Congratulations on purchasing your SLENDE RTONE SYSTEM-ARMS. Please
read your user manual fully before using this product.

This revolutionary new concept allows a single hand-held controller
to be attached to a range of garments which tone different areas of
the body, saving you money on your next

SLENDERTONE purchase.

SLENDERTONE SYSTEM-ARMS uses clinically proven EMS technology to

exercise the triceps muscles in your upper arm. A signal is sent to
the muscles and as that signal strength increases, the muscles
contract. The

SLENDERTONE SYSTEM-ARMS product should be used while

relaxing in the comfort of your own home.

Use your

SLENDERTONE SYSTEM-ARMS product 5 times a week for 10-20

mins and in just 4 weeks, you can expect to see these results:

• Toned & defined arms

• Feel confident in sleeveless tops and dresses

For best results we recommend that you use your

SLENDERTONE SYSTEM-

ARMS in conjunction with a normal, healthy diet and exercise.

SLENDERTONE SYSTEM is an electronic muscle stimulator intended for the

enhancement of performance of normal muscle. It may also be used,
with medical supervision, for the rehabilitation of muscle which has
become deficient due to disuse or injury.

If you have any difficulty setting up your unit or have any other
questions or concerns about your

SLENDERTONE SYSTEM-ARMS product

call the SLENDERTONE Careline on :

UK: 0845 070 7777
Rep. of Ireland: 1890 9223388
International: [phone]
Email: [email protected]
slendertone.com/system

Please read these precautions before using your

SLENDERTONE SYSTEM-ARMS unit:

• You should only use this product while in a relaxed, seated position, with
your arms bent slightly and resting in your lap.

• Do not straighten your arms during the session, as this can lead to an
ineffective session and may cause some discomfort.

• Never use

SLENDERTONE SYSTEM-ARMS while invloved in any activity which

includes using your arms or hands.

• Your arms are likely to move involuntarily during a session.

• Keep your unit in your hands during each session.

• Do not fasten the straps too tightly around your arms.

• If the garment leads are damaged or exposed, they should be replaced
immediately.

• Maximum use of a

SLENDERTONE SYSTEM product is one session per day per

body area.

You should find the following parts inside your pack.

1. Arm garments ( x 2 ):
The arm garments have been ergonomically designed and are fastened
around your upper arm using the straps.

2. Straps ( x 4 ):
These are used to hold the garments in place. They will fit an arm circumference
range between 22-37cm.

3. Unit Connector:
This connects the unit to the garments. Make sure the unit and garments are
fully connected before use.

IMPORTANT: Do not disconnect the unit from the garments until it has been

switched off.

4. Pack of four adhesive pads.
These adhesive pads are placed onto the garments before use. When you
wrap the garments around your arms, these pads must be in contact with
your skin so that signals can be sent to your muscles.

5. Instruction Literature:
This is a detailed guide to using your

SLENDERTONE SYSTEM-ARMS and an additional

quick start guide to help get you started.

6.

SLENDERTONE Pouch:

Use this pouch to store your SLENDERTONE SYSTEM-ARMS between toning sessions.

introducing your slendertone system-arms

1

2

3

4

5

6

English

welcome

precautions

System Arms IM:Layout 1 28/10/2008 11:33 Page 4

System Arms IM:Layout 1 28/10/2008 11:34 Page 6

1. On/Off Button ( )

unit display

Press and hold this button for 2 seconds to
turn your unit on or off. You may also pause
the exercise by briefly pressing this button.

. Increase Toning Intensity ( )

2
Press and hold these buttons to increase
the intensity of the exercise. The right-hand

1.

button controls the garment on your right
arm. The left-hand button controls the
garment on your left arm.

2.

how does muscle stimulation technology work?unit controls

SLENDERTONE SYSTEM-ARMS uses electrical muscle stimulation (EMS) technology.

This technology has been used in hospitals and by physiotherapists for over
50 years. Here is a summary of how EMS technology works.

English

4.

. Decrease Toning Intensity ( )

3
Press and hold these buttons to decrease

5.

the intensity of the signal to either arm.

. Programme Button ( P )

4
Press this button to select the toning programme you
wish to use. There are 3 programmes, which are
explained later in this manual (page 8).

. Information Button ( i )

5
Press this button to see your training information, such as the maximum
intensity for your current or last session and the number of sessions you
have completed.

unit display

Toning intensity from the left arm garment.
Toning intensity from the right arm garment.
Counts down the time left in the current session. Also displays error

messages (see page 9).
Appears when the exercise has been paused.
Indicates that the sound is off.
Keylock is active - you cannot change the intensity levels or the

program accidentally.
This symbol indicates a poor contact between the unit and garments

or between the pads and the skin (see page 11 for more details).
Shows the battery power remaining.
Number of sessions completed.
Shows the programme currently running (1 - 3).
This symbol appears during each contraction phase.
Maximum intensity for the current/ last session.

3.

Signals are sent between the pads.

The signals switch on the nerves

which control the triceps muscles.

Step 1

As the signal strength increases, the

nerves, in turn, cause your muscles

to contract and relax rhythmically.

Step 2

setting up your slendertone system-arms

Step 1 - Charge the battery. Insert your charger into a
socket and then connect it to your unit (Fig. a). It’ll take
approximately 2-3 hours to fully charge the battery.
Your unit is fully charged when all three sections of the
battery icon are full. The battery icon will flash when the
battery is low and needs to be recharged.

NOTE: Do not leave your unit connected to the charger

when the battery is fully charged.

Step 2 - Connect the unit to the garments. The unit and
garments must be connected properly for your

SYSTEM-ARMS to work. ‘Click’ the unit connector into the

SLENDERTONE

garment connector as shown in Fig. b.

tep 3 - Place the pads on the garments. Place the

S
garments so that the four silver studs are facing you.
Remove the adhesive pads from their pack. You’ll notice
that one side of each pad has a grid pattern on it while
the other side is plain black.

i) Remove the covers from the patterned side of the four

(
pads (Fig. c).

ii) Place the patterned side of the pads over the silver

(
studs within the white squares (Fig. d).

IMPORTANT:

Before you progress, make sure that all of the silver studs are completely
covered by the pads. Press the edges of each pad firmly onto the material
before use.

Fig. a

Fig. b

Fig. c

Fig. d

54

System Arms IM:Layout 1 28/10/2008 11:34 Page 8

Step 4 - Remove the covers from the black side of all

Fig. a
four pads (Fig. a). Do not throw these covers away as
you will need to put them back onto the pads at the
end of your session.

NOTE: You should only use SLENDERTONE pads with your
SLENDERTONE SYSTEM-ARMS unit.

tep 5 - Positioning the garments.

S
(i) Attach two straps to one side of each garment (fig. b).

Fig. b

(ii) Take the garment which is connected to the GOLD
lead and place the point of your RIGHT elbow directly
onto the connector symbol ( ) on the inside of that
garment. Then press the garment onto the back of
your arm (Fig. c). Fasten that garment firmly in place
using the straps (Fig. d).

iii) Repeat step (ii), placing the garment connected to

(

Fig. c

the BLACK lead onto your LEFT arm.

IMPORTANT:

You may need to adjust the position of the garments
slightly until you find the most comfortabel position.

Fig. d
However, the positioning will become much easier
after a few sessions.

NOTE:

For the best results, we recommend that you do five
training sessions per week. You should, however, only
do one session per day, as this allows your muscles to
recuperate.

caring for your garments

Your garments may cleaned using a lightly dampened sponge, but you must
first remove the pads. Always follow the cleaning instructions when cleaning
the garments.

Never machine-wash or hand-wash your garments. Always clean
them using a lightly dampened cloth or sponge.

Do not use bleach when washing the garments.

Do not dry clean your garments.

your first toning session

Muscle toning can be an unusual sensation, but a
pleasant one. It may tickle to begin with. We recommend
that you use the product while seated until you become
accustomed to the sensation. This progresses to a
smooth muscle contraction as the toning intensity
increases. To get started, follow these simple steps:

tep 1: Press and hold the on/off button ( ) for two

S
seconds to switch your unit on (Fig. a).

tep 2: Select the program you wish to use by pressing

S
the program button ( P

- Fig. b). Then, to start the program,
press and hold the increase intensity buttons ( - Fig. c)
until you feel your muscles contracting. Always choose an
intensity level at which you feel a strong but comfortable
contraction. This will vary from person to person. The
increasing intensity level is displayed on the screen.

tep 3: Continue increasing the intensity throughout the

S
session if possible. You will feel the muscle contractions
getting stronger as the intensity increases. Remember the harder you work
your muscles the better the results you will see, but always reduce the
intensity if you feel any discomfort. Your unit’s intensity range is 0-99.

PAUSING A SESSION

If you wish to pause a session before it is finished, simply press the on/off
button briefly. The display will show that the unit is paused ( ). To resume
the session, briefly press the on/off button again. The display will return to
its normal mode.

tep 4: SESSION OVER

S
At the end of the training session your SLENDERTONE SYSTEM-ARMS will stop
automatically. However, you may switch off your unit at any time during a
session by pressing and holding the on/off button for two seconds. You
should see the display turn off.

tep 5: Remove the garments and put the covers back on the black side of

S
the pads. Store everything in the pouch until your next session.

NOTE: Do not disconnect the unit from the garments without first switching

the unit off, as this may result in an error on your display.

Well done on completing your first training session!

Fig. a

Fig. b

Fig. c

English

Do not tumble dry your garments. Dry them on a flat surface. Do not
dry them over anything hot. (e.g. a radiator) as they contain plastic
parts. Ensure the garments are completely dry before using them
again.

The garments should never be ironed.

76

System Arms IM:Layout 1 28/10/2008 11:35 Page 10

getting results with your slendertone system-arms

1. Use the strongest training intensity you can - the harder you work your
muscles, the better the results you will see, but remember, stimulation
should never be uncomfortable.

. Use your SLENDERTONE SYSTEM-ARMS as part of a normal, healthy lifestyle.

2
Improve your diet and try to increase the amount of exercise you do. Other

SLENDERTONE SYSTEM garments are available to help tone and firm other areas

of your body.

3. Your SLENDERTONE SYSTEM-ARMS has 3 toning programmes which are listed in
the table below. The unit will automatically progress through each programme
adter a set number of sessions. The display shows the programme currently
selected.

Programme

Beginner

Intermediate

Advanced

You cannot change a programme during a session. First switch your unit off
and on again. Then select your programme using the programme button.

4

. To help you get the most from your unit, you should follow the 30 day
plan. To do this, use SLENDERTONE SYSTEM-ARMS 5 times a week for 4 weeks and
record the highest intensity levels in your diary (the diary is inside the back
cover). Each week you have two rest days. The diary below shows one person’s
plan, recorded during scientific testing over a 30-day period. The intensity
level will vary from person to person.

Try to increase your toning intensity regularly. But remember, do not over-exert
yourself. Any workout should be at a level comfortable for you.

Duration

10:00
15:00
20:00

T

raining Level

Light

Moderate

Strong

30-day plan

Week Day 1 Day 2 Day 3 Day 4 Day 5 Day 6 Day 7

1 (20 20) rest (25 25) rest (30 30) (40 40) (40 40)
2 rest (50 50) (55 55) rest (60 60) (65 65) (65 65)
3 rest (65 65) (70 70) rest (70 70) (70 70) (75 75)
4 rest (75 75) (75 75) rest (80 80) (80 80) (80 80)

Each box shows th
session.

Fill-in your diary every time you complete a toning session. Leave the diary
somewhere you will see it regularly to motivate you to reach your goal.

e highest toning intensity for either arm during each

additional unit functions

I

nformation Button ( i )
Press the information button any time during a session
to see the highest intensity level you have reached for
that session. Pressing the information button twice
shows you the total number of sessions you have
completed (Fig. a). While pressing the information
button three times identifies the product type you
are using.

ute Function ( )

M
If you want to switch off your unit’s sound effects,
press and hold the programme button for two seconds
(Fig. b). The mute function remains active indefinitely
unless manually changed. Deactivate the mute function
by again pressing the programme button for two
seconds

eylock Function ( )

K
If you find a comfortable exercise intensity, press and
hold the information button for two seconds to lock
that intensity (Fig. c). This function only remains
active during the session in which it is activated. If
you wish to increase the intensity further, deactivate
the keylock function by again pressing the information
button for two seconds.

rror Messages

E
In the unlikely event of your unit developing a problem,
“Err” will appear on your unit display (Fig. d). If this
occurs you should switch the unit off and then switch
it back on again. It should now operate properly. If the
problem persists, please call your local careline for
further assistance:

UK: 0845 070 7777
Rep. of Ireland: 1890 9223388
International: [phone]
Email: [email protected]

attery Power / Replacing the battery

B
The battery icon on the display will flash when the
battery is low and needs to be recharged. After a
period of time, you may find that your battery will
only power your unit for a limited number of sessions,
requiring you to charge the battery more frequently.
This is because rechargeable batteries have a limited
number of charge cycles and may eventually need to
be replaced.

Should you need to replace the rechargeable battery, remove the small
rubber plug from the back cover of your unit (Fig. e), unscrew the back cover
and remove it. Replace the existing battery pack with a new battery pack
(Fig. f) and replace the battery cover. You can purchase a new battery pack by
contacting the

SLENDERTONE Careline.

Fig. a

Fig. b

Fig. c

Fig. d

Fig. e

Fig. f

English

98

System Arms IM:Layout 1 28/10/2008 11:35 Page 12

frequently asked questions

The stimulation is uncomfortable. How can I improve this?

• Make sure the pads are positioned correctly and that they are pressed
firmly against your skin - see page 6. Switch off your unit and reposition the
garments if necessary.

• You can also smear a few drops of water on the black surface of the pads. This
can improve the comfort of the muscle stimulation, but be careful not to get
water on the unit. Ensure the unit is switched OFF before you do this!

• Ensure the metal studs are fully covered by the pads.

My skin is red after the exercise. Is this a problem?

• Some redness of the skin after a toning session is normal. It is partly due to
an increase in the blood flow under the skin and should fade after a while. You
may also experience some reddening of the skin due to the pressure of the
garments. This is the same as the pressure marks you can get from tight
clothing. You should not be concerned about this. It should fade soon after
you remove them.

• If the redness is excessive, you may have the toning intensity too high. This may
increase the reddening in sensitive skin. Try using a lower toning intensity for a
few days. If the problem persists, you should stop using the unit.

Will the product cause muscle soreness?

As with all exercise some muscle soreness can occur after using

SYSTEM-ARMS. This is normal and should go away after a while. Use a low toning

intensity for a few sessions if you are experiencing muscle soreness.

How do I know when to replace the pads?

• With time the pads pick up skin debris and may need to be replaced as this
makes the workout less effective and less comfortable.

• You may notice the signal is weakening even if the batteries are OK. This
usually indicates that the pads are wearing and will soon need replacing. You
can check this by first adjusting the garments to ensure correct positioning of
the pads. If the problem persists, try using the unit with a new battery pack. If
the signal is still weak or uncomfortable, you should order new pads.

• New pads can be purchased online at slendertone.com/system (check for
special offers) or from the careline.

Can I use

SLENDERTONE SYSTEM-ARMS to treat muscles weakened from lack of use

due to injury?

Yes. The unit may be used for the alleviation of or compensation for injury.
Consultation with your doctor or physiotherapist is required to establish a
rehabilitation programme with your

SLENDERTONE SYSTEM-ARMS, which would

safely provide improvement to the strength and tone of the triceps muscles.

Battery performance has degraded significantly.

After an extended period of time you may notice a degradation in the
performance of the battery in your unit. At this point you should purchase
a new rechargeable battery pack. New rechargeable battery packs can be
purchased through the

SLE NDERTON E Careline, or by visiting

slendertone.com/system.

SLENDE RTONE

quick guide to solving problems

roblem

P
No signal/ display is

blank

The display is on but
there is no signal

The battery symbol is
flashing

The symbol has
appeared on the
display*

Unpleasant feeling
beneath the pads

Contractions are weak
even with a high
intensity

“Err” appears on the
display

Possible Cause
The battery is low

The battery is low

The battery is low

The unit and garments
are not properly
connected

The covers are still on
the pads

The pads are worn

The pads are not
covering the studs

Poor pad contact with
the skin

The pads are worn

Pads are not covering
the metal studs

Too many consecutive
sessions

The pads are worn

The battery is low

Poor pad positioning

Pads are not covering
the studs

Error message

olution

S
Recharge the battery

Recharge the battery

Recharge the battery

Ensure the garments
and unit are properly
connected

Remove the covers from
the pads

Visit the website or
contact your local
retailer for new pads

Make sure the pads fully
cover the metal studs

Press the pads firmly
against the skin

Visit the website or
contact your local
retailer for new pads

Reposition the pads so
that the metal studs are
covered

You should just do one
session per day one any
single body area

Visit the website or
contact your local
retailer for new pads

Recharge the battery

See page 6 for correct
pad positioning

Reposition the pads so
that the metal studs are
covered

Switch the unit off and on
again. If the error persists
call the careline

English

* The symbol always appears in conjunction with the left/ right intensity
indicators. If the left indicator appears, there is a problem with the left-arm
garment, the right indicator acknowledges a problem with the right-arm
garment. If both indicators appear there is a problem with both garments.

1110

1312

Your SLENDERTONE product is suitable for use by all healthy adults. However,
as with other forms of exercise, some care is needed when using it, so
always follow the points below and read your user manual carefully before
use. Some of the points below are gender specific.

Please do not use if:

• You have an electronic implant (e.g. cardiac pacemaker or defibrillator) or
suffer from any other heart problem.

• You are pregnant.

• You suffer from cancer, epilepsy or are under medical supervision for
cognitive dysfunction.

• The unit is in close proximity (e.g. 1m) to shortwave or microwave therapy
equipment.

• You are connected to high-frequency surgical equipment.

• Wearing the device necessitates placement over areas at which
drugs/medicines are administered by injection (short term or long term) e.g.
hormone treatment.

Please get your doctor’s or physiotherapist’s permission before using your

SLENDERTONE product if:

• You have any serious illness or injury not mentioned in this guide.

• You have recently had an operation.

• You take insulin for diabetes.

• You want to use it on a young child.

• You suffer from muscle or joint problems.

• Using the device as part of a rehabilitation programme.

When applying the pads and garments, always remember to :

• Place the pads and garments ONLY as indicated in this manual.

• Avoid placing the pads or garments on the front or sides of the neck, across
or through the heart (i.e. one pad on the front of the chest and one on the
back), in the genital region or on the head. (Other toning units are available
for other areas of the body - details are available at slendertone.com/system
or from your local retailer)

• Avoid any recent scars, broken or inflamed skin, areas of infection or
susceptibility to acne, thrombosis or other vascular problems (e.g. varicose
veins), or any parts of the body where feeling is limited.

• Avoid areas of injury or restricted movement (e.g. fractures or sprains).

• Avoid placing the pads directly over metal implants.

Possible adverse reactions:

• A small number of isolated skin reactions have been reported by people
using muscle stimulation devices, including allergies, a prolonged reddening
of the skin and acne.

• On very rare occasions, first-time users of EMS have reported feeling light­headed or faint. We recommend that you use the product while seated until
you become accustomed to the sensation.

To reposition pads during a session:

• Always pause the programme currently running, unfasten the garments
and then refasten them once the position of the pads has been adjusted.

After strenuous exercise or exertion:

• Always use a lower toning intensity to avoid muscle fatigue.

Contact the careline if:

• Your unit is not working correctly. Do not use it in the meantime.

• You experience any irritation, skin reaction, hypersensitivity or other adverse
reaction. You should, however, note that some reddening of the skin can
appear under the garments during and for a short time after a session.

Note:

• An effective treatment should not cause undue discomfort.

Important:

• Keep your unit out of the reach of children.

• The studs and pads must not be connected to other objects.

• Do not use your unit at the same time as any other device which transfers
an electrical current into the body (e.g. another muscle stimulator).

• Cease using your unit if you are feeling light headed or faint. Consult your
doctor if this happens.

• Do not touch the pads or metal studs while the unit is switched on.

• Do not use while driving, operating machinery or cycling.

• For first time users, muscle stimulation can be an unusual sensation. We
recommend that you begin with low stimulation intensities to familiarise
yourself with the sensation before progressing to higher stimulation intensities.

• The arm garments are for use by one person only. Do not share your garments
with anyone else.

• Do not over exert yourself when using muscle stimulation. Any workout
should be at a level comfortable for you.

• Do not try to eat or drink anything while using

SLENDERTONE SYSTEM-ARMS.

• SLENDERTONE will not accept responsibility if the guidelines and instructions
supplied with this unit are not followed.

N.B. If you are in any doubt about using your

SLENDERTONE SYSTEM-ARMS for

any reason, please consult your doctor before use.

dos & don’ts

English

System Arms IM:Layout 1 28/10/2008 11:35 Page 14

System Arms IM:Layout 1 28/10/2008 11:35 Page 16

technical specifications

Caring for your unit

Your unit should not be allowed to get wet or be left in excessive sunlight. It
may be cleaned regularly using a soft cloth, lightly dampened in soapy
water. Do not allow the interior of your unit to become wet. Do not use
detergents, alcohol, spray aerosols or strong solvents on your unit.

Access to the interior of the unit is not required for maintenance purposes.

If your unit is damaged, you should not use it but should return it to
or your local distributor for replacement or repair. Repairs, service and
modifications may not be carried out by anyone other than qualified service
personnel authorised by

IMPORTANT: Under no circumstance should anything other than the correct

SLENDERTONE.

type of batteries – (rechargeable batteries 3.6V NiMH) be used with your
unit. These can be purchased from the

SLENDERTONE careline.

Disposing of the pads and batteries

Used pads and batteries must never be disposed of in a fire but in accordance
with your country’s national laws governing the disposal of such items.

NOTE: The signal gradually increases to a peak intensity level at the start of

the contraction phase (i.e. ramp up) and gradually decreases to nothing at
the start of the relaxation phase (i.e. ramp down). When the symbol is
flashing, the stimulus is significantly reduced.

NOTE: In accordance with the laws within the member state, safety testing on

the device should be carried out every two years.

NOTE: In compliance with German law, product safety testing must be conducted

every two years by an authorised test service.

Accessories:

You can purchase all

SLENDERTONE accessories at slendertone.com/system.

When ordering new pads, only use those carrying the SLENDERTONE brand. Any
others may not be compatible with your unit and could degrade the minimum
safety levels.

Adhesive Pads (each pack contains):

• 4 small adhesive pads Type 715

SLENDERTONE SYSTEM Arm Garments (E:60)
SLENDERTONE SYSTEM Female Belt (E:10)
SLENDERTONE SYSTEM Male Belt (X:10)
SLENDERTONE SYSTEM Shorts (E:20)
SLENDERTONE Belt Extension

Battery Pack (3.6V, NiMH)
Battery Charger (2504-0303)

SLENDERTONE

Description of your unit’s symbols:

There are a number of technical markings on your unit. These can be explained
as follows:

The unit and garments are manufactured for Bio-Medical Research Ltd, Parkmore
Business Park West, Galway, Ireland.

The unit requires 1 x 3.6 volt (NiMH) DC battery pack DC is indicated by the
symbol:

The Output Frequency indicates the number of pulses per second transmitted by
the unit. This is measured in hertz, which is indicated by “Hz”.

Output (RMSA) means the maximum output root mean square current for each
channel.

Output (RMSV) means the maximum output root mean square voltage for each
channel.

This symbol means “Attention, consult the accompanying documents”.

!

This symbol means type BF equipment.

This symbol on your unit is to indicate conformity to the requirements
of the Medical Device Directive (93/ 42/EEC). 0366 is the number of the

0366

notified body (VDE).

SN stands for ‘serial number’. Inside the box, on the back of the unit is the serial
number specific to this unit. The letter preceding the number indicates the year
of manufacture, where “L” denotes 2006, “M” denotes 2007 etc.

The garments’ batch number is represented on their packaging, by the number
corresponding with the LOT symbol.

Rated Outputs – Voltage/Currents: E:60

Parameter 500Ω 1KΩ 1K5Ω
Output RMSV 6.4V 12.7V 12.7V
Output RMSA 12.7mA 12.7mA 8.5mA
Output Frequency 50Hz 50Hz 50-Hz
DC Component: Approx. 0 C 0 C 0 C
Positive Pulse Width: 175-200µs 175-200µs 175-200µs
Negative Pulse Width: 175-200µs 175-200µs 175-200µs
Interphase Interval: 100 µs 100 µs 100 µs

Attention:

This unit can deliver currents in excess of 2mA/cm2if used with incorrect electrodes.

At the end of the product lifecycle, do not throw this product into the normal
household garbage, but bring it to a collection point for the recycling of
electronic equipment.

English

Product Type: 390

Intended use: Muscle stimulator

Waveform: Symmetrical bi-phasic square waveform when measured into a

resistive load.

Environmental Specifications:

perating: Temperature Range: 0 - 35°C (32 - 95°F)

O

Humidity: 20 - 65 % RH

Storage: Temperature Range: 0 - 35°C (32 - 95°F)

Humidity: 20 - 85 % RH

Some product materials can be re-used if you bring them to a recycling
point. By re-using some parts or raw materials from used products you
make an important contribution to the protection of the environment.
Please contact your local authorities if you need more information about
collection points in your area.

Waste Electrical and Electronic Equipment can have potentially harmful
effects on the environment. Incorrect disposal can cause harmful toxins to
build up in the air, water and soil and can be harmful to human health.

Garment Materials:

Outer material:
laminated to 100% polyurethane; Binding: 100% Nylon; Hook & Loop: 100%
Nylon; Foam: EVA; Elasticated Straps: 100% Nylon.

80% Nylon, 20% polyester; Inner Material: 100% Polyester

1514
