following interfaces and functions:

User interface for monitoring and configuration

The product is equipped as standard with an integrated webserver, which provides a user interface for configuring and monitoring the product. The product user interface can be called up via the web browser if there is an existing connection to an end device (e.g. computer, tablet PC or smartphone).

Smart Inverter Screen

The Smart Inverter Screen enables you to view the status display and to display the current power and consumption on the user interface login page. This gives you an overview of the most important inverter data without having to log into the user interface.

The Smart Inverter Screen is deactivated by default. The Smart Inverter Screen can be activated via the user interface once the inverter has been commissioned.

SMASpeedwire

The product is equipped with SMASpeedwire as standard. SMASpeedwire is a type of communication based on the Ethernet standard. SMASpeedwire is designed for a data transfer rate of 100Mbps and enables optimum communication between Speedwire devices within systems.

The products supports the encrypted system communication with SMA Speedwire Encrypted Communication. In order to be able to use the Speedwire encryption in the system, all Speedwire devices, except for the SMAEnergyMeter, must support the function SMA Speedwire Encrypted Communication.

Class 1 wiring methods are to be used for field wiring connection to the terminals of the communication interface.

SMA Webconnect

The inverter is equipped with a Webconnect function as standard. The Webconnect function enables direct data transmission between the inverter and SunnyPortal (online monitoring system from SMA).

User Manual SBxx-US-1XP-41-BA-en-11 15

Page 16

3 Product Overview

There are two SunnyPortal versions: the classical SunnyPortal (https://www.sunnyportal.com) and the newly developed SunnyPortal powered by ennexOS (https://ennexOS.sunnyportal.com). Both systems differ in their supported functions. With an existing user account, you can log into both portals as well as into SunnyDesign (system planning software from SMA).

In a SunnyPortal system, up to four inverters with Webconnect function can be displayed together. A communication product (e.g. SMADataManager) is required for systems with more than four inverters.

The system must be registered in the classic SunnyPortal if the inverter is integrated into a local network and connected to the Internet via this network. With this connection, you have the possibility to view the data online in real time.

If the inverter is connected to the Internet via the cellular network, you must register the system in SunnyPortal powered by ennexOS. The communication with the inverters is optimized with regard to the data volume and availability of the inverter. No data can be viewed in real time. Note that the inverter must be equipped with a firmware version ≥3.01.17.R for connection via the cellular network.

SMA Solar Technology AG

WLAN

The product is equipped with a WLAN interface as standard. The inverter is delivered with the WLAN interface activated as standard. If you do not want to use WLAN, you can deactivate the WLAN interface.

In addition, the product has a WPS function. The WPS function is for automatically connecting the product to a network (e.g. via router) and establish a direct connection between the product and an end device.

Expanding the radio range in the WLAN network

In order to expand the radio range of the inverter in the WLAN network, you can install the Antenna Extension Kit accessory set in the inverter.

Modbus

The product is equipped with a Modbus interface. The Modbus interface is deactivated by default and must be configured as needed.

The Modbus interface of the supported SMA products is designed for industrial use – via SCADA systems, for example – and has the following tasks:

• Remote query of measured values

• Remote setting of operating parameters

• Setpoint specifications for system control

Module slots

The inverter is standard-equipped with two module slots. The module slots are located on the communication assembly and allow additional modules to be connected (e.g. SMA Sensor Module). The modules are available as accessories. The installation of two identical modules is not permissible.

SMARS485Module

The inverters of type "SBx.x-1SP-US-41" can be retrofitted with the SMARS485Module.

User ManualSBxx-US-1XP-41-BA-en-1116

Page 17

SMA Solar Technology AG

By installing the SMA RS485 Module, the inverter is able to communicate with the energy meter of the SMARevenueGradeMeterKit.

Class 1 wiring methods are to be used for field wiring connection to the terminals of the communication interface.

3 Product Overview

Antenna Extension Kit

Within the WLAN network, the Antenna Extension Kit enables the radio range of the inverter to be upgraded (Information on assembly and connection see manual of the Antenna Extension Kit). The Antenna Extension Kit can be retrofitted.

SMA Cellular LTE Modem Kit

The inverter can be retrofitted with the SMA Cellular LTE Modem Kit from firmware version

03.01.17.R. The SMACellular LTE Modem Kit allows the direct data transmission between the inverter and the

internet portal SunnyPortal powered by ennexOS via the cellular network as an alternative to data transmission via Ethernet or WLAN. In addition, the SMA Cellular LTE Modem Kit enables the communication between the inverter and the energy meter.

The SMACellular LTE Modem Kit transmits up to four times a day a limited amount of data to SunnyPortal powered by ennexOS. The standard term of the mobile data plan for the SMACellular LTE Modem Kit is five years. All costs are covered within the term. No additional costs will be incurred. You have the possibility to extend the term of the mobile data plan. For this purpose, contact SMA Solar Technology AG. By using the SMACellular LTE Modem Kits, a local network connection is not absolutely necessary. However, it is recommended to be able to view all information regarding the system in SunnyPortal powered by ennexOS.

Energy meters in accordance with ANSI C12.20

The inverter type "SBx.x-1SP-US-41" can be retrofitted with the SMA Revenue Grade Meter Kit that in accordance with ANSI C12.20 includes an energy meter. The inverter must be equipped either with the SMA Cellular LTE Modem Kit or SMA RS485 Module to operate the SMA Revenue Grade Meter Kit. The inverter type "SBx.x-1TP-US-41" is equipped with an energy meter as standard.

The energy meter fulfills the accuracy class 0.5 in accordance with ANSI C12.20. The energy meter is a so called PV production meter intended to measure the generated energy of the inverter. The measured values of the energy meter can be used for billing purposes.

Grid Management Services

The inverter is a grid support interactive inverter. The inverter was tested in accordance with the UL1741 SA (2016-09-07) to be compliant with the

source requirements documents of the states available at the time. For connecting the inverter to the utility grid, no additional grid monitoring equipment is necessary. A description of the tested functions and instructions on the activation and setting of functions can be found in the technical information "Grid Support Utility Interactive Inverters" at www.SMA-Solar.com.

PV Rapid Shutdown Equipment

The inverter is listed as PV Rapid Shutdown Equipment (PVRSE) according to UL 1741. All DC inputs and AC outputs of this product comply with photovoltaic rapid shutdown requirements

for controlled conductors outside the array.

User Manual SBxx-US-1XP-41-BA-en-11 17

Page 18

3 Product Overview

SMA Solar Technology AG

A complete PV Rapid Shutdown System consists of the inverter, PV array disconnect switches, and a Rapid Shutdown initiation device. The Rapid Shutdown initiation device serves to initiate a rapid shutdown. The PV Rapid Shutdown System must limit the DC conductors to <30V within 30seconds.

NOTICE - The inverter's Rapid Shutdown function is initiated by disconnecting the inverter from the AC grid voltage, for example, by opening the main PV system AC disconnect. The AC disconnect that serves as the Rapid Shutdown initiation device must be readily accessible and clearly marked in accordance with National Electrical Code®. The Rapid Shutdown status of the PV system will be indicated by the On/Off (Closed/Open) position of this AC disconnect. The Off (Open) position indicates that a rapid shutdown has been initiated.

If PV array disconnect switches compliant with the SunSpec communication signal for Rapid Shutdown systems are installed, the inverter can transmit a SunSpec-compliant "permission to operate" signal to them via its DC input conductors. When a rapid shutdown is initiated, the inverter will stop transmitting the SunSpec signal. When the SunSpec signal is not being received, the PV array disconnect switches are responsible for reducing line voltages within the PV array in accordance with National Electrical Code®. In the event of a rapid shutdown via the SunSpec communication signal, it is important that all PV modules connected to the inverter are always equipped with SunSpec-compliant PV array disconnect switches, otherwise the inverter cannot start feed-in operation. The sum of the standby voltages of all PV array disconnect switches of a string must be <30V to ensure safe discharging of the DC lines. In addition, the recommended total length of all DC lines of a string should not exceed 300m (1000ft). The total length defines the length of the entire string wiring including the connection cable of the PV module switch in the string (measured from the positive DC terminal to the negative DC terminal of the inverter).

A PV Rapid Shutdown system can also be installed using PV array disconnect switches initiated in case of power failures or other means. In these cases, it must be ensured that the PV system Rapid Shutdown initiation device initiates a rapid shutdown of the PV array devices at the same time that the inverter is disconnected from grid voltage.

The PV array disconnect switches must disconnect the PV array from the inverter within a maximum of 15 seconds after Rapid Shutdown initiation.

The inverter is capable of grid support operation where in case of a power failure or by activating the AC disconnect, the inverter remains connected to the utility grid for a defined ride-through time and waits for voltage recovery. If grid voltage does not recover within the defined ride-through time, the inverter disconnects from the grid and a rapid shutdown is initiated.

The Rapid Shutdown function is disabled by default. The Rapid Shutdown function should only be enabled when PV array disconnect switches have been installed within the PV array or between the PV array and the inverter. The Rapid Shutdown function can be enabled during or after inverter commissioning via the user interface by selecting the operating mode suitable for the PV array disconnect switches. If the Rapid Shutdown function is enabled and no PV array disconnect switches are installed, the inverter cannot discharge the connected DC input conductors during a rapid shutdown. As a result, the inverter can be damaged.

WARNING - THIS PV RAPID SHUTDOWN EQUIPMENT DOES NOT PERFORM ALL OF THE FUNCTIONS OF A COMPLETE PV RAPID SHUTDOWN SYSTEM. THIS PV RAPID SHUTDOWN EQUIPMENT MUST BE INSTALLED WITH OTHER EQUIPMENT TO FORM A COMPLETE PV RAPID SHUTDOWN SYSTEM THAT MEETS THE REQUIREMENTS OF NEC (NFPA 70) FOR

User ManualSBxx-US-1XP-41-BA-en-1118

Page 19

SMA Solar Technology AG

CONTROLLED CONDUCTORS OUTSIDE THE ARRAY. OTHER EQUIPMENT INSTALLED IN OR ON THIS PV SYSTEM MAY ADVERSLY AFFECT THE OPERATION OF THE PV RAPID SHUTDOWN SYSTEM. IT IS THE RESPONSIBILITY OF THE INSTALLER TO ENSURE THAT THE COMPLETED PV SYSTEM MEETS THE RAPID SHUT DOWN FUNCTIONAL REQUIREMENTS. THIS EQUIPMENT MUST BE INSTALLED ACCORDING TO THE MANUFACTURER’S INSTALLATION MANUAL.

3 Product Overview

Parallel Operation of the DC Inputs A and B

The DC inputs A and B of the inverter can be operated in parallel and up to three strings can be connected to it in parallel. As a result, as opposed to normal operation, up to three strings can be connected directly to inverters with two DC inputs and up to four strings to inverters with three DC inputs. The inverter automatically detects the parallel operation of the DC inputs A and B.

Secure power supply operation

You can connect an external outlet and a switch to the inverter in order to enable the outlet. In case of a grid failure, the outlet supplies a load with current from the PV system. When the outlet is enabled via the switch, the load is supplied with current from the PV system. The inverter automatically regulates the energy supply of the outlet depending on the solar irradiation on the PV system. When the outlet is enabled and a load is supplied with current from the PV system, the inverter is disconnected from the utility grid and does not feed into the utility grid.

When using the SMA Rooftop Communication Kit and the TS4-O module technology components, secure power supply operation is only available if an external rapid shutdown initiator and the switch for secure power supply operation are connected to the module of the SMA Rooftop Communication Kit. The switch for secure power supply operation must be connected to the module in series with a voltage supply of 18V (e.g. two 9V batteries). If an external rapid-shutdown initiator is used, the AC miniature circuit breaker is no longer the rapid-shutdown initiator in the system.

When using TS4-F or TS4-S module technology components, secure power supply operation is not available.

No secure power supply operation when using TS4-F and TS4-S module technology components

If the SMARooftopCommunicationKit is installed in the inverter and TS4-F and TS4-S module technology components are used in the system, the secure power supply operation is not available. Secure power supply operation is only available in connection with TS4-O module technology components.

No secure power supply operation when using PV array disconnect switch as per the SunSpec interoperability specification

The secure power supply operation is not available if the Rapid Shutdown function of the inverter is enabled and the PV array disconnect switches are used in accordance with the SunSpec Interoperability Specification.

User Manual SBxx-US-1XP-41-BA-en-11 19

Page 20

3 Product Overview

SMA Solar Technology AG

Do not connect loads that require a stable electricity supply to the outlet for secure power supply operation.

Secure power supply operation must not be used for loads that require a stable electricity supply. The power available during secure power supply operation depends on the solar irradiation on the PV system. Therefore, power output can fluctuate considerably depending on the weather or may not be available at all.

• Do not connect loads to the outlet for secure power supply operation if they are dependent on a stable electricity supply for reliable operation.

Multifunction Relay

The inverter is equipped with a multifunction relay as standard. The multifunction relay is an interface that can be configured for the operating mode used by a particular system.

SMA ShadeFix

The inverter is equipped with the shade management system SMA ShadeFix. SMA ShadeFix uses an intelligent MPP tracking system to determine the operating point with the highest output during shading conditions. With SMA ShadeFix, inverters use the best possible energy supply from the PV modules at all times to increase yields in shaded systems. SMA ShadeFix is enabled by default. The time interval of SMA ShadeFix is usually six minutes. This means that the inverter determines the optimum operating point every six minutes. Depending on the PV system or shading situation, it may be useful to adjust the time interval.

String-failure detection

The self-learning string failure detection identifies to which of the three inverter DC inputs the strings are connected. The self-learning string failure detection identifies if the connected string is inoperable and is no longer contributing to the energy yield (e.g. due to damages such as a cable break) and monitors the input to which the defective string is connected. If the error persists, an event will be reported at the latest one day after the detection of the defective string. This prevents partial failures of the PV array from being undetected for a long time and which will result in yield losses. The self-learning string failure detections automatically identifies if a string has been repaired and resets the event. If the defective string should no longer be connected, the event must be reset manually.

Arc-Fault Circuit Interrupter (AFCI)

In accordance with the National Electrical Code®, the inverter has a system for DC arc fault detection and interruption. The arc-fault circuit interrupter is listed in accordance with UL 1699B Ed.1. A detected electric arc causes the inverter to interrupt feed-in operation for a short time and to resume the feed-in operation automatically. If the installation conditions allow it, you can deactivate the arc-fault circuit interrupter.

SMA Smart Connected

SMA Smart Connected is the free monitoring of the inverter via the SMA SunnyPortal. Thanks to SMA Smart Connected, the PV system operator and qualified person will be informed automatically and proactively about inverter events that occur.

User ManualSBxx-US-1XP-41-BA-en-1120

Page 21

SMA Solar Technology AG

SMA Smart Connected is activated during registration in SunnyPortal. In order to use SMA Smart Connected, it is necessary that the inverter is permanently connected to SunnyPortal and the data of the PV system operator and qualified person is stored in SunnyPortal and up-to-date.

3 Product Overview

3.4 LED Signals

The LEDs indicate the operating state of the inverter.

LED signal Explanation

The green LED is flashing (twoseconds on and twoseconds off)

The green LED is flashing (1.5s on and 0.5s off)

The green LED flashes quickly

The green LED is glowing Feed-in operation

The green LED is pulsing Feed-in operation

The green LED is off The inverter is not feeding into the utility grid.

The red LED is glowing Event occurred

The blue LED flashes slowly for approx. one minute

Waiting for feed-in conditions The conditions for feed-in operation are not yet met. As soon as the

conditions are met, the inverter will start feed-in operation.

Secure power supply operation The secure power supply operation is enabled and the inverter sup-

plies the outlet with current from the PV system.

Update of central processing unit The central processing unit of the inverter is being updated.

The inverter feeds in with a power of at least 90%.

The inverter is equipped with a dynamic power display via the green LED. Depending on the power, the green LED pulses fast or slow. If necessary, you can switch off the dynamic power display via the green LED.

In addition to the glowing red LED, the display indicates the following information about the event:

• Event type

• Event number

• Date and time at which the event occurred

Communication connection is being established The inverter is establishing a connection to a local network or is es-

tablishing a direct connection to an end device via Ethernet (e.g. computer, tablet PC or smartphone).

User Manual SBxx-US-1XP-41-BA-en-11 21

Page 22

3 Product Overview

LED signal Explanation

The blue LED flashes quickly for approx. two minutes (0.25s on and 0.25s off).

The blue LED is glowing Communication active

WPS active The WPS function is active.

There is an active connection with a local network or there is a direct connection with an end device via Ethernet (e.g. computer, tablet PC or smartphone).

SMA Solar Technology AG

3.5 Display messages

Display message Explanation

Package Installed firmware version and configured country data set

Ser Product serial number

HW Hardware version of the product

FW-HP Firmware version of the central processing unit

FW-KP Firmware version of the communication processor

Ethcom A Status of the network port A

Ethcom B Status of the network port B

E-IP Ethernet IP address of the product

SMsk Subnet mask of the product

GW Gateway address of the product

DNS IP address of the domain name server

Wlancom Status of the WLAN connection

W-IP WLAN IP address of the product

DC A Status of the DC input A

DC B Status of the DC input B

DC C Status of the DC input C

AC12 Voltage / current between the line conductors L1 and L2

AC13 Voltage / current between the line conductors L1 and L3

AC23 Voltage / current between the line conductors L2 and L3

SPS-mode active The secure power supply operation is enabled.

P: Overload Overload at the input for secure power supply operation

Update status Firmware update information

Error An event has occurred.

User ManualSBxx-US-1XP-41-BA-en-1122

Page 23

SMA Solar Technology AG

Display message Explanation

P Instantaneous output power

E-Total Total produced energy

Pmax Maximum output power

cos φ Displacement power factor

Update file(s) found New firmware version available

Update progress Update is being performed

3 Product Overview

User Manual SBxx-US-1XP-41-BA-en-11 23

Page 24

4 Operation

SMA Solar Technology AG

4 Operation

4.1 Activating and Operating the Display

You can activate and operate the display by tapping on the enclosure lid of the Connection Unit.

Procedure:

1. Activate the display. Tap on the enclosure lid of the Connection Unit once. ☑ The backlight is switched on.

2. To move to the next message, tap on the enclosure lid of the Connection Unit once.

4.2 Establishing a connection to the user interface

4.2.1 Establishing a Direct Connection via Ethernet

Requirements:

☐ The product must be commissioned. ☐ An end device (e.g. computer) with an Ethernet interface must be available. ☐ The product must be connected directly to the end device. ☐ The respective latest version of one of the following web browsers must be installed: Chrome,

Edge, Firefox, Internet Explorer or Safari.

☐ The SMA Grid Guard code of the Installer must be available for the changing of grid-relevant

settings after completion of the first ten feed-in hours or installation assistant (see "Application for SMAGridGuard Code" at www.SMA-Solar.com).

IP address of the inverter

• Standard inverter IP address for the direct connection via Ethernet: 169.254.12.3

Procedure:

1. Tap on the enclosure lid of the Connection Unit and continue to switch up to the message E-IP:

169.254.xxx.xxx.

2. Read off the displayed IP address for the direct connection via Ethernet and either remember it

or write it down.

3. Open the web browser of your end device. Enter the IP address in the address bar of the web

browser. Then press Enter key.

Web browser signals a security vulnerability

After the IP address has been entered, a message might appear indicating that the connection to the user interface of the product is not secure. SMA Solar Technology AG guarantees the security of the user interface.

• Continue loading the user interface.

☑ The login page of the user interface opens.

User ManualSBxx-US-1XP-41-BA-en-1124

Page 25

SMA Solar Technology AG

4 Operation

4.2.2 Establishing a direct connection via WLAN

Requirements:

☐ The product must be commissioned. ☐ An end device (e.g. computer, tablet PC or smartphone) must be available. ☐ The respective latest version of one of the following web browsers must be installed: Chrome,

Edge, Firefox, Internet Explorer or Safari. ☐ JavaScript must be enabled in the web browser of the end device. ☐ The SMA Grid Guard code of the Installer must be available for the changing of grid-relevant

settings after completion of the first ten feed-in hours or installation assistant (see "Application

for SMAGridGuard Code" at www.SMA-Solar.com).

SSID, IP address and WLAN password

• SSID in WLAN: SMA[serial number] (e.g. SMA0123456789)

• Device-specific WLAN password: see WPA2-PSK on the type label of the product or the rear side of the manual included in delivery

• Standard access address for a direct connection via WLAN outside of a local network:

https://smalogin.net or 192.168.12.3

Importing and exporting files with end devices having an iOS operating system is not possible.

For technical reasons, importing and exporting files (e.g., importing an inverter configuration, saving the current inverter configuration or exporting events and parameters) is not possible with mobile end devices having an iOS operating system.

• Use an end device that does not have an iOS operating system for importing and exporting files.

You have several options to connect the product to an end device. The procedure can be different depending on the end devices. If the procedures described do not apply to your end device, establish the direct connection via WLAN as described in the manual of your end device.

The following connection options ar available:

• Connection with WPS

• Connection with WLAN network search

Connection with WPS

Requirement:

☐ The end device must have a WPS function.

Procedure:

1. Enable the WPS function on the inverter. To do this, tap twice on the enclosure lid of the Connection Unit.

☑ The blue LED flashes quickly for approx. two minutes. The WPS function is active during

this time.

User Manual SBxx-US-1XP-41-BA-en-11 25

Page 26

4 Operation

2. Enable the WPS function on your end device.

☑ The end device automatically connects to the inverter. The web browser of your end

device opens and the login page of the user interface is displayed.

3. If the web browser of your end device does not open automatically and the login page of the user interface is not displayed, open the web browser and enter https://smalogin.net in the address bar.

SMA Solar Technology AG

Connection with WLAN network search

1. Search for WLAN networks with your end device.

2. Select the SSID of the inverter SMA[serial number] in the list with the found WLAN networks.

3. Enter the device-specific WLAN password (see WPA2-PSK on the type label of the product or the rear side of the manual included in delivery).

4. Open the web browser of your end device and enter https://smalogin.net in the address bar.

☑ The login page of the user interface is displayed.

5. If the login page of the user interface does not open, enter the IP address 192.168.12.3 or, if your end device supports mDNS services, SMA[serial number].local or https://

SMA[serial number] in the address bar of the web browser.

4.2.3 Establishing a Connection via Ethernet in the local network

New IP address for connecting with a local network

If the product is connected to a local network (e.g. via a router), the product will receive a new IP address. Depending on the type of configuration, the new IP address will be assigned automatically by the DHCP server (router) or manually by you. Upon completion of the configuration, the product can only be reached via the following access addresses:

• Generally applicable access address: IP address manually assigned or assigned by the DHCP server (router) (identification via network scanner software or network configuration of the router).

• Access address for Apple and Linux systems: SMA[serial number].local (e.g. SMA0123456789.local)

• Access address for Windows and Android systems: https://SMA[serial number] (e.g. https://SMA0123456789)

User ManualSBxx-US-1XP-41-BA-en-1126

Page 27

SMA Solar Technology AG

Requirements:

☐ The product must be connected to the local network via a network cable (e.g. via a router). ☐ The product must be integrated into the local network. Tip: There are various methods of

integrating the product into the local network with the aid of the installation assistant. ☐ An end device (e.g. computer, tablet PC or smartphone) must be available. ☐ The end device must be in the same local network as the product. ☐ The respective latest version of one of the following web browsers must be installed: Chrome,

Edge, Firefox, Internet Explorer or Safari. ☐ The SMA Grid Guard code of the Installer must be available for the changing of grid-relevant

settings after completion of the first ten feed-in hours or installation assistant (see "Application

for SMAGridGuard Code" at www.SMA-Solar.com).

Procedure:

1. Open the web browser of your end device, enter the IP address of the inverter in the address bar of the web browser and press the enter key.

Web browser signals a security vulnerability

• Continue loading the user interface.

☑ The login page of the user interface opens.

4 Operation

4.2.4 Establishing a Connection via WLAN in the Local Network

New IP address for connecting with a local network

• Generally applicable access address: IP address manually assigned or assigned by the DHCP server (router) (identification via network scanner software or network configuration of the router).

• Access address for Apple and Linux systems: SMA[serial number].local (e.g. SMA0123456789.local)

• Access address for Windows and Android systems: https://SMA[serial number] (e.g. https://SMA0123456789)

User Manual SBxx-US-1XP-41-BA-en-11 27

Page 28

4 Operation

Requirements:

☐ The product must be commissioned. ☐ The product must be integrated into the local network. Tip: There are various methods of

Edge, Firefox, Internet Explorer or Safari. ☐ The SMA Grid Guard code of the Installer must be available for the changing of grid-relevant

settings after completion of the first ten feed-in hours or installation assistant (see "Application

for SMAGridGuard Code" at www.SMA-Solar.com).

SMA Solar Technology AG

Importing and exporting files with end devices having an iOS operating

system is not possible.

For technical reasons, importing and exporting files (e.g., importing an inverter configuration,

saving the current inverter configuration or exporting events and parameters) is not possible

with mobile end devices having an iOS operating system.

• Use an end device that does not have an iOS operating system for importing and exporting files.

Procedure:

• Enter the IP address of the inverter in the address bar of the web browser. ☑ The login page of the user interface opens.

4.3 Logging In and Out of the User Interface

After a connection to the user interface of the inverter has been established, the login page opens. Log onto the user interface as described below.

Usage of cookies

For the correct display of the user interface, cookies are required. The cookies are used for convenience only. By using this user interface you agree to the placement of cookies.

Password assignment for user and installer

The passwords for the user groups Installer and User must be assigned when accessing the user interface for the first time. If the inverter was registered in a communication device (e.g., SMADataManager) and the system password was assigned, the system password is also the installer password. In this case, only the user password must be assigned.

• If you as a specialist assign the user password, only pass the password on to persons to access the inverter data via the user interface.

• If you as a user assign the installer password, only pass the password on to persons to receive access to the system.

User ManualSBxx-US-1XP-41-BA-en-1128

Page 29

SMA Solar Technology AG

4 Operation

Installer password for inverters registered in a communication device or in SunnyPortal

To be able to register the inverter in a communication device (e.g., SMADataManager) or in a SunnyPortal system, the password for the user group Installer must match the system password. If you assign a password for the user group Installer via the user interface of the inverter, the same password must also be used as the system password.

• Assign a uniform installer password to all SMA devices in the system.

Procedure:

1. In the drop-down list Language, select the desired language.

2. In the Password field, enter a password for the User user group.

3. In the Repeat password field, enter the password again.

4. Click on Save.

5. In the New password field, enter a password for the Installer user group. Assign a uniform password to all SMA devices to be registered in a system. The installer password is also the system password.

6. In the Repeat password field, enter the password again.

7. Click on Save and log in.

☑ The Configuring the Inverter page opens.

1. In the drop-down list Language, select the desired language.

2. In the User group drop-down list, select the entry Installer or User.

3. Enter the password in the field Password.

4. Select Login.

☑ The start page of the user interface opens.

Log Out as the User or Installer

1. On the right-hand side of the menu bar, select the menu User Settings.

2. In the subsequent context menu, select [Logout].

☑ The login page of the user interface opens. The logout was successful.

User Manual SBxx-US-1XP-41-BA-en-11 29

Page 30

4 Operation

4.4 Start Page Design of the User Interface

SMA Solar Technology AG

Figure 2: Design of the user interface's start page (example)

User ManualSBxx-US-1XP-41-BA-en-1130

Page 31

SMA Solar Technology AG

4 Operation

Position Designation Description

A Menu Provides the following functions:

• Home Opens the user interface homepage

• Instantaneous values Current measured values of the inverter

• Device Parameters The various operating parameters of the inverter can

be viewed and configured here depending on the user group.

• Events All events that have occurred in the selected time

period are displayed here. The event types are Information, Warning and Error. Currently existing events of the types Error and Warning will be additionally displayed in the Device status viewlet. However, only the higher-priority event is displayed. If, for example, there is a Warning and an Error present at the same time, only the Error will be displayed.

• Device configuration Various settings for the inverter can be made here.

The selection available is dependent on which user group you are logged in as and the operating system of the device with which the user interface has been called up.

• Data You will find all data that is saved in the internal

memory of the inverter or on an external storage medium on this page.

B User settings Provides the following functions, depending on the user

group logged in:

• Starting the installation assistant

• SMA Grid Guard login

• Logout

C Help Provides the following functions:

• Displaying information on Open Source licenses used

• Link to the website of SMA Solar Technology AG

User Manual SBxx-US-1XP-41-BA-en-11 31

Page 32

4 Operation

SMA Solar Technology AG

Position Designation Description

D Status bar Displays the following information:

• Inverter serial number

• Inverter firmware version

• IP address of the inverter within the local network and/or IP address of the inverter during WLAN connection

• With WLAN connection: Signal strength of WLAN connection

• User group logged in

• Date and device time of the inverter

E Current power and cur-

rent consumption

Temporal progression of the PV power and the power consumption of the household over the selected time period. Please note, the power consumption will only be displayed if an energy meter is installed in the PV system.

F Status display The various areas display information on the current status

of the PV system.

• Device status Displays whether the inverter is currently in a fault-

free operating state or whether there is an Error or Warning present.

• Current power Displays the power currently being generated by the

inverter.

• Yield Displays the energy yield of the inverter.

• Grid supply Displays the energy supply from the utility grid.

• Power at the grid-connection point Indicates which power is currently fed in or obtained

at the grid-connection point.

• Irradiation / wind speed Depending on the connected sensors, displays the

current solar irradiation and/or wind speed.

• Temperature measurement Depending on the connected sensors, displays the

current temperature of the PV modules and/or the ambient temperature.

User ManualSBxx-US-1XP-41-BA-en-1132

Page 33

SMA Solar Technology AG

4 Operation

4.5 Displaying and Downloading the Stored Data

If an external storage device is plugged in, you can display and download the stored data.

Procedure:

1. Activate the user interface (see Section4.2, page24).

2. Log into the user interface (see Section4.3, page28).

3. Select the menu Data.

4. Select the folder Data.

5. To call up the data, select the respective folder and click on the required file.

6. To download the data, select the data type to be exported in the drop-down list. Then apply the time filter and select Data export.

4.6 Activating the Smart Inverter Screen

With the Smart Inverter Screen, the most important inverter data is displayed directly on the user interface login page. To activate the Smart Inverter Screen, proceed as listed in the following.

Procedure:

1. Activate the user interface (see Section4.2, page24).

2. Log in as Installer or User.

3. Select the menu User Settings (see Section4.4, page30) on the start page of the user interface.

4. Select [Smart Inverter Screen].

☑ The Smart Inverter Screen has been activated.

User Manual SBxx-US-1XP-41-BA-en-11 33

Page 34

4 Operation

SMA Solar Technology AG

4.7 Starting the Installation Assistant

The installation assistant leads you step-by-step through the steps necessary for the initial configuration of the inverter.

Layout of the installation assistant

Figure 3: Layout of the installation assistant (example)

Position Designation Description

A Configuration steps Overview of the installation assistant steps. The number of

steps depends on the type of device and the additionally installed modules. The current step is highlighted in blue.

B User information Information about the current configuration step and the

setting options of the configuration step.

C Configuration field You can make settings in this field.

Requirement:

☐ When configuring after completion of the first tenfeed-in hours or after exiting the installation

assistant, the SMA Grid Guard code must be available in order to change the grid-relevant parameters (see "Application for SMAGridGuard Code" at www.SMA-Solar.com).

Procedure:

1. Open the user interface (see Section4.2, page24).

2. Log in as Installer.

3. Select the menu User Settings (see Section4.4, page30) on the start page of the user interface.

4. In the context menu, select [Starting the installation assistant].

☑ The installation assistant will open.

User ManualSBxx-US-1XP-41-BA-en-1134

Page 35

SMA Solar Technology AG

4 Operation

4.8 Secure power supply operation

4.8.1 Enable secure power supply operation

If an outlet and a switch for secure power supply operation are connected to the inverter, you can supply a load with current from the PV system in case of a grid failure during the day. If you enable the secure power supply operation, the inverter supplies loads that are connected to the outlet for secure power supply operation.

In case of overload, underload or insufficient solar irradiation, the voltage supply of the outlet is briefly interrupted. The inverter automatically attempts to reestablish the voltage supply 20seconds after the interruption. This can lead to inadvertent starting of the load that is connected to the outlet. Ensure that the load connected to the outlet does not consume too much power. If necessary, reduce the power consumption of the load.

In case of a grid failure during the night, secure power supply operation is not possible.

During the night, secure power supply operation cannot be enabled since the PV system does not produce power that is required to supply the load.

• In case of a grid failure during the night, do not enable secure power supply operation.

• Continue to operate the inverter on the utility grid and wait for restoration of grid operation.

• In the event of a persistent grid failure, switch to secure power supply operation after sunrise.

Do not connect loads that require a stable electricity supply to the outlet for secure power supply operation.

• Do not connect loads to the outlet for secure power supply operation if they are dependent on a stable electricity supply for reliable operation.

Procedure:

1. If no load is connected to the outlet, connect a load.

2. Turn the switch of the outlet to secure power supply operation.

3. Wait one minute. ☑ The inverter commences secure power supply operation. As soon as the inverter supplies

the outlet with power, the green LED flashes (1.5s on and 0.5s off) and the message SPS-mode active is shown in the display along with the amount of power being supplied from the inverter to the outlet. In addition, the control light of the outlet for secure power supply operation glows.

User Manual SBxx-US-1XP-41-BA-en-11 35

Page 36

4 Operation

4. The PV system's output is too low when: the green LED does not flash and no message that the

secure power supply operation mode is enabled appears on the display or the control lamp of the outlet does not glow. Irradiation on the PV system is probably too low or the connected load requires more power than currently available. Carry out the following measures:

• Ensure that the outlet's switch is set to secure power supply operation.

• If irradiation is too low, wait for it to increase.

• Connect a load with lower power consumption to the outlet.

5. If no voltage can be measured at the outlet, ensure that the switch of the outlet is set to secure

power supply operation, and that the switch, outlet and control light for secure power supply operation are correctly connected.

SMA Solar Technology AG

4.8.2 Disable secure power supply operation

1. If necessary, disconnect the load from the outlet.

2. Turn the switch of the outlet to grid operation. ☑ Grid operation is activated.

3. Switch on the circuit breaker of the PV system.

☑ The inverter connects to the utility grid and starts feed-in operation.

4.9 Activate WPS Function

The WPS function can be used for different purposes:

• Automatic connection to a network (e.g. via router)

• Direct connection between the product and an end device

Depending on the intended application of the WPS function, the procedure for activation will vary.

Activating WPS function for automatic connection to a network

Requirements:

☐ WLAN must be activated in the product. ☐ WPS must be activated on the router.

Procedure:

1. Activate the user interface (see Section4.2, page24).

2. Log in as Installer.

3. Start the installation assistant (see Section4.7, page34).

4. Select Network configuration.

5. Select WPS for WLAN network button in the WLAN tab.

6. Select Activate WPS.

7. Select Save and next and exit the installation assistant.

☑ The WPS function is activated and the automatic connection to the network can be

established.

User ManualSBxx-US-1XP-41-BA-en-1136

Page 37

SMA Solar Technology AG

4 Operation

Activating the WPS function for direct connection to the end device.

• Activate the WPS function on the inverter. To do this, tap twice on the enclosure lid of the Connection Unit.

☑ The blue LED flashes quickly for approx. two minutes. The WPS function is active during

this time.

4.10 Switching WLAN On and Off

The inverter is equipped with an activated WLAN interface as standard. If you do not want to use WLAN, you can switch the WLAN function off and switch it on again whenever needed. In doing so, you can switch the WLAN direct connection and the WLAN connection in the local network on independently of each other.

Switching on the WLAN function only possible via Ethernet connection

If you switch off both the WLAN function for the direct connection and for the connection in the local network, access to the inverter user interface and therefore reactivation of the WLAN interface is only possible via an Ethernet connection.

The basic procedure for changing operating parameters is explained in another section (see Section4.13 "Changing Operating Parameters", page38).

Switching WLAN Off

If you would like to switch the WLAN function off completely, you must switch off both the direct connection and the connection in the local network.

Procedure:

• To switch off the direct connection in the parameter group PV system communication > WLAN, select the parameter Soft-access-point is turned on and set this to No.

• To switch off the connection in the local network in the parameter group PV system communication > WLAN, select the parameter WLAN is turned on and set this to No.

Switching WLAN On

If you have switched the WLAN function for direct connection or for connection in the local network off, you can switch the WLAN function back on in accordance with the following procedure.

Requirement:

☐ If the WLAN function was previously switched off completely, the inverter must be connected

to a computer or router via Ethernet.

Procedure:

• To switch on the WLAN direct connection, in the parameter group PV system communication > WLAN, select the parameter Soft-access-point is turned on and set this

to Yes.

• To switch on the WLAN connection in the local network, in the parameter group System communication > WLAN, select the parameter WLAN is turned on and set this to Yes.

User Manual SBxx-US-1XP-41-BA-en-11 37

Page 38

4 Operation

SMA Solar Technology AG

4.11 Switching the Dynamic Power Display Off

As standard, the inverter signals its power dynamically via the pulsing of the green LED. When doing so, the LED flashes on and off uniformly or is permanently lit at full power. The various gradations are related here to the set active power limit of the inverter. If this display is not desired, switch this function off in accordance with the following procedure. Once this has been done, the green LED is lit permanently to signalize feed-in operation.

The basic procedure for changing operating parameters is explained in another section (see Section4.13 "Changing Operating Parameters", page38).

Procedure:

• In the parameter group Device > Operation, select the parameter Dynamic power display via green LED and set this to Off.

4.12 Changing the Password

The password for the inverter can be changed for both user groups. Furthermore, the user group

Installer can change the password for the user group User as well as its own password.

PV systems registered in a communication product

With PV systems that are registered in a communication product (e.g. SunnyPortal, ClusterController), you can also assign a new password for the user group Installer via the communication product. The password for the user group Installer is also the system password. If you assign a password for the user group Installer via the user interface of the inverter that does not correspond to the system password in the communication product, the inverter can no longer be reached by the communication product.

• Ensure that the password for the user group Installer is the same as the system password in the communication product.

Procedure:

1. Activate the user interface (see Section4.2, page24).

2. Log into the user interface (see Section4.3, page28).

3. Call up the menu Device Parameters.

4. Select [Edit parameters].

5. In the parameter group User Rights > Access Control change the password of the desired user group.

6. Select [Save all] to save the changes.

4.13 Changing Operating Parameters

The operating parameters of the inverter are set to certain values by default. You can change the operating parameters to optimize the performance of the inverter.

User ManualSBxx-US-1XP-41-BA-en-1138

Page 39

SMA Solar Technology AG

This section describes the basic procedure for changing operating parameters. Always change operating parameters as described in this section. Some function-sensitive parameters can only be viewed by qualified persons and can only be changed by qualified persons by entering the personal SMA Grid Guard code.

4 Operation

No configuration via SunnyExplorer

SunnyExplorer does not support the configuration of inverters with their own user interface. The inverter can be detected via SunnyExplorer, however it is expressly not recommended to use SunnyExplorer to configure this inverter. SMA Solar Technology AG does not accept liability for missing or incorrect data and possibly resulting yield losses.

• Use the user interface for the configuration of the inverter.

Requirements:

☐ Changes to grid-relevant parameters must be approved by the responsible grid operator.

Procedure:

1. Open the user interface (see Section4.2, page24).

2. Log into the user interface (see Section4.3, page28).

3. Call up the menu Device Parameters.

4. Click on [Edit parameters].

5. Log in using the SMA Grid Guard code to change those parameters designated by a lock (only for installers):

• Select the menu User Settings (see Section4.4, page30).

• In the subsequent context menu, select [SMA GridGuard login].

• Enter the SMA Grid Guard code and select [Login].

6. Expand the parameter group that contains the parameter which is to be configured.

7. Change the desired parameters.

8. Select [Save all] to save the changes.

☑ The inverter parameters are set.

4.14 Configuring the Country Data Set

As standard, the inverter is meant for connection to a utility grid with a 208V wye connection or a 240V split-phase system, and the associated country data set UL1741/2016/120 is factory-set. If the default country data set does not correspond with the grid configuration, the country data set can be adapted to the connected grid configuration.

User Manual SBxx-US-1XP-41-BA-en-11 39

Page 40

4 Operation

The basic procedure for changing operating parameters is explained in another section (see Section4.13 "Changing Operating Parameters", page38).

Grid configuration Configurable country data sets

208Vdelta connection UL 1741: UL1741/2016/208

CA Rule 21: HECO_OHM Rule 14H SRD 1.1: HECO_OHM

Rule 14H SRD 1.1 / 208 L-L ISO-NE: NE-ISO / 208 L-L

208 V wye connection UL 1741: UL1741/2016/120

CA Rule 21: CA Rule 21 / 120 L-N-L HECO_OHM Rule 14H SRD 1.1: HECO_OHM

Rule 14H SRD 1.1 / 120 L-N-L ISO-NE: NE-ISO / 120 L-N-L

240 V delta connection UL 1741: UL1741/2016/240

CA Rule 21: CA Rule 21 / 240 L-L HECO_OHM Rule 14H SRD 1.1: HECO_OHM

Rule 14H SRD 1.1 / 240 L-L ISO-NE: NE-ISO / 240 L-L

240V split-phase system UL1741/2016/120

CA Rule 21: CA Rule 21 / 120 L-N-L HECO_OHM Rule 14H SRD 1.1: HECO_OHM

Rule 14H SRD 1.1 / 120 L-N-L ISO-NE: NE-ISO / 120 L-N-L

Stand-alone grid Island Mode 50Hz / Island Mode 60Hz

SMA Solar Technology AG

Procedure:

• Select the parameter Set country standard and set the required country data set.

4.15 Configuring the Rapid Shutdown Function

The Rapid Shutdown function of the inverter must be enabled if the PV modules or PV strings are equipped with an additional DC disconnection unit that disconnects the PV array from the inverter. You can enable the Rapid Shutdown function by selecting one of three available operating modes in accordance with the DC disconnection unit used. If you do not want to use the Rapid Shutdown function, you can disable it.

User ManualSBxx-US-1XP-41-BA-en-1140

Page 41

SMA Solar Technology AG

Explanation of operating modes:

Operating mode Explanation

SunSpec Shutdown

Off

TS4 Shutdown

For using an additional DC disconnection unit independent of the inverter between the inverter and PV generator that disconnects the generator.

For using PV array disconnect switch as per the SunSpec interoperability specification.

The Rapid Shutdown function is disabled.

When using TS4 module technology TS4-R-F devices are excluded. With TS4-R-F, SunSpec Shutdown must be selected.

4 Operation

No secure power supply operation when using PV array disconnect switch as per the SunSpec interoperability specification

Procedure:

1. Open the user interface (see Section4.2, page24).

2. Log into the user interface as an Installer.

3. On the right-hand side of the menu bar, select the menu User Settings (see Section4.4 "Start Page Design of the User Interface", page30).

4. In the context menu, select [Starting the installation assistant].

5. Select [Save and next] until you reach the Safety functions step.

6. Configure the Rapid Shutdown function according to the DC disconnection unit used.

4.16 Changing the Operating Mode of the Multifunction Relay

The default operating mode of the multifunction relay is Fault indication (FltInd) . If you decide to use another operating mode and have established the correct electrical connection for this operating mode and the associated connection variant, you will have to change the operating mode of the multifunction relay and make other settings, if necessary.

The basic procedure for changing operating parameters is explained in another section (see Section4.13 "Changing Operating Parameters", page38).

Procedure:

1. Call up the menu Device Parameters.

2. Select [Edit parameters].

3. In the parameter group Device > Multifunction relay > Operating mode select the parameter Operating mode of multifunction relay or Mlt.OpMode and set the desired operating mode.

User Manual SBxx-US-1XP-41-BA-en-11 41

Page 42

4 Operation

4. Once you have set the operating mode Self-consumption or SelfCsmp, you can configure other settings:

• In the parameter group Device > Multifunction relay > Self-consumption >

Minimum On power select the parameter Minimum On power for MFR selfconsumption or Mlt.MinOnPwr and set the desired value. This will configure the

power threshold from which a load is to be activated.

• In the parameter group Device > Multifunction relay > Self-consumption >

Minimum power On time select the parameter Minimum power On time, MFR selfconsumption or Mlt.MinOnPwrTmm and set the desired value. This will configure the

minimum time for which the power must have exceeded the minimum switch-on power threshold in order to trip activation of the load.

• In the parameter group Device > Multifunction relay > Self-consumption >

Minimum On power select the parameter Minimum On time for MFR selfconsumption or Mlt.MinOnTmm and set the desired value. This will configure the

minimum time for which the load remains activated.

5. If you have set the operating mode Control via communication or ComCtl, in the parameter group Device > Multifunction relay > Control via communication > Status select the parameter Status of MFR with control via communication or Mlt.ComCtl.Sw and set the desired value. This determines whether the multifunction relay can be controlled via a communication product.

6. If you have set the operating mode Battery bank or BatCha, make further settings:

• In the parameter group Device > Multifunction relay > Battery bank > Minimum On

power select the parameter Minimum On power for MFR battery bank or Mlt.BatCha.Pwr and set the desired value. This will configure the power threshold from

which the battery is to be charged.

• In the parameter group Device > Multifunction relay > Battery bank > Minimum

time before reconnection select the parameter Minimum time before reconnection of MFR battery bank or Mlt.BatCha.Tmm and set the desired value. This will

configure the minimum time which must elapse after charging the battery before the battery can be charged again.

7. Select [Save all] to save the changes.

SMA Solar Technology AG

4.17 Configuring the ModbusFunction

The Modbus interface is deactivated by default and the communication ports 502 set. In order to access SMA invertes with SMA Modbus® or SunSpec® Modbus®, the Modbus interface

must be activated. After activating the interface, the communication ports of both IP protocols can be changed. For information on commissioning and configuration of the Modbus interface, see the technical information "SMA and SunSpec Modbus® Interface" at www.SMA-Solar.com.

For information on which Modbus registers are supported, see the technical information "Modbus® parameters and measured values" at www.SMA-Solar.com.

User ManualSBxx-US-1XP-41-BA-en-1142

Page 43

SMA Solar Technology AG

4 Operation

Data security during enabled Modbus interface

If you enable the Modbus interface, there is a risk that unauthorized users may access and manipulate the data or devices in your PV system.

To ensure data security, take appropriate protective measures such as:

• Set up a firewall.

• Close unnecessary network ports.

• Only enable remote access via VPN tunnel.

• Do not set up port forwarding at the communication port in use.

• In order to disable the Modbus interface, reset the inverter to the default settings or disable the parameter again.

Procedure:

• Activate the Modbus interface and adjust the communication ports if necessary (see the technical information "SMA and SunSpec Modbus® Interface" at www.SMA-Solar.com).

4.18 Setting SMA ShadeFix

You can set the time interval in which the inverter has to determine the optimum operating point. If you do not want to use SMA ShadeFix, you can disable the feature.

The basic procedure for changing operating parameters is explained in another section (see Section4.13 "Changing Operating Parameters", page38).

Procedure:

• In the parameter group DC-side > DC settings > SMA ShadeFix, set the parameter Time interval of SMA ShadeFix and set the required time interval. The ideal time interval is

usually six minutes. This value should only be increased if the shading situation changes extremely slowly.

☑ The inverter optimizes the MPP of the PV system at the predetermined time interval.

• In order to disable the SMAShadeFix feature, in the parameter group DC-side > DC settings

> SMA ShadeFix, set the parameter SMA ShadeFix switched on to Off.

4.19 Deactivating the Arc-Fault Circuit Interrupter (AFCI)

The basic procedure for changing operating parameters is explained in another section (see Section4.13 "Changing Operating Parameters", page38).

Procedure:

• Select the parameter AFCI switched on or AfciIsOn and set to No.

User Manual SBxx-US-1XP-41-BA-en-11 43

Page 44

4 Operation

SMA Solar Technology AG

4.20 Saving the Configuration in a File

You can save the current configuration of the inverter in a file. You can use this file as a data backup for this inverter and then import this file into this inverter again or another inverter from the same type or device family to configure the inverter. When saving, only the device parameters will be saved, not any passwords.

Procedure:

1. Activate the user interface (see Section4.2, page24).

2. Log into the user interface (see Section4.3, page28).

3. Select the menu Device Configuration.

4. Select [Settings].

5. In the context menu, select [Saving the configuration in a file].

6. Follow the instructions in the dialog.

4.21 Adopting a Configuration from a File

To configure the inverter, you can adopt the configuration from a file. To be able to do this, you must first save the configuration of another inverter from the same type or device family in a file (see Section4.20 "Saving the Configuration in a File", page44). When saving, only the device parameters will be adopted, not any passwords.

Requirements:

☐ Changes to grid-relevant parameters must be approved by the responsible grid operator. ☐ The SMA Grid Guard code must be available (see "Application for SMAGridGuard Code"

at www.SMA-Solar.com).

Procedure:

1. Open the user interface (see Section4.2, page24).

2. Log into the user interface as an Installer (see Section4.3, page28).

3. Select the menu Device Configuration.

4. Select [Settings].

5. In the context menu, select [Adopting the configuration from a file].

6. Follow the instructions in the dialog.

4.22 Updating the Firmware

If no automatic update is set for the inverter in the communication product (e.g. SMADataManager, ClusterController, SunnyPortal) or via the user interface of the inverter, you have the option of carrying out a manual firmware update.

You have the following options to update the firmware:

• Update the firmware with the existing update file via the user interface of the inverter.

User ManualSBxx-US-1XP-41-BA-en-1144

Page 45

SMA Solar Technology AG

• Update the firmware with the existing update file via USB flash drive.

• Search and install the firmware via the user interface of the inverter.

4 Operation

Faulty firmware update due to disconnecting the inverter from the utility grid.

The inverter must be connected to the utility grid during the firmware update. This will ensure a proper firmware update.

• Do not disconnect the inverter from the utility grid during the firmware update.

Update the firmware with the existing update file via the user interface of the inverter.

Requirements:

☐ An update file with the desired inverter firmware must be available. The update file is, for

example, available for download on the product page of the inverter at www.SMA-Solar.com. To download the update file, it is necessary to enter the serial number of the inverter.

Procedure:

1. Open the user interface (see Section4.2, page24).

2. Log into the user interface as an Installer (see Section4.3, page28).

3. Select the menu Device Configuration.

4. In the inverter row, click on the gear icon and select Update firmware.

5. Select [Browse] and select the update file for the inverter.

6. Select Update firmware.

7. Follow the instructions in the dialog.

Update the firmware with the existing update file via USB flash drive.

Requirements:

☐ A USB flash drive with maximum 32GB and file system FAT32 must be available.

Procedure:

1. Create an "UPDATE" folder on the USB stick.

2. Save the update file with the required firmware in the "UPDATE" folder on the USB flash drive. The update file is, for example, available for download on the product page of the inverter at www.SMA-Solar.com. Ensure that only the update file to which the inverter is to be updated must be stored on the USB flash drive.

DANGER

Danger to life due to high voltages

• Disconnect the inverter from any voltage sources and open the enclosure lid of the Connection Unit (see the inverter installation manual).

4. Insert the USB flash drive in the USB port on the communication assembly.

User Manual SBxx-US-1XP-41-BA-en-11 45

Page 46

4 Operation

5. Commission the inverter (see inverter installation manual). ☑ During start-up phase of the inverter, the desired firmware is being installed. At the same

time, the status of the update is shown in the display: Update status: xxxxxxx

☑ Once the desired firmware has been installed in the inverter, the status successful is

shown in the display.

6. If the message error occurred is shown in the display, perform the firmware update again.

DANGER

SMA Solar Technology AG

Danger to life due to high voltages

• Disconnect the inverter from any voltage sources and open the enclosure lid of the Connection Unit (see the inverter installation manual).

8. Pull the USB flash drive out of the USB port.

9. Commission the inverter (see inverter installation manual).

Search and install the firmware via the user interface of the inverter.

Requirements:

☐ The inverter must be connected to the Internet.

Procedure:

1. Open the user interface (see Section4.2, page24).

2. Log into the user interface as an Installer (see Section4.3, page28).

3. Click on [Edit parameters].

4. Go to Device > Update.

5. Select the parameter Check for update and install it and set it to Execute.

6. Click on [Save all].

☑ The firmware is updated in the background.

User ManualSBxx-US-1XP-41-BA-en-1146

Page 47

SMA Solar Technology AG

5 Cleaning the Inverter

NOTICE

Damage due to cleaning agents

The use of cleaning agents may cause damage to the product and its components.

• Clean the product and all its components only with a cloth moistened with clear water.

• Ensure that the inverter is free of dust, foliage and other dirt.

User Manual SBxx-US-1XP-41-BA-en-11 47

Page 48

6 Troubleshooting

SMA Solar Technology AG

6 Troubleshooting

6.1 Forgotten Password

If you have forgotten the password for the inverter, you can unlock the inverter with a Personal Unlocking Key (PUK). For each inverter, there is one PUK for each user group (User and Installer). Tipp: With PV systems that are registered in a communication product, you can also assign a new password for the user group Installer via the communication product. The password for the user group Installer is the same as the system password in the communication product.

Procedure:

1. Request PUK (application form available at www.SMA-Solar.com).

2. Open the user interface (see Section4.2, page24).

3. Enter the PUK instead of the password into the field Password.

4. Select Login.

5. Call up the menu Device Parameters.

6. Click on [Edit parameters].

7. In the parameter group User Rights > Access Control change the password of the desired user group.

8. Select [Save all] to save the changes.

Password assignment for inverters that are registered in a communication product

The password for the user group Installer is also the system password for the system in the communication product. Changing the password of the user group Installer can lead to the inverter no longer being able to be reached by the communication product.

• In the communication product, assign the changed password of the user group Installer as the new system password (see the manual of the communication product).

User ManualSBxx-US-1XP-41-BA-en-1148

Page 49

SMA Solar Technology AG

6.2 Event Messages

Event number Message, cause and corrective measures

101 102 103 105

202 203 205 206

Grid fault

The grid voltage or grid impedance at the connection point of the inverter is too high. The inverter has disconnected from the utility grid.

Corrective measures:

• Ensure that the correct country data set has been configured.

• Check whether the grid voltage at the connection point of the inverter is permanently in the permissible range.

If the grid voltage is outside the permissible range due to local grid conditions, contact the grid operator. The grid operator must agree with an adjustment of the voltage at the feed-in point or with a change of the monitored operating limits.

If the grid voltage is permanently within the permissible range and this message is still displayed, contact Service.

Grid fault

The utility grid has been disconnected, the AC cable is damaged or the grid voltage at the connection point of the inverter is too low. The inverter has disconnected from the utility grid.

Corrective measures:

• Ensure that the circuit breaker is switched on.

• Ensure that the AC cable is not damaged and that it is connected correctly.

• Ensure that the country data set has been configured correctly.

• Check whether the grid voltage at the connection point of the inverter is permanently in the permissible range.

If the grid voltage is permanently within the permissible range and this message is still displayed, contact Service.

6 Troubleshooting

User Manual SBxx-US-1XP-41-BA-en-11 49

Page 50

6 Troubleshooting

Event number Message, cause and corrective measures

301

Grid fault

The ten-minute average value of the grid voltage is no longer within the permissible range. The grid voltage or grid impedance at the connection point is too high. The inverter disconnects from the utility grid to maintain power quality.

Corrective measures:

• During the feed-in operation, check whether the grid voltage at the connection point of the inverter is permanently in the permissible range.

If the grid voltage is permanently within the permissible range and this message is still displayed, contact Service.

401 404

Grid fault

The inverter has disconnected from the utility grid. A stand-alone grid or a very large change in the power frequency was detected.

Corrective measures:

• Check the grid connection for significant short-term frequency fluctuations.

501

SMA Solar Technology AG

Grid fault

The power frequency is not within the permissible range. The inverter has disconnected from the utility grid.

Corrective measures:

• If possible, check the power frequency and observe how often fluctuations occur.

If fluctuations occur frequently and this message is displayed often, contact the grid operator and request approval to change the operating parameters of the inverter.

If the grid operator gives his approval, discuss any changes to the operating parameters with the Service.

User ManualSBxx-US-1XP-41-BA-en-1150

Page 51

SMA Solar Technology AG

Event number Message, cause and corrective measures

601

Grid fault

The inverter has detected an excessively high proportion of direct current in the grid current.

Corrective measures:

• Check the grid connection for direct current.

• If this message is displayed frequently, contact the grid operator and check whether the monitoring threshold on the inverter can be raised.

701

Frq. not permitted > Check parameter

The power frequency is not within the permissible range. The inverter has disconnected from the utility grid.

Corrective measures:

• If possible, check the power frequency and observe how often fluctuations occur.

If fluctuations occur frequently and this message is displayed often, contact the grid operator and request approval to change the operating parameters of the inverter.

If the grid operator gives his approval, discuss any changes to the operating parameters with the Service.

1001

6 Troubleshooting

L/N swapped > Check connection

The connection of L and N is swapped.

Corrective measures:

• Ensure that L and N are correctly connected (see installation manual).

1302

Waiting for grid voltage > Installation failure grid connection > Check grid and fuses

L or N not connected.

Corrective measures:

• Ensure that L and N are connected (see installation manual).

• Ensure that the AC conductors are not damaged and correctly connected (see installation manual).

• Ensure that the circuit breaker is switched on.

User Manual SBxx-US-1XP-41-BA-en-11 51

Page 52

6 Troubleshooting

Event number Message, cause and corrective measures

1501

Reconnection fault grid

The changed country data set or the value of a parameter you have set does not correspond to the local requirements. The inverter cannot connect to the utility grid.

Corrective measures:

• Ensure that the country data set has been configured correctly. To do this, select the parameter Set country standard and check the value.

3301 3303

Unstable operation

There is not enough power at the DC input of the inverter for stable operation. The inverter cannot connect to the utility grid.

Corrective measures:

• Ensure that the PV array is designed correctly.

• Ensure that the PV array is not covered by snow or otherwise shaded.

• Ensure that the PV array is free of errors.

3401 3402 3407

DC overvoltage > Disconnect generator

Overvoltage at the DC input. This can destroy the inverter. This message is signalized additionally by rapid flashing of the LEDs.

Corrective measures:

• Disconnect the inverter from voltage sources immediately (see installation manual).

• Check whether the DC voltage is below the maximum input voltage of the inverter. If the DC voltage is below the maximum input voltage of the inverter, reconnect the terminal block with the connected DC conductors to the inverter.

• If the DC voltage exceeds the maximum input voltage of the inverter, ensure that the PV array has been correctly rated or contact the installer of the PV array.

• If this message is repeated frequently, contact the Service.

3501

SMA Solar Technology AG

Insulation failure > Check generator

The inverter has detected a ground fault in the PV array.

Corrective measures:

• Check the PV system for ground faults.

User ManualSBxx-US-1XP-41-BA-en-1152

Page 53

SMA Solar Technology AG

Event number Message, cause and corrective measures

3601

High discharge curr. > Check generator

The leakage current of the inverter and the PV array is too high. There is a ground fault, a residual current or a malfunction.

The inverter interrupts feed-in operation immediately after exceeding a threshold. When the fault is eliminated, the inverter automatically reconnects to the utility grid.

Corrective measures:

• Check the PV system for ground faults.

3701

Resid.curr.too.high > Check generator

The inverter has detected a residual current due to temporary grounding of the PV array.

Corrective measures:

• Check the PV system for ground faults.

3801 3802 3805

DC overcurrent > Check generator

Overcurrent at the DC input. The inverter briefly interrupts feed-in operation.

Corrective measures:

• If this message is displayed frequently, ensure that the PV array has been correctly rated and wired.

3901 3902

Waiting for DC start conditions > Start cond. not met

The feed-in conditions for the utility grid are not yet fulfilled.

Corrective measures:

• Ensure that the PV array is not covered by snow or otherwise shaded.

• Wait for higher irradiation.

• If this message is displayed frequently in the morning, increase the voltage limit for starting grid feed-in. Change the parameter Critical voltage to start feed-in.

• If this message is displayed frequently with medium irradiation, ensure that the PV array is correctly rated.

6 Troubleshooting

User Manual SBxx-US-1XP-41-BA-en-11 53

Page 54

6 Troubleshooting

Event number Message, cause and corrective measures

4301

Electric arc detected > Check DC generator

The inverter has detected an electric arc. A detected electric arc causes the inverter to interrupt feed-in operation for a short time and to resume the feed-in operation automatically.

Corrective measures:

• Check the PV array.

6512

Minimum operating temperature not reached

The inverter will only recommence grid feed-in once the temperature has reached at least −25°C.

6701 6702

Communication disturbed

Error in the communication processor, the inverter continues feeding in, however. The cause must be determined by the Service.

Corrective measures:

• If this message is displayed frequently, contact the Service.

6803

Self-diagnosis > Input A defective Corrective measures:

• Check whether a string is connected to input A. If a string that once was connected is not used anymore, the string-failure detection must be reset.

• Contact the Service.

6903

SMA Solar Technology AG

7106

7110

7112

Self-diagnosis > Input B defective Corrective measures:

• Check whether a string is connected to input B. If a string that once was connected is not used anymore, the string-failure detection must be reset.

• Contact the Service.

Update file defect.

The update file is defective. The update failed. The inverter continues to feed in.

No update file found

No new update file was found on the SD memory card. The update failed. The inverter continues to feed in.

Update file successfully copied

User ManualSBxx-US-1XP-41-BA-en-1154

Page 55

SMA Solar Technology AG

Event number Message, cause and corrective measures

7113

The memory card is full or write-protected

7303

Update main CPU failed

The cause must be determined by the Service.

Corrective measures:

• Contact the Service.

7324

Wait for update conditions

The testing of the update conditions was not successful. The firmware update package is not suitable for this inverter.

Corrective measures:

• Retry update.

• Ensure that the selected update file is suitable for this inverter.

• If this message is displayed again, contact the Service.

7331

Update transport started

Update file is being copied.

7332

Update transport successful

Update file was copied successfully to the inverter's internal memory.

7333

6 Troubleshooting

Update transport failed

Update file could not be copied to the inverter's internal memory. In the event of connection with the inverter via WLAN, a poor connection quality can be the cause.

Corrective measures:

• Retry update.

• For WLAN connection, improve the WLAN connection quality (e.g. via SMA Antenna Extension Kit) or establish connection with the inverter via Ethernet.

• If this message is displayed again, contact the Service.

7340

User Manual SBxx-US-1XP-41-BA-en-11 55

Update communication failed

Page 56

6 Troubleshooting

Event number Message, cause and corrective measures

7347

Incompatible file

The configuration file is not suitable for this inverter.

Corrective measures:

• Ensure that the selected configuration file is suitable for this inverter.

• Retry import.

7348

Incorrect file format

The configuration file is not of the required format or is damaged.

Corrective measures:

• Ensure that the selected configuration file is of the required format and is not damaged.

• Retry import.

7350

Transfer of a configuration file has started

The configuration file is being transferred.

7351

Update WLAN

The inverter is updating the WLAN module.

7352

SMA Solar Technology AG

7353

7354

7355

Update of WLAN not successful

The update of the WLAN module failed.

Corrective measures:

• Retry update.

• If this message is displayed again, contact the Service.

Update time zone database

The inverter is updating the time zone database.

Update of time zone database not successful

The update of the time zone database failed.

Corrective measures:

• Retry update.

• If this message is displayed again, contact the Service.

Update WebUI

The inverter is updating the inverter user interface.

User ManualSBxx-US-1XP-41-BA-en-1156

Page 57

SMA Solar Technology AG

Event number Message, cause and corrective measures

7356

Update of the WebUI not successful

The update of the inverter user interface failed.

Corrective measures:

• Retry update.

• If this message is displayed again, contact the Service.

7619

Communication fault with meter unit > Check communication to meter

The inverter is not receiving any data from the energy meter.

Corrective measures:

• Ensure that the energy meter is correctly integrated into the same network as the inverter (see energy meter manual).

• For WLAN connection, improve the WLAN connection quality (e.g. via SMA Antenna Extension Kit) or connect the inverter with the DHCP server (router) via Ethernet.

8003

Active power limited temperature

The inverter has reduced its power output for more than ten minutes due to excessive temperature.

Corrective measures:

• Clean the cooling fins on the rear of the enclosure and the air ducts on the top using a soft brush.

• Ensure that the inverter has sufficient ventilation.

• Ensure that the ambient temperature +45°C (113°F) has not been exceeded.

• Ensure that the inverter is not exposed to direct solar irradiation.

8206

6 Troubleshooting

Electr. arc detected > Please confirm by tapping

The inverter has detected an electric arc and was recommissioned after a disconnection. By tapping, you are confirming that you have repaired any possible damage to PV modules, DC conductors or plugs in the PV system.

Corrective measures:

• Tap on the enclosure lid of the Connection Unit within ten seconds of the message appearing in order to recommission the inverter.

User Manual SBxx-US-1XP-41-BA-en-11 57

Page 58

6 Troubleshooting

Event number Message, cause and corrective measures

8503

Self-diagnosis > Input C defective Corrective measures:

• Check whether a string is connected to input C. If a string that once was connected is not used anymore, the string-failure detection must be reset.

• Contact the Service.

8708

Timeout in communication for active power limitation

Communication to the system control absent. Depending on the fall-back setting, either the last received values will be retained or the active power will be limited to the set percentage value of the inverter nominal power.

Corrective measures:

• Ensure that the connection to the system manager (e.g. SunnyHomeManager) is intact and that no cables are damaged or that no plugs have been pulled.

8801 8803

No display

No information can be shown on the display.

9002

SMA Solar Technology AG

9003

9005

SMA Grid Guard code invalid

The SMAGridGuard code entered is incorrect. The operating parameters are still protected and cannot be changed.

Corrective measures:

• Enter the correct SMAGridGuard code.

Grid parameter locked

Changes to the grid parameters are now blocked. In order to be able to make changes to the grid parameters, from now on you must log in using the SMA Grid Guard code.

Changing of grid parameters not possible > Ensure DC supply

This error can have the following causes:

• The parameters to be changed are protected.

• The DC voltage at the DC input is not sufficient to run the main CPU.

Corrective measures:

• Enter the SMA Grid Guard code.

• Ensure that at least the DC start voltage is available (green LED is flashing, pulsing or glowing).

User ManualSBxx-US-1XP-41-BA-en-1158

Page 59

SMA Solar Technology AG

Event number Message, cause and corrective measures

9034

Error in Rapid Shutdown System

This message can have the following causes:

• The Rapid Shutdown Function was not correctly configured.

• The PV generator could not be correctly disconnected. Voltage can be applied to the DC inputs of the inverter.

• The standby voltage of all PV module switches of a string is > 30V.

Corrective measures:

• Check the configuration of the Rapid Shutdown function and ensure that the operating mode selected is selected according to the DC disconnection unit used.

• Check the functionality of the PV module switches.

• Check the standby voltage of the PV module switches used and ensure that the standby voltage of all PV module switches of a string < 30V.

9037

Generator connection not carried out

The PV module switches did not connect the PV generator.

Corrective measures:

• Check the functionality of the SunSpec-compliant PV module switches.

9202

6 Troubleshooting

SPS AC overvoltage

An AC source has been connected to the outlet for secure power supply operation.

Corrective measures:

• Check the connection at the SPS slots, and make any necessary corrections.

9203

Short circuit in the SPS power outlet

The maximum initial load has been overshot or the appliance's initial current is above the maximum permissible load current of the terminal for secure power supply operation for more than 5s.

Corrective measures:

• Reduce the load at the terminal for secure power supply operation.

• If necessary, select an appliance with a lower initial current.

User Manual SBxx-US-1XP-41-BA-en-11 59

Page 60

6 Troubleshooting

Event number Message, cause and corrective measures

10110

Time synchronization failed: [x]

No time information could be called up from the set NTP server.

Corrective measures:

• Ensure that the NTP server was configured correctly.

• Ensure that the inverter is integrated into a local network with Internet connection.

10248 10249

Load reduced through device reduction or increase of query interval

The network is busy. Data exchange between the devices is not at an optimum and is greatly delayed.

Corrective measures:

• Reduce the number of devices in the network.

• If necessary, increase the data query intervals.

• If necessary, reduce the number of devices in the network.

10250

[Interface]: package error rate [ok / high]

The package error rate has changed. If the package error rate is high, the network is overloaded or the connection to the network switch or DHCP server (router) is disturbed.

Corrective measures if the package error rate is high:

• Ensure that with an Ethernet connection, the network cable and the network connector are not damaged and that the network connectors are correctly plugged.

• If necessary, increase the data query intervals.

• If necessary, reduce the number of devices in the network.

10251

[Interface]: communication status goes to [OK / Warning / Error / Not connected]

The communication status to the network switch or DHCP server (router) has changed. An additional error message may be displayed.

10252

SMA Solar Technology AG

[Interface]: communication disrupted

There is no valid signal on the network line.

Corrective measures:

• Ensure that with an Ethernet connection, the network cable and the network connector are not damaged and that the network connectors are correctly plugged.

• Ensure that the DHCP server (router) and any network switches are signalizing correct operation.

User ManualSBxx-US-1XP-41-BA-en-1160

Page 61

SMA Solar Technology AG

Event number Message, cause and corrective measures

10253

[Interface]: connection speed goes to [100Mbit / 10Mbit]

The data transfer rate has changed. The cause for the status [10 Mbit] can be a defective plug, a defective cable or the pulling or plugging of the network connector.

Corrective measures if the status is [10 Mbit]:

• Ensure that with an Ethernet connection, the network cable and the network connector are not damaged and that the network connectors are correctly plugged.

• Ensure that the DHCP server (router) and any network switches are signalizing correct operation.

10254

[Interface]: duplex mode goes to [Full / Half]

The duplex mode (data transfer mode) has changed. The cause for the status [Half] can be a defective plug, a defective cable or the pulling or plugging of the network connector.

Corrective measures if the status is [Half]:

• Ensure that with an Ethernet connection, the network cable and the network connector are not damaged and that the network connectors are correctly plugged.

• Ensure that the DHCP server (router) and any network switches are signalizing correct operation.

10255

[Interface]: Network load OK

The network load has returned to a normal range after being busy.

10282

[User group]-Login via [protocol] locked

After several incorrect login attempts, login has been blocked for a limited time. In this case, the User login will be blocked for 15minutes, the GridGuard login for 12hours.

Corrective measures:

• Wait until the given time has expired and then retry login.

10283

WLAN module faulty

The WLAN module integrated in the inverter is defective.

Corrective measures:

• Contact the Service.

6 Troubleshooting

User Manual SBxx-US-1XP-41-BA-en-11 61

Page 62

6 Troubleshooting

Event number Message, cause and corrective measures

10284

No WLAN connection possible

The inverter does not currently have a WLAN connection to the selected network.

Corrective measures:

• Ensure that the SSID, the WLAN password and the encryption method have been entered correctly. The encryption method is specified by your WLAN router or WLAN Access Point and can be changed there.

• Ensure that the WLAN router or WLAN Access Point is in range and is signalizing correct operation.

• If this message is displayed often, improve the WLAN connection by using a WLAN repeater (e.g. SMA Antenna Extension Kit).

10285

WLAN connection established

Connection to the selected WLAN network has been established.

10286

WLAN connection lost

The inverter has lost WLAN connection to the selected network.

Corrective measures:

• Ensure that the WLAN router or WLAN Access Point is still active.

• Ensure that the WLAN router or WLAN Access Point is in range and is signalizing correct operation.

• If this message is displayed often, improve the WLAN connection by using a WLAN repeater (e.g. SMA Antenna Extension Kit).

10339

Webconnect enabled

The inverter can communicate with Sunny Portal without an additional SMA communications product (e.g. SunnyDataManager).

10340

Webconnect disabled

The Webconnect function has been switched off. This means that the inverter can not communicate with SunnyPortal without an additional SMA communications product (e.g. SunnyDataManager).

• If the inverter is to communicate with Sunny Portal without an additional SMA communication product, switch the Webconnect function on.

SMA Solar Technology AG

User ManualSBxx-US-1XP-41-BA-en-1162

Page 63

SMA Solar Technology AG

Event number Message, cause and corrective measures

10341

Webconnect error: no connection

It is likely that there is an error in the network settings.

Corrective measures:

• Check the network components (DLAN, WLAN Access Point etc.).

• Ensure that the following ports are not blocked:

– Registrar: ied.sma.de:9523 – Proxy: ied.sma.de:9523 – Stun: stun.sma.de:3478 – Domain: ied.sma.de (for SIP URI)

10343

Webconnect error: Default gateway not configured

It is likely that there is an error in the network settings.

Corrective measures:

• Check the network components (DLAN, WLAN Access Point etc.).

• Ensure that the following ports are not blocked:

– Registrar: ied.sma.de:9523 – Proxy: ied.sma.de:9523 – Stun: stun.sma.de:3478 – Domain: ied.sma.de (for SIP URI)

10344

Webconnect error: DNS server not configured

It is likely that there is an error in the network settings.

Corrective measures:

• Check the network components (DLAN, WLAN Access Point etc.).

• Ensure that the following ports are not blocked:

– Registrar: ied.sma.de:9523 – Proxy: ied.sma.de:9523 – Stun: stun.sma.de:3478 – Domain: ied.sma.de (for SIP URI)

10345

No reply to DNS request

It is likely that there is an error in the network settings.

Corrective measures:

• Check the network components (DLAN, WLAN Access Point etc.).

• Ensure that the following ports are not blocked:

– Registrar: ied.sma.de:9523 – Proxy: ied.sma.de:9523 – Stun: stun.sma.de:3478 – Domain: ied.sma.de (for SIP URI)

6 Troubleshooting

User Manual SBxx-US-1XP-41-BA-en-11 63

Page 64

6 Troubleshooting

Event number Message, cause and corrective measures

10346

SIP proxy DNS resolution failed

It is likely that there is an error in the network settings.

Corrective measures:

• Check the network components (DLAN, WLAN Access Point etc.).

• Ensure that the following ports are not blocked:

– Registrar: ied.sma.de:9523 – Proxy: ied.sma.de:9523 – Stun: stun.sma.de:3478 – Domain: ied.sma.de (for SIP URI)

10347

Stun server DNS resolution failed

It is likely that there is an error in the network settings.

Corrective measures:

• Check the network components (DLAN, WLAN Access Point etc.).

• Ensure that the following ports are not blocked:

– Registrar: ied.sma.de:9523 – Proxy: ied.sma.de:9523 – Stun: stun.sma.de:3478 – Domain: ied.sma.de (for SIP URI)

10348

Webconnect error: No reply to request to STUN server

It is likely that there is an error in the network settings.

Corrective measures:

• Check the network components (DLAN, WLAN Access Point etc.).

• Ensure that the following ports are not blocked:

– Registrar: ied.sma.de:9523 – Proxy: ied.sma.de:9523 – Stun: stun.sma.de:3478 – Domain: ied.sma.de (for SIP URI)

SMA Solar Technology AG

User ManualSBxx-US-1XP-41-BA-en-1164

Page 65

SMA Solar Technology AG

Event number Message, cause and corrective measures

10349

Webconnect error: No reply to SIP option packs

It is likely that there is an error in the network settings or a Sunny Portal maintenance message is present.

Corrective measures:

• If a Sunny Portal maintenance message is present, wait until the maintenance has been completed.

• Check the network components (DLAN, WLAN Access Point etc.).

• Ensure that the following ports are not blocked:

– Registrar: ied.sma.de:9523 – Proxy: ied.sma.de:9523 – Stun: stun.sma.de:3478 – Domain: ied.sma.de (for SIP URI)

10350

Webconnect error: Registration rejected by SIP registrar

It is likely that there is an error in the network settings.

Corrective measures:

• Check the network components (DLAN, WLAN Access Point etc.).

• Ensure that the following ports are not blocked:

– Registrar: ied.sma.de:9523 – Proxy: ied.sma.de:9523 – Stun: stun.sma.de:3478 – Domain: ied.sma.de (for SIP URI)

10351

Unknown SIP registry

It is likely that there is an error in the network settings.

Corrective measures:

• Check the network components (DLAN, WLAN Access Point etc.).

• Ensure that the following ports are not blocked:

– Registrar: ied.sma.de:9523 – Proxy: ied.sma.de:9523 – Stun: stun.sma.de:3478 – Domain: ied.sma.de (for SIP URI)

6 Troubleshooting

User Manual SBxx-US-1XP-41-BA-en-11 65

Page 66

6 Troubleshooting

Event number Message, cause and corrective measures

10352

Webconnect error: Faulty communication

It is likely that there is an error in the network settings or a Sunny Portal maintenance message is present.

Corrective measures:

• If a Sunny Portal maintenance message is present, wait until the maintenance has been completed.

• Check the network components (DLAN, WLAN Access Point etc.).

• Ensure that the following ports are not blocked:

– Registrar: ied.sma.de:9523 – Proxy: ied.sma.de:9523 – Stun: stun.sma.de:3478 – Domain: ied.sma.de (for SIP URI)

10353

Webconnect error: registration of the SIP registry has not responded

It is likely that there is an error in the network settings or a Sunny Portal maintenance message is present.

Corrective measures:

• If a Sunny Portal maintenance message is present, wait until the maintenance has been completed.

• Check the network components (DLAN, WLAN Access Point etc.).

• Ensure that the following ports are not blocked:

– Registrar: ied.sma.de:9523 – Proxy: ied.sma.de:9523 – Stun: stun.sma.de:3478 – Domain: ied.sma.de (for SIP URI)

27107

Update file OK

The update file is suitable for this inverter and its components and is fully available for the next update step.

27108

Memory card is being read

The storage medium is being read.

27109

No new update on the memory card

A new update file was not found on the storage medium.

27301

Update communication

The inverter is updating the communication component.

27302

Update main CPU

The inverter is updating the inverter component.

27312

Update completed

The inverter has successfully completed the update.

SMA Solar Technology AG

User ManualSBxx-US-1XP-41-BA-en-1166

Page 67

SMA Solar Technology AG

Event number Message, cause and corrective measures

27331

27332

29001

29004

Update transport started

The inverter has successfully started the update.

Update transport successful

The update file has been successfully transferred to the communication component.

Inst. code valid

The entered GridGuard code is valid. Protected parameters have now been unlocked and you can adjust the parameters. The parameters will be automatically locked again after ten feed-in hours.

Grid parameters unchanged

Changing the grid parameters is not possible.

6 Troubleshooting

6.3 Checking the PV System for Ground Faults

If the inverter displays the event numbers 3501, 3601 or 3701, there could be a ground fault. The electrical insulation from the PV system to ground is defective or insufficient.

DANGER

Danger to life due to electric shock when touching live system components in case of a ground fault

If a ground fault occurs, parts of the system may still be live. Touching live parts and cables results in death or lethal injuries due to electric shock.

• Disconnect the product from voltage sources and make sure it cannot be reconnected before working on the device.

• Touch the cables of the PV array on the insulation only.

• Do not touch any parts of the substructure or frame of the PV array.

• Do not connect PV strings with ground faults to the inverter.

• Ensure that no voltage is present and wait five minutes before touching any parts of the PV system or the product.

WARNING

Danger to life due to electric shock from destruction of the measuring device due to overvoltage

• Only use measuring devices with a DC input voltage range of 600V or higher.

User Manual SBxx-US-1XP-41-BA-en-11 67

Page 68

6 Troubleshooting

Procedure:

In order to check the PV system for ground faults, perform the following actions in the prescribed order. The exact procedure is described in the following sections.

• Check the PV system for ground faults by measuring the voltage.

• If the voltage measurement was not successful, check the PV system via insulation resistance measurement for ground faults.

SMA Solar Technology AG

Test by Measuring the Voltage

Proceed as follows to check each string in the PV system for ground faults.

Procedure:

DANGER

Danger to life due to high voltages

• Disconnect the inverter from any voltage sources (see the inverter installation manual).

2. Measure the voltages:

• Measure the voltage between the positive terminal and the ground potential (PE).

• Measure the voltage between the negative terminal and the ground potential (PE).

• Measure the voltage between the positive and negative terminals. If the following results are present at the same time, there is a ground fault in the PV system:

☑ All measured voltages are stable. ☑ The sum of the two voltages to ground potential is approximately equal to the

voltage between the positive and negative terminals.

3. If a ground fault is present, determine the location of the ground fault via the ratio of the two measured voltages and eliminate the ground fault.

4. If a definite ground fault cannot be measured and the message is still displayed, measure the insulation resistance.

5. Reconnect the strings without ground faults to the inverter and recommission the inverter (see inverter installation inverter).

User ManualSBxx-US-1XP-41-BA-en-1168

Page 69

SMA Solar Technology AG

100 V 100 V 100 V 100 V 100 V

V = 200 V

V = 300 V

6 Troubleshooting

Location of the ground fault

The example shows a ground fault between the second and third PV module.

Test by Measuring the Insulation Resistance

If the voltage measurement does not provide sufficient evidence of a ground fault, the insulation resistance measurement can provide more exact results.

Figure 4: Schematic diagram of the measurement

User Manual SBxx-US-1XP-41-BA-en-11 69

Page 70

6 Troubleshooting

total

SMA Solar Technology AG

Calculating the insulation resistance

The expected total resistance of the PV system or of an individual string can be calculated using the following formula:

The exact insulation resistance of a PV module can be obtained from the module manufacturer or the datasheet.

For the resistance of a PV module an average value can be assumed: for thin-film PV modules approximately 40MOhm and for polycrystalline and monocrystalline PV modules approximately50MOhm per PV module (for further information on calculating the insulation resistance see the Technical Information "Insulation Resistance (Riso) of Non-Galvanically Isolated PV Systems" at www.SMA-Solar.com).

Required devices:

☐ Suitable device for safe disconnection and short-circuiting ☐ Measuring device for insulation resistance

Device required for safe disconnection and short-circuiting of the PV array

The insulation resistance can only be measured with a suitable device for safe disconnection and short-circuiting of the PV array. If no suitable device is available, the insulation measurement must not be carried out.

Procedure:

1. Calculate the expected insulation resistance per string.

DANGER

Danger to life due to high voltages

• Disconnect the inverter from any voltage sources (see the inverter installation manual).

3. Install the short circuit device.

4. Connect the measuring device for insulation resistance.

5. Short-circuit the first string.

6. Set the test voltage. The test voltage should be as close as possible to the maximum system voltage of the PV modules but must not exceed it (see datasheet of the PV modules).

7. Measure the insulation resistance.

8. Eliminate the short circuit.

9. Measure the remaining strings in the same manner.

☑ If the insulation resistance of a string deviates considerably from the theoretically

calculated value, there is a ground fault present in that string.

10. Reconnect to the inverter only those strings from which the ground fault has been eliminated.

11. Reconnect all other strings to the inverter.

User ManualSBxx-US-1XP-41-BA-en-1170

Page 71

SMA Solar Technology AG

6 Troubleshooting

12. Recommission the inverter (see inverter installation manual).

13. If the inverter still displays an insulation error, contact the Service (see Section9, page74). The PV modules might not be suitable for the inverter in the present quantity.

User Manual SBxx-US-1XP-41-BA-en-11 71

Page 72

7 Accessories

SMA Solar Technology AG

7 Accessories

You will find the accessories for your product in the following overview. If required, these can be ordered from SMA Solar Technology AG or your distributor.

Designation Short designation SMA order number

SMA Antenna Extension Kit

SMA485Module Only for inverters of type "SBx.x-1SP-

SMACellularLTEModemKit

SMARevenueGradeMeterKit

Accessory set for one SMA inverter for the optimization of the SMA inverter’s WLAN radio range.

US-41": for establishing communication between the inverter and the energy meter of the SMARevenueGradeMeterKit (only applicable if no SMACellularModemKit is used)

Only for inverters of type "SBx.x-1SPUS-41": for establishing communication with the SunnyPortal via the mobile communication network (as an alternative to Ethernet or WLAN) For establishing communication between the inverter and the energy meter of the RevenueGradeMeterKit

Only for inverters of type "SBx.x-1SPUS-41": for the installation of an energy meter according to ANSI C12.20

EXTANT-US-40

MD.485-US-40

CellModKit-US-10

RGM05Kit-US-10

User ManualSBxx-US-1XP-41-BA-en-1172

Page 73

SMA Solar Technology AG

8 Compliance Information

FCC Compliance

This device complies with Part 15 of the FCC Rules and with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions:

1. this device may not cause harmful interference, and

2. this device must accept any interference received, including interference that may cause undesired operation.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.

L'exploitation est autorisée aux deux conditions suivantes :

1. l'appareil ne doit pas produire de brouillage, et

2. l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications made to this equipment not expressly approved by SMA Solar Technology AG may void the FCC authorization to operate this equipment.

IC Compliance

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

User Manual SBxx-US-1XP-41-BA-en-11 73

Page 74

9 Contact

SMA Solar Technology AG

9 Contact

If you have technical problems with our products, please contact the SMAServiceLine. The following data is required in order to provide you with the necessary assistance:

• Device type

• Serial number

• Firmware version

• Event message

• Mounting location and mounting height

• Type and number of PV modules

• Optional equipment, e.g. communication products

• Use the name of the system in SunnyPortal (if available)

• Access data for SunnyPortal (if available)

• Special country-specific settings (if available)

• Operating mode of the multifunction relay

United States SMA Solar Technology

America LLC Rocklin, CA

Canada SMA Solar Technology

Canada Inc. Mississauga

México SMA Solar Technology

de México Mexico City

Toll free for USA and US Territories +1877-MY-SMATech (+1877-697-6283)

International: +1916625-0870

Toll free for Canada / Sans frais pour le Canada : +1877-MY-SMATech (+1877-697-6283)

Internacional: +1 916 625-0870

User ManualSBxx-US-1XP-41-BA-en-1174

Page 75

Page 76

www.SMA-Solar.com

SMA SUNNY BOY User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Legal Provisions

Table of Contents

1 Information on this Document

1.1 Validity

1.2 Target Group

1.3 Content and Structure of this Document

1.4 Levels of Warning Messages

1.5 Symbols in the Document

1.6 Typographies in the Document

1.7 Designation in the document

1.8 Additional Information

2 Safety

2.1 Intended Use

2.2 IMPORTANT SAFETY INSTRUCTIONS

3.1 Product Description

3 Product Overview

3.2 Symbols on the Product

3.3 Interfaces and Functions

3.4 LED Signals

3.5 Display messages

4 Operation

4.1 Activating and Operating the Display

4.2 Establishing a connection to the user interface

4.2.1 Establishing a Direct Connection via Ethernet

4.2.2 Establishing a direct connection via WLAN

4.2.3 Establishing a Connection via Ethernet in the local network

4.2.4 Establishing a Connection via WLAN in the Local Network

4.3 Logging In and Out of the User Interface

4.4 Start Page Design of the User Interface

4.5 Displaying and Downloading the Stored Data

4.6 Activating the Smart Inverter Screen

4.7 Starting the Installation Assistant

4.8 Secure power supply operation

4.8.1 Enable secure power supply operation

4.8.2 Disable secure power supply operation

4.9 Activate WPS Function

4.10 Switching WLAN On and Off

4.11 Switching the Dynamic Power Display Off

4.12 Changing the Password

4.13 Changing Operating Parameters

4.14 Configuring the Country Data Set

4.15 Configuring the Rapid Shutdown Function

4.16 Changing the Operating Mode of the Multifunction Relay

4.18 Setting SMA ShadeFix

4.19 Deactivating the Arc-Fault Circuit Interrupter (AFCI)

4.20 Saving the Configuration in a File

4.21 Adopting a Configuration from a File

4.22 Updating the Firmware

5 Cleaning the Inverter

6 Troubleshooting

6.1 Forgotten Password

6.2 Event Messages

6.3 Checking the PV System for Ground Faults

7 Accessories

8 Compliance Information

9 Contact
