Description
Act-O-Matic®, Chrome Plated, Self-Cleaning Shower Head with
Thumb Screw Volume Control.
Flow Rate
2.5 gpm/9.4 Lpm maximum
Specifications
Act-O-Matic, Chrome Plated Shower Head with the following
features:
• Spring loaded, Self-Cleaning Spray Disk to prevent particle
clogging
• “Cone-within-a-cone” Spray Pattern for total body coverage
• Pressure Compensating 2.5 gpm/9.4 Lpm Flow Control
• All Brass Construction
• Universal Ball Joint with Thumb Screw Volume Control
• 1/2” I.P.S. Inlet
Shower Head shall be in conformance to all requirements of
ANSI/ASME Standard A112.18.1M, CSA B-125 and the United
States Federal Energy Policy Act.
Variations
YC Spray Arm with Set Screw Flange
Program Configurations
PB Polished Brass
LG Luster Gold (24k)
AB Antique Brass
SF Satin Finish
NOTE: Shower Head available with
1/2” Whitworth Thread (please specify).
See Accessories Section of the Sloan catalog for details
on these and other Shower Head variations.
Act-O-Matic
®
Shower Head
This space for Architect/Engineer approval
The information contained in this document is subject to change without notice.
Copyright © 2006 SLV6664 Printed in the U.S.A.
10500 Seymour Avenue •Franklin Park, Illinois, 60131-1259
Phone 800-671-6970 • Fax 847-671-6944
A SLOAN VALVE COMPANY
AC-11
