Congratulations on your choice of SKYRC B6 V2 DC Balance
Charger/Discharger. This unit is simple to use, but the operation
of a sophisticated automatic charger such as SKYRC B6 does
require some knowledge on the part of the user. These operating
instructions are designed to ensure that you quickly become
familiar with its functions. It is therefore important that you read
right through the Operating Instructions, Warning and Safety
Notes before you attempt to use your new charger for the first
time. We hope you have many years of pleasure and success
with your new battery charger.

SkyRC B6 V2 is a high-performance, micro processor control
charge/discharge with battery management suitable for use with
all current battery types(LiPo/LiFe/Li-Ion/LiHV/NiMH/NiCd/Pb)
batteries.The charger deliver dedicated 60W integrated power
and can fill battery at up to 6A. Except SkyRC normal charging
programs, it is versatile with the addition of AGM and Cold modes
for Lead Acid(Pb) battery.

This charger can be powered by 11-18V DC, it is able to power
DC equipment such as LED pit light, motor checker, etc.

Please BE SURE to read these INSTRUCTIONS, WARNING and
SAFETY NOTES before you use the charger for the first time.It
can be dangerous to mis-handle batteries and battery chargers,
as there is always a risk of batteries catching fire and exploding.

Mishandling batteries and battery
chargers is extremely dangerous,
which may cause fire and explosion.

01 ·B6 V2

Introduction

Please read this entire operating manual completely and
attentively before using this product, as it covers a wide range of
information on operating and safety. Or please do use this
product in company with a specialist!

LCD Display

Resume or Start
Charge Processes

DC Input
11-18V

Scroll Through
the Main Menu
Stop Any Charge
Processes

Alter Values
See the Status
of Individual Cells

Temperature
Sensor Port

Balance Lead Socket

Output Socket

· 02 B6 V2 03 ·B6 V2

Optimized Operating Software

SkyRC B6 V2 features the so-called AUTO function that sets the
feeding current during the process of charging/discharging. For
Lithium batteries, it can help prevent overcharging which may lead to
explosion. It will disconnect the circuit automatically and alarm once
detecting malfunction, to achieve maximum safety and minimize the
trouble. All the settings can be configured by users.

Voltage Calibration (for expert user only)

SkyRC B6 V2 allows you to calibrate the voltage directly on the
device with a 6S LiPo battery. (For more information please contact
us at [e-mail])

Memory of Last Operation

SkyRC B6 V2 will memorize your last operation of charging/
discharging before power off.

AGM Charge and Cold Charge

For Pb batteries, there are two more charging modes: AGM charge
and Cold charge.

DJI Battery Program

SkyRC B6 V2 can charge batteries for DJI Mavic/Inspire with the
maximum charge current of 4A.

DC/DC Converter

SkyRC B6 V2 charger is integrated with DC power input, pumping max
power of 60W with the voltage ranging of 5-26V and 1-6A current.

Battery Memory (Data Store/Load)

The charger can store up to 10 different charge/discharge profiles for
each channel. You can keep the data pertaining to program setting of
the battery of continuous charging or discharging. Users can call out
these data at any time without any special program setting.

Terminal Voltage Control(TVC)

The charger allows user to change the end voltage. (for expert user only)

Balancing Individual Cells Battery During Discharging

During the process of discharging, SKYRC B6 V2 can monitor and
balance each cell of the battery individually. Error message will be
indicated and the process will be ended automatically if the voltage of
any single one cell is abnormal.

Special Features

Special Features

Storage Mode of Lithium Battery

“STORAGE” has the capacity to control the final battery voltage,
which is necessary and helpful for a rarely used battery.

Re-Peak Mode of NiMH/NiCd Battery

In re-peak charge mode, the charger can peak charge the battery
once, twice or three times in a row automatically. This is good for
making the battery fully charged.

Cyclic Charging/Discharging

1 to 5 cyclic and continuous process of charge > discharge or
discharge > charge is operable for battery refreshing and balancing
to stimulate the battery's activity.

Battery Voltage Meter

The user can check battery's total voltage, the highest voltage, the
lowest voltage and each cell's voltage.

Battery Internal Resistance Meter

The user can check battery voltage and battery internal resistance.

Capacity Limit

The charging capacity is always calculated as the charging current
multiplied by time. If the charging capacity exceeds the limit, the
process will be terminated automatically when you set the maximum
value.

Processing Time Limit

You can also limit the maximum process time to avoid any possible
defect.

Temperature Threshold*

The battery's internal chemical reaction will cause the temperature of
the battery to rise. If the temperature limit is reached, the process will
be terminated.

* This function is only available by connecting optional temperature
probe, which is not included in the package.

Warning and Safety Notes

These warnings and safety notes are particularly important.
Please follow the instructions for maximum safety;
otherwise the charger and the battery can be damaged or at
worst it can cause a fire.

Never leave the charger unattended when it is connected to its
power supply. If any malfunction is found, TERMINATE THE
PROCESS AT ONCE and refer to the operation manual.

Keep the charger well away from dust, damp, rain, heat, direct
sunshine and vibration. Never drop it.

The allowable DC input 11-18V.

This charger and the battery should be put on a heat-resistant,
noninflammable and nonconductive surface. Never place them on
a car seat, carpet or similar. Keep all the inflammable volatile
materials away from operating area.

Make sure you know the specifications of the battery to be
charged or discharged to ensure it meets the requirements of this
charger. If the program is set up incorrectly, the battery and
charger may be damaged .It can cause fire or explosion due to
overcharging.

Standard Battery Parameters

Nominal
Voltage

Max Charge
Voltage

Storage
Voltage

Allowable
Fast Charge

Min. Discharge
Voltage

Be very careful to choose the correct voltage for different types of
battery otherwise you may cause damage to the batteries. Incorrect
settings could cause the cells to fire or explode.

LiIon

LiPo

3.7V/cell

3.6V/cell

4.2V/cell

4.1V/cell

3.7V/cell

3.8V/cell

≦1C

≦1C

3.0-3.3V/cell 2.9-3.2V/cell

LiFe

3.3V/cell

3.6V/cell

3.3V/cell

≦4C

2.6-2.9V/cell

LiHV

3.7V/cell

4.35V/cell

3.85V/cell

≦1C

3.1-3.4V/cell

NiMH

NiCd

1.2V/cell

1.2V/cell

1.5V/cell

1.5V/cell

n/a

n/a

1C-2C

1C-2C

0.1-1.1V/cell 0.1-1.1V/cell

Pb

2.0V/cell

2.46V/cell

n/a

≦0.4C

1.8V/cell

· 04 B6 V2 05 ·B6 V2

Never attempt to charge or discharge the following types
of batteries.

A battery pack which consists of different types of cells (including
different manufacturers)
A battery that is already fully charged or just slightly discharged.
Non-rechargeable batteries (Explosion hazard).
Batteries that require a different charge technique from NiCd,
NiMh, LiPo or Gel cell (Pb, Lead acid).
A faulty or damaged battery.
A battery fitted with an integral charge circuit or a protection circuit.
Batteries installed in a device or which are electrically linked to
other components.
Batteries that are not expressly stated by the manufacturer to be
suitable for the currents the charger delivers during the charge
process.

Please bear in mind the following points before
commencing charging:

Did you select the appropriate program suitable for the type of
battery you are charging?
Did you set up adequate current for charging or discharging?
Have you checked the battery voltage? Lithium battery packs can
be wired in parallel and in series, i.e. a 2 cell pack can be 3.7V (in
parallel) or 7.4V (in series).
Have you checked that all connections are firm and secure?
Make sure there are no intermittent contacts at any point in the
circuit.

Charging

During charge process, a specific quantity of electrical energy is
fed into the battery. The charge quantity is calculated by multiplying
charge current by charge time. The maximum permissible charge
current varies depending on the battery type or its performance,
and can be found in the information by the battery manufacturer.
Only batteries that are expressly stated to be capable of quick­charge are allowed to be charged at rates higher than the standard
charge current.

Warning and Safety Notes Warning and Safety Notes

Connect the battery to the terminal of the charger: red is positive
and black is negative. Due to the difference between resistance of
cable and connector, the charger can not detect resistance of the
battery pack, the essential requirement for the charger to work
properly is that the charge lead should be of adequate conductor
cross-section, and high quality connectors which are normally gold­plated should be fitted to both ends.

Always refer to the manual by battery manufacturer about charging
methods, recommended charging current and charging time.
Especially, the lithium battery should be charged according the
charging instruction provided by the manufacturer strictly.

Attention should be paid to the connection of lithium battery
especially.

Do not attempt to disassemble the battery pack arbitrarily.

Please get highlighted that lithium battery packs can be wired in
parallel and in series. In the parallel connection, the battery s
capacity is calculated by multiplying single battery capacity by the
number of cells with total voltage stay the same. The voltage s
imbalance may cause fire or explosion .Lithium battery is
recommended to charge in series.

Discharging

The main purpose of discharging is to clean residual capacity of
the battery, or to reduce the battery voltage to a defined level. The
same attention should be paid to the discharging process as
charging. The final discharge voltage should be set up correctly to
avoid deep-discharging. Lithium battery can not be discharged to
lower than the minimum voltage, or it will cause a rapid loss of
capacity or a total failure. Generally, lithium battery doesn't need
to be discharged. Please pay attention to the minimum voltage of
lithium battery to protect the battery.

Some rechargeable batteries have a memory effect. If they are
par tly used and r echa rged befor e the whole charge i s
accomplished, they remember this and will only use that part of
their capacity next time. This is a memory effect . It is said that
NiCd and NiMH batteries are suffering from memory effect. NiCd
has more memory effect than NiMH.

· 06 B6 V2 07 ·B6 V2

Program Flow Chart Program Flow Chart

ENTER

NiMH Sensitivity

D.Peak  4mV

3.2V/CELL

DISCHG VOLTAGE

TVC=YOUR RISK

LiPo DISCHARGE

1.0A 7.4V (2S)

LiFe DISCHARGE

1.0A 6.6V (2S)

LiPo STORAGE

LiFe STORAGE

2.0A 7.4V (2S)

2.0A 6.6V (2S)

LiPo CHARGE

2.0A 7.4V (2S)

LiFe CHARGE

2.0A 6.6V (2S)

LiFe BALANCE CHG

2.0A 6.6V (2S)

LiPo BALANCE CHG

2.0A 7.4V (2S)

ENTER

ENTER

LiPo BATT

BATT/PROGRAM

BATT/PROGRAM

LiFe BATT

Lilo DISCHARGE

1.0A 7.2V (2S)

LiHV DISCHARGE

1.0A 7.6V (2S)

Lilo STORAGE

2.0A 7.2V (2S)

LiHV STORAGE

2.0A 7.6V (2S)

Lilo CHARGE

2.0A 7.2V (2S)

LiHV CHARGE

2.0A 7.6V (2S)

Lilo BALANCE CHG

2.0A 7.2V (2S)

LiHV BALANCE CHG

2.0A 7.6V (2S)

ENTER

ENTER

LiHV BATT

BATT/PROGRAM

LiIo BATT

BATT/PROGRAM

NiMH CYCLE

CHG>DCHG 1

NiCd CYCLE

CHG>DCHG  1

NiMH RE-PEAK

1

NiCd RE-PEAK

1

NiCd DISCHARGE

1.0A CUT: 3.2V

NiMH DISCHARGE

1.0A CUT: 3.2V

NiCd CHARGE

CURRENT 2.0A

NiMH CHARGE

CURRENT 2.0A

ENTER

ENTER

NiCd BATT

NiMH BATT

BATT/PROGRAM

BATT/PROGRAM

Pb DISCHARGE

1.0A 4.0V (2P)

MAIN 16.78V

H4.200V L4.195V

Pb COLD CHG

2.0A 4.0V (2P)

4.20 4.19 4.19 V

4.19 0.00 0.00 V

2.0A 4.0V (2P)

Pb AGM CHG

ENTER

METER

Pb NORMAL CHG

2.0A 4.0V (2P)

BATTERY VOLTAGE

ENTER

ENTER

TOOL KITS

Pb BATT

BATT/PROGRAM

BATT/PROGRAM

TATAL: 16mΩ

5 3 3 mΩ

5 0 0 mΩ

ENTER

RESISTANCE

BATTERY INTERNAL

Mavic STORAGE

BEFORE CHARGING

Mavic CHARGE

TURN ON BATTERY

Mavic CHARGE

BEFORE CHARGING

Mavic CHARGE

TURN ON BATTERY

ENTER

Mavic

DJI DRONE BATT

U=0.0V I=0.0A

DC/DC CONVERTER

Rest Time

CHG>DCHG 10Min

BEFORE CHARGING

TB4X STORAGE

Temperature Unit

Celsius

TB4X CHARGE

TURN ON BATTERY

Temp Cut-Off

ON 50°C 122°F

TB4X CHARGE

BEFORE CHARGING

ON 5000mAH

Capacity Cut-Off

TB4X CHARGE

TURN ON BATTERY

ENTER

TB4X

DJI DRONE BATT

Safety Timer

ON 120Min

ENTER

BATT/PROGRAM

SYSTEM SETTING->

NiCd Sensitivity

D.Peak  4mV

DISCHG CURRENT

1.0A

CHARGE CURRENT

2.0A

Key Beep ON

Buzzer ON

DC Input Low

Cut-Off 11.0V

BATT VOLTAGE

7.4V ( 2S )

Load Factory Set

Enter

LiPo

BATT TYPE

ENTER

Version

HW:1.00 SW: 1.04

[ BATT MEMORY 1 ]

ENTER SET->

ENTER

Stop

BATT PROG

BATT/PROGRAM

BATT MEMORY

4.20V

SAVE PROGRAM

ENTER

ENTER

LiPo DISCHARGE

1.0A 7.4V(2S)

SAVE PROGRAM

SAVE….

LiPo STORAGE

2.0A 7.4V(2S)

LiPo 7.4V (2S )

[ BATT MEMORY 1 ]

LiPo CHARGE

2.0A 7.4V(2S)

C:2.0A D:1.0A

[ BATT MEMORY 1 ]

ENTER>3Seconds

LiPo BALANCE CHG

2.0A 7.4V(2S)

TRICKLE

100mA

0.5V/CELL

DISCHG VOLTAGE

1Min

PEAK DELAY

DISCHG CURRENT

1.0A

ENTER

CHARGE CURRENT

2.0A

SAVE PROGRAM

ENTER

2.4V (2S)

BATT VOLTAGE

SAVE PROGRAM

SAVE….

BATT TYPE

NiMH

NiMH 2.4V (2S )

[ BATT MEMORY 2 ]

ENTER

ENTER>3Seconds

ENTER SET->

[ BATT MEMORY 2 ]

[ BATT MEMORY 2 ]

C:2.0A D:1.0A

ENTER

1.8V/CELL

DISCHG VOLTAGE

DISCHG CURRENT

1.0A

NiMH CYCLE

CHG>DCHG 1

CHARGE CURRENT

2.0A

NiMH RE-PEAK

1

BATT VOLTAGE

4.0V (2P)

NiMH DISCHARGE

1.0A CUT: 1.0V

BATT TYPE

Pb

ENTER

NiMH CHARGE

CURRENT 2.0A

ENTER SET->

[ BATT MEMORY 3 ]

ENTER

SAVE PROGRAM

ENTER

SAVE PROGRAM

SAVE….

[ BATT MEMORY 3 ]

Pb 4.0V (2S )

[ BATT MEMORY 3 ]

C:2.0A D:1.0A

ENTER>3Seconds

Pb DISCHARGE

1.0A 4.0V(2P)

Pb COLD CHG

INC

INC

DEC

Pb NORMAL CHG

2.0A 4.0V (2P)
Pb AGM CHG

2.0A 4.0V (2P)

DEC

2.0A 4.0V (2P)

· 08 B6 V2 09 ·B6 V2

Explanation of Buttons Power and Battery Connection

1. Connecting to power source
12V DC Battery / Power Adapter Output DC 11-18V

BATT PROG / STOP Button:
It is used to stop the progress or go back to previous step/screen
DEC Button:
It is used to go through the menus and decrease the parameter value
INC Button:
It is used to go through the menus and increase the parameter value
ENTER / START Button:
It is used to enter parameter or store parameter on screen.

When you are willing to alter the parameter value in the program,
press the START/ENTER button to make it blink then change the
value by pressing DEC and INC button. The value will be stored by
re-pressing the START/ENTER button. If there is another parameter
can be altered in the same screen, when you confirm the first
parameter value, the next parameter value will start to blink which
means it is ready to alert.

When you are willing to start the progress, press and hold the
START/ENTER button for 3 seconds. When you are willing to stop the
progress or go back to previous step/screen, press the BATT
PROG/STOP button once.

When you power on the charger, it will enter LiPo Battery balance
program directly. You could change the mode (balance mode, normal
charge mode, fast charge mode, store mode or discharge mode),
enter the desired charging/discharging mode, set the referred
parameter and start the progress.

4S LiPo Battery Pack

or 12V Pb Battery

11-18V

Adapter

XT60

STOP STATUS START

STOP STATUS START

If you have no request for LiPo Battery program, please press the
BATT PROG/STOP button to enter BATT PROGRAM screen.

· 10 B6 V2 11 ·B6 V2

Power and Battery Connection

Charge Operation

2. Connecting the battery

TO AVOID SHORT CIRCUITS, ALWAYS CONNECT
THE CHARGE LEADS TO THE CHARGER FIRST,
AND THEN TO THE BATTERY. REVERSE THE

WARNING!

SEQUENCE WHEN DISCONNECTING THE PACK.

1) LiPo Battery Connection

Lithium Battery Pack

STOP STATUS START

The balance wire of the battery must be connected to the charger.
Always remember to keep right polarity in the connection. Please
refer to the wiring diagram above,which shows a correct way for
your LiPo battery connection in the balance charge mode.
In the other modes, there is no request to connect the balance wire
to the balance socket in the charger.
But we suggest to charge your battery in balance mode for better
performance.

2) NiMH/NiCd or Pb Battery Connection

NiMH Battery Pack

STOP STATUS START

Charging Program

Depends on different battery type, the operation programs are different.

Batt
Type

LiPo
LiHV
Lilon
LiFe

NiMH
NiCd

Pb

Mavic
TB4X

Operation
Program

CHARGE

DISCHARGE

STORAGE

BAL
CHARGE

CHARGE

DISCHARGE

RE-PEAK

CYCLE

NORMAL CHG

AGM CHG

COLD CHG

DISCHARGE

CHARGE

STORAGE

This charging mode is for charging LiPo/LiHV/LiFe/LiIon
battery in normal mode.

This mode is for discharging LiPo/LiHV/LiFe/LiIon battery.

This program is for charging or discharging lithium battery
which will not be used for long time.

This mode is for balancing the voltage of lithium-polymer
battery cells while charging.

The charger will charge NiMH and NiCd batteries using
the charge current set by the user.

This mode is for discharging NiMH/NiCd battery.

In re-peak charge mode, the charger can peak charge
the battery once, twice or three times in a row
automatically. This is good for confirming the battery is
fully charged, and for checking how well the battery
receives fast charges.

1 to 5 cyclic and continuous process of charge>discharge
or discharge>charge is operable for battery refreshing
and balancing to stimulate the battery's activity.

This mode is for charging Pb battery.

This mode is for charging AGM battery.

This mode is for charging Pb battery in cold days when the
temperature is 5℃ to -20℃.

This mode is for discharging Pb battery.

This charging mode is for charging Mavic/TB4X battery
in normal mode.

This program is for charging or discharging Mavic/TB4X
battery which will not be used for long time.

Description

· 12 B6 V2 13 ·B6 V2

Lithium Battery Program (LiPo/LiFe/Lilon/LiHV) Lithium Battery Program (LiPo/LiFe/Lilon/LiHV)

(1)

A memory profile is available for setting and storing pertinent
information for up to 10 different program sets. Once a battery
program is stored into memory, it will be retained until changed
again manually. Recalling a program memory number makes the
charger instantly ready to go!

(2)

If you do not wish to use the battery program memories, this
charger can be manually set before each use.

The following flowchart shows how the program is set manually:

BATT/PROGRAM

LiPo BATT

STA RT/E NTE R

LiPo BALANCE CHG

2.0A 11.1V (3S)

STA RT/E NTE R

LiPo BALANCE CHG

2.0A 11.1V (3S)

STA RT/E NTE R

LiPo BALANCE CHG

2.0A 11.1V (3S)

STA RT/E NTE R

LiPo BALANCE CHG

2.0A 11.1V (3S)

STA RT/E NTE R
> 3 Sec onds

BATT/PROGRAM Select

Press INC and DEC to go through all the
programs and press START/ENTER to enter
LiPo BATT Program.

Mode Select

Press INC and DEC to go through all the
modes and press START/ENTER to enter
LiPo Balance Charge Mode.

Battery Setting

Press START/ENTER, the present value will
start to blink. Press INC and DEC to change
the value and press START/ENTER to
confirm your setting.
At the same time, the battery pack’s cell
count will start to blink, press INC and DEC
to change the value and press START/
ENTER to confirm your setting.

Program Start

Press and hold START/ENTER for 3
seconds to start the program.

BATTERY CHECK

...............

R:3SER S:3SER

CANCEL(STOP)

R:3SER S:3SER

CONFIRM(ENTER)

STA RT/E NTE R

10. 20V

50%

003 01mAhC 2 .0A

12. 61V

FUL L

005 68mAh0.0A

12. 61V

FUL L

00: 05:250.0 A

Program Stop

During the charging
process, press STOP
to stop the charging
process.

The charger is detecting the battery cell.

R shows the number of cells detected by the
charger and S is the number of cells set by
you on the previous screen. If the two numbers
are not identical, press STOP to go back to
the previous screen to recheck the number of
cells of the battery pack that you set before
going ahead.

R shows the number of cells detected by the
charger and S is the number of cells set by
you on the previous screen. If the two
numbers are identical, press START/ENTER
to start the charging process.

Charging Status Monitor
During charge process, real-time status will be
shown as seen on the left. Print INC or DEC,
more status will show on the screen.

Program Complete

Once the battery is fully charged, the screen
will read “FULL” and the charger will emit a
ringing sound. The charger also displays
battery voltage, charged capacity and elapsed
time.

Video
Tutorial

· 14 B6 V2 15 ·B6 V2

Please scan and watch the tutorial video about
how to charge LiPo battery in balance mode.

Lithium Battery Program (LiPo/LiFe/Lilon/LiHV)

NiMH/NiCd Battery Program

VARIOUS INFORMATION DURING THE PROCESS

Press INC or DEC during the charging or discharging process to
view further pertinent information on the LCD screen.

Real-time status: battery type, battery

10. 20V

50%

003 01mAhC 2 .0A

INC

3.87 3.89 3.86 V

50%

003 01mAhC 2 .0A

DEC

End Voltage

12.6V(3S)

DEC

IN Power Voltage

12.56V

DEC

Ext. Temp ---­Int. Temp 37°C

DEC

Temp Cut-Off
　　　 50C/122F

DEC

Safety Timer
ON 120min

DEC

Capacity Cut-Off
ON 5000mAh

cell count, charge current, battery pack
total voltage,working mode, elapsed
time and charged capacity.

Voltage of each cell in the battery pack
when the battery is connected with
balance lead.

10. 20V

Final voltage when the program ends.

Input voltage.

Internal temperature.
Temperature probe needs to be connected
to show external temperature.

Cut-off temperature.

Safety timer ON and duration of time in
minutes.

Capacity cut-off ON and value of the set
capacity limit.

NiMH/NiCd:

This program is only suitable for charging/discharging NiMH/NiCd
batteries. The B6 V2 offers the following NiMH/NiCd charge modes:
Charge, Discharge, Re-Peak and Cycle.

Selecting the Battery Type:

After powering on the B6 V2, press the INC or DEC button repeatedly
until you reach the appropriate program for the battery type you wish
to charge. For this example we have chosen the “NiMH BATT“ or
“NiCd BATT” program. Now press the ENTER button to enter the
desired program.

WARNING!

NiMH/NiCd Charge Mode:

BEFORE YOU BEGIN CHARGING YOUR BATTERY, MAKE SURE
YOU HAVE READ AND UNDERSTOOD ALL OF THE WARNINGS
AND SAFETY INFORMATION CONTAINED ON PAGES 05-07.

After selecting the correct battery type, if the screen does not read
“CHARGE”, use the DEC or INC buttons to change it to the
“CHARGE” mode.

NiMH CHARGE

CURRENT 2.0A

NiMH 2.0A 6.22V

CHG 00:02:22

NiMH 2.0A 6.22V

CHG 00106mAh

· 16 B6 V2 17 ·B6 V2

BEFORE YOU BEGIN CHARGING YOUR BATTERY,
MA KE S UR E YO U ARE CHA RG ING NIMH/ NI CD
BATTERIES. CHARGING LIPO BATTERY UNDER NIMH/
NICD BATTERY PROGRAM WILL CAUSE FIRE.

Press the ENTER button and the amp rate
value will begin blinking. Use the DEC or INC
button to adjust the value to the desired rate.
Follow the instructions provided on your battery

STA RT/E NTE R

when setting the charge current.
Press and hold the ENTER button for 3

seconds to start charging.

Once charging has commenced, the charger
will display the following real-time information:
battery type, charging current, battery voltage,
working mode, elapsed time and charged
capacity. Once the battery is fully charged, the
screen will read "FULL" and the charger will
emit a ringing sound. You can press the STOP
button at any time during the charging process
to stop charging.

NiMH/NiCd Discharge Mode:

NiMH DISCHARGE

1.3A CUT: 5.10V

After selecting the correct battery type, use
the INC or DEC b utton to selec t the
“DISC HARGE” mode. Press t he START
button and the amp rate value will begin
flashing. Use the INC or DEC buttons to
adjust the value to the desired discharge rate.
Press the START button again and the
voltage cut-off will begin to flash. Use the INC
or DEC button to adjust the value to the
desired rate.

NiMH 0.6A 5.43V

DCH 00:02:22

Follow the instructions provided on your
battery when setting the voltage cut-off. The
T200 will stop discharging when the battery
has reached the preset voltage cut-off.

NiMH 0.6A 5.43V
DCH 00106mAh

Press and hold the START button for 3
se co nd s t o st art di sch arg in g. O nc e
discharging has commenced, the charger will
display the following real-time information:
battery type, discharging current, battery
voltage, working mode, elapsed time and
discharged capacity.

NiMH DONE 5.10V

DISCHG 00:03:17

When discharging is complete, the screen will
read “DONE” and the charger will emit a
ringing sound.
The charger will display the elapsed time, end
voltage and the discharged capacity in mAh.
You can press the STOP button at any time
during the discharging process to stop the
discharge process.

NiMH/NiCd Battery ProgramNiMH/NiCd Battery Program

NiMH/NiCd Re-Peak Mode:

Applicable to NiMH and NiCD batteries only, in re-peak mode the
charger can peak- charge the battery once, twice, or three times in a
row automatically. This process is good for confirming that the battery
is fully charged and for verifying how well the battery can accept a fast
charge. A five-minute cool-down delay occurs after each re-peak
charge.

IN RE-PEAK MODE, THE B6 V2 USES THE CHARGE AMPERAGE
AND VOLTAGE SETTINGS ENTERED IN CHARGE MODE.

NiMH RE-PEAK
2

STA RT/E NTE R

NiMH 2.0A 6.28V
RPC 00:04:04

NiMH 2.0A 6.28V
RPC 00686mAh

After selecting the correct battery type, use
the INC or DEC button to select the “RE­PEAK” mode. Press the START button and
the Re-peak cycle number 1 begins to flash
on the screen. Use the INC or DEC button to
scroll through the cycle count and set a
number between 1 and 3.
Press and hold the START button for 3
seconds to start the re-peak process.

Once the Re-Peak process has begun, the
charger will display the following real-time
information: battery type, charging current,
battery voltage, elapsed time and charged
capacity.
Once the Re-Peak process has completed,
the screen will read “DONE” and the charger
will emit a ringing sound. The charger will
display the charge/discharge capacity for
each cycle. Using the + and - buttons, you
can scroll through the history data of each
cycle.

· 18 B6 V2 19 ·B6 V2

NiMH/NiCd Cycle Mode:

The B6 V2 makes cycling of NiMH/NiCd batteries easy. The process of
discharging and recharging (cycling) can be performed automatically
with one simple step and will improve the performance of NiMH/NiCd
batteries. We strongly recommend cycling any battery that has been
discharged and stored for a period of time. This will increase the
rema ining usable b atter y life and a lso improve the battery
performance.

NiMH CYCLE
CHG > DCHG 1

STA RT/E NTE R

After selecting the correct battery type, use
the INC or DEC button to select the “CYCLE”
mode. The Cycle Mode gives you two cycling
options: “DCHG>CHG” or “CHG>DCHG“. The
“DCHG>CHG” option will first discharge the
battery and then recharge the battery.

NiMH CYCLE
CHG > DCHG 5

The “CHG>DCHG” option will first charge the
battery and then discharge the battery. If this
screen does not show your desired cycling
option, press the START button once and this
setting will begin flashing. Use the INC or
DEC button to change this setting.
Pressing the START button again will cause
the cycle count to begin flashing. Use the INC
or DEC button to change this to the number of
cycles you want the B6 V2 to run. The T200
can cycle the battery a maximum of 5 times
consecutively.

NiMH 2.0A 6.39V
C > D 00:04:04

Press and hold the START button for 3
seconds to start the Cycle Mode.
Once cycling has commenced, the charger will
display the following real-time information:

NiMH 2.0A 6.39V
C > D 00034mAh

battery type, charging/ discharging current,
battery voltage, working mode,elapsed time
and charged/discharged capacity. You will also

NiMH/NiCd Battery ProgramNiMH/NiCd Battery Program

see “D>C“ or “C>D“. This will indicate which
cycling order you have chosen.
Either “D“ or “C“ will be flashing. This flashing
indicates which part of the cycle is currently
being executed.

Once the cycling process is complete, the screen will read “DONE”
and the charger will emit a ringing sound. The B6 V2 will display the
charged/discharged capacity for each cycle. Using the + and ­buttons, you can scroll through this data for each cycle.

Additional NiMH/NiCd Process Information:

During the NiMH/NiCd battery charging/discharging process the B6
V2 can display a variety of information. Using the INC or DEC
buttons, you can also view the following information:

NiMH Sensitivity
D.Peak 4mV/CELL

Ext. Temp ---­Int. Temp 37 C

Safety Timer
ON 200min

In Power Voltage

12.56V

Temp Cut-off

50 C/122 F

Capacity Cut-Off
ON 5000mAh

Delta peak voltage sensitivity setting

External*/ internal temperature

Safety timer setting

Input Voltage

Temperature cut-off

Capacity limit setting

· 20 B6 V2 21 ·B6 V2

Pb Lead-acid Battery Program Pb Lead-acid Battery Program

Pb Lead-Acid Battery Program

Pb (Lead-Acid):

BATT/PROGRAM
Pb BATT

Pb Charge Mode:

After selecting the correct battery type, use the INC or DEC button to
change it to the “CHARGE“ mode.
Press the START button and the amp rate value will begin flashing.
Use the INC or DEC buttons to adjust the value to the desired charge
rate. The amp rate should be set to 1/10th of capacity. For example, if
you are charging a 20Ah battery the charge rate should be set to 2A.
Follow the instructions provided on your battery when setting the amp
rate.

Pb Normal Charge

2.0A 12.0V(6P)

P-6 1.5A 13.56V
CHG 00:02:22

P-6 1.5A 13.56V
CHG 00106mAh

P-6 FULL 13.62V
CHG 00106mAh

· 22 B6 V2 23 ·B6 V2

This program is only suitable for charging
Pb(lead-acid) batteries with nominal voltage
ranging from 2 to 20V which are significantly
diff eren t from N iMH/ NiCd batteries. Pb
batteries are suggested to charge with a low
current of 0.1C and cannot be used for fast
charging. Please follow the instruct ions
provided by the battery manufacturer.

The B6 offers the following Pb charge modes:
Charge, AGM, COLD and Discharge.

Press the START button again and the
nominal battery pack voltage will begin
flashing. Use the INC or DEC button to set the
voltage and the number of cells.
Press and hold the START button for 3
seconds to start charging.

Once charging has commenced, the charger
will display the following real-time information:
battery type, charging current, battery voltage,
working mode,elapsed time and charged
capacity.

When charging is complete, the screen will
read “FULL” and the charger will emit a ringing
sound.

Pb AGM Mode:

After selecting the correct battery type, use the INC or DEC button to
change it to the “AGM CHARGE“ mode.
Press the START button and the amp rate value will begin flashing.
Use the INC or DEC buttons to adjust the value to the desired charge
rate. The amp rate should be set to 1/10th of capacity. For example, if
you are charging a 20Ah battery the charge rate should be set to 2A.
Follow the instructions provided on your battery when setting the amp
rate.

Pb AGM CHG

1.5A 12.0V(6P)

P-6 1.5A 13.56V
AGM CHG 00:02:22

P-6 1.5A 13.56V

AGM CHG 00106mAh

P-6 FULL 13.62V
AGM CHG 00106mAh

Press the START button again and the
nominal battery pack voltage will begin
flashing. Use the INC or DEC button to set the
voltage and the number of cells.
Press and hold the START button for 3
seconds to start charging.

Once charging has commenced, the charger
will display the following real-time information:
battery type, charging current, battery voltage,
working mode, elapsed time and charged
capacity.
When charging is complete, the screen will
read “FULL” and the charger will emit a ringing
sound.

Pb Lead-acid Battery Program Pb Lead-acid Battery Program

Pb Cold Mode:

Pb COLD CHG

1.5A 12.0V(6P)

P-6 1.5A 13.56V
COLD CHG 00:02:22

P-6 1.5A 13.56V

COLD CHG 00106mAh

P-6 FULL 13.62V
COLD CHG 00106mAh

Press the START button again and the
nominal battery pack voltage will begin
flashing. Use the INC or DEC button to set the
voltage and the number of cells.
Press and hold the START button for 3
seconds to start charging.

Once charging has commenced, the charger
will display the following real-time information:
battery type, charging current, battery voltage,
working mode, elapsed time and charged
capacity.
When charging is complete, the screen will
read “FULL” and the charger will emit a ringing
sound.

Pb Discharge Mode:

After selecting the correct battery type, use the INC or DEC buttons
to change it to the “DISCHARGE“ mode.
Press the START button and the amp rate value will begin flashing.
Use the INC or DEC buttons to adjust the value to the desired
discharge rate. Follow the instructions provided with your battery
when setting the amp rate.

Pb Discharge

1.5A 12.0V(6P)

Press the START button again and the
nominal battery pack voltage will begin
flashing. Use the INC or DEC buttons to set
the voltage and the number of cells.
Press and hold the START button and

P-6 1.5A 13.56V
DCH 00:02:22

discharging will begin.

P-6 DONE 13.62V
DCHG 00106mAh

Additional Pb Process Information:

During the Pb battery charging/discharging process the B6 V2 can
display a variety of information. Using the INC or DEC buttons you can
also view the following information:

Capacity Cut-Off
ON 5000mAh

Temp Cut-off
50 C

In Power Voltage

12.56V

Once d ischarging has commenced, the
charger will display the following real-time
information: battery type, cell count,discharging
current, battery voltage, elapsed time and
discharged capacity.
When discharging is complete, the screen will
read “DONE” and the charger will emit a
ringing sound.

Capacity cut­off setting

Temperature
cut-off

Safety Timer
ON 200min

Ext. Temp ---­Int. Temp 37 C

Safety timer
setting

External*/
internal
temperature

Input voltage

P-6 1.5A 13.56V
DCH 00106mAh

· 24 B6 V2 25 ·B6 V2

DJI Battery Program DJI Battery Program

This program is only suitable for charging/ discharging DJI Mavic
and TB4X battery, B6 offers two operation modes: charge and
storage.
Selecting the Battery Type:
After powering on the B6 V2, press DEC or INC, DJI BATT program
involved in the "TOOL KITS" program, press the INC or DEC button
repeatedly until you reach the appropriate program for the battery
type you wish to charge. For this example we have chosen the "DJI
DRONE BATT Mavic" or "DJI DRONE BATT TB4X" program. Now
press the ENTER button to enter the desired program.

Charge Mode:

Connect the battery to the charger as show on the diagram.
Turn on the battery before you put it in charging mode.

CONNECTION DIAGRAMCONNECTION DIAGRAMCONNECTION DIAGRAM

Note: Mavic charging cable is not included
in the package

BATT/PROGRAM
TOOL KITS

ENTER

DJI DRONE BATT

Mavic

ENTER

Mavic CHARGE

TURN ON BATTERY

PRESSENTER>3"

Press the ENTER button and the amp rate
value will begin blinking. Use the INC or DEC
button to adjust the value to the desired rate.
Follow the instructions provided on your
battery when setting the charge current.

Press and hold the ENTER button for 3 seconds
to start charging.

Press the Power Button once
Then Press Again and Hold
for 2 Seconds to Turn On

10. 20V

50%

003 01mAhC 2 .0A

12. 61V

FUL L

005 68mAh0.0A

12. 61V

FUL L

00: 05:250.0 A

BATT/PROGRAM
TOOL KITS

ENTER

DJI DRONE BATT

Mavic

ENTER

Mavic CHARGE

TURN ON BATTERY

+ -

Mavic STORAGE

TURN ON BATTERY

PRESSENTER>3"

10. 20V

50%

003 01mAhC 2 .0A

12. 61V

DON E

005 68mAh0.0A

12. 61V

DON E

00: 05:250.0 A

Once charging has commenced, the charger
will display the following real-time information:
charging current, battery voltage, working
mode, elapsed time and charged capacity.
Once the battery is fully charged, the screen
will read "FULL" and the charger will emit a
ringing sound. You can press the STOP
button at any time during the charging
process to stop charging.

Storage Mode:

When the battery is idle for temporary days, it is
better to charge/ discharge the battery to 65%
of total power in order to prevent swelling.

Turn on the battery before you put it in storage
mode.

After selecting the corr ect battery type, u se
the INC or DEC button to change the charge
mode to "STORAGE" mode setting.

Pres s th e ENT ER b utton and the amp rate
value will begin blinking. Use the INC or DEC
button to adjust the value to the desired rate.
Follow the instructions provided on your battery
when setting the charge current.

Press and hold the ENTER button for 3 seconds
to start charging.

Once charging has commenced, the charger
will display the following real-time information:
charging current, ba tter y voltage, working
mode, el apsed tim e an d charged cap acity.
Once the battery is fully charged, the screen
will read "DO NE" and the charger will emit a
ringing sound. You can press the STOP button
at an y time dur ing the char ging proces s to
stop charging.

· 26 B6 V2 27 ·B6 V2

DC / DC Converter

B6 V2 charger is integrated with a DC/DC converter. A DC/DC
converter is an electronic circuit that converts a source of direct
current (DC) from one voltage level to another. It is a type of electric
power converter. For B6 V2, the output voltage range from 5-26V
and output current range from 1-6A. The maximum power is 60W.

DC Input
(11-18V)

STOP STATUS START

BATT/PROGRAM
TOOL KITS

ENTER

DC/DC CONVERTER
U=0.0V I=0.0A

ENTER

DC/DC CONVERTER
U=6.0V I=3.4A

PRESSENTER>3"

U=5.9V I=1.2A
POWER=7W

This program can be found in the "TOOL
KITS", press DEC or INC button repeatedly
until you rea ch "DC/DC CONVERTER"
program, double press the ENTER, then
press DEC or INC to set the output voltage
and current.

Press and hold the ENTER button for 3
seconds, the charger will start to work as
a power supply, you can read the output
voltage/ current / power on the screen.

Caution: The maximum DC Power output is 60 Watts. Please check
your device loading before you allocate the power.

DC Output

(5-26V / 1-6A)

Battery Memory Set and Call Out

The charger can store up to 10 different charge/discharge profiles for
your convenience, and the stored profiles can be recalled quickly
without having to go through the setup process.
When you are willing to alter the parameter value in the program,
press START/ENTER to make it blink then change the value with INC
or DEC. The value will be stored by pressing START/ENTER once.
Note: All following screen are taking 2S(7.4V) LiPo battery for
example.

1. Battery Memory Set

[ BA T T ME MO R Y 1 ]
EN T ER S ET - >

STA RT/ ENT ER

BA T T TY PE
Li P o

DE C IN C

BA T T VO LT S

7. 4 V ( 2S )

DE C IN C

CH A RG E CU R RE NT

4. 9 A

DE C IN C

DS C H CU RR E NT

2. 0 A

DE C IN C

DS C H VO LT A GE

3. 0 V/ CE L L

DE C IN C

Enter the battery memory program.
(10 different charge/discharge profiles can
be stored).

Set the battery type(LiPo/LiHV/LiFe/LiIon/
NiMH/NiCd/Pb).

Set the voltage and number of cells(1-6S).

Set the charge current(0.1-6.0A).

Set the discharge current (0.1A-2.0A).

Set the discharge voltage(3.0-3.3V/Cell).

· 28 B6 V2 29 ·B6 V2

Battery Memory Set and Call Out System Setting

TV C =Y OU R R IS K

4. 2 0V

DE C IN C

SA V E PR OG R AM
EN T ER

STA RT/ ENT ER

SA V E PR O GR AM
SA V E .

[ BA T T ME M OR Y 1 ]
Li P o  7. 4 V (2 S)

[ BA T T ME M OR Y 1 ]
C: 4 .9 A D :2 .2 A

START/ENTER
>3 Seconds

EN T ER C H AR GE R
LO A D

Li P o BA L AN CE C H G

4. 9 A 7. 4 V( 2S )

Set the terminal voltage(4.18-4.25V).

Press ENTER to save program.

Indicate the battery type and battery cell of the
saved profile.

Indicate the charge and discharge current of
the saved profile.
Press the START/ENTER for 3 seconds to call
out the memory.

2. Battery Memory Call Out

Load the memory set

Press START/ENTER for 3 seconds to start
the process.

It will be operated with the default value of the essential user settings
when it is powered on for the first time.The screen displays the
following information in sequence and the user can change the value
of parameter on each screen.
When you are willing to alter the parameter value in the program,
press START/ENTER to make it blink then change the value with INC
or DEC. The value will be stored by pressing START/ENTER once.

ITEM SELECTION DESCRIPTION

When you start a charge process,
the integral safety timer
automatically starts running at the
same time. This is programmed to
prevent overcharge the battery if it
proves to be faulty, or if the
termination circuit cannot detect
the battery full. The value for the
safety timer should be generous
enough to allow a full charge of
the battery.

This program sets the maximum
cha rge capac ity that wil l be
supplied to the battery during
charge. If the delta peak voltage is
not detected nor the safety timer
expired by any reason, this feature
will automatically stop the process
at the selected capacity value.

The battery's internal chemical
reaction will cause the
temperature of the battery to rise.
If the temperature limit is reached,
the process will be terminated.

You can choose the temperature
displayed by Celsius or Fahrenheit
as you like.

A rest time allowing the battery to
cool down between
charging/discharging cycle.

Sa fe t y Ti me r
ON 1 20 M in

Ca pa c it y Cu t- O ff
ON 5 00 0 mA H

Te mp C u t- Of f
ON 5 0 C 12 2 F

Te mp e ra tu re U n it
Ce ls i us

Re st T i me
CH G> D CH G 10 Mi n

OFF/
ON
(1-720 Min)

OFF/
ON
(100-50000mAh)

OFF/
ON
(20 C/68 F ­80 C/176 F)

Celsius
Fahrenheit

1-60Min

· 30 B6 V2 31 ·B6 V2

System Setting

Battery Voltage Meter

ITEM

Ni MHS e ns it iv i ty
D. Pe a k De fa ul t

Ni CdS e ns it iv i ty
D. Pe a k De fa ul t

Ke y Be e p ON
Bu zz e r ON

DC I np u t Lo w
Cu t- O ff  1 1. 0V

Lo ad F a ct or y Se t
En te r

Ve rs i on
HW :1 . 00 S W: 1 .0 4

SELECTION DESCRIPTION

This program is for NiMH/NiCd

Default:
4mV/Cell
3-15mV/Cell

OFF/ON

10-12 V

battery only. When the charger
detects the delta peak value
reaches the value you set, the
charger will say the battery is fully
charged.

The beep sounds at every time
touching the buttons to confirm
your action. The beep or melody
sounded at various times during
operation to alert different mode
changes.

There will be error message when
DC input voltage is lower than the
reset value.

Press ENTER to load factory
default setting.

It indicates the hardware and
firmware version.

The user can check battery's total voltage, the highest voltage, the
lowest voltage and each cell's voltage.

Please connect the battery to the charger main battery lead to
battery socket and balance wires to balance socket.

This diagram shows
the correct way to
connect your battery
to check the voltage.

4.2 0 4.19 4 .19 V

4.1 8 4.18 4 .19 V

STOP STATUS START

Lithium Battery Pack

BA T T/ P RO GR A M
BA T T ME T ER

START
ENT ER

4. 2 0 4. 1 9 4. 19 V

4. 1 8 4. 1 8 4. 19 V

IN C

MA I N 25 . 13 V
H4 . 20 0 V L4 .1 8 2V

Press the START/ENTER to enter the Lithium
Battery Meter program.

The screen indicate each cell's voltage.

The screen indicate the total voltage, the
highest voltage and the lowest voltage.

· 32 B6 V2 33 ·B6 V2

Battery Resistance Meter

The user can check battery's total resistance, the highest resistance,
the lowest resistance and each cell's resistance.

Please connect the battery to the charger main battery lead to battery
socket and balance wires to balance socket.

Warning and Error Message

In case of an error the screen will display the cause of error and emit
an audible sound.

Incorrect polarity connected.

This diagram shows
the correct way to
connect your battery to
check the resistance.

BA T T/ P RO GR A M
BA T T RE S IS TA N CE

Sta rt
Ent er

01 2 0 05 0 0 5 mΩ

00 6 0 08 0 0 6 mΩ

IN C

TA T AL :42 mΩ

01 2 00 5 0 05 mΩ
00 6 00 8 0 06 mΩ

STOP STATUS START

Lithium Battery Pack

Press the START/ENTER to enter the Lithium
Battery Resistance program.

The screen indicate each cell's resistance.

The screen indicate the total resistance, the
highest resistance and the lowest resistance.

CE LL N O T MA TC H

VO LT E R RO R

CE LL V O LT E RR OR

WR ON G B AT T TY PE

SU PP L Y VO LT
TO O HI G H

SU PP L Y VO LT
TO O LO W

IN TE R NA L TE MP .
TO O HI G H

BA TT T E MP ER AT U RE
TO O HI G H

OV ER C H AR GE
CA PA C IT Y LI MI T

OV ER T I ME L IM IT

· 34 B6 V2 35 ·B6 V2

The battery is interrupted.

The battery cell you sent is different from what
charger detected.

Battery voltage wrong.

One cell voltage of your battery is too high.

Wrong battery type.

Input voltage higher than 18V

Input voltage less than 11V

The internal temperature of the unit goes too high.

The external temperature of the battery goes
too high.

The battery capacity is more than the maximum
capacity which the user sets.

The charging time is longer than the maximum
charging time which the user sets.

The Set Contains

Specification

THESETCONTAINS

1. SKYRC B6 V2 Charger

2. DC Input Cable

3. Dean Charging Cable

4. Bare charging cable

5. Instruction Manual

2

3

4

DC Input Voltage:11-18V
Display Type: 2x16 LCD Display Backlight: Blue
Case Material: Aluminium Controls: Four Buttons
Case Size: 115x84x31mm Weight: 238g
External Port: 1-6S Balance Socket-XH, Temperature Probe Socket,
Battery Socket, DC Input.
Delta Peak Detection for NiMH/NiCd: 3-15mV/cell / Default: 4mV/cell
Battery Cutoff Temperature: 20ºC/68ºF-80ºC/176ºF(adjustable)
Charge Voltage: NiMH/NiCd: Delta peak detection
 LiPo: 4.18-4.25V/cell
LiHV:4.25-4.35V/cell

Instruction Manual

ersion 1.00]

[Version 1.00]

LiFe: 3.58-3.7V/cell
LiIon: 4.08-4.2V/cell
Balance Current: 300mA/cell
Reading Voltage Range: 0.1-26.1V/cell
Battery Types/Cells: LiPo/LiHV/LiFe/LiIon: 1-6cells

1

5

NiMH/NiCd: 1-15cells
 Pb: 2-20V
Battery Capacity Range: NiMH/NiCd: 100-50000mAh
LiPo/LiHV/LiFe/LiIon: 100-50000mAh
Pb: 100-50000mAh
Charge Current: NiMH/NiCd/LiPo/LiHV/LiFe/Li-ION/Pb: 0.1A-6.0A

RECOMMENDED ACCESSORIES

4mm
5mm

DJI Mavic/TB4X: 4A
Safety Timer: 1-720minutes off
Charge Wattage: 60W
Discharge Current: 0.1A-2.0A
Discharge Cut-off Voltage: NiMH/NiCd: 0.1-1.1V/cell

Tamiya Charging Cable

SK-600023-12

Dean Charging Cable

SK-600023-15

4mm/5mm Bullet

Charging Cable for 2S Battery

SK-600023-14

LiPo: 3.0-3.3V/cell LiHV: 3.1-3.4V/Cell
LiFe: 2.6-2.9V/cell LiIon: 2.9—3.2V/cell
Pb: 1.8-2.0V/cell
Discharge Wattage: 5W
Balance Cells: 2-6 cells
Memory: 10 different charge/discharge profiles
Charge Method: CC/CV for lithium types and lead (Pb) batteries

Ec3 Charging Cable

SK-600023-13

Temperature Sensor

SK-600040-01

Delta-peak Sensitivity for NiMH/NiCd.

· 36 B6 V2 37 ·B6 V2

Pb Normal:2.4V/cell
Pb AGM:2.45V/cell
Pb Cold:2.45V/cell

Conformity Declaration Regulatory Information

SkyRC B6 V2 satisfy all relevant and mandatory EC directives and FCC
Part 15 Subpart B.

EN 55014-1:2006
+ A1:2009+A2:2011

EN 55014-2:1997+
A1:2001+ A2:2008

FCC Part 15, Subpart B

This symbol means that you must dispose of electrical from the
General household waste when it reaches the end of its useful
life. Take your charger to your local waste collection point or

recycling centre. This applies to all countries of the European Union,
and to other European countries with a separate waste collection
system.

Electromagnetic compatibility-Requirements
for household appliances, electric tools and
Similar apparatus – Part 1: Emission

Electromagnetic compatibility-Requirements
for household appliances, electric tools and
Similar apparatus – Part 2: Immunity-Product
family standard

Radiated Emission

FCC Note:

This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that
may cause undesired operation.

The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications or change to this equipment.
Such modifications or change could void the user's authority to
operate the equipment.

This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

To maintain compliance with FCC's RF exposure guidelines, this
equipment should be installed and operated with a minimum distance
of 20cm between the radiator and your body.

· 38 B6 V2 39 ·B6 V2

Commonly Used Terms

Commonly used terms

Final charge voltage: the voltage at which the battery's charge limit
(capacity limit) is reached. The charge process switches from a high
current to a low maintenance rate (trickle charge) at this point. From
this point on further high current charging would cause overheating
and eventual terminal damage to the pack.

Final discharge voltage: the voltage at which the battery's discharge
limit is reached. The chemical composition of the batteries determines
the level of this voltage. Below this voltage the battery enters the deep
discharge zone. Individual cells within the pack may become reverse
polarized in this condition, and this can cause permanent damage.

A, mA: unit of measurement relating to charge or discharge
current.1000 mA = 1 A (A=Ampere,mA=Milliampere)

Ah, mAh: unit of measurement for the capacity of a battery (Amperes
x time unit; h = hour). If a pack is charged for one hour at a current of 2
A, it has been fed 2 Ah of energy. It receives the same quantity of
charge (2 Ah) if it is charged for 4 hours at 0.5 A, or 15 minutes (=1/4
h) at 8 A.

'C'-rating: Capacity is also referred to as the 'C' rating. Some battery
suppliers recommend charge and discharge currents based on the
battery 'C' rating. A battery's '1C' current is the same number as the
battery's rated capacity number, but noted in mA or amps. A 600mAh
battery has a 1C current value of 600mA, and a 3C current value of (3
x 600mA) 1800mA or 1.8A. The 1C current value for a 3200mAh
battery would be 3200mA (3.2A).

Nominal voltage(V): The nominal voltage of the battery pack can be
determined as follows;

-.NiCd or NiMH: multiply the total number of cells in the pack by 1.2. A
8-cell pack will have a nominal voltage of 9.6 volts (8x1.2).

-.LiPo: multiply the total number of cells in the pack by 3.7. A 3-cell
LiPo wired in series will have a nominal voltage of 11.1 volts (3x3.7).

-.LiIo: multiply the total number of cells in the pack by 3.6. A 2-cell LiIo
wired in series will have a nominal voltage of 7.2 volts (2x3.6).

-.LiFe: multiply the total number of cells in the pack by 3.3. A 4-cell LiIo
wired in series will have a nominal voltage of 13.2 volts (4x3.3).
If the nominal voltage of the battery is not printed on the battery's label,
consult your battery manufacturer or supplier. Do not guess the rated
voltage of battery.

Warranty and Service

Liability exclusion

This charger is designed and approved exclusively for use with the types of
battery stated in this Instruction Manual. SkyRC accepts no liability of any
kind if the charger is used for any purpose other than that stated.
We are unable to ensure that you follow the instructions supplied with the
charger, and we have no control over the methods you employ for using,
operating and maintaining the device. For this reason we are obliged to
deny all liability for loss, damage or costs which are incurred due to the
incompetent or incorrect use and operation of our products, or which are
connected with such operation in any way.Unless otherwise prescribed by
law, our obligation to pay compensation, regardless of the legal argument
employed, is limited to the invoice value of those SkyRC products which
were immediately and directly involved in the event in which the damage
occurred.

Warranty and service

We guarantee this product to be free of manufacturing and assembly defects

for a period of one year from the time of purchase. The warranty only applies

to material or operational defects, which are present at the time of purchase.

During that period, we will repair or replace free of service charge for products

deemed defective due to those causes.

This warranty is not valid for any damage or subsequent damage arising as a

result of misuse, modification or as a result of failure to observe the procedures

outlined in this manual.

Note:

The warranty service is valid in China only.

1.

2.

If you need warranty service overseas, please contact your dealer in the
first instance, who is responsible for processing guarantee claims
overseas. Due to high shipping cost, complicated custom clearance
procedures to send back to China. Please understand SkyRC can't
provide warranty service to overseas end user directly.

If you have any questions which are not mentioned in the manual,

3.
please feel free to send email to [e-mail]

· 40 B6 V2 41 ·B6 V2
