SiriusXM Onyx Plus with Vehicle Kit User Guide

Download

Dock & Play Radio

VEHICLE

KIT INCLUDED

USER GUIDE

Table of Contents

Compatibility ..................4

Introduction ...................5

Features ........................... 5

Safety and Care Information ..........6

What’s in the Box? .................. 8

Onyx Plus Functions .................9

PowerConnect Vehicle Dock ......... 10

Vehicle Installation ............ 12

Step 1: Choose a Location for Your

Radio ...........................12

Step 2: Install the Adhesive or Vent

Mount ........................... 14

Step 3: Mount the Magnetic Mount

Antenna ......................... 18

Step 4: Route the Magnetic Mount

Antenna Cable ...................24

Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power

Adapter .........................35

Step 6: Connect the Audio ..........36

Subscribe ................... 45

Using Your Onyx Plus ..........47

The Main Display ...................47

Navigation Basics ................. 48

Listening to Satellite Radio .......... 51

FM Presets ........................56

Special Features ..............56

Album Art .........................57

Parental Controls ...................58

TuneMix ...........................63

TuneScan ......................... 66

TuneStart. . . . . . . . . . . . . . . . . . . . . . . . . 69

Pause & Replay ....................71

Song/Artist Alerts ..................73

Game/Score Alerts .................78

Sports Ticker ......................85

Where Else Can You Use Your

Onyx Plus? .................. 91

Conﬁguring Your Onyx Plus .....92

Radio ID ...........................92

Channel Tuning ....................93

FM Settings. . . . . . . . . . . . . . . . . . . . . . . 94

Brightness ........................ 99

Audio Level .......................100

Alerts ............................101

Parental Controls .................. 101

Feature Settings ..................101

Parental Controls .................. 103

Signal Indicator ................... 103

Auto Shut Off .....................104

Factory Settings .................. 105

Demo Mode ......................108

Using the Vehicle Dock From the

Universal Xpress Car Kit .......... 110

Turn FM Transmitter On/Off ......... 111

Troubleshooting ............. 113

Product Speciﬁcations ........118

Patent and Environmental

Information ................119

FCC Statement .............. 120

Copyrights and Trademarks .... 121

Owners Record .............. 122

Compatibility

The XDPIV2 Vehicle Dock included with your Onyx Plus is compatible with the AMPS dash and vent mounts included with your Onyx Plus, as well as the T-Slot dash and vent mounts (previously included with Onyx). The AMPS mounting accessories are not compatible with the previous version of the Vehicle Dock, XDPIV1.

The XDPIV2 Vehicle Dock can be identiﬁed by a label, and the four AMPS mounting points, both on the rear of the dock.

Rear View

4 AMPS Mounting Points

Model: XDPIV2

Label XDPIV2

AMPS Style Mounts

AUDIOANT PWRFM

T-Slot

T-Slot Style Mounts

Introduction

Features

Thank you for purchasing the SiriusXM Onyx Plus with Vehicle Kit!

SiriusXM Onyx Plus has these exciting features to enhance your overall experience:

• View program and channel information on a full color display featuring album art, channel logos and graphics

• Store up to 20 of your favorite channels for one-touch access

• Pause, rewind and replay live satellite radio plus all your Smart Favorite channels

• Start songs from the beginning when you tune to a Smart Favorite music channel

with TuneStart™

• Create your own music channel that is a blend of your Smart Favorite music channels with TuneMix™

• Scan and select songs that have already played on your Smart Favorite music channels with TuneScan™

• Enjoy SiriusXM Xtra Channels - 20+ channels of additional music, sports, entertainment and SiriusXM Latino, a collection of Spanish language channels*

• Listen at home, at the ofﬁce, outdoors, or in additional vehicles - all with just one subscription

• Get alerts so you won’t miss any of your favorite artists, songs, games and scores**

• Catch up on the latest sports scores with Sports Ticker™ **

• Browse what’s playing on other channels while listening to the current one

• Lock and unlock channels with mature content

• Jump back to the previous channel with One-Touch Jump™

• Access trafﬁc and weather for the city of your choice with the press of a button

• Hear SiriusXM through your existing vehicle stereo with easy, do-it-yourself installation***

• Includes PowerConnect™ Vehicle Kit – add optional accessories for your home,

outdoors, or even vehicles.

• Store and easily access FM presets to optimize PowerConnect™ performance

• Works on the XM network

Please read the entire User Guide before Using Your Onyx Plus!

*Access to Xtra channels depends on subscription package. Subscription sold separately. **Game and Score Alerts, and Sports Ticker, depend on the subscription package, which must include

the play-by-play channels of the desired sports leagues. Subscription sold separately. ***Requires an FM stereo or Aux In capability. Use the included Aux In cable if your vehicle has Aux In

capability for best performance. Will also work with cassette adapter (sold separately).

Introduction

Safety and Care Information

IMPORTANT! Self installation instructions and tips are provided for your convenience. It is your responsibility to determine if you have the knowledge, skills, and physical ability required to properly perform an installation. SiriusXM shall have no liability for damage or injury resulting from the installation or use of any SiriusXM or third party products. It is your responsibility to ensure that all products are installed in adherence with local laws and regulations and in such a manner as to allow a vehicle to be operated safely and without distraction. SiriusXM product warranties do not cover the installation, removal or reinstallation of any product.

•Do not expose to extreme temperatures (above 140°F or below -4°F, or above 60°C or below -20°C).

• Do not expose to moisture. Do not use device near or in water. Do not touch the device with wet hands.

• Do not let any foreign matter spill into device.

• Do not store in dusty areas.

• Do not expose to chemicals such as benzene and thinners. Do not use

liquid or aerosol cleaners. Clean with a soft damp cloth only.

•Do not expose to direct sunlight for a prolonged period of time, and do not expose to ﬁre, ﬂame, or other heat sources.

• Do not try to disassemble and/or repair device yourself.

• Do not drop your device or subject it to severe impact.

• Do not place heavy objects on device.

• Do not subject device to excessive pressure.

• If the LCD screen is damaged, do not touch the liquid crystal ﬂuid.

Introduction

Warning!

•Opening the case may result in electric shock.

•If the liquid crystal ﬂuid comes in contact with your skin, wipe the skin

area with a cloth and then wash the skin thoroughly with soap and running water. If the liquid crystal ﬂuid comes into contact with your eyes, ﬂush the eyes with clean water for at least 15 minutes and seek medical care. If the liquid crystal ﬂuid is ingested, ﬂush your mouth thoroughly with water. Drink large quantities of water, and induce vomiting. Seek medical care.

•Make sure that you insert the PowerConnect Power Adapter all the way into the vehicle’s cigarette lighter or power adapter socket.

•If you are using PowerConnect as your audio connection option, it is advisable not to insert a multi-outlet adapter into the same vehicle cigarette lighter or power adapter socket to simultaneously power other devices. Some multi-outlet adapters can prevent the PowerConnect feature from working properly.

• When using this product, it is always important to keep your eyes on the road and hands on the steering wheel. Not doing so could result in personal injury, death, and/or damage to your device, accessories, and/or to your vehicle or other property.

• Vehicle installation, service activation, and Radio conﬁguration functions should not be performed while driving. Park your vehicle in a safe location before beginning installation.

•This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

Your device should be placed in your vehicle where it will not interfere with the function of safety features, e.g., deployment of airbags. Failure to correctly place device may result in injury to you or others, if the unit becomes detached during an accident and/or obstructs the deployment of an airbag.

Introduction

What’s in the Box?

34567890

Onyx Plus Radio

Aux In Cable

Cable

Routing Adapter

menu alerts

t-mix t-scn

twx b / #

PowerConnect™ Vehicle Dock

Screws (4)

Dash Mount

Vent Mount and

Extended Vent Clamps

PowerConnect Power

Adapter

Magnetic Mount

Antenna

Antenna & Dash Mount

Alcohol Preparation Pads

Introduction

Onyx Plus Functions

Up and Down Buttons

Press to preview and tune to channels through the channel lineup; also press to scroll through lists and highlight items in lists.

Plus

Number Buttons

Press to tune to a stored favorite channel; Press and hold to store a favorite channel. Also used to enter channel numbers when the Direct button is pressed.

Channels stored in buttons 1 - 9 in banks A & B are smart favorites used for enhanced pause and replay, and for advanced music features TuneStart, TuneMix, and TuneScan.

Channels stored in button 0 in banks A & B are regular favorites.

34567890

Left and Right Buttons Press to search for channels by category.

menu alerts

t-mix t-scn

twx b / #

Pause and Replay Buttons

Pause, rewind, and replay live radio and smart favorite channels.

Banks/Direct Button Press to switch between favorite channel banks (A/B); Press and hold to enter a channel number using the number buttons and directly tune to the channel.

Power/FM Button Press to turn Radio on and off; Press and hold to quickly access FM channel presets.

Select Button When in a menu or list, press to confirm selection of highlighted item; when in TuneMix or TuneScan, press to end TuneMix/Scan and continue playing the currently tuned channel, or press and hold to end Tune Mix/Scan and return to the previously tuned channel.

Menu/Alerts Button Press to access advanced features and configuration options; when in configuration options, press and hold to return to main display screen; Press and hold to save a Song, Artist, or Game alert.

TuneMix/TuneScan Button

Press to begin TuneMix; Press and hold to begin

TuneScan.

Jump/Traffic Weather Button

Press to go back to the previous channel to which you were listening; Press and hold to directly access traffic and weather for the city of your choice.

Introduction

PowerConnect Vehicle Dock

Color-Coded Connections

The color-coded PowerConnect Vehicle Dock makes it simple to connect. Just match the colors on the cable ends to the colors on the dock to see what goes where.

Rear View

AUDIOANT PWRFM

AUDIO (Green) Connection for Aux In Cable or optional Cassette Adapter (sold separately).

ANT (Silver)

Connection for the Magnetic Mount Antenna.

PWR (Red) Connection for PowerConnect Power Adapter.

FM (Blue) Connection for optional FM Direct Adapter (sold separately).

Introduction

Wire Guide

The PowerConnect Vehicle Dock has a wire guide at the top rear that can help you to organize the cables and wires connected to the dock. If you need to bring a cable or wire from one side of the dock to the other, utilize the wire guide by looping the cable though the wire guide as shown.

Wire Guide

Option 1 Option 2

Vehicle Installation

WARNING! DO NOT attempt to install Onyx Plus while driving. Park your vehicle in a safe location before beginning installation.

Step 1: Choose a Location for Your Radio

When installing Onyx Plus in your vehicle, choose a location where it will not block your vision, interfere with the controls, or obstruct the air bag. The location should be easily accessible and provide good visibility of the display, and should not be located where it will be in direct sunlight, which will affect the visibility of the display screen.

Several examples of Onyx Plus mounted in a vehicle are shown: A is the on dash method using the Adhesive Mount, and B is the vent clip method using the Vent Mount.

jump

direct

jump

direct

Option 3

Vehicle Installation

jump

direct

Option 4

Option

jump

direct

ption 6

jump

direct

jump

direct

Vehicle Installation

Option 1

Option 2 Option 4

Step 2: Install the Adhesive or Vent Mount

Follow the instructions on the next several pages for the mounting method you have selected.

Installing the Adhesive Mount:

CAUTION! The adhesive used on the Adhesive Mount may be difﬁcult to remove. Do not install this mount on leather surfaces (contact your automobile dealership if you are unsure about your dash surface), and make sure the air temperature is at least 60°F (15°C) during installation. If it’s not at least 60°F, turn on the heater in your vehicle to bring the temperature up to 60°F.

1. Locate a flat surface for the Adhesive Mount. Make sure there is ample room for the PowerConnect Vehicle Dock and Onyx Plus Radio when installed.

2. Set the orientation of the Adhesive Mount before adhering it. Loosen the knob and adjust the adhesive foot for the location you selected in “Step 1: Choose a Location for Your Radio” on page 12.

Option 3

3. The dock mounting plate can be tilted in different directions. Adjust as necessary for your particular vehicle. When the orientation is correct, tighten the knob.

Vehicle Installation

Knob Adhesive Foot

Dock Mounting Plate

4. Attach the Adhesive Mount to the PowerConnect Vehicle Dock using the 4 provided screws.

5. Before you attach the Adhesive Mount to the dash, skip ahead and finish the remainder of the vehicle installation so that the cables are attached to the dock.

6. Once the cables have been attached to the dock, clean the mounting surface in the vehicle with the alcohol preparation pad and let it dry thoroughly.

7. Peel off the adhesive liner. Position, press, and hold the Adhesive Mount in place for 30 seconds.

IMPORTANT!

adhesive to cure (dry) for a minimum of 2-4 hours before using the mount. The best adhesion occurs after 24 hours.

TIP! To remove the Adhesive Mount, carefully lift the adhesive pad with your ﬁngers or a spoon. Warming the pad with a hair dryer for several minutes will help soften the adhesive.

Allow the Adhesive Mount

ANT

UDIO

Vehicle Installation

Installing the Vent Mount:

IMPORTANT! To make the cable connections easier, wait until after you have connected all the cables to the dock before you attach the Vent Mount to a vent.

1. Locate a vent with horizontal louvers sturdy enough to hold your PowerConnect Vehicle Dock and Onyx Plus Radio.

2. If the vent louvers in your vehicle are recessed, you may need to use the longer vent clamps with the Vent Mount. If so, remove the shorter vent clamps and install the longer ones into the Vent Mount. Be sure to observe the orientation of the vent clamps as shown, and replace both vent clamps.

Vent Mount Rear View

Slide Left Clamp to

Hole in Center

Pull Clamp Out

Towards You

Round End Orientation

Insert Round End

of the Extended

Clamp in the

Center Hole

Extended Vent Clamps

Vent Mount

Rear View

Short Vent

Clamps

Slide Clamp to Left

to Complete

Installation

Repeat to Replace

Right Clamp

Vehicle Installation

3. Attach the Vent Mount to the

PowerConnect Vehicle Dock using the 4 provided screws.

4. Before you attach the Vent Mount to the vent, skip ahead and finish the remainder of the vehicle installation so that the cables are attached to the dock.

Note! For greater clarity, the next illustration does not show the dock attached to the Vent Mount, however, the dock should be attached before continuing.

5. Once the cables have been attached to the dock, push the Vent Mount onto the vehicle vent as shown (1) until it hooks on the rear of the vent louver (2).

1 2 3

Dash

PUSH

Dash

Vent

Louver

FOOT

6. Rest the foot against the bottom of the vent (2), and adjust the tilt of the Vent Mount by repositioning the foot to the other adjustment hole (3).

TIP! To remove the Vent Mount, push the mount into the vent. Then lift up until disengaged from the rear of the vent louver, and remove the Vent Mount.

UDIO

HOOKED

Vent

ADJUSTMENT

ANT

Dash

Vent

TILT

HOLES

Vehicle Installation

Step 3: Mount the Magnetic Mount Antenna

Mount the Magnetic Mount Antenna on the outside of your vehicle, on a horizontal surface that will always face the sky. The antenna contains a strong magnet which will stick to any metal part of your vehicle, but will not damage the vehicle.

To install the Magnetic Mount Antenna:

1. Choose the best location for your antenna considering your vehicle type. Pay particular attention to any accessories that you may have like luggage racks and how frequently you may use them.

Sedan/Coupe: We recommend mounting the antenna just above

either the front windshield or the back window as shown.

Magnet

Vehicle Installation

SUV: We recommend mounting the antenna at the rear of the

roof as shown.

Convertible: We recommend mounting the antenna at the

leading edge of the trunk as shown.

Pickup Truck: We recommend mounting the antenna just above the front windshield as shown.

IMPORTANT! Consult a professional installer if your vehicle roof or hood is non-metallic (i.e., ﬁberglass), or you have difﬁculty ﬁnding a location for your antenna.

2. Clean the surface of the selected mounting location using the alcohol preparation pad and let it dry thoroughly.

Vehicle Installation

3 If you are installing the antenna at the roof edge, or hood edge, install

the Cable Routing Adapter to direct the antenna cable downward.

Routing Adapter

Adapter orientation

Without Cable

Installed

Cable Routing

Place the antenna

wire into the groove

of the Cable Routing

Adapter

With Cable

Routing Adapter

Installed

Slide the Cable Routing

Adapter down the antenna

wire and press it into the

antenna until it is ﬂush with

the bottom of the antenna

Vehicle Installation

4 Place the antenna in the location you selected. Follow the Tips and

Cautions shown on the next several pages.

TIP! Mount the antenna on the roof (for most vehicles) or trunk (for convertibles) where it has a clear view of the sky in all directions.

Vehicle Installation

CAUTION! Don’t mount the antenna inside the vehicle, for example, on the dashboard.

CAUTION! Don’t mount the antenna on any of the vehicle’s front, back or side pillars.

CAUTION! Don’t mount the antenna close to a roof rack. Adjust the rack so it’s further away from the antenna or move the antenna closer to the center of the roof.

Vehicle Installation

CAUTION! Don’t mount the antenna close to another antenna. Mount it at least 3 inches away.

Vehicle Installation

Step 4: Route the Magnetic Mount Antenna Cable

Before you begin routing the antenna cable, read these general instructions for how to route and hide the antenna cable. Then route your antenna cable according to the instructions which follow for your speciﬁc type of vehicle.

Use a blunt plastic putty knife, a credit card,

a plastic knife, or a similar blunt tool to lift the

Feed cable under rubber moulding around window

rubber window moulding

Tuck the cable under the

moulding around the window

Route cable out from under rear windshield

Vehicle Installation

moulding and tuck into weatherstripping around trunk opening Avoid sharp bends by running cable through weatherstripping for several inches

Pull weatherstripping from trunk opening

Tuck cable into weatherstripping. Route cable through weatherstripping several inches to avoid sharp bends

Pull cable out of weatherstripping and route through trunk to cabin

Route cable out of window moulding and into weatherstripping around trunk opening

Bring cable out of weatherstripping and into trunk

Vehicle Installation

Route cable along trunk wall and into cabin

Route cable along trunk wall and into cabin through gap or conduit, along existing wiring harness

Vehicle Installation

Use a blunt plastic putty

knife or similar blunt tool

to lift edge of interior

trim and tuck cable

under trim. Continue

towards front of vehicle

Route cable under trim or upholstery

Continue routing cable under trim or carpet towards front of vehicle

Route cable from trunk under interior trim, into cabin and towards front of vehicle

Continue routing cable under

Vehicle Installation

carpet or console to radio location

Pull carpet or mat back

Bring cable out from trim and route under carpet to dashboard or console

TIP! Always be careful to include enough slack in your cable to accommodate open doors or trunk lids. Use things typically found around the home, like electrical tape, to secure cables in areas so that hinges do not pinch the cable with the door. Hide any excess cable in the trim.

Coil excess cable under carpet or mat

Bring cable out from trim

Vehicle Installation

Sedan/Coupe With Antenna Placed at the Rear of the Roof:

1. Feed the antenna cable from the antenna underneath the rubber molding around the rear window. Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around the rear window and tuck the antenna cable underneath the molding. Route the antenna cable around and down the window to the lowest point. If your rear window does not have rubber molding, we recommend consulting a professional installer.

2. Route the antenna cable out of the window molding and into the rubber weather stripping around the trunk opening. Lift the weather stripping from the opening and tuck the cable inside it, then replace the weather stripping. To avoid sharp bends in the cable, run the cable inside the weather stripping for a few inches, then remove the cable from the weather stripping inside the trunk. Keep the cable away from hinges, gears, etc., that could damage it.

3. Route the cable out from the rubber weather stripping and along the trunk wall. Continue routing the cable into the vehicle cabin through a conduit or along an existing wiring harness.

4. Route the cable through the main cabin area under the interior trim, towards the front of the vehicle. Use a blunt plastic putty knife or similar blunt tool to lift the plastic trim just enough to tuck the cable under underneath. Avoid side airbag locations on back pillars and above the doors. Airbag locations are marked with “SRS”

Vehicle Installation

logos. Be careful not to crimp or cut the cable.

5. Bring the cable out from the trim near the front of the cabin and route it under the carpet toward the dashboard or console. Coil any excess cable in a hidden location, such as under the carpet, keeping it away from any vehicle pedals or controls. Secure the excess cable with wire ties (purchased separately).

6. Bring the end of the cable out at the PowerConnect Vehicle Dock location. Leave yourself enough cable so you can easily connect it to the antenna connector of the dock.

7. Continue with “Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power Adapter” on page 35.

Sedan/Coupe With Antenna Placed at the Front of the Roof

1. Feed the antenna cable from the antenna underneath the rubber molding around the windshield. Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around the windshield and tuck the antenna cable underneath the molding. Route the antenna cable around and down the windshield to the lowest point.

2. At the lowest corner of the windshield, route the cable out of the windshield molding and into the rubber weather stripping around the door opening. Lift the weather stripping from the opening and tuck the cable inside it, then replace the weather stripping. Run the cable inside of the weather stripping to the bottom of the door

Vehicle Installation

opening.

3. Pull the cable out of the weather stripping at the bottom of the door opening and route it under the carpet toward the dashboard. Coil any excess cable in a hidden location, such as under the carpet, keeping it away from any vehicle pedals or controls. Secure the excess cable with wire ties.

4. Bring the end of the cable out at the PowerConnect Vehicle Dock location. Leave yourself enough cable so you can easily connect it to the antenna connector of the dock.

5. Continue with “Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power Adapter” on page 35.

Sport Utility Vehicle (SUV)

1. Feed the antenna cable underneath the rubber weather stripping of the rear tailgate window/door and route the cable along the rear hatch. Lift the weather stripping from the opening and tuck the cable inside it, then replace the weather stripping. Pull the cable out from weather stripping and route it into the cabin under the interior trim. Avoid hinges or gears that could crimp or cut the cable.

2. Route the cable through the SUV’s main cabin area under the interior trim, towards the front of the vehicle. Use a blunt plastic putty knife or similar blunt tool to lift the plastic trim just enough to tuck the cable

Vehicle Installation

under underneath. Avoid side airbag locations on back pillars and above the doors. Airbag locations are marked with “SRS” logos. Be careful not to crimp or cut the cable.

3. Bring the cable out from the trim near the front of the cabin and route it under the carpet toward the dashboard or console. Coil any excess cable in a hidden location, such as under the carpet, keeping it away from any vehicle pedals or controls. Secure the excess cable with wire ties (purchased separately).

4. Bring the end of the cable out at the PowerConnect Vehicle Dock location. Leave yourself enough cable so you can easily connect it to the antenna connector of the dock.

5. Continue with “Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power Adapter” on page 35.

Convertible

1. Bring the antenna cable from the antenna into the trunk at the front edge of the trunk lid. Keep any bends in the cable loose. Tape or tie the cable along the inside of the trunk lid to the trunk lid hinge strut.

2. Allow enough slack in the cable so the trunk lid can easily open and close and keep the cable away from hinges, gears, etc., that could crimp or cut it. Route the cable along the trunk wall and into the cabin through a conduit or along an existing wiring harness.

3. Route the cable through the main cabin area under the interior trim,

Vehicle Installation

towards the front of the vehicle. Use a blunt plastic putty knife or similar blunt tool to lift the plastic trim just enough to tuck the cable under underneath. Avoid side airbag locations on back pillars and above the doors. Airbag locations are marked with “SRS” logos. Be careful not to crimp or cut the cable.

4. Bring the cable out from the trim near the front of the cabin and route it under the carpet toward the dashboard or console. Coil any excess cable in a hidden location, such as under the carpet, keeping it away from any vehicle pedals or controls. Secure the excess cable with wire ties (purchased separately).

5. Bring the end of the cable out at the PowerConnect Vehicle Dock location. Leave yourself enough cable so you can easily connect it to the antenna connector of the dock.

6. Continue with “Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power Adapter” on page 35.

Pickup Truck

1. Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around the windshield and tuck the antenna cable underneath it.

2. Continue tucking the cable underneath the windshield molding around the windshield to the lowest corner.

3. At the lowest corner of the windshield, route the cable out of the windshield molding and into the rubber weather

Vehicle Installation

stripping around the door opening. Lift the weather stripping from the opening and tuck the cable inside it, then replace the weather stripping. Run the cable inside of the weather stripping to the bottom of the door opening.

4. Pull the cable out of the weather stripping at the bottom of the door opening and route it under the carpet toward the dashboard. Coil any excess cable in a hidden location, such as under the carpet, keeping it away from any vehicle pedals or controls. Secure the excess cable with wire ties.

5. Bring the end of the cable out at the PowerConnect Vehicle Dock location. Leave yourself enough cable so you can easily connect it to the antenna connector of the dock.

Continue with “Step 5: Connect the Magnetic Mount Antenna and

PowerConnect Power Adapter” on page 35.

Vehicle Installation

Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power Adapter

1. Plug the Magnetic Mount Antenna into the

silver ANT connector on the PowerConnect Vehicle Dock.

2. Insert the PowerConnect Power Adapter into your vehicle’s cigarette lighter or power adapter socket.

AUDIOANT PWR FM

3. Plug the PowerConnect Power Adapter into the red PWR connector on the dock.

AUDIOANT PWRFM

Vehicle Installation

Step 6: Connect the Audio

To play XM audio through your vehicle’s stereo or FM radio, decide on one of the following audio connection options:

•Option 1: Best: Use the provided Aux In Cable if your vehicle’s stereo system has an auxiliary input connection or jack. Refer to your vehicle’s owners manual to ﬁnd the location of the auxiliary input jack, or consult the vehicle dealer.

TIP! The auxiliary input jack may be located on the face plate of the vehicle radio, on the back of the radio, anywhere on the front dash panel, inside the glove compartment, or inside the center console in between the front seats.

•Option 2: Better: Use a Cassette Adapter if your vehicle has a built- in cassette player. Cassette Adapters are sold separately and can be purchased from an electronics retailer, or go to www.siriusxm.com/ accessories.

•Option 3: Good: Use the PowerConnect feature of Onyx Plus. PowerConnect plays the audio through your vehicle’s FM radio.

•Option 4: Best: Use the FM Direct Adapter. If none of the previous three audio connection options will work in your vehicle, then you will need to use the FM Direct Adapter (FMDA) (sold separately). The FMDA needs to be installed by a professional installer and directly connects Onyx Plus to your vehicle’s FM radio. To learn more, check with the retailer where you bought your Radio, or go to www.siriusxm.com/ accessories.

Follow the installation instructions in the next several sections for the audio connection option that you have selected.

Vehicle Installation

Option 1: Aux In Cable Installation Instructions

1. Plug one end of the Aux In Cable into the green AUDIO connector on the dock.

AUDIOANT PWRFM

2. Plug the other end into the auxiliary input jack of your vehicle’s stereo system.

3. If you are using the vent mounting method, attach the Vent Mount to the vehicle vent.

4. Insert your Onyx Plus into the dock.

5. Power on your Onyx Plus by pressing the

Power button.

6. Be sure the vehicle is outside and the antenna has a clear view of the sky. Verify that you are receiving the XM signal. There should be at least two bars on the lower left corner of the main display screen that denotes antenna signal strength. You can also press menu and then press down

to scroll to and

highlight Signal Indicator. Press the Select button. The Satellite and Terrestrial bars show the strength of the signal being received. If the signal reception is good, press and hold menu to return to the main display screen.

menu alerts

t-mix t-scn

twx

b / #

menu alerts

Vehicle Installation

7. Ensure Onyx Plus is tuned to channel 1, the XM Preview channel. Upon power up, Onyx Plus should tune to channel 1 by default, when it’s not yet activated. If it’s not on channel 1, refer to “Listening to Satellite Radio” on page 51 to learn about how to tune a channel.

8. Turn on your vehicle’s stereo system. Set it to play from the auxiliary input source. You should hear XM channel 1 through your vehicle’s stereo system. You are now ready to activate your Onyx Plus.

9. Go back to “Step 2: Install the Adhesive or Vent Mount” on page 14 and finish installing the Dash or Vent Mount. Then the installation is complete.

10.

The audio level output of Onyx Plus can be increased or decreased as

necessary to match the audio levels of other sources in your vehicle. Refer to “Audio Level” on page 100.

If the signal reception is good, showing at least two bars in the lower left corner of the display, but there is no XM audio, be sure the vehicle’s stereo system is set to the auxiliary input source (step 8). Also be sure that the audio level is set high enough to be heard (step 10). Refer to “Troubleshooting” on page 113 for additional help.

Vehicle Installation

Option 2: Cassette Adapter Installation Instructions

1. Plug the Cassette Adapter into the green AUDIO connector on the dock.

2. Insert the Cassette Adapter into the vehicle’s cassette deck. You may

need to turn on your vehicle’s stereo system in order to do so.

AUDIO ANT PWRFM

3. If you are using the vent mounting method, attach the Vent Mount to the vehicle vent.

4. Insert your Onyx Plus into the dock.

5. Power on your Onyx Plus by pressing the Power

button. Be sure the vehicle is outside and the antenna

has a clear view of the sky. Verify that you are receiving the XM signal. There should be at least two bars in the lower left corner of the main display screen that denotes antenna signal strength. You can also press menu and then press down

to scroll to

and highlight Signal Indicator. Press the Select button. The Satellite and Terrestrial bars show the

strength of the signal being received. If the signal reception is good, press and hold menu to return to the main display screen.

alerts

t-mix

t-scn

twx

b / #

menu alerts

Vehicle Installation

6. Ensure Onyx Plus is tuned to channel 1, the XM Preview channel. Upon power up, Onyx Plus should tune to channel 1 by default, when it’s not yet activated. If it’s not on channel 1, refer to “Listening to Satellite Radio” on page 51 to learn about how to tune a channel.

7. Turn on your vehicle’s stereo system. Set it to play from the auxiliary input source. You should hear XM channel 1 through your vehicle’s stereo system. You are now ready to activate your Onyx Plus.

8. Go back to “Step 2: Install the Adhesive or Vent Mount” on page 14 and finish installing the Dash or Vent Mount. Then the installation is complete.

10.

The audio level output of Onyx Plus can be increased or decreased as

necessary to match the audio levels of other sources in your vehicle. Refer to “Audio Level” on page 100.

If the signal reception is good, showing at least two bars in the lower left corner of the display, but there is no XM audio, be sure the vehicle’s stereo system is set to the cassette source (step 4). Also be sure that the audio level is set high enough to be heard (step 5). Refer to “Troubleshooting” on page 113 for additional help.

Vehicle Installation

Option 3: PowerConnect Installation Instructions

1. If you are using the vent mounting method, attach the Vent Mount to the vehicle vent.

2. Insert your Onyx Plus into the dock.

3. Power on your Onyx Plus by pressing the Power

button.

Be sure the vehicle is outside and the antenna has a clear view of the sky. Verify that you are receiving the XM signal. There should be at least two bars in the lower left corner of the main display screen that denotes antenna signal strength. You can also press menu and then press down scroll to and highlight Signal Indicator. Press the Select button. The Satellite and Terrestrial bars show the strength of the signal being received. If the signal reception is good, press and hold menu to return to the main display screen.

4. You’ll first need to find an available FM channel. An available FM channel is one that’s not being used by an FM radio station in your area. When you tune your FM radio to an available channel, you should only hear static or silence – not talk or music. We recommend one of the following methods to find an available FM channel:

a. Use the SiriusXM FM Channel

alerts

t-mix

t-scn

twx

b / #

menu alerts

Vehicle Installation

Finder at www.siriusxm.com/ fmchannel. Go to the website and

enter your zip code. The Channel Finder will suggest a list of available FM channels in your area. For convenience, write down or print out the list.

b. Manually tune through your local FM

channels on your vehicle’s FM radio. Locate and create a list of channels that aren’t being used by any FM radio station. Write down the list. Once you have created your list of available FM channels, you will need to ﬁnd the one that provides the best match for Onyx Plus.

TIP! You’ll need to use the ‘Manual’ tune function on your vehicle’s FM radio to tune through every FM channel one-by-one. Turn on your vehicle’s FM radio. Start at 88.1 and use the ‘Manual’ tune function on your vehicle’s FM radio to tune through each FM channel one-by-one (88.1 followed by 88.3 etc.) to locate channels that aren’t being used by a local FM radio station. Write down each FM channel that has only static or silence on it, until you reach 107.9.

7. Pick the first FM channel on your list from step 5. Turn on your vehicle’s FM radio (if you have not already done so) and tune it to this FM channel.

NOTE! If you are using the Vehicle Dock from the Universal Xpress Car Kit instead of the PowerConnect Vehicle Dock which came with your Onyx Plus, you will have to disable AUX Detect. Refer to “Using the Vehicle Dock From the Universal Xpress Car Kit” on page 110, and complete the additional

Vehicle Installation

instructions before continuing with the next step. The audio connection will be through your vehicle’s FM radio, but it is not PowerConnect.

8. Set your Onyx Plus to transmit on the same FM channel that you have selected in step 7:

99.3

34567890

i. Press menu. ii. Press down

highlight FM Settings and press the Select button.

iii. FM Channels will be highlighted. If it

is not highlighted, press scroll to and highlight FM Channels. Press the Select button.

iv. Press down to scroll to and

highlight the storage location FM 2 and press the Select button.

v. Tune to the available FM channel

you choose in step 3. Press left and right to tune in steps of .2, i.e., 99.3 to 99.5. Press down

to tune in steps of 1, i.e., 99.3

to 100.3. Press the Select button to select the FM channel.

alerts

t-mix t-scn

twx b / #

MATCH FM CHANNELS

to scroll to and

down

and

Vehicle Installation

vi. Start Using is highlighted. Press the Select button. vii. The FM channel you selected will be conﬁrmed on the display

screen. Onyx Plus will tune to the FM channel.

9. You should hear XM channel 1 through your vehicle’s FM radio. If you are satisfied with the sound quality, the installation is complete. You are now ready to activate your Onyx Plus.

10.

Go back to “Step 2: Install the Adhesive or Vent Mount” on page 14

and finish installing the Dash or Vent Mount. Then the installation is complete.

11.

If the selected FM channel doesn’t work well for you, work down the list

of FM channels until you find one with which you are satisfied. Each time, you will need to tune your vehicle’s FM radio to the FM channel and then set your Onyx Plus to transmit on the same FM channel (steps 7 & 8).

If the signal reception is good, showing at least two bars in the lower left corner of the display, but there is no XM audio, verify that both Onyx Plus and your vehicle’s FM radio are tuned to the same FM channel (steps 7 &

8). Also ensure the chosen FM channel is a suitable one to use in your area (step 5). Verify that nothing is plugged into the AUDIO connector on the PowerConnect Vehicle Dock. Refer to “Troubleshooting” on page 113 for additional help.

Option 4: FM Direct Adapter (FMDA) Installation

The FMDA needs to be installed by a professional installer. Professional installation can help improve your Radio’s reception and signiﬁcantly reduce the visibility of wires. To learn more, check with the retailer where you bought your Radio, or go to www.siriusxm.com/accessories.

You can follow either the general activation and subscription process or use the on-board activation guide to activate your Onyx Plus and subscribe to the XM service.

General activation and subscription process:

Subscribe to the XM service by following these steps:

1. Make sure your Onyx Plus is turned on, tuned to XM Preview channel 1, and receiving the XM signal so that you can hear the XM audio.

2. Make a note of the XM Radio ID. You can find it:

•by selecting Radio ID in menu items

•on channel 0 (zero)

•on a label on the bottom of the gift box

•on the label on the back of your Onyx Plus

NOTE! The XM Radio ID does not use the letters I, O, S, or F.

3. To subscribe:

•Online: Go to www.siriusxm.com/activatenow to access or set up an

online account, subscribe to the service, and activate your Radio.

•By phone: Call 1-866-635-2349.

Activation usually takes 10 to 15 minutes after you have completed the subscription process, but may take up to an hour. We recommend that your Radio remain on until subscribed. Once subscribed, the Radio will receive

*The phone number shown above may differ from the one shown on your Onyx Plus. All numbers are valid.

and you can tune to channels in your subscription plan. Press up or down to tune to other channels, and left or right to

browse the different categories of channels. Learn what all the buttons do by turning to “Navigation Basics” on page 48.

Activation guide:

For your convenience, Onyx Plus has an on-board activation guide. You can activate your radio and subscribe to the XM service by using this guide, where you will be guided step-by-step through the subscription process. To access and use the guide, simply follow these steps:

1. Turn Onyx Plus on and press the menu button.

2. Activate Radio will be highlighted. Press the Select button.

3. Follow the directions on each successive screen until you complete the subscription process.

Channel Name/Logo

Album Art

Using Your Onyx Plus

The Main Display

When listening to a channel, information about the channel and what is currently playing is displayed. In addition, other information may also be displayed.

Channel Number

Favorite Channel Indicator

Artist Name

or Talk Show Host

or Sports Teams/Score

Song/Program Title

or Talk Show Schedule

or Game Time/Game Details

Antenna Signal

Strength

Tom Petty

You Wreck Me

....NYM 1/NYY 1, t3rd, Ch 180....BOS

NYC Pending

Informational

Messages

Informational

Icons

Pause and Replay Timebar Sports Ticker

Using Your Onyx Plus

Navigation Basics

Power/FM Button

Pressing Power/FM turns Onyx Plus On or Off. Pressing and holding Power/ FM provides easy tuning of FM presets for optimized PowerConnect

performance. It is not available when an Aux In Cable or Cassette Adapter is used for the audio connection.

Navigation Buttons

Pressing Left, Right, Up, and Down navigates through various features and functions of Onyx Plus.

•Left

•Up or Down button (press and release): Immediately tunes to the

•Up or Down button (press and hold): Continuously scrolls

Select Button

Pressing Select selects a highlighted item in a list and conﬁrms settings. When in TuneMix or TuneScan mode, press Select to end TuneMix/Scan and continue to listen to the currently tuned channel, or press and hold Select to end TuneMix/Scan and return to the channel to which you were tuned before TuneMix/Scan began playing.

or Right button: Displays the channel categories such as

Rock, Pop, Sports, Talk/News, etc. Repeated presses cycle through the categories one at a time. Also, decreases or increases the settings of various menu options such as Brightness, Audio Level, etc.

next or previous channel in the channel lineup. Also, scrolls through lists and highlights an item in the list.

through any list. While on the main display screen, continuously scrolls through the channel lineup and brieﬂy displays the information of each channel. When the button is released, Radio tunes to the last channel it had scrolled to in the channel lineup.

menu alerts

t-mix t-scn

twx

Using Your Onyx Plus Plus

Menu/Alerts Button

Pressing Menu/alerts displays various options to make setup and feature changes. Pressing menu/alerts when in menu options returns to the previous menu option screen until menu options is exited. Pressing and holding menu/ alerts when in menu options returns to the main display screen in most instances. Pressing and holding menu/alerts when at the main display screen prompts to save a song, artist, or game alert if you are tuned to a music channel or sports game where an alert can be saved.

TuneMix/TuneScan Button

Pressing t-mix/t-scn puts the radio in TuneMix mode where the radio plays songs in a shufﬂe like format from the channels which you have saved as smart favorites. Pressing and holding t-mix/t-scn puts the radio in TuneScan mode where the radio plays the ﬁrst 10 seconds of each song that has not been listened to from each of the channels which you have saved as smart favorites.

Jump/twx Button

Pressing jump/twx tunes to the previous channel that was playing previous to the currently tuned channel. Pressing it again returns it to the original channel. Pressing and holding jump/twx tunes to the channel broadcasting trafﬁc and weather conditions of a city of your choice, selected from a list of the 22 most congested cities.

Banks/Direct Button

Pressing b / # changes the current favorite bank from bank A to bank B, or B to A. Pressing and holding b / # prompts for the entry of a channel number using the number buttons. Once the channel number is entered, the Radio directly tunes to the new channel.

b / #

Using Your Onyx Plus

...

Pause and Replay Buttons

Replays up to approximately 60 minutes of stored content from the currently tuned channel, and approximately 30 minutes of stored content from your smart favorite channels as well as from the channel that was tuned immediately previous to the current channel. (Refer to “Favorite Channels” on page 53 for more information about smart favorites.)

plays/pauses, rewinds, and fast-forwards through temporarily stored

content.

Note: 60 and 30 minutes are approximate times which may vary depending upon the type of channels and the number of channels saved as smart favorite channels.

Number Buttons

Each number button stores a favorite channel in its button location and provides one touch access to it afterward. Number buttons are also used to enter a channel number after pressing and holding banks/direct to directly tune a channel.

Number buttons 1 through 9 are smart favorites while number button 0 is a regular favorite. Smart favorites remember up to approximately 30 minutes of content that played on the smart favorite channel so that when you tune the favorite channel you can rewind up to 30 minutes, or for as long as Onyx Plus has been powered on. Smart favorites are also used for the TuneStart, TuneMix, and TuneScan features.

1 0

Using Your Onyx Plus

Listening to Satellite Radio

Tune to a channel:

1. Press and release up and down to immediately tune to the next or previous channel.

2. Press and hold up and down to quickly scroll through the channels. Release to tune to the channel that is displayed.

Onyx Plus can be set to tune channels in numerical order, or to tune channels in category order, i.e., pop channels, then rock channels, etc., when channels are tuned using up page 93 to for more information.

View a category:

Channels are organized into categories to make it easier for you to ﬁnd the ones that suit your taste.

1. To view channels in a category in list mode press left

2. Scroll through the category using up

and down , and find the channel

you want to tune.

3. Press the Select button to select the channel, or press left view channels in the previous or next category.

TIP! To brieﬂy listen to each channel in the category, scroll to and highlight Scan at the end of the category list and press the Select button. Refer to “Scanning Channels in a Category” on page 55 to learn more about Scan.

or right .

and down . Refer to “Channel Tuning” on

or right to

Using Your Onyx Plus

Direct Tune

A channel can be tuned directly by entering the channel number using the number buttons.

1. To directly tune to a channel press b/#.

2. Use the number buttons 0-9 to enter

the channel number and wait a moment until the channel is tuned, or press the Select button to immediately tune to the channel.

Return to Main Display Screen

Pressing and holding menu/alerts in most instances will return you to the main display screen. In some cases, you may need to follow the instructions on the display screen.

Jump and Trafﬁc/Weather

Pressing jump/twx ( ) will immediately tune to the previous channel to which you had been listening.

Pressing and holding jump/twx will tune to the trafﬁc/weather for your city. If you had not previously set the city for your location, you will be prompted to set your city.

If the trafﬁc/weather broadcast of your selected city is not immediately available, a message will be displayed at the bottom of the screen to indicate that a trafﬁc/weather report is pending. Once the trafﬁc/weather report is ready to be broadcast, the Radio will automatically tune to the trafﬁc/weather channel. Since a channel may broadcast the trafﬁc and

Using Your Onyx Plus

weather reports of more than one city, you may have to wait a few minutes for the broadcast of your selected city.

Pressing and holding jump/twx while a trafﬁc/weather report is pending will cancel the trafﬁc/weather report. Pressing jump/twx after the Radio has tuned to the trafﬁc/weather channel will return back to the channel to which you had been listening immediately prior to the trafﬁc/ weather channel.

Favorite Channels

You can set up to 20 of your favorite channels (10 in bank A and 10 in bank B) so you can easily access them. Each favorite channel can be assigned to a number button. An icon on the main display screen shows the currently selected bank

Number buttons 1 through 9 are smart favorites while number button 0 is a regular favorite. Smart favorites remember up to 30 minutes of content that played on the smart favorite channels so that when you tune a smart favorite channel you can rewind up to 30 minutes. Smart favorites are also used for the TuneStart, TuneMix, and TuneScan features. When you save or replace a smart favorite the conﬁrmation screen will indicate that you are saving or replacing a smart favorite.

Smart favorite channels are indicated on the main display screen by a star

to the left of the favorite number.

icon

To assign a favorite channel to a number button:

1. Tune to the desired channel.

or b. Change banks by pressing b/#.

Using Your Onyx Plus

Select the bank in which you want to save the favorite channel by pressing b/#.

Press and hold a number button between 0-9 that you want to assign to that favorite channel. An advisory with the channel number and name will be displayed on the screen confirming that the channel has been assigned.

To listen to a favorite channel:

Select the bank by pressing b/#.

2. Press the number button between 0-9 that was assigned to the desired favorite channel. Onyx Plus will tune to that channel.

TIP! When you are at the main display screen, press left to see your list of favorite channels. Scroll to highlight a favorite and press the Select button to listen to that channel.

To replace a favorite channel:

Select the bank by pressing b/#.

2. Press and hold the number button between 0-9 that you wish to replace with the currently tuned channel until the advisory message is show.

3. Press Select button to replace the favorite, or menu to cancel.

Using Your Onyx Plus

Scanning Channels in a Category

You can scan a category and listen to each channel for 10 seconds before Onyx Plus automatically tunes to the next channel. If you want to stay tuned to the channel being played and stop the scan, just press the Select button.

To scan a category:

1. Press left

2. Scroll down using down

which will be Scan and the category name.

3. Press the Select button. The scan will begin.

4. Press the Select button to stop the scan, and to continue to listen to

the channel currently being played, or press up and down to return to the channel you were listening to before you began the scan.

or right until the desired category is displayed.

to highlight the last item in the category

Special Features

FM Presets

FM presets make it easy to quickly access stored FM channels and choose a new FM channel from them.

Use FM presets when you use PowerConnect or the FMDA to listen to your Onyx Plus through your vehicle’s FM radio. (Refer to “Option 3: PowerConnect Installation Instructions” on page 41 for more information.)

To use a different FM preset:

1. Press and hold Power/FM to display the FM Channels list showing the current FM preset.

2. Press up the FM preset, or use the number keys to select the corresponding FM preset, for example, pressing 3 will select FM3. Press Select. The Radio will tune to the selected FM channel. If the preset is the one you want, press menu or wait for the confirmation screen to time out.

3. Set your vehicle’s FM radio to the same FM channel.

IMPORTANT! You need to ensure that your vehicle’s FM radio is tuned to the same FM channel.

TIP! To conﬁgure the list of preset FM channels, you need to ﬁnd available FM channels in your area. Refer to”Find Available FM Channels in Your Area” on page 94. Next, refer to “Set and Select an FM Channel” on page 96.

and down to highlight

Special Features

Album Art

Onyx Plus can display album art for the currently playing song on music channels. Album art is on by default, but you can choose not to have album art displayed.

Album Art is displayed when available. This means that for some songs album art may not be available, some channels may display album art more consistently than others, while other channels may not display album art. Also, if you tune a channel while a song is being played, there may be a delay in displaying the album art, or it may not be displayed at all.

To turn album art on or off:

1. Press menu.

2. Press down

highlight Feature Settings. Press the Select button.

3. Press down highlight Album Art.

4. Press the Select button to toggle album art on or off.

5. Press and hold menu to return to the main display screen.

to scroll to and

Special Features

Parental Controls

Onyx Plus has a parental control feature which allows you to lock access to individual channels, or lock access to an entire category. A 4-digit code controls access to the locked channel or locked category.

Locked channels are skipped (not shown) if you tune channels using up and down the locked channel will be shown but not the artist and song/program information. Instead, a lock icon

If you attempt to tune to a locked channel, either by using direct tune or through the category list, you’ll be prompted to enter your 4-digit code. When the correct code is entered, you’ll be able to tune to and listen to the channel. All locked channels become unlocked and remain unlocked until you turn Onyx Plus Off, and back On. In the category list, the previously locked channels will show an unlocked icon

To turn Parental Controls On (or Off):

1. Press menu.

2. Press down

Select button.

•If this is the ﬁrst time you want to turn on Parental Controls, Parental

. When you browse a category, the channel logo and number of

and the word “Locked” is shown.

to scroll to and highlight Parental Controls. Press the

Controls will be highlighted. Press the Select button. You will be

prompted to select a 4-digit code:

i. For each digit, press one of the 0-9 keys (or press down

or up

Special Features

to select digits) and then press right next digit. (Press left need to go back and edit a previous digit.)

ii. When you have selected all 4

digits of your code press the

Select button.

iii. The Code Conﬁrmation screen

will be displayed. For your records, write down the code you have selected. Press the Select button. Continue with step 3.

•If you had previously selected a 4-digit code you will be prompted to enter your code:

i. For each digit, press one of the

0-9 keys (or press down up

press right need to go back and edit a previous digit.)

ii. When you have selected all 4 digits of the code press the Select

button.

3. At the “Parental Controls” screen, Parental Controls will be highlighted. Press the Select button to turn parental controls on (or press the Select button to turn parental controls off).

4. Press and hold menu to return to the main display screen.

to advance to the

if you

to select digits) and then

to advance to the next digit. (Press left if you

Special Features

To lock (or unlock) channels or categories:

1. Press menu.

2. Press down

Select button.

3. You will be prompted to enter the 4-digit code. For each digit, press one of the 0-9 keys (or press down then press right need to go back and edit a previous digit.)

4. When you have entered all 4 digits of the code press the Select button.

5. If Parental Controls is shown as off, press the Select button to turn it

on, otherwise continue with the next step.

6. At the “Parental Controls” screen, Press down highlight Locked Channels. Press the Select button.

7. A list of all the categories and the channels in each category will be displayed. Press down or category you want to lock. Press the Select button. A lock icon will be displayed to the left of the channel or category you locked. (To unlock a locked channel or category, simply highlight the locked

to scroll to and highlight Parental Controls. Press the

or up to select digits) and

to advance to the next digit. (Press left if you

to scroll to and

or up to scroll to and highlight a channel

Locked Channels Locked Category

Special Features

channel or category and press the Select button. The lock icon will disappear indicating the channel or category is unlocked.)

8. You can continue to lock and unlock as many channels or categories as you wish. When you are finished, press and hold menu to return to the main display screen.

To change your code:

1. Press menu.

2. Press down

Select button.

3. You will be prompted to enter your existing 4-digit code. For each digit, press one of the 0-9 keys (or press down digits) and then press right if you need to go back and edit a previous digit.)

4. When you have entered all 4 digits of the code press the Select button.

5. If Parental Controls are shown as off, press the Select button to turn it

on, otherwise continue with the next step.

6. At the “Parental Controls” screen, Press down highlight Change My Code. Press the Select button.

7. You will be prompted to enter a new 4-digit code. For each digit, press one of the 0-9 (or press down to select digits) keys and then press right (Press left and edit a previous digit.)

to scroll to and highlight Parental Controls. Press the

or up to select

to advance to the next digit. (Press left

to scroll to and

or up

to advance to the next digit.

if you need to go back

Special Features

8. The Code Confirmation screen will be displayed. For your records, write down the code you have selected. Press the Select button.

9. Press and hold menu to return to the main display screen.

To listen to a locked channel:

There are two ways to tune to a channel which has been locked. The ﬁrst is to directly tune to the locked channel, and the second is to select the locked channel from a category list.

1. Directly tune to or select the locked channel:

To directly tune to a locked channel:

i. Press direct and enter the channel number using the 0-9 keys.

To select a locked channel from the category list:

i. Press left

channel to which you wish to tune.

ii. Press down to scroll to and highlight the locked channel. Press

the Select button.

2 You will be prompted to enter your existing 4-digit code. For each

digit, press one of the 0-9 keys (or press down digits) and then press if you need to go back and edit a previous digit.)

3 When you have entered all 4 digits of the code, press the Select

button. If your code is correct the channel will be tuned. All locked

channels become unlocked and remain unlocked until you turn Onyx Plus Off, and back On. In the category list, the previously locked channels will show an unlocked icon

or right to view the category list of the locked

or up to select

left to advance to the next digit. (Press right

Special Features

TuneMix

TuneMix plays songs in a unique mix from the music channels you have saved as smart favorites, allowing you to build a blended channel from as few as three to as many as 18 music channels.

TuneMix can be conﬁgured to play all the music channels saved as smart favorites from favorite channel banks A and B (all channels, default), or conﬁgured to play only the music channels from the currently selected favorite channel bank (bank). If TuneMix is conﬁgured as bank, you can create two different listening experiences such as rock music in bank A and pop music in bank B.

NOTE! When TuneMix is in all channels mode, in addition to the smart favorite channels, it will also include the current channel to which you are tuned, and the immediate previous channel to which you had been tuned, if they were music channels.

Tips for Obtaining the Best Experience from TuneMix

Before using the TuneMix feature, familiarize yourself with the following tips to help you obtain the best experience from TuneMix:

•TuneMix plays songs which have aired on your smart favorite music channels. This means that when Onyx Plus is powered on, it needs a few minutes to accumulate songs to play. If TuneMix has too few songs, it may abort prematurely. For best results, when you ﬁrst power Onyx Plus on, wait a few minutes before invoking TuneMix.

•The more music channels you save as smart favorites, the more songs TuneMix will have to play. For best results, save a minimum of three music channels in a bank as smart favorites.

•SiriusXM’s programming rights regulate the songs which play in TuneMix. Songs which have played for 30 seconds or longer in TuneMix,

Special Features

or songs which have been skipped three times by pressing may not be played again during the current listening session.

•Certain music channels are not eligible for TuneMix due to the way in which they are broadcast. While these music channels can be saved as smart favorites, they will not be included in TuneMix.

•Entering menu options will end TuneMix. Avoid entering the menu options during TuneMix.

To begin TuneMix:

To use TuneMix, ﬁrst have to save a minimum of three music channels to smart favorite channel buttons 1 through

9. (TuneMix does not use favorite channel button 0.) Refer to “Favorite Channels” on page 53 to learn how to save favorite channels.

Press t-mix/t-scn to begin. Onyx Plus will display the TuneMix icon that the radio is in TuneMix mode, and TuneMix will begin playing. Songs that you don’t want to listen to can be skipped by pressing

To end TuneMix:

There are two ways to end TuneMix:

•If you want to end TuneMix and continue listening to the channel that TuneMix is currently playing, press the Select button.

•If you want to return to the channel to which you were listening prior to

to show

Special Features

TuneMix, press and hold the Select button.

TuneMix will terminate if you tune another channel, if you press jump , if you press and hold t-mix/t-scn to enter TuneScan mode, or if you press banks/direct (b/#) when TuneMix is in bank mode.

To conﬁgure TuneMix for Bank or All Channels:

1. Press menu/alerts.

2. Press down

highlight Feature Settings. Press the Select button.

3. Press down highlight Tune Mix/Scan.

4. Press the Select button to toggle between bank and all channels. Note that you are configuring both TuneMix and TuneScan.

5. Press and hold menu/alerts to return to the main display screen.

to scroll to and

Special Features

TuneScan

TuneScan plays the ﬁrst 10 seconds of songs in a unique mix from the music channels you have saved as smart favorites, allowing you to build a virtual channel from as few as three to as many as 18 music channels. While listening to TuneScan, if you hear a song you like simply press the Select button to continue listening to the song.

TuneScan can be conﬁgured to play from all the music channels saved as smart favorites from favorite channel banks A and B (all channels) (default), or conﬁgured to play only the music channels from the favorite channel bank currently selected (bank). If TuneScan is conﬁgured as bank, you can create two different listening experiences such as rock music in bank A and pop music in bank B.

NOTE! When TuneScan is in all channels mode, in addition to the smart favorite channels, it will also include the current channel to which you are tuned, and the immediate previous channel to which you had been tuned, if they were music channels.

Tips for Obtaining the Best Experience from TuneScan

Before using the TuneScan feature, familiarize yourself with the following tips to help you obtain the best experience from TuneScan:

•TuneScan plays songs which have aired on your smart favorite music channels. This means that when Onyx Plus is powered on, it needs a few minutes to accumulate songs to play. If TuneScan has too few songs, it may abort prematurely. For best results, when you ﬁrst power Onyx Plus on, wait a few minutes before invoking TuneScan.

•The more music channels you save as smart favorites, the more songs TuneScan will have to play. For best results, save a minimum of three music channels in a bank as smart favorites.

Special Features

•SiriusXM’s programming rights regulate the songs which play in TuneScan. Songs which have been skipped three times may not be played again during the current listening session.

•Certain music channels are not eligible for TuneScan due to the way in which they are broadcast. While these music channels can be saved as smart favorites, they will not be included in TuneScan.

•Entering menu options will end TuneScan. Avoid entering the menu options during TuneScan.

To begin TuneScan:

To use TuneScan you ﬁrst have to save a minimum of three music channels to smart favorite channel buttons 1 through 9. (TuneScan does not use favorite channel button 0.) Refer to “Favorite Channels” on page 53 to learn how to save favorite channels.

Press and hold t-mix/t-scn to begin. Onyx Plus will display the TuneScan icon show that the radio is in TuneScan mode, and TuneScan will begin playing. Songs that you don’t want to listen to can be skipped by pressing

, or you can return

to the previous song by pressing

To end TuneScan:

There are two ways to end TuneScan:

•If you want to end TuneScan and continue listening to the song that TuneScan is currently playing, press the Select button.

•If you want to return to the channel to which you were listening prior to

TUNE SCAN

Special Features

TuneScan, press and hold the Select button.

TuneScan will terminate if you tune to another channel, if you press menu/

alerts, jump mode, or if you press banks/direct (b/#) when TuneScan is in bank mode.

To conﬁgure TuneScan for Bank or All Channels:

1. Press menu/alerts.

2. Press down to scroll to and

highlight Feature Settings. Press the Select button.

3. Press down highlight Tune Mix/Scan.

4. Press the Select button to toggle between bank and all channels. Note that you are configuring both TuneScan and TuneMix.

5. Press and hold menu/alerts to return to the main display screen.

, or play/pause , if you press t-mix/t-scn to enter TuneMix

to scroll to and

Special Features

TuneStart

TuneStart plays the current song from the beginning when you tune to a music channel which you have saved as a smart favorite channel. (Refer to “Favorite Channels” on page 53 for more information on smart favorite channels.) A TuneStart will also occur if you tune back to the channel that was tuned immediately prior to the currently tuned channel, either by pressing jump TuneStart is on by default.

When a TuneStart occurs, the main display screen will display the Pause and Replay timebar to indicate that a TuneStart has occurred. Should you wish to return to the live broadcast, press and hold Play/Pause.

In order for a TuneStart to occur, the beginning of the song must be present in the TuneStart memory. If Onyx Plus is powered on after a song has already begun to be broadcast, a TuneStart will not be possible for that song.

A TuneStart will only occur once per song. For example, if you tune to smart favorite music channel A1 and a TuneStart occurs, then tune channel B1, and then tune back to channel A1 while the same song is still playing on channel A1, a TuneStart will not occur. However, if you want to hear the song from the beginning, you can always press and release Rewind return to the beginning of the song.

, or by directly tuning the channel.

Note: Certain music channels are not eligible for TuneStart due to the way in which they are broadcast. While these music channels can be saved as smart favorites, TuneStart will not occur for these channels.

Special Features

To turn TuneStart off or on:

1. Press menu/alerts.

2. Press down

highlight Feature Settings. Press the Select button.

3. Tune Start will be highlighted. Press the Select button to toggle between off and on.

4. Press and hold menu/alerts to return to the main display screen.

to scroll to and

Special Features

Pause & Replay

Pause & Replay gives you the opportunity to “hear that again” by temporarily storing and then letting you access the stored content. For the currently tuned channel, you can pause and replay for as long as you have been tuned to the channel, up to a maximum of approximately 60 minutes.

You can also Pause and Replay up to approximately 30 minutes from channels which you have saved as smart favorite channels, and also from the channel that was tuned immediately prior to the currently tuned channel. (Refer to “Favorite Channels” on page 53 for more information on smart favorite channels.) Pressing Pause & Replay mode.

To Play/Pause:

1. Press and release to pause the live broadcast. At this point the

2. Pressing and releasing again will begin

or places the Radio into

TIP! Turning Onyx Plus off removes the temporarily stored content from the Radio.

Radio will mute and continue to store live audio.

playing stored audio from the point at which the Radio was paused.

TIP! Pressing left (or pressing left twice, if favorite channels are stored) will show the Replay List. A listing of artist names and song or show titles are shown for the stored audio from most recent to oldest, beginning with entry called “Go to Live”. Press down

and up to scroll to and

Special Features

highlight a song or program and press the Select button to play it. Choosing Go to Live exits Pause & Replay mode and resumes playing the live broadcast.

To listen to the previous track:

1. Press and release program.

2. Repeated press and releases skips backwards to the start of the previous songs or programs until the beginning of the stored audio is reached. When the beginning is reached, playback automatically begins.

TIP! Pressing and holding rewinds through stored audio in 5 second intervals, which increases to 15 and then 30 second intervals the longer the button is pressed. Playback begins when the button is released. If the beginning of the stored audio is reached, playback automatically begins.

To listen to the next track:

1. Press and release to skip forward to the start of the next song or program.

2. Repeated press and releases skips forward to the beginning of the next songs or programs until the end of stored audio is reached. When the end is reached, the Radio will exit Pause & Replay mode and resume playing the live broadcast.

TIP! Pressing and holding advances through the stored audio in 5 second intervals, which increases to 15 and then 30 second intervals the longer the button is pressed. Playback begins when button is released. If end of stored audio is reached, the Radio exits Pause & Replay mode and resumes playing the live broadcast.

To listen to live broadcast:

1. Pressing and holding exits Pause & Replay mode and resumes playing the live broadcast.

to rewind to the beginning of the current song or

while the Radio is in Pause & Replay mode

Special Features

Song/Artist Alerts

You can set your Onyx Plus to alert you when the following events occur:

•Song Alert: Alerts can be set for your favorite songs, so that whenever the song begins to play on any music channel, you will be alerted and given the opportunity to tune to the channel.

•Artist Alert: Alerts can be set for your favorite artists, so that whenever a song by that artist begins to play on any music channel, you will be alerted and given the opportunity to tune to the channel.

Song and artist alerts can be saved while you are tuned to a channel where the song or artist is currently playing. Alerts can be set while listening to the live broadcast, while in Pause and Replay mode, and while in TuneMix or TuneScan mode. You can save up to 100 Song and Artist Alerts. If the alert list is full you will be prompted to replace an existing alert.

Alerts are displayed visually and are accompanied by an optional audible alert beep, except when you are not at the main display screen. If you are not at the main display screen, you will hear the audible alert beep (provided it’s turned on), but the visual alert will be delayed until you have returned to the main display screen.

While a single alert is displayed, you can press the Select button to tune to the channel, or press menu/alerts to dismiss the alert, or wait for the alert to time out.

There may be occasions when several Song/Artist Alerts happen simultaneously, and then a list of alerts will be displayed. These multiple

Special Features

alerts can be a mixture of Song, Artist, Game, and Score alerts, depending upon what alerts you have saved. You can browse through the multiple alerts by pressing down highlight an alert, and press the Select button to tune to the channel. Once you have selected an alert from the list, all other alerts in the list are dismissed.

To save a Song or Artist Alert:

1. While the song is playing press and hold menu/alerts.

TIP! You can save an alert for a song or artist that you had listened to previously on the channel. Press the song.

2. You will be prompted to select whether to save a Song Alert or an Artist Alert. Highlight your choice by pressing down the Select button, or press menu/ alerts to cancel.

3. A message will confirm that you have successfully saved the alert.

TIP! If you saved an Artist Alert for a song, you will not be able to save a song

alert, and the message Artist Alert Already Saved... will be displayed. This happens because you will be alerted whenever any song by that artist begins to play, so it is not necessary to save individual songs by the artist.

or up to scroll to and

to rewind to

or up and press

Special Features

To edit Song and Artist Alerts:

Individual Song and Artist alerts can be edited in the following ways:

•Turn alerts on or off (on/off): An individual Song or Artist alert can be turned off so you no longer receive an alert, but it is still kept in the alert list so you can turn it back on.

•Delete alert (del): Song or Artist alerts can be permanently deleted.

•Switch alert (sw): Onyx Plus remembers both the Song and the Artist

for each saved alert, although you will only receive an alert for one or the other depending upon which you have selected. Switch provides the ability to turn a Song Alert into an Artist Alert, and an Artist Alert into a Song Alert.

1. Press menu/alerts.

2. Press down

3. Press down

the Select button

4. From the list of alerts, highlight the alert you want to edit by pressing

down yellow and artists are shown in blue.

5. Press and release the Select button to

move through the options and select a setting:

sw: Switch, to switch the alert from

to scroll to and highlight Alerts. Press the Select button. to scroll to and highlight Edit Song/Artist Alerts. Press

or up . Songs are shown in

an Artist Alert to a Song Alert and vice versa. Wait 2 seconds for the confirmation screen to

Special Features

appear and press the Select button to confirm the switch or press menu/alerts to cancel.

del: Delete the alert. Wait 2 seconds for the confirmation screen to

appear and press the Select button to confirm the deletion or press menu/alerts to cancel.

off: Turn the alert off, but keep it in the list.

on: Turn an alert which had previously been turned off back on.

6. Press and hold menu/alerts to return to the main display screen.

To turn all Song and Artist Alerts on or off:

You can turn all Song or Artist Alerts on or off without deleting the saved alerts. If you turn them off, you will no longer receive Song or Artist alerts.

1. Press menu/alerts.

2. Press

3. Song/Artist Alerts will be highlighted.

4. Press and hold menu/alerts to return

down to scroll to and highlight

Alerts. Press the Select button.

Press the Select button to toggle the alerts on or off.

to the main display screen.

Special Features

To turn the audible alert beep on or off:

If you do not wish to hear an audible alert beep when a Song or Artist Alert occurs, you can turn it off. You will still continue to receive the visual alert.

1. Press menu/alerts.

2. Press down to scroll to and

highlight Alerts. Press the Select button.

3. Press down

highlight Audible Alert Beep. Press the Select button to toggle the alerts on or off.

4. Press and hold menu/alerts to return

to the main display screen.

to scroll to and

Special Features

Game/Score Alerts

If your subscription package includes the play-by-play sports channels for your desired sports leagues, and SiriusXM broadcasts the games, you can set your Onyx Plus to alert you when the following events occur:

•Game Alert: Alerts can be set for your favorite sports teams so that whenever SiriusXM begins broadcasting a game in which your favorite sports team is playing, you will be alerted and given the opportunity to tune to the game.

•Score Alert: When you set a Game Alert for your favorite sports teams, a Score Alert is automatically set also. If you are not listening to the game, you will be alerted each time there is a new score in the game, and given the opportunity to tune to the game. Score Alerts can be turned off if you do not wish to receive them.

IMPORTANT! A subscription package which includes the play-by-play sports channels of the desired leagues is required. For example, if you selected an alert for an NFL team, and your subscription package did not include NFL play-by-play sports channels, you cannot receive Game or Score Alerts.

We recommend you do not select alerts for teams in a league which are not included in your subscription package. Check your subscription package to conﬁrm that it includes the play-by-play sports channels for the desired leagues before selecting any teams for alerts in the leagues.

Special Features

Game/Score Alerts can be saved while you are tuned to a channel where a game is being broadcast, or you can preselect teams through the menu options. There is no limit on the number of sports teams which can be saved for Game/Score Alerts.

When a single alert is displayed, you can press the Select button to tune to the channel, or press menu/alerts to dismiss the alert, or wait for the alert to time out.

There may be occasions when several Game/Score Alerts happen simultaneously, and then a list of alerts will be displayed. These multiple alerts can be a mixture of Game, Score, Song, and Artist alerts, depending upon what alerts you have saved. You can browse through the multiple alerts by pressing down

to scroll to and highlight an alert, and press the Select button to tune to the channel. Once you have selected an alert from the list, all other alerts in the list are dismissed.

Tips for Obtaining the Best Experience With Game/Score Alerts

Before selecting teams for Game/Score Alerts, familiarize yourself with the following tips to help you obtain the best experience with Game/Score Alerts:

or up

Special Features

•Game and Score Alerts normally do not occur if you are tuned to the channel which is broadcasting the game in which the selected team is playing. However, it’s possible that the same game may be broadcast on multiple SiriusXM channels simultaneously. If so, you will receive Game Alerts for the other channels where the game is being broadcast. You can temporarily turn off Game Alerts if desired (page 84).

•For a given sport, during the season it is likely that SiriusXM will be broadcasting several games simultaneously. This will result in Game Alerts when each game begins, and Score Alerts throughout the games. For sports where scores are frequent, you may ﬁnd constant Score Alerts to be disruptive. You can temporarily turn off Score Alerts if you ﬁnd them to be disruptive (page 84).

•Avoid selecting all teams in a league for alerts. Select only those teams you are most interested in following.

•Use the Sports Ticker instead of Score Alerts to keep up with scores.

To save a team for Game/Score Alert while listening to a game:

1. While tuned to the channel where the

game is being broadcast press and hold menu/alerts.

2. You will be prompted to select the

team for the Game/Score Alert. Highlight your choice by pressing

down button, or press menu/alerts to cancel.

3. The next screen will highlight the team

you have selected, with the Alert box highlighted in blue with white letters.

or up and press the Select

Special Features

Press the Select button to select the team for Game/Score Alerts. The text will change from white letters to black letters to indicate the teams has been selected for Game/Score Alerts.

4. If you also want to add the team to the Sports Ticker, press down the Select button.

5. Press and hold menu/alerts to return to the main display screen.

TIP! Read steps 6 and 7 on page 81 to learn more about the Alert and Ticker boxes, and how they show the selected teams.

To preselect (or deselect) teams for Game/Score Alerts:

1. Press menu/alerts.

2. Press down

3. Press down

Select button.

4. Press down to scroll to and highlight Choose Teams. Press the Select button.

5. Press down the league. Press the Select button.

6. Each team has two selections to the left of the team name, an Alert

to scroll to and highlight Alerts. Press the Select button.

to scroll to and highlight Sports Alerts/Ticker. Press the

to scroll to and highlight

and press

Special Features

and a Ticker box. (Refer to “Sports Ticker” on page 85 for more information about the Sports Ticker.) Pressing and releasing down or up the Alert or Ticker box in blue, Pressing and holding down

navigates through each Alert and Ticker box, highlighting

or up

navigates through the teams.

Alert

The Alert and Ticker boxes for teams which are not yet selected

Ticker

are shown with a black background with white letters.

Alert

The Alert or Ticker box for teams which are highlighted

Ticker

for selection, but not yet selected, are shown with a blue background and white letters.

Alert

The Alert and Ticker boxes for teams which have been selected

Ticker

are shown with a white background with black letters.

The Alert or Ticker box for teams which are highlighted for

Alert

Ticker

selection, and have been selected, are shown with a blue background and black letters.

7. Press and hold down want to set an alert. If necessary, use down

to scroll to and highlight the team for which you

or up to place the blue highlight on an Alert box (blue background, white letters) and press the Select button. The text in the Alert box will change from white to black (blue background, black letters) to indicate that the Game/Score Alert has been selected for the team. Repeatedly pressing the Select button toggles the selection of the Alert box to select (or deselect) Alert.

TIP! You can select (or deselect) a team for the Sports Ticker in the same way you selected a team for a Game/Score Alert. Simply highlight the Ticker box in blue and press the Select button.

8. You can continue to select teams for Game/Score Alerts until you are finished. Pressing menu/alerts will return you to the previous page if

Special Features

you wish to select teams in other leagues.

9. Press and hold menu/alerts to return to the main display screen.

To quickly select (or deselect) all teams in a league for Game and Score Alerts:

All teams in a league can be selected at once for Game/Score Alerts by using the All Teams selection at the beginning of the list of teams. All Teams can also be used to quickly deselect all teams in a league.

1. Press menu/alerts.

2. Press down

3. Press down

Select button.

4. Press down button.

5. All Teams will be highlighted, and the Alerts box will be highlighted in blue.

To select all teams for Game/Score Alerts: Press the Select button.

The Alert box next to each team will now have a white background with black letters indicating that the teams are selected for alerts.

To deselect all teams for Game/Score

Alerts: Press the Select button twice. The ﬁrst press selects all teams and the second press deselects all the teams in the league. The Alert box next to each team will have a black

to scroll to and highlight Alerts. Press the Select button.

to scroll to and highlight Sports Alerts/Ticker. Press the

to scroll to and highlight a league. Press the Select

Special Features

background with white letters indicating that no teams are selected for alerts.

6. Press and hold menu/alerts to return to the main display screen.

To turn Game and Score Alerts on or off and setting the audible alert beep on or off:

1. Press menu/alerts.

2. Press down

3. Press down

Select button.

4. Press down to scroll to and highlight either Game Alerts or Score

Alerts.

5. Press and release the Select button to move through the options and select a setting:

on: The visual alert is on and the

on+beep: Both the visual and

off: The visual and audible alert beep

6. Press and hold menu/alerts to return to the main display screen.

to scroll to and highlight Alerts. Press the Select button. to scroll to and highlight Sports Alerts/Ticker. Press the

audible alert beep is off (default).

audible alert beep are on.

are off.

Special Features

Sports Ticker

Sports Ticker shows status of games in progress including current score, and the ﬁnal score for games which have ended within the last 24 hours. For games in progress, it also shows the channel number if the game is being broadcast by SiriusXM. The Sports Ticker is displayed on the main display screen, and depending upon how many teams have been selected, the Sports Ticker scrolls across the screen. Whenever a score occurs, the scoring team is shown in yellow in the Sports Ticker.

IMPORTANT! A subscription package which includes play-by-play sports channels is required. To receive all the information, including the channel number on which the game is being broadcast, a subscription package containing the play-by-play channels for that particular league is required. For example, if you selected an NFL team to be displayed on the ticker and your subscription package does not include the NFL play-by-play sports channels, Sports Ticker will not display the channel number on which the game is being broadcast.

Teams can be selected while you are tuned to a channel where a game is being broadcast, or you can preselect teams through menu options. There is no limit on the number of sports teams which can be saved for the Sports Ticker.

Note: It’s possible that the game involving the team you have selected for Sports Ticker is being broadcast on multiple SiriusXM channels simultaneously. If so, the Sports Ticker will only display one channel number on which the game is being broadcast.

Special Features

To save a team for the Sports Ticker while listening to a game:

1. While tuned to the channel where the game is being broadcast press and hold menu/alerts.

2. You will be prompted to select the team for the Game/Score Alert. Highlight your choice by pressing

down button, or press menu/alerts to cancel.

3. The team you have selected will be highlighted, and the Alert box highlighted in blue. Press down highlight Ticker in blue with white letters.

4. Press the Select button to select the team the Sports Ticker. The text will change from white letters to black letters to indicate the team has been selected for the Sports Ticker.

5. Press and hold menu/alerts to return to the main display screen.

or up and press the Select

TIP! Read steps 6 and 7 on page 87 to learn more about the Alert and

Ticker boxes, and how they show the selected teams.

Special Features

To preselect (or deselect) teams for the Sports Ticker:

1. Press menu/alerts.

2. Press down

3. Press down

Select button.

4. Press down to scroll to and highlight Choose Teams. Press the

Select button.

5. Press down to scroll to and highlight the league. Press the Select

button.

6. Each team has two selections to the left of the team name, an Alert and a Ticker box. (Refer to “Game/Score Alerts” on page 78 for more information about Game and Score Alerts.) Pressing and releasing down box, highlighting the Alert or Ticker box in blue, Pressing and holding down

Alert

The Alert and Ticker boxes for teams which are not yet selected

Ticker

Alert

The Alert or Ticker box for teams which are highlighted

Ticker

Alert

The Alert and Ticker boxes for teams which have been selected

Ticker

The Alert or Ticker box for teams which are highlighted for

Alert

Ticker

to scroll to and highlight Alerts. Press the Select button. to scroll to and highlight Sports Alerts/Ticker. Press the

or up navigates through each Alert and Ticker

or up navigates through the teams.

are shown with a black background with white letters.

for selection, but not yet selected, are shown with a blue background and white letters.

are shown with a white background with black letters.

selection, and have been selected, are shown with a blue background and black letters.

Special Features

7. Press and hold down to scroll to and highlight the team for which

you want to set an alert. Use down highlight on an Ticker box (blue background, white letters) and press the Select button. The text in the Ticker box will change from white to black (blue background, black letters) to indicate that the team is selected for the Sports Ticker. Repeatedly pressing the Select button toggles the selection of the Ticker box to select or deselect the team.

TIP! You can select (or deselect) a team for a Game/Score Alert in the same way you selected a team for a Sports Ticker. Simply highlight the Alert box in blue and press the Select button.

8. You can continue to select teams for the Sports Ticker until you are finished. Pressing menu/alerts will return you to the previous page if you wish to select teams in other leagues.

9. Press and hold menu/alerts to return to the main display screen.

To quickly select (or deselect) all teams in a league for the Sports Ticker:

All teams in a league can be selected at once for the Sports Ticker by using the All Teams selection at the beginning of the list of teams. All Teams can also be used to quickly deselect all teams in a league.

1. Press menu/alerts.

2. Press down

3. Press down

Select button.

4. Press down to scroll to and highlight a league. Press the Select button.

to scroll to and highlight Alerts. Press the Select button. to scroll to and highlight Sports Alerts/Ticker. Press the

or up to place the blue

Special Features

5. All Teams will be highlighted, and the Alerts box will be highlighted in blue.

Press down box in blue.

To select all teams for the Sports

Ticker: Press the Select button. The

Ticker box next to each team will now have a white background with black letters indicating that the teams are selected for alerts.

To deselect all teams for the Sports Ticker: Press the Select button

twice. The ﬁrst press selects all teams and the second press deselects all the teams in the league. The Ticker box next to each team will have a black background with white letters indicating that no teams are selected for the Sports Ticker.

6. Press and hold menu/alerts to return to the main display screen.

To turn the Sports Ticker on or off:

1. Press menu/alerts.

2. Press down

highlight Alerts. Press the Select button.

3. Press down highlight Sports Alerts/Ticker. Press the Select button.

4. Press down

to highlight the Ticker

to scroll to and

Special Features

highlight Sports Ticker.

5. Press and release the Select button to toggle the Sports Ticker on or off.

6. Press and hold menu/alerts to return to the main display screen.

Where Else Can You Use Your Onyx Plus?

SiriusXM offers a variety of accessories that allow you to adapt your Onyx Plus to your lifestyle and enhance your listening experience. With these accessories, you can effortlessly take your Satellite Radio listening experience from your vehicle to your home or ofﬁce or on the go — all with a single subscription.

•In Your Home, Ofﬁce, etc. – With a Home Kit, you can play your Onyx Plus through your existing stereo system or powered speakers.

•In Your Other Vehicles – With Vehicle Kits, you can enjoy your Onyx Plus in other vehicles.

•In Almost Any Location You Like – With a portable Sound System you have the freedom to listen to your Onyx Plus where and when you want, from your kitchen or den, to the ofﬁce, to outside on the deck, or at a picnic.

For more information on XM accessories or to purchase an accessory, please visit your local retailer or www.siriusxm.com/accessories.

Conﬁguring Your Onyx Plus

Radio ID

Your Onyx Plus has an 8 character alphanumeric ID which uniquely identiﬁes your Radio. This ID is used during the subscription process.

To display the Radio ID:

1. Press menu/alerts.

2. Radio ID will be highlighted. If it is not

highlighted, press down and highlight Radio ID. Press the Select button. The Radio ID will be displayed.

3. Press and hold menu/alerts to return to the main display screen.

to scroll to

Conﬁguring Your Onyx Plus

Channel Tuning

Channel tuning controls the way channels are displayed when tuning to channels through the channel line up. There are two different channel tuning modes, Tune by Channel and Tune by Category. The default setting is Tune by Channel.

•Tune by Channel: Channels are displayed in ascending or descending numerical order, regardless of their category. The numerical channel numbers are shown when channels in a category are viewed in list mode.

•Tune by Category: Channels are grouped and displayed according to their category such as Rock, Pop, Christian, etc., regardless of their numerical channel number. Once you have scrolled through all the channels in a category, the channels in the next category are shown.

To conﬁgure Channel Tuning:

1. Press menu/alerts.

2. Press down

Select button.

3. Press down to scroll to and highlight Tune by Channel or Tune by

Category. Press the Select button.

4. Press and hold menu/alerts to return to the main display screen.

to scroll to and highlight Channel Tuning. Press the

Conﬁguring Your Onyx Plus

FM Settings

Find Available FM Channels in Your Area

Before attempting any of the procedures below, you should park your vehicle in a safe location. Do not attempt to set up your FM channels or any Onyx Plus function while driving.

PowerConnect allows you to listen to SiriusXM through your existing vehicle radio. You will ﬁrst need to ﬁnd an available FM channel, which is a channel that is not being used by an FM radio station in your area. When you tune your vehicle’s FM radio to an available channel, you should only hear static or silence – not talk or music.

Once you have found an available FM channel, you’ll need to tune Onyx Plus and your vehicle’s radio to the same FM channel to receive XM audio through your vehicle’s radio.

We recommend one of the following methods to ﬁnd an available FM channel:

1. Use the SiriusXM FM Channel Finder

Use the SiriusXM FM Channel Finder at www.siriusxm.com/fmchannel.

Go to the website and enter your zip code. The Channel Finder will suggest a list of available FM channels in your area. For convenience, write down or print out the list.

Tune Onyx Plus to a favorite XM channel (or to channel 1, if it’s not

activated). Turn on your vehicle’s FM radio. Pick the first FM channel on your Channel Finder list and tune the FM radio to that channel. If you do not hear a local FM station broadcast, then tune Onyx Plus to the same FM channel. (Refer to “Set and Select an FM Channel” on page

96.) You should hear the XM channel through your vehicle’s radio. If you are satisfied with the sound quality, you’re done! If this FM channel doesn’t work well for you, work down the list until you find an FM channel that allows you to hear XM clearly.

Conﬁguring Your Onyx Plus

2. Manually tune through your local FM channels

Manually tune through your local FM channels on your vehicle’s FM

radio. Turn on your vehicle’s FM radio. Start at 88.1 and use the ‘Manual’ tune function on your vehicle’s FM radio to tune through each FM channel one-by-one (88.1 followed by 88.3 etc.) to locate channels that aren’t being used by a local FM radio station. Write down each FM channel that has only static or silence on it, until you reach 107.9. Once you have created your list of available FM channels, you will need to find the one that provides the best match for Onyx Plus.

Tune Onyx Plus to a favorite XM channel (or to channel 1, if it’s not

activated). Pick the first FM channel on your list and tune the FM radio to that channel. Then tune Onyx Plus to the same FM channel. (Refer to “Set and Select an FM Channel” on page 96.) You should hear the XM channel through your vehicle’s radio. If you are satisfied with the sound quality, you’re done! If this FM channel doesn’t work well for you, work down the list until you find an FM channel that allows you to hear XM clearly.

NOTE! You may ﬁnd an FM channel with static or silence that does not work with Onyx Plus. It is possible that some type of inaudible interference is present that prevents reception of the XM broadcast. Your only options are to use another FM channel or a different audio connection method.

TIP! If you regularly drive from one location to another, such as your daily commute, you may need to use different FM channels along your route for best performance. If this is the case, we recommend saving the best FM channels as presets on your FM radio and Onyx Plus. Then you simply select and match the best channel for the area you are in.

TIP! It will be much more difﬁcult to ﬁnd available FM channels in large cities than in most suburban or rural locations. A direct audio connection using the Aux In Cable, Cassette Adapter, or professional installation is your best solution if you drive in or near large metropolitan areas.

Conﬁguring Your Onyx Plus

NOTE! The SiriusXM FM Channel Finder relies on data from the Federal Communications Commission. The data may not reﬂect the latest stations in your area. In addition, local geography and weather conditions can impact reception, so your results may be different from the list.

NOTE! The performance of FM radios are different, based on manufacturer and vehicle style. Some may not work well with the type of FM transmitter used by Onyx Plus. This is why we recommend a direct audio connection using the Aux In Cable or Cassette Adapter if they can be used in your vehicle. Professional installation can also resolve almost any performance issue.

Set and Select an FM Channel

Onyx Plus allows you to easily store (i.e., preset) up to 5 different FM

channels. At any time, you can select any one of these 5 FM presets to hear SiriusXM through your existing vehicle radio. Having a choice of 5 FM presets also makes it easy to switch to the appropriate FM channel as you travel from one area to another. Each FM preset is stored in its own storage location. You can easily add or edit the FM preset in any one of the 5 storage locations.

IMPORTANT! Onyx Plus and the vehicle’s FM radio need to be tuned to the same FM channel in order to hear the audio.

TIP! The FM 1 storage location is preset with FM channel 97.9.

To set and select an FM preset:

1. Press menu/alerts.

2. Press down

highlight FM Settings and press the Select button.

3. FM Channels will be highlighted. If it is not highlighted, press down

to scroll to and

Conﬁguring Your Onyx Plus

scroll to and highlight FM Channels. Press the Select button.

4. Press down FM 5) you want to set and press the Select button. You can choose among the following options:

i. If the chosen storage location is empty (denoted by “---“), or if

the storage location contains the FM preset currently being used (denoted by “current”), then the FM channel tuning screen is displayed.

ii. If the chosen storage location has

an FM preset that is not currently being used, and you want to edit it, Edit Channel is highlighted. Press the Select button. The FM channel tuning screen is displayed.

iii. If the chosen storage location has

an FM preset that is not currently being used, and you want to start using it, press Using and press the Select button. Skip to step 7.

5 Press left

desired FM channel in steps of .2, i.e.,

99.3 to 99.5. Press down tune to the desired channel in steps of 1, i.e., 99.3 to 100.3. Press the Select button to select the FM channel.

6 If you are editing the storage location

that has the “current” FM preset, skip

to scroll to and highlight the storage location (FM 1 to

to highlight Start

or right to tune to the

or up to

Conﬁguring Your Onyx Plus

to step 7. Otherwise, Start Using will be highlighted. Press the Select button.

NOTE! You can also set an FM preset without having to start using it right away. Just press menu/alerts and exit the screen.

7 The chosen FM channel will be confirmed on the display screen and

Onyx Plus will tune to that FM channel.

8 Set your vehicle’s FM radio to same FM channel.

IMPORTANT! You’ll ﬁrst need to ﬁnd a suitable FM channel that is unused or

available in your area.

To quickly select an FM preset:

1. Press and hold Power/FM to display the FM preset list showing the current FM preset.

2. Press down FM preset, or use the number keys to select the corresponding FM preset, for example, pressing 3 will select FM3. Press the Select button. The Radio will tune to the selected FM channel. If the preset is the one you want, press menu/alerts or wait for the confirmation screen to time out.

3. Set your vehicle’s FM radio to the same FM channel.

or up to highlight the

Conﬁguring Your Onyx Plus

Brightness

The Brightness of the Onyx Plus display can be adjusted for optimal viewing.

To change the brightness of the display screen:

1. Press menu/alerts.

2. Press down to scroll to and

highlight Brightness and press the Select button.

3. Press left increase the brightness of the display.

4. Press the Select button to confirm the brightness setting.

5. Press and hold menu/alerts to return to the main display screen.

to decrease or right to

Conﬁguring Your Onyx Plus

Audio Level

The audio level of Onyx Plus can be adjusted when an audio connection is made between the dock and the vehicle’s stereo system. Audio level

is used to adjust Onyx Plus’s audio sources you may use, such as a CD player, other FM stations, or an MP3 player.

Do not use the audio level as a volume control. Use the volume control on your vehicle’s stereo instead.

To adjust the audio level:

1. Press menu/alerts.

2. Press down

highlight Audio Level and press the Select button.

3. Press left increase the audio level.

4. Press the Select button to confirm the new audio level.

5. Press and hold menu/alerts to return to the main display screen.

to scroll to and

to decrease or right to

volume level to match the volume of other

100

SiriusXM Onyx Plus with Vehicle Kit User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
