sks il vetro Audio Operating Instructions Manual

Bedienungsanleitung
Operating Instructions
Notice d‘utilisation
il vetro Audio
Version 1.1
Deutsch
Nachdem das Gerät angeklingelt wurde, die Sprechtaste betätigen.
Wechselsprechen
Ist das Gespräch angenommen, kann mit der Sprechtaste auch das Freisprechen deaktiviert werden. So lange die Sprechtaste gedrückt wird, ist das Sprechen von Innensprechstelle zur Türsta­tion möglich. Bei nicht gedrückter Sprechtaste ist die Sprechrichtung von der Türstation zur Innen­sprechstelle. Die Wechselsprech-Funktion ist nur
für die Dauer des Gesprächs aktiv.
Rufabschaltung
Halten Sie die Rufabschalttaste solange gedrückt (ca. 5 Sekunden), bis sie die Bestätigungstöne (3 gleichlange Töne) hören. Der Rufton ist jetzt abge­schaltet. Um auf diesen Zustand hinzuweisen, blinkt die Türöffnertaste im Sekundentakt.
Der Rufton wird automatisch nach 12 Stun­den oder nach Spannungsausfall wieder
eingeschaltet.
Rufeinschaltung
Tippen Sie kurz die Rufabschalttaste. Sie hören einen durchgehenden hohen Signalton. Der Rufton ist jetzt wieder eingeschaltet.
Tür öffnen
Wurde das Gerät angeklingelt, kann innerhalb von 2,5 Minuten mit der Türöffnertaste die Tür geöffnet werden.
Deutsch
+ Hausrufklingelton ändern
Die Tontaste gedrückt halten und anschließend die Türöffnertaste innerhalb von 2 Sekunden kurz drücken. Mit jedem Tastendruck der Türöffnertaste erklingt eine andere Melodie. Wird die gewünschte Melodie abgespielt, lassen Sie beide Tasten los. Es stehen 8 verschiedene Kingeltöne zur Auswahl.
+ Etagenrufklingelton ändern
Die Tontaste gedrückt halten und anschließend die Türöffnertaste innerhalb von 2 Sekunden drücken und gedrückt halten. Warten Sie bis die gewünsch­te Melodie ertönt. Lassen Sie beide Tasten los. Es stehen 4 verschiedene Etagenruftöne zur Aus­wahl.
Klingellautstärke ändern
Die Tontaste gedrückt halten, bis die gewünschte Lautstärke erreicht ist. Die Lautstärke ist 5-stufig einstellbar.
+ Licht- und Sondertaste
Die Sondertaste „S“ wird zum Aktivieren des
Schaltaktors 4507 verwendet. Die Lichttaste ist standardmäßig zum Schalten des Schaltaktors 4507 verwendet. Sie kann optional als potenzial­freier Kontakt konfiguriert werden. Wenn Sie die
Funktion „potenzialfreier Kontakt“ benötigen, teilen
Sie uns das bei Auftragsvergabe bitte mit! Drücken Sie die gewünschte Taste bis der Bestäti­gungston zu hören ist.
+ Internruf
Deutsch
Die Funktion „Internruf“ ist nur beim Sondermodell möglich, wenn Sie die Funktion benötigen, teilen Sie dies bitte bei Auftragsvergabe mit. Die Sprechtaste drücken und wieder los lassen und danach die für den Internruf konfigurierte Taste gedrückt halten bis der Bestätigungston ausgegeben wird.
Pflegehinweise
Reinigen Sie die Sprechstelle nur mit einem wei­chen Tuch, welches mit einer milden Seifenlösung angefeuchtet ist. Trockene Reinigung, aggressive Reiniger und Scheuermittel können die Oberfläche beschädigen.
Service
Für die Gewährleistung gelten die gesetzlichen Bestimmungen. Der Austausch des Gerätes im
Servicefall erfolgt durch Ihren Elektroinstallateur.
Accepting a call
English
Press the speech key after the door bell rings.
Two-way calling
After you have accepted the call, you can deacti­vate the "hands-free call" function by pressing the speech key. Communication from the internal unit to the door unit is possible for as long as you press the speech key. If the speech key is not pressed, then only communication from the door unit to the internal unit is possible. The "two-way call" function is only activated for the duration of
the call.
Switching off the ring tone
Press the ring-tone on/off key continuously (for approx. 5 seconds) until you hear 3 equally long confirmation tones. The ring tone is now switched off. The open door key flashes once per second to confirm this.
After 12 hours or after a power supply cut­off, the ring tone is automatically switched back on.
Switching on the ring tone
Press the ring-tone on/off key briefly. You will hear an uninterrupted high tone. The ring tone is now switched on again.
Opening the door
When the door bell rings, you have 2.5 minutes to open the door with the open door key.
+ Changing the ring tone for
English
Press the ring tone key continuously and then briefly press the open door key within 2 seconds. With every press of the open door key, you will hear a different tone. When you hear the desired tone, release both keys. You can choose from 8 different ring tones.
apartment calls
+ Changing the ring tone for
Press the ring tone key continuously and, within 2 seconds, also press the open door key without releasing it. Wait until you hear the desired ring tone. Release both keys. You can choose from 4 different ring tones.
floor calls
Modifying the volume of the ring
tone
Press the ring tone key continuously until the desired volume has been reached. You can set the volume to 5 levels.
+ Light key and special key
The special key “S” is used to activate the switch
actuator 4507. The light key is normally used to switch the switch actuator 4507. As an option, this key can also be configured as a potential-free contact. If you would like the "potential-free con­tact" option, please notify us when you place your order. Press the required key until you hear a confirma­tion tone.
+ Internal call
English
The "internal call" function is only available on the special model. If you would like this function, please state this when you place your order. Press the speech key and release. After that, press the internal call key continuously until you hear a confirmation tone.
Care of your phone
Only ever clean your intercom using a soft cloth dampened with mild soap solution. Dry cleaning, aggressive cleaning agents and abrasives can damage the surface.
Servicing
Statutory warranty conditions apply. Exchange of the device in case of servicing must be performed by your electrical installer.
Entamer une conversation
Français
Lorsque quelqu’un a sonné, appuyez sur la touche de conversation.
Converser
Dès que vous avez entamé une conversation, vous pouvez désactiver la fonction « communication mains libres » en appuyant sur la touche de con­versation. Tant que vous appuyez sur la touche de conversation, une communication du poste inté­rieur vers le poste extérieur est possible. Si vous
n’appuyez pas sur la touche de conversation,
seule une communication du poste extérieur vers le poste intérieur est possible. La fonction « con­verser » n’est activée que pendant la durée de la conversation.
Désactiver la tonalité
Maintenez la touche de désactivation de la tonalité enfoncée (pendant environ 5 secondes) jusqu’à ce que vous entendiez 3 bips longs de confirmation. La tonalité est alors coupée. À titre de confirma­tion, la touche de l’ouvre-porte clignote une fois par seconde.
Au bout de 12 heures ou après une cou­pure de courant, la tonalité est réactivée automatiquement.
Activer la tonalité
Appuyez brièvement sur la touche pour désactiver la tonalité. Vous entendez un bip aigu continu. La tonalité est réactivée.
Ouvrir la porte
Français
Lorsque quelqu’un sonne, vous disposez de
2 minutes et demie pour ouvrir la porte au moyen de la touche de l’ouvre-porte.
+ Modifier la tonalité de
Maintenez la touche de réglage de la tonalité enfoncée et dans les 2 secondes, appuyez briè­vement sur la touche de l’ouvre-porte. Chaque fois que vous appuyez sur la touche de l'ouvre-porte, vous entendez une tonalité différente. Lorsque vous entendez la tonalité souhaitée, relâchez les deux touches. Vous avez le choix parmi 8 tonalités différentes.
l’appel de l’appartement
+ Modifier la tonalité de
Maintenez la touche de réglage de la tonalité enfoncée et dans les 2 secondes, appuyez briè­vement sur la touche de l’ouvre-porte et mainte­nez-la enfoncée. Attendez jusqu'à ce que vous entendiez la tonalité souhaitée. Relâchez alors les deux touches. Vous avez le choix parmi 4 tonalités différentes.
l’appel à l’étage
Modifier le volume de la tonalité
Maintenez la touche de réglage de la tonalité enfoncée jusqu’au volume souhaité. Vous pouvez régler le volume en 5 paliers.
+ Touche de l’éclairage et
Français
La touche spéciale « S » est utilisée afin d’activer
l’actionneur de commutation 4507. La touche de l’éclairage est généralement utilisée afin de com- muter l’actionneur de commutation 4507. En op-
tion, cette touche peut aussi être configurée comme un contact libre de potentiel. Si vous sou­haitez la fonction « contact libre de potentiel », veuillez le signaler à la commande.
Appuyez sur la touche de votre choix jusqu’à ce
que vous entendiez une tonalité de confirmation.
+ Appel interne
La fonction « appel interne » n’est disponible que sur le modèle spécial. Si vous souhaitez cette fonction, veuillez le signaler à la commande. Appuyez sur la touche de conversation, puis relâ­chez. Maintenez ensuite la touche d’appel interne
enfoncée jusqu’à ce que vous entendiez une
tonalité de confirmation.
Conseils d’entretien
Pour nettoyer votre téléphone, n‘utilisez qu’un chiffon doux humidifié d’une solution savonneuse
non agressive. Un nettoyage à sec, un détergent agressif et un produit abrasif peuvent endommager la surface.
touche spéciale
Service
Les dispositions légales s’appliquent à la garantie. En cas de réclamation, l’échange de l’appareil est
assuré par votre installateur-électricien.
