CODE NUMBER
3346087
DESCRIPTION
Polished Chrome Finish, Sloan® Deck-Mounted Foam Soap Dispenser.
DETAILS
Finish: Polished Chrome (CP)
Power Type: Battery
Height: 197/1000" (5mm)
Width: 79/1000" (2mm)
Depth: 41/200" (5mm)
Sensor Type: IR
SLOAN® SOAP DISPENSER
ESD-500-CP
FEATURES
Sensor Activated, Electronic, Chrome Plated Die Cast Body, Hand
Washing Foam Soap Dispenser with the following features:
Modular one-piece construction easily attaches to deck surface
All electronics in spout are sealed
Designed for drip free foam dispensing operation
Motor Assembly suspended under counter connected to soap
dispenser spout
Motor Assembly rotates 360 degrees for easy installation
Battery life of 45,000 activations
1,500 dispenses per foam soap bottle
Ships with 2 bottles of non-scented, non-colored foam soap
(1500ml per bottle)
Additional foam soap can be purchased through Sloan (ESD-321) or
GOJO distribution (8565-02-N6300GN)
Ships with battery pack (4 "D" Alkaline batteries included)
Sensor range – nominal 5”
GFI outlet suggested per code
120V/15 Amp
Optional AC adaptor can be purchased separately (part number
0346090)
Select the ESD-501 to combine ESD-500 soap dispenser, 2 bottles
of soap and the EFX.250.500.0000 faucet
COMPLIANCES & CERTIFICATIONS
(ADA Compliant)
RECOMMENDED SPECIFICATION
Sloan Foam Soap Dispenser model number ESD-500. Chrome
Plated Dispenser. Supplied with 2 bottles of 1500ml soap.
DOWNLOADS
ESD Series Installation Instructions
ESD-500/600/700/800/1500/2000/2100 Repair and
Maintenance Guide
Additional Downloads
NOTES
All information contained within this document subject to
change without notice.
SOAP REFILLS
ESD-321 (1500mL)
VIDEOS
PVD Special Finishes
Sloan 10500 Seymour Ave, Franklin Park, IL 60131
Phone: 800.982.5839 • Fax: 800.447.8329 • sloan.com
Code 3346087 • Downloaded 06/09/20 • Revised 05/15/20 • View Latest Version
Page 1 of 2
Page 2
ROUGH-IN
SLOAN® SOAP DISPENSER
ESD-500-CP
MATCHING FAUCETS
This soap dispenser is compatible with BASYS® faucets.
