SH69P26 EVB
Application Note for SH69P26 EVB
SH69P26 EVB
The SH69P26 EVB is used to evaluate the SH69P26 chip's function for the development of application program. It contains
an SH69V26 chip for evaluating the functions of SH69P26. The following figure shows the placement diagram of SH69P26
EVB.
JP1
J2J1
VCC GND
J3
U2
ROMLROMH
U3U2
5V
3V
EXT
HALTPOWER
STOP LVR CMPEN
74HC273
JP2
J4
1
IDD TEST
SH69V26
S1
1ON2345678
JP4
J6
1
U1
U3
74HC273
1
J5
ST
JP3
ICE
JP6
1
C2 C1
Y1
ROSC
JP7
SW1
RESET
1/10 Ver0.1
SH69P26 EVB
There are two configurations of SH69P26 EVB in application development: ICE mode and stand-alone mode.
In ICE mode, the ICE (motherboard) is connected to the EVB by ICE interface.
USB port
Application
Board
Evaluation
Board
USB
RICE
Power
PC
Board
Evaluation
Board
RICE66 Emulator
(a) ICE mode
DC 5V
Application
Board
In standalone mode, the EVB is no longer connected to the motherboard, but the Flash (or EPROM) must be inserted
to the socket that stored the application program.
Application
LPT port
Power
PC
Evaluation board
(b) Stand-alone mode
2/10
SH69P26 EVB
The process of your program’s evaluation on SH69P26 EVB
User can use
obj file. Rice66 IDE is a real-time in-circuit emulator program. It provides real-time and transparent emulation support for the
SH6X series 4-bit microcontroller. And integrate assembler can create binary (*.obj) file and the other files.
Use Flash (or EPROM) In standalone mode
Rice66 IDE is built-in with an object file depart function. The command ”Split object file” can separate the one 16 bits object
file into two 8 bits files, which contain the high and low bytes respectively.
Write the high/low byte obj file to Flash (or EPROM) and insert them to EVB (ROMH and ROML). Then, user can evaluate
the program in standalone mode.
Sino Wealth Rice66 Integrated Development Environment (IDE)
to emulate the program and produce the
3/10
SH69P26 EVB
SH69P26 EVB Interface Connector: (Top View from EVB)
Port interface connector: J6 (TOP View from EVB)
：
External VCC input for stand alone mode:
J1, J2
-The external power input when the EVB worked in stand-alone mode. The voltage of Vcc must be 5V±5%.
Interface to ICE:
J4, J5
-connect to RICE66 2.0, or connect to RICE66 3.0 with a transition board.
J3
-connect to RICE66 3.0 directly.
Interface to test the EV chip operating current
JP2 -
User can test the EV chip current through JP2
PG2
PG3
PE3
PE2
PE1
PE0
PC2
PC3
GND
PA0
PA1
PA2
PA3
PD0
PD1
PH0
PG1
PG0
PF3
PF2
PF1
PF0
PC1
PC0
VCC
PB3
PB2
PB1
PB0
PD3
PD2
PH1
Note: In ICE mode, the current value is correct only when the RICE66 runs in external clock from EVB mode. (Select the
“external clock from EVB” in OSC Frequency Config manual.)
4/10
SH69P26 EVB
Switch setting:
S1
Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Remarks
RST LVR0 LVR
X X X X X Off Off
X X X X X Off Off On
X X X X X Off On Off
X X X X X Off On On
X X X X X On Off Off
X X X X X On Off On
X X X X X On On Off
X X X X X On On On
X X X X Off X X X
X X X X On X X X
X X X
X X X On X X X X WDT Disable
X X Off X X X X X LVR Disable
X X On X X X X X LVR Enable
X Off X X X X X X High LVR voltage
X On X X X X X X Low LVR voltage
Off X X X X X X X Reset pin Enable
On X X X X X X X Reset pin Disable
#Note : LVR value might exceed the SPEC range.
WDT OSC3 OSC2
Off
X X X X WDT Enable
OSC1 OSC0
Off
External clock
Internal ROSC RC oscillator 2M
Internal ROSC RC oscillator 4M
Internal ROSC RC oscillator 6M
External ROSC RC oscillator
Ceramic resonator
Crystal oscillator
32.768KHz Crystal oscillator
2 ~ 8MHz
400KHz ~ 2MHz
5/10
SH69P26 EVB
Jumper setting:
JP1 EV chip power supply select
Short at 3V position The power of EV chip is set as internal 3V power source.
Short at 5V position
Short at EXT position
JP3 EVB ICE/Stand-alone mode select
Short at Stand-alone position Select stand-alone mode. (The system clock is provided by the on board oscillator.)
Short at With-ICE position
JP4 OSCI OSCO share select
Short at OSCI position
Short at OSCO position
JP6
Short The stack overflow function in the ICE mode will on
Open
JP7
The power of EV chip is set as internal 5V power source.
The EV chip use external power supply that was input from EXT_VDD pin.
Select with-ICE mode. (The system clock is provided by the ICE.)
OSCI pin will be disable d and shared as PORTC0
OSCO pin will be disabled and shared as PORTC1.
STACK overflow select
The stack overflow function in the ICE mode will off
RESET pin share select*
Short RESET pin will be disabled and shared as PORTC.3
Open
Note: If external Reset pin is enabled (PORTC.3 is shared as Reset pin) in main chip application, SH69P26 will provide
*
better performance on Electro Magnetic Compatibility (EMC)
SW1 (RESET):
Reset the whole system by pressing the button.
RESET pin will be enabled.
Diagnostic LED:
Power LED: The LED will be turned on when the EVB is powered.
HALT LED:
STOP LED:
LVR LED:
CMP LED:
The LED will be turned on during the low voltage reset active.
The LED will be turned on when the system is in HALT mode.
The LED will be turned on when the system is in STOP mode.
The LED will be turned on when CMP is active.
6/10
SH69P26 EVB
Notes:
Application notes:
1.1 After entering into the RICE66 and successfully downloaded the user program, use the F5 key on the PC
keyboard to reset the EVB before running the program. If abnormal response occurs, the user must switch off
the ICE power and quit RICE66, then wait for a few seconds before restarting.
1.2 When running the RICE66 for the first time, the user needs to select the correct MCU type, clock frequency ...
then save the settings and restart RICE66 again.
1.3 Can’t Step (F8) or Over (F9) a HALT and STOP instruction.
1.4 Can’t emulate the interrupt function in Step (F8) operating mode.
1.5 When you want to escape from HALT or STOP (in ICE mode), please press F5 key on the PC keyboard twice.
1.6 T he maximum current limit supplied from EVB to the target is 100mA. When the current in the target is over
100mA, please use external power supply.
1.7 When EV board worked in “with ICE” mode, user can use the clock from EXOSC_IN (JP7) as the system clock.
(Refer to the RICE66 User’s Guide).
Programming notes:
2.1 Clear the data RAM and initialize all system registers during the initial programming.
2.2 Never use the reserved registers.
2.3 Do not execute arithmetic operation with those registers that only have 1, 2 or 3 bits. This kind of operation may
not produce the result you expected.
2.4 To add “p=69P26” and “romsize=6144” at the beginning of a program. If any problem occurs during the
compilation of the program, check the device and set if it was set correctly.
2.5 Both index register DPH and DPM have three bits; so pay attention to the destination address when using them.
2.6 The clock of the Base timer and LCD driver is sourced by the low frequency oscillator (OSC). When evaluating
the LCD and the Base-timer function, the “External from EVB” item in the Config manual should be selected.
2.7 The capacitors for LCD power supply must be connected at all time, whether the LCD is being used or not. It
takes more than 0.3 second to wake up from STOP mode when using 32.768kHz crystal. So, if the system is
awake when the key is pressed, the key may have been released when the program starts to read the Key
value.
2.8 Notes for interrupt:
2.8.1 Please make sure that the IE flag is enabled before entering into a “HALT” or a “STOP mode. It means that
the “HALT” or “STOP” instruction must follow the set “IE” instruction closely.
7/10
SH69P26 EVB
2.8.2 After the CPU had responded to an interrupt, IRQ should be cleared before resetting IE in order to avoid
multi-responses.
2.8.3 Interrupt Enable instruction will be automatically cleared after entering into the interrupt-processing
subroutine. If setting IE is too early, it is possible to reenter into the interrupt. So the Interrupt Enable
instruction should be placed at the last 3 instructions of the subroutine.
2.8.4 CPU w ill not respond to any interrupt during the next two instructions after the Interrupt Enable flag be set
from 0 to 1.
2.8.5 After CPU has responded to an interrupt, IE will be cleared by the hardware. It is recommended to clear the
IRQ at the end of interrupt subroutine.
2.8.6 The stack has four levels. If an interrupt is enabled, there will be only three levels that can be used.
2.8.7 It is recommended that the last line of program is “END”.
Examples:
1> D escription: CPU can not wakeup after executing the “HALT” or “STOP” instruction.
Program: Interrupt Enable instruction is set outside the interrupt subroutine
<Wrong example> <Correct example >
…… ……
LDI IE, 0FH ; enable interrupt LDI IE, 0FH ; enable interrupt
NOP NOP
NOP NOP
HALT HALT
Analysis:
instruction cycle, CPU will respond to the interrupt and IE will be cleared. Then when returning to main
program, CPU starts to execute “HALT” or “STOP” and will not be activated, because IE is cleared to zero
and all interrupts are disabled.
Solution:
After two “NOP” instructions, if an interrupt request comes or IRQ is non-zero during the third
“HALT” or “STOP” are being followed closely by the “LDI IE, 0FH”
2> Description: CPU responds to one interrupt several times.
Program: Interrupt Enable instruction is placed outside the interrupt subroutine.
L1:
……
LDI IE, 0FH ; enable interrupts
NOP
NOP
JUMP L1
Analysis:
the interrupt again when it executes the two instructions followed by “LDI IE, 0FH”. This will happen again
and again. So CPU responds to one interrupt several times.
Solution:
8/10
After executing this two “NOP” instruct ions, and IRQ is not cleared in tim e, CP U will r espond t o
The relative IRQ flag is cleared in time after responding to the interrupt.
SH69P26 EVB
3> Description: CPU is running dead in the interrupt-processing program.
Program: an interrupt subroutine.
ENTERINT:
……
LDI IE, 0FH
NOP
LDA STACK, 0
RTNI
Analysis:
the last relative IRQ flag is not cleared in time, then CPU will respond to the interrupt again, so the interrupt
is nesting again. When the stack is over 4 levels, it will run into a dead loop.
Solution:
interrupt is enabled; After the interrupt is responded, the relative IRQ flag should be cleared before
enabling the interrupt.
2.9 Notes for TIMER
2.9.1 When setting the Timer Counter, write first T0L, then T0H.
2.9.2 After setting TM0, T 0L, T0H, there is no need to rewrite after the Timer counts overflow, otherwise it will
cause a time error every time. The timer is interrupted by the reload registrar that was set in different time.
After executing “LDI IE, 0FH” and the following two instructions, an interrupt request comes or
Make sure that the CP U can quit from interrupt subroutine wi thin two instruction cycles after
2.10 Notes for I/O
2.10.1 Never do the logical operation with the I/O ports. Especially when the I/O ports are connected with the other
components externally.
2.10.2 When the internal pull-high resistor is turned on, “1” must be written to I/O Port before Reading.
2.10.3 When counting external pulse, please directly read the PORT status to make sure that the counted number
is correct.
2.10.4 The Key De-bounce time is recommended to be 50ms. But in the Rubber Key application, it is best to test
Rubber Key’s De-bounce time.
2.11 When the Compiler of old version compiles program, the last line will be read twice. So, if the last line is an
instruction, two same operations will be occurred. If there is Label in the last line, compiler will g ive an error
named ‘repeated definition’. This will happen in main program or included files and it is recommended that the
last line should be a blank line or END.
2.12 It takes 0.3 second to wake up from STOP when using 32768Hz crystal. So, if the system is waked up by key
pressing, the key may have been released when the program begins to read Key value. Please pay more
attention to this problem.
In 28 pin mode, All bits of the $22 RAM are reserved, Always keep it to “0” in the User’s program.
2.13
In 28 pin mode, All bits of the $20 RAM are reserved, Always keep it to “1” in the User’s program.
2.14
9/10
SH69P26 EVB
Application notes Revision History
Revision No. History Date
0.1 Add reset pin share function Jan.2006
0.0 Original Oct.2005
10/10
