Sky Phone SKYMINI User Manual

GSM Telephone mobile User Manual

Phone Specifications

2 Before Using Your Phone ............................................ 4

2.1 Fitting SIM card ........................................................... 4

2.2 Fitting the battery ........................................................ 4

2.3 Removing the battery .................................................. 5

2.4 Charging the battery ................................................... 5

2.5 PIN ............................................................................. 6

3 Basic Function Description.......................................... 7

3.1 Turning the phone on .................................................. 7

3.2 Inquiring I MEI (International MobileEquipment Identity)

.......................................................................... 9

3.3 Making a call ............................................................... 9

3.4 Reject incoming call .................................................. 10

3.5 Answering a call ........................................................ 10

3.6 Adjusting volume ...................................................... 11

3.7 Ending a call ............................................................. 11

3.8 Emergency service ................................................... 11

3.9 Making international call ........................................... 12

3.10 Extension number dialing .......................................... 12

3.11 Missed /Answered/Dialed calls ................................. 12

3.12 Call forwarding .......................................................... 14

3.13 Call waiting ............................................................... 14

3.14 Call restriction ........................................................... 15

3.15 Hold on call ............................................................... 15

3.16 Switching off your phone ........................................... 16

4. Restore factory Seting

1. Phone Specifications

2 Before Using Your Phone

2.1 Fitting SIM card

！·Please keep SIM card away from children.

·Any scratch or bending of SIM card may damage

SIM card easily; Therefore, pay special attention while inserting, removing or storing SIM card.

·Before removing SIM card, be sure power is off and remove the battery. Turn the phone to ba ck side; unlock the latch and insert the SIM card into SIM card retainer, then lo ck the latch (as shown by the arrow). While fitting the SIM card, be sure that metal contact clip of SIM card is downward and the corner clip is at lower right corner (as shown in the figure).

2.2 Fitting the battery

Put the battery at the back of phone, put the battery toward the bottom of the phone, insert the back cover and lock it in position (as shown by the arrow).

2.3 Removing the battery

Turn the phone to back side, pull down the release latch to remove the back cover, lift up the battery and remove it from the phone. All settings or data saved in SIM card and the phone may be lost after you remove the battery.

2.4 Charging the battery

Attach battery charger plug marked with an arrow to the charging slot at the bottom of the phone. After the connection of battery charger, the grid of battery level icon scrolls on the top right corner of the display. When the grid stops scrolling and battery indicator shows full grid, the battery is fully charged; press the button on the two sides of charges to remove the plug. ！·When the battery is in low capacity, alarm

information appears on internal display and the indicator shows no power. The phone will turn off

automatically when the power is extremely low. Don’t keep the battery in low capacity for long time; otherwise, it will damage the battery and shorten its service life.

·Please use the specified battery charger to ensure that the phone works normally.

2.5 PIN PIN

The PIN (Personal Identification Number) protects your SIM card against unauthorized use. Generally PIN is provided with SIM by network operator. If you input incorrect PIN for three consecutive times, the SIM card will be locked; input PUK code to unlock it; please contact network operator for details. PIN2 The PIN2 is also provided with SIM card by network operator because it is required to input the PIN2 to

use some function (unit of accounting, fixed dialing number). If you input incorrect PIN2 for three consecutive times, the phone will be locked; it is required to input PUK2 code to unlock the phone; please contact network operator for details. PUK code To unlock SIM card, PUK code is required; Generally PUK code is provided with SIM card; otherwise, you should contact service provider to acquire PUK code; if you lose this PUK code, please contact service provider.

3 . Basic Function Description

3.1 Turning the phone on

1. Long press red button to turn your phone on; then

backlight is on and instant animation appears.

If SIM card is not installed or i n poor contact; alarm prompt appears; press red button to turn off your phone, and re-install SIM card. ！In case SIM card is not installed or in poor contact,

your phone will not enter menu mode, only emergency call is available.

2. In case SIM card is being protected by PIN, the

prompt—“Input PIN” appears; please input correct PIN and press left soft button to confirm.

3. In case that SIM card is locked, the prompt—input PUK code, will appear.

4. The phone will search network automatically after you turn it on. ！When the phone has searched the authorized

network, network name and signal strength will appear on the display; in case the phone fails to search the authorized network, only emergency
