Skymsen TA4 User manual

METALÚRGICA SIEMSEN LTDA.

Rodovia Ivo Silveira - km 12, nº 9525, Galpão 1 - Bairro: Bateas - CEP: 88355-202

Fone: +55 47 3211 6000 - Fax: +55 47 3211 6020

www.siemsen.com.br - [email protected]

CNPJ: 82.983.032/0001-19

Brusque - Santa Catarina - Brasil

50280.4 - INGLÊS

Data de Correção: 10/01/2014

- Besides this equipment, a complete range of other products are manufactured, consult our dealers.

the informaon contained in the p resent Instrucon Manual may be mod iﬁed without previous noce.

- Due to the constant improvements introduced to our equipments,

HIGH ROTATION STAINLESS STEEL BLENDER,SEAMLESS

STAINLESS STEEL CUP

MODEL

TA-04MB-N

SUMÁRIO

1. Introducon ......................................................................................3

1.1 Safety .................................................................................................................... 3

1.2 Main Components ................................................................................................. 6

1.3 Technical Characteristcs ......................................................................................... 7

2. Instalaon and Pre-Operaon ........................................................... 7

2.1 Installaon ............................................................................................................ 7

2.2 Pre Operaon ........................................................................................................ 8

3. Operaon .......................................................................................... 9

3.1 Starng ....................... .............................................. ....................................... ...... 9

3.2 Feeding Procedures ............................................................................................... 9

3.3 Cleaning ................................................................................................................11

3.4 Cauons with Stainless Steel: ...............................................................................12

4. General Safety Pracces .................................................................. 13

4.1 Basic Operaon Pracces ....................................................... ...............................13

4.2 Safety Procedures and Notes before Switching the Machine ON ...........................14

4.3 Roune Inspecon ......................................... ....................................... ................15

4.4 Operaon .............................................................................................................15

4.5 Aer Finishing The Work ............................. ........................ ............... ................... 15

4.6 Maintenance ........................................................................................................16

4.7 Advice ..................................................................................................................16

5. Analysis and Problems Solving ........................................................ 17

5.1 Problem, causes and soluons . ............................................................................17

6. Norms ............................................................................................. 19

7. Maintenance ................................................................................... 19

8. Electric Diagram ............................................................................... 20

___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________

2

23

___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________

1. Introducon

1.1 Safety

This equipment if not correctly used is potenally dangerous, Maintenance, cleaning or any other services shall be performed by a qualiﬁed person, with the equipment unplugged.

To avoid accidents respect the following instrucons:

1.1.1 Read completely these instrucons.

1.1.2 To avoid to risk electric shocks and damage to the equipment never use it with wet clothes or shoes and/or standing on wet ﬂoors. Do not plunge it into water nor any other liquid, do not spray water directly to the equipment.

1.1.3 When the equipment is in operaon the operator shall supervise it , principally when children might be near.

1.1.4 Unplug the equipment when: It is not in use, before to clean it, before to remove or

to place some accessory. Before maintenance or any other service.

1.1.5 Do not operate the equipment if the cord or plug are damaged. Do not lean the cord on table edges, nor let them lie on hot surfaces.

1.1.6 When the equipment may have fall, have been damaged any way, or simply does not work, take it to Technical Assistance to check.

1.1.7 The use of accessories not recommended by the manufacturer may cause corporal damages.

1.1.8 Keep the hands or any other object away from moving parts while the equipment is

in operaon.

1.1.9 During operaon, never wear loose clothes with wide sleeves principally around

the wrists.

1.1.10 Make sure the equipment voltage and the network voltage are the same, and the

equipment has been solidly grounded.

1.1.11 Knife blades are very sharp, handle with care.

1.1.12 Always place the Cup Lid # 02 (Pic. 01) on the lid before to switch ON the blender.

1.1.13 Always hold the Cup # 03 (Pic. 01) as long the blender is operang. If the Cup turns

22

3

loose switch immediately OFF the blender.

1.1.14 When blending hot liquids, remove the Cap # 01 (Pic 01) and keep the hands oﬀ the Lid oriﬁce avoiding occasional burnings.

1.1.15 Never touch the knife when the blender is operang.

1.1.16 When installing the blender ground it properly in accordance with local

recommendaons.

1.1.17 Do not use the blender outside.

1.1.18 Do not let the blender operate without supervision.

1.1.19 Your blender does not replace any other kitchen appliance. It is not supposed to

make mashed potatoes, it does not blend egg white or any other cream for covering, it does not grind raw meat, it does not blend hard pastas and does not extract kernels from

fruit and vegetables.

1.1.20 Remember that this kind of blender works in seconds and not in minutes. Therefore, never let your blender working for more than one minute. It is beer to switch it oﬀ and check the mixing consistency aer a few seconds to avoid over blending.

1.1.21 Overload the motor with big or heavy porons, since it will decrease the blender’s lifespan. If the motor stops, immediately switch it oﬀ, unplug and remove part of the load

before restarng the operaon.

1.1.22 For your safety, the temperature of the processed products shall not exceed 40 °C.

___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________

4

21

8. Electric Diagram

IMPORTANT

Make sure the cord is in perfect condions for use. If it is not, change it for a new

one in accordance with the technical speciﬁcaons and safety rules.

The substuon shall be made by a qualiﬁed professional, and shall respect the

local safety norms.

IMPORTANT

This equipment must not be used by children or any persons with reduced

physical or mental aptness, lack of experience or knowledge, unless they are

under supervision or have received from the person responsible for safety, proper

instrucons on how to use the equipment.

20

IMPORTANT

Children shall be watched in order to avoid them to play with the equipment.

IMPORTANT

In case of emergency take oﬀ the plug from its socket.

IMPORTANT

Never spray water directly on to the equipment.

5

1. 2 Main Components

6. Norms

All components are made with carefully selected materials, in accordance with Siemsen experience and standard tesng procedures.

Picture 01

01

02

03

04

07

The following Norms apply:

ABNT NBR NM 60335-1 IEC 60335-2-64

7. Maintenance

Maintenance must be considered a set of procedures with the purpose to keep the

equipment best operang condions , therefore increasing the equipment life and safety.

* Cleaning – check item 3,3 Cleaning.

* Wiring - Check all wires regarding deteriorate condions as well as all electric contacts (terminals) regarding ghtening and corrosion.

*Contacts – ON/OFF switch, emergency buon, reset buon , electronic circuits etc, check the equipment in order to assure that all components are correctly working and the

equipment operaon is normal.

* Installaon – make sure the installaon followed item 2.1 instrucons.

1 – Each month check:

- Check the electrical installaon.

- Measure the voltage at the socket.

- Measure the working current and match it with the nominal current.

- Check the ghtening of all electric terminals to avoid bad contacts.

- Check electric motor sha clearance.

- Check the wiring for overheang, insulaon failures and mechanical damages.

06

01 - Cap 02 - Lid 03 - Cup 04 - Housing

6

05 - On/oﬀ Switch

06 - Feet 07 - General Key

05

2 – Each three month checks:

- Check electrical components such as ON/OFF switch, emergency buon, reset buon, electronic and electric circuits, overheang, insulaon failings, or mechanical damages.

- Check bearings clearances.

- Check retainers, O’rings, V’rings and other seals.

19

Table 02

PROBLEM CAUSES SOLUTIONS

- Electricity shortage.

- The blender does no switch

ON.

- Burning smell or smoke.

- The blender starts, but aer to place the ingredients inside the cup , the blender rotaon

is too low.

- Damaged cord. - Problem during transportaon. - Call technical assistance.

-Unusual noises. - Damaged bearing - Call technical assistance.

- Prob le m w i t h t he

blender electric circuit.

- Problem with the blender

electric Circuits.

- Problem with the motor. - Call technical assistance.

- Check electricity.

- Call technical assistance.

1.3 Caracteríscas Técnicas

QUADRO 01

CARACTERÍSITCAS UNIDADE TA-04MB-N

Capacidade máxima do copo l4

Voltage (*) V 220

Frequency Hz 50 / 60 Power Rang W 590 Consumpon kW/h 0,59

Height mm 710

Width mm 270 Depth mm 240

Net Weight kg 4,6

Shipping Weight kg 5,7

2. Installaon and Pre Operaon

2.1 Installaon

2.1.1 Placing

The Blender is to be installed onto a leveled surface approximately 850mm high.

- Product pieces too large do not

-The product does not process.

- Cup is leaking. - Damaged seal. - Call technical assistance.

allow contact with the knife.

- Blunt knife.

- Cut smaller pieces about 3,5 cm.

- Call technical assistance.

18

2.1.2 Electrical Installaon

This equipment was developed to be used with: 220V. Upon receiving the Blender control

the voltage indicated on the cord label.

The cord has a plug with three pins one of them is grounding. It is mandatory the three

pins to be connected before to start to use the blender.

7

IMPORTANT

Make sure that the network voltage is the same as the machine voltage.

2.2 Pre Operaon

Before using the machine all parts that get in contact with food must be washed with running water and neutral soap. To clean your Blender read item 3.3 Cleaning.

Make sure the blender is stable on its working place.

2.2.1 Placing the Cup

The Cup # 03 (Pic. 1) has a placing system allowing it to be easy and safely ﬁed

To remove the Cup just li it using the handle .

Always remove or replace the Cup holding it ﬁrmly by its handle.

IMPORTANT

Never remove or place tha Cup with the Blender switched ON.

5. Analysis and Problems Solving

5.1 Problem, causes and soluons

The Blenders were designed to operate with the need of minimum maintenance but the natural wearing caused by longer use of the equipment may occasionally cause some malfuncons.

If such problem occurs with your Blender refer to Table 02 in which the most common

situaons are listed with recommended soluons.

2.2.2 Placing the Lid

The Cup has a Lid (pic. 02) developed with non toxic material assuring an eﬃcient seal while processing. Make sure the lid is correctly placed on the cup as you may see picture 02 below.

Picture 02

8

17

4.6 Maintenance

2.2.3 Placing the Cap

4.6.1 Danger

Any maintenance with the machine in working situaon is dangerous.

TURN IT OFF BY PULLING THE PLUG OFF THE SOCKET DURING MAINTENANCE.

IMPORTANT

Always unplug the machine when emergency cases arise.

4.7 Advice

Electrical or mechanical maintenance must be done by qualiﬁed personal for such

operaon.

Person in charge has to be sure that the machine is under TOTAL SAFETY condions when

working.

The Cap (Pic.03) may be used to watch the process and also to add ingredients.

To remove it just turn it clockwise, and when loose li it.

Picture 03

16

3 . Operaon

3.1 Starng

Plug the device into the outlet;

Turn the main switch;

The Blender is started by pressing the ON/Oﬀ Switch # 05 (Pic.01) to posion “I“.

To switch OFF the blender press the ON/OFF Switch to posion “O “.

3.2 Feeding Procedures

Before to use the blender all the parts in contact with the product shall be washed with water and neutral soap (read item 3.3 cleaning).

Make sure the equipment is stable on its working place.

9

Remove the Lid with its Cap from the Cup.

With the blender switched OFF put inside the Cup ﬁrst the receipt liquid ingredients and only aer the ingredients having more consistence.

IMPORTANT

Cut the products in small size pieces of about 3,5 cm. This will help the blending

process me principally with frozen products.

When blending ice add some water.

Place the Lid and the Cap following instrucon given at item 2.2.2 and 2.2.3.

MPORTANT

Do not use the blender to process heavy dough .

4.3 Roune Inspecon

4.3.1 Advice

When checking the tension of the belts or chains, DO NOT introduce your ﬁngers between the belts and the pulleys and nor between the chain and the gears.

4.3.2 Precauons

Check if motors and sliding or turning parts of the machine produce abnormal noises.

Check the tension of the belts and chains and replace the set when belt or chain show signs of being worn out.

When checking tensions of belts or chain DO NOT introduce your ﬁngers between belts and pulleys, nor between the chains and gears.

Check protecons and safety devices to make sure they are working properly.

4.4 Operaon

4.4.1 Advice

Be sure your hair is not loose in order to avoid geng caught by turning parts which could

lead to a serious accident. Tie your hair well up and/or cover your head with a scarf. The operaon performed by not trained or skilled personnel shall be forbidden.

- Never touch turning parts with your hands or in any other way.

- NEVER operate machine without all original safety devices under perfect condions.

IMPORTANT

The blending me may be diﬀerent for diﬀerent products kinds.

When blending solid ingredients add some liquid, not following such precauon

may create an overheang that will damage the seal.

IMPORTANT

Never switch the machine on without load in it because it will cause irreparable

damages.

10

4.5 Aer Finishing The Work

4.5.1 Precauons

Always TURN THE MACHINE OFF by removing the plug from the socket before cleaning the

machine.

Never clean the machine unless it has come to a COMPLETE STOP.

Put all components back to their funconal posions before turning it ON again.

DO NOT place your ﬁngers in between belts and pulleys nor chains and gears.

15

4.1.3 Advices

In case of power shortage, immediately turn the machine OFF.

- Use recommended or equivalent lubricants, oils or greases.

- Avoid mechanical shocks as they may cause failures or malfuncon.

- Avoid penetraon of water, dirt or dust into mechanical or electrical components of the machine.

- DO NOT MODIFY original characteriscs of the machine.

- DO NOT REMOVE, TEAR OFF or MACULATE ANY SAFETY or IDENTIFICATION LABELS stuck

on the machine. If any label has been removed or is no longer legible, contact your nearest dealer for replacement.

4.2 Safety Procedures and Notes Before Switching Machine ON

IIMPORTANT

Carefully read ALL INSTRUCTIONS of this manual before turning the machine ON.

Be sure to be familiar with the instrucons and that you have well understood

all informaon contained in this manual. If you have any queson contact your

supervisor or your nearest Dealer.

4.2.1 Danger

An electric cable or electric wire with damaged jacket or bad insulaon could cause electrical shocks as well as electrical leak. Before use, check condions of all wires and

cables.

3.3 Cleaning

IMPORTANT

Never do cleaning with the machine plugged in. Always unplug the machine

before cleaning.

The blender shall be totally cleaned and sanitary:

- Before to be used ﬁrst me;

- Aer daily operaon is ﬁnished;

- When it has not be used for a long me;

Some parts of the blender may be removed to be cleaned:

-Cup # 03 (Pic.01);

-Lid # 02 (Pic.01);

-Cap # 01 (Pic.01).

Clean all the parts with water and neutral soap.

4.2.2 Advices

Be sure ALL INSTRUCTIONS in this manual have been thoroughly understood. Every funcon and operaonal procedure have to be very clear to the operator. Contact your nearest Dealer for further quesons.

Any manual command (switch, buon or lever) shall be given only aer being sure it is the correct one.

4.2.3 Precauons

The electric cable has to be compable with the power required by the machine. Cables

touching the ﬂoor or close to the machine need to be protected against short circuits.

14

IMPORTANT

Do not spray water directly on to the blender.

11

3.4 Cauons with Stainless Steel:

4. General Safety Pracces

The Stainless Steel may present rust signs, which ARE ALWAYS CAUSED BY EXTERNAL AGENTS, especially when the cleaning or sanizaon is not constant and appropriate.

The Stainless Steel resistance towards corrosion is mainly due to the presence of chrome, which in contact with oxygen allows the formaon of a very thin protecve coat. This

protecve coat is formed through the whole surface of the steel, blocking the acon of external corrosive agents.

When the protecve coat is broken, the corrosion process begins, being possible to avoid it by means of constant and adequate cleaning.

Cleaning must always be done immediately aer using the equipment. For such end, use water, neutral soap or detergent, and clean the equipment with a so cloth or a nylon sponge. Then rinse it with plain running water, and dry immediately with a so cloth, this way avoiding humidity on surfaces and especially on gaps.

The rinsing and drying processes are extremely important to prevent stains and corrosion from arising.

IMPORTANT

Acid soluons, salty soluons, disinfectants and some sterilizing soluons (hypochlorites, tetravalent ammonia salts, iodine compounds, nitric acid and others), must be AVOIDED, once it cannot remain for long in contact with the

stainless steel.

IMPORTANTE

Caso algum item das NOÇÕES GERAIS DE SEGURANÇA, não se aplique ao seu

produto, favor desconsiderar.

The following safety instrucons are addressed to both the operator of the machine as well as the person in charge of maintenance.

The machine has to be delivered to the operator in perfect condions of use by the Distributor to the user. The user shall operate the machine only aer being well acquainted

with the safety procedures described in the present manual. READ THIS MANUAL WITH

ATTENTION.

4.1 Basic Operaon Pracces

4.1.1 Dangerous parts

Some parts of the electric devices are connected to high voltage points. These parts when

touched may cause severe electrical shocks or even be FATAL.

Never touch commands such as buons, switches and knobs with wet hands, wet clothes and/or shoes. By not following these instrucons operator could be exposed to severe electrical shocks or even to a FATAL situaon.

4.1.2 Warnings

These substances aack the stainless steel due to the CHLORINE on its composion,

causing corrosion spots (ping). Even detergents used in domesc cleaning must not remain in contact with the stainless steel longer than the necessary, being mandatory to remove it with plain water and then

dry the surface completely.

Use of abrasives:

Sponges or steel wool and carbon steel brushes, besides scratching the surface

and compromising the stainless steel protecon, leave parcles that rust and react contaminang the stainless steel. That is why such products must not be used for cleaning and sanizaon. Scrapings made with sharp instruments or similar must also be avoided.

Main substances that cause stainless steel corrosion: Dust, grease, acid soluons such as vinegar, fruit juices, etc., saltern soluons (brine),

blood, detergents (except for the neutral ones), common steel parcles, residue of sponges or common steel wool, and also other abrasives.

12

The operator has to be well familiar with the posion of ON/OFF Switch to make sure the Switch is easy to be reached when necessary. Before any kind of maintenance, physically

remove plug from the socket.

Provide space for a comfortable operaon thus avoiding accidents.

Water or oil spilled on the ﬂoor will turn it slippery and dangerous. Make sure the ﬂoor is

clean and dry.

Before giving any manual command (switch, buons, turn keys or lever) be sure the

command is the correct one. Check this manual for further details if necessary.

Never use a manual command (switch, buons, lever) unadvisedly. If any work is to be made by two or more persons, coordinaon signs will have to be given

for each operaon step. Every step of the operaon shall be taken only if the sign has been made and responded.

13
