Singtech SGT-T600 User Manual

PN: 5839004043

While all efforts have been made to ensure the accuracy of all contents in this manual, we assume no liability for errors or omissions or statements of any kind in this manual, whether such errors or omissions or statements resulting from negligence, accidents, or any other cause. The contents of this manual are subject to change without notice.

Protect our environment! We strive to produce products in compliance with global environmental standards. Please consult your local authorities for proper disposal.

Note: User’s Manual is just to guide the user about the functionality of the phone. This is not any certificate of technology. Some functions may vary due to modifications and upgrading of software or due to printing mistake.

TABLE OF CONTENTS

GENERAL INFORMATION..........................................1

PHONE OVERVIEW....................................................2

STATUS ICONS...............................................................3

SMART TOUCH SCREEN................................................4

GETTING STARTED....................................................5

Installing SIM Card and Battery.........................................5

Installing Memory Card.....................................................5

Charging the Battery........................................................6

Switch On/Off the Phone..................................................6

Automatic Customer Registration......................................7

BASIC OPERATIONS..................................................8

Make Calls.......................................................................8

To Dial International Number ............................................8

Clear Wrong Enters..........................................................9

Adjusting the Sound Volume.............................................9

Answer/Reject an Incoming Call .......................................9

Options During A Call.......................................................9

MAIN MENU..............................................................10

Call Logs.......................................................................10

Phonebook....................................................................10

Messages......................................................................10

Calculator......................................................................13

Internet..........................................................................14

Camera .........................................................................14

Image Viewer.................................................................14

Time Manager................................................................14

Calendar........................................................................14

Media Player..................................................................15

File Manager..................................................................15

User Profiles..................................................................15

Settings.........................................................................15

FM Radio.......................................................................19

Organizer ......................................................................19

Ebook reader.................................................................20

Bluetooth.......................................................................20

Google ..........................................................................20

Wi-fi...............................................................................20

Fun & Games ................................................................20

Answer Machine ............................................................21

NTV...............................................................................21

Opera............................................................................22

E-mail............................................................................22

Sound Recorder.............................................................22

APPENDIX ................................................................23

Appendix A: Troubleshooting..........................................23

SAFETY PRECAUTIONS

Before using your phone, please read the following important information to eliminate or reduce any possibility of causing damage and personal injury.

Do not use wireless phones while driving. Switch off wireless devices in aircraft. The signal may

cause interference. Using them on aircraft is illegal. Do not use mobile phones where blasting is in

progress. Follow any regulations and rules strictly. Do not use mobile phones at Petrol stations. Don’t

use near fuel or chemicals. Do not dispose your battery or mobile in a fire.

Follow any regulations or rules in hospital and health care facilities. Switch phone off near medical equipment.

All wireless devices may get interference that could affect performance.

The repair or installation of the device should be done at Authorized service centers

Use only approved accessories and batteries. Use only in normal position. Do not expose your

phone to extreme high temperatures above +60C （+140F）. Do not use anything static to clean your phone.

Ensure the phone is turned on and in service. Enter the emergency number, then press Pick Up key. Give your location. Do not end the call until told to do so.

Improper use will invalidate the warranty! These safety instructions also apply to original accessories.

GENERAL INFORMATION

Antenna

Use of other antenna devices could damage your mobile phone and reduce performance. Your phone has a built-in antenna. Don’t touch the antenna area unnecessarily when the phone is switched on. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.

Network Service

A lot of features described in this manual are called network service. They are special services provided by wireless service providers. You should subscribe to these services from your home service provider and learn instructions on uses before you select the network you want to use.

Accessories

Li-Ion battery is the manufacturer-approved rechargeable battery available for your phone. Some batteries may performs better after several full charge/discharge cycles. Use batteries, chargers and accessories approved by the phone manufacturer with this particular model. The use of any other types will invalidate any approval or warranty applying to the phone, and may be dangerous. Please consult with your dealer for availability of approved accessories.

PHONE OVERVIEW

1 Receiver 8 Cord hole 2 Screen 9 Earphone Jack 3 Call/Send Key 10 Stylus 4 End Key 11 Side Keys 5 Menu Key 12 Camera Button 6 Power Key 13 Camera 7 USB Connecter 14 Speaker

STATUS ICONS

The table below lists various icons that might appear on the status bar while using the phone. Apart from the icons for signal strength level and the power, other icons are displayed as per the current mode and priority of the phone.

Icon Description

Indicates the network signal strength of Master SIM. Indicates the network signal strength of Slave SIM. Indicates the current battery capacity.

Indicates that there is an unread message in Master SIM. Indicates that there is an unread message in Slave SIM. Indicates that there is a missed call in Master SIM. Indicates that there is a missed call in Slave SIM. Indicates that the current Sound Status is the Ring only.

Indicates that the current Sound Status is the Vibrate then Ring.

Indicates that the current Sound Status is the Vibrate and Ring.

Indicates that the current Sound Status is the Vibrate only.

Indicates that the current profile mode is the Headset mode.

Indicates that the current alarm clock is set as activated. Indicates that the audio player is running.

Indicates the current keypad-locked state. Indicates that the Wi-Fi is connected.

Indicates that the Bluetooth is turn on.

SMART TOUCH SCREEN

The phone features a full touch, 8 cm wide screen with eight idle displays and access to utilities on just one-touch. So swipe right or left to navigate through various screens accessing your favorite features without entering the main menu. In the standby mode, tap the screen and then drag left or right to view the desktop screens. Please refer to “settings > Phone settings > desktop setting” for more details.

The first row known as the status bar displays various icons, including signal strength, battery, time and profile mode. Tap the status bar and scroll down to open the notification bar. The notification bar provides immediate access to the features, such as Bluetooth, User Profile, Multi SIM Settings and Wi-Fi.

Customizable Menu Icons

You can re-design and customize the desktop as per your desire. Just long press on the desired icon and move it to the required position. You can place the icons anywhere on the same screen or in any other menu screen.

GETTING STARTED

Please switch off your phone before inserting or removing the battery/SIM card or memory card.

Installing SIM Card and Battery

Your phone is provided with two SIM slots for two different SIM cards. The SIM card inserted in the slot1 is called Master SIM, and the other one in the slot2 is known as Slave SIM.

 Hold the phone with the front facing downwards; pull

the battery cover.

 Remove the back cover of the phone.  Insert the SIM cards in the slots.  Attach the battery.  Push the battery cover until it clicks into place.

Installing Memory Card

The phone supports T-Flash card, which is a multimedia memory card used to multiply the memory of the phone. The T-flash card is small and should be pulled out /installed carefully and prudently in order to avoid any kind of damage.

 Switch off your phone.  Remove the battery cover.  Slide the T-Flash card into the slot.  Attach the battery.  Push the battery cover until it clicks into place.

Charging the Battery

The phone prompts a warning tone and message stating insufficient battery when the power of your phone is low. Please follow the instructions mentioned below to charge your phone:

 Plug the connector of the charger into the jack of the

phone.

 Plug the charger into a standard AC wall outlet.

Note:

When is shown on the screen, it indicates that there is not enough power and you should now charge your phone. When charging is complete, the battery icon will stop flashing.

Charging……. Fully Charged……

You must fully charge the battery before using the phone for the first time. It is recommended to charge the battery for four hours before using the phone for the first time.

If the phone is turned on during charging, you can still make or answer calls, but this will consume battery power, thus will extend the charging time of the phone.

Switch On/Off the Phone

To turn on/off the phone, press and hold the Power Key. If you have enabled the SIM Lock function then enter the PIN code (the 4 to 8 digits secret code of your SIM card). It is preconfigured and provided to you by your network operator or retailer. If you enter an incorrect PIN code 3 times in succession, your SIM card will be locked. To unlock it, you must obtain a code from your network

operator.

Automatic Customer Registration

After 4 hours of usage a SMS from the phone will be sent automatically for the customer registration.

Note: standard SMS charges apply.

BASIC OPERATIONS

Make Calls

If the icon / appears on the screen, then you can make or receive calls.

 In the standby mode, tap Dialer , enter the desired phone

number (should affix the international/ national/ regional code or district code if necessary) and then tap / to make a

call.

 In the standby mode, tap Phonebook , use the scroll bar to

select the desired contact or enter the initials of the name to be searched and then tap to make a call.

 In the standby mode press Call/Send Key to dial a phone

number listed in the recent call log.

To Dial International Number

The phone supports dialing the international emergency phone number. Using your handset, you can dial an emergency call in any country or region under the normal situation regardless of SIM card inserted when the phone is located within the coverage of the GSM network.

Input the emergency phone number and press send key or tap / to dial.

 In the idle mode, tap the * twice to prefix the international

symbol +.

 Enter the country code, area code and phone number.  Tap / to make an International call.

The phone will select the main network automatically after powered on if it is located within the coverage of the main network. The phone can use other network, called as roaming, if the phone is not located within the coverage of the main network when the network operator protocol permits.

Clear Wrong Enters

If you tap a wrong number, tap ( ) to erase the wrong number.

Adjusting the Sound Volume

During a call, you can press the Side Key to adjust the earpiece volume.

Answer/Reject an Incoming Call

 To answer an incoming call, press the Call/Send Key or tap

the ( ) . You can use the earphone to answer the call when the

generic earphone is inserted in the phone.

 To end or reject an incoming/ongoing call, press the End Key

or tap the ( ).

Options During A Call

Press <Options> to use the following functions during the call:

 Hold Single Call: temporarily hold the current call.  End Single Call: end the current call.  New Call: call the opposite party to build a Call to Many.  Phonebook: enter in the phonebook menu.  Messages: enter in the SMS menu.  Sound Recorder: record the current call.  Background sound: enter in the background sounds menu.  Mute: open or close the mute mode.  DTMF: open or close the DTMF function during the call.

MAIN MENU

Menu guides you to the various features, applications and services available in your phone. Tap access to the Main Menu.

Call Logs

Access the call log menu to view the call details of the Master SIM and Slave SIM.

Call History

This sub-menu lets you view the call details i.e. the missed, received and dialed call logs. Scroll the Up/Down keys to select a call and then select view to see the details. Press options to perform the operations, such as call, send message, add to

blacklist, delete。

Missed Calls

With this function, you can check recent missed calls. Scroll Up/Down to select a missed call. Press options to access missed call information, and perform operations, such as delete, save to phone book, call, and so on.

Phonebook

This menu refers to the directory wherein all the contacts are stored in an alphabetical order. You can view, edit, delete, send message and perform various other functions on each contact of your phonebook.

Messages

Your phone features, sending and receiving of SMS (Short Message Service) and MMS (Multimedia Message Service).

In the standby mode, Tap to access the Main Menu and then tap Messages.

Write Message

You can create and send SMS/MMS to a particular contact using this sub-menu.

SMS

A SMS is a text message that can only contain letters, numbers and symbols.

Inbox/Conversations

Inbox sub-menu enables you to view all the messages received on

your Master/ Slave SIM.

Drafts

The created messages can be saved to drafts folder for future use. After selecting a message from the Drafts folder, select Options to edit/delete or send the saved message from the desired SIM.

Outbox

The messages that are not delivered successfully get stored in the outbox folder.

Archive

You can move messages from Inbox, Drafts or Sent messages to archive.

Delete Messages

You can delete the message stored in Inbox, Drafts, Outbox, Sent and Archive messages folder.

Templates

Your phone is provided with some commonly used pre-defined messages.

Message Settings

You can change the MMS settings through this menu.

1. Multimedia Message Data Account: You can set primary account and secondary

account for Master/ Slave SIM.

Common Settings:

 Compose: You can configure Slide time, Creation Mode,

Picture Resizing , auto signature, signature.

 Sending: You can configure Validity period, Delivery Report,

Read Report, Priority, Delivery Time, Send and save.

 Retrieval: You can configure Home network, Roaming, Filters,

Read report and Delivery Report.

 Preferred Storage: You can set phone or memory card for the

preferred storage.

 Memory Status: You can check the usage, used memory and

free memory of phone and memory card.

2. Service Message Enable Push: You can set to accept all, accept authenticate or

trusted or disable. Enable Service Loading: You can set to prompt, auto launch or

disable. Enable White list: You can set discard if unmatched, notify if

unmatched or disable.

White list: You can edit white list.

Broadcast Message

This network service enables you to receive all kind of text messages, such as weather reports or transportation information. There are several networks who afford this service in this world. Please consult your network operator for more reference.

Calculator

Calculator enables you to make basic arithmetic calculations, such as addition, subtraction, multiplication and division. Enter the numbers using on-screen keyboard and choose the desired operator. Use CLEAR to delete the entered numbers and = to get the output.

Internet

To access the Internet menu, enter the Main Menu in the standby mode and then select internet. You can use the network-related services with this function.

STK Services

This service is offered as the SIM card service provided by the network operator.

Data Account

You can use this function to edit the account related settings.

Camera

The phone is provided with a 3.2 MP camera, which supports the photographing and video shooting functions. Pictures are saved in

the file system of the phone or the memory card. You can tap /

to switch between video and camera mode.

Image Viewer

Pictures taken can be accessed quickly through Image viewer. Select Options for available options while viewing pictures.

Time Manager

World clock

Tap Add and choose the desired city. The related date and time will be displayed on the screen.

Clock

The mobile phone provides 5 alarms and you can set them as your need. If you have configured an alarm, an icon indicated that you have configured the alarm will appear.

Stopwatch

You can use the phone as a stopwatch.

Calendar

You can view and edit the memo of a specified date with this function.

Media Player

Media player allows you to play audio and video files. The phone supports T-Flash memory card, wherein you can store your favorite songs and videos. The Play, Stop, Back, Forward functions

correspond to the ( ) buttons respectively, Please press the side key to adjust music volume and press to switch to full

screen.

Warning: Make sure that the volume is appropriate for your hearing while using the audio player.

File Manager

You can browse, open and manage the data saved in the Phone and Memory card by accessing the Storage sub-menu. The phone provides a certain space for users to manage files and supports the T-Flash card. You can use the file manager to conveniently manage various directories and files on the phone and the T-Flash card. Choose Files to enter the root directory of the memory. The root directory will list the default folders, new folders and user files. You can also format both the storage i.e. phone and memory card.

User Profiles

The phone provides seven pre-defined user profiles that allow the operations of the phone to best suit the environment you are in. The profiles are General, Silent, Meeting, Outdoor, Power Saving, Flight Mode and My Style. The phone will automatically enter the headset profile if you connect the headset to your phone.

Settings

Multi SIM Switch

Select with SIM status or Use default mode as desired.

Multi SIM Settings

Select Multi SIM open, Only Master SIM open, Only Slave SIM open as desired.

Pen Calibration

Click any position on the screen to start calibration. Then follow the prompt and operate, as this operation allows the screen to respond more quickly and correctly.

Phone Settings

Time and date

You can set Home City, foreign city, Time/Date, Format and Update with time zone.

Auto Power On / Off

You can set the time for auto power on /off. Do turn the status on before using that function, and then the time.

Language

Select the desired language for the display text.

Input Method

Select the desired input method for the default input method.

Desktop setting

You can select Calendar, Message, Music, Album, Contacts, Notes, Bluetooth, Mode Setting, and so on.

Encoding

You can select ASCⅡ, ISO-8859-1, Windows-1252 and GB2312.

Display

With this function you can configure the basic status of display characteristics including Wallpaper, Screen Saver, Power On Display, Power Off Display, Screen switch effect and so on.

Themes

You can choose themes for your phone as per your choice.

Greeting Text

You can edit the greeting text, If you set the status ON, greetings will display when power ON.

Auto update time

It can be set to On, First confirm and Off. (Network Service).

Keypad light Setting

You can configure the Keypad light's State, Start time and End time.

UART Settings

When using this phone for GPRS, select different UART port to decide whether Master/ Slave SIM to be used.

Misc. Settings

LCD backlight: You can set the LCD backlight.

Font Type/ Font Size

You can configure the Font Type and Font Size.

Security Settings

 Master/Slave SIM Security Settings: You will be asked to

input the PIN. It can be configured if the PIN is correct. If SIM card is set on, you will need to input the PIN every time you switch on the power. If you enter incorrect PIN three times, you will be asked to enter PUK. PUK is used to release and modify the locked PIN. If PUK is not provided or missed, please consult your network operator.

 Phone lock: You can lock or unlock the phone. Enter the

password to activate or deactivate the phone lock. When the phone is locked, you will be asked to enter the phone password. 4-8 numbers can be used for the phone password. The default phone password is 1122.

 Auto keypad lock: You can lock/unlock the phone keyboard

and set the Key Lock Time to Off, 5 sec, 30 sec, 1 min, and 5 min.

 Change password: you can change phone password and

Tracker password.

 Certificate manager: you can manage Auth. Certificate and

User certificate.

Call Settings

Master/ Slave SIM Call Settings

 Call Waiting: Activate, the network will notify you of a new

incoming call while you have a call in progress (Net work Service).

 Call Divert: This network service allows you to divert your

incoming calls to anther number. For details, contact your service provider.

 Call Barring: Activate, this network service allows you to

restrict incoming calls from your phone. For details, contact

your service provider.

 Line Switching: you can switch between Line1 and Line2.

Advanced settings

 Blacklist: When this Black list is enabled, you won’t receive

the calls from the numbers entered in the Blacklist.

 Whitelist: You can set 20 numbers. When this white list is

enabled, you can but receive the calls from the numbers entered in the white list.

 Auto redial: On, the phone will automatically redial the last

dialed number after a while if you fail to connect to the number. Press Abort to end Auto Redial.

 Background sound: Set the background sound during

calling.

 Call Time Reminder: This function prompts you to end the

call in time to save the call cost. You can select Off, Single, or Periodic.

 Auto quick end: You can set ON/ OFF, and set a time

(1~9999s) as your desire.

 Reject by SMS: On. If you get an incoming call at an

inconvenient time, tap the Mute > Message, and then you can send a message to the caller.

 Answer mode: You can set Any key or Auto answer when

headset mode.

Restore Factory Settings

All settings can be restored to factory settings with this function. The default password is 1122.

Network Settings

You can set the options of Master SIM network settings, Slave SIM network settings and preferred mode.

Master/ Slave SIM network settings

 Network Selection: You can choose Automatic or Manual to

select the network (Auto is recommended). When you select Automatic, the phone will make the preferential selection according to the network where the SIM card belongs. When you select Manual, you are required to select the same

network as the registered network with the network operator by SIM card for your use.

 Preferences: you can add from list or create new.

Preferred mode

Select GSM only, Wi-Fi only, GSM preferred, Wi-Fi preferred as desired.

FM Radio

You can use your phone to listen to FM radio stations once the original Headset is plugged into the connector. Please press the

side key to adjust music volume. Tap the ( ) to play/stop the FM radio. Tap the ( ) to search the channels. Tap the ( ) to

record the FM radio.

Organizer

Unit Converter

You can convert the units for weight and length. Enter the number into the column, and then press OK to get the result.

Currency Converter

You can make currency conversions. Press ok after enter the exchange rate, and then enter the number of the currency, and press ok to get the result.

Tasks

You can View, Add, Edit, Search, Delete, Delete overdue, Delete All, Jump to date, View uncompleted, Send Calendar and Save as file as desired. Start up the Memo and tap done. Tap Options to access the next step to add a new memo.

Notes

You can View, Edit, add a new note, Mark several, and Delete as desired.

Phonebook Backup

You can export or import UDX file by UDX agent, Please refer to “Help” for more details.

Ebook reader

You can read E-book with “*.TXT” format which saved in your memory card.

Bluetooth

You can transfer data, such as music to other device using Bluetooth. Search the device and accept/transfer data. The received data is automatically stored in the directory.

Google

You phone also provide you interesting applications. Most of them need the network support. Please contact with your dealer and your network operator for more information.

Wi-Fi

You can access Wireless Application Protocol (WAP) sites and use WAP-based services on your phone. To access WAP sites, you need to subscribe to the service from your service provider and set the relevant parameters on your phone. From the Home screen, go to Main menu > WLAN to access wireless controls and turn Wi-Fi on or off.

To connect to a Wi-Fi network

Tap Wi-Fi, choose a network and select connect. If required, please enter the password and tap connect. (Networks that require a

password appear with a lock icon. .)

To add Wi-Fi network

From Home screen, go to Main Menu > WLAN > Options > Add, a new window is displayed. Follow the on-screen instructions and enter necessary information, then click Done to store settings.

Fun & Games

Java

You may download the latest Java games and applications from the Internet. You can view the details of installed games or applications, remove them form your device, and specify installation settings.

Warning: Only install and use applications and other software from trusted sources.

Java Settings

This function includes settings of Java Audio, Java backlight, Java vibration, and so on. You can configure those options as desired.

Java Default Security

There are 4 options you can set: Third Party, Untrusted domain, Restore default and Domain options. For Third Party and Untrusted domain, you can define which functions the Java application can access. The value that you can set for each functionally depends on the protection domain of the software package.

 Network access: Create a data connection to the network  Auto Invocation: Open the application automatically.  Messaging: Send messages.  Multimedia: Capture images or record videos or sound.  Read user data: Read your calendar entries, contacts, or any

other personal data.

 Write user data: Add personal data, such as entries to Contacts.  Local connectivity: set Prompt at first, Prompt once, Never,

Prompt always.

After you finished settings, please tap OK to save.

Games

The phone provides an interesting game. You can set BGM, sound effect, vibration and volume by accessing Games settings.

Answer Machine

You can configure the Auto answer, Storage, Pick up time, Record duration, Greeting file and Remote access.

NTV

Draw out the antenna in the top right corner of the phone.

States Icons:

Indicates the network signal strength of TV.

Full screen Adjust the volume

Adjust the Channel Auto Scan Program List

Options

Press the to access these options as below:

1. Set Region: to choose your area/city.

2. Input Channel: to get into the function of manual search.

3. Program List: to pick up a channel.

4. Auto Scan: to preset list.

5. Full Screen: to switch full screen.

Opera

Opera Mini is a fast and compact web browser that allows you to access the Internet on your phone. With Opera Mini, you can use your cell phone to access web sites and content, including your mail, community sites, news, blogs and more.

Your phone can send and receive e-mails. You can configure POP3/SMTP protocol based email accounts on your handset.

Sound Recorder

The mobile phone supports WAV, AWB and AMR recording formats. You can record conversations, which can be saved to the Audio folder under File Manager.

Note: GPRS should be activated from the operator side and also in the SIM Card

APPENDIX

Appendix A: Troubleshooting

This section lists some problems that you might meet while using your phone. If you feel that your phone do not operate normally, please reset settings first, and then follow Troubleshooting Guide. If you are still unable to solve problems, please contact the authorized service center or the store from where you purchased the phone.

Problems Solutions

Can not

answer or

make a call

Make sure that the phone has been switched on. Make sure that the battery is charged. Make sure that the signal intensity is high enough. Make sure the own number function in the call setting is system preset or number sending. Make sure the line switch in call setting is the system preset line. Check whether you have set up call barring or fixed dialing or any other safety function. Check whether you have set up call diverts. Check whether you have inserted the proper SIM card correctly.

Low voice Check if the volume has been set too low.

No ring

Check whether you have set up the” Silent” option. Check whether the ring volume is not too low Move away from a noisy place to check if you can hear the phone ringing. Check whether you have set up call diverts.

LCD unclear

Check whether the contrast has been set too low.

T-Flash card detect slowly

Format your T-Flash card with your phone. Note: To protect your files from getting lost,

please backup the important information into the safe place before you formatting card.

Singtech SGT-T600 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
