TME-N ActiveCore

SKOPE Top Mount Chiller Hydrocarbon

Service Manual

MAN80128 Rev. 1.0 Nov. 2018

TME-N ActiveCore SKOPE Top Mount Chiller Hydrocarbon Service Manual

MAN80128 Rev. 1.0 Nov. 2018

SKOPE Industries Limited reserve the right to alter specifications without notice.

is a registered trademark of SKOPE Industries Limited.

SKOPE INDUSTRIES LIMITED Head Office PO Box 1091, Christchurch New Zealand Freephone: 0800 947 5673 Fax: (03) 983 3896 E-mail: enquiry@skope.co.nz Website: www.skope.co.nz

Trademark Infringement

The SKOPE trademark on this product is infringed if the owner, for the time being, does any of the following:

• Applies the trade mark to the product after their state, condition, get-up or packaging has been altered in any manner

• Alters, removes (including part removal) or obliterates (including part obliteration) the trade mark on the product

• Applies any other trade mark to the product

• Adds to the product any written material that is likely to damage the reputation of the trade mark

Notice of the above contractual obligations passes to:

• Successors or assignees of the buyer

• Future owners of the product

SKOPE TME-N ActiveCore

Service Manual

iii

CONTENTS

1 Servicing Hydrocarbon

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

SKOPE HC Service Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2 Specifications

Models. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3 Electronic Controller

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

SCS Connect Field App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

SCS Connect Track App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

SKOPE Connect App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Controller Faceplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Buttons and Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Service Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

SCS Connect Field App and Track App . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

App Categories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Faults and Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4 Wiring

Model: TME650/1000N-A Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

5 Spare Parts

Main Assembly - TME650N-A Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Main Assembly - TME1000N-A Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Cabinet Assembly - TME650N-A Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Cabinet Assembly - TME1000N-A Series . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Glass Door Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Lit Sign Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Unit Assembly UTHCNI-0010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

6 Installation

Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Ventilation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Door Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Fitting Door Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Removing Door Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Shelf Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Repositioning Shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

7 Replacement Procedures

Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Sign Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Alignment Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Height Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Replacing the Gasket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Removing and Refitting the Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Adjusting Door Tension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Replacing the Torsion Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Hinge Reversal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Refrigeration Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Before Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Refrigeration Unit Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Gas Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

SKOPE TME-N ActiveCore

Service Manual

Leak Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

On-Site Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

HydrocarbonWorkshop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Removing the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Replacing the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Unit Electrics Box Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Unit Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Condenser Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Evaporator Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Compressor Electrics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Refrigeration System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Unit Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Controller Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

QC Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Replacing the Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Door Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Control Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Evaporator Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Condenser Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Ambient Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Condenser Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

8 Troubleshooting

Electronic Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Cabinet and Refrigeration Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Diagnostic Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

On-site work procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

SKOPE TME-N ActiveCore

Servicing Hydrocarbon

Service Manual

1 Servicing Hydrocarbon

Overview

This cooler utilises hydrocarbon (HC) R290 Propane as its refrigerant. Hydrocarbon is a natural refrigerant that has a very low environmental impact.

Special service requirements are needed as hydrocarbon is a flammable refrigerant.

Safety hazards

The main hydrocarbon safety hazards are:

Flammable refrigerant.

Venting of hydrocarbon and compressor oil.

Asphyxiation.

SKOPE does NOT recommend performing hazardous activities on the refrigeration system. See “Refrigeration System” on page 48 for more information including examples of hazardous activities.

Servicing Hydrocarbon

Service Manual

SKOPE TME-N ActiveCore

SKOPE HC Service Requirements

Servicing must only be performed by Approved SKOPE Service Technicians, and must meet all requirements in the SKOPE HC Service Policy (available from SKOPE), including the following:

x MUST – Ensure all workers are trained in the SAFETY of hydrocarbon products to the appropriate

level for the work required.

x MUST – Follow all Local Safety Regulations relevant to flammable refrigerant gases.

o Australia should reference - AIRAH Flammable Refrigerants – Safety Guide

o New Zealand should reference – Flammable Refrigerant Safety Documentation

(Refrigerant License NZ)

x MUST – Adhere to all on-site (workplace) Health and Safety requirements x MUST – ONLY use SKOPE OEM Spare Parts; or identical replacement parts. Any variation in

replacement part may render the system non-compliant and unsafe.

x MUST – Follow all best practice work activities for servicing hydrocarbon refrigerants (SKOPE

recommend attending specific hydrocarbon refrigeration handling training courses). Nitrogen must be used for purging system before commencing “Hot Work” – brazing.

x MUST – Adhere to relevant SKOPE Service Manual. If any contradiction, the local Regulations take

precedence over SKOPE requirements

x MUST – Work only in suitable, safe and compliant work spaces. Personal Protective Equipment

must always be used when working on Hydrocarbon equipment.

x MUST – Service people diagnosing refrigeration faults must always carry and utilise Flammable

Gas detectors when working on Hydrocarbon equipment.

x MUST – Prior to any service work; know where and how to safely and quickly isolate power supply

to cabinet

x MUST – Not perform any Hot Work (brazing etc.) in the field. These are to be completed in a

SKOPE approved hydrocarbon workshop (in a dedicated specific Hazardous Work Area for Hot Work)

x MUST – Not transport a refrigeration system with an active leak. If there is an active leak the

refrigerant must be safely removed (with use of Bullet Piercing Valve or Line Tap valves) before transporting. Valves must be removed at the hydrocarbon service depot once repair is completed.

x MUST – All hydrocarbon workshop areas must have emergency plans; that includes suitable

evacuation and fire control plans and equipment.

x MUST – Only use refrigerant grade hydrocarbon, to precise mass specified on removable

refrigeration system serial label.

x MUST – Be accurate refrigerant charge; The refrigerant mass is ultra-low charge and must only be

measured in by accurate scales to +/- 1.0gram. Refrigerant MUST not be overcharged; or added to an already charged system.

x MUST – Use identical drier replacement; as any change will affect gas charge volume; and effect

reliability compliance and safety.

x MUST – Any pipework replacement, must be identical to OEM parts. x MUST – Not introduce a sparking device inside a cabinet or inside a removable refrigeration

system. Battery drills should not be used.

x MUST – Not perform any activity that could stress a refrigeration pipe (unless in a workshop) x MUST – Have the Wellington Drive SCS Field app installed on a Bluetooth enabled device carried

by the service technician. The app should be utilised for safe, accurate diagnosis of the system and it is required to complete a controller replacement in the field.

x RECOMMENDED – Have the Wellington Drive SCS Track app installed on a Bluetooth enabled

device carried by the service technician. This passive app collects system data from the Wellington Drive SCS Connect Controller and transmit it to the cloud.

SKOPE TME-N ActiveCore

Specifications

Service Manual

2 Specifications

Models

This service manual is appli cable to the SKOPE TME ActiveCore top mount chillers detailed in the table below. Refer to the relevant product specification sheet (available on the SKOPE website: www.skope.com) for specifications.

Series Model SKOPE ID

TME650N-A ActiveCore

TME650N-A SM65GYN

TME650N-AC SM65BYN

TME1000N-A ActiveCore

TME1000N-A SM10GYN

TME1000N-AC SM10BYN

Electronic Controller

Service Manual

SKOPE TME-N ActiveCore

3 Electronic Controller

Overview

The cooler is fitted with a Wellington Drive SCS Connect electronic controller. The controller is located above the door/s and visible from the outside of the chiller.

Controller servicing can be performed via the controller faceplate, or the SCS Connect Field app.

Apps

SCS Connect

Field App

The SCS Connect Field app is designed for service techs, and provides access to the controller from mobile devices with Bluetooth capability. The app provides information on data logging, alarm notification and diagnostic control.

See “SCS Connect Field App and Track App” on page 11 for information on setting up and using the app.

SCS Connect

Track App

The SCS Connect Track app is used to upload data from chillers fitted with a Wellington SCS Connect electronic controller.

SKOPE

Connect App

The SKOPE-connect app is designed for end-users and provides wireless access to the controller from mobile devices with Bluetooth capability.

The app allows end users to adjust some electronic controller settings including energy saving modes, open/close hours and preset temperature set points for specific product.

The app may be useful for diagnostics. Download from the Google Play Store, or Apple App Store.

SKOPE TME-N ActiveCore

Electronic Controller

Service Manual

Controller Faceplate

Buttons and

Display

The controller faceplate includes the front display panel and interface buttons.

Service Mode Service mode can be accessed and used via the SCS Connect Field app

(see “SCS Connect Field App and Track App” on page 11), or the controller faceplate (see below).

Note: A 9 digit pin code is required to access service mode via the controller buttons. Contact your User Manager to receive your activation code.

To enable and use service mode via the controller faceplate

2 3 4 5

8 7

No. Description

1 Night Mode: Indicator. On during cooler night mode.

Display: Indicator. Digital display of cabinet air temperature or messages. The temperature is what the sensor inside the cooler detects, and not necessarily the product temperature. However, they may be very close depending on how the controller is set to sense temperature.

Light Switch - Night Mode (back/abort): Button. Press to switch the lights on or off. Press and hold to switch cooler between day and night mode. Used during programming.

4 Up: Button. Used for programming.

Bluetooth: Indicator. On when ready to connect to a device. Flashing when connected to a device.

Defrost Cycle (next/enter): Button. Press and hold to initiate manual defrost. Used during programming.

7 Down: Button. Used for programming.

Fault - Alarm: Indicator. On during fault or alarm. Note: Alarm message is also shown on the display during alarm.

9 Compressor: Indicator. On when the compressor is running.

10 Defrost Mode: Indicator. On during defrost cycle.

11 Fan: Indicator. ON when evaporator fan running.

1. Press and hold the up and down buttons simultaneously until prompted to enter the 9 digit pin code.

2. Enter service mode pin code.

3. Use the up, down, back/abort and next/enter buttons to navigate to the desired category.

Electronic Controller

Service Manual

SKOPE TME-N ActiveCore

There are 5 main service mode categories when accessing and using service mode via the controller faceplate:

Parameters

Provides access and editing of individual controller parameters. It is not recommended that parameters are changed unless absolutely

necessary. If incorrect parameter settings are suspected, reload the complete parameter set.

Reset

Returns the controller back to factory settings. Parameter set must be reloaded after performing a reset.

Manual test

Allows inspection of input values from sensors, and check the effects of output adjustments to peripherals, and to run preset test routines.

Statistics

Displays logged values and event counts to assist with fine tuning and diagnostics.

About

Lists the properties of the refrigeration system and the controller, including cooler model codes, firmware, hardware and software versions.

SKOPE TME-N ActiveCore

Electronic Controller

Service Manual

SCS Connect Field App and Track App

Connecting Follow the procedures below to install and set-up the app, and connect to a

controller.

Note: The SCS Connect Field app and Track app is separate from the SKOPE-connect app.

To install the SCS Connect Field app

To connect to a controller

1. Download and install the Connect Field app or Track app from Google Play or Apple Store (search for “scs wellington” to find it).

2. When you first run the app, you will be requested to enter an activation code. Contact your Service Manager or SKOPE to receive your activation code (you must be connected to the internet at the time of activation).

Your activation code is unique to you, and should NEVER be shared with anyone else, as it determines your personal access level for the app. The same code will give you access to all SCS apps you are authorised to use.

3. Once activation is complete, you must define a 4-digit PIN code. This can be any code unique to you. Each time you start the app, you will be required to enter this same PIN code. This is to prevent other people accessing the app from unlocked phones.

4. You can see which databases you are activated against from the “Settings” screen. You can be activated to more than one database at the same time. Simply select ACTIVATE ANOTHER DATABASE, and enter the new databases unique activation code, as in Step 2.

1. Check that the Bluetooth logo on the top right of the controller faceplate is lit, indicating that the controller is ready to connect to a device.

Note: A flashing Bluetooth logo indicates that the controller is currently connected to a device.

2. Open the SCS Connect Field app.

3. Select a controller to connect to from the list of visible controllers.

Note: This list is filtered by your activation permissions, so devices you are not authorised to connect to will not be displayed.

4. Select ‘connect’ to connect to the controller.

5. Check that the Bluetooth logo on the top right of the controller faceplate is flashing, indicating that the controller is connected.

Electronic Controller

Service Manual

SKOPE TME-N ActiveCore

App

Categories

Various options are available in the app menu to provide information about the connected controller and it’s cooler. Depending on user access level, some menu options may not be available.

Home screen

The home screen shows a graphic representation of the current state of the cooler being controlled.

Output control

Provides control of the controller input sensors and switches, and output relays.

Edit parameters

Provides access and editing of individual controller parameters. Note: Parameter changes must be recorded on warranty/job card.

It is not recommended that parameters are changed unless absolutely necessary. If incorrect parameter settings are suspected, reload the complete parameter set. Note: Updated parameters are not applied until DISCONNECT has been selected from the menu (after loading new parameter set).

Load parameter file

Allows reloading of cooler default parameter set or changing to new parameter set. See “Replacing the Controller” on page 50 for instructions. Note: Updated parameters are not applied until DISCONNECT has been selected from the menu (after loading new parameter set).

Statistics

Information from the past seven days on cooler activity including temperatures, door openings and alarms.

SCS info

Controller version and cooler asset information.

SCS setup

Add or change SCS info (see above).

Disconnect

Disconnect from currently connected controller.

Settings

Change app general settings.

SKOPE TME-N ActiveCore

Electronic Controller

Service Manual

Faults and Alarms

The following table explains faults and alarms that the electronic controller may log and display.

If a fault occurs, the fault - alarm indicator is lit on the controller faceplate, but no message is displayed. Faults do not affect product temperature, and require no action from the shop owner.

Alarms are logged and the alarm message is displayed on the controller faceplate. Alarms may result in abnormal product temperature.

Some faults and alarms can be cleared by the shop owner, and others can only be cleared by a service technician.

If the cooler is connected to the power supply and has warm product, check the SCS Connect Field App for active fault or alarm, and investigate. If the cooler does not have an active fault or alarm, check the app statistics to determine if and when the controller signalled a fault or alarm.

Refer to the tables below for faults and alarm descriptions and possible causes and actions. The service tech type column refers to the service tech skill level required to complete a task. Refer to the SKOPE HC Service Policy for service tech type details.

Faults

Alarms

Description Service tech

type

Possible root cause

Door left open.

The door has been open for several minutes.

1, 2, 3, 4 - door not self closing (torsion fault)

- door switch / circuit

- controller

Excessive door open counts

Over-voltage protection

The maximum allowable mains supply voltage has been exceeded. The cabinet has temporarily shut down to prevent damage and will restart once the supply voltage decreases.

1, 2, 3, 4 - should be a one off; if continues:

- line voltage / rural

- voltage setting parameter

- controller

Under-voltage protection

The mains supply voltage has dropped below the minimum allowable level. The cabinet has temporarily shut down to prevent damage and will restart once the supply voltage increases.

1, 2, 3, 4 - should be a one off; if continues:

- power supply overloaded / multibox

- line voltage / rural.

- voltage setting parameter

- controller

High condensing temperature protection

The system was operating at an elevated temperature and has temporarily shut down to prevent damage. Extended operation in this condition may result in ALARM 15, increased energy consumption and a reduction in cabinet life. This alarm may be caused by very high ambient temperature.

2, 3, 4

NO swap unit required

- condenser not clean

- poor installation / ventilation

- condenser fan motor / blade

- controller

Excessive compressor cycling protection

The system has been turning on and off too frequently.

2, 3, 4

Take spare unit in case refrigeration system fault.

- condenser blocked

- poor installation / ventilation

- cabinet / unit gasket seals leaking

- door not self closing / gasket leaking

- product; hot / blocking cabinet airflow

- overloaded from excess door openings / ambient

- fan motor / blade (condenser / Evap)

- controller

- compressor / gas leak = SWAP unit

Code Description Service tech

type

Possible root cause

dor Door left open.

The door has been open for several minutes. Will revert to door left open FAULT after 10 minutes (see faults table on previous page).

1, 2, 3, 4 - door not self closing (torsion fault)

- door switch / circuit

- controller

Electronic Controller

Service Manual

SKOPE TME-N ActiveCore

8 Estimated product temperature below

allowable range

The estimated product temperature has been below the allowable range for longer than the permissible time. Potential causes are: an empty or partially filled cabinet, or low ambient temperature.

1, 2, 3, 4 - low ambient

- App settings

- controller

9 Estimated product temperature above

allowable range

The estimated product temperature has been above the allowable range for longer than the permissible time. Potential causes are: excessive door openings, door being left open, or warm product loaded into cabinet.

2, 3, 4 NO Swap unit required to be taken (but may be

required as fault could still be with sealed refrigeration system)

- condenser blocked

- poor installation / ventilation

- frozen blocked evap coil

- unit gasket leaking (to cabinet seal / lid seal)

- door leaking air (bad gasket / door not self closing)

- product; hot / blocking cabinet airflow

- overloaded from excess door openings / ambient

- fan motor / blade (condenser / Evap)

- App settings

- controller

- compressor / gas leak = arrange SWAP unit

Excessive condensing temperature protection

The system was operating at an excessive temperature and has shut down to prevent permanent damage. This alarm may occur due to very high ambient temperature.

2, 3, 4

NO swap unit required

- condenser not clean

- poor installation / ventilation

- condenser fan motor / blade

- controller

Control probe failure

A critical system sensor has failed and the cabinet can no longer operate.

2, 3, 4

NO swap unit required

- control Probe / circuit

- controller

Electrical over-current protection activated

The compressor was drawing too much current and has shut down to prevent permanent damage.

2, 3, 4

Take spare unit in case refrigeration system fault.

- condenser blocked

- poor installation / ventilation

- cabinet / unit gasket seals leaking

- door not self closing / gasket leaking

- product; hot / blocking cabinet airflow

- overloaded from excess door openings / ambient

- fan motor / blade (condenser / Evap)

- controller

- compressor / gas leak = SWAP unit

Failed to reach set temperature

The refrigeration system has been operating continuously for a long period without reaching the set temperature.

2, 3, 4

Take spare unit in case refrigeration system fault.

- condenser blocked

- poor installation / ventilation

- frozen blocked evap coil

- cabinet seal leaking / door / unit

- product; hot / blocking cabinet airflow

- overloaded from excess door openings / ambient

- fan motor / blade (condenser / Evap)

- controller

- compressor / gas leak = SWAP unit

Over cooling product

The internal temperature is too low. The system has temporarily shut down until the temperature has returned to normal. This can occur if the set temperature has been raised by a large amount.

1, 2, 3, 4

- confirm if really too cold; change parameters accordingly

Evaporator fan over-current protection

The current supplied to the evaporator fan motor is too high.

2, 3, 4

NO swap unit required

- faulty fan motor

- fan blade fault (imbalance / debris / blockage)

- controller

Condenser fan over-current protection

The current supplied to the condenser fan motor is too high.

2, 3, 4

NO swap unit required

- faulty fan motor

- fan blade fault (imbalance / debris / blockage)

- controller

Controller communication error

Controller has lost communication channels.

1, 2, 3, 4

- App

- controller / circuit

Continued over page

Code Description Service tech

type

Possible root cause

SKOPE TME-N ActiveCore

Electronic Controller

Service Manual

Controller update failed

Controller update could not be completed.

1, 2, 3, 4

- App

- controller / circuit

Controller hardware failure

Controller hardware has failed.

1, 2, 3, 4

- App

- controller / circuit

Probe failure

A non-critical system probe has failed. The cabinet will continue to operate with partial function but requires service.

2, 3, 4

NO swap unit required

- Evap probe / connections

- controller

No downward tendency

The temperature is no longer decreasing.

2, 3, 4

Take spare unit in case refrigeration system fault.

- condenser blocked

- poor installation / ventilation

- cabinet / unit gasket seals leaking

- door not self closing / gasket leaking

- product; hot / blocking cabinet airflow

- overloaded from excess door openings / ambient

- fan motor / blade (condenser / Evap)

- controller

- compressor / gas leak = SWAP unit

Compressor cutting out

The compressor cut out on its internal protection or pressure switch.

2, 3, 4

Take spare unit in case refrigeration system fault.

- condenser blocked

- poor installation / ventilation

- cabinet seal leaking / door / unit

- product; hot / blocking cabinet airflow

- overloaded from excess door openings / ambient

- fan motor / blade (condenser / Evap)

- controller

- compressor / gas leak = SWAP unit

Excessive automatic defrosting

The system is automatically defrosting too frequently.

2, 3, 4

Take spare unit in case refrigeration system fault.

- door not self closing / gasket leaking

- Evaporator probe

- Evaporator motor / fan

- controller

- compressor / gas leak = SWAP unit

Compressor stalling

The compressor is stalling on start up.

2, 3, 4

Take spare unit in case refrigeration system fault.

- condenser blocked

- poor installation / ventilation

- cabinet / unit gasket seals leaking

- door not self closing / gasket leaking

- product; hot / blocking cabinet airflow

- overloaded from excess door openings / ambient

- fan motor / blade (condenser / Evap)

- controller

- compressor / gas leak = SWAP unit

Code Description Service tech

type

Possible root cause

Wiring

Service Manual

SKOPE TME-N ActiveCore

4 Wiring

Model: TME650/1000N-A Series

S18-2 P18-2

S24-4 P24-4

P6-1 S6-1

P3-1 S3-1

P3-4 S3-4

P6-4 S6-4

Compressor

Start

Relay

Compressor

Overload

S24-3 P24-3

S21-4 P21-4

S21-2 P21-2

Condenser Fan

S18-4 P18-4

Evaporator Fan

S2-1 P2-1

S2-2 P2-2

S2-3 P2-3

S2-5 P2-5

Cabinet

Probe

Evaporator

Probe

Inlet-L Inlet-N

T1-2

GNYE

EMC Filter

P17-2 S17-2

S6-2 P6-2

P4-1 S4-1

Pillar elements

WDTL

SCS

Controller

SSR

Comp.

123

AD5

DI1

AD1

DI2

AD2

DI3

AD3

DI4

AD4

P3-2 S3-2

S19-2 P19-2

S19-4 P19-4

T1-1

S4-2 P4-2

P18-1 S18-1

P21-1 S21-1

P19-1 S19-1

Door Switch

Condenser

Probe

P17-1 S17-1

P16-1 S16-1

P16-2 S16-2

P20-2 S20-2

P20-1 S20-1

S23-4

S23-1

S23-3

P22-1 S22-1

P22-2 S22-2

P7-2 S7-2

S2-4 P2-4

P7-1 S7-1

mbient

Probe

Programming

Port

S5-2 P5-2

BU GNS

BN GNS

BK GNS

S15-1 P15-1

S15-2 P15-2

Lighter shaded areas

only present on two

door cabinet.

GNS indicates a Green

sleeve on the wire

LED Power

Supply

S25 P25

S5-1 P5-1

LED Lighting

WIRE COLOURS

BK Black

BN Brown

RD Red

OG Orange

GN Green

BU Blue

GY Grey

WH White

GNYE Green-Yellow

Based upon IEC 757 Standard

LEGEND

Internal Unit Junction Box Sockets/Plugs S9/P9 Not Used S19/P19 Evaporator Motor Unit Socket/Plug (White 4-way)

Inlet IEC Cabinet Socket/Plug S10/P10 Not Used S20/P20 Condenser Sensor Socket/Plug (Red 2-way)

S1/P1 Not Used S11/P11 Not Used T1 Unit Terminals

S2/P2 Unit Junction Box to Controller Signal Socket/Plug (6-way) S12/P12 Not Used External Sockets/Plugs

S3/P3 Unit Junction Box to Controller Power Socket/Plug (Blue 4-way) S13/P13 Not Used S21/P21 Evaporator Motor Extension Socket/Plug (White 4-way)

S4/P4 Heater Wire Unit Socket/Plug (Black 3-way) S14/P14 Not Used S22/P22 Ambient Sensor Socket/Plug (Blue 2-way)

S5/P5 Light Unit Socket/Plug (White 3-way) S15/P15 Compressor Unit Socket/Plug (Blue 4-way) S23/P23 Programming/Comms Port Socket (Blue 4-way)

S6/P6 Unit Junction Box to Controller Power Socket/Plug 1 (Red 4-way) S16/P16 Evaporator Sensor Socket/Plug (Black 2-way) S24/P24 Compressor Electrics Plug

S7/P7 Door Sensor Socket/Plug (White 2-way) S17/P17 Cabinet Sensor Socket/Plug (White 2-way) S25/P25

LED Driver DC Output Socket/Plug (Red 2-way)

S8/P8 Not Used S18/P18 Condenser Motor Unit Socket/Plug (Red 4-way) -

SKOPE TME-N ActiveCore

Wiring

Service Manual

Notes

Spare Parts

Service Manual

SKOPE TME-N ActiveCore

5 Spare Parts

Main Assembly - TME650N-A Series

Parts — Main Assembly TME650N Series

No. Description Page

1 Cabinet assembly Page 20

2 Door assembly Page 22

3 Sign assembly Page 23

4 Unit assembly Page 25

SKOPE TME-N ActiveCore

Spare Parts

Service Manual

Main Assembly - TME1000N-A Series

Parts — Main Assembly TME1000N Series

No. Description Page

1 Cabinet assembly Page 21

2 Door assembly Page 22

3 Sign assembly Page 23

4 Unit assembly Page 25

323

Spare Parts

Service Manual

SKOPE TME-N ActiveCore

Cabinet Assembly - TME650N-A Series

Parts — Cabinet Assembly TME650N Series

Notes: Check the part colour before ordering. If the colour differs from the list above, state the specific colour when ordering.

No. Description Page

Unpainted/standard Colour: White Colour: Black

1 Top hinge - RH - HB0070110582A -

2 Door lock bracket - cabinet piece - HB0070206938 -

3 Bottom hinge - RH - HB0070110851 -

4 Tension bracket - - HB0070110580

5 Height adjustment block lock nut - - HB0070110581

6 Controller clip - HB0070206333 -

7 Door sensor assembly (includes magnet) HB0074091496 - -

8 Rear castor HB0070105066 - -

Front castor lockable

HB0070105065 - -

10 Shelf support strip HB0070110331 - -

11 Shelf clip - HB0070205867 -

12 Wire shelf - HB0070110864 -

13 LED light ELL11771 - -

14 Light power supply ELZ11239 - -

7 12

SKOPE TME-N ActiveCore

Spare Parts

Service Manual

Cabinet Assembly - TME1000N-A Series

Parts — Cabinet Assembly TME1000N Series

Notes: Check the part colour before ordering. If the colour differs from the list above, state the specific colour when ordering.

No. Description Part No.

Unpainted/standard Colour: White Colour: Black

1 Top hinge - LH - HB0070110583A

2 Top hinge - RH - HB0070110582A

3 Door lock bracket - cabinet piece - HB0070206938

4 Bottom hinge - LH - HB0070110850

5 Bottom hinge - RH - HB0070110851

6 Tension bracket - - HB0070110580

7 Height adjustment block - - HB0070110581

8 Controller clip - HB0070206333

9 Door sensor assembly (includes magnet) HB0074091496 - -

10 Rear castor HB0070105066 - -

Front castor lockable

HB0070105065 - -

12 Shelf support strip HB0070110331 - -

13 Shelf clip - HB0070205867

Wire shelf - split (10 per cabinet) - HB0070110862 -

Wire shelf - wide (5 per cabinet) - HB0070110863 -

15 LED light ELL11771 - -

16 Light power supply ELZ11239 - -

Updated image to come

214 8

1 3

12 9

Spare Parts

Service Manual

SKOPE TME-N ActiveCore

Glass Door Assembly

Parts — Glass Door Assembly

Notes: Check the part colour before ordering. If the colour differs from the list above, state the specific colour when ordering.

No. Description SKOPE Part No.

Unpainted/standard Colour: White Colour: Black

TME650N door assembly - RH - HB0070832242 -

TME1000N door assembly - RH - HB0070832243 -

TME1000N door assembly - LH - HB0070832244 -

2 Door lock bracket - door piece TBC - -

3 Bush PLM5075 - -

4 Door handle -

HAN11195/0844AS (silver, for white door)

TME650N Magnetic gasket GKT0432SK - -

TME1000N Magnetic gasket GKT0572SK

6 Torsion bar REF5014 - -

7 Bush washer PLM11298 - -

8 Capstan SM12BV/396 - -

9 Split pin FAS5076 - -

Hinge reversal kit (RH to LH) (single door only) (not pictured)

TBC - -

SKOPE TME-N ActiveCore

Spare Parts

Service Manual

Lit Sign Assembly

Parts — Lit Sign Assembly TME650N-AC

Parts — Lit Sign Assembly TME1000N-AC

Notes: Check the part colour before ordering. If the colour differs from the list above, state the specific colour when ordering.

No. Description SKOPE Part No.

Lit sign assembly TBC

Non-lit sign assembly (sign replacement panel)

HB0070825987

2 Sign back strip HB0070110813

3 Sign side HB0070206332

4 Sign light bar (lit-sign) ELL11772

5 Controller surround HB0070206332

6 Sign panel (opal) (lit-sign) PLY11242-MT65

7 Sign panel (transparent) (lit-sign) HB0070206409

No. Description SKOPE Part No.

Lit sign assembly TBC

Non-lit sign assembly (sign replacement panel)

HB0070832533A

2 Sign back strip HB0070110812

3 Sign side HB0070206332

4 Sign light bar (lit-sign) ELL11773

5 Controller surround HB0070206332

6 Sign panel (opal) (lit-sign) PLY11242-MT10

7 Sign panel (transparent) (lit-sign) HB0070206408

46726

Spare Parts

Service Manual

SKOPE TME-N ActiveCore

Unit Assembly UTHCNI-0010

17 19 14 16

SKOPE TME-N ActiveCore

Spare Parts

Service Manual

Parts — Unit Assembly

*Note: When ordered as a spare part, the refrigeration unit does not include evaporator box lid, top metal strap bracket and hold down bracket. If required, these items must be ordered in addition to the refrigeration unit (items 22, 31 and 32).

No. Description SKOPE Part No.

1 Unit assembly* HB0070832517

2 Unit electrics box assembly TBC

3 Electronic controller box (cover and

base, excludes controller)

TBC

4 Suction line assembly HB0070702718

5 Evaporator fan blade HB0074000313A

6 Evaporator fan motor ELM11309

7 Condensate pipe support HB0070110674

8 Drier HB0074180006

9 EMI filter HB0074600001

10 Controller box cover HB0070206126

11 Condenser fan motor ELM11309

12 Condenser coil HB0070702720

13 Condenser temperature probe HB0070401693B

14 Condenser fan blade HB0074000313

W/Drive SCS Connect electronic controller

ELZ11749

16 Controller box base HB0070206125

17 Unit electrics box enclosure front HB0070207012A

18 Unit electrics box enclosure HB0070207014

19 Cable clamp HB0070206127

20 Unit electrics box enclosure rear HB0070207013A

21 Unit plastic bottom HB0070206212B

22 Hold down bracket HB0070110815A

23 Compressor - Wanbao FN90M HB0074000848

24 Control temperature probe HB0070400542

25 Evaporator temperature probe HB0070400506

26 Evaporator box HB0070510928A

27 Evaporator coil HB0070702232

28 Unit plastic top cover HB0070206133

29 Unit gasket seal 2306mm PLE11052-2306

30 Unit gasket seal 1571mm PLE11052-1571

31 Evaporator box lid HB0070511356

32 Top metal strap bracket HB0070110816

Ambient temperature probe (not pictured)

HB0070401693A

- Mains power cord (not pictured) HB0070400636

- TME650N Light loom (not pictured) SM65BYN/X05

- TME1000N Light loom (not pictured) SM10BYN/X05

Installation

Service Manual

SKOPE TME-N ActiveCore

6 Installation

Installation Guidelines

When installing this cabinet, ensure the installation guidelines below are considered and met.

Ventilation Requirements

This chiller must have the following ventilation clearances at all times.

Ventilation

Ensure all ventilation

requirements below are

met.

Door Opening

Allow adequate space

for the door/s to open

and close properly.

Sunlight

Do not install the chiller

in direct sunlight.

Uneven Surface

Do not install the chiller

on an uneven surface.

Surface

The installation surface

must be capable of

supporting the loaded

cabinet.

Power Supply

Do not overload the power

supply.

Blocking

Ventilation

Do not store boxes or items

in front or on top of the

chiller.

Climate Class

The chiller must be

installed in an

environment within its

climate class.

The climate class is stated on the cabinet rating label

inside the chiller.

No below clearance required

Min. 300mm above

No side

clearance

required

No behind clearance required

SKOPE TME-N ActiveCore

Installation

Service Manual

Door Handles

Fitting Door

Handles

For transit purposes the door handles may be packed separately inside the cabinet. If the door handles are packed separately, follow the steps below to fit them to the door/s.

To fit a door handle

1. Remove the handle/s from inside the cabinet by carefully cutting the cable ties securing the handle, and remove the packaging.

2. A metal spring clip is fitted inside the handle mounts at each end of the handle.

Ensure that the spring clips point up.

3. Locate BOTH handle mounts simultaneously onto both door brackets.

Then push the handle down onto the brackets, until the handle locks into place.

4. If the handle does not lock into place, check that the spring clips are pointing up and try again.

If only one end of the handle locks into place, unscrew the door handle (see over page), and refit ensuring both of the handle mounts are located onto the brackets before pushing the handle down and locking into place.

Handle mount

Spring clip (pointing up)

Handle

Bracket

Front of

door

Bracket

CAUTION

Ensure BOTH handle mounts are located before pushing

down.

Installation

Service Manual

SKOPE TME-N ActiveCore

Removing

Door Handles

The door handles can be removed for transporting and moving the cabinet through doorways, or for refitting.

To remove a door handle

1. Open the door, and peel back the door gasket from behind the handle mounts on the inside of the door frame.

2. Unscrew the handle mounts through the holes on the inside of the door frame (top and bottom screws only), and remove the handle.

3. Remove the bracket/s from the handle mount by pressing the bracket in and down until it unclips from the handle mount.

4. Fit and screw the bracket/s back onto the door. Ensure the catches are pointing up as pictured.

5. Refit the door gasket by clipping it back into place on the inside of the door frame. If the gasket is out of shape after refitting it, a hair drier can be used to heat and reshape it.

Bracket

Handle mount

Handle

Bracket

Catch

SKOPE TME-N ActiveCore

Installation

Service Manual

Shelves

The chiller is fitted with five wire shelves per door, which may be positioned at different heights to suit various products

Shelf Clips Each wire shelf is held in place with four shelf clips, which engage in the

shelf support strips and slide up and down to the desired shelf position.

The support strips are numbered for easy location of shelf clips. View the numbers in the bottom LH corner of the shelf clip.

To fit a shelf clip

To adjust the shelf clip height

To remove a shelf clip

Repositioning

Shelves

When repositioning standard shelves, unload and remove the shelf, establish the desired position and slide the shelf clip in each of the shelf support strips to the desired position (see “To adjust the shelf clip height” on page 29). Sit the shelves on the shelf clips.

1. The shelf clip twists onto the shelf support strip. Position the shelf clip with the flat side up against the shelf support strip and the two prongs pointing up. Twist the top of the clip anticlockwise onto the shelf support strip until it locks in place.

1. Pull the shelf clip tab up and slide the shelf clip up or down as required. Once in position, ensure the shelf clip is locked into place.

1. Pull the shelf clip tab up and twist the top of the clip clockwise off the shelf support strip.

Shelf support strip

Prongs

Shelf clip

Tab

Replacement Procedures

Service Manual

SKOPE TME-N ActiveCore

7 Replacement Procedures

Lighting

The cooler is fitted with LED modular interior lights, and TME-AC models are also fitted with an LED modular sign light. Ensure the light is replaced with the same light type. Fluorescent or LED tubes cannot be used in place of LED modular lights.

Refer to the table below for replacement light specifications.

Light specifications

The lighting is made up of three components which are replaceable:

 LED modular light

 Light power supply (1 per cabinet)

 Interior wiring loom (1 per door)

Power is supplied to the lights by the power supply (located in the cabinet electrics panel above the door/s) via the wiring loom/s which run down the sidelight channel.

Lighting components are all non serviceable items. If a component is faulty, it should be removed and a SKOPE OEM new replacement component fitted.

Refer to the diagnostics table below to determine what component may be at fault, and the procedures over the next few pages for component replacement instructions.

Ensure the cabinet is isolated from the power supply before cleaning or removing parts.

IMPORTANT

Replace the light with the same SKOPE OEM part.

DO NOT use alternative LED strip or tube lights, or fluorescent

tubes.

Model Interior light Sign light

Description Part No. Description Part No.

TME650N-A

Interior light ELL11771

n.a. n.a.

TME650N-AC Sign light ELL11772

TME1000N-A n.a. n.a.

TME1000N-AC Sign light ELL11773

SKOPE TME-N ActiveCore

Replacement Procedures

Service Manual

Lighting fault diagnostics

To replace an interior light component

Problem Possible Cause Repair

No lights working. Cabinet is dark.

Lights switched off.

Switch lights on at electronic controller faceplate (see page 9), or the app.

Controller is in Energy Saving mode.

Open the door to bring the controller into Normal mode.

Controller alarm.

Check controller for alarm code.

Plug not connected properly.

Check and clean plugs on top of the cabinet.

Light power supply fault.

Replace light power supply.

Light component not working.

Plug not connected properly.

Check and clean plug connection in side light channel, behind the loom cover.

Faulty light. Replace light.

Segment of light not working.

Faulty light. Replace light.

1. Unplug the chiller from the power supply.

2. Unplug the light, and remove the light from the plastic casing.

3. Clip the replacement light into place on the plastic casing, ensuring the male end of the light is at the top, and plug the light in.

4. Ensure the light is firmly and completely clipped in.

5. Reconnect to the power supply and check for correct operation.

Replacement Procedures

Service Manual

SKOPE TME-N ActiveCore

To replace the LED driver power supply

To replace an interior wiring loom

1. Disconnect the chiller from the power supply.

2. Remove the sign panel.

3. Detach the refrigeration unit and carefully push back or remove to allow access to the cabinet electrics cover.

4. Unscrew the cabinet electrics cover.

5. Remove the light power supply.

6. Replace the light power supply and reassemble.

1. Disconnect the chiller from the power supply.

2. Unplug the light from the wire loom.

3. Gain access to the cabinet electrics panel (see procedure above).

4. Move up to the cabinet roof, and unplug the wiring loom from the light power supply, and if applicable the sign light.

5. Remove the putty from the loom entry point on the cabinet roof, and pull the loom up through the cabinet ceiling.

6. Refit the new loom and reassemble. Ensure:

All plugs are clean, correctly fitted and plugged in. That the ceiling and roof hole is completely sealed with putty.

Cabinet electrics cover

Light power supply

SKOPE TME-N ActiveCore

Replacement Procedures

Service Manual

Sign Light The sign is lit by an LED modular light which can be replaced by following

the steps below.

To replace the sign light

1. Disconnect the chiller from the power supply.

2. Undo the two fixing screws from the sign top cover and remove the top cover.

3. Remove the front sign panel/decal by sliding them up and out of the sign.

4. Remove the sign cover from the top of the sign.

5. Remove additional sign panel by sliding up and out of the sign.

6. Cut the cable tie holding the light cable at the back of the sign.

7. Undo the two most RH sign reflector screws.

8. Carefully pull the light plug and cable through to the front of the sign, manipulating the reflector as required.

9. Unclip and replace the light.

10. Rout the light plug and cable back through behind the reflector and hole at the back of the sign, and cable tie in place.

11. Reassemble the sign, reconnect to the power supply and check for correct operation.

Light

Light cable (pulled through to front)

Reflector

Reflector screws

(removed)

Replacement Procedures

Service Manual

SKOPE TME-N ActiveCore

Doors

Alignment

Adjustment

If a door is out of alignment, realign it by loosening the top hinge bracket fixing screws, and move the top of the door as required.

Height

Adjustment

A height adjustment block is fitted below the bottom hinge. As standard, the notched edges on the bottom of the hinge and the top of the height adjustment block align to set the door to the correct level. If the door is not at the correct height when at the standard setting, follow the steps below to adjust the height.

Note: The door height cannot be adjusted on the middle door on three door models.

To adjust the door height

Replacing the

Gasket

The one-piece door gasket clips into the door frame and runs around the perimeter of the door. Remove the gasket by peeling it from the door frame, starting at a corner.

If the gasket is out of shape after refitting, use a hair dryer to heat and reshape it.

Removing and

Refitting the

Door

For ease of servicing and to reverse the hinging, the door can be removed from the cabinet.

To remove the door

WARNING

For safe door operation the door bottom hinge bracket must

always be fitted with a split pin.

1. Disconnect the chiller from the power supply.

2. Loosen off the bottom hinge, and remove the height adjustment block.

3. Set the door to the correct height, rotate and refit the height adjustment block to the most appropriate setting and tighten up the bottom hinge screws.

Bottom hinge

Height adjustment

block

1. Disconnect the chiller from the power supply.

2. Remove the sign panel and sign sides.

3. Single door cabinets only:

Detach the refrigeration unit and carefully push back to allow access to the top hinge.

Continued over page

SKOPE TME-N ActiveCore

Replacement Procedures

Service Manual

To replace the top hinge bracket (if necessary)

To refit the door

4. Remove the split pin from the capstan at the bottom hinge (outside door pictured).

5. Unscrew and remove the tension bracket. Take care when removing as the bracket is under tension.

6. Unscrew the top hinge, and lift the door up and off the cabinet.

1. Follow the steps on the previous page to remove the door.

2. Remove the top hinge from the top of the door and replace.

1. Lift the door onto the bottom hinge.

2. Fit the top hinge to the top of the door, and partially fix in place on the top of the cabinet. Align the door with the cabinet and tighten the fixing screws.

Ensure the top hinge spacer is fitted under the top hinge before fixing the top hinge in place.

3. Apply tension to the door (see page 36).

4. Fit the split pin through the hole in the capstan to lock the door in place (outside door pictured).

5. Fit the height adjustment block to the bottom screw hole (not fitted to middle doors). As standard, the notched edges on the bottom of the hinge and the top of the height adjustment block align to set the door to the correct level. If necessary, rotate the height adjustment block to level the door.

Split pin

Bottom

hinge

Capstan

Tension

bracket

Split pin

Bottom hinge

Capstan

Replacement Procedures

Service Manual

SKOPE TME-N ActiveCore

Adjusting Door

Tension

The door has an internal torsion bar, pretensioned at the factory, that lets the door self-close. If necessary, the door tension can be further adjusted by rotating the capstan mounted in the bottom hinge bracket.

To adjust the door tension

Replacing the

Torsion Bar

When the door tension can no longer be adjusted, replace the torsion bar.

To replace the torsion bar

1. Remove the split pin from the capstan at the bottom hinge.

2. Remove the tension bracket from the bottom hinge.

3. Use a tool to apply tension to the door via the capstan. First, rotate the capstan against the door opening direction to remove any slack. Once resistance is felt, continue to rotate 180° to provide tension.

While holding door tension on the capstan, fit the tension bracket to the top screw hole so that it supports the door tension on the capstan.

Outside door pictured.

4. Fit the split pin through the hole in the capstan to lock the door in place.

5. Check door tension by holding the door open about 100mm and letting it go. The door should gently close, with the gasket forming an airtight seal with the cabinet.

Tension bracket

Tensioning tool

Capstan

Split pin

Height

adjustment block

Bottom hinge

1. Remove the door from the cabinet (see page 34).

2. Lever the capstan, bush and bush washer from the bottom of the door, and unhook from the torsion bar.

Note: The torsion bar cannot easily be removed from the door. Cut the old torsion bar and push it into the door frame.

Fit the capstan, bush and bush washer to the new torsion bar, and fit this assembly into the bottom of the door.

3. Refit the door (see page 34).

SKOPE TME-N ActiveCore

Replacement Procedures

Service Manual

Hinge

Reversal

The single door cabinet is supplied with the door hinged on the RH side. If required, the hinge can be swapped to the LH side. Some spare parts are required to complete the procedure, and are available in the LH Hinge Kit.

To reverse the door hinging

1. Remove the door from the cabinet (see page 34).

2. Remove the door lock bracket from the top of the cabinet.

3. Remove the bottom hinge, tension bracket and height adjustment block. Retain the tension bracket and height adjustment block (these are fitted to the opposite side once the door is refitted). The bottom hinge can be discarded.

4. Unplug the door switch cable from the cabinet. The door switch is fitted to the door switch bracket, above the door.

5. Fit the new bottom hinge.

6. Remove the door lock bracket from the door, and fit to the opposite end.

7. Remove the bush and retain for the other end of the door.

8. Remove the capstan, bush and bush washer, and unhook from the torsion bar.

Note: The torsion bar cannot easily be removed from the door. Push the torsion bar into the door frame.

Fit the capstan, bush and bush washer to the new torsion bar, and fit this assembly to the opposite end of the door.

9. Fit the bush (retained from step 7) to the end of the door, opposite the capstan.

10. Remove the door switch magnet from the end of the door, and fit to the opposite end. Note: Ensure the magnet is orientated correctly and does not protrude past the frame edge.

11. Refit the door (see page 34).

12. Apply the SKOPE logo label to the top LH corner of the door. Use the label backing to align the label as pictured.

13. Apply the blanking labels over the upside down logos at the bottom of the door.

Torsion bar

Bush

washer

Capstan

Bush

Door lock bracket

Door switch magnet

Replacement Procedures

Service Manual

SKOPE TME-N ActiveCore

Refrigeration Unit

Before

Servicing

Overview

Ensure you have read and understand this manual before commencing with any servicing.

Important. Ensure the following before servicing:

Only technicians contracted to SKOPE hydrocarbon service policy

may service this cabinet.

SKOPE hydrocarbon refrigeration systems must only be serviced by

appropriately skilled refrigeration mechanics.

Servicing of sealed refrigeration system must be completed at a

hydrocarbon workshop/service area with dedicated hydrocarbon equipment and personal protective equipment.

All local hydrocarbon storage and handling regulations and

procedures must be adhered to at all times.

Ensure all electronic controller alarms diagnostics and refrigeration system diagnostics are performed to confirm a refrigeration system fault is present. Do NOT open the refrigeration system. Check all components such as the electronic controller and electrical systems. If a sealed system fault is suspected, the system must not be opened; it must be sent to a SKOPE approved service depot for repair.

Safety hazards

The main hydrocarbon safety hazards are:

Flammable refrigerant.

Venting of hydrocarbon and compressor oil.

Asphyxiation.

Refrigerant identification

The cabinet rating label (located in the upper inside of the cabinet) states the refrigerant type. In addition to this, a warning labels are fitted to hydrocarbon refrigeration coolers to indicate the use of R290 refrigerant.

Personal Protective Equipment

Ensure all required P.P.E is used correctly during servicing.

Service equipment

All refrigeration service tools must be hydrocarbon compliant and any electrical equipment that could be exposed to the refrigerant must be intrinsically safe. ONLY dedicated hydrocarbon service equipment may be used.

In addition to standard tools for accessing and removing parts, specialist tools are required when completing refrigeration system service tasks detailed in this manual:

Intrinsically safe vacuum pump.

IMPORTANT

Use only dedicated hydrocarbon SKOPE OEM spare parts.

DO NOT use alternative parts.

For safety compliance, only SKOPE supplied c omponents specified

for the appliance shall be used for repairs.

SKOPE TME-N ActiveCore

Replacement Procedures

Service Manual

Dedicated hydrocarbon gauges.

Intrinsically safe hydrocarbon combustible gas leak detector.

Intrinsically safe scales to 0.1gm accuracy.

Well ventilated work area.

Refrigeration

Unit Assembly

The refrigeration unit is a top mounted, electronically controlled removable unit.

For safety and compliance, only SKOPE supplied parts specifically for this appliance may be used for repairs. Other parts may appear to be suitable, but may not be approved or safe for use in an appliance with hydrocarbon refrigerant.

The unit must only be used on a SKOPE Hydrocarbon compliant cabinet. Refer to the cabinet rating label to determine if the cabinet is suitable for use with a hydrocarbon unit. The rating label MUST state refrigerant as R290. If the label states a different refrigerant, or does NOT state a refrigerant, it is NOT suitable for a hydrocarbon unit.

For servicing or transportation, the refrigeration unit unplugs and lifts off the cabinet. Some minor servicing can be performed without removing the refrigeration unit.

The model and serial number are both printed on the unit rating/serial number label attached to the top of the side of the cover.

WARNING

The hydrocarbon unit must only be used on an hydrocarbon

compliant cabinet.

Unit electrics box

Evaporator coil

Compressor electrics

Evaporator fan

Condenser fan

Evaporator tub

Compressor

Condenser coil

Unit electrics box cover

Replacement Procedures

Service Manual

SKOPE TME-N ActiveCore

Specifications for the model are in the following table. Verify model and basic requirements before servicing.

Unit specifications

Gas Detector A gas detector is required and must be used when servicing HC units. A gas

detector is a safety device for Hydrocarbon gas to warn the technician that hazardous flammable gas is present.

Leak Detector A leak detector is recommended for servicing HC units. It is used to track

and locate the source of Hydrocarbon gas leaks.

On-Site Work The service technician must have required knowledge, skills and tools to

proceed with on-site refrigeration sealed system diagnostics.

Minimum knowledge and skills

Experience and qualifications suitable for work on a flammable

refrigeration system.

Performs no unsafe activity. Fully complies with SKOPE HC service policy.

Minimum tools and equipment

Hydrocarbon gas detector Safety signage - suitable to create a safe work zone 1.5m around the

cabinet.

Refrigeration gauge set - suitable for R290 flammable refrigerant. Bullet valves/line piercing valves suitable for 6mm tube.

Service vehicle

Suitable for transporting flammable gas (being HC refrigeration

systems). Vehicle storage area must be well ventilated externally, and not ventilated into the vehicle. There must be no ignition sources in the storage area, nor any areas where the gas may pool.

Must be able to transport swap units. Should carry minimum SKOPE HC service parts.

Not Cooling

Fault

If a customer reports a ‘not cooling’ fault, and it has been established that the cabinet is not cooling, follow the procedure on page 58 when making the service visit.

Hydrocarbon

Workshop

The following tools and equipment are required in the hydrocarbon workshop:

Hydrocarbon Leak Detector. Dedicated Hazardous workshop Area - suitable for servicing and

release of flammable refrigerant.

Refrigeration Gauge set - suitable for R290 flammable refrigerant. Dry Nitrogen - suitable for purging and high pressure testing. Refrigeration Vacuum pump rated as suitable for use with R290 (by

Vacuum pump supplier).

Charging scales rated as suitable for use with R290 (by scales

supplier), accuracy to 1.0gm.

R290 refrigerant supply cylinder.

Unit Model: UTHCNI-0010 (spare part number: HB0070832517)

Compressor: Wanbao FN90M

Compressor capacity: 740 Watts

Refrigerant / Charge R290 / 99 g

SKOPE TME-N ActiveCore

Replacement Procedures

Service Manual

Removing the

Unit

Follow the steps below to remove the refrigeration unit from the cabinet. Ensure the chiller is disconnected from the power supply before removing the unit.

The unit is heavy and requires a minimum of two people to lift from the cabinet. Steps or a platform about one metre high are suggested to allow the unit to be safely lifted, carried and put down at waist height.

To remove the refrigeration unit

1. Unplug the chiller from the power supply.

2. Remove the top sign. If fitted with key locks, open the door/s and unscrew the sign from the brackets below the sign.

3. Detach the electronic controller assembly from the top of the cabinet, and clip it onto the top of the unit.

4. Remove electrics cover and unplug the mains supply plug and cabinet plugs.

Note: The unit plugs (plugs feeding into the unit) and electronic controller plugs (plugs feeding to the electronic controller assembly) do not need to be unplugged.

5. Remove the sign back strip. Note: If necessary the sign sides can also be removed.

6. Undo the two unit fixing screws (one on each side of the unit) and lift the unit off the cabinet.

7. When refitting the unit, ensure:

The gasket on the top of the cabinet is in good condition. The mains and cabinet plugs are reconnected. The electrics cover is refitted. The unit is re-fixed in place.

Sign side

Electronic

controller assembly

Sign back strip

Electrics

cover

Mains and

cabinet plugs

Sign side

Top sign

Replacement Procedures

Service Manual

SKOPE TME-N ActiveCore

Replacing the

Unit

The SKOPE ActiveCore refrigeration unit is interchangeable between bottom and top mount hydrocarbon (R290) ActiveCore chillers.

When interchanging from a bottom mount chiller to a top mount chiller, an evaporator lid, strap brackets and hold down brackets must be fitted to seal the top of the evaporator tub, and to fix the unit to the top of the cabinet.

New spare part refrigeration units supplied by SKOPE are not supplied with the evaporator tub lid, top strap brackets and hold down brackets. When replacing a faulty top mount refrigeration unit, retain these parts for use on the new spare part replacement unit.

The evaporator tub lid, top strap brackets and hold down brackets can be ordered in addition to the refrigeration unit if required. See page 25 for spare part numbers.

To replace a unit with a SKOPE supplied spare part refrigeration unit

WARNING

The hydrocarbon unit must only be used on a hydrocarbon

compliant cabinet.

Evaporator

tub lid

Top strap

brackets

Hold down

bracket

Hold down

bracket

Bottom plugs

1. Disconnect the chiller from the power supply and remove the existing unit (see page 41).

2. On the new unit, push the bottom plugs out of the bottom of the evaporator box.

3. Swap the evaporator tub lid, top strap brackets and hold down brackets from the existing unit to the new unit.

4. Fit the new unit to the cabinet.

SKOPE TME-N ActiveCore

Replacement Procedures

Service Manual

Unit Electrics

Box Assembly

The unit electrics box assembly contains the mains supply socket, EMI filter and panel mount socket connectors for the unit and cabinet. Refer to the diagram over the page or label on the electrics box cover for socket connection identification.

Due to the confined space within the unit electrics box, plugs may come loose as a result of movement and vibrations. Take care when refitting to ensure all plugs are securely attached to the correct sockets.

To remove and open the unit electrics box assembly

UPDATE

1. Disconnect the chiller from the power supply.

2. If present, unclip the electronic controller from the top of the electrics box.

3. Undo the fixing screw at the top of the electrics box cover, and remove the cover.

4. Unplug all unit plugs from the unit electrics box.

5. Undo the two fixing screws at the base of the electrics box, and detach the electrics box from the unit.

6. To open the electrics box, undo the two fixing screws on the back of the electrics box and swing the back cover off.

UPDATE

Replacement Procedures

Service Manual

SKOPE TME-N ActiveCore

Unit Cover Remove the unit cover to access parts within the unit assembly.

To remove the unit cover

Condenser

Fan

The condenser fan assembly is made up of a fan motor, fan blade and mounting brackets which can be replaced if necessary.

If the fan stops for any reason, check all connections to ensure no plugs have come loose. Refer to the label on the electrics box cover to identify the condenser fan plug and socket in the electrics box.

ActiveCore R290 Junction Box Layout

13 14

15 16

Key Colour Description Key Colour Description

1 n.a. Not used 11 n.a. Not used 2 White Controller Signal 12 n.a. Not used 3 Blue Controller Return 13 n.a. Not used

4BlackTrace Heating 14n.a. Not used

5 White Lighting 15 Blue Compressor

6 Red Controller Power 16 Black Evaporator Sensor

7 White Door Sensor 17 Blue Appliance Sensor 8 n.a. Not used 18 Red Condenser Fan

9 n.a. Not used 19 White Evaporator Fan

10 n.a. Not used 20 Red Condenser Sensor

/$%5HY-XO\

1. Disconnect the chiller from the power supply and remove the refrigeration unit (see page 41).

2. Unscrew the four machine screws from the sides of the refrigeration unit and lift the cover off the unit.

IMPORTANT

Replace the motor with the same SKOPE OEM part.

DO NOT use alternative parts.

SKOPE TME-N ActiveCore

Replacement Procedures

Service Manual

It is important that the fan blade and/or fan motor is replaced with the same part to ensure safety, correct alignment and refrigeration performance, and compliance. Fan blades should be tightened to the fan motor manufacturer recommended torque settings (shown in the table below).

Fan motor manufacturer recommended torque settings

To access and remove the condenser fan assembly

To replace the fan blade

To replace the fan motor (with correct SKOPE spare part only)

Fan motor manufacturer Torque setting

Wellington Drive 1.5 Nm

1. Isolate the chiller from the power supply and remove the refrigeration unit (see page 41).

2. Remove the unit cover (see page 44).

3. Open the electrics box and unplug the condenser fan motor plug (see page 43).

4. Cut the cable ties holding the cables along the unit, and free up the condenser fan motor cable.

5. Remove the fan assembly (fan motor, fan blade, mounting brackets) from the unit by lifting the shroud up and out.

1. Remove the condenser fan assembly (see above).

2. Remove the screw and washer from the centre of the fan blade, and lift the blade from the motor.

3. Replace new blade and fix with 12mm flat washer and serrated head screw. Tighten the blade to fan motor manufacturer recommended torque setting.

4. Reassemble unit and test.

1. Remove the condenser fan assembly and the fan blade (see above).

2. Unplug the fan flexible cord from the electrics box (see page 43).

3. Detach the fan motor from the fan mounting brackets by removing the four screws from the mounting bracket.

4. Fit new motor and reattach fan blade with 12mm flat washer and serrated head screw. Tighten the blade to 1.5Nm.

5. Reassemble unit, ensuring all cables are neatly cable tied away from the fan blade, and test for correct operation.

Replacement Procedures

Service Manual

SKOPE TME-N ActiveCore

Evaporator

Fan

The evaporator fan assembly is made up of a fan motor and fan blade, both of which can be replaced when necessary. The evaporator fan flexible cord has a white plug.

If the fan stops for any reason, check all connections to ensure no plugs have come loose. Refer to the label on the electrics box cover to identify the evaporator fan plug and socket in the electrics box.

The fan motor and fan blade are fixed to the evaporator shroud via the brackets. The shroud (complete with fan motor and fan blade) can be lifted off the evaporator tub once the refrigeration unit cover has been removed.

Fan motor manufacturer recommended torque settings

To access the evaporator fan assembly

To replace the fan blade

IMPORTANT

Replace the motor with the same SKOPE OEM part.

DO NOT use alternative parts.

Fan motor manufacturer Torque setting

Wellington Drive 1.5 N m

1. Isolate the chiller from the power supply and remove the refrigeration unit (see page 41).

2. Remove the refrigeration unit cover.

3. Free up cables from the putty on the evaporator tub perimeter.

4. Cut cable ties to release control probe from the fan bracket.

5. Lift the assembly up and out of the evaporator box.

1. Isolate the chiller from the power supply and remove the refrigeration unit (see page 41).

2. Gain access to the evaporator fan assembly (see above).

3. Remove the screw and washer from the centre of the fan blade, and lift the blade from the motor.

4. Fit new blade, ensuring it is centred within the evaporator shroud. Tighten the blade to fan motor manufacturer recommended torque setting.

5. Reassemble unit and test for correct operation.

SKOPE TME-N ActiveCore

Replacement Procedures

Service Manual

To replace the fan motor (with correct SKOPE spare part only)

Compressor The compressor is located at the front of the refrigeration unit, beside the

condenser. If the compressor is causing excessive noise, check the mountings to ensure there is no damage to the rubber or the washers, nuts and screws.

Before replacing the compressor, check all plug connections and ensure the compressor electrics are operating correctly (see “Compressor Electrics” on page 47). The compressor must be supplied with consistent voltage over 220 volts, ensure the voltage does not drop at start-up. If the voltage does drop, ensure the unit has a direct power supply (not from a multi-box or extension cord). Generally a faulty compressor may have a distinct hissing sound and run with a very hot body temperature.

Compressor

Electrics

The compressor electrics are located on the front of the compressor.

To access the compressor electrics, remove the refrigeration unit (see page 41) and unit cover (see page 44). The capacitor unclips from the relay cover, and the relay cover unclips from the compressor.

1. Follow the above steps to access the evaporator fan assembly and remove the fan blade.

2. Free the fan flexible cord by cutting the cable ties, trace the cable back to the connector (near the compressor electrics) and unplug.

3. Detach the fan motor from the fan mounting brackets by removing the four screws from the mounting bracket.

4. Attach to the replacement motor. Ensure that the flexible cord points towards the bottom of the evaporator tub once reinstalled. Take care to recable tie the fan and temperature probe flexible cords back onto the mounting bracket (to prevent high frequency vibration).

5. Fit fan blade, ensuring it is centred within the evaporator shroud. Tighten the blade to 1.5Nm.

6. Reassemble unit and test for correct operation.

IMPORTANT

To eliminate possible vibrati on noise, ensure no pipes touch the

plastic base and condenser assembly.

Replacement Procedures

Service Manual

SKOPE TME-N ActiveCore

Refrigeration System

Unit Removal For detailed instructions on removing the unit, refer to unit removal

instructions available on the instruction sheet attached to the back of the sign panel, or on page 41 of this service manual.

Diagnostics The following diagnostic test is useful for workshop diagnosis of a short of

gas situation. Perform the test before opening the refrigeration system.

It is beneficial to have a correctly operating unit running beside the unit being serviced to compare behaviour.

Note: These diagnostic procedures are indicative only.

Refrigeration system diagnostic test (perform in suitable workshop)

1. Isolate the chiller from the power supply and remove the refrigeration unit, and remove the unit cover.

2. Place unit on bench and connect service probe to red plug on unit.

3. Connect the refrigeration unit to the power supply and allow to run for approximately 10 minutes until the evaporator temperature stabilises.

4. Refer to the table below to determine if the system charge is correct. A system with the correct refrigerant charge will frost back towards the compressor. The point where the frost stops is affected by the ambient temperature. The table below details the frost stop point on a correctly charged system running on the bench.

5. If the suction pipe frosts to the appropriate frost stop point, the charge is likely correct. If the frost does not go back to the point shown there may be a capillary blockage or compressor fault.

6. Use the table below to determine whether the system is short of refrigerant or a blocked capillary.

7. After fault has been diagnosed and repaired, reassemble the refrigeration system and test run.

Ambient 50% charged 75% charged 100% charged

10°C

Cold with light sweat Cold with light sweat Frosting to

compressor

20°C Cold with light sweat Sweating 50mm from

compressor

Frosting to compressor

30°C

Dry Dry Frosting 20mm from

compressor

40°C Dry Dry Sweating 50mm from

compressor

Diagnosis

Frost back (after 10 mins)

Blocked capillary None

Normal operation Refer to table above

SKOPE TME-N ActiveCore

Replacement Procedures

Service Manual

Electronic Controller

Controller

Location

The electronic controller is located within the electronic controller box assembly.

To access the controller

QC Terminals The terminals at the back of the controller are locking QC terminals, which

cannot be pulled off without pressing in the locking tabs.

Use needle nose pliers to unlock and gently remove the terminals.

1. Disconnect the chiller from the power supply.

2. Open the electronic controller box assembly by undoing the two fixing screws at the rear of the assembly. Note: On one door cabinets it is necessary to move the unit back to access the controller box assembly.

Replacement Procedures

Service Manual

SKOPE TME-N ActiveCore

Replacing the

Controller

Follow the steps below to replace the controller.

Note: Replacement spare part electronic controllers are not supplied with the parameter set loaded. This must be loaded via the SCS Connect Field app after replacing the controller. Internet access may be required.

To replace the controller

1. Disconnect the chiller from the power supply and access the electronic controller (see “Controller Location” on page 49).

2. Remove the cable clamps and disconnect the terminals from the back of the controller.

3. Fit the new replacement controller, and connect up the terminals at the back of the controller. Fit low voltage terminals before high voltage terminals.

4. Reassemble the controller box and cabinet, perform electrical safety test as required, and reconnect to the power supply.

5. Use a mobile device to connect to the controller with the SCS Connect Field app (see “SCS Connect Field App and Track App” on page 11).

6. Navigate to the LOAD PARAMETER FILE menu.

7. Select the appropriate parameter file from LOCAL. If not available in LOCAL, search for the parameter file in SERVER (internet access required), and download to LOCAL.

8. Confirm correct file and WRITE TO SCS.

9. After WRITE TO SCS is complete, select MENU DISCONNECT to save parameter set on SCS.

10. Power cycle the controller and check that correct parameter set has been applied

11. Power cycle the controller and check that correct parameter set has been applied

12. Set up controller and cabinet links as required:

Corporate

The service tech must link to the controller to the cabinet serial number in the SCS Connect Field app.

General Market

The owner must set up SKOPE-connect (if in use).

Controller

Flex 1 (red)

Controller

Flex 2 (blue)

Controller

Signal Flex (6-Way)

SKOPE TME-N ActiveCore

Replacement Procedures

Service Manual

Door Switch The chiller is fitted with a door switch above each door, which tells the

electronic controller when a door is opened. A small magnet in the door frame activates the switch. A cable connects the switch to the electronic controller via an inline connector on top of the cabinet.

To remove the door switch

Control Probe The control probe is cable tied to a bracket on the evaporator fan motor

bracket (see image below).

To replace the control probe

1. Disconnect the chiller from the power supply.

2. Disconnect the door switch cable plug from the inline connector on top of the cabinet.

3. Unscrew the two fixing screws from the door switch and remove.

4. Fit the replacement door switch and connect via the inline connector.

1. Remove the evaporator fan assembly (see page 46).

2. Detach the probe from the evaporator fan shroud bracket and trace the probe cable back to the unit electrics box and unplug (see page 42).

3. Following the same path as the original probe, fit the new probe with cable ties as necessary. Ensure the probe cable is securely plugged into the rear of the unit junction box, and that it is cable tied to the evaporator fan shroud bracket, with the probe bent away from the fan bracket at a 45° angle.

Replacement Procedures

Service Manual

SKOPE TME-N ActiveCore

Evaporator

Probe

The evaporator probe is located within the evaporator coil. It controls the refrigeration system defrost initiation and termination.

To replace the evaporator probe

1. Disconnect the chiller from the power supply and remove the refrigeration unit (see page 41).

2. Remove the unit cover (see page 44).

3. Remove the evaporator fan assembly (see page 46).

4. Remove both pieces of putty securing the pipes and cables on the evaporator tub perimeter.

5. Carefully lift the coil up and out of the evaporator tub. Take care of pipes and cables when lifting out.

6. Detach the probe from the side of the evaporator coil, and trace the probe cable back to the unit electrics box, cutting cable ties as required, and unplug (see page 42).

7. Following the same path as the original probe, run the new probe to the evaporator coil and secure with cable ties. Locate the probe in the same location as the original probe (against the side of the coil above the bottom pipe as pictured above). Plug the probe cable securely into the electrics box.

8. Reassemble the unit and test for correct operation.

SKOPE TME-N ActiveCore

Replacement Procedures

Service Manual

Condenser

Probe

The condenser probe is located on the side of the condenser coil. It monitors condenser temperature.

To replace the condenser probe

1. Disconnect the chiller from the power supply and remove the refrigeration unit (see page 41).

2. Remove the unit cover (see page 44).

3. Detach the probe from the side of the condenser coil, and trace the probe cable back to the unit electrics box, cutting cable ties as required, and unplug (see page 42).

4. Following the same path as the original probe, run the new probe to the condenser coil and secure with cable ties. Locate the probe in the same location as the original probe (as pictured above) and insulate with cork tape. Plug the probe cable securely into the electrics box.

5. Reassemble the unit and test for correct operation.

Replacement Procedures

Service Manual

SKOPE TME-N ActiveCore

Ambient Probe The ambient probe is located above the door. It monitors the temperature

around the refrigeration unit. Note: Th e a m b i e n t probe is wired in series with the door switch.

To replace the ambient probe

Ambient probe

1. Disconnect the chiller from the power supply (see page 30).

2. Remove the sign panel.

3. Detach the refrigeration unit and carefully push back or remove to allow access to the cabinet electrics cover.

4. Unscrew the cabinet electrics cover.

5. Detach the probe from the electrics cover, and trace the probe cable back to the connector, cutting cable ties as required, and unplug.

6. Fit the new probe and secure with cable ties. Ensure the probe is located in the same location as the original probe (as pictured above).

7. Reassemble the unit and test for correct operation.

Cabinet electrics cover

SKOPE TME-N ActiveCore

Replacement Procedures

Service Manual

Cleaning

Cabinet Wipe the inside and outside of the cabinet with a damp cloth, taking care to

keep moisture away from electrical parts. As with any maintenance, ensure the chiller is unplugged from the power supply before cleaning.

Condenser

Coil

To ensure trouble-free performance, the condenser coil must be kept clean. We strongly urge monthly cleaning with a soft brush to remove dust and fluff. A more thorough cleaning is required by qualified service personnel every six months. The condenser coil must be kept clean for efficient and reliable operation.

To clean the condenser coil and optional condenser filter

WARNING

Unplug the chiller from the power supply before cleaning the

condenser coil.

1. Isolate the chiller from the power supply.

2. Remove the front panel from the top of the cabinet by swinging it out and off. Lit sign front panels will also need to be unplugged.

3. Brush the condenser coil with a soft brush to remove any dust and fluff.

4. Refit the sign panel and reconnect to the power supply.

Important

When refitting, ensure the tabs on the back of the sign are located in the notches on top of the cabinet, and that the sign is pushed fully in and secure.

Front panel

Condenser coil

Tab and notch

Troubleshooting

Service Manual

SKOPE TME-N ActiveCore

8 Troubleshooting

Electronic Controller

Alarms signal unexpected operational changes in the cooler. When an alarm is activated, use the electronic controller app to assist with fault diagnosis and service as necessary. See page 11 for information.

Cabinet and Refrigeration Unit

Diagnostic

Table

For problems with the cabinet and refrigeration unit use the following table.

Problem Possible Cause Repair

• Cabinet not operating

• No controller display

• Loss of power supply • Check mains power supply.

• Loose plug in electrics

box

• Check all plugs in electrics box are connected correctly.

• Sign and/or Interior lights not on.

• Electronic controller is in ‘Night’ mode.

• Switch the light on while keeping the chiller in night mode by pressing the light button on the electronic controller faceplate.

• Change the chiller into ‘day’ mode by pressing and holding the DayNight button on the electronic controller faceplate, or hold the door open for ten seconds.

• Light switched off. • Switch light on via button on the electronic controller faceplate.

• Electronic controller

displays alarm indicating a refrigeration system error.

• Diagnose and repair. If system fault found, return to SKOPE.

• Failed LED light. • Service light.

• Excess noise vibration • Refrigeration pipes transferring vibration into unit

• Re-align pipes.

• Frozen evaporator coil • Set-point is too cold • Check and raise.

• Evaporator probe fault. • Check and replace evaporator probe.

• Controller fault • Replace controller.

• Short of refrigerant • Perform refrigeration system diagnostics (see page 48) and service as required.

Continued over page

SKOPE TME-N ActiveCore

Troubleshooting

Service Manual

• Power consumption is higher than expected

• Unit operating too hot • Clean the condenser.

• Ensure the cabinet has good ventilation around the refrigeration unit.

• Ensure the cabinet is within the maximum operating temperature.

• Cabinet door is opened excessively

• Ensure door is closed more often.

• Product too cold • Raise set point

• Product is too warm. • Frequent door opening. • Limit door openings.

• Recently loaded • Allow time for the product to cool down.

• Door not closing properly. • Check and clean door gasket.

• Refrigeration unit

operating too hot.

• Excessive door opening

or refrigeration heat load.

• Ensure the cabinet has good ventilation around the refrigeration unit.

• Ensure the cabinet is within the maximum operating conditions.

• Set point is to high • Lower set point.

• Moisture build up on door or exterior.

• High humidity. • Check ambient operating temperature and reposition chiller if necessary.

• Frequent door opening. • Limit door openings.

• Door not closing properly. • Check and clean door gasket.

• Chiller door does not shut properly.

• Chiller is on an uneven surface.

• Level the chiller.

• Door is obstructed. • Check shelves and

product.

• Warm cabinet temperatures

• Compressor operating for long periods (more than 1 hour)

• Blocked condenser • Clean the condenser.

• Poor ventilation around refrigeration unit

• Ensure the cabinet has good ventilation around the refrigeration unit.

• Ensure the cabinet is within the maximum operating temperature.

Troubleshooting

Service Manual

SKOPE TME-N ActiveCore

On-site work procedure

If a customer reports a ‘not cooling’ fault, and it has been established that the cabinet is not cooling, follow the procedure below when making the service visit.

Download data

using SCS

Connect Track

app (outside 1.5m

safe work area).

Safely isolate cabinet from

power supply.

Calibrate gas

detector (away

from potential

gas source).

Place gas detector on ground in front

of cabinet and wait 10 seconds. If no

gas detected on oor, open cooler

door and check for gas inside cabinet.

Is gas detected?

Connect cabinet to power supply.

Tag power supply

with ‘Out of

Service’ warning

label.

Refrigeration

system is

considered to

have a gas leak.

Check refrigeration characteristics

and component operations to

determine fault.

If fault is component (NOT sealed

refrigeration system), replace onsite

with authorised OEM part

Is fault in sealed

refrigeration

system?

Arrange

refrigeration unit

swap:

Ensure unit is available and

customer agrees

with swap.

Safely remove

unit from cabinet

(see pg. 41) and

move to the

service vehicle

area.

Fit replacement

unit.

Reload data

downloaded in

cell 2.

Procedure

continued over

page.

Create 1.5m safe

working area

around cabinet.

No Yes

Yes

SKOPE TME-N ActiveCore

Troubleshooting

Service Manual

On-site work procedure (continued)

Fit bullet (line

piercing) valves

to low and high

side of system.

Create a safe work area around faulty

unit. Area must be in open well

ventilated space. Ensure no hazards,

ignition sources or drains.

Fit HC gauge set.

Safely release gas

(do NOT release

gas into water).

After gas is

released, remove

gauges and t caps to valves.

Ensure valves not

leaking.

Send faulty unit for repair. The unit

must be transported in a suitably

ventilated vehicle, and must be stored

in a well ventilated place.

Label unit with

suspected fault.

Degas faulty unit

and return to

service depot:

Can gas be

released safely?

Yes

Transport unit in

gas safe vehicle

to safe area for

gas release.

SKOPE Contacts

SKOPE Industries Limited

A.B.N. 73 374 418 306 AU: 1800 121 535 NZ: 0800 947 5673 skope@skope.com

www.skope.com

Skope TME-N ActiveCore Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
