Skywalker STEC12B, STEC12R, STEC12G, STEC12P User Manual
1
WARNING
Read all precautions and instructions
in this manual before using this
equipment. Save this manual for
future reference. Maximum user
weight 200 lbs
IMPORTANT
Trampoline and Enclosures are
susceptible to winds. Be sure to secure
your trampoline and enclosure.
Wind Damage is not covered in the
warranty of your trampoline.
User’sManual
Model
STEC12B /STEC12R /STEC12G/STEC12P
CAUTION: Adult Assembly
Required
2
Model
STEC12B /STEC12R /STEC12G /STEC12P
A serial decal is found on one of the trampoline legs. Model number decal tag is located on the jumping mat.
CONTENTS
Important Precautions..........................................................3
Warning Label Placement....................................................4
Before You Begin.................................................................4
Trampoline Safety Information............................................5
Enclosure Safety Information...............................................6
Methods of Accident Prevention..........................................7
Important Warnings..............................................................8
Use and Instructional Material.............................................9
Instructional Program and Model Lessons..........................10-11
Part Identification Chart.......................................................12
Exploded Drawing and Parts List........................................13-14
Ordering Replacement Parts................................................14
Assembly............................................................................15-23
Care and Maintenance..........................................................24
Limited Warranty..................................................................25
QUESTIONS?
If you have questions after reading this manual, please call our toll-free Customer Care Hot Line. The trained
technicians on our Customer Care Hot Line will provide immediate assistance.
Customer Care Hot Line: 1-866-603-JUMP (5867) Monday--Friday, 8 a.m. --5 p.m. Mountain Time
REPLACEMENT PARTS
www.skywalkertrampolines.com
WARNING
Read the assembly, installation, care, maintenance, and use instructions in this manual prior to assembling and using this trampoline. Save this manual for future reference.
High Wind: The trampoline can be blown around by high winds. If you expect high winds, the trampoline should be
moved to a sheltered location, taken apart, or tied down to the ground with ropes and stakes (NOT INCLUDED). At least
four ropes and four stakes should be used. The top of the stakes should be at ground level so they will not create a tripping
hazard. In addition, the top of the stakes should be covered, if necessary, so that users will not be injured by falling on the
stakes. The manufacturer’s warranty does not cover any type of wind damage.
Do not stand near the trampoline in windy or gusty conditions. A trampoline can become airborne when exposed to sustained
wind or gusting wind conditions. This can result in serious injury, parlysis, or death, as well as property damage. To reduce
these risks, disassemble the trampoline and enclosure and store them until weather conditions improve.
Anchoring a trampoline frame may prevent the trampoline from moving as a result of the wind, but even anchored trampolines can become airborne or damaged. Consult a qualified contractor to determine what type of anchor works best in your
location.
3
11.
12.
13.
14.
15.
USE INSTRUCTIONS
To reduce the risk of serious injury, read and follow all of the warnings, precautions, and instructions in this manual before you use the trampoline enclosure. Warnings and instructions for care, maintenance, and use of
this trampoline and enclosure are included to promote safe enjoyable use of this equipment.
WARNING
It is the responsibility of the owner and supervisors of the
trampoline and enclosure to make sure all users obey the
safety instructions given in this manual. The trampoline should
only be used with mature, knowledgeable supervision.
Secure the trampoline and trampoline enclosure against
unauthorized and unsupervised use. If you use a ladder to get
on and off the trampoline, be sure to remove it when the
trampoline and enclosure are not being used.
Be sure there is enough clear space above the trampoline and
enclosure before use. It is best to have at least 24 feet(7.3
meters) of clear space above the ground. This space must be
clear of wires, tree limbs, and any other possible hazards.
Lateral (sideways) clearance is very important. Do not place
the trampoline and enclosure near walls, buildings, fences,
sidewalks, and other play areas. Always keep a clear space on
all sides of the trampoline and enclosure.
Remove any objects that could interfere with the performer.
Maintain a clear area around and under the trampoline.
Be sure the trampoline and enclosure are on a level surface
before use.
Always inspect the trampoline and enclosure before each
use.Make sure that the frame, padding, netting, enclosure
tubes, and foam sleeves are correctly and securely positioned.
Replace any worn, defective, or missing parts. (Jumpers may
be hurt if the trampoline and enclosure are used when they are
in poor condition.)
Bounce only when the surface of the mat(bed) is dry. There
should be very little or no wind or air movement. The trampoline and enclosure must not be used in gusty or severe winds.
The trampoline and enclosure frames are made of metal. They
are not grounded and will conduct electricity. For this reason,
an electrocution hazard exists. No lights, electric heaters,
extension cords, or household electrical appliances are to be
permitted on the trampoline or in enclosure at any time.
Use the trampoline and enclosure in an area with lots of light.
If the trampoline and enclosure are indoors or in shady areas,
you may need to us artificial (electical) lighting in the area.
During the winter months, the trampoline soft materials will
need to be removed and stored in a dry place. If left up in the
winter months, it may cause damage to the springs, jump mat,
spring pad, and enclosure. The warranty will be void.
This trampoline and enclosure is made for users who weigh
less than 200 pounds.
Trampolines over 20 in. (51 cm) tall are not recommended for
use by children under 6 years of age.
The trampoline enclosure is to be used only with the size of
trampoline for which the enclosure is designed.
Misuse and abuse of the trampoline enclosure is dangerous
and can cause serious injury.
Do not attach anything to the enclosure barrier that is not a
manufacturer-approved acessory or part of the enclosure
system.
Please remove any jewelry before jumping begins. Jewelry may
get caught in the enclosure netting.
Wear clothing free of drawstrings, hooks, loops, or anything
that could be caught while using the trampoline/enclosure and
result in entaglement and strangulation, or both.
DO NOT let more than one person inside the trampoline
enclosure at the same time. Two or more people jumping at the
same time can cause serious injury.
DO NOT jump on the trampoline while you have or are holding
any objects, especially something sharp or breakable.
DO NOT use the trampoline and enclosure if you have been
using alcohol or drugs.
DO NOT attempt or allow summersaults (flips) on the trampoline. Landing on the head or neck can cause serious injury,
paralysis, or death, even when landing in the middle of the
jumping mat.
Always climb on to and off of the trampoline. It is a dangerous
practice to jump from the trampoline to the floor or ground
when dismounting, or to jump onto the trampoline when
mounting.
DO NOT use the trampoline as a springboard to other
objects.Enter and exit the enclosure only at the enclosure door
or barrier made for that purpose.
DO NOT attempt to crawl under, jump over, intentionally
bounce off of, hang from, climb on, kick, or cut the barrier
netting.
While keeping head erect, focus eyes on the trampoline toward
the perimeter. This will help control bounce.
Stop bouncing by flexing knees as feet come in contact with the
trampoline bed. Learn this skill before attempting others.
Avoid bouncing too high. Stay low until bounce control and
repeated landings in the center of the trampoline can be accomplished. Control is more important than height.
Avoid bouncing when tired. Keep turns short.
Learn fundamental bounces and body positions thoroughly
before trying more advanced skills. A variety of trampoline
activities can be carried out performing the basic fundamentals
in various series and combinations, performing one fundamental
after another, with feet bounces between them.
For additional information concerning the trampoline equipment contact the manufacturer. For information concerning skill
training, contact a certified trampoline instructor.
4
WARNING LABEL PLACEMENT
Trampoline Safety Instructions
WARNING
Do not land on head or neck.
Do not attempt or allow somersaults.
Landing on your head or neck can cause
serious injury, paralysis, or death, even
when landing in the middle of th mat.
Use trampoline only with mature,
knowledgeable supervision.
Only one person at a time on the trampoline.
Do not allow more than one person on the
trampoline. Use by more than one person at
the same time increases the chance of injury.
Use trampoline only with mature,
knowledgeable supervision. This trampoline
is not recommended for children under 6
years of age.
Do not land on head or neck.
Do land on head or neck. Paralysis
or death can result, even if you land
in the middle of the trampoline mat
(bed). Do not do somersaults (flips).
Use trampoline enclosure only with
mature, knowledgeable supervision.
Enforce all safety rules and be
familiar with the information in the
User’s manual to help users in
following enclosure instructions and
trampolines safety.
Only one person at a time on the
trampoline. Multiple jumpers
increases the chance of loss of
control and this can result in broken
head, back or leg. Users may
become entangled in or strangled by
loose cards or gaps between
trampoline and enclosure.
For the Supervisor.
Read the instructions before using the trampoline. Enforce all of the safety rules and be familiar with the information in the User’s Manual
to help new users learn basic jumps and all users to follow trampoline safety.
All trampoline users must have mature, knowledgeable supervision, regardless of the skill or age of the jumper.
This trampoline is not recommended for use by children under 6 years of age.
Inspect the trampoline before using. Keep frame pad in place. A worn or damaged mat (bed), spring, or frame piece should be replaced
immediately.
Keep objects away that could interfere with the jumper.
Secure thet rampoline against unauthorized and unsupervised use.
Do not use when trampoline is wet or in a windy condition.
For the Jumper:
Do not use the trampoline when under the influence of drugs or alcohol.
Avoid bouncing when tired.
Jumping:
Learn the basic jumps and body positions very well before trying more difficult stunts. Study the User’s Manual to learn how to do basic
jumps.
Stop your bounce by flexing your knees as your feet come in contact witht the trampoline mat (bed).
Avoid jumping too high or for too long. Always control your jump. A controlled jump is one where the take of and land spots are the same.
Bounce in the center of the trampoline. Focus eyes on trampoline toward the perimeter mat. Failure to do so may result in a loss of balance
and control.
Take turns jumping one at a time, and always have someone watch you.
Getting on and off:
Climb on to and off the trampoline. Do not jump on or off. Do not use the trampoline as a springboard to other objects.
For further equipment information contact Skywalker. For skill training information, contact a trainer certification organization.
ATTACH TO TRAMPOLINE
For the Supervisor.
Use trampoline enclosure only with mature, knowledgeable supervision. Enforce all safety rules and be familiar with the
information in the users manual to help users in following trampoline enclosure instructions and trampoline safety.
This trampoline enclosure system is not recommended for use by children under 6 years of age.
Do not exceed the weight limit recommended by the manufacturer.
Use only when the trampoline mat (bed) is clean and dry. Inspect the trampoline and enclosure prior to each use and replace
any worn or damaged parts.
Use only when enclosure barrier has no holes, pole clamps are tightly secured to the poles, and the support (frame) and the
barrier is properly suspended.
For the Jumper:
Do not use the trampoline when under the influence of drugs or alcohol.
Jumping:
Avoid jumping too high for too long. Always control your jump. Do not try to jump over the barrier.
Do not intentionally rebound of the barrier. Do not hang from, kick, cut or climb on the barrier.
Wear clothing free of drawstrings, hooks, loops, or anything that could get caught while
using the trampoline/enclosure and result in entaglement or stranglement or both.
Getting on and off:
Climb on to and off the trampoline at the enclosure door or barrier opening. Do not jump on or off. Do not crawl under the
barrier. Do not use the trampoline as a springboard to other objects.
Do not jump from other objects, buildings, or surfaces, onto the trampoline, or into or over the trampoline enclosure.
For further equipment information contact SKWYALKER TRAMPOLINES. For skill training information, contact a trainer
certification organization.
ATTACH TO NETTING AT DOOR
Do not land on head or neck.
Do not attempt or allow somersaults. Landing on your head or
neck can cause serious injury, paralysis, or death, even when
landing in the middle of th mat.
Use trampoline only with mature, knowledgeable supervision.
Only one person at a time on the trampoline.
Do not allow more than one person on the trampoline.
Use by more than one person at the same time increases the
chance of injury.
Use trampoline only with mature, knowledgeable supervision.
This trampoline is not recommended for children under 6 years
of age.
WARNING
WARNING
Do not attempt or allow
somersaults.
(Flips)
Do not land on head or neck.
Landing on your head or neck can
cause serious injury, paralysis, or
death, even when landing in the middle
of th mat.
Use trampoline only with mature,
knowledgeable supervision.
Do not allow more than one
person on the trampoline.
Multiple jumpers increase the chance
of loss of control, collision and falling
off. This can result in broken head,
neck, back, or legs.
Use Trampoline only with mature,
knowledgeable supervision.
This trampoline is not recommended
ofor children under 6 years of age.
Read all of the instructions before
using this trampoline.
Inspect before using and replace any
worn, defective or missing parts.
The labels shown on this page have
been attached to the trampoline in
the indicated locations. The Safety
Instructions placard will need to be
attached by the owner (see step 14).
If one of the labels or the placard is
missing or illegible, call our
Customer Care Hot Line toll-free at
1-866-603-JUMP (5867), Monday
through Friday, 8 a.m. until 5 p.m.
Mountain Time, to order a free
replacement label or placard.
Specific Use Limitations HIGH WIND
It is possible for the trampoline and enclosure to be blown about by high winds. If you expect high winds, move the
trampoline and enclosure to a sheltered location. Disassemble (take down) the enclosure netting. Tie the trampoline frame
down to the ground using ropes and stakes (not included). The only sure method to protect your trampoline and the
surrounding environment during high winds is to completely disassemble the unit and store indoors.
BEFORE YOU BEGIN
Thank you for choosing your Skywaker Trampolines brand trampoline. Skywalker Trampolines round trampolines are
designed and crafted to provide many years of fun and fitness. This trampoline comes equipped with warning and instructions for the assembly, care, maintenance, and use of the trampoline. This information must be read by all trampoline
supervisior and users before any person is allowed to jump on the trampoline.
If you have questions after reading this manual, please call our toll-free Customer Care Hot Line at
1-866-603-JUMP(5867), Monday through Friday, 8 a.m. until 5 p.m. Mountain Time (excluding holidays). To help us
assist you please mention the model and name of the trampoline when calling. (see the inside cover of this manual.))
The placard shown at the right was sewn to the
trampoline enclosure netting.
Note: The labels and placard shown are not
actual size.
5
TRAMPOLINE SAFETY INFORMATION
In trampoline use, as in all active recreational sports, participants can be injured. However, there are steps that can be
taken to reduce risk of injury. In this section, primary accident patterns are identified and the responsibilities of
supervisors and jumpers in accident prevention are described.
ACCIDENT CLASSIFICATION
Somersaults(flips): Landing on your head or neck, even in the middle of the trampoline mat, increases the risk of a
broken back or neck, which can result in paralysis or death. Such events can occur when a jumper makes an error
trying to perform a forward or backward somersault(flip). Do not perform somersaults(flips) on this backyard trampoline.
Multiple Jumpers: More than one jumper at a time on the trampoline increases the chance of a jumper becoming
injured by losing control of his or her jump. Jumpers may collide with on another, fall off of the trampoline, fall onto
or through the springs, or land incorrectly on the mat. The jumper weighing the least is the jumper most likely to be
injured.
Mounting and Dismounting (Getting on and off): The trampoline mat is several feet above ground level. Jumping
from thet rampoline to the ground or any other surface may result in injury. Jumping onto the the trampoline from a
roof, deck, or other objects also prsents a risk of injury. Smaller children may need assistance getting onto or down
from the trampoline. Climb carefully onto and off of the trampoline. Do not step onto the springs or the fame pad. Do
not grasp the frame pad to pull yourself onto the trampoline.
Striking the Frame or the Springs: Injury may result from hitting the frame or falling through the springs while
jumping or getting onto or off of the trampoline. Stay in the center of the mat when jumping. Be sure to keep the
frame pad in place to cover the fame. The frame pad is not made or intended to suppor the weight of trampoline user.
Don ot step or jump directly on the frame pad.
Loss of Control: Jumpers who lose control of their jumps may land on the mat incorrectly, land on the frame or
springs, or fall off of the trampoline. A controlled jump is one where the landing is in the same spot as the takeoff.
Before learning a more difficult stunt, you should be able to do one over an over with control. Attempting a stunt
beyond present skill levels increases the chance of loss of control. To regain control and stop your jump bend your
knees sharply when you land.
Alcohol or Drug Use: The chance of injury increases when a jumper has consumed alcohol or taken drugs. These
substances impair a person’s reaction time, judgement, and phyiscal coordination.
Encountering Objects: Jumping on a trampoline while other people, pets, or objects are underneath it will increase the
chance of getting hurt. Jumping while holding or having an object on the trampoline, particularly one that is sharp or
breakable, will increase the chance of injury. Placing a trampoline too close to overhead electical wires, tree limbs, or
other objects can increase the chance of injury.
Poor Maintenance of The Trampoline: Jumpers may be injured if a trampoline is when it is in poor condition. A torn
mat, bent frame, broken spring, or missing frame pad, for example, should be replaced before anyone is allowed to
jump. Inspect the trampoline before each use.
Weather Conditions: A wet trampoline is too slippery for safe jumping. Gusty or high winds can cause jumpers to lose
control. To reduce the chance of injury, use the trampoline only when the weather is good.
Access: To prevent access to the trampoline by unsupervised smaller children, the optional access ladder should
always be taken away and stored in a safe place when the trampoline is not in use.
6
ENCLOSURE SAFETY INFORMATION
NEED FOR TRAMPOLINE ENCLOSURE SAFETYUSING THE ENCLOSURE SAFELY
A trampoline enclosure is a recreational product.
The information on this page and on pages 7-9 identify important safety precautions. The precautions are not all-inclusive, because an enclosure can be used in ways that this manual cannot cover completely.
To prevent pinches and cuts during enclosure use, a frame pad must be installed on the trampoline (See the trampoline
manufacturer’s instructions). The frame pad must be placed on the trampoline before the enclosure is erected. The
frame pad reduces the chance of injury from accidental contact with the springs and frame.Adult Supervision of
Children
USING THE ENCLOSURE SAFETY
Adult Supervision of Children
Children using a trampoline with a trampoline enclosure must be supervised by adults. Young children must be
supervised constantly. Adults must pay particular attention to:
• Things that children bring into the enclosure.
• Children’s activities inside the enclosure.
• Conditions inside the enclosure while children are using it.
• The way children enter and exit the enclosure.
Additional details of safety enclosure use are described below.
Electrocution Hazard Associated with the Metal Frame of the Trampoline and Enclosure
The trampoline and enclosure frames are made of galvanized steel. They are not grounded and will conduct electricity.
For this reason, an electrocution hazard exists. No lights, electric heaters, extension cords, or household electrical
appliances are to be permitted on the trampoline or in the enclosure at any time.
Hazards Associated with Entering and Leaving the Trampoline Enclosure
A trampoline enclosure installed on a trampoline is raised off the ground. The height of the enclosure increases the risk
of a fall when a jumper is entering or leaving the enclosure. Young children, especially, may have difficulty entering
and exiting the enclosure. To reduce the risk of falling, always help young children to get into and out of the enclosure.
Enter and exit the trampoline enclosure only through the door of the enclosure (the opening in the netting walls). The
trampoline mat (bed) and the netting walls of the enclosure are separate pieces. No jumper, especially young children,
should ever leave the enclosure by going out between the mat and the netting walls. Trying to get out this way creates
a risk of choking from being caught between the trampoline frame and the netting walls.
Darkness increases the chances of a fall when a jumper is entering or leaving the enclosure. Do not use the trampoline
unless there is plenty of lighting provided.
Hazards Associated with Animals, Sharp or Breakable Objects
To avoid damage to the trampoline enclosure and the trampoline, do not allow pets or other animals inside of the
enclosure. The claws and teeth of animals can damage the netting. Do not jump on the trampoline while holding or
wearing a sharp or breakable object.
7
METHODS OF ACCIDENT PREVENTION
The Supervisor's Role in Preventing Accidents
It is the responsibility of the supervisors of trampoline users to provide knowledgeable and mature supervision. They
need to know and enforce all of the rules and warnings printed in this manual to minimize the likelihood of accidents
and injuries. They also need to inform users of these rules. During periods of time when supervision is unavailable or
inadequate, this may require that the trampoline is taken down, placed in a secure area, or otherwise secured against
unauthorized use. Another option that may be considered is covering the trampoline with a heavy tarp that can be
secured with locks and chains. It is the responsibility of the supervisor to make sure that the placard with TRAMPOLINE SAFETY INSTRUCTIONS (see step 14 in assembly instructions) is kept posted on the trampoline and that
jumpers are informed about these instructions.
The Jumper's Role in Preventing Accidents
Education on the part of the user is a must for safety. Users must first learn a low, controlled bounce and then learn the
basic landing positions and combinations before proceeding to intermediate skills. Jumpers must understand why they
have to master "control" before they can start thinking about other moves. Understanding the proper progression of
skills in jumping on a trampoline must be the first lesson. Review this manual to learn about the basic techniques for
using the trampoline. Follow the rules on the placard with TRAMPOLINE SAFETY INSTRUCTIONS (see step 14 in
assembly instructions). For further information or additional instructional materials, contact a certified trampoline
instructor.
TRAMPOLINE SAFETY INSTRUCTIONS
For the Supervisor
Read the instructions before using the trampoline. Enforce all of the safety rules. Become familiar with the information
in this manual so you can help new users learn basic jumps and all users follow trampoline safety. All trampoline users
must have mature, knowledgeable supervision, regardless of their skill or age. This trampoline is not recommended for
use by children under 6 years of age. Inspect the trampoline before using it. Do not use the trampoline without the frame
pad securely in place to cover the frame. Do not use the trampoline in wet or windy conditions. A worn or damaged mat,
spring, or frame piece should be replaced immediately.
JUMPING
Learn fundamental jumps and body positions thoroughly before trying more advanced skills. Know your own limits in
performing each of the trampoline jumps. Study this manual to learn how to do basic jumps.
Stop your bounce by flexing your knees as your feet come in contact with the trampoline mat. Learn this skill before
attempting any others.
Hazards Associated with High Winds
A trampoline with an enclosure can be moved or blown over by high winds. Anyone in its path, or inside of the enclosure, may be injured if this happens. If you expect high winds, take down the enclosure netting and stake the trampoline
frame to the ground (see page 24), or move the trampoline and enclosure to a sheltered location.
The only sure
method to protect your trampoline and the surrounding environment during high winds is to completely
disassemble the unit and store indoors.
Damage due to wind or weather is not warranted.
WARNING
8
Storing the Trampoline Enclosure Safely
Specific steps for storing the trampoline enclosure are given later in this manual. There are special safety precautions to
be aware of when storing the enclosure.
Remove the attached arch sections as a unit and place them on the ground. Separate the tubes after they are on the ground.
Avoid pinching your fingers by wearing gloves and keeping your fingers away from pinch points near the bracket
assembly while you are removing the tubes from the frame.
Placing the Trampoline and Enclosure in a Safe Place
There must be at least 24 feet (7.3 meters) of clear, open space above the ground. Do not place or store anything underneath the trampoline and enclosure. To avoid injury, the trampoline and enclosure must be kept away from objects and
possible hazards including electric power wiring, tree limbs, and fences. Do not place the trampoline and enclosure near
any other recreational devices or structures such as a swimming pool or swing set. The trampoline and enclosure must be
placed on a level surface before use. The area around the trampoline must always have plenty of light.
For the Supervisor
• Be familiar with the information in this manual and enforce all of the safety rules. Help all users to utilize the
trampoline and enclosure safely.
• All trampoline and enclosure users must have someone to supervise them at all times, regardless of the skill or age of
the user.
• Secure the trampoline and enclosure against unauthorized and unsupervised use. Keep the trampoline and enclosure
free of any objects that could interfere with the jumper.
• This trampoline and enclosure is not recommended for use by children under 6 years of age or by anyone weighing
more than 200 pounds.
• Use the trampoline and enclosure only when the trampoline mat (bed) is clean and dry. Inspect the trampoline and
enclosure prior to each use and replace any worn or damaged parts. Use only when the enclosure netting has no holes,
all uprights are tightly bolted into their sockets, and the netting is properly suspended.
• DO NOT attempt or allow somersaults on the trampoline. Landing on the back or neck can cause serious injury,
paralysis, or death, even when landing in the middle of the bed.
For the Jumper
Do not use the trampoline enclosure when under the influence of drugs or alcohol.
JUMPING
• Avoid jumping too high or for too long. Always control your jump.
• Take turns jumping one at a time, and always have someone watch you.
• Do not attempt to jump over the netting. Do not intentionally bounce off of the netting. Do not hang from, kick, cut, or
climb on the netting.
• Wear clothing that does not have drawstrings, hooks, loops or anything else that could get caught while using the
trampoline/enclosure and result in entanglement or strangulation, or both.
• Do not attach anything to the netting that is not a Skywalker Trampolines approved accessory or part of the of the
trampoline enclosure.
WARNING
9
GETTING ON AND OFF THE TRAMPOLINE
Climb onto and off of the trampoline. Do not jump onto or off of it. Do not use the trampoline as a springboard to jump to
other objects or places.
ENTERING AND EXITING THE TRAMPOLINE ENCLOSURE
The Trampoline should be used only under the appropriate adult supervision.
A ZIPPER CLIP IS PROVIDED TO HELP SECURE THE TRAMPOLINE AGAINST UNSUPERVISED USE BY
CHILDREN AND TO KEEP THE ZIPPER IN THE CLOSED POSITION DURING USE. A responsible adult supervisorshould be present to assure that the zipper clip is attached to the D-ring on the jump mat and that the horizontal clips
areattached to the D-rings on the enclosure netting, both during use and after use.
For additional information regarding equipment, contact Skywalker Holding, LLC. For additional information regarding
skill training, contact a trainer certification organization.
USE AND INSTRUCTIONAL MATERIAL
OVERVIEW OF TRAMPOLINE USE
The first periods of trampoline use should focus on learning fundamental body positions and practicing the eight basic
bounces that are described on pages 10 and 11.
During this learning period, jumpers should practice these basic techniques and perfect them. Braking, or checking the
bounce, should be taught first and stressed as a safety measure. Jumpers should brake their jump whenever they start to
lose their balance or control. This is done by simply flexing the knees sharply upon landing and absorbing the upward
thrust of the mat. This allows the jumper to stop suddenly and avoid losing control.
With trampoline use, the takeoff point and landing point of a good, controlled jump are in the same spot. An exercise is
considered learned only when a jumper is able to perform it correctly time after time. Jumpers should never go on to any
advanced stunt until they can perform all previous stunts correctly each time.
Allow each jumper a brief turn on the trampoline. Extended bouncing exposes an overtired user to an increased risk of
injury. Longer turns tend to lessen the interest of others waiting to jump. Clothing should consist of a T-shirt and shorts.
Jumpers should wear regulation gymnastic shoes or heavy socks, or they may jump barefoot. Street shoes or tennis shoes
should not be worn on the trampoline. Beginning jumpers may wish to wear loose-fitting protective clothes, such as a
long-sleeve shirt and pants, until correct landings are mastered. This will reduce the chance of mat (bed) burns from
improper landings on elbows and knees. No hard-sole shoes should be worn, as they cause extra wear on the trampoline
mat.
Mounting and dismounting (getting on and off) properly should be a strict rule from the beginning. Users should climb
onto the trampoline by placing their hands on the frame and stepping or rolling up onto the frame, across the springs, and
onto the mat. They should not step directly on the frame pad or hold on to the frame pad when getting onto or off of the
trampoline. Users should always place their hands on the frame while getting on or off. To get off, jumpers should walk
to the side of the mat, bend over and place one hand on the frame, and then step from the mat to the ground. If you have
installed the optional ladder, its rungs can be used to get on or off. Always face the ladder and place your hands on the
frame. Make sure your foot has secure contact with the ladder rung when using it.
Reckless bouncing should not be permitted. All skills should be learned at moderate heights. Control, rather than height,
should be emphasized. Jumpers should be forbidden to practice alone and unsupervised.
10
Instructional Program And Model Lessons
The following lessons are examples of an instructional program. They should follow a complete discussion and
demonstration of body mechanics between the supervision and the student(s). See also page 12.
1. Mounting and dismounting (getting on and off)-Demonstration and practice of proper techniques.
2. Fundamental bounce-Demonstration and practice.
3. Braking (stopping the bounce)-Demonstration and practice. Braking on command.
4. Hand and knee drop-Demonstration and practice, stressing four-point landing and alignment.
Lesson 1: Fundamental Bounce
1. Start from a standing position with your head erect
and your eyes on the frame pad.
2. Swing your arms forward and up in a circular motion.
3. Bring your feet together and point your toes
downward while in the air.
4. Keep your feet about 15 inches apart when landing on
the mat.
Lesson 3: Hand and Knee Drop
1. Demonstration and practice, stressing four-point landing and
alignment.
2. Start bouncing from a standing position, keeping your
eyes on the frame pad.
3. Land on the mat on your hands and knees.
4. Push with your hands and come back up to an erect
position.
Lesson 2: Knee Drop
1. Review and practice of skills already learned.
2. Start bouncing from a standing position, keeping your
eyes on the frame pad.
3. Land on your knees, keeping your back straight and
your body erect.
4. Come back up to an erect position
5. Half twist to right, to the left, to the feet, and then to the
knees.
Lesson 4: Back Drop
1. Review and practice skills learned.
2. Start from a low bounce and land on your back.
3. Keep your chin forward on your chest as you land.
4. Kick forward and up with your legs to return to an
erect position.
5. Demonstration, emphasizing the forward thrust of the hips
by arching the body as one leg is brought forward from the
standing (not bouncing) position, and the drop to the back with
the chin held forward to the chest and the eyes forward on the
frame pad. Spotting this skill is most important. Demonstration
of back drop with low bounce and practice of both techniques.
11
Lesson 5: Seat Drop
1. Review and practice of skills already learned.
2. Land in a sitting position with your legs parallel to the
mat.
3. Place your hands on the mat beside your hips.
4. Push with your hands to return to an erect position.
5. Half twist to the feet. Seat drop, knee drop, hand and knee
drop, repeat.
Lesson 7: Half Turntable
1. Review and practice of skills already learned.
2. Start from the front drop position and push to the left
or right with your arms to begin turning your body in
the opposite direction.
3. Turn your head and shoulders toward the direction
that your body is turning.
4. Keep your back parallel to the mat and your head up.
5. After completing a half turn, land in the front drop
position.
Lesson 6: Front Drop
1. To save time and avoid mat (bed) burns, all students should be
requested to assume the front drop position on the floor while the
instructor checks for faults. Suggested progression: from hand and
knee bounce, the body is extended for the landing in the front
drop position, and the rebound is made to the feet.
2. Start from a low bounce and land on the mat in a prone
position.
3. Keep your head up and your arms extended forward on the mat.
4. Push with your arms to return to an erect position.
Lesson 8: Swivel Hips
1. Suggested progression: seat drop, feet, half twist, repeat; seat
drop, half twist to feet, repeat; seat drop, half twist to seat drop.
2. Start with a seat drop.
3. Turn your head to the left or right and swing your
arms up in the same direction.
4. Turn your hips in the same direction as your head and
arms, completing a twist.
5. Land in the seat drop position.
Lesson 9
Once each of lessons are learned, the student should now be encouraged to design and organize routines, with emphasis on
good form. The instructor may judge or grade students and arrange groupings for further instruction accordingly. To stimu-
late interest in competition, the game of “Trampoline Horse” can be introduced. Before the game begins, students must
count off. To start the game, student number 1 performs a stunt. Student number 2 then mounts the trampoline, performs the
same stunt and adds a second stunt. Student number 3 mounts and performs stunts 1 and 2 and adds a third stunt. Thus the
series of stunts is continuously lengthened. The first person to miss a stunt in the series assumes the letter “H” and starts a
new series with a stunt. If a person misses again, he assumes the letter “O.” When a person accumulates “H-O-R-S-E,” he
or she is eliminated from the game. The last remaining contestant is the winner. Lesson planning from this point on should
be facilitated by contacting a certified trampoline instructor.
1
3
2
Top Tube with T-joint (6 pcs)
Top Tube with Socket (6 pcs)
Leg extension (12 pcs)
5 Jumping mat (1 pc)
6 Frame Pad (1 pc)
4 Leg brace (6 pcs)
7 Enclosure net (1 pc)
10 Curved Tube (6 pcs)
13 End Cap (6 pcs)
16 Spring Tool (1 pc)
17 Screw Driver (1 pc)
14 M5x50mm Bolt (6 pcs)
15
M4.8x16mm Self-tapping
Screw(33 pcs), 3 spare parts
11 Foam (12 pcs)
12 Pole Cap (6 pcs)
8 Spring (72 pcs)
9 Straight Tube（6 pcs）
Use below drawings to identify all the parts.
12
Part Identification Chart (not to the actual scale)
2
2
2
2
2
2
1
1
1
1
1
1
3
3
3
3
3
3
3
4
3
3
4
3
3
3
4
4
4
4
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
9
10
13
14
12
11
12
14
14
14
14
12
12
15
15
15
15
15
15
8
5
6
16
17
7
9
9
9
9
9
10
10
10
10
10
14
12
11
11
11
11
11
11
13
13
13
13
13
11
11
12
15
11
13
Exploded Drawing
14
Parts List
Key No. Qty. Description
1 6 Top Tube with T-joint
2 6 Top Tube with Socket
3 12 Leg extension
4 6 Leg brace
5 1 Jumping mat
6 1 Frame Pad
7 1 Enclosure net
8 72 Spring
9 6 Straight Tube
10 6 Curved Tube
11 12 Foam
12 6 Pole Cap
13 6 End Cap
14 6 M5x50mm Bolt
15 33 M4.8x16mm Self-tapping Screw(3 spare parts) 16
1 Spring Tool
17 1 Screw Driver #
1 User’s Manual and Safety Placard #
1 Set of ASTM Frame Labels
#These parts are not illustrated. Specifications are subject to change without notice.
ORDERING REPLACEMENT PARTS
To order replacement parts, visit our web site at www.skywalkertrampolines.com or call our toll-free Customer Care
Hot Line at 1-866-603-Jump (5867), Monday through Friday, 8 a.m. until 5 p.m. Mountain Time (excluding holidays).
To help us assist you, please provide the following information when calling:
• the MODEL of the trampoline (see the front cover of this manual)
• the KEY NUMBER and DESCRIPTION of the part (see the PART LIST above)
• the quantity needed
• the desired method of shipping
1
2
T-joint
Socket
spring holes
face the ground
spring holes
face the ground
Horizontal square tube
(used to connect the Top tube)
Vertical round tube
(used to connect the Leg extension)
T-joint
Horizontal square tube
(used to connect the Top tube)
Vertical round tube
(used to connect the Leg extension)
Vertical square tube
(used to connect Enclosure pole)
Socket
1
15
ASSEMBLY
ASSEMBLY (PUTTING THE TRAMPOLINE AND ENCLOSURE TOGETHER)
IMPORTANT ASSEMBLY INFORMATION
• Need phillips screw driver (included with trampoline) and 2 adjustable wrenches (for putting the trampoline together). A rubber
mallet is also recommended to make assembly easier.
• Assembly requires two adults. Keep children away from the trampoline and enclosure until they are completely put together.
• Use gloves to protect your hands from pinch points during assembly.
• Make sure that the trampoline is properly put together, with the frame pad correctly laid out, before you put together the trampoline
enclosure.
• The assembly steps refer to parts by their descriptions and key numbers (see the PARTS LIST on page 14 and make sure that all
listed parts are included. If a part is missing, refer to ORDERING REPLACEMENT PARTS at the bottom of page 14.
TRAMPOLINE PLACEMENT
1. Place the trampoline and enclosure on a level surface before you use it.
2. Adequate overhead clearance is essential. A minimum of 24 feet (7.3 meters) from the ground is recommended. Provide clearance
from wires, tree limbs, and other possible hazards. Lateral (sideways) clearance is also essential. Place the trampoline and enclosure
away from walls, structures, fences, and other play areas. Maintain a clear space on all sides of the trampoline and enclosure.
3. Use the trampoline in a well-lighted area. If the trampoline is indoors or in a shady areas you may need to use artificial (electrical)
lighting in the area.
4. Secure the trampoline and enclosure against unauthorized and unsupervised use.
5. Remove any objects from under the trampoline and enclosure.
6. The owner and supervisors of the trampoline are responsible to make all users aware of practices specified in this manual.
7. The trampoline enclosure is only to be used as an enclosure for a specific round trampoline.
Trampoline and Enclosure Assembly
To make assembly easier, read the assembly tips at the top of
this page.
1. Locate the Top tube with T-joint(1) and the Top tube
with Socket(2) as shown.
NOTE: Make sure all the spring holes are facing the
ground during this step.
NOTE: If you don’t assemble in the right order, you will
have to
disassemble the entire trampoline in order to attach
correctly.
Identify the T-joint and Socket shown in right will be
helpful for you, they are pre-installed on Top tube.
Loading...
