SKY WING Communication Electronics SK S15 User Manual

S15 Bluetooth Speaker

User manual

S15 is a stereo Bluetooth Speaker with single diver, Bluetooth version V4.1+EDR,
Support HFP v1.6, A2DP v1.2, AVRCP v1.4, Output power reach to 3W, support AUX
input.

■ Button function.

Bluetooth mode：

Short press: previous song.
Long press: volume down

Bluetooth mode:

Short press: next song
Long press: volume up

Bluetooth mode:

Short press to play / pause /answer / reject/cancel calls.

Double click: redial the last called number

Long press for 2 seconds: reject calls / Audio switch from phone to speakers.

Long press for 2 seconds then release: voice-activated dialing (The function will not work if not

release the button after 2 seconds).

Slide the button to “AUX” side to get into AUX mode, Slide the button to
“Bluetooth”side to get into Bluetooth mode.

Remark:

1. The microphone mute function operation: long press“ ”button

and“ ”button simultaneously for 2 seconds when talking through the speaker.

2. Those buttons does not work in AUX mode

■ Speaker buttons and interface instruction:
