Skil 6410 Instruction Manual

IMPACT DRILL
6410 (F0156410..)

SKIL Europe BV - Konijnenberg 60 01/09 2610399528
4825 BD Breda - The Netherlands

www.skileurope.com

www.skilmasters.com

ORIGINAL INSTRUCTIONS . . . . . . . . . . . . . 7

NOTICE ORIGINALE . . . . . . . . . . . . . . . . . . 9

ORIGINALBETRIEBSANLEITUNG . . . . . .

12

ORIGINELE GEBRUIKSAANWIJZING. . . . 16

BRUKSANVISNING I ORIGINAL . . . . . . . . 19

ORIGINAL BRUGSANVISNING . . . . . . . . . 21

ORIGINAL DRIFTSINSTRUKS. . . . . . . . . .

24

ALKUPERÄISET OHJEET . . . . . . . . . . . . . 27

MANUAL ORIGINAL . . . . . . . . . . . . . . . . . 29

MANUAL ORIGINAL. . . . . . . . . . . . . . . . . . 33

ISTRUZIONI ORIGINALI . . . . . . . . . . . . . . 36

EREDETI HASZNÁLATI UTASÍTÁS. . . . . . 39

PÒVODNÍM NÁVODEM K POUÎÍVÁNÍ . . . 42

OR‹J‹NAL ‹fiLETME TAL‹MATI . . . . . . . . . 45

INSTRUKCJÑ ORYGINALNÑ. . . . . . . . . . . 47

ОРИГИНАЛНЬОЕ РУКОВОДСТВО

ПО ЭКСПЛУАТАЦИИ . . . . . . . . . . . . . . . .

51

ОРИГІНАЛЬНА ІНСТРУКЦІЯ

З ЕКСПЛУАТАЦІЇ . . . . . . . . . . . . . . . . . . .

54

ΠΡΩΤΟΤΥΠΟ Ο∆ΗΓΙΩΝ ΧΡΗΣΗΣ . . . . . . 57

INSTRUCØIUNI DE FOLOSIRE

ORIGINALE . . . . . . . . . . . . . . . . . . . . . . . .

61

ОРИГИНАЛНО РЪКОВОДСТВО

ЗА ЕКСПЛОАТАЦИЯ . . . . . . . . . . . . . . . .

64

PÔVODN¯ NÁVOD NA POUÎITIE. . . . . . . 67

ORIGINALNE UPUTE ZA RAD . . . . . . . . . 70

ORIGINALNO UPUTSTVO ZA RAD. . . . . . 73

IZVIRNA NAVODILA. . . . . . . . . . . . . . . . . . 76

ALGUPÄRANE KASUTUSJUHEND. . . . . . 78

ORI˛INÅLÅ LIETO·ANAS PAMÅC±BA . . . 81

ORIGINALI INSTRUKCIJA . . . . . . . . . . . . . 84

GB

F

D

NL

S

DK

N

FIN

E

P

I

H

CZ

TR

PL

RU

UA

GR

RO

BG

SK

HR

SRB

SLO

EST

LV

LT

ME77

2

6410

1

2

E

A

B

C

D

F

G

3

750

Watt

13 mm 16 mm

EPTA 01/2003

1,9 kg

0-3000/min

35 mm

2-13 mm

RUBBER

0-48000 p/min

3

6

5

4

4

7 8

9

C

PLASTICS

5

!

0

6

@

#

GB

Impact drill 6410
INTRODUCTION

• This tool is intended for impact drilling in brick, concrete
and stone as well as for drilling in wood, metal, ceramic
and plastic; tools with electronic speed control and left/
right rotation are also suitable for screwdriving and
thread cutting

• Read and save this instruction manual 2

TECHNICAL SPECIFICATIONS 1
TOOL ELEMENTS 3

A Switch for on/off and speed control
B Button for switch locking
C Wheel for maximum speed control
D Switch for changing direction of rotation
E Switch for selecting drilling function
F Auxiliary handle
G Depth gauge

SAFETY

GENERAL SAFETY INSTRUCTIONS

WARNING! Read all safety warnings and all

instructions. Failure to follow the warnings and

instructions may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for future
reference. The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or battery­operated (cordless) power tool.

1) WORK AREA SAFETY

a) Keep work area clean and well lit.

Cluttered or dark areas invite accidents.

b) Do not operate power tools in explosive

atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks

which may ignite the dust or fumes.

c) Keep children and bystanders away while operating

a power tool. Distractions can cause you to lose
control.

2) ELECTRICAL SAFETY

a) Power tool plugs must match the outlet.

Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools.

Unmodifi ed plugs and matching outlets will reduce risk
of electric shock.

b) Avoid body contact with earthed or grounded

surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric

shock if your body is earthed or grounded.

c) Do not expose power tools to rain or wet conditions.

Water entering a power tool will increase the risk of
electric shock.

d) Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase

the risk of electric shock.

e) When operating a power tool outdoors,

use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk
of electric shock.

f) If operating a power tool in a damp location is

unavoidable, use an earth leakage circuit breaker.
Use of an earth leakage circuit breaker reduces the risk
of electric shock.

3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use

common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication.

A moment of inattention while operating power tools
may result in serious personal injury.

b) Use personal protective equipment. Always wear

eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.

c) Prevent unintentional starting. Ensure the switch is

in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your fi nger on the

switch or energising power tools that have the switch
on invites accidents.

d) Remove any adjusting key or wrench before turning

the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.

e) Do not overreach. Keep proper footing and balance

at all times. This enables better control of the power
tool in unexpected situations.

f) Dress properly. Do not wear loose clothing or

jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long

hair can be caught in moving parts.

g) If devices are provided for the connection of dust

extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection

can reduce dust-related hazards.

4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power

tool for your application. The correct power tool will

do the job better and safer at the rate for which it was
designed.

b) Do not use the power tool if the switch does not turn

it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.

7

c) Disconnect the plug from the power source and/or

the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce

the risk of starting the power tool accidentally.

d) Store idle power tools out of the reach of children

and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.

Power tools are dangerous in the hands of untrained
users.

e) Maintain power tools. Check for misalignment or

binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly

maintained power tools.

f) Keep cutting tools sharp and clean.

Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits etc.,

in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations

different from those intended could result in a
hazardous situation.

5) SERVICE

a) Have your power tool serviced by a qualified repair

person using only identical replacement parts.

This will ensure that the safety of the power tool is
maintained.

SAFETY INSTRUCTIONS FOR IMPACT DRILLS

• Wear ear protectors with impact drills (exposure to
noise can cause hearing loss)

• Use auxiliary handles supplied with the tool (loss of
control can cause personal injury)

• Hold the power tool only by the insulated gripping

surfaces when performing an operation where the
accessory may contact hidden wiring or its own
power cord (contact with a “live” wire will also make

exposed metal parts of the power tool “live” and shock
the operator); always use auxiliary handle F 3

• Use suitable detectors to find hidden utility lines or
call the local utility company for assistance (contact
with electric lines can lead to fi re or electrical shock;
damaging a gas line can result in an explosion;
penetrating a water pipe will cause property damage or
an electrical shock)

• Avoid damage that can be caused by screws, nails and
other elements in your workpiece; remove them before
you start working

• Always keep the cord away from moving parts of the
tool

• Secure the workpiece (a workpiece clamped with
clamping devices or in a vice is held more securely than
by hand)

• When you put away the tool, switch off the motor and
ensure that all moving parts have come to a complete
standstill

• Use completely unrolled and safe extension cords with
a capacity of 16 Amps (U.K. 13 Amps)

• In case of electrical or mechanical malfunction,
immediately switch off the tool and disconnect the plug

• SKIL can assure fl awless functioning of the tool only
when the correct accessories are used which can be
obtained from your SKIL dealer

• Use only accessories with an allowable speed matching
at least the highest no-load speed of the tool

• This tool should not be used by people under the age of
16 years

• Do not work materials containing asbestos (asbestos
is considered carcinogenic)

• Dust from material such as paint containing lead, some
wood species, minerals and metal may be harmful
(contact with or inhalation of the dust may cause
allergic reactions and/or respiratory diseases to the
operator or bystanders); wear a dust mask and work

with a dust extraction device when connectable

• Certain kinds of dust are classifi ed as carcinogenic
(such as oak and beech dust) especially in conjunction
with additives for wood conditioning; wear a dust

mask and work with a dust extraction device when
connectable

• Follow the dust-related national requirements for the
materials you want to work with

• If the cord is damaged or cut through while working, do
not touch the cord, but immediately disconnect the plug

• Never use the tool when cord is damaged; have it
replaced by a qualifi ed person

• Always check that the supply voltage is the same as the
voltage indicated on the nameplate of the tool (tools
with a rating of 230V or 240V can also be connected to
a 220V supply)

• If the drill bit becomes unexpectedly jammed (causing a
sudden, dangerous reaction), immediately switch off the
tool

• Be aware of the forces that occur as a result of jamming
(especially when drilling metals); always use auxiliary

handle F

• Always disconnect plug from power source before
making any adjustment or changing any accessory

WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):

• Do not connect the blue (= neutral) or brown (= live) wire
in the cord of this tool to the earth terminal of the plug

• If for any reason the old plug is cut off the cord of this
tool, it must be disposed of safely and not left
unattended

3 and take a secure stance

USE

• On/off 4

• Switch locking for continuous use 5

• Speed control for smooth starting 6

• Maximum speed control 7

- switch on the tool

- lock the switch

- turn wheel C to select maximum speed

8

• Changing direction of rotation 8

- when not properly set in left/right position,
switch A cannot be activated

! change direction of rotation only when tool is at a

complete standstill

• Normal drilling/screwdriving versus impact drilling 9

! select drilling function only when tool is switched

off and plug is disconnected

• Changing bits 0

- insert the bit as deep as possible in the chuck

! do not use bits with a damaged shank
! only use sharp bits

• Adjusting drilling depth !

• Holding and guiding the tool @

! while working, always hold the tool at the grey-

coloured grip area(s)

- always use auxiliary handle F 3 (can be adjusted
as illustrated)

- keep the ventilation slots uncovered

- do not apply too much pressure on the tool; let the
tool do the work for you

APPLICATION ADVICE

• For drilling in concrete or stone a steady pressure on
the drill is required

• When drilling ferrous metals

- pre-drill a smaller hole, when a large hole is required

- lubricate drill bit occasionally with oil

• When turning in a screw at/near the cross cut end or an
edge of wood, pre-drill a hole in order to avoid cracking
of the wood

• Vibration level

The vibration emission level stated at the back of this

instruction manual (indicated by an asterisk) has been
measured in accordance with a standardised test given
in EN 60745; it may be used to compare one tool with
another and as a preliminary assessment of exposure to
vibration when using the tool for the applications
mentioned

- using the tool for different applications, or with

different or poorly maintainted accessories, may
signifi cantly increase the exposure level

- the times when the tool is switched off or when it is

running but not actually doing the job, may
signifi cantly reduce the exposure level

! protect yourself against the effects of vibration by

maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns

MAINTENANCE / SERVICE

• Always keep tool and cord clean (especially the
ventilation slots)

! disconnect the plug before cleaning

• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools

- send the tool undismantled together with proof of

purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skilmasters.com)

ENVIRONMENT

• Do not dispose of electric tools, accessories and
packaging together with household waste material

(only for EU countries)

- in observance of European Directive 2002/96/EC on

waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility

- symbol # will remind you of this when the need for

disposing occurs

F

Perceuse à percussion 6410
INTRODUCTION

• Cet outil est conçu pour les travaux de perçage en
frappe dans la brique, le béton et dans la pierre naturelle
ainsi que le perçage dans le bois, le métal, la céramique
et les matières plastiques; les outils avec réglage
électronique de la vitesse et rotation à droite/à gauche
sont également appropiés pour le vissage et le fi letage

• Lisez et conservez ce manuel d’instructions 2

SPECIFICATIONS TECHNIQUES 1
ELEMENTS DE L’OUTIL 3

A Interrupteur de marche/arrêt et réglage de vitesse
B Bouton de blocage de l’interrupteur
C Molette de réglage de la vitesse maximum
D Commutateur pour inverser le sens de rotation
E Commutateur pour sélectionner la fonction de perçage
F Poignée auxiliaire
G Jauge de profondeur

SECURITE

INSTRUCTIONS GENERALES DE SECURITE

ATTENTION! Lisez tous les avertissements de

sécurité et toutes les instructions. Ne pas suivre les

avertissements et instructions peut entraîner un choc
électrique, un incendie et/ou de graves blessures sur les
personnes. Conservez tous les avertissements et

toutes les instructions pour pouvoir s’y reporter
ultérieurement. La notion d’”outil électroportatif” dans les

avertissements se rapporte à des outils électriques
raccordés au secteur (avec câble de raccordement) et à
des outils électriques à batterie (sans câble de
raccordement).

9

CE DECLARATION OF CONFORMITY We declare under our sole responsibility that this product is in conformity with the following

GB

standards or standardized documents: EN 60 745, EN 55 014, in accordance with the provisions of the directives 2006/95/EC,
2004/108/EC, 98/37/EC (until Dec. 28, 2009), 2006/42/EC (from Dec. 29, 2009 on).
NOISE/VIBRATION Measured in accordance with EN 60 745 the sound pressure level of this tool is 94 dB(A), the sound power level
105 dB(A) (standard deviation: 3 dB) and the vibration ✱ m/s

Technical file at: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE DÉCLARATION DE CONFORMITÉ Nous déclarons sous notre propre responsabilité que ce produit est en conformité avec

F

les normes ou documents normalisés suivants: EN 60 745, EN 55 014, conforme aux réglementations 2006/95/CE, 2004/108/CE,
98/37/CE (jusqu’au 28.12.2009), 2006/42/CE (à partir du 29.12.2009).
BRUIT/VIBRATION Mesuré selon EN 60 745 le niveau de la pression sonore de cet outil est 94 dB(A), le niveau de la puissance
sonore 105 dB(A) (déviation standard: 3 dB) et la vibration ✱ m/s

Dossier technique auprès de: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE KONFORMITÄTSERKLÄRUNG Wir erklären in alleiniger Verantwortung, daß dieses Produkt mit den folgenden Normen oder

D

normativen Dokumenten übereinstimmt: EN 60 745, EN 55 014, gemäß den Bestimmungen der Richtlinien 2006/95/EG,
2004/108/EG, 98/37/EG (bis 28.12.2009), 2006/42/EG (ab 29.12.2009).
GERÄUSCH/VIBRATION Gemessen gemäß EN 60 745 beträgt der Schalldruckpegel dieses Gerätes 94 dB(A), der Schal­leistungspegel 105 dB(A) (Standard- abweichung: 3 dB) und die Vibration ✱ m/s

Technische Unterlagen bei: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE CONFORMITEITSVERKLARING Wij verklaren, dat dit product voldoet aan de volgende normen of normatieve documenten:

NL

EN 60 745, EN 55 014, overeenkomstig de bepalingen van de richtlijnen 2006/95/EG, 2004/108/EG, 98/37/EG (tot 28-12-2009),
2006/42/EG (vanaf 29-12-2009).
GELUID/VIBRATIE Gemeten volgens EN 60 745 bedraagt het geluidsdrukniveau van deze machine 94 dB(A), het geluids­vermogen-niveau 105 dB(A) (standaard deviatie: 3 dB) en de vibratie ✱ m/s

Technisch dossier bij: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE KONFORMITETSFÖRKLARING Vi intygar och ansvarar för, att denna produkt överensstämmer med följande norm och

S

dokument: EN 60 745, EN 55 014, enl. bestämmelser och riktlinjema 2006/95/EG, 2004/108/EG, 98/37/EG (till 28.12.2009),
2006/42/EG (from 29.12.2009).
LJUD/VIBRATION Ljudtrycksnivån som uppmätts enligt EN 60 745 är på denna maskin 94 dB(A), ljudeffektnivån 105 dB(A)
(standard deviation: 3 dB) och vibration ✱ m/s

Teknisk tillverkningsdokumentation finns hos: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE KONFORMITETSERKLÆRING Vi erklærer under almindeligt ansvar, at dette produkt er i overensstemmelse med følgende

DK

normer eller normative dokumenter: EN 60 745, EN 55 014, i henhold til bestem melserne i direktiverne 2006/95/EF, 2004/108/EF,
98/37/EF (indtil 28.12.2009), 2006/42/EF (fra 29.12.2009).
STØJ/VIBRATION Måles efter EN 60 745 er lydtrykniveau af dette værktøj 94 dB(A), lydeffektniveau 105 dB(A)
(standard deviation: 3 dB) og vibrationsniveauet ✱ m/s
Teknisk dossier hos: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

2

(hand-arm metod).

2

(hand-arm method).

2

(méthode main-bras).

2

(hånd-arm metoden).

2

(Hand-Arm Methode).

2

(hand-arm methode).

CE SAMSVARSERKLÆRING Vi erklærer at det er under vårt ansvar at dette produkt er i samsvar med følgende standarder eller

N

standard- dokumenter: EN 60 745, EN 55 014, i samsvar med reguleringer 2006/95/EF, 2004/108/EF, 98/37/EF (frem til 28.12.2009),
2006/42/EF (fra 29.12.2009).
STØY/VIBRASJON Målt ifølge EN 60 745 er lydtrykknivået av dette verktøyet 94 dB(A), lydstyrkenivået 105 dB(A) (standard
deviasjon: 3 dB) og vibrasjonsnivået ✱ m/s

Tekniske underlag hos: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE TODISTUS STANDARDINMUKAISUUDESTA Todistamme täten ja vastaamme yksin siitä, että tämä tuote en allalueteltujen

FIN

standardien ja standardoimisasiakirjojen vaatimusten mukainen EN 60 745, EN 55 014, seuraavien sääntöjen mukaisesti 2006/95/EY,
2004/108/EY, 98/37/EY (28.12.2009 asti), 2006/42/EY (29.12.2009 alkaen).
MELU/TÄRINÄ Mitattuna EN 60 745 mukaan työkalun melutaso on 94 dB(A), yleensä työkalun äänen voimakkuus on 105 dB(A)
(keskihajonta: 3 dB) ja tärinän voimakkuus ✱ m/s

Tekninen tiedosto kohdasta: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE DECLARACION DE CONFORMIDAD Declaramos bajo nuestra sola responsabilidad que este producto está en conformidad

E

con las normas o documentos normalizados siguientes: EN 60 745, EN 55 014, de acuerdo con las regulaciones 2006/95/CE,
2004/108/CE, 98/37/CE (hasta el 28.12.2009), 2006/42/CE (a partir del 29.12.2009).
RUIDOS/VIBRACIONES Medido según EN 60 745 el nivel de la presión acústica de esta herramienta se eleva a 94 dB(A),
el nivel de la potencia acústica 105 dB(A) (desviación estándar: 3 dB) y la vibración a ✱ m/s
Expediente técnico en: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

2

(hånd-arm metode).

2

(käsi-käsivarsi metodi).

2

(método brazo-mano).

09 SKIL Europe BV A. v.d. Kloot

88

CE DECLARAÇÃO DE CONFIRMIDADE Declaramos sob nossa exclusiva responsabilidade que este producto cumpre as

P

seguintes normas ou documentos normativos: EN 60 745, EN 55 014, conforme as disposições das directivas 2006/95/CE,
2004/108/CE, 98/37/CE (até 28.12.2009), 2006/42/CE (a partir de 29.12.2009).
RUÍDO/VIBRAÇÕES Medido segundo EN 60 745 o nível de pressão acústica desta ferramenta é 94 dB(A), o nível de potência
acústica 105 dB(A) (espaço de erro: 3 dB) e a vibração ✱ m/s

Processo técnico em: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE DICHIARAZIONE DI CONFORMITÀ Dichiaramo, assumendo la piena responsabilità di tale dichiarazione, che il prodotto è

I

conforme alle seguenti normative e ai relativi documenti: EN 60 745, EN 55 014 in base alle prescrizioni delle direttive 2006/95/EG,
2004/108/EG, 98/37/EG (fino al 28.12.2009), 2006/42/EG (a partire dal 29.12.2009).
RUMOROSITÀ/VIBRAZIONE Misurato in conformità al EN 60 745 il livello di pressione acustica di questo utensile è 94 dB(A),
il livello di potenza acustica 105 dB(A) (deviazione standard: 3 dB) e la vibrazione ✱ m/s
Fascicolo tecnico presso: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE MINÖSÉGI TANUSÍTVÁNY Teljes felelösségünk tudatában kijelentjük, hogy jelen termék a következö szabványoknak vagy

H

kötelezö hatósági elöírásoknak megfelel: EN 60 745, EN 55 014, a 2006/95/EK, 2004/108/EK, 98/37/EK (2009.12.28-ig),
2006/42/EK (2009.12.29-től kezdve) elöírásoknak megfelelöen.

ZAJ/REZGÉS Az EN 60 745 alapján végzett mérések szerint ezen készülék hangnyomás szintje 94 dB(A), hangteljesítmény szintje
105 dB(A) (normál eltérés: 3 dB) a rezgésszám ✱ m/s

A műszaki dokumentáció a következő helyen található: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE STRVZUJÍCÍ PROHLÁŠENÍ Potvrzujeme na odpovědnost, že tento výrobek odpovídá následujícím normám nebo normativním

CZ

podkladům: EN 60 745, EN 55 014, podle ustanovení směrnic 2006/95/ES, 2004/108/ES, 98/37/ES (do 28.12.2009), 2006/42/ES
(od 29.12.2009).
HLUČNOSTI/VIBRACÍ Měřeno podle EN 60 745 činí tlak hlukové vlny tohoto přístroje 94 dB(A), dávka hlučnosti 105 dB(A)
(standardní odchylka: 3 dB) a vibrací ✱ m/s
Technická dokumentace u: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE STANDARDIZASYON BEYANI Yeğane sorumlu olarak, bu ürünün aşağıdaki standartlara veya standart belgelerine uygun

TR

olduğunu beyan ederiz: EN 60 745, EN 55 014, yönetmeliği hükümleri uyarınca 2006/95/EG, 2004/108/EG, 98/37/EG
(28.12.2009 tarihine kadar), 2006/42/EG (29.12.2009 tarihinden itibaren).
GÜRÜLTÜ/TİTREŞIM Ölçülen EN 60 745 göre ses basıncı bu makinanın seviyesi 94 dB(A), çalışma sırasındaki gürültü 105 dB(A)
(standart sapma: 3 dB) ve titreflim ✱ m/s

Teknik belgelerin bulunduğu merkez: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

OŚWIADCZENIE ZGODNOŚCI CE Niniejszym oświadczamy ponosząc osobistą odpowiedzialność, że produkt wykonany jest

PL

zgodnie z następującymi normami i dokumentami normalizującymi: EN 60 745, EN 55 014, z godnie z wytycznymi 2006/95/EU,
2004/108/EU, 98/37/EU (do 28.12.2009), 2006/42/EU (od 29.12.2009).

HAŁASU/WIBRACJE Pomiarów dokonano zgodnie z normą EN 60 745 ciśnienie akustyczne narzędzia wynosi 94 dB(A),
poziom mocy akustycznej 105 dB(A) (poziom odchylenie: 3 dB) zaś wibracje ✱ m/s

Dokumentacja techniczna: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

2

(metoda ruka-paže).

2

(el-kol metodu).

2

(método braço-mão).

2

(kézre-ható érték).

2

(metodo mano-braccio).

2

(metoda dłoń-ręka).

ЗАЯВЛЕНИЕ О СООТВЕТСТВИИ Мы с полной ответственностыо заявляем, что это изделие соответствует следующим

RU

стандартам или станда ртизованным документам: EN 60 745, EN 55 014, в соответсувии с инструкциями 2006/95/EC,
2004/108/EC, 98/37/EC (до 28.12.2009), 2006/42/EC (начиная с 29.12.2009).
ШУМНОСТИ/ВИБРАЦИИ При измерении в соответствии co стандартoм EN 60 745 уровень звукового давления для этого
инструмента составляет 94 дБ (A), уровeнь звуковой мощности - 105 дБ (A) (стандартное отклонение: 3 dB) и вибрации -

2

✱ м/с

(по методу для рук).

Техническая документация у: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE ВІДПОВІДНІСТЬ Ми заявляємо, що відповідність даного продукту наступним стандартам і регулюючим документам

UA

повністю нашою відповідальністю: EN 60 745, EN 55 014, відповідно до положень директив 2006/95/EG, 2004/108/EG,
98/37/EG до 28.12.2009 p.), 2006/42/EG (після 29.12.2009 p.).
ШУМ/ВІБРАЦІЯ Зміряний відповідно до EN 60 745 рівень тиску звуку даного інструменту 94 дБ(А), потужність звуку
105 дБ(А) (стандартне відхилення: 3 дБ) i вібрація ✱ м/с
Технічні документи в: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE ∆ΗΛΩΣΗ ΣΥΜΒΑΤΟΤΗΤΑΣ ∆ηλώνου>ε υπευθύνως τι το προϊν αυτ είναι κατασκευασ>ένο σύ>φωνα >ε τους εξής

GR

κανονισ>ούς ή κατασκευαστικές συστάσεις: EN 60 745, EN 55 014, κατά τις διατάξεις των κανονισ>ών της Κοινής Αγοράς
2006/95/EK, 2004/108/EK, 98/37/EK (έως 28.12.2009), 2006/42/EK (απ 29.12.2009).
ΘΟΡΥΒΟ/ΚΡΑ∆ΑΣΜΟΥΣ Μετρη>ένη σύµφωνα >ε EN 60 745 η στάθ>η ακουστικής πίεσης αυτού του εργαλείου ανέρχεται
σε 94 dB(A), η στάθ>η ηχητικής ισχύοςσ σε 105 dB (κοινή απκλιση: 3 dB) και ο κραδασµς σε ✱ m/s
βραχίονα).
Τεχνικς φακελος απ: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

2

(ручна методика).

2

(>εθοδος χειρς/

09 SKIL Europe BV A. v.d. Kloot

89

DECLARAŢIE DE CONFORMITATE CE Declarăm pe proprie răspundere că acest product este conform cu următoarele standarde

RO

sau documente standardizate: EN 60 745, EN 55 014, în conformitate cu regulile 2006/95/CE, 2004/108/CE, 98/37/CE (până la

28.12.2009), 2006/42/CE (începând cu 29.12.2009).
ZGOMOT/VIBRAŢII Măsurat în conformitate cu EN 60 745 nivelul de presiune a sunetului generat de acest instrument este de
94 dB(A), nivelul de putere a sunetului 105 dB(A) (abaterea standard: 3 dB) iar nivelul vibraţiilor ✱ m/s
Documentaţie tehnicå la: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE ДЕKЛАPAЦИЯ ЗA CБOTВETCTBИE Декларираме на изцяло наша отговорност, че това изделие е съобразено със

BG

следните стандарти или стандартизирани документи: EN 60 745, EN 55 014, в съответствие с нормативната уредба на
2006/95/EG, 2004/108/EG, 98/37/EG (до 28.12.2009), 2006/42/EG (от 29.12.2009).
ШУМ/ВИБPAЦИИ Измерено в съответствие с EN 60 745 нивото на звуково налягане на този инструмент е 94 dB(A),
нивото на звукова мощност е 105 dB(A) (стандартно отклонение: 3 dB) а вибрациите са ✱ m/s
Подробни технически описания при: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE PREHLÁSENIE O ZHODE Výhradne na našu vlastnú zodpovednosť prehlasujeme, že tento výrobok zodpovedá nasledujúcim

SK

normám alebo normovaným dokumentom: EN 60 745, EN 55 014, v súlade s predpismi 2006/95/EG, 2004/108/EG, 98/37/EG
(do 28.12.2009), 2006/42/EG (od 29.12.2009).
HLUKU/VIBRÁCIÁCH Merané podľa EN 60 745 je úroveň akustického tlaku tohto nástroja 94 dB(A), úroveň akustického výkonu
je 105 dB(A) (štandardná odchýlka: 3 dB) a vibrácie sú ✱ m/s

Súbor technickej dokumentácie sa nachádzajú na adrese: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE IZJAVA O USKLA ĐENOSTI Izjavljujemo uz punu odgovornost da je ovaj proizvod usklađen sa slijedećim normama i

HR

normativnim dokumentima: EN 60 745, EN 55 014, prema odredbama smjernica 2006/95/EG, 2004/108/EG, 98/37/EG
(do 28.12.2009), 2006/42/EG (od 29.12.2009).

BUCI/VIBRACIJAMA Mjereno prema EN 60 745 prag zvučnog tlaka ovog električnog alata iznosi 94 dB(A), jakost zvuka
105 dB(A) (standardna devijacija: 3 dB) a vibracija ✱ m/s

Tehnička dokumentacija se može dobiti kod: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE IZJAVA O USKLA ĐENOSTI Pod punom odgovornošću izjavljujemo da je ovaj proizvod usklađen sa sledećim standardima ili

SRB

standardizovanim dokumentima: EN 60 745, EN 55 014, u skladu sa odredbama smernica 2006/95/EG, 2004/108/EG, 98/37/EG
(do 28.12.2009), 2006/42/EG (od 29.12.2009).
BUKA/VIBRACIJE Mereno u skladu sa EN 60 745 nivo pritiska zvuka ovog alata iznosi 94 dB(A), jačina zvuka 105 dB(A) (normalno
odstupanje: 3 dB) a vibracija ✱ m/s

Tehnička dokumentacija kod: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

IZJAVA O USTREZNOSTI CE Odgovorno izjavljamo, da je ta izdelek v skladu z naslednjimi standardi ali standardnimi dokumenti:

SLO

EN 60 745, EN 55 014, v skladu s predpisi navodil 2006/95/ES, 2004/108/ES, 98/37/ES (do 28.12.2009), 2006/42/ES
(od 29.12.2009).
HRUP/VIBRACIJA Izmerjeno v skladu s predpisom EN 60 745 je raven zvočnega pritiska za to orodje 94 dB(A), jakosti zvoka
105 dB(A) (standarden odmik: 3 dB) in vibracija ✱ m/s
Tehnična dokumentacija se nahaja pri: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

2

(mereno metodom na šaci-ruci).

2

(metóda ruka - paža).

2

(postupkom na šaci-ruci).

2

(metoda ‘dlan-roka’).

2

(metoda mînă - braţ).

2

(метод ръка-рамо).

CE VASTAVUSDEKLARATSIOON Kinnitame ainuvastutajana, et see toode vastab järgmistele standarditele või normdokumentidele:

EST

EN 60 745, EN 55 014 vastavalt direktiivide 2006/95/EÜ, 2004/108/EÜ, 98/37/EÜ (kuni 28.12.2009), 2006/42/EÜ (alates 29.12.2009)
nõuetele.
MÜRA/VIBRATSIOON Vastavalt kooskõlas normiga EN 60 745 läbi viidud mõõtmistele on antud seadme helirõhk 94 dB(A),
helitugevus 105 dB(A) (standardkõrvalekalle: 3 dB) ja vibratsioon ✱ m/s

Tehniline toimik saadaval aadressil: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE DEKLARĀCIJA PAR ATBILSTĪBU STANDARTIEM Mēs ar pilnu atbildību paziņojam, ka šis izstrādājums atbilst standartiem vai

LV

standartizācijas dokumentiem EN 60 745, EN 55 014 un ir saskaņā ar direktīvām 2006/95/EK, 2004/108/EK, 98/37/EK
(līdz 28.12.2009) un 2006/42/EK (no 29.12.2009).
TROKSNIS/VIBRĀCIJA Saskaņā ar standartu EN 60 745 noteiktais instrumenta radītā trokšņa skaņas spiediena līmenis ir
94 dB(A), skaņas jaudas līmenis ir 105 dB (A) (pie tipiskās izkliedes: 3 dB) un vibrācijas paātrinājums ir ✱ m/s

Tehniskā lieta no: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

CE ATITIKTIES DEKLARACIJA Mes atsakingai pareiškiame, kad šis gaminys atitinka tokius standartus ir normatyvinius

LT

dokumentus: EN 60 745, EN 55 014 pagal reglamentų 2006/95/EB, 2004/108/EB, 98/37/EB (iki 2009-12-28), 2006/42/EB
(nuo 2009-12-29) nuostatas.
TRIUKŠMINGUMAS/VIBRACIJA Šio prietaiso triukšmingumas buvo išmatuotas pagal EN 60 745 reikalavimus keliamo triukšmo
garso slėgio lygis siekia 94 dB(A), akustinio galingumo lygis 105 dB(A) (standartinis nuokrypis: 3 dB) ir vibracijos pagreitis rankos
plaštakos srityje tipiniu atveju yra mažesnis, kaip ✱ m/s
Techninė byla laikoma: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.

2

.

2

(käe-randme-meetod).

2

(roku-delnu metode).

09 SKIL Europe BV A. v.d. Kloot

90

91

123

When drilling in metal When impact drilling in concrete Uncertainty (K)

Pendant le perçage du métal Pendant le perçage de percussion du béton Incertitude (K)

Beim Bohren in Metall Beim Schlagbohren in Beton Unsicherheit (K)

Bij het boren in metaal Bij het klopboren in beton Onzekerheid (K)

Vid borrning i metall Vid slagborrning i betong Onoggrannhet (K)

Ved boring i metal Ved slagboring i beton Usikkerhed (K)

Ved boring i metall Ved slagboring i betong Usikkerhet (K)

Metalliin porattaessa Betoniin iskuporattaessa Epävarmuus (K)

Al taladrar en metal Al taladrar con percusión en hormigón Incertidumbre (K)

Ao perfurar en metal Ao perfurar com percussão em betão Incerteza (K)

Nella foratura nel metallo Nella foratura a percussione nel cemento Incertezza (K)

Fém fúrásakor Beton ütvefúrásakor Szórás (K)

Pfii vrtání do kovu Pfii vrtání do betonu s pfiíklepem Nepfiesnost (K)

Metalde delerken Betonde darbeli delerken Tolerans (K)

Podczas wiercenia w metalie Podczas wiercenia udarowego w betonie B∏àd pomiaru (K)

Пpи свеpлении в металле Пpи свеpлении с ударом в бетоне Недостоверность (K)

Свердління в металі Свердління з ударом в бетоні Похибка (K)

Oταν τρυπάτε σε µέταλλo Oταν τρυπάτε µε κρούση σε µπετν Ανασφάλεια (K)

Când gåuriøi în metal Când gåuriøi cu percuøie în beton Incertitudine (K)

Пpи пpобиване в метал Пpи удаpно пpобиване в бетон Неопределеност (K)

Pri v⁄taní do kovu Pri v⁄taní do betónu s príklepom NepresnosÈ (K)

Kod bu‰enja u metalu Kod udarnog bu‰enja u betonu Nesigurnost (K)

Pri bu‰enju metala Pri udarnom bu‰enju betona Nesigurnost (K)

Pri vrtanju v kovino Pri udarnem vrtanju v beton Netoãnost (K)

Metalli puurimisel Betooni löökpuurimisel Mõõtemääramatus (K)

Veicot urb‰anu metÇlÇ Veicot triecienurb‰anu betonÇ Izkliede (K)

Gr´Ïdami metalo Gr´Ïiant betonà smginiu reÏimu Paklaida (K)

LT

LV

EST

SLO

SRB

HR

SK

BG

RO

GR

UA

RU

PL

TR

CZ

H

I

P

E

FIN

N

DK

S

NL

D

F

GB

✱

6410

1 5,6 m/s

2

2 13,7 m/s

2

3 1,5 m/s

2
