PARTS LIST
HSM-2212
-----·-------------··--------------------------------
..
.
. (
" •
• : I j
ll(lot••~l
, . ,
..
. ,
..
U t
I:
I
((
KAUUN
MFG.
IIIIDa:J
CO..ll'D.
1
○
ref no. part no. name of parts
--- -------------- --------------------01 SP-000011222 SET SCREW
02 SP-220118000 FACE PLATE
03 SP-301008000 SET SCREW
04 SP-000011211 SET SCREW
05 SP-220501004 THREADER BASE COMP.
06 SP-000016032 SCREW
07 SP-250125058 ADJUSTING HOLE PLUG
08 SP-220062008 BOBBIN STOPER
09 SP-220055008 REAR COVER
10 SP-250020007 RUBBER
11 SP-250087002 SET SCREW
12 SP-220037004 REAR COVER
13 SP-250045008 BOBBIN WINDER SPRING C
14 SP-000000309 SNAP RING 5D
15 SP-220015006 WINDER FIXED PLATE
16 SP-301022000 BOBBIN WINDER SHAFT PIN
17 SP-220014005 BOBBIN CRANK
18 SP-220013004 BOBBIN WINDER
19 SP-353029008 COIL
20 SP-353030002 RUBBER RING
21 SP-250507003 250 ARM/BED
22 SP-301046000 SET SCREW
23 SP-301087003 SET SCREW
24 SP-250013007 LEAD SHAFT
25 SP-220617004 UPPER TENSION COMP.
26 SP-355026001 SET SCREW
27 SP-301008000 SET SCREW
28 SP-260035006 SET SCREW
29 SP-230008007 TENSION CHECK SPRING
30 SP-301261003 SET SCREW
31 SP-250006007 NEEDLE PLATE
32 SP-220036003 EXTENSION TABLE PLATE
33 SP-220060006 NUT
34 SP-250023103 ADJUSTING FOOT
35 SP-353049004 PANEL FIXATION
36 SP-220120108 FRONT COVER (DRAWING)
37 SP-370048006 HINGED SCREW
38 SP-260027038 SELECTOR DIAL
39 SP-220095309 SELECT DIAL INDICATED PLATE
40 SP-220163000 RATING PLATE
41 SP-220061007 HANDLE COVER
42 SP-000012201 SNAP RING
ref no. part no. name of parts
--- -------- --------------------01 SP-301083009 THREAD TAKE-UP CRANK
02 SP-000003508 SPRING PIN 4*20
03 SP-301084000 SET SCREW
04 SP-301068008 SET SCREW
05 SP-250002003 FRONT BUSHING
06 SP-250004005 FRONT BUSHING BRACKET
07 SP-301008000 SET SCREW
08 SP-301086002 NYLON WASHER
09 SP-301340306 COLLAR
10 SP-301087003 SET SCREW
11 SP-301093002 UPPER SHAFT SET SCREW
12 SP-370265001 UPPER SHAFT GEAR (12 PATTERN)
13 SP-370504005 SELECT CAM COMP
14 SP-220001009 UPPER SHAFT
15 SP-250005006 REAR BUSHING BRACKET
16 SP-00000090 7 E RING UPPER SHAFT
17 SP-250002003 FRONT BUSHING
18 SP-220002000 MOTOR BELT
19 SP-220004002 WHEEL TRANSPORT PLATE
20 SP-220008006 BALANCE PLATE
21 SP-000011222 SET SCREW
22 SP-220005003 TRANSPORT PIN
23 SP-220003012 HAND WHEEL
24 SP-000016032 SCREW
25 SP-250087002 SET SCREW
26 SP-220006015 CLUTCH BUTTON
27 SP-220007016 WHEEL COVER
28 SP-610100000 SPRING
29 SP-301544003 TAKE-UP LEVER CAMP
30 SP-301100003 SET SCREW
31 SP-301503000 NEEDLE HOLDER
32 SP-301046000 SET SCREW
33 SP-370011000 ZIGZAG DRIVING PLATE
34 SP-220028002 SUPPORTER
35 SP-000012326 RING
36 SP-301245001 WASHER
37 SP-301016001 SET SCREW
38 SP-301045009 ECCENTRIC PIN
39 SP-000000206 SNAP RING 4D
40 SP-000000309 SNAP RING 5D
41 SP-250089004 NEEDLE BAR SUPPORTER
42 SP-301016001 SET SCREW
43 SP-301047001 SPRING
44 SP-260042006 NEEDLE BAR
45 SP-260502009 NEEDLE CLAMP COMP
46 SP-301244206 NEEDLE
47 SP-230010002 TENSION RELEASE LEVER *A
48 SP-290026007 SPRING
49 SP-301252001 GUIDE BRACKET
50 SP-301087003 SET SCREW
51 SP-370154006 PRESSER BAR LIFTER
52 SP-250007008 PRESSURE BAR LIFTER
53 SP-301070003 HINGED SCREW
54 SP-220030007 NEEDLE BAR STOPPING PLATE
55 SP-301245001 WASHER
56 SP-301049003 SET SCREW
57 SP-370147006 SPRING
58 SP-271094007 TENSION SPRING SETTER
59 SP-301037008 SET SCREW
60 SP-301061001 PRESSER BAR
61 SP-301522005 PRESSER FOOT HOLDER
62 SP-353012008 ZIGZAG PRESSER FOOT
63 SP-610012004 SET SCREW
2
○
3
○
ref no. part no. name of parts
--- -------- --------------------01 SP-220605548 PATTERN COMP. (12 PATTERN)
02 SP-301008000 SET SCREW
03 SP-301151009 NUT
04 SP-351047006 BAND
05 SP-370042000 STRETCH STITCH ROD
06 SP-301155003 SPRING
07 SP-250081109 ADJUSTER
08 SP-301289007 SET SCREW
09 SP-301154002 HINGED SCREW
10 SP-301046000 SET SCREW
11 SP-301087003 SET SCREW
12 SP-301153104 COLLAR
13 SP-370045003 SPRING
14 SP-270284003 ADJUSTING PLATE
15 SP-000000505 SNAP RING 9D
16 SP-301152000 FEED REGULATOR SHAFT
17 SP-301008000 SET SCREW
18 SP-230003792 STITCH LENGTH DIAL
19 SP-270655294 STITCH LENGTH DIAL COMP.
20 SP-380024052 REVERSE BUTTON
21 SP-220801007 LIGHT CORD COMP.
22 SP-650816103 LIGHT BULB
23 SP-301285106 BELT
24 SP-230813003 MOTOR COMP.
25 SP-000003807 SPRING PIN 2*14
26 SP-250146000 NUT
27 SP-301555007 MOTOR WHEEL COMP.
28 SP-000000103 SNAP RING 3D
29 SP-260025003 MOTOR BRACKET
30 SP-450063008 SPRING WASHER
31 SP-301143008 SET SCREW
32 SP-260050007 INSULATED PLATE
33 SP-000063023 SET SCREW
34 SP-000063034 RECEPTACLE
35 SP-000063001 SCREW
36 SP-260026037 SWITCH FIXED PLATE
37 SP-250831009 SWITCH COMP
38 SP-370044002 WASHER
39 SP-370043001 ROD SPRING
ref no. part no. name of parts
--- -------- -----------------------01 SP-301181008 FEED DOG BASE SPRING
02 SP-301197007 SPRING HOLDER
03 SP-301185002 SET SCREW
04 SP-220012003 SET SCREW
05 SP-220011002 DROP FEED CRANK
06 SP-301151009 NUT
07 SP-301195005 SPRING
08 SP-000000309 SNAP RING 5D
09 SP-250010004 SET SCREW
10 SP-220010001 UP/DOWN SHAFT
11 SP-301512002 CRANK ROD COMP
12 SP-301106009 TAPER SCREW
13 SP-301087003 SET SCREW
14 SP-353014000 LOWER SHAFT BRACKET
15 SP-301107000 NUT
16 SP-353015001 SCREW
17 SP-301109002 LOWER SHAFT
18 SP-301110006 LOWER SHAFT FRONT BUSHING
19 SP-301182102 FEED LIFTING CAM
20 SP-301111100 LOWER SHAFT REAR BUSHING
21 SP-301113009 OSCILLATING SHAFT GEAR
22 SP-301115001 SET SCREW
23 SP-301114000 SET SCREW
24 SP-301147002 FORKED ROD SLIDE BLOCK
25 SP-301146001 FORKED ROD SLIDE BLOCK DRAFT
26 SP-301145000 FORKED ROD
27 SP-000000402 SNAP RING 6D
28 SP-301179003 CONNECTING PIN
29 SP-301241007 CENTER PIN B
30 SP-301517007 FEED ROCK CRANK
31 SP-301171005 FEED ROCK SHAFT
32 SP-301131003 SET SCREW
33 SP-301173007 FEED DOG BASE SHAFT
34 SP-000000206 SNAP RING 4D
35 SP-301172006 FEED DOG BASE
36 SP-301175009 SET SCREW
37 SP-301174008 FEED DOG
38 SP-301046000 SET SCREW
39 SP-301130105 BEVEL GEAR
40 SP-301129101 COLLAR
41 SP-301542207 HOOK RACE BODY COMP.
42 SP-301541000 HOOK RACE SHAFT COMP.
43 SP-301132406 HOOKPANEL
44 SP-610081004 BOBBIN
45 SP-301515304 BOBBIN CASE
4
○
ACCESSORIES
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
1. All purpose foot (On machine): SP-353012008
2. Buttonhole foot (Plastic): SP-303401003
3. Zipper foot: SP-301438003
4. Bobbin (Plastic): SP -610081004
5. Screw driver: SP-301439004
6. Needle plate screw driver: SP-660403001
7. Felt: SP-301403009
8. Buttonhole cutter: SP-303403201
9. Feed cover plate (Plastic): SP-220401003
10. ＃14 Needle: SP-301244206
Twin Needle: SP-301408107
11. Spool pin (A) (Plastic): SP-220405007
12. Spool pin (B) (Plastic): SP-220406008
13. Low shank adapter(On machine): SP-301522005
INSTRUCTION MANUAL: 220435006
14.
DUST COVER: SP-353435805
15.
16. CONTROLLER COMP: SP-230814004
CARTON: SP-220717005
17.
17
ACCESSORIES (OPTION)
1 2
3 4
5 6
7 8
9 10
11 12
1. Hemmer foot: SP-301405001
2. Button sewing foot (Plastic): SP-301406002
3. Blind hem foot: SP-353431007
4. Satin stitch foot (Plastic): SP-301447005
5. Embroidery foot: SP-380413007
6. Quilting foot: SP-301404000
7. Overcasting foot: SP-303404006
8. Cording foot: SP-353432008
9. Walking foot: SP-280416007
10. Gathering foot: 280415006
11. Quilting guide: SP-301434009
12. Seam guide: SP-301433008
13. Side cutter: SP-680461009
13
