Alliance™
Quick Reference Guide
This card is not meant to replace the
product user manual. For complete
manual, contact Sizewise.
800-814-9389
sizewise.com
Page 2
Components
Removable
Top Deck
Integrated Side
Rail Controls
Bed Length Extender
Side Rails
CPR Release
Handle
Footboard Controls
with RSS
Central Lock and
Steer Casters
To lower rail: Pull up on handle located under side rail. The rail will
gradually lower.
To raise rail: Pull the side rail upward to its highest position until it
locks in place.
Battery Backup
This bed is equipped with an emergency battery backup. The battery
will charge when plugged into an AC outlet.
Page 3
Casters
GREEN: locks right
foot caster parallel
with frame
Controls
Head Up/Down/Lock
RED: locks all casters NEUTRAL: all casters
move freely
Deck Flat
Cardio Chair
Head Up/Down
Feet Up/Down
Bed Up/Down
Under-Bed Lighting
Nurse Call
Bed Flat/Cardio Chair
Foot Up/Down/Lock
CPR
Nurse Call
Bed Up/Down/Lock
Lockout
Trend/Reverse
Trend and Lock
Rest Secure System™ (RSS)
instructions available in user
manual or separate Quick
Reference Guide.
To Lock/Unlock specic features: Press the (key button) and then
press the (lock button) associated with that feature. Repeating
this process will then unlock the feature. While this can only be
performed from the footboard control, it aects ALL controls.
Page 4
Code Situation
1. Unlock casters and pull bed from wall.
2. Engage brakes, remove headboard, and lower side rails for
patient access.
3. For LAL support surfaces: press CPR button or turn CPR dial on
blower and/or open CPR valve at head of mattress if installed.
4. Squeeze and hold CPR lever located at head of bed. You may also
use CPR button located on footboard control to atten deck.
5. Proceed with facility protocols for resuscitation.
Troubleshooting
Bed will not respond
— Verify all functions on footboard control are unlocked.
— Verify bed’s power cord is plugged into working
AC outlet and not cut, frayed, or damaged.
— Inspect patient hand control for damage and ensure it is
properly connected.
Function of bed doesn’t operate
— Verify function in question is unlocked on footboard control.
Bed will not operate on battery power
— Verify patient hand control is properly connected.
Warning: Before working on any electrical component, unplug bed
and disconnect battery. If these steps aren’t performed, damage to
the electrical system may occur.
If equipment continues to malfunction, contact Sizewise 24/7/365
at 800-814-9389
sizewise.com 800-814-9389
PRD-0002F-0319 27650028, Rev. 2.0
