Accuracy:
Movement:
Suspension:
Tracking:
Shielding:
Response Time:
Overload (1 sec.):
Overload (Continuous):
Repeatability:
Dial:
Case:
Resistance:
Operating Temperature:
Pointer:
Scale Length:
Net Weight:
±3% F.S. AC Rectified, ±2% for DC or Annular
Annular rectifier, self-shielding
Pivot and jewel
±3%
Calibration is unaffected by magnetic panel
mounting.
1.5 seconds maximum
10 times F.S.
1.5 times F.S.
2%
Sharp clear scale. Each dial arc is calibrated to
track the specific type of movement used.
Metal shielded cover with black matte finish
±15% of meter impedance
-4°F to +149°F (-20°C to +65°C)
Knife-edge with black matte finish
Models 3323, 3343: 2.74" (70.0mm)
Models 3324, 3344: 4.05" (103.0mm)
Models 3323, 3343: 12oz (0.340kg)
Models 3324, 3344: 17oz (0.48kg)
Specifications
• Rugged metal case for rigorous
environments
• Splash-proof and sealed against moisture,
dust and dirt
• Calibration not affected by steel panel
mounting
• O-Ring sealed zero adjust and electrical
terminals
Dimensions
3 - 1/2”-Model 3323, 3343
4 - 1/2”-Model 3324, 3344
