SAFETY WARNING
Disregarding any of the safety precautions and instructions contained in this Operator’s Guide, Safety Handbook, Safety Video or
on-product warnings may result in injury, including the possibility
of death.
This Operator’s Guide, the Safety Handbook and Safety Video
should remain with the unit at time of resale.
In USA, products are distributed by Bombardier Motor Corporation
of America. In Canada, products are distributed by Bombardier Inc.
The following are trademarks of Bombardier Inc or its subsidiaries.
BOMBARDIER
ROTAX
RER
Printed in Canada (Mmo2002-006a.fm GM)
TM ®
©
2001 Bombardier Inc. All rights reserved.
®
TM
are trademarks and ® are registered trademarks of Bombardier Inc. or its subsidiaries.
®
MX-Z
DESS
®
TM
SKI-DOO
TM
DPM
®
2002 SKI-DOO OPERATOR’S GUIDE
This guide is applicable to the following model:
®
MX-Z
800 (2145)
1
FOREWORD
Congratulations on your purchase of a new SKI-DOO snowmobile.
Whatever model you have chosen, it is backed by the Bombardier
warranty and a network of authorized SKI-DOO snowmobile dealers
ready to provide the parts, service or accessories you may require.
The Operator’s Guide and the Safety Handbook have been prepared
to acquaint the owner/operator and passenger of a new snowmobile
with the various snowmobile controls, maintenance and safe operating instructions. Each is indispensable for the proper use of the product.
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. When used without
the safety alert symbol , potential hazard exists for property
damage only.
NOTE: Indicates supplementary information needed to fully com-
plete an instruction.
Although the mere reading of such information does not eliminate
the hazard, the understanding and application of the information will
promote the correct use of the vehicle.
Your dealer is committed to your satisfaction. He has taken training
to perform the initial set-up and inspection of your snowmobile as
well as completed the final adjustment required to suit your specific
weight and riding environment before you took possession. At delivery, your dealer would have explained the snowmobile controls and
provided you with a brief explanation of the various suspension adjustments. We trust you have taken full advantage of this!
WARNING
WARNING
At delivery, you were also informed of the warranty coverage and
completed the Warranty Registration Form which is to be sent to us
for processing.
2
The information and components/system descriptions contained in
this guide are correct at time of publication.
We also reserve the right at any time to discontinue or change specifications, designs, features, models or equipment without incurring
obligation.
The illustrations show the typical construction of the different assemblies and, in all cases, may not reproduce the full detail or exact shape
of the parts shown, however, they represent parts which have the
same or a similar function.
It is understood that this guide may be translated into another language. In the event of any discrepancy, the English version shall prevail.
Most components of this snowmobile are built with parts dimensioned in the metric system. Most fasteners are metric and must not
be replaced by customary fasteners or vice versa.
We recommend genuine Bombardier products for replacement parts
and accessories. They’ve been specially designed for your vehicle and
manufactured to meet Bombardier demanding standards.
A Shop Manual can be obtained for complete service, maintenance
and more repair information.
3
TABLE OF CONTENTS
SAFETY MEASURES............................................................ 7
LIST OF HOT PARTS................................................................ 8
LIST OF MOVING PARTS........................................................ 8
BOMBARDIER LIMITED WARRANTY NORTH AMERICA:
2002 SKI-DOO
BOMBARDIER LIMITED WARRANTY INTERNATIONAL:
2002 SKI-DOO
FREQUENTLY ASKED QUESTIONS....................................... 15
AUTHORIZED SKI-DOO DEALERS ......................................... 17
HOW TO IDENTIFY YOUR SNOWMOBILE ............................ 17
Vehicle Description Decal.......................................................... 17
Serial Numbers.......................................................................... 18
®
SNOWMOBILES............................................ 9
®
SNOWMOBILES............................................ 12
ON-VEHICLE IMPORTANT INSTRUCTIONS.......................... 20
CONTROLS/INSTRUMENTS/EQUIPMENT ........................... 25
1) Throttle Lever...................................................................... 26
2) Brake Lever ......................................................................... 26
3) Parking Brake Locking Lever............................................... 26
4) Parking Brake Pilot Lamp (Red)........................................... 28
5) Handlebar ............................................................................ 28
6) Start/RER Button................................................................. 33
7) Tether Cut-Out System ....................................................... 35
8) DESS/RER Pilot Lamp (Red)................................................ 38
9) Engine Cut-Out Switch........................................................ 38
10) Headlamp Dimmer Switch .................................................. 40
11) High Beam Pilot Lamp (Blue) .............................................. 40
12) Rewind Starter Handle ........................................................ 40
13) Choke Lever ........................................................................ 41
14) Speedometer....................................................................... 41
15) Mode Button ....................................................................... 43
16) Odometer............................................................................ 43
17) Trip Meter............................................................................ 43
18) Resetable Hourmeter .......................................................... 44
19) Tachometer ......................................................................... 44
20) Engine Overheat Warning Lamp (Red)................................ 44
21) Low Injection Oil Level (Red) .............................................. 44
4
22) Fuel Tank Cap ...................................................................... 45
23) Mechanical Fuel Level Gauge .............................................. 46
24) Heated Grip Switch.............................................................. 46
25) Heated Throttle Lever Switch.............................................. 47
26) Hood and Side Panel Latches .............................................. 48
27) Adjustable Toeholds............................................................. 50
28) Heated Carburetor Valve...................................................... 51
29) Storage Compartment ......................................................... 51
30) Tool Bag............................................................................... 52
31) Fuses ................................................................................... 53
32) Spare Spark Plug Holder ...................................................... 54
33) Spare Drive Belt Holder ....................................................... 55
34) Front Grab Handles/Front Bumper....................................... 56
35) Adjustable Suspensions....................................................... 56
General....................................................................................... 56
Guidelines to Adjust Suspension ............................................... 57
TROUBLESHOOTING CHART.................................................. 73
In Deep Snow ............................................................................ 73
FUEL AND OIL .......................................................................... 74
Recommended Fuel................................................................... 74
Recommended Oil..................................................................... 75
COLD WEATHER CARBURETION MODIFICATIONS ............. 76
BREAK-IN PERIOD.................................................................... 76
Engine........................................................................................ 76
Belt............................................................................................. 76
10-Hour Inspection..................................................................... 76
PRE-OPERATION CHECK......................................................... 77
PRE-OPERATION CHECK LIST ................................................ 78
OPERATING INSTRUCTIONS.................................................. 80
Principle of Operation ................................................................ 80
Starting the Engine .................................................................... 81
Emergency Starting ................................................................... 82
Shutting Off the Engine ............................................................. 84
VEHICLE WARM-UP................................................................. 85
POST-OPERATION CARE......................................................... 86
SPECIAL OPERATIONS............................................................ 86
Riding at High Altitudes ............................................................. 86
5
Engine Overheating................................................................... 86
Fuel Flooded Engine.................................................................. 86
Rear Suspension Slider Shoe Sticking....................................... 86
PERIODIC MAINTENANCE CHART......................................... 87
FLUID LEVELS.......................................................................... 89
Brake System............................................................................ 89
Chaincase Oil Level................................................................... 89
Oil Injection System .................................................................. 91
Cooling System ......................................................................... 92
MAINTENANCE ....................................................................... 93
Vehicle Cleaning and Protection................................................ 93
Belt Guard Removal and Installation ......................................... 94
Drive Belt Removal/Installation ................................................. 95
Drive Chain Tension .................................................................. 98
TRA Drive Pulley Adjustment.................................................... 99
Drive Belt Condition .................................................................. 101
Brake Condition......................................................................... 102
Brake Adjustment...................................................................... 102
Rear Suspension Condition ....................................................... 102
Suspension Stopper Strap Condition......................................... 102
Track Condition.......................................................................... 102
Track Tension and Alignment.................................................... 103
Steering and Front Suspension Mechanism ............................. 107
Wear and Condition of Skis and Runners.................................. 107
Exhaust System ........................................................................ 108
Air Filter Cleaning ...................................................................... 108
Headlight Beam Aiming............................................................. 109
Bulb Replacement..................................................................... 110
TOWING THE VEHICLE ........................................................... 111
TRANSPORTING THE VEHICLE.............................................. 111
STORAGE AND PRESEASON PREPARATION....................... 112
Storage...................................................................................... 112
Preseason Preparation .............................................................. 112
TROUBLESHOOTING .............................................................. 113
SPECIFICATIONS..................................................................... 116
CHANGE OF ADDRESS OR OWNERSHIP.............................. 117
PRIVACY OBLIGATIONS/DISCLAIMER ................................. 118
6
SAFETY MEASURES
Observe the Following Warnings:
For vehicles with a parking brake, always engage brake when ve-
hicle is not in use.
Throttle mechanism should be checked for free movement and
return to idle position before starting engine.
In an emergency, the snowmobile engine can be stopped by acti-
vating the engine cut-out button or pulling the tether cord.
Engine should be running only when belt guard is secured in place.
Never run the engine without drive belt installed. Running an unloaded engine such as without drive belt or with track raised, can
be dangerous.
Never run the engine with the hood or side panels opened or re-
moved.
Never run the engine in a non well-ventilated area and/or unattended.
Maintain your snowmobile in top mechanical condition at all times.
Your snowmobile is not designed to be operated on public streets,
roads or highways. In most States and Provinces, it is considered
an illegal operation.
Electric start models only: Never charge or boost a battery while
installed on snowmobile.
Do not lubricate throttle and/or brake cables and housings.
Only perform procedures as detailed in this guide. Unless other-
wise specified, engine should be turned OFF and cold for all lubrication, adjustment and maintenance procedures.
Snowmobile can carry a passenger only if an extra seat and a single
or double hand grip were installed.
The performance of this snowmobile may significantly exceed that
of other snowmobiles you have operated. Therefore, use by novice or inexperienced operators is not recommended.
The engine and components used in a particular model should not
be used on other models. Use of Rotax
®
snowmobile engines in
other than SKI-DOO snowmobiles is not recommended or authorized by Bombardier Inc.
Do not stud the track. At speed it may cause the track to tear and
separate from vehicle posing a risk of severe injury or death.
7
Electronic reverse (RER
TM
) models only: The shifting to reverse
mode on these snowmobiles is done by the push of the START/RER
button when the engine is running. Wait until the reverse alarm
sounds and the DESS
TM
/RER indicator lamp comes on in the clus-
ter gauge before operating throttle to proceed in reverse.
The reverse speed of these snowmobiles is not limited. Always pro-
ceed with caution as fast reverse could result in loss of vehicle
stability. Come to complete stop before selecting reverse gear. Always remain seated and apply the brake before shifting. Ensure the
path behind is clear of obstacles or bystanders before preceeding.
LIST OF HOT PARTS
All power train components.
LIST OF MOVING PARTS
All transmission, suspension and steering parts.
8
BOMBARDIER LIMITED WARRANTY NORTH
AMERICA: 2002 SKI-DOO
1. SCOPE OF THE LIMITED WARRANTY
BOMBARDIER INC. (hereinafter “BOMBARDIER”) warrants its 2002 SKI-DOO
snowmobiles from defects in material or workmanship for the period described
below.
All genuine BOMBARDIER parts and accessories, installed by an authorized
BOMBARDIER dealer (as hereinafter defined) at the time of delivery of the 2002
SKI-DOO snowmobile, carry the same warranty as that of the snowmobile.
Use of the product for racing or any other competitive activity, at any point,
even by a prior owner will render this warranty null and void.
2. WARRANTY COVERAGE PERIOD
This warranty will be in effect FROM THE DATE OF DELIVERY TO THE FIRST
RETAIL CONSUMER or the date the product is first put into use, whichever
occurs first and for a period of:
a. TWELVE (12) CONSECUTIVE MONTHS, for private use owners. The war-
ranty coverage period on a snowmobile delivered between June 1
December 1
or
b. TWELVE (12) CONSECUTIVE MONTHS, for commercial use owners. The
warranty coverage period on a snowmobile delivered between June 1
December 1
The repair or replacement of parts or the performance of service under this warranty does not extend the life of this warranty beyond its original expiration date.
st
of a given year will expire December 1st of the following year;
st
of a given year will expire December 1st of the following year.
®
SNOWMOBILES
st
and
st
and
3. CONDITIONS TO HAVE WARRANTY COVERAGE
This warranty coverage is available only on 2002 SKI-DOO snowmobile purchased as new and unused by its first owner from a BOMBARDIER dealer
authorized to distribute SKI-DOO products in the country in which the sale
occurred (hereinafter “BOMBARDIER dealer”), and then only after the
BOMBARDIER specified pre-delivery inspection process is completed and
documented. Warranty coverage only becomes available upon proper registration of the product by a BOMBARDIER dealer. Such limitations are necessary
in order to allow BOMBARDIER to preserve both the safety of its products, and
also that of its consumers and the public.
Routine maintenance outlined in the Operator’s Guide must be timely performed in order to maintain warranty coverage. BOMBARDIER reserves the
right to make warranty coverage contingent upon proof of proper maintenance.
4. WHAT TO DO TO OBTAIN WARRANTY COVERAGE
The customer must notify a servicing BOMBARDIER dealer within two (2) days
of the appearance of a defect, and provide it with reasonable access to the
product and reasonable opportunity to repair it. The customer must also present
to the BOMBARDIER dealer, proof of purchase of the product and must sign
the repair/work order prior to the start of the repair in order to validate the
warranty repair. All parts replaced under this limited warranty become the property of BOMBARDIER.
5. WHAT BOMBARDIER WILL DO
BOMBARDIER’s obligations under this warranty are limited to, at its sole dis-
cretion, repairing parts found defective under normal use, maintenance and
service, or replacing such parts with new genuine BOMBARDIER parts without
charge for parts and labor, at any authorized BOMBARDIER dealer.
BOMBARDIER reserves the right to improve or modify products from time to time
without assuming any obligation to modify products previously manufactured.
9
6. EXCLUSIONS - ARE NOT WARRANTED
• Normal wear and tear;
• Routine maintenance items, tune ups, adjustments;
• Damage caused by failure to provide proper maintenance and/or storage, as
described in the Operator’s Guide;
• Damage resulting from removal of parts, improper repairs, service, maintenance,
modifications or use of parts not manufactured or approved by BOMBARDIER
or resulting from repairs done by a person that is not an authorized servicing
BOMBARDIER dealer;
• Damage caused by abuse, abnormal use, neglect, use of the product on
surfaces other than snow, or operation of the product in a manner inconsistent with the recommended operation described in the Operator’s Guide;
• Damage resulting from accident, submersion, fire, theft, vandalism or any act
of God;
• Operation with fuels, oils or lubricants which are not suitable for use with
the product (see the Operator’s Guide);
• Snow or water ingestion;
• Incidental or consequential damages, or damages of any kind including with-
out limitation towing, storage, telephone, rental, taxi, inconvenience, insurance coverage, loan payments, loss of time, loss of income; and
• Damage resulting from tracks which have been studded.
7. LIMITATIONS OF LIABILITY
THIS WARRANTY IS EXPRESSLY GIVEN AND ACCEPTED IN LIEU OF ANY
AND ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING
WITHOUT LIMITATION ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT THAT THEY CANNOT BE DISCLAIMED, THE IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THE LIFE OF THE EXPRESS WARRANTY. INCIDENTAL AND
CONSEQUENTIAL DAMAGES ARE EXCLUDED FROM COVERAGE UNDER
THIS WARRANTY. SOME STATES/PROVINCES DO NOT ALLOW FOR THE
DISCLAIMERS, LIMITATIONS AND EXCLUSIONS IDENTIFIED ABOVE, AS
A RESULT, THEY MAY NOT APPLY TO YOU. THIS WARRANTY GIVES
YOU SPECIFIC RIGHTS, AND YOU MAY ALSO HAVE OTHER LEGAL
RIGHTS WHICH MAY VARY FROM STATE TO STATE, OR PROVINCE TO
PROVINCE.
Neither the distributor, any BOMBARDIER dealer nor any other person has
been authorized to make any affirmation, representation or warranty regarding
the product, other than those contained in this limited warranty, and if made,
shall not be enforceable against BOMBARDIER.
BOMBARDIER reserves the right to modify this warranty at any time, being
understood that such modification will not alter the warranty conditions applicable to the products sold while this warranty is in effect.
8. TRANSFER
If the ownership of a product is transferred during the warranty coverage period, this warranty shall also be transferred and be valid for the remaining coverage period provided that BOMBARDIER is notified of such transfer of ownership in the following way:
a. The former owner contacts BOMBARDIER (at the phone number provided
below) or an authorized BOMBARDIER dealer and gives the coordinates of
the new owner; or
b. BOMBARDIER or an authorized BOMBARDIER dealer receives a proof that
the former owner agreed to the transfer of ownership, in addition to the
coordinates of the new owner.
10
9. CONSUMER ASSISTANCE
a. In the event of a controversy or a dispute in connection with this BOMBARDIER
LIMITED WARRANTY, BOMBARDIER suggests that you try to resolve the
issue at the dealership level. We recommend discussing the issue with the
authorized dealer’s service manager or owner.
b. If the issue has not yet been resolved, please submit your complaint in
writing or call the appropriate number below:
In Canada: In USA:
BOMBARDIER INC. BOMBARDIER MOTOR
RECREATIONAL PRODUCTS CORPORATION OF AMERICA
SKI-DOO
®
CUSTOMER ASSISTANCE CENTER SKI-DOO
RECREATIONAL PRODUCTS
®
VALCOURT QC J0E 2L0 CUSTOMER ASSISTANCE CENTER
Tel: (819) 566-3366 P.O. BOX 8035
7575 BOMBARDIER COURT
WAUSAU WI 54402-8035
Tel: (715) 848-4957
© 2001 Bombardier Inc. All rights reserved
® Registered trademark of Bombardier Inc.
11
BOMBARDIER LIMITED WARRANTY
INTERNATIONAL: 2002 SKI-DOO
®
SNOWMOBILES
1. SCOPE OF THE LIMITED WARRANTY
BOMBARDIER INC. (hereinafter “BOMBARDIER”) warrants its 2002 SKI-DOO
snowmobiles from defects in material or workmanship for the period described
below.
All genuine BOMBARDIER parts and accessories, installed by an authorized
BOMBARDIER distributor/dealer (as hereinafter defined) at the time of delivery
of the 2002 SKI-DOO snowmobile, carry the same warranty as that of the snowmobile.
Use of the product for racing or any other competitive activity, at any point, even
by a prior owner will render this warranty null and void.
2. WARRANTY COVERAGE PERIOD
This warranty will be in effect FROM THE DATE OF DELIVERY TO THE FIRST
RETAIL CONSUMER or the date the product is first put into use, whichever
occurs first and for a period of:
a. TWELVE (12) CONSECUTIVE MONTHS, for private use owners. The war-
ranty coverage period on a snowmobile delivered between June 1
December 1
or
b. TWELVE (12) CONSECUTIVE MONTHS, for commercial use owners. The
warranty coverage period on a snowmobile delivered between June 1
December 1
The repair or replacement of parts or the performance of service under this
warranty does not extend the life of this warranty beyond its original expiration
date.
st
of a given year will expire December 1st of the following year;
st
of a given year will expire December 1st of the following year.
st
and
st
and
3. CONDITIONS TO HAVE WARRANTY COVERAGE
This warranty coverage is available only on 2002 SKI-DOO snowmobile purchased as new and unused by its first owner from a BOMBARDIER distributor/
dealer authorized to distribute SKI-DOO products in the country in which the
sale occurred (hereinafter “BOMBARDIER distributor/dealer”), and then only
after the BOMBARDIER specified pre-delivery inspection process is completed
and documented. Warranty coverage only becomes available upon proper registration of the product by a BOMBARDIER dealer. Such limitations are necessary in order to allow BOMBARDIER to preserve both the safety of its products,
and also that of its consumers and the public.
Routine maintenance outlined in the Operator’s Guide must be timely performed in order to maintain warranty coverage. BOMBARDIER reserves the
right to make warranty coverage contingent upon proof of proper maintenance.
4. WHAT TO DO TO OBTAIN WARRANTY COVERAGE
The customer must notify a servicing BOMBARDIER distributor/dealer within
two (2) days of the appearance of a defect, and provide it with reasonable access
to the product and reasonable opportunity to repair it. The customer must also
present to the BOMBARDIER dealer, proof of purchase of the product and
must sign the repair/work order prior to the start of the repair in order to validate
the warranty repair. All parts replaced under this limited warranty become the
property of BOMBARDIER.
12
5. WHAT BOMBARDIER WILL DO
BOMBARDIER’s obligations under this warranty are limited to, at its sole dis-
cretion, repairing parts found defective under normal use, maintenance and
service, or replacing such parts with new genuine BOMBARDIER parts without
charge for parts and labor, at any authorized BOMBARDIER distributor/dealer.
BOMBARDIER reserves the right to improve or modify products from time to
time without assuming any obligation to modify products previously manufactured.
6. EXCLUSIONS - ARE NOT WARRANTED
• Normal wear and tear;
• Routine maintenance items, tune ups, adjustments;
• Damage caused by failure to provide proper maintenance and/or storage, as
described in the Operator’s Guide;
• Damage resulting from removal of parts, improper repairs, service, maintenance, modifications or use of parts not manufactured or approved by
BOMBARDIER or resulting from repairs done by a person that is not an
authorized servicing BOMBARDIER dealer;
• Damage caused by abuse, abnormal use, neglect, use of the product on
surfaces other than snow, or operation of the product in a manner inconsistent with the recommended operation described in the Operator’s Guide;
• Damage resulting from accident, submersion, fire, theft, vandalism or any act
of God;
• Operation with fuels, oils or lubricants which are not suitable for use with the
product (see the Operator’s Guide);
• Snow or water ingestion;
• Incidental or consequential damages, or damages of any kind including with-
out limitation towing, storage, telephone, rental, taxi, inconvenience, insurance coverage, loan payments, loss of time, loss of income; and
• Damage resulting from tracks which have been studded.
7. LIMITATIONS OF LIABILITY
THIS WARRANTY IS EXPRESSLY GIVEN AND ACCEPTED IN LIEU OF ANY
AND ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING
WITHOUT LIMITATION ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT THAT THEY CANNOT BE DISCLAIMED, THE IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THE LIFE OF THE EXPRESS WARRANTY. INCIDENTAL AND
CONSEQUENTIAL DAMAGES ARE EXCLUDED FROM COVERAGE UNDER
THIS WARRANTY. SOME STATES/PROVINCES DO NOT ALLOW FOR THE
DISCLAIMERS, LIMITATIONS AND EXCLUSIONS IDENTIFIED ABOVE, AS
A RESULT, THEY MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU
SPECIFIC RIGHTS, AND YOU MAY ALSO HAVE OTHER LEGAL RIGHTS
WHICH MAY VARY FROM STATE TO STATE, OR PROVINCE TO PROVINCE.
Neither the distributor, any BOMBARDIER dealer nor any other person has been
authorized to make any affirmation, representation or warranty regarding the
product, other than those contained in this limited warranty, and if made, shall
not be enforceable against BOMBARDIER.
BOMBARDIER reserves the right to modify this warranty at any time, being
understood that such modification will not alter the warranty conditions applicable to the products sold while this warranty is in effect.
13
8. TRANSFER
If the ownership of a product is transferred during the warranty coverage period, this warranty shall also be transferred and be valid for the remaining coverage period provided that BOMBARDIER is notified of such transfer of ownership in the following way:
a. The former owner contacts BOMBARDIER or an authorized BOMBARDIER
distributor/dealer and gives the coordinates of the new owner; or
b. BOMBARDIER or an authorized BOMBARDIER distributor/dealer receives a
proof that the former owner agreed to the transfer of ownership, in addition
to the coordinates of the new owner.
9. CONSUMER ASSISTANCE
a. In the event of a controversy or a dispute in connection with this BOMBARDIER
LIMITED WARRANTY, BOMBARDIER suggests that you try to resolve the
issue at the distributorship/dealership level. We recommend discussing the
issue with the authorized dealer’s service manager or owner.
b. If further assistance is required, the distributor’s service department should
be contacted in order to resolve the matter.
© 2001 Bombardier Inc. All rights reserved
® Registered trademark of Bombardier Inc.
14
FREQUENTLY ASKED QUESTIONS
Q: Why must my snowmobile be registered at the factory? After all
I do have my original invoice as proof of when I purchased my
snowmobile.
A: Registration is very important and your SKI-DOO dealer must
register your snowmobile with Bombardier. Make sure the
registration form has been sent. All of this will allow you to:
a) have warranty work performed at any authorized SKI-DOO
dealer in North America. Your registration form will provide
the authorized SKI-DOO dealer with all the necessary data
to complete warranty claim forms.
b) be advised by Bombardier should there be a safety recall or
particular warranty campaign.
c) be contacted much faster by the police, the minute they
find your stolen snowmobile (if such a case occurs).
Q: Why must my snowmobile be registered with the governing
body having jurisdiction over snowmobile use?
A: Snowmobile registration has two purposes: In many provinces
or states it is mandatory to register a snowmobile in the same
way as for a car. It allows the state or province to maintain
records of existing snowmobiles and governmental agencies
use part of the registration fees for establishing and maintaining trails.
Q: Where can I find information on the lubrication and maintenance
of my snowmobile?
A: In the Operator’s Guide provided with the snowmobile at the
time of delivery.
Q: Will the entire warranty be voided or cancelled, if I do not operate
or maintain my new snowmobile exactly as specified in the Op-
erator’s Guide?
A: The warranty of the new snowmobile cannot be “Voided” or
“Cancelled” if predelivered by an authorized SKI-DOO dealer.
However, if a particular failure is caused by operation or maintenance other than is shown in the Operator’s Guide, THAT
failure may not be covered under warranty. This includes service work performed by the customer, especially the critical
adjustments: ignition timing, carburetion and oil injection/or oil
mixture.
15
Q: Would you give some examples of abnormal use or strain, ne-
glect or abuse which may affect warranty?
A: These terms are general and overlap each other in areas.
Some specific examples may include: running the snowmobile out of oil, chain failure caused by a Iack of lubrication, operating the snowmobile with a broken or damaged part which
causes another part to fail, and so on. If you have any specific
questions on operation or maintenance, please contact your
authorized SKI-DOO dealer for advice.
Q: What costs are my responsibility during the warranty period?
A: The customer’s responsibility includes all costs of normal
maintenance services, non-warranty repairs, accidents and
collision damage, as well as oils, and spark plugs, and incidental or consequential damage costs as explained in the warranty.
Q: Are “Genuine” Bombardier replacement parts used in warranty
repairs covered by warranty?
A: Yes. When installed by an authorized SKI-DOO dealer, any
“Genuine” Bombardier part used in warranty repairs assumes
the remaining warranty that exists on the snowmobile.
Q: If I sell my snowmobile within the warranty period, will the new
owner qualify for the balance of the warranty?
A: Yes, provided the re-sale has been registered with the manu-
facturer.
Q: How can I receive the best owner assistance?
A: The satisfaction and goodwill of the owners of Bombardier
products are of primary concern to your authorized SKI-DOO
dealer and Bombardier. Normally, any problems that arise in
connection with the sales transaction or the operation of your
snowmobile will be handled by your authorized SKI-DOO
Dealers Sales or Service Departments. It is recognized, however, that despite the best intentions of everyone concerned,
misunderstandings will sometimes occur. Frequently, complaints are the result of a breakdown in communications and
can quickly be resolved by a member of the authorized SKIDOO dealership management. If the problem already has
been reviewed with the Sales Manager or Service Manager,
contact the General Manager or the owner of this authorized
SKI-DOO dealership.
We are always pleased to receive your comments on the SKI-DOO
snowmobile.
16
AUTHORIZED SKI-DOO DEALERS
For Canada and USA Only
To find the nearest authorized SKI-DOO dealer, dial: 1-800-375-4366
or visit our web site at WWW.SKIDOO.COM.
HOW TO IDENTIFY YOUR SNOWMOBILE
Vehicle Description Decal
Vehicle description decal is located on right hand side of tunnel.
A33H01A
TYPICAL
1. Vehicle description decal
1
17
1
3
2
A00A6HB
VEHICLE DESCRIPTION DECAL
1. Manufacturer identification
2. Manufacturing date
3. Vehicle identification number (V.I.N.)
4. Model name
5. Option package
6. Engine type
7. Model year
8. Color codes
5
4687
Serial Numbers
The main components of your snowmobile (engine and frame) are
identified by different serial numbers. It may sometimes become
necessary to locate these numbers for warranty purposes or to trace
your snowmobile in the event of loss. These numbers are required
by the authorized SKI-DOO dealer to complete warranty claims properly. No warranty will be allowed by Bombardier Inc. if the engine
serial number or Vehicle Identification Number (V.I.N.) is removed or
mutilated in any way. We strongly recommend that you take note of
all the serial numbers on your snowmobile and supply them to your
insurance company.
Vehicle Identification Number (V.I.N.) Location
V.I.N. is scribed on vehicle description decal. See above. It is also
embossed on tunnel near vehicle description decal.
18
Model Number Location
Model number is part of vehicle identification number (V.I.N.).
X X X X X X X X X X X X X X X X X
Model number
A00A6IA
V.I.N. DESCRIPTION
Engine Serial Number Location
Serial number
A32C01B
TYPICAL
1. Engine serial number
1
19
ON-VEHICLE IMPORTANT INSTRUCTIONS
Please read the following instructions carefully before operating snowmobile.
1
5432
6
A33A02A
LOCATION OF IMPORTANT INSTRUCTIONS
Instruction 1
A33H0NA
20
Instruction 2
DO NOT SIT HERE / NE PAS SASSEOIR ICI
A33H02A
21
Instruction 3
A33A03A
22
A01A2EA
Instruction 4
A01A2FA
Instruction 5
23
A01A24D
Instruction 6
TYPICAL — ALL MODELS
24
CONTROLS/INSTRUMENTS/EQUIPMENT
29 30 28 32 31 33 34
A33H01B
TYPICAL
3
2
10
6
5
22
35
27 26 35
24
25
9
Callout
1
7
13
12
23
A33A01A
TYPICAL
26
2727
25
21
14
20
11
8
4
19
A33A05A
TYPICAL
15
16-17-18
1) Throttle Lever
Located on the right hand side of handlebar and designed to be
thumb activated. When squeezed, it increases the engine speed and
engages the transmission. When released, engine speed returns automatically to idle.
WARNING
Throttle lever must operate easily and smoothly. It must return
to idle position when released.
2) Brake Lever
Located on the left hand side of handlebar. When squeezed, the
brake is applied. When released, it automatically returns to its original
position. Braking effect is proportional to the pressure applied on the
lever and to the type of terrain and its snow coverage.
3) Parking Brake Locking Lever
Located on left hand side of handlebar. Parking brake should be used
whenever snowmobile is parked.
26
Whenever parking brake is applied and engine is running, brake/parking
brake pilot lamp lights up to remind you that it is engaged.
WARNING
Make sure brake lever lock is fully disengaged before operating the snowmobile.
When you ride the vehicle, brake that are caused to drag by a
continuous pressure on the lever may cause damage to the
brake system and cause loss of braking capacity and/or fire.
To engage mechanism, squeeze brake lever and maintain while pull-
ing locking lever with a finger. When brake lever is held at half-way
the parking brake should be fully applied.
To release mechanism, squeeze brake lever. Locking lever will automatically return to its original position. Brake lever now returns to rest
position. Always release parking brake before riding.
3
1
2
A33D01A
TYPICAL
1. Locking lever
2. OFF — Release
3. ON — Locked
27
4) Parking Brake Pilot Lamp (Red)
Lights when brake or parking brake is applied (with engine running).
5) Handlebar
The handlebar controls the steering of travel of the snowmobile. As
the handlebar is rotated to right or left, the skis are turned right or left
to steer the snowmobile.
Steering column position is adjustable. Proceed as follows.
There are 2 positions.
NOTE: Following procedure describes how to change steering col-
umn position from rearward to forward position.
Unscrew 4 bolts retaining windshield assembly to handlebar. Re-
move windshield ass’y.
A33H04A
ONE SIDE SHOWN
1. Bolts retaining windshield ass’y
28
1
Loading...
