Si-tex CVS-126 User's Manual

Download

CVS-126

CVS-126 Instruction Manual

Doc No. 0093132702

Document Revision History

No. Doc. No / Rev. No. Date Revised

Revised Content

0 0093132702-00 09/04/2008

1 0093132702-01 25/05/2008

Revision criteria for document number/version number

First edition

Chapter all

If any contents of the document has been revised, the version number is altered on the cover

sheet and corresponding chapter revised, while the other chapters remain unchanged. The

document number is designated lower right on the cover sheet and at the left or right part of every

footer.

Prohibition of copy/reprint

No part of this manual shall be reprinted or copied by any means without written permission by

Koden Electronics Co., Ltd.

Disclaimer

The specifications and technical issues described in this manual are subject to change without

notice. Koden Electronics Co., Ltd. has no responsibility for any human and physical damage or

failure caused by the interpretive error of this manual.

0093132702-01 i

Important Notice CVS-126

Important Notice

• The re-use and transcription of Instruction Manual (hereafter called this manual) needs permission of our company. Our company prohibits the un-authorized re-use and transcription.

• If this manual is lost or damaged, consult our dealer or our company.

• The specification of our products and the content in the Instruction Manual are subject to changed

without notice.

• In the explanation of this manual, the content displayed on the menu of product may be different. The keys and menus in the illustration may differ in physical font and shape. And some parts may be omitted.

• Our company is not liable for damage and trouble arisen from misunderstanding the content described in this manual.

• Our company is not liable for earthquake, lightning, fire for which our company is not responsible, action by third party, other accident, customer’s unintended error/abuse and damage caused by the use under other abnormal condition.

• Our company is not liable for damage of accompaniment (change/loss of memorized content, loss of business profit, stop of business) arisen from use or failure of our product.

• If the stored data is changed or lost, irrespective of any cause of trouble and damage, our company is not liable for it.

• Our company is not liable for any damage arisen from malfunction caused by combination of software and connected equipment we do not involve.

ii 0093132702-01

CVS-126 For Your Safe Operation

For Your Safe Operation

Pictorial used in this Instruction Manual

This Instruction Manual uses the following pictorials. Understand the meaning of each pictorial and

implement the maintenance and inspection.

Symbol Meaning

Mark for warning

This symbol denotes that there is a risk of death or serious injury when not dealing with it correctly.

Mark for danger high voltage

This symbol denotes that there is a risk of death or serious injury caused by electric shock when not dealing with it correctly.

Mark for caution

This symbol denotes that there is a risk of slight injury or damage of device when not dealing with it correctly.

Mark for prohibition

This symbol denotes prohibition of the specified conduct. Description of the prohibition is displayed near the mark.

Caution Item on Handling

Do not disassemble or modify. It may leads to trouble, fire, smoking or electric shock. In case of trouble, contact our dealer or our company.

In case of smoke or fire, boat power off and the power of this unit. It may cause fire, electric shock or damage.

Be cautious of remaining high voltage. A high voltage may remain in the capacitor for several minutes after you have powered off. Before inspecting inside, wait at least 5 minutes after powering off or discharge the remaining electricity in an appropriate manner. Then, start the work.

The information displayed in this unit is not provided directly for your navigation. For your navigation, be sure to see the specified material.

0093132702-01 iii

For Your Safe Operation CVS-126

Use the specified fuse. If un-specified fuse is used, it may cause a fire, smoke or damage.

Whenever transmitting, be sure to submerge the transducer in water first. If transmitted without submerging the transducer, it may be damaged.

Caution Item on Equipment

Be careful of a high voltage inside.

A high voltage, which may risk your life, is used. This high voltage remains in the circuit after you have powered off switch. To prevent touching the high voltage circuit inadvertently, the protection cover is provided to the high voltage circuit and the high voltage caution label is affixed. Ensure to power off switch for your safety and discharge the electricity remaining in the capacity before starting to check. An engineer authorized by our company should inspect and maintain

Be sure to power off in the boat.

If the power switch is inadvertently powered on during work, you will be electrified. To prevent such accident from occurring, ensure to power off in the boat and the power of equipment. Furthermore, it is safer to hang the caution tag described as [Under Work] near the power switch of equipment.

Be careful of dust

Inhaling dust may cause A respiratory disease. When cleaning the inside of equipment, be careful not to inhale dust. Wearing a safety mask is recommended.

Caution on location of equipment

Do not install the equipment where it is excessively damp and suffers from excessive water drops.

Escaping from static electricity

The static electricity may be generated from the carpet on the floor in the cabin or clothes made of synthetic fiber. The static electricity may destroy the electronic parts on the circuit board. Handle the circuit board, taking the measure of static electricity free.

Install the transducer at the location where it is not affected by bubble and noise The bubble and noise seriously degrade the performance of this unit.

iv 0093132702-01

CVS-126 Contents

Contents

Document Revision History....................ⅰ

Important Notice .....................................ⅱ

For Your Safe Operation ........................ⅲ

Contents .................................................ⅴ

Introduction.............................................. ⅶ

System Configuration............................... ⅷ

Configuration of Equipment...................... ⅹ

Chapter 1 Basic Operation...................... 1-1

1.1 How to use the key .................... 1-1

How to remove the protection

cover .......................................... 1-2

When removing the CVS-126

Display unit ................................ 1-2

1.2 Power On/Off ............................. 1-3

Power on.................................... 1-3

Power off.................................... 1-3

Selection of Echo sounder mode

and Depth mode ........................ 1-8

Fine-adjusting the Auto Gain ..... 1-9

Adjust the gain manually............ 1-9

Easy Gain Adjustment................ 1-9

Confirm the gain state.............. 1-10

1.7 Use of 【EVENT】 key.......... 1-10

Select the event. ...................... 1-10

Preset the destination. ............. 1-10

Store the image........................ 1-11

Start the homing....................... 1-11

1.8 Use of 【FUNC】 key ............ 1-12

How to use the 【FUNC】 key1-12

Preset of 【FUNC】 key ........ 1-12

1.9 Operation of VRM .................... 1-13

Chapter 2 How to use the Menu ............. 2-1

2.1 How to operate the menu .......... 2-1

Alarm of Power Voltage ............. 1-3

1.3 LCD Brilliance Adjustment ......... 1-4

Adjustment of LCD Brilliance ..... 1-4

Brightness Adjustment of Panel

Brilliance .................................... 1-4

1.4 Switch-over of Menu .................. 1-4

Normal Image (Low frequency,

high frequency) .......................... 1-4

Dual Frequency.......................... 1-5

Zoom (Low frequency, high

frequency) .................................. 1-5

Navigation Menu

(NAV1, NAV2) ............................ 1-7

1.5 Switch-over of Range................. 1-8

Set the range switching to auto

range. ......................................... 1-8

1.6 Gain Adjustment......................... 1-8

Display the menu. / Stop the

display of menu.......................... 2-1

Menu Operation ......................... 2-1

2.2 Change of Image Speed ............ 2-2

2.3 Rejection of Interference............ 2-2

Interference Rejection................ 2-2

2.4 Color Rejection of Weak Echo ... 2-2

Color Rejection .......................... 2-2

2.5 Rejection of Noise ...................... 2-3

Noise Rejection.......................... 2-3

2.6 Setting of Shift............................ 2-3

Setting of Fixed Shift.................. 2-3

Setting of Auto Shift. .................. 2-3

2.7 Setting of Zoom Range .............. 2-3

2.8 Setting of Zoom Start ................. 2-4

2.9 Setting of Background Color...... 2-4

2.10 Setting of White Line.................. 2-4

Basic Operation of Gain............. 1-8

0093132702-01 v

2.11 Preset of Range ......................... 2-5

2.12 Setting of Alarm.......................... 2-5

Contents CVS-126

Stopping the alarm sound ..........2-5

Setting the alarm ........................2-6

Release the alarm. .....................2-6

Confirm the alarm state. ............. 2-6

2.13 Preset/ WPT edit/ WPT delete of

Destination.................................2-6

NAV Start....................................2-6

Cancel the NAV. .........................2-7

Edit the destination.....................2-7

Delete the destination. ...............2-8

Recall the image stored and

preset it as a destination. ...........2-8

2.14 Store/Recall/Deletion of Image... 2-9

Store the image. .........................2-9

Recall the stored image. ............2-9

Delete the stored image. ............2-9

Add the comment to the stored

Image Swap .............................2-14

Chapter 3 How to use the system menu .3-1

3.1 Display of System Menu ............ 3-1

3.2 Setting of External In/Out ...........3-1

3.3 Setting of Correct Item ...............3-2

3.4 Setting of System Item ...............3-2

3.5 Setting of Basic Set Item ............ 3-3

3.6 Maintenance Menu.....................3-3

Chapter 4 Maintenance and Inspection...4-1

4.1 Inspection ...................................4-1

4.2 Cleaning .....................................4-1

4.3 Fuse Replacement .....................4-1

4.4 If you suspect a trouble ..............4-2

4.5 Diagnostic Test ........................... 4-3

Chapter 5 Installation..............................5-1

5.1 Item of Caution on Installation....5-1

image........................................2-10

2.15 Selection of Zoom ....................2-10

2.16 Selection of NAV Display ......... 2-11

Type of NAV Display................. 2-11

Dividing Method of Display....... 2-11

Selection of NAV Menu ............ 2-11

2.17 Explanation of Sonar ................2-12

Switch-over of Sonar Tone .......2-12

Connection of External

Speaker ....................................2-12

2.18 Explanation of Menu Item ........2-12

TVG ..........................................2-12

Change the TX power. .............2-12

Display the A scope. / Stop the

display of A scope. ...................2-13

Change the display color of echo

sounder image..........................2-13

5.2 Installation of CVS-126 Display

unit ..................................................5-2

5.3 Installation of Transducer ........... 5-5

5.4 Wiring .........................................5-7

5.5 Serial Data................................ 5-10

Chapter 6 Table Attached........................6-1

6.1 Menu List....................................6-1

6.2 Specification ...............................6-3

6.3 Appearance ................................6-4

Change the depth value. ..........2-13

Display the water temp graph. /

Stop the display of water temp

graph. .......................................2-13

Disp Width ................................2-13

vi 0093132702-01

CVS-126 Introduction

Introduction

The CVS-126 is a Dual frequency (50kHz/200kHz) Color LCD display echo sounder.

This unit equipped with digital process displays the circumstance in the water under all conditions, matching with the high luminance 5.7 inch LCD.

The main features of this unit are as follows.

• With the digital reception process, the compatibility of the high resolution in a shallow depth and the noise rejection capability in a deep depth are established. The auto mode function provides the best image.

• The unit can be installed in an open bridge and is highly waterproof.

• Up to 10 images can be stored. If you connect the optional GPS, the homing function, that directs

your boat to navigate easily to the location desired, is available by marking the event mark when recalling the stored image.

• The unit is designed to save power consumption. The white LED is adopted for illuminating the LCD and the power consumption is minimal in this class. The unit emits less heat and the occurrence of condensation is rare.

• The various alarm functions are available. (Bottom, school of fish, water temperature*, board speed*, arrival*, XTE*, power) (Note: The mark * denotes that the connection of option is mandatory)

• When flush-mounting, the unit can be easily installed from front side.

0093132702-01 vii

System Configuration CVS-126

GPS sensor

TD: transducer

External water temperature meter

/ speed sensor

System Configuration

Connection Diagram

CVS-126 Display unit

GPS-20A

External Navigation Equipment

* (Inner-hull, through-hull)

* TD-500T-2B (Inner-hull) * TD-500T-3B (through-hull) (Dual frequency combination type 50/200kHz)

Water temperature sensor

External speaker

(For speaker with amplifier)

(Prepared by a user)

viii 0093132702-01

ST-80/90/100

Requirement: Option cable (CW-840-0.3M) Note: To use the water temperature sensor / speed sensor, the wiring of transducer connector has to be changed.

DC10.8 31.2V

: Standard

: Option

CVS-126 System Configuration

DC10.8~31.2V

Connection to the water temperature sensor

hull

sensor

Transducer

To POWER connector

connector

CVS-126 echo sounder unit With mounting bracket and protection cover

Legend

Standard configuration

CW264-2M

External power output (For GPS etc)

Option

External speaker (For speaker with amplifier)

(Prepared by a user)

NMEA circuit input output GPS sensor (GPS-20A) External navigation equipment, external water temperature meter

Red

Black

Option cable (CW-840-0.3M)

Connection to the Transducer

Connection to the speed sensor

Note: To use the water temperature sensor / speed sensor, the wiring of transducer connector has to be changed.

Water temperature

/ speed sensor

ST/80/90/100

Transducer TD-500T-2B (Dual frequency combination type 50/200kHz) Plastic made Equipped with inner-

0093132702-01 ix

Transducer TD-500T-3B (Dual frequency combination type 50/200kHz) Bronze made Equipped with through-hull

Configuration of Equipment CVS-126

Configuration of Equipment

Standard Equipment Configuration List

1 Transmission-receiver

2 Protection cover

3 DC power cable

Name of item Type Remark Weight/

display unit

(Complex cable)

Quantity

Length

CVS-126 600W output

with mounting bracket and knob

C38MB12020 150g 1

CW-264-2M With 12 connector at

one end/ un-treated at the other end

1.3 kg

2m 1

4 Fuse

5 Trans Tapping Screw TPT5 x 20U For fixing CVS-126

6 Cap

7 Instruction Manual CVS-126.OM.E English 1

8 Quick Reference CVS-126.QR.E English 1

F-7161-2A Cylinder (ø6.3x32)

LTWCAP-DABCFXC1 For transducer cable

Normal fusion type for main power

Display unit

connector

x 0093132702-01

CVS-126 Configuration of Equipment

Essential Option

1 Transducer Type of transducer transducer cable (with

Name of item Type Remark Weight/

Length

9m 1

connector at one end)

Quantity

Type of transducer

1 TD-500T-2B

2 TD-500T-3B

Specification Frequency Material Mounting method

Option List

1 Water temperature

Name of Item Specification Remark Weight/Length

sensor / speed sensor

50/200kHz Plastic Inner-hull

(The inner-hull kit is needed.)

50/200kHz Bronze Through-hull

ST-80 For transom mounting

Plastic made (with cable)

ST-90 For through-hull mounting

Plastic made (with cable)

0.3kg/ 8m

0.6kg/ 8ｍ

ST-100 For through-hull mounting

Bronze made (with cable)

2 GPS sensor GPS-20A-10M-3 For GPS measuring

(With power & signal cable)

3 Inner-hull kit MFB-04 Plastic made for installing the

transducer TD-500T-2

4 Cable for transducer CW-840-0.3M Needed when using the

optional water temperature sensor / speed sensor.

0093132702-01 xi

1.2kg/ 8ｍ

250g/10m

1.3kg

30cm

Chapter 1 Basic Operation CVS-126

Chapter 1 Basic Operation

1.1

1.1 How to use the key

1.11.1

CVS-126 Display unit

1 2

5 4

In addition, for your convenience when operating keys other than keys in the menu by the【MENU】 key, the menu displayed automatically closes.

No. Key Name Explanation

1 【DISP】

2 【EVENT】

3 【Cursor】

4 【FUNC】 It recalls directly the item preset. 5 【MENU】 It opens or closes the menu. 6 【 RANGE 】 It changes the range setting.

7 【Knob】

8 【BRILL 】/ Power

It switches to the high frequency or low frequency of echo sounder image, zoom and navigation menu.

It notifies the external equipment of the present position. It presets the menu. It begins a homing.

It selects the menu item. It changes the set value. It moves the VRM marker. It moves the marker for notifying the event.

Press: It recalls the gain adjustment. Rotate: It changes the gain value. It selects the item in the menu.

Press: Power on. It adjusts the brilliance and brightness of panel. Long-press: Power off.

1-1 0093132702-01

CVS-126 Chapter 1 Basic Operation

How to remove the protection cover

While widening the claws at right and left sides of protection cover, draw the protection cover towards you.

Claw

When removing CVS-126 Display unit:

To prevent dust from entering, cap the connector at the rear of CVS-126 Display unit and the power cable with caps.

Install the supplied cap to the transducer cable as shown in the figure and cap it.

Caution: Do not pull the cable strongly. If you do so, it will be broken.

When :

The cleaning of the display goes after removing the front-frame. After removing the front-frame, use a synthetic detergent and OA cleaner and wipe the display lightly. Then dry sufficiently, and return the front- frame to original position.

Caution: The display has a special coating. Do not use a solvent such as paint thinner,

acetone, alcohol, and benzene, etc.

Caution: Strong rubbing may cause bruising, scratching.

0093132702-01 1-2

Chapter 1 Basic Operation CVS-126

L H

1.2

1.2 Power On/Off

1.21.2

Power on

Press the 【BRILL 】 key to power on. The startup menu is displayed. When started up, the memories (ROM, RAM) are automatically checked. When checking is normally finished, the menu below is displayed.

Rainbow pattern Time mark

Gain

School of fish

Range

Oscillation line

Fish

Depth

Type of Gain H: High frequency gain,

Dual freq image

Function icon

Caution: If an error occurs in the memory

check, the LED on the operation panel blinks. The unit may not function normally. If you suspect trouble, contact the dealer of your purchase or our company.

Language Selection at Initial Startup.

When powering on first, after the [Initialize] is processed, the [Language] menu is displayed.

Language

English

日本語

Select the language with 【】 key or 【】 key. (The language can be selected by rotating the

【knob】.)

Press the 【MENU】 key to decide the language.

After a few seconds pass, the menu selected in 【DISP】 is displayed.

L: Low frequency gain

Type of Range R: M: Manual Range, R: A: Auto Range, R: AS: Auto Shift

Power off

When powering off, keep pressing the

【BRILL 】 key for 3 seconds.

The remaining time for the power to shut off is displayed on the menu.

Alarm of Power Voltage

If the power voltage drops below a certain level, the icon blinks and the alarm beeps.

1-3 0093132702-01

CVS-126 Chapter 1 Basic Operation

Ultra-sonic

1.3

1.3 LCD Brilliance

1.31.3

Adjustment

Adjustment of LCD Brilliance

The [Lcd brill] and [Panel brill] can be switched every time when pressing the 【BRILL 】key.

Press the 【BRILL 】 key for a short period of time to display the menu ([Lcd brill]).

Rotate the 【Knob】. When “1” is selected, it is darkest. When “10” is selected, it is brightest.

Lcd brill

Press the 【MENU】 key to close the menu.

Brightness Adjustment of Panel Brilliance

The brightness of panel can be adjusted,

Press the 【BRILL 】 key for a short period of time to display the menu ([Panel brill]).

Rotate the 【Knob】. When “1” is selected, it is darkest. When “10” is selected, it is brightest.

Panel brill

Press the 【MENU】 key to close the menu.

Select the display you desire to display.

Disp

NAV1/ Normal (H)

Normal (H)

Zoom (H) Dual Freq Zoom (L) Normal (L) NAV2/ Normal (L)

(High): High frequency

(Low): Low frequency

NAV1: Navigation display1

NAV2: Navigation display2

Press the 【MENU】 key to close the menu.

Normal Image (Low frequency, high frequency)

Low frequency(50kHz)

Since the beam width is wide, the search range becomes wide so that the beam can search the deep depth.

High frequency(200kHz)

Since the beam width is narrow, it is hard to be interfered by noise and bubble in the sea so that the school of fish can be searched in a high resolution.

Low frequency

(50 kHz)

1.4

1.4 Switch-over of Menu

1.41.4

7 kinds of displays are provided in all. Select the display suitable for your purpose.

Press the 【DISP】 key.

0093132702-01 1-4

Point A

Sea level

School of fish

High frequency

(200 kHz)

Your boat

Point B

signal

Chapter 1 Basic Operation CVS-126

Dual Frequency

The high frequency image can be displayed in the right half side and the low frequency image can be displayed in the left half side. Since the beam width differs depending on frequency, the school of fish and sea bottom look different.

Low frequency image

High frequency image

Zoom (Low frequency, high frequency)

A part of normal image can be zoomed. (1) [Bottom], (2) [Bottom Discrimination], [zoom], (4) [Bottom Zoom] and (5) [Bottom Follow Zoom] are provided for zoom.

The unit is set to (1) [Bottom] at ex-factory. To change to other zoom display, set it in the menu. (See [2.7 Setting of Zoom Range].)

Zoom type

Bottom It displays the position of

Bottom Discrimination

Zoom It displays a zoom start

Bottom Zoom It displays the position of

Zoom start position

the bottom in the fixation in the display bottom part.

It displays the position of the bottom in the fixation in the position of 1/4 under the display.

position in the fixation at the top of the display.

the bottom in the position which is the same as the ordinary display.

Zoomed range

It displays the bottom and upper in the zoom.

It displays the bottom and upper in the zoom, it displays under the bottom in the ordinary. (Under the bottom, it doesn't display in the zoom).

It displays in the zoom from the zoom start position to the range you set.

It displays upper side of the bottom in the zoom except the bottom.

Purpose

It is convenient to see a school of fish near the bottom.

It is convenient to see a school of fish and a bottom quality near the bottom.

It is convenient to see the specified range in the zoom.

It is convenient to see a school of fish near the bottom and the form of the bottom.

Bottom Follow Zoom

1-5 0093132702-01

It always displays the position of the bottom in the lower part of the display.

It displays the bottom and upper and lower sides in the zoom.

It is convenient to see a school of fish near the bottom and the form of the bottom.

CVS-126 Chapter 1 Basic Operation

Zoom image

(1) Bottom

Zoomed range

(2) Bottom Discrimination

The display width of zoom is displayed in orange.

Normal image

30.0

Zoom image

The display width of zoom is displayed in orange.

Normal image

(3) Zoom

Zoom start position

Zoomed range

30.0

Zoom image

The display width of zoom is displayed in orange.

Normal image

30.0

0093132702-01 1-6

Chapter 1 Basic Operation CVS-126

The display width of zoom is displayed in orange.

(4) Bottom Zoom

Normal image

Zoomed range

(5) Bottom Follow Zoom

Zoomed range

30.0

Zoom image

The image below the bottom is not zoomed.

The display width of zoom is displayed in orange.

Normal image

30.0

Zoom image

Navigation Menu (NAV1, NAV2)

The navigation menu can be displayed at the left side on the display. To display the information other than depth, sensors need to be connected. (See [2.16 Selection of NAV Display].)

R:M 12.6VH:9.0

0.0

10.0

20.0

30.0

40.0

50.0

60.0

Depth

高

Water temp

Range

Total range

R:M 12.6VH:9.0

0.0

10.0

20.0

30.0

40.0

50.0

60.0

70.0

1-7 0093132702-01

CVS-126 Chapter 1 Basic Operation

1.5

1.5 Switch-over of Range

1.51.5

The range of measured depth displayed on the display can be changed.

To meet your purpose, select the range of measured depth.

Set the range switching to auto range.

By following automatically the bottom, the image of echo sounder in the suitable range of measured depth can be displayed.

This mode is convenient to display always the range from sea level to bottom.

The range value changes

Range

5.0

10.0

50.0

80.0

100.0

150.0 300 500

Press the 【MENU】 key to close the menu. When the [Manual] is set, the [R : M] is displayed at the upper side of menu.

Caution: By selecting the [D.range] →→→→

[Range preset], the range can be preset.

1.6

1.6 Gain Adjustment

1.61.6

The gain can be adjusted in the auto mode (Echo sounder mode, Depth mode) or manual mode.

Press the [MENU] key to display the menu.

Select [Display Range] → [Range Mode].

Select the [Auto Range].

Range Mode

Manual

Auto Range

Auto Shift

(See [2.6 Setting of Shift].)

Press the [MENU] to close the menu. When the [Auto Range] is set, the [R : A] is displayed a the upper side of menu.

Set the range switching to Manual range.

Press the 【】 key of 【 range】 key or

【】 key.

[Cruising mode]

Eliminating the weak echo, it displays clearly the sea bottom of strong echo. It is suitable for cruising to the fishery ground.

[Fishing mode]

It displays clearly the weak echo reflected from the school of fish. It is suitable for searching the school of fish.

Basic Operation of Gain

Every time when rotating the 【Knob】, the [Gain] and [Auto Gain Select] are switched.

By rotating the 【Knob】, the gain adjustment or auto gain can be selected.

Selection of Echo sounder mode and Depth mode

The gain adjustment can be set to [Auto Adjust].

Press repeatedly the 【Knob】 until the [Auto Gain Select] menu is displayed.

Select the range you desire to set.

0093132702-01 1-8

Select the [Depth mode] or [Echo sounder mode] by rotating the 【Knob】.

Chapter 1 Basic Operation CVS-126

Over-gain

Gain select

Manual

Cruising

Fishing

Press the 【MENU】 key to close the menu. When the [Cruising mode] is set, the [A : AC] is displayed at the upper side of menu. When the [Fishing mode] is set, the [A : AF] is displayed at the upper side of menu.

Fine-adjusting the Auto Gain

When the [Cruising mode] or [Fishing mode] is set, the gain can be fine-adjusted.

Press repeatedly the 【Knob】 until the [Auto Gain Select] menu is displayed.

Select the [Cruising mode] or [Fishing mode] by rotating the 【Knob】.

Press the 【Knob】 to display the Auto Gain Adjustment].

Fine-adjust the gain by rotating the 【Knob】.

Auto gain adjust

Every time when pressing the [Auto Gain Select] and [Auto Gain Adjust] are alternately displayed.

Press the 【MENU】 key to close the menu.

When pressing the 【Knob】 again, the previous menu before pressing the

【MENU】 key is displayed.

Adjust the gain manually.

When the image of high frequency only is displayed on the display, the high frequency gain can be adjusted.

When the image of low frequency only is displayed on the display, the low frequency gain can be adjusted.

image. Adjust properly the gain so that the optimum image can be always displayed.

Under-gainOptimum

Press the 【Knob】.

Select the [Manual] by rotating the 【Knob】.

Press the 【Knob】.

Adjust the gain by rotating the 【Knob】.

Gain (H)

Stop increasing the gain just before noise appears on the image.

When the [Disp] is set to other than [Normal freq],

every time when pressing the [Knob], the [Gain (High Frequency)] or [Gain (Low Frequency)] → [Auto Gain Select] is displayed.

When the [Disp] is set to the [Normal freq],

every time when pressing the [Knob], the [Gain (High Frequency)] -> [Gain (Low Frequency)] → [Auto Gain Select] is displayed.

Press the 【MENU】 to close the menu.

When pressing the 【Knob】 again, the previous menu before pressing the

【MENU】 key is displayed.

Easy Gain Adjustment

Depending on the item of [Auto Gain Select], the adjustment menu differs.

When both of the high frequency image and low frequency image are displayed, by pressing the [Knob], the adjustable frequency can be changed.

Caution: If you increase the gain too much,

noise will appear on the entire image, resulting in an unclear

1-9 0093132702-01

Rotate the 【Knob】.

The gain adjustment menu is displayed and the gain can be adjusted.

Press the 【MENU】 to close the menu.

CVS-126 Chapter 1 Basic Operation

12.6V

Confirm the gain state.

The present set value of frequency (high frequency or low frequency) adjusted last is displayed at the upper left side of menu.

Example) The high frequency gain is 8.0 → H: 8.0.

H:8.0

1.7

1.7 Use of 【EVENT】 key

1.71.7

By pressing the 【EVENT】 key, three functions of [Store Position]. [Store Image] and [Homing] are available.

The homing is the function to instruct your boat to navigate easily to a point where you desire to go back.

[Save pos]: The latitude and longitude of a point can be stored.

R:M

When presetting the destination, switch [NAV] → [EVENT Key set] → [Store pos].

In the state that no other key is pressed, press the 【】 key or 【】key.

Move the cursor (Redline) with the 【】 key or 【】 key to the location to be preset as a destination.

[Store image]: An image of the fish finder can be stored in the internal memory.

[Homing]: The WPT navigation starts, using the latitude and longitude of a point which is set as a destination by pressing the 【EVENT】 key. Simultaneously, the latitude and longitude of the point can be stored in the destination list.

Select the event.

Select the functions when pressing the

【EVENT】 key.

Press the 【MENU】 key.

Select [NAV] → [EVENT Key set].

Change the setting of [EVENT key set].

EVENT Key set

Store pos

Store image

Homing

(Refer to [2.6 Setting of Shift ].)

Press the 【MENU】 to close the menu.

Cursor (Redline)

Press the 【EVENT】 key. When decided, the red line is drawn at the designated location on the echo sounder menu and the latitude and longitude of designated location are registered in the destination list. At this moment, the list number of preset destination is displayed.

Preset the destination.

When you find the school of fish or tide, its location can be preset as a destination. (10 locations at maximum)

0093132702-01 1-10

Chapter 1 Basic Operation CVS-126

It registered in Pic list No.1

Store the image.

Cursor (Redline)

It registered in the Wpt list No.1

When you find the school of fish or tide, its location can be stored as a destination. (10 locations at maximum)

When storing the image, switch [NAV] → [EVENT Key set] → {Store pos}.

Press the 【EVENT】 key. The image of echo sounder presently displayed is stored and the list number of stored image is displayed.

After a certain time passes, the message disappears and storing the image is finished.

Caution: If the destination list is fully filled,

the preset destination list is not deleted, showing the message that the image is fully filled. After a certain time passes, the message disappears.

A list of Pic is full.

It was not possible to register

After a certain time passes, the message disappears and presetting the destination is finished.

Caution: When pressing the 【【【【EVENT】】】】 key,

if [In out] →→→→ [NMEA output data] →→→→ [TLL] is set to ON, the latitude and longitude of location above-designated is output to the navigation system connected.

Caution: If the destination list is full, the

preset destination list is not deleted, showing the message that the list is fully filled. After a certain time passes, the message disappears.

A Wpt list is full. It was not possible to register

Start the homing

When you find a school of fish or a tidal flow, your boat can go back easily to that point.

Your boat can go back to any point on an image you saved. (See [2.13 WPT navigation].)

To perform the homing, it is necessary to select [Navigation] → EVENT key set → [Homing].

In the state that no other key is pressed, press the 【】 key or the 【】 key.

Move the cursor (red line) to a point you desire to go back with the【】 key or 【】 key.

1-11 0093132702-01

CVS-126 Chapter 1 Basic Operation

37.0m

Background Color

1.8

1.8 Use of 【FUNC】 key

1.81.8

When factory-shipped, the [Image Speed] is assigned to the 【FUNC】 key. The function settable to the 【FUNC】 key can be selected among [Image Speed], [Interference Rejection], [Color Rejection], [Noise Rejection], [Range Mode], [Shift], [Zoom Range], [Zoom Start], [Background] and [White Line]. Set the function frequently used for your convenience.

How to use the 【【【【FUNC】】】】 key

Press the 【FUNC】 key.

Change the setting by rotating the 【Knob】.

Cursor (Redline)

Press the 【EVENT】 key. When you decide, the red line is drawn on the image of the fish finder at the point you designate and the latitude and longitude of the point you designate is stored in the destination list. At this moment, the number of the stored destination list is displayed.

The navigation display (NAV1) is displayed and the WPT navigation starts.

12.6V

In case of [Image speed]

Image Speed

2/1

1/1

stop 1/1.5 1/2 1/2.5 1/3 1/3.5 1/4 1/4.5

Press the 【MENU】 key to close the menu.

Note: The display of NAV1/Normal (H) is

displayed.

Preset of 【【【【FUNC】】】】 key

Press the 【MENU】 key.

Select [System] → [FUNC key set].

Select the function.

FUNC key set

Image Speed

IR Color Rejection Noise Rejection Range Mode Shift Zoom Range Zoom Start

White L

0093132702-01 1-12

Chapter 1 Basic Operation CVS-126

Movable marker

Press the 【MENU】 key to close the menu. The icons of functions preset are displayed at the upper right side on the menu.

Image Speed IR Color Rejection Noise Rejection Range Mode Shift Zoom Range Zoom Start Background Color White Line L

1.9

1.9 Operation of VRM

1.91.9

The VRM (movable marker) shown by the green line can be moved up and down.

It is convenient to measure the depth by aligning with the target such as school of fish.

Press the 【】 key or 【】 key. The movable marker (straight line) is displayed.

Press the 【】 key or 【】 key. The movable marker moves up and down. The movable marker and the numerical of marker depth are simultaneously highlighted.

Marker Depth

1-13 0093132702-01

When displaying dual images, if the 【】 key or 【】 key is pressed, the movable marker moves to the neighboring image.

Caution: When several seconds pass after

finishing the VRM operation, the numerical of marker depth becomes normal display.

CVS-126 Chapter 2 How to use the Menu

Adjust

Alarm1

Alarm2

Sonar

Chapter 2 How to use the Menu

2.1

2.1 How to operate the

2.12.1

Display the menu. / Stop the display

of menu.

Press the 【MENU】 key. The menu and explanation of operation are displayed.

Name of menu selected

Menu column

D.range Image

NAV Disp

Setting item column

Image speed

Color rejection

Noise rejection

TGV

TX power Return

Guide

t is displayed when the [Operation Guide] is set to ON.

(See [3.4 Setting of System Item].)

Press the 【MENU】 key. The menu and explanation of operation close.

1/1

Strong

Medium

Cursor

Setting value

uto

Adjust D.range Image

Alarm1 Alarm2 NAV Disp Sonar Next

Range mode

Shift

Zoom select

Zoom range

Zoom start

Range preset

Return

Manual

0m Bottom

10.0m

Press the 【】 key. The cursor appears in the set item column. (The cursor appears by pressing the

【Knob】.)

Select the set item you desire to change with the 【】 key or 【】 key. (The set item can be selected by rotating the 【Knob】.)

Adjust D.range Image

Alarm1 Alarm2 NAV Disp Sonar Next

Range mode

Shift

Zoom select

Zoom range

Zoom start

Range preset

Return

Manual

Bottom

10.0m

Press the 【】 key. The set menu corresponding to the selected item is displayed. (It can be displayed by rotating the

【Knob】.)

Menu Operation

When the menu is displayed, press the

【】 key or 【】 key to select the menu

name. Depending on the selected menu name, the content in the set item column at the right side changes. (The menu name can be selected by rotating the 【Knob】.)

Range mode

Manual

Auto range

Auto shift

Change the set content with the 【】 key

or 【】 key. (It can be changed by rotating the [Knob].)

Press the 【】 key.

Shift

0~300 m

The cursor returns to the set item column. (It can be displayed by rotating the

【Knob】.)

To select the menu name of other, press

0093132702-01 2-1

Chapter 2 How to use the Menu CVS-126

the 【】 key. The cursor returns to the menu column.

Press the 【MENU】 key to close the menu.

2.2

2.2 Change of Image

2.22.2 Speed

The image speed of echo sounder can be changed. Even if the school of fish and bottom are same, the image changes depending on the image speed.

The setting of image speed is shown by the comparison with the normal image speed “1/1”.

“2/1” image speed is two times the normal image speed. “1/2” is a half time the normal image speed. When “Stop” is selected, the image speed is stopped.

Press the 【MENU】 key.

Select the [Adjust] → [Image Speed].

Change the setting of [Image Speed].

having the same frequency and same firing times as those your boat has, the interference noise may be displayed. If you set the interference rejection, the interference noise can be reduced. In the order of weak → strong, the noise rejection capability becomes high.

Image of school of fish

Interference image

OFF

Press the 【MENU】 key.

Select the [Adjust] → [Interference Rejection].

Change the setting of [Inference Rejection].

Weak

Strong

Image speed

2/1

1/1

Stop 1/1.5 1/2 1/2.5 1/3 1/3.5 1/4 1/4.5

Press the 【MENU】 key to close the menu

2.3

2.3 Rejection of

2.32.3 Interference

Interference Rejection

The interference noise from the echo sounder of other boats can be reduced.

If a neighboring boat uses the echo sounder

OFF

Weak

Strong

Press the 【MENU】 key to close the menu.

2.4

2.4 Color Rejection of

2.42.4 Weak Echo

Color Rejection

The color of weak echo can be rejected.

Rejecting noise on the entire image and weak echo around the school of fish makes it easier to see the school of fish. It is the convenient function when displaying the echo stronger than the specific signal. (setting:0～50%)

Press the 【MENU】 key.

Select the [Adjust] → [Color Rejection].

2-2 0093132702-01

CVS-126 Chapter 2 How to use the Menu

Change the setting of [Color Rejection].

Setting of Fixed Shift

Color Rejection

Press the 【MENU】 key to close the menu.

2.5

2.5 Rejection of Noise

2.52.5

Noise Rejection

The influence of noise can be reduced.

Due to echo reflected from plankton and dust, the speck-like noise may appear on the entire image. Setting the [Noise Rejection] reduces the speck-like noise and makes it easier to see the image of school of fish.(setting:0～10)

The greater the set value becomes, the stronger the effect of noise rejection becomes.

The scope of range starting with the shift value is displayed.

Press the 【MENU】 key.

Select [D. Range] → [Shift].

Change the set value of [Shift].

Shift

0~300 m

Press the 【MENU】 key.

Select [Adjust] → [Noise Rejection].

Change the setting of [Noise Rejection].

Noise Rejection

Press the 【MENU】 key to close the menu.

2.6

2.6 Setting of Shift

2.62.6

The [Fixed Shift] and [Auto Shift] are provided.

Fixed Shift:

The image range is shifted up and down.(setting:except ft:0～300,ft:0～1000)

Auto Shift:

Since the bottom is always displayed in the lower side, if the depth changes, the image is shifted automatically. (In the depth direction)

Press the 【MENU】 key to close the menu.

Setting of Auto Shift.

The image is automatically shifted so that the bottom is always displayed.

Press the 【MENU】 key.

Select [D. Range] → [Range Mode].

Select the [Auto Shift].

Range Mode

Manual Auto Range

Auto Shift

Press the 【MENU】 key to close the menu. [R: AS] is displayed at the upper side of menu.

2.7

2.7 Setting of Zoom Range

2.72.7

Set the zoom range in each mode of [BTM], [Bottom Discrimination], [Zoom], [Bottom Zoom]

0093132702-01 2-3

Chapter 2 How to use the Menu CVS-126

White line

and [Bottom Follow Zoom]

The zoom range of each mode is identical.

(See [1.4

(setting:except ft:2.5～200,ft:10.0～650)

2.8

2.8 Setting of Zoom Start

2.82.8

Switch-over of Menu

].)

Zoom Range

Press the 【MENU】 key.

Select [D. Range] → [Zoom Range].

Change the set value of [Zoom Range].

Zoom Range

10.0

Press the 【MENU】 key to close the menu.

Zoom start

0~800 m

Press the 【MENU】 to close the menu.

2.9

2.9 Setting of Background

2.92.9 Color

Responding to the ambient brightness, the background color of display can be changed.

Press the 【MENU】 key.

Select [Display] → [Background Color].

Change the setting of [Background Color].

Background

Pale blue

Marine blue

Blue Dark blue Black Pale gr. bl. Gr. blue Dark. Gr. bl. White Night mode

Press the 【MENU】 to close the menu.

Select the zoom start in the [Zoom].

(See [1.4

Switch-over of Menu

].)

(setting:except ft:0～800,ft:0～2800)

Zoom Start

Press the 【MENU】 key

Select [Display Range] → [Zoom Start]

Change the set value of [Zoom Start].

2-4 0093132702-01

2.10

2.10 Setting of White Line

2.102.10

As the surface of bottom is marked with the white line of constant width, the school of fish at the bottom can be easily identified.

Press the 【MENU】 key

CVS-126 Chapter 2 How to use the Menu

Select [Disp] → [White Line].

Change the setting of [White Line]. “1” is narrowest. “5” is widest. In the auto mode, responding to the strength of echo reflected from the bottom, the width of white line changes.

White line

OFF

2 3 4 5 Auto

Press the 【MENU】 key to close the menu.

[Bottom alarm] issues the alarm when the position recognized as the bottom is shallower than the upper limit or deeper than the lower limit. It is convenient when keeping the specific depth.

(setting:except ft:0～800,ft:0～2800)

[Fish alarm] issues the alarm when an echo recognized as school of fish exists in the set range.

(setting:except ft:0～800,ft:0～2800)

It is convenient for you to judge whether the echo of school of fish is present or not.

(setting:except ft:0～800,ft:0～2800)

Caution: In the [Level], select the strength

of echo reflected from the school of fish in the [Fish alarm].

[Water temp alarm] issues when the water temp is within or out of the set range. It is convenient to keep the specific water temp region.(setting:-5 ～45℃,23～113ºF)

2.11

2.11 Preset of Range

2.112.11

The range switched with the 【 range 】 key can be set.

Preset the set value suitable for you purpose.

(setting:except ft:0～800,ft:0～2800)

Press the 【MENU】 key.

Select [Display Range] → [Range Preset] → [Range 1 to 8].

Select the set value of [Range 1 to 8].

Range1

20.0

Press the 【MENU】 key to close the menu.

[Speed alarm] issues when the boat speed is faster or slower than the set range. It is convenient when the speed limit is obliged.(setting:0～80)

[Arrival alarm] can be used in the state that the destination is set. The alarm is issued when your boat arrives within a certain range of destination. A certain range is set in the [NAV alarm range].

(See [1.7

[XTE alarm] can be used in the state that the destination is set. The alarm is issued when your boat is off a certain distance from the course on the line drawn straightly from destination to the location when setting the destination. A certain distance is set in the [NAV alarm range].

In the [NAV alarm range], select the alarm range of [Arrival alarm] and [XTE alarm].(setting:10～999m)

Use of 【Event】 key.)

Stopping the alarm sound

To stop the alarm sound and the alarm display, press 【MENU】 key.

2.12

2.12 Setting of Alarm

2.122.12

6 alarms of bottom alarm, fish alarm, water temp alarm, speed alarm, arrival alarm and XTE alarm can be set.

They are notified by alarm sound and alarm display.

0093132702-01 2-5

Chapter 2 How to use the Menu CVS-126

[Water temp alarm]

Arrival alarm

XTE alarm

Adjust

Alarm1

Alarm2

Adjust

Alarm1

Alarm2

Setting the alarm

D.range Image

NAV Disp Sonar Next

D.range Image

NAV Disp Sonar

Bottom alarm

Upper depth

Lower depth

Fish alarm

Position

Range

Level

Return

Water temp warm

Upper temp alarm

Lower temp alarm

Speed alarm

Speed limit

NAV alarm range

Return

OFF

50m

OFF

50m Medium

OFF

20.0

15.0

OFF

0kt

OFF OFF

10m

The set state of [Water temp alarm], [Speed alarm], [Arrival alarm] and [XTE alarm] can be confirmed by the icons at the upper side of display.

[XTE alarm]

[Arrival alarm]

[Bottom alarm]

[Fish alarm]

[Speed alarm]

Press the 【MENU】 key.

Select your desired alarm from [Alarm 1] or [Alarm 2].

Select the [ON] of alarm you desire.

If the setting of [Alarm range] is provided in the alarm desired, select the alarm range.

Change the set value of alarm range.

Press the 【MENU】 key to close the menu.

Release the alarm.

Press the 【MENU】 key.

Select the alarm to be released from [Alarm 1] or [Alarm 2].

Select the [OFF] of alarm to be released.

Close the menu with the 【MENU】 key.

2.13

2.13 Preset/ WPT edit/ WPT

2.132.13 delete of Destination

NAV Start.

The NAV can be started by selecting the destination from the destination list.

To perform the NAV start, the destination must be preset.

(See [1.7

Use of 【Event】 key].)

Press the 【MENU】 key.

Select [NAV] → [NAV start].

Select the [Destination list] preset.

Confirm the alarm state.

The set state of [Bottom alarm] and [Fish alarm] can be confirmed on the bar at the right corner of display. However, when the display is out of the range, they are not displayed.

2-6 0093132702-01

CVS-126 Chapter 2 How to use the Menu

[WPT edit] list.

Caution: The list No. selected is reversed

in red.

After selecting the number, press the 【】 key or the 【Knob】.

Select the [Yes] in the confirmation menu and press the 【MENU】 key. Then, the NAV starts.

NAV starts

Yes

Cancel the NAV.

The NAV started can be canceled halfway.

Press the 【MENU】 key

Select [NAV] → [NAV cancel].

Press the [Yes].

NAV cancel

Yes

After selecting the number, press the 【】 key or the 【Knob】.

Select the character with the 【】 key or

【】 key. ( character: A～Z,blank,0～

9,+,-./)

Move the position of characters to be reversed with the 【】 key or 【】key.

Press the 【MENU】 key. Then, the NAV is released.

Edit the destination.

By entering the latitude and longitude, the destination can be preset.

The list preset in the past can be edit.

Press the 【MENU】 key.

Select [NAV] → [WPT edit].

Select the list No. to be edited from the

0093132702-01 2-7

Caution: At this moment, if the [Knob] is

Chapter 2 How to use the Menu CVS-126

pressed, the setting is cancelled and the menu returns to the menu item.

Caution: If the values of latitude and

longitude are abnormal or are not entered, they cannot be preset.

After finishing the edit work, press the

【MENU】 key.

Select the [Preset] in the confirmation menu and press the 【MENU】 key. Then, the edit is finished.

Edit is finished

Yes

Delete the destination.

The destination list preset in the past can be deleted.

The deletion takes some time.

Press the 【MENU】 key.

Select [NAV] → [WPT delete].

Select the list number of destination to be deleted from the [WPT delete].

Caution: If the 【【【【Knob】】】】 is pressed at this

moment, it is canceled.

Press the 【MENU】 key. Then, the destination is deleted and the menu closes.

Recall the image stored and preset it

as a destination.

Call the image stored in the past and it can be preset as a destination.

【Event】 key].)

Press the 【MENU】 key.

Select [NAV] → [Image recall].

Select the image No. from the [Image recall] list.

Image recall

No. Comment 1

PIC00001

PIC00002 PIC00003

3 4

PIC00004 PIC00005

PIC00006

PIC00007

PIC00008

PIC00009

PIC00010

(See [1.7

Use of

After selecting the number, press the 【】 key or the 【Knob】.

Select the [Yes] in the confirmation menu and press the 【MENU】 key. Then, the destination is deleted.

Destination is delete

Yes

Press the 【】key or the 【Knob】.

Move the cursor to the location preset as a destination with the【】key or 【】 key and select it.

2-8 0093132702-01

CVS-126 Chapter 2 How to use the Menu

Cursor

（

red line

）

When the echo sounder image to be stored appears, press the 【EVENT】 key.

When the image store is fully filled, it shows that the [Store image] is fully filled. After deleting the unwanted image, try it again.

Recall the stored image.

The image stored in the past can be recalled.

During recalling, the image cannot be stored.

Press the 【MENU】 key.

Select [NAV] → [Image recall].

Select the number of image to be recalled from the [Image recall] list.

Caution: You can switch to other stored

image with the 【【【【

When starting the NAV, press the

【EVENT】key.

When you do not start the NAV, press the

【MENU】 key.

2.14

2.14 Store/Recall/Deletion

2.142.14

or 【【【【

】】】】

key.

】】】】

of Image

Store the image.

The present image of echo sounder can be stored.

To memorize, it takes some time.

To memorize the image, the 【EVENT】 key must be switched to the [Store image].

Press the 【MENU】 key.

Select [NAV] → [EVENT key set].

Select the [Store image].

EVENT key set

Store pos

Store image

Homing

Press the 【MENU】 key to close the menu.

Image recall

No. Comment 1

PIC00001

PIC00002 PIC00003

3 4

PIC00004 PIC00005

PIC00006

PIC00007

PIC00008

PIC00009

PIC00010

After selecting the number, press the 【】 key or 【Knob】 to enter.

Press the 【MENU】 key to return to the normal menu.

Caution: When other stored image exists

beside the recall image, switch to other image with the 【【【【

【【【【

key.

】】】】

and

】】】】

Delete the stored image.

The image stored in the past can be deleted.

To delete, it takes some time.

Press the 【MENU】 key.

Select [NAV] → [Image delete].

Select the number of image to be deleted from the [Image delete] list.

0093132702-01 2-9

Chapter 2 How to use the Menu CVS-126

Image delete

No. Comment 1

PIC00001

PIC00002 PIC00003

3 4

PIC00004 PIC00005

PIC00006

PIC00007

PIC00008

PIC00009

PIC00010

After selecting the number, press the 【】 key or the 【Knob】.

Select the character with the 【】 key or

【】 key.( character: A～Z,blank,0～

9,+,-./)

Image comment

No. Comment 1

P I C00001

P I C00002

P I C00003

Select the comment position with the 【】 key or 【】 key.

After selecting the number, press the 【】 key or 【Knob】 to enter.

Select the [Yes] in the confirmation menu and press the 【MENU】 key. Then, the preset image is deleted.

Confirm image

Yes

Add the comment to the stored

image.

It is convenient to judge the stored image.

Press the 【MENU】 key.

Select [NAV] → [Image comment].

Select the number of image to which the comment is added from the [Image comment].

Image comment

No. Comment 1

PIC00001

PIC00002 PIC00003

3 4

PIC00004 PIC00005

PIC00006

PIC00007

PIC00008

PIC00009

PIC00010

Image comment

No. Comment 1

P I C00001

P I C00002 P I C00003

Caution: At this moment, if the 【【【【Knob】】】】 is

pressed, the setting is cancelled and the menu returns to the menu item.

After finishing the edit, press the 【MENU】 key.

Select the [Register] in the confirmation menu and press the 【MENU】 key. Then, the edit is finished.

Edit is finished

Not register

2.15

2.15 Selection of Zoom

2.152.15

Set the zoom display with the display mode ([zoom (H)] or [zoom (L)].

The [Bottom], [Bottom Discrimination], [Zoom], [[Bottom Zoom] and [Bottom Follow Zoom] are provided.

(See [1.4

Switch-over of Menu

].)

Press the 【MENU】 key.

Select [Display range] → [Zoom image].

Select the zoom image.

2-10 0093132702-01

CVS-126 Chapter 2 How to use the Menu

NAV1

Simple plotter

Speed meter

Zoom select

BTM.

B.D. Zoom B.Z. B.F.Z.

Press the 【MENU】 key to close the menu.

For each zoom display, refer to [1.4 Switch-over of display].

2.16

2.16 Selection of NAV

2.162.16 Display

The information can be displayed on the NAV display (NAV 1, NAV2).

display1

display2

display3

display4

Information to be displayed in 1 to 4 Wpt dist dir., Time required, Wind dir., Wind speed, depth, Lat/Lon, Boat speed, course, water temp, Heading and XTE

RNG

BRG

Water temp

Course

XTE

Boat speed

Depth

HDG

The time required

Wind dir.

Lat/Lon

Wind speed

Type of NAV Display

Depending on the division method (2 division, 4 division), the information to be displayed differs.

2 division

display1

display2

Compass

Dividing Method of Display

Press the 【MENU】 key.

Select [Display] → [NAV 1] → [NAV 2].

Select the dividing method (2 division, 4 division).

Press the 【MENU】 key to close the menu.

Selection of NAV Menu

Press the 【DISP】 key.

Select the [NAV1/Normal (H)] or the [NAV2/Normal (L)].

Press the 【】key. The [NAV1 display1] is displayed.

Information displayed in 1 and 2 Simple plotter, speed meter and compass

4 division

0093132702-01 2-11

NAV display1

Simple Plotter

Select by rotating the 【Knob】.

To change the [NAV 2], press the 【】

Chapter 2 How to use the Menu CVS-126

key.

Caution: Every time when pressing the

【【【【

key, the [Display] switches

】】】】

in the order of [NAV1] to [NAV4].

Select the [NAV] by rotating the 【Knob】.

Press the 【MENU】 key to close the menu.

2.17

2.17 Explanation of Sonar

2.172.17

Switch-over of Sonar Tone

The sonar can be outputted to the built-in speaker by selection.

The school of fish and condition of bottom on the display of echo sounder can be confirmed by hearing the sonar.

Sonar tone

OFF

Press the 【MENU】 key.

Select the [Sonar] → [Sonar tone].

Select the [ON] or [OFF] of Sonar tone].

2.18

2.18 Explanation of Menu

2.182.18 Item

The various items in the menu are explained.

TVG

The TVG corrects the difference of strength between echo reflected from the shallow depth and echo reflected from deep depth so that the reflection can be uniformed.

The deeper the depth is, the weaker the reflected signal of echo sounder becomes due to attenuation. Thus, comparing with the signal reflected from the same size fish in the shallow depth, the signal reflected from the fish in the deep depth becomes weak. The TVG corrects the echo signal reflected from the deep depth to be equal to that reflected from shallow depth by increasing the receiver gain so that the effect that the strength of echo signal reflected from the deep depth looks same as that reflected from the shallow depth provided. The correction gain due to the depth increases in the order of weak → medium → strong. When set to “weak”, the TVG also provides the effect that reduces noise in the shallow depth.

Select the [Adjust] → [TVG].

Caution: When set to [OFF], the built-in

speaker does not output the sonar. When set to [ON], the built-in speaker outputs the sonar.

Press the 【MENU】 key to close the menu.

Connection of External Speaker

Connect the external speaker with amplifier (option) so that you can hear the sonar easily.

The sonar is always outputted. Adjust the speaker volume with the volume provided on the speaker.

Caution: The external speaker is an option.

Select the [weak, medium, strong].

TVG

Weak

Medium

Strong

Change the TX power.

The strength of transmission output (power) can be changed.

When the noise of interference with the neighboring echo sounder occurs, if the powers of transmission outputs at both sides are weakened, the interference noise can be suppressed.

In the [Auto] setting, the transmission output is automatically adjusted.

2-12 0093132702-01

CVS-126 Chapter 2 How to use the Menu

Adjust D.range Image

Alarm1 Alarm2 NAV Disp Sonar Next

Image speed

Color Rejection

Noise Rejection

Clutter

TGV

TX power

Return

1/1

Strong

0.0

Medium Auto

Select the [Display] → [A scope].

To display the A scope, select the [ON]. To stop the display of A scope, select the [OFF].

Change the display color of echo

sounder image

Select the [Adjust] → [TX power].

When selecting the smaller number, the transmission power becomes weak.

TX power

30 40 50

60 70 80 90 100

Auto

Display the A scope. / Stop the

display of A scope.

The echo strength of latest echo can be displayed at the right side of echo sounder display.

The strength of echo sounder image is expressed by the horizontal width. This expression is called [A scope].

The width for strong echo is wide and the width for weak echo is narrow. This makes it easier for you to see the echo.

Adjust D.range Image

Alarm1 Alarm2 NAV Disp Sonar Next

A scope

White line

Background color

Color tone

Depth value

Water temp graph

Return

OFF

Marine blue

64 color

Large

OFF

The [Monochrome], [8 color], [16 color] and [64 color] can be selected.

Select the [Display] → [Color tone].

Select the [Color tone].

Change the depth value.

The display size of depth value and the scale value can be changed.

Select the [Display] → [Depth display].

Select the size of display.

Display the water temp graph. / Stop

the display of water temp graph.

The latest water temp value and the graph of past water temp data can be displayed.

Select the [Display] → [Water temp graph].

To display the water temp graph, select the [ON]. To stop the display of water temp graph, select the [OFF].

Disp Width

When the image is zoomed or the high frequency/low frequency displayed, the disp width can be changed.

0093132702-01 2-13

Chapter 2 How to use the Menu CVS-126

Adjust D.range Image

Alarm1 Alarm2 NAV Disp Sonar Next

Disp width

Image swap

NAV 1

NAV 2

Return

Center

A B

Select the [Disp] → [Disp. width].

Select the width of image.

Image Swap

The images of echo sounder at the right and left sides can be swapped.

Select the [Display] → [Image swap].

Select the swap state.

2-14 0093132702-01

Chapter 3 How to use the system menu CVS-126

Chapter 3 How to use the system menu

3.1

3.1 Display of System Menu

3.13.1

After powering on, besides the menu displayed first with the 【MENU】 key, the system menu, of which setting is not frequently changed, is provided.

[In out],[Correct],[System],[Setting],[Maintain]

Display the system menu

Press the 【MENU】 key.

Select the [Next].

Adjust D.range Image

Alarm1 Alarm2 NAV Disp Sonar Next

In out

Correct

System

Setting

Maintain

Press the 【】 key to display the system menu.

Prev In out Correct

System Setting Maintain

Adjust

D.range


Alarm1

Alarm2

NAV Disp

Sonar

Return to the normal menu.

Select the [Prev].

Press the 【】 key to display the normal menu.

3.2

3.2 Setting of External

3.23.2 In/Out

Set the setting related to the input/output.

Prev In out Correct

System Setting Maintain

Buzzer Setting

Set the buzzer sound to ON/OFF.

Temp Source

Switch the Sensor/NMEA.

Use the built-in water temp meter for sensor.

Use the external input value for NMEA.

Speed Source

Switch the Sensor/NMEA.

Use the built-in speed meter for sensor.

Use the external input value for NMEA.

Baud Rate

Change the transmission speed of external input/output.

Match the transmission speed with that of external equipment connected.(setting: 4800,9600,19200,38400)

Buzzer Setting

Temp source

Speed source

Baud rate

NMEA monitor

NMEA output data

Return

OFF

Sensor

4800

OFF

0093132702-01 3-1

CVS-126 Chapter 3 How to use the system menu

NMEA Monitor

The external input data can be displayed.

To return to the original menu, press the

【MENU】 key.

NMEA Output Data

The output of NMEA sentence can be set to ON/OFF.

Select the sentence name.

Press the 【】 key.

Prev In out Correct

System Setting Maintain

Select the ON/OFF.

Select the [Prev].

Press the 【】 key.

Caution: If you omit steps 4 and 5, the

3.3

3.3 Setting of Correct Item

3.33.3

Prev In out Correct

System Setting Maintain

DBT

DPT

GGA

MTW

TLL

VHW

VTG

ZDA

Return

OFF

setting is valid. But, when selecting the [In out] menu next, the [NMEA out data] is displayed.

Draft set

Sonic speed

Water temp

Boat speed

Inner-hull

Return

0.0m

Seawater

0.0

Draft Set

The tolerance of depth can be corrected.

Set the depth from the sea level to the set depth of your transceiver/receiver. Normally set draft value of your boat.(setting: expect ft:-10.0～

10.0,ft:-30.0～30.0)

Sonic Speed

Set the [Seawater] or [Freshwater]. Change to meet the usage,

Water Temp

The error of water temp value can be corrected.

(setting:-10.0～10.0℃,-10～10°F)

Boat Speed

The tolerance of boat speed value can be corrected.

When the [Speed source] is set to the [Sensor], it is corrected by %. (setting:-50～50%)

When the [Speed source] is set to the [NMEA], it is corrected by numeral. (setting:-10.0～10.0)

Inner-hull

The signal attenuation value in inner-hull use can be adjusted.（setting:-10～10: through-hull:0）

3.4

3.4 Setting of System Item

3.43.4

Prev In out Correct System Setting

Maintain

Simple menu

Operation Guide

FUNC.key setting

Language

Return

OFF

Image speed

English

3-2 0093132702-01

Chapter 3 How to use the system menu CVS-126

All WPTs:DLT

All IMG DT:DLT

Simple Menu

Set the simple menu display.

The items displayed in the menu are limited only to the setting items of minimum requirement.

When making the setting change fewer, it is convenient.

Operation Guide

When displaying the menu, it sets whether or not the operation guide is displayed at the lower part on the display.

When setting to “No display of operation guide”, the echo sounder image can be easily seen at the menu operation.

FUNC key set

Set the function assigned to the 【FUNC】 key.

(See [1.8

Use of 【FUNC】 key

].)

Depth Unit

It switches the unit of depth to fm, l.fm and ft.

Temperature Unit

It switches the unit of temperature to °C, °F.

Location Offset

The location offset can be set by 0.5 hours (30 minutes) unit.(setting:-11.0～14.0h)(UTC:0.0)

GPS select

It selects whether the GPS sensor is the KODEN made one or not.

GPS initialize

It is valid only when KODEN GPS is connected.

Language

Switch to the language to be displayed.

(See [1.2

3.5

3.5 Setting of Basic Set

3.53.5

Power On/ Off

].)

Item

Range & Speed Unit

The GPS sensor is initialized.

When connecting the GPS sensor other than KODEN GPS, do not use this item.

3.6

3.6 Maintenance Menu

3.63.6

Prev In out Correct System Setting

Maintain

Simulation

Initialize

System check

Return

OFF

Simulation

When the [Simulation] is set to ON, the pseudo image of echo sounder is displayed.

It switches the display unit to [nm, kt] or [km, km/h].

0093132702-01 3-3

CVS-126 Chapter 3 How to use the system menu

Initialize

It returns all the settings in the menu to the factory settings. However, the memorized data of display remains unchanged.

Caution: It returns to the factory settings

and the power is automatically shut down.

System Check

It is used for diagnostic test.

(See [4.5

Diagnostic Test ].)

All WPTs deletes

All WPT lists can be deleted.

All stored image deletes

All stored image lists can be deleted.

3-4 0093132702-01

Chapter 4 Maintenance and Inspection CVS-126

thinner solvent. If done so, the filter

Chapter 4 Maintenance and Inspection

4.1

4.1 Inspection

4.14.1

The daily maintenance and inspection extends the life of equipment. To always keep the equipment in the best condition, implement periodically the inspection shown in the table below.

Item Content of Inspection

Connector at the rear of CVS-126 Display unit

Wiring of cables Check the wiring of cables connecting the equipment and the

Grounding of display unit Scrape the rust off the ground terminal and make its contact well.

4.2

4.2 Cleaning

4.24.2

Check the looseness.

damage of cable.

CVS-126 Display unit

To protect the LCD and enhance the visibility of display, the acrylic filter is installed to the surface of CVS-126 Display unit. If this part is dirty, an image becomes unclear. So, dip the soft cloth in the neutral or alcohol detergent and wipe the filter surface lightly with the cloth wrung lightly.

Caution

Thinner

NEVER use a surface will chemically decompose, resulting in of transparency.

Transducer

In case of through-hull equipped transducer, check the surface of opening of transducer (portion form which the ultra-sonic is emitted). If shells and oil are stuck, scrub the surface with a wooden or bamboo knife with caution not to damage the surface and remove stuck matters. If you scrub strongly, the surface will be damaged, resulting in deteriorated performance of transducer.

4.3

4.3 Fuse Replacement

4.34.3

If the input voltage is too high, the over-current flows or a trouble occurs inside, the fuse will blow out. The fuse is housed in the power cable.

0093132702-01

Warning

Use the specified fuse. If you use a fuse other than specified one, it may lead to a serious accident.

4-1

CVS-126 Chapter 4 Maintenance and Inspection

4.4

4.4 If you suspect a trouble

4.44.4

Symptom Trouble cause Countermeasure

Even if the power is powered on, nothing is displayed.

The unit starts up. But, nothing is displayed on the display.

Too much interference and noise.

The display of water temperature / boat speed is abnormal or not displayed.

The display of present location/course is abnormal or not displayed.

• Blown fuse.

• The power voltage is out of

specification (10.8 to 31.2 VDC).

• Poor connection between power cable and battery.

• Connection between transducer and display unit.

• Defect of LCD display block.

• Installed position of

transducer.

• Interference from the echo sounder on other boat.

• Connection of sensor connector.

• Input source of water temperature sensor / speed sensor.

• Connection between this unit and navigation equipment.

• Exchange a fuse.(See [4.3 Fuse Replacement])

• Use a proper power as per specification.

• Confirm a connection between the power cable and the battery.

• Confirm a connection between Transducer and Display unit.

• Consult a repair shop or the distributor in your market.

• Confirm the position of transducer. (See [5.3 Installation of Transducer])

• Apply the interference rejection. (See [2.3 Rejection of Interference])

• Confirm the connection of the sensor connector.

• Confirm the input source.

• Confirm a connection between

Display unit and the navigation equipment.

4-2 0093132702-01

Chapter 4 Maintenance and Inspection CVS-126

4.5

4.5 Diagnostic Test

4.54.5

Perform the operation diagnosis.

When checking the operation diagnosis of panel key, the state of sensor inside and the version of software, it is using.

①

R O M R A M N M E A O K N G V O L T T E MP

S P E E D

G A I N

②

③

KM-E67 Ver1.00 20080408 FishSnd ver01.00 Jan 23 2008 09:18:54 Ipl ver01.00 Jan 24 2008 15:21:33

SimData ver01.00 Jan 24 2008 15:21:33 TOP.ncd 3s400ft256 2008/03/26 14:38:31

Return to the normal menu.

Press the 【MENU】 key for more than 3 seconds.

Diagnose.

① displays the diagnostic result.

The result of ROM and RAM check displays OK when normal and NG when abnormal.

Caution: To test the NMEA, TEMP and

SPEED, the special jig is necessary.

② implements the key input test. When pressing the key, the color of a part corresponding to the pressed key changes.

When pressing the [Knob], the LCD test is performed.

Confirm the version.

③ displays the information on the version of software.

When inquiring, inform us of verXX.XXX.

0093132702-01

4-3

Chapter 5 Installation CVS-126

Chapter 5 Installation

5.1

5.1 Item of Caution on Installation

5.15.1

To exercise fully the performance of echo sounder, the installation of CVS-126 must be performed by an engineer who is officially authorized by our company. The installation work includes the following content.

(1) Unpacking the configuration items

(2) Inspection of configuration unit, spare, accessories and material for installation

(3) Check of power voltage and capacity of current

(4) Decision of installing location

(5) Installation of CVS-126 Display unit and transducer

(6) Installation of accessories

(7) Plan and execution of cable laying and connection

(8) Adjustment after completion of installation

Unpacking the configuration parts

Unpack the configuration items and confirm that all of the items match with the contents on the equipment configuration list. If not matched, Contact the dealer you purchased or our sales company.

Inspection of configuration items and accessories

Inspect the appearance of each configuration item and accessories and check that no dents or damage exist.

If any dents or damage exists and they are believed to be caused by accident during transportation, contact the transportation and insurance company and consult our sales company or our dealer nearest to you.

Decision of Installing Location

To exercise fully the performance of equipment, install the equipment, considering the points mentioned below.

(1) Install the equipment at the location in the bridge so that its display can be easily seen.

(2) Select a safe location where the equipment is not exposed to humidity, water splash, rain and

direct sunshine.

(3) Keep enough space for maintenance. Especially, secure enough space at the rear panel where

many cables are concentrated.

(4) Keep the equipment as far away from the wireless transmitter/receiver as possible.

5-1 0093132702-01

CVS-126 Chapter 5 Installation

The equipment is not waterproofed. Avoid excessively damp place. Do not install the equipment in place suffering from excessive water-drops. Otherwise, the inside of display window mists over or corrosion may occur inside.

Laying and Connection of Cable

(1) Keep the transducer and power cable as far away from the cables of other electronic equipment

as possible.

(2) The cabinet of CVS-126 Display unit is securely grounded to the hull, using the ground terminal on

the rear panel.

Caution: The ground side of power input of this equipment is connected to the ground

terminal. In case of + (positive) ground, it cannot be used. The power may short-circuit.

(3) If you connect the power cable directly to the battery, the interference from other electronic

equipment is not subject to occurrence. (See Fig. 5.1.)

CVS-126 Display unit

Good example

Battery Battery

Noise

Fig. 5.1 Connection of Power Line

Bad example

CVS-126 Display unit

Noise

Confirmation after Installation

Be sure to confirm the following items before starting up this equipment. The confirmation is mandatory to operate the equipment normally.

(1) Is the power voltage in the boat within the appropriate voltage range? Is the current capacity

enough? Voltage Range: 10.8 to 31.2V when measured at the power connector input.

(2) Is the wiring of transducer cable correct? Is the wiring shorted?

5.2

5.2 Installation of CVS-126 Display unit

5.25.2

CVS-126 Display unit can be desk-top installed or flush-mount installed.

It cannot be installed in other method (Example: Suspended installation). Install in the following procedure.

0093132702-01 5-2

Chapter 5 Installation CVS-126

126 Display unit

Desk-top Installation

(1) Loosen the knob bolt fixing CVS-126

Display unit to the mounting bracket, push

CVS-

Knob bolt

Turn two turns the knob bolt to loosen it and pull the unit upward.

Fixing screw 4

the unit to the left side and pull the unit upward.

(2) Place the removed unit to a safe and flat

place.

(3) Place the mounting bracket on the location

for the unit to be installed and fix it with four screws (trans-tapping screws) supplied with installing materials.

(4) Connect the connectors for power and

transducer to the unit respectively.

Mounting bracket

(5) Install the unit to the mounting bracket and

fix the unit by turning clockwise the knob

Fig. 5.2 Desk-top Installation

bolt

Flush-mount Installation

(1) Make a square hole (160mm x 160mm) at the location to be installed. (See Fig. 5.4.)

(2) Turn counter-clockwise the knob bolt fixing CVS-126 Display unit to the mounting bracket to

loosen it, push the unit to the left side and pull the unit upward. The mounting bracket and knob bolt are no longer used.

(3) Confirm that the unit matches with the square holes. If not matched, correct the square hole.

(4) Remove the front frame of CVS-126 Display unit, pulling it toward you. (See Fig. 5.3.)

(5) Connect the connectors for power and transducer to the unit respectively.

(6) Install the CVS-126 Display unit in the installing location (square hole) and fix it with four tapping

screws (4mm) (M4 or pan-head). (Prepare 4mm screws suitable for thickness of installing location.)

(7) Install the front frame removed in step (4).

5-3 0093132702-01

CVS-126 Chapter 5 Installation

Fixing screw 4mm 4 pieces

Not supplied

Threading hole

160 16

R30

Front frame

Figure 5.3 Flush-mount Installation

Figure 5.4 Work of flush-mount installation hole

0093132702-01 5-4

Chapter 5 Installation CVS-126

5.3

5.3 Installation of Transducer

5.35.3

The standard installation of this echo sounder is shown in figure 5.5.

Figure 5.5 Installation of Transducer

In case of Inner-Hull

Using the optional inner-hull kit (MFB-04), install the transducer to the inner side of ship’s bottom.

Caution on installation

Figure 5.6 Inner-Hull Installation

(1) Select the location where no bubble is generated during navigation.

(2) Select the relatively thin location of ship’s bottom.

(3) Be sure to remove oil on the contact surface. File the contact surface with sand paper (#400) so

that the adhesive strength will increase.

(4) The adhered surface will dry in about two hours.

(5) Leave the unit for a whole day and fill in the coolant. More than 80% of the transducer should be

submerged in the coolant.

5-5 0093132702-01

CVS-126 Chapter 5 Installation

ransducer

In case of through hull

Install the transducer directly to the ship’s bottom

Installation Procedure

(1) Select the installing location.

(2) Remove the fixing nut and one piece of rubber packing.

(3) If the slope of ship’s bottom is greater than 5°, make a wooden base to fit to the slope of ship’s

bottom. To reduce the water resistance, cut the bow direction tip of wooden base at the outer side of ship’s bottom in the triangle shape.

(4) Make holes at the installing location. If the wooden base is used, make holes in the wooden base.

(5) Thread the rubber packing in the transducer and then the cable.

(6) To prevent water from seeping through the gap between the transducer and the hole, fill out the

gap with FRP or silicon glue. (Glue the wooden base likewise.)

(7) Thread the rubber packing and fix it with the fixing nut firmly.

(8) Connect the transducer cable to the connector of CVS-126 Display unit.

Fixing nut

Rubber packing

In case that the slope of ship

Rubber packing

Ship

s bottom

Less than 5

s bottom is less than 5

Figure 5.7 Through-hull Installation

Fixing nut

Wooden base

Rubber packing

In case that the slope of ship

Rubber packing

Wooden base

Ship

s bottom

s bottom is greater than 5

0093132702-01 5-6

Chapter 5 Installation CVS-126

Line output for speaker with amplifier

For power of GPS etc

ransducer

X+

Speed sensor power

5.4

5.4 Wiring

5.45.4

Connection of Cable to CVS-126 Display unit

Connect the power cable and transducer to the connectors of CVS-126 Display unit.

Power input

10.8~31.2VDC NMEA data input output

GPS, plotter etc

POWER TD

Sonar tone output

Power output

T For 50/200kHz in common Speed sensor data input

Water temperature sensor data input

GND

Pin Assignment of Rear Connector

Pin assignment viewed from the rear of CVS-126 Display unit.

POWER

Sonar tone R

Sonar tone L Power + GND

A T

NM E NM E NM E NM E Power Shield Sonar tone COM Outside power

A T A R A R

Speed sensor input

Transducer input output Transducer shield Transducer input output Water temperature sensor power Water temperature sensor input Speed sensor GND

5-7 0093132702-01

CVS-126 Chapter 5 Installation

DC- (Black)

Connection of Power Cable and Transducer

Connect the power cable to the [POWER] connector and the transducer to the [TD] at the rear of CVS-126 Display unit connector.

Connection of DC power cable (CW-264-2M)

To [POWER] connector

Caution: Wind the insulation tape around the un-used lead wire for core-wires not to contact

each other.

3.5 stereo jack

DC+ (Red)

Connection of transducer

To [TD] connector

Grounding

• Use heavy gauge cable for grounding wire.

• Connect the grounding wire to the grounding material in a short distance.

• When connecting the external equipment of which positive polarity is connected to the ground line,

do not connect the ground of signal line to the cabinet ground.

Connection with external equipment

The DC power cable contains the connection cables for external equipment such as navigation equipment and KODEN GPS sensor.

Color Pin

Red ③ Power input+ (with 2A fuse)

Black ⑨ Power input- (with 2A fuse)

Orange ⑥ NMEA data output +

Blue ⑤ NMEA data output -

White ⑦ NMEA data input +

Green ⑧ NMEA data input -

Remark

Color Pin

White ②

Red ①

Black ⑪

Yellow ⑫ Outside power

Gray ④ GND

Shield ⑩

External speaker output (with ø3.5 stereo jack)

Remark

0093132702-01 5-8

Chapter 5 Installation CVS-126

Connection with Speed Sensor or Water Temperature Sensor (Option)

When installing the optional speed sensor or water temperature sensor, connect to the [TD] connector together with the transducer via the transducer cable (Type: CW-840-0.3M). For wiring, see the figure below.

After soldering, implement the waterproof and insulation treatment on the connected part with the self-melting tape.

Structure of Transducer Cable

2 core shield wire

lead wire

Connection Table of Transducer

Transducer Cable Transducer

3 Orange Red 4 Shield Shield 5 White White

TD1 (Orange)

Shield

TD2 (White)

SPD.PULSE (Blue)

SPD.VCC (Violet)

SPD.GND (Black)

TEMP.VCC (Green)

TEMP.SIG (Red)

TD-500T-2 No. of 2 core shield Color of 2 core shield TD-500T-3

To the speed sensor

To the water temperature sensor

Connection Table of Speed Sensor and Water Temperature Sensor

Transducer Cable Water Temperature Sensor / Speed Sensor

No, of lead

wire

1 Blue — Green Green Green

2 Violet — Red Red Red

6 Green Gray White White White

7 Red Gray Brown Brown Brown

8 Black — Shield Shield Shield

5-9 0093132702-01

Color of lead

wire

T-81 ST-80

ST-80-1

ST-90

ST-90-1

ST-100

ST-100-1

CVS-126 Chapter 5 Installation

Connection of External Speaker (Prepared by a customer)

The ø3.5 stereo jack is provided to the power cable. If you connect the speaker with the amplifier to the external, you can clearly hear the sonar sound. Adjust the volume of speaker with the amplifier equipped to the speaker

3.5 stereo jack

5.5

5.5 Serial Data

5.55.5

Input Data

The sentences of GGA, GLL,HDT, MTV, MWV, RMC, VHW, VTG and ZDA can be received. The type of NMEA0183 Ver.1.5, Ver.2.0 and Ver.3.0 can be inputted.

Information Priority Order of Sentence Information Priority Order of Sentence

Latitude, Longitude

Course VTG>RMC Wind Speed MWV

Haedding HDT Date ZDA>RMC

Ground Speed VTG>RMC Time ZDA>GGA

Water Speed VHW Water

GGA>RMC>GLL Wind Direction MWV

MTW

Temperature

Output Data

The sentences of DBT, DPT, GGA, GLL, HDT,MTW, MWV,RMC, TLL, VHW, VTG and ZDA can be transmitted. The output is performed in the type of NMEA0183 Ver.2.0. However, the DBT is performed in Ver.1.5.

Sentence Information Sentence Information DBT Depth MWV Wind Direction, Wind Speed DPT Depth from the transducer RMC Latitude/Longitude, Course,

Ground Speed, Date GGA Latitude/Longitude, Time TLL Target Position GLL Latitude/Longitude VHW Water Speed HDT Headding VTG Course, Ground Speed MTW Water Temperature ZDA Date,Time

0093132702-01 5-10

Chapter 6 Table Attached CVS-126

Chapter 6 Table Attached

6.1

6.1 Menu List

6.16.1

The factory set value is shown by the bold and underline.

6-1 0093132702-01

CVS-126 Chapter 6 Table Attached

Inner

hull (-10～10:0)

All WPTs:DLT

All IMG DT:DLT

,Homing

GLL

HDT MWV RMC

Other

KODEN GPS

0093132702-01 6-2

Chapter 6 Table Attached CVS-126

6.2

6.2 Specification

6.26.2

Item Content

Model CVS-126

Transmission Frequency

Transmission Method

Transmission Power

Overall

Transmission Firing Times

Transmission Pulse Width

Minimal Reception Gain

Display 5.7 inch color TFT LCD QVGA

Display Mode Normal, dual frequency, zoom, NAV (homing mode, compass), A scope, tide

Zoom Mode Bottom, bottom discrimination, zoom, bottom zoom, bottom follow zoom

Range 2.5 to 800m (It can be set at arbitrary 8 locations.)

Range Unit m, fm, l.fm, ft

Shift Amount 0 to 300m (Maximum depth 1200m using Shift)

Indicator

Zoom Range 2.5m to 200m

Image Speed 10 stages (2/1, 1/1, stop, 1/1.5, 1/2, 1/2.5, 1/3, 1/3.5, 1/4, 1/4.5)

Function Registration

Color tone Monochrome, 8 color, 16 color, 64 color

Data

Output Data

Serial

Power DC10.8—31.2V 10W

50kHz/200kHz

Single or alternate

600W

5000 times/minute at maximum

50µs to 30ms

0dBµV

Image speed, range method, shift, interference rejection, color rejection, noise rejection, zoom range, zoom depth, white line, background color

Type NMEA0183 Ver.1.5/2.0/3.0 Input Data

GGA, GLL, MTW, MWV, RMC, VHW, VTG, ZDA

Type NMEA0183 Ver.2.0 (DBT only Ver.1.5)

DBT, DPT, GGA, GLL, MTW, RMC, TLL, VHW, VTG, ZDA

Range of Operating Temperature

Upper limit of Store Temperature

Upper limit of humidity

Waterproof IPX5

Vibration Resistant

Environment Condition

Size of Cabinet Maximum 182x208x130 (Unit 182x182x85)

Weight 1.3kg

6-3 0093132702-01

-15°C to +55°C

+70°C

93% ± 3% (At +40°C)

When the following vibration is applied to equipment respectively under specified condition, its performance should not be affected.

• From 2 - 5Hz up to 13.2Hz vibration width ±1mm ±% (Maximum acceleration 7m/s2 constant at 13.2Hz)

• From 13.2Hz up to 60Hz Maximum acceleration 7m/s2 constant

CVS-126 Chapter 6 Table Attached

6.3

6.3 Appearance

6.36.3

0093132702-01 6-4

Chapter 6 Table Attached CVS-126

6-5 0093132702-01
