ELECTRIC SERIES SCISSOR LIFTS
0608SE(1930SE)/0608ME(1932ME)
Compliance with ISO/CE/ANSI/CSA/AS/EAC standards
PRODUCT HIGHLIGHTS
Effi cient and environmentally friendly
■ Higher work effi ciency
■ Environmental protection, zero emissions
Reduced maintenance costs
■ Rapid, convenient transportation with two-way forklift slot
■ Lower cost of ownership with highly versatile parts
Reliable performance
■ Bumper rail protection
Standard features
Maintenance-free battery Automatic braking system
Proportional control Emergency lowering system Forklift pocket and lifting eyes
Bumper rail Emergency stop at both platform and ground controls Electrophoresic paint technology
2WSx2WD Fault diagnosis system Foldable guardrail
Non-marking tyres Tilt protection Overload sensing system
Integrated hand shield Automatic pothole guard
Optional features
Overhead anti-collision device Headlight RCBO
AC power to platform
Foot switch
Drive at full height
SINOBOOM.COM | [email protected]
NO.128 EAST JINZHOU AV., NINGXIANG HI-TECH INDUSTRY PARK, CHANGSHA, HUNAN, CHINA, 410600
Page 2
ELECTRIC SERIES SCISSOR LIFTS
0608SE(1930SE)/0608ME(1932ME)
Compliance
with ISO/CE/ANSI/CSA/AS/EAC standards
Model 0608SE/0608ME(1930SE/1932ME)
Dimensions
Max Working Height
A Max Platform Height
B Max Horizontal Extension
C Length-Stowed
D Width-Stowed
E Height-stowed (Rail Folded)
E Height-stowed (Rail Unfolded)
F Wheelbase
Ground Clearance(Pothole Guard Stowed)
Ground Clearance(Pothole Guard Deployed)
Platform Dimensions(LxWxH)
Platform Allowable Occupants(Indoor/Outdoor)
Platform Capacity
Drive Speed-Stowed
7.8m(25'7")
5.8m(19')
0.9m(3')
1.8m(5'11")
0608SE 0.79m(2'7") / 0608ME 0.81m(2'8")
1.88m(6'2")
2.14m(7')
1.33m(4'4")
75mm(3")
24mm(0.95")
1.64mx0.76mx1.1m(5'5"x2'6"x3'7")
Performance
0608SE(2persons/-), 0608ME(2persons/1 person)
230kg(507lbs)
4km/h(2.5mph)
B
A
Drive Speed-Raised
Elevation Time(Unloaded)
Descent Time(Unloaded)
Gradeability
Turning Radius(Inside/Outside)
Tilt Rating(Front to Back/Side to Side)
Tyre Size/Type
Batteries
Power Source
Drive Mode
Charger Input
Charger Output
Hydraulic Tank Capacity
0.8km/h(0.5mph)
15s~20s
25s~30s
25%
0/1.49m(0/4'11")
3°/1.5°
323x100mm(12.7x4")/solid
Power
6Vx4/225Ah
24V DC
Motor, front-wheel
100~240V AC
30A
7L(1.54gal(UK)/ 1.85gal(US))
Weight
E
F
C
Weight 1,575kg(3,473lbs)
Standards Compliance
We reserve the right to make specification changes without notification. The above represents the current specifications at time of publication. 02. 2022
ISO/CE/ANSI/CSA/AS/EAC
