F16-J1 User’s Manual
All-In-One PC
Model: F16-J1
User’s Guide
Version: V1.0
1
F16-J1 User’s Manual
CONTENTS
Ⅰ SUMMARY ............................................................................................................... 2
1.1FEATUR ES ......................................................................................................... 2
Ⅱ HARDWARE SETTINGS ......................................................................................... 3
2.1 QUICK VIEW ..................................................................................................... 3
2.2 ACCESSORY INSTALLATION ................................................................................ 4
2.3 ADJUST ANGLE ................................................................................................. 6
2.4 POWER ON ...................................................................................................... 6
Ⅲ OS & DRIVERS INSTALLATI O N ............................................................................. 7
3.1 INSTALL OS MODE ............................................................................................ 7
3.2 INSTALL DRIVERS .............................................................................................. 7
Ⅵ SPECIFICATION ...................................................................................................... 8
2
F16-J1 User’s Manual
Ⅰ S UMMARY
1.1 Features
▌High quality 15” 4:3 TFT active matrix LCD panel
▌Intel celeron J1900, 4 Core 4 Threads 2GHz(up to 2.42 GHz)
▌1x SO-DIMM DDR3L 4GB（ Max to 8GB（
▌Resolution 1024 x 768, contrast ratio 700:1, brightness 250cd/m2
▌Integrate PCT(Projected Capacitive Touch) screen, Multi-touch,10 point
▌Stand or Wall Mount Available
▌Optional: MSR, VFD, Second 15" display(optional PCT touch)
▌Supply OEM/ODM service
3
F16-J1 User’s Manual
Ⅱ H A R D W A R E S E T T I N G S
2.1 Quick View
2.1.1 Front
2.1.2 I/O Ports
4
F16-J1 User’s Manual
2.2 Accessory Installation
1．Power Supply
Plug in the power cable
2 x USB2.0
5
F16-J1 User’s Manual
2．LAN Cable
Connecting the RJ45 cable
3．MSR
MSR(magnetic stripe swipe card reader) is installed in the factory, manufacturer is
not responsible for any possible problem caused by self disassembly
Card Reader
6
F16-J1 User’s Manual
2.3 Adjust Angle
Adjusting the machine to proper angle
2.4 Power On
1. Make sure all parts connected correctly
2. Press the power switch until beep sound
Power Switch
7
F16-j1 User’s Manual
Ⅲ OS & Drivers Installation
3.1 Install OS Mode
There are two ways to install OS：
If you had DOS drivers for the network card you might be able to connect to your local
lan and copy the setup files to the local disk.
or
Install a bootable OS using an external USB CD-ROM/DVD device
3.2 Install Drivers
After OS installed successfully, the system needs to install hardware drivers:
Hardware drivers installation order：install chipsets drivers first, then install
drivers
Installation method：
(1) Insert Driver CD into the CD-ROM/DVD device, double-click the executable file
Setup.exe in the corresponding file folder
(2) If there is not any executable file under the corresponding file folder，click
My Computer, find the CD-ROM , click autorun.exe, then choose the correct device.
F16-j1 User’s Manual
8
Ⅵ S P E CIFICATION
Mother Board
CPU Intel celeron J1900, 4 Core 4 Threads 2GHz(up to 2.42 GHz)
Memory
1x SO-DIMM DDR3L 4GB（Max to 8GB）
Heat Elimination Mode Fan-less
OS Windows 7/8, POSReady, Linux etc.
Storage
HDD 64GB SSD
Easy Swap
I/O Ports
Serial 3 × COM (RS-232 )
USB 5 × USB 2.0 , 1 x USB 3.0
LAN
1 × RJ45，Gigabit Ethernet
PS2 1 × PS/2
VGA 1 ×VGA out
Audio 1 ×MIC in, 1 × Audio out
LPT
1 x LPT
Other
DC IN DC 12V
Weight
9．5Kg
Package Size 430*360*5000mm
Operate Temperature
0
o
～ 40oC
Storage Temperature
-20
o
～ 60oC
Storage Humidity
20 %
～ 90% RH, Non Condensing
F16-j1 User’s Manual
9
