Page 1
Refrigeration
Use & Care
User Manual
SSM6100WB, SSM6100MB
SBM4300WB, SBM3800MB, SBM3800WB
STM3900WB, STM3900MB
Page 2
2 quick start quide / contents Simpson Refrigeration
Congratulations and thank you for choosing our refrigerator. We are
sure you will find your new refrigerator a pleasure to use. Before you
use the refrigerator, we recommend that you read through the entire
user manual, which provides the description of the refrigerator and
its functions.
To avoid the risks that are always present when you use an electric
appliance, it is important that the refrigerator is installed correctly
and that you read the safety instructions carefully to avoid misuse
and hazards.
We recommend that you keep this instruction booklet for future
reference and pass it on to any future owners.
After unpacking the refrigerator please check it is not damaged. If in
doubt, do not use the refrigerator but contact your local Electrolux
Customer Care Centre.
Information on disposal for users
• Most of the packing materials are recyclable. Please dispose of
those materials through your local recycling depot or by placing
them in appropriate collection containers.
• If you wish to discard this refrigerator, please contact your local
authorities and ask for the correct method of disposal
Simpson quick start guide
1. Ensure appliance is on a flat surface.
2. Leave standing in stable upright position for half an
hour prior to turning ‘on’.
3. Plug into power socket and turn on.
4. Temperature controls are pre-set to ‘mid’ adjust
as required.
5. Leave run for 2 – 3 hours before storing food.
For optimum usage, safety information and handy
hints please read full document.
Important safety instructions 3
Installing your new refrigerator 4
Side by Side model features 6
Top and Bottom Mount model features 7
Refrigerator & freezer operation 8
Controlling the temperature 8
Using your refrigerator 10
Changing the light bulb 10
Cleaning your refrigerator 11
Energy consumption 11
Safety 12
Helpful hints 12
Troubleshooting 13
Notes 14
Warranty 15
Congratulations Contents
Page 3
Simpson Refrigeration safety instructions 3
Please read the user manual carefully and store in a handy place for
later reference.
The symbols you will see in this booklet have these meanings:
This symbol indicates information concerning your
personal safety
This symbol indicates information on how to avoid
damaging the appliance
This symbol indicates tips and information about
use of the appliance
This symbol indicates tips and information about economical
and ecological use of the appliance
Meanings of symbols used in this manual are shown below:
This symbol indicates never to do this
This symbol indicates always do this
• If pressurised aerosol containers bear the
word ‘flammable’ and/or a small flame
symbol, do not store them inside any
refrigerator or freezer. If you do so you may
cause an explosion.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
• Children should be supervised to ensure that they do not
play with the appliance.
• When you dispose of your old refrigerators and freezers,
remove any doors. Children can suffocate if they get
trapped inside.
• This appliance contains insulation formed with ammable
blowing gases. Avoid safety hazards by carefully disposing of
this appliance.
Important safety instructions
The appliance must be plugged into its own dedicated
220-240V, 50Hz AC electrical outlet.
Ensure that the electric outlet is properly earthed
to ground. Consult a qualified electrician if you are
unsure.
Do not use an extension cord or adapter plug.
If the power cord is damaged, it should be replaced by
a service technician or a qualified person.
Unplug the appliance before cleaning and before
changing the light bulb to avoid electric shock.
Never unplug the appliance by pulling on the power
cord. Always grip the plug firmly, and pull straight out
of the receptacle to prevent damaging the power cord.
Choose a location that is not too cold - the
temperature should be above 10°C.
Put the appliance in a dry place, avoiding areas of high
moisture or humidity.
Don’t put the appliance in frosty or unprotected areas,
for example in a garage or on a verandah.
Don’t put the appliance in direct sunlight.
Don’t put the appliance near stoves, fires or heaters.
When correctly installed, your appliance should:
• have adequate clearance to the back and sides for air
circulation (refer to page 4).
• be aligned to the surrounding cupboards.
• have doors that will self-close from a partially
open position.
• Have the stability foot in place (see diagrams on pages 4 and 5) to
prevent the appliance falling forward when a door with heavy food load
is opened.
Page 4
4 installing your refrigerator Simpson Refrigeration
Installing your refrigerator
The appliance should arrive with the
front adjustable rollers wound down to
tilt the top of the refrigerator backwards
by about 10 -15mm from upright.
The stability foot should also be wound
fully up so it will not interfere with the
operation of the rollers (see diagram
in Step 3 below).
The rollers are designed for forward or backward
movement only. They are not castors. Moving the
refrigerator sideways may damage your floor and
the rollers.
1. Roll the refrigerator into its final position.
2. The top of the refrigerator should be tilted back by approximately
10 -15mm. This will allow the doors to self-close providing a
consistent door seal.
3. If the refrigerator is not tilted back, you can adjust the two front
rollers by turning the large, plastic roller nut (see diagram below).
This will increase the height of the rollers. One turn of the nut
will tilt the refrigerator back approximately 10mm. If you have
difficulty turning the roller nut you can have someone tilt the
refrigerator back, so that you have better access. Alternatively, you
can access the rollers from the side, using a flat screwdriver to
help you turn the nut (see diagram below).
4. Check the alignment of the refrigerator to the surrounding
cupboards. The top of the refrigerator should be level from side
to side (see diagram below). If you need to adjust the level, use
the adjustable rollers as discussed in Step 3.
Installing your new refrigerator
Clearance around your Side by Side refrigerator
Your Side by Side Refrigerator can be installed between
cupboards or fixtures but you must allow for the following
spaces around the cabinet.
1. Allow a minimum of 5mm clearance on both sides.
2. Allow 10mm clearance at the back of the refrigerator.
3. Allow a minimum of 10mm clearance above hinge covers.
4. If you do not have a cupboard with a rear gap, the
recommended clearance area on top increases from
50mm to 90mm (x) and from 32mm to 72mm (y).
5. Allow a 250 or 300mm clearance on the hinge side of the
doors, if you place the refrigerator next to the wall. This will
make cleaning easier.
6. Make sure that cupboards or xtures do not stick out further
than the refrigerator cabinet.
Clearance around your Top and Bottom Mount refrigerator
1. Allow a minimum of 5mm clearance on both sides.
2. Allow 10mm clearance at the back of the refrigerator.
3. Allow a minimum of 10mm clearance above hinge covers.
4. If you do not have a cupboard with a rear gap, the recommended
clearance area on top increases from 50mm to 90mm.
5. When positioned in a corner area, spacing of at least 350mm on
the hinge side will allow the doors to open enough to enable the
removal of bins and shelves.
Note: Doors on all models are designed to sit proud of cabinetry (not flush). The
refrigerator should be placed against a wall and the gap between the rear
of the refrigerator and the wall should be no greater than 75mm.
90mm
50mm
30mm
30mm
Recommended
airspace
CABINET
DOOR
350mm
10-15mm
Fixed rea
r
rollers
Height adjustable
front rollers
Top of refrigerator
is level ie. horizontal
Adjust front rollers
for uneveness of floor
eg. wind this roller
down or up
Aligned to
cupboards
ie. even gap
Stability foot
wound up
Large plastic
roller nut
10mm
5mm
5mm
Recommended
airspace
CABINET
DOORS
(y)
(x)
10mm
5mm
5mm
Recommended
airspace
CABINET
DOORS
(y)
(x)
Freezer
Door
Fridge
Door
250mm
300mm
Page 5
Simpson Refrigeration installing your refrigerator 5
5. If the refrigerator now rocks from one corner to the opposite
rear corner, this means that the floor is uneven; you will need to
put some packing under one of the rear rollers. You could use
thin pieces of solid material, such as thin board, vinyl floor tiles or
laminate. Place the packing so that it will sit under one of the rear
rollers when the refrigerator is rolled into position.
6. You may now need to fine-tune the installation by repeating
Steps 3, 4 and 5.
7. When you have the appliance in its nal position, it needs to be
stabilised. Wind the stability foot down to the floor until it just
makes contact with the floor. Lift the front of the appliance to
take the weight off the stability foot, then turn it ¼ turn further
to ensure firm contact with the floor. Whenever you need to
move the appliance, be sure to wind the foot back up so that the
appliance can roll freely and be sure to reset it when reinstalling.
Whenever you need to move the refrigerator, be sure to wind the
foot back up so that the refrigerator can roll freely.
8. Clean your refrigerator thoroughly following the instructions
on page 11 and wipe off any dust that has accumulated
during shipping.
9. Plug the refrigerator into the power point. Don’t use a double
adaptor. If you need to roll the refrigerator out to get at the
power point, remember to raise the stability foot before you
do so.
10. We recommend that you let your refrigerator run for two
to three hours before you put any food in it. This will allow
you to check that it is operating properly.
Congratulations! You have successfully installed your
new refrigerator.
Keep ventilation openings, in the appliance enclosure
or in the built-in structure clear of obstruction.
Adjusting door alignment – Side by Side refrigerator only
Each door is independently adjustable in the vertical direction by
turning the adjustable bolts under the hinges using a spanner.
The doors can be adjusted up or down. Depending on
the amount of adjustment required it may be sufficient
to adjust only one door. (see Diagrams below)
Note: When the height of the rollers and adjusting bolts are correctly adjusted the
refrigerator will stand firmly on the floor then adjust door alignment as required.
Large plastic roller nut
Front Roller
Adjusting Bolt
Stabilising
foot wound
down
side view
front view
¼ turn
Page 6
6 side by side model features Simpson Refrigeration
Side by Side model
Note: Product illustrations demonstrate various features but may not be completely in line with current products.
1 6
2
3
15
8
7
9
10
11
13
13
12
14
1 Freezer air outlets
2 Adjustable freezer door bins
3 Adjustable spill safe slide-out glass shelves
4 Freezer air returns
5 Freezer roll out basket
6 Temperature controls
7 Dairy bin
8 Fridge light
9 Adjustable fridge door bins
10 Adjustable spill safe slide-out glass shelves
11 Fridge air return vent
12 Crisper humidity control
13 Bottle bins
14 Crisper
15 Adjustable rollers
Side by Side model features
4
5
Page 7
Simpson Refrigeration top and bottom mount model features 7
1 Freezer air outlets
2 Wire shelves
3 Freezer air returns
4 Fridge air outlets
5 Temperature controls
6 Glass shelves
7 Crisper humidity control
8 Crisper divider (where tted)
9 Full width crisper (where tted)
10 Adjustable rollers
11 Full width freezer door bins
12 Dairy compartment
13 Half width door bins
14 Full width door bins (two bins on selected models only)
15 Stabilising foot
16 Fridge light
Bottom Mount model additional features
17 Freezer basket
Top Mount model Bottom Mount model
Note: Product illustrations demonstrate various features but may not be completely in line with current products.
14
14
8
13
1 11 1312 4
2
4
5
16
6
7
8
9
10 1015 1514
12
16
5
1
2
7
9
3
17
6
3
Top and Bottom Mount model features
Page 8
8 refrigerator and freezer operation Simpson Refrigeration
The refrigerator transfers heat from food placed inside the appliance
to the outside air.
This process makes the rear, the sides and the area
adjacent to the doors, particularly at initial start up, feel
warm. This is normal.
There is a cooling coil located behind the rear wall of the cabinet.
This coil cools and removes moisture from the air. A fan then
circulates cold, dry air throughout the cabinet.
This air circulation means that foods are refrigerated far more quickly
than in refrigerators where the air remains relatively static.
Avoid placing food against air outlets as this will affect
air circulation.
A light frosting will occasionally occur on the cold interior of the
freezer when the door is opened frequently. This is normal and will
disappear after a few days in most climates.
Make sure you fully close the freezer door after you load or remove
food. If the door is left partly open, a heavy frost will coat the inside of
the freezer. If a frost develops, remove it. Take care to properly close
the door and the frost will not reoccur. If the food is placed forward
of the ribs on the bottom of the freezer, it will keep the door open.
Ensure that all food is stored behind the ribs.
Your new energy efficient appliance uses a high-speed compressor and
other energy efficient components that may produce different noises
to your old appliance.
These sounds are normal and include:
• compressor running noise.
• air movement noise from the small fan motor.
• occasional gurgling, similar to water boiling.
• a popping noise, heard during automatic defrosting.
• a clicking noise, just prior to the compressor starting up.
These noises are normal and not cause for alarm.
Further details can be found on page 13.
Set the temperature by using the main temperature controls at the
rear of the refrigerator compartment. When you first start your
refrigerator, set both refrigerator and freezer controls to MID. The
refrigerator temperature control is affected by altitude and it is
recommended that it be set warmer to compensate. e.g. at 1000
metres above sea level set the refrigerator temperature control
to one setting warmer than MID.
A good indication of optimal freezer temperature is ice cream
that is frozen, but still soft enough for easy scooping.
For the fridge compartment, we recommend using drinking water
and simply adjusting the fridge controls until the water is at your
ideal temperature.
To change settings. When you change temperature settings, make small
adjustments and wait 24 hours before assessing whether you need to
make any further changes.
Side by Side temperature control
Adjusting the refrigerator temperature – side by side model
1. Select the refrigerator control (right knob).
2. Rotate the knob clockwise to set colder.
3. Rotate the knob anti-clockwise to set less cold.
Adjusting the freezer temperature – Side by Side model
1. Select the freezer control (left knob).
2. Rotate the knob clockwise to set colder.
3. Rotate the knob anti-clockwise to set less cold.
Refrigerator and freezer operation Controlling the temperature
less cold
colder
freezer
mid
fridge
colder
less cold
mid
Ribs
less cold
colder
mid
fridge
Page 9
Simpson Refrigeration controlling the temperature 9
The refrigerator temperature control is affected by altitude
and is recommended that it be set warmer to compensate.
e.g. at 1000 metres above sea level set the refrigerator temperature
control to one half setting warmer than MID.
Wait 24 hours after changing settings: When you change
temperature settings, make small adjustments and wait 24 hours
before assessing whether you need to make any further changes.
NB: Testing ice cream is a good way to check the freezer temperature.
Testing drinking water is a good way to check the refrigerator
compartment temperature.
• Coldest freezer setting is not recommended in normal and
very hot climates as this will limit the cooling to the
refrigerator section.
• In very cold climates (where temperatures are below 10°C)
the freezer may need to be set colder.
• Adjustment of the fridge compartment temperature may cause
a small movement in freezer temperature.
Chill Channel – Side by Side model only
The chill channel allows air to circulate through your refrigerator. For
optimum cooling, keep the channel behind your shelves clear.
Try to avoid storing plates, trays or any object that may extend beyond the
back edge of your shelves. Doing so may block the cold air ow from
the vents located in the control housing, causing uneven temperatures in
your refrigerator. This may also freeze items stored on the top shelf.
Top Mount temperature control
Adjusting the refrigerator temperature – Top Mount
freezer (TM) model
1. Select the refrigerator control (bottom knob).
2. Rotate the knob clockwise to set colder.
3. Rotate the knob anti-clockwise to set less cold.
Adjusting the freezer temperature – Top Mount
freezer (TM) model
1. Select the freezer control (top knob).
2. Rotate the knob clockwise to set colder.
3. Rotate the knob anti-clockwise to set less cold.
Bottom Mount temperature control
Adjusting the refrigerator temperature – Bottom Mount
freezer (BM) model
1. Select the refrigerator control (top knob).
2. Rotate the knob clockwise to set colder.
3. Rotate the knob anti-clockwise to set less cold.
Adjusting the freezer temperature – Bottom Mount
freezer (BM) model
1. Select the freezer control (bottom knob).
2. Rotate the knob clockwise to set colder.
3. Rotate the knob anti-clockwise to set less cold.
colder
less
cold
mid
fridge
colder
less
cold
colder
less
cold
mid
fridge
freezer
mid
less cold
colder
mid
fridge
less cold
colder
colder
less cold
freezer
mid
mid
fridge
Page 10
10 using your refrigerator / changing the light bulb Simpson Refrigeration
Changing the light bulb Using your refrigerator
This section tells you how to make the most of the many useful
features and how to clean them.
Door storage bins
Both refrigerator and freezer are fitted with door storage bins. You
can adjust the refrigerator bins to meet different storage needs. All
the door bins are completely removable for cleaning. If you want to
remove or adjust a bin, lift it over the support lugs on the inner door
panel. To replace, push the bin down over the support lugs to lock it
in place.
Crisper bin
You can use the crisper bin to store vegetables, fruit or smallgoods.
You can change the humidity inside the bin by sliding the
humidity control.
• Storing vegetables
You should store vegetables in the crisper bin remembering to set
the humidity control to more humid (closed).
• Storing fruit & smallgoods
You can also store fruit & smallgoods in the crisper bin remembering
to set the humidity control to less humid (open).
Changing the light bulb – Side by Side fridge
1. Switch off the power at the power point and remove the
refrigerator’s power cord from the power point.
2. Carefully unclip the light cover. You do this by inserting your
fingers behind the top of the light cover and pulling it out while at
the same time pushing it up at the bottom.
3. Pull the cover out until it is clear of the housing.
4. Unscrew the light bulb and replace it with a bulb that is the same
as the original.
5. Replace the cover by inserting the tab back into place and pushing
in the cover with both hands at the top.
6. Wait 5 minutes to ensure pressures in the refrigeration system
are equalized. Then reconnect and turn the refrigerator on at the
power point.
Changing the light bulb – Top and Bottom Mount fridge
1. Switch off the power at the power point and remove the
refrigerator’s power cord from the power point.
2. Carefully unclip the light cover. You do this by pushing the light
cover tabs at the front towards the back of the cabinet, then
lowering the cover down.
3. Unscrew the light bulb and replace it with a bulb that is the same
as the original, as specified on the rating plate behind the cover.
4. Replace the light cover by hooking the light cover lugs into the
rear of the housing and pressing the front of the cover until it
clips in.
5. Wait 5 minutes to ensure pressures in the refrigeration system
are equalized. Then reconnect and turn the refrigerator on at the
power point.
Push Push
PullPull
Ta bTab
PushPush
Page 11
Simpson Refrigeration cleaning your refrigerator / energy consumption 11
Energy consumption (electricity costs)Cleaning your refrigerator
Before cleaning: Turn appliance off at the power point, then
remove power cord from socket. This will make sure
there is no chance of getting an electric shock.
Doors and exterior
You should only clean the doors with lukewarm soapy water and a
soft cloth, rinsing with clean water and then wipe the surface with
clean water and a soft clean cloth to remove soap residue.
Do not use stainless steel cleaners, abrasive pads or
other cleaners as they are likely to scratch the surface.
Damage to this product after delivery is not covered
by your warranty.
Interior
You should clean the appliance interior regularly. It will be easiest to
clean when the food supply is low. Wash the interior with a soft cloth
and use an unscented mild soap with luke-warm water. Thoroughly
dry all surfaces and removable parts. Avoid getting water on appliance
controls. If you have taken out any removable parts, replace them and
switch the power on before re-stocking the appliance with food.
Naturally, you should keep the interior of your appliance hygienic by
promptly and thoroughly wiping up any food spills.
Door seals
Take care to keep door seals clean. Sticky food and drink can cause
seals to stick to the cabinet and tear when you open the door. Wash
seal with a mild detergent and warm water. Rinse thoroughly and dry.
Never use hot water, solvents, commercial kitchen
cleaners, aerosol cleaners, metal polishes, caustic or
abrasive cleaners, or scourers to clean this appliance, as
they will damage it. Many commercially available cleaning
products and detergents contain solvents that will
damage your refrigerator. When cleaning, use only a soft
cloth with an unscented mild soap and lukewarm water.
The following guide will help you reduce the running cost of your new
refrigerator. This will save you money and help conserve our valuable
energy resources.
1. If you keep your old refrigerator, save power by switching it off
when not in use.
2. Do not set your freezer temperature too low. After 24 hours, ice
cream should be firm but able to be scooped out with a spoon
without bending the handle. If ice cream is rmer than this (or too
soft), adjust the freezer temperature controls (see ‘Temperature
control’, page 8).
3. Ensure that the refrigerator doors seal properly as
you close them.
4. Before you open the refrigerator doors, decide what you want
to put in or take out. This will minimize the time you have the
doors open.
5. It is best to have the refrigerator in a place that is out of direct
sunlight and away from heating appliances of any kind. For
example, do not place the refrigerator next to a cooker, stove
or dishwasher.
6. Allow hot foods to cool to room temperature before you put
them in your freezer.
7. Thaw frozen food in the refrigerator section.
8. If you keep the freezer compartment filled to capacity, your
food mass will help maintain the freezer temperature when you
open the door.
9. Do not block air vents. Doing so may cause the refrigerator to
run longer and use more energy.
Turning off the refrigerator
If you are leaving for a short holiday, there is no need to turn off
your refrigerator .
If you are going on a long holiday and want to turn the refrigerator
off, follow the steps below.
1. Take all the food out of the refrigerator and freezer
compartments.
2. Switch off the refrigerator and remove the electric cord from
the power point.
3. Clean the inside.
4. Leave the doors open. This prevents bacteria from growing and
causing smells in the refrigerator.
Power failure
If there is a power failure in your area, keep the door to the freezer
closed. Most foods in your freezer will stay frozen for 24 hours.
Page 12
12 safety / helpful hints Simpson Refrigeration
Safety
It is important to use your appliance safely. This means you need to
supervise young children and infirm persons when they use it. You
need to make sure that young children do not play with the appliance.
Follow the tips below.
Always do this
Check the power point is properly grounded –
if you are not sure get an electrician to check it.
Switch off the appliance at the power point before you
clean or move it.
If the supply cord is damaged you should have
it replaced by the manufacturer, it’s service agent
or similarly qualified person. This will prevent a
safety hazard.
Never do this
Never let children play with the appliance.
Never store spray cans, explosive liquids or flammable
liquids in the refrigerator.
Never store fizzy drinks in the freezer compartment.
Never lick icy foods when they first come out of the
freezer. This can freeze burn your lips and mouth.
Never try to repair the appliance yourself.
Never use electric heaters or dryers to defrost the
freezer because you can receive an electric shock.
Never use electrical appliances inside the food
storage areas.
This appliance contains insulation formed with
flammable blowing gases. For safety reasons,
take care when you dispose of it.
Do not damage the appliance circuit.
When you dispose of your old refrigerator or freezer,
remove any doors. Children can suffocate if they get
trapped inside.
Helpful hints for storing food
Always do this
Buy the freshest, best quality food and put it in the
refrigerator as soon as possible.
Cover food with plastic wrap or foil to stop it drying
out and to help prevent bad smells.
Rinse and wrap fish and poultry before you put them
in the refrigerator.
Minimise bacteria by removing stuffing from
poultry before you put it in the refrigerator.
When you store eggs in the refrigerator compartment,
store them with the pointed end down.
Never do this
Store bananas, avocados or mangoes in the
refrigerator. This can cause them to go black
or to go soft.
Put hot or warm food in the refrigerator.
Allow it to cool first.
Helpful hints for freezing food
You can use the freezer to store food which you buy in bulk when
prices are low. You can also cook extra food and freeze it for later use.
Always do this
Buy the freshest, best quality food and put it in the
freezer as soon as possible.
Place food in plastic bags or plastic wrap before
you put it in the freezer.
Squeeze the air out of plastic bags as this
prevents frost.
When you buy frozen foods in the supermarket,
keep them in their packaging when you store them.
Defrost food, especially chicken and fish, in the
refrigerator compartment. This stops bacteria
from growing.
Leave food in its wrapping while it defrosts.
Use defrosted food immediately.
Never do this
Never refreeze defrosted food.
Helpful hints
Page 13
Simpson Refrigeration troubleshooting 13
If you think something may be wrong with your refrigerator, you can carry out some easy checks before calling for service.
You may locate the problem, sparing yourself from inconvenience and saving time and money.
Problem
Solution
When your appliance
is not operating
• Check that the power cord is plugged into the power outlet properly and that the outlet is switched ‘ON’.
• Try running another appliance from the power outlet. If no power is coming from the outlet you may have blown a fuse
or tripped a circuit of your household power supply.
• Try adjusting the temperature control to a slightly “colder” position.
• It is normal for the freezer fan NOT to operate during the automatic defrost cycle, or for a short time after the appliance
is switched on.
When there
is refrigerator/
freezer noise
Modern refrigerators/freezers with increased storage capacity use high speed compressors. These can provide a seemingly
high level of sound which is quite normal. Normal operational sounds include:
• Occasional gurgling, similar to water boiling.
• Air ow noise (air circulates because of a small fan).
• A popping noise heard during automatic defrost.
Other strange sounds may mean that you need to check and take action. For example, noises may mean that:
• The cabinet is not level.
• The oor is uneven or weak.
• Bottles are badly placed and rattling.
• There are vibrations from an object on top of or behind or beside the refrigerator.
• The back of the refrigerator cabinet is touching the wall.
Remember it is quite normal for noise to seem louder just after the refrigerator starts operating.
If there are
odours inside
the appliance
• The interior may need cleaning.
• Some foods produce odours.
• Some containers and wrapping can cause odours.
• Ask yourself if the odour started about the same time you started storing something unusual.
When the motor
seems to run more
than expected
Your new appliance provides you with large capacities in both the refrigerator section and the separate freezer. It is normal
for the motor to operate frequently. However, to keep operation to a minimum, check the following:
• Are doors kept open too long or too often?
• Are controls set too cold? Refer to page 8 “Temperature control”.
• Have large amounts of warm food just recently been stored? Summer, festive seasons and holidays usually mean a lot more
work for your appliance.
• If the day is hot or the room is very warm, the appliance will need to run more than normal.
• The appliance will run more than normal just after you install it or when it has been turned off for a long time.
If the temperature in
the refrigerator is too
warm
• Check that the appliance has enough clearance at the sides, back and top. Refer to page 4 “Installing your new refrigerator”.
• Refer to page 8 “Temperature control”.
• You may have kept the door open too long or too frequently.
• Food containers or packaging may be holding a door open.
If the temperature in
the refrigerator is too
cold
• Refer to page 8 “Temperature control”.
• Increase the temperature to avoid high energy consumption.
If heavy frosting
occurs in the freezer
Make sure you fully close the freezer and fridge doors. If the doors are left partly open a heavy frost will coat the inside of the
freezer. If a frost develops, remove it. Take care to properly close the doors and the frost will not reoccur.
If water drips
on the floor
The defrost water tray, (located on the compressor at the back of the cabinet), may not be properly positioned, or the drain
tube may not be properly positioned to direct water into this tray. You may need to pull the refrigerator away from the wall
to check the tray and tube.
If you still require service
If you have a problem, and the problem persists after you have made the checks mentioned above, contact your nearest Electrolux approved
Service Centre or the dealer you bought the refrigerator from. Be ready to quote the model number, 9-digit PNC and 8-digit serial number,
which is stated on the label inside the refrigerator compartment.
Troubleshooting
Page 14
14 notes Simpson Refrigeration
Notes
Page 15
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
APPLIANCE: SIMPSON TOP MOUNT FREEZER
This document sets out the terms and conditions of product warranties for
Electrolux branded appliances. It is an important document. Please keep it
with your proof of purchase documents in a safe place for future reference
should you require service for your Electrolux appliance.
General Terms and Conditions
1. In this warranty
(a) ‘Electrolux’ means Electrolux Home Products Pty Ltd ABN 51 004 762 341 in
respect of Appliances purchased in Australia and Electrolux (NZ) Limited in respect
of Appliances purchased in New Zealand;
(b) ‘Appliance’ means any Electrolux product purchased by you accompanied by this
document;
(c) ‘Warranty Period’ means
(i) where you use the Appliance for personal, domestic or household purposes
in Australia the period of ‘24’ months and in New Zealand the period of ‘24’
months;
(ii) where you use the Appliance for commercial purposes, in Australia the period
of ‘3’ months and in New Zealand the period of ‘3’ months, (if the period stated
is 0 months you are not covered by this product warranty) following the date of
original purchase of the Appliance;
(d) ‘you’ means the purchaser of the Appliance not having purchased the appliance for
re-sale, and ‘your’ has a corresponding meaning.
2. This warranty only applies to Appliances purchased and used in Australia or
New Zealand and is in addition to (and does not exclude, restrict, or modify in any way)
any non-excludable statutory warranties in Australia or New Zealand.
3. Electrolux warrants that, when dispatched from an Electrolux warehouse,
the Appliance is free from defects in materials and workmanship for the
Warranty Period.
4. During the Warranty Period Electrolux or its Authorised Service Centre will, at no extra
charge if your appliance is readily accessible without special equipment, and subject to
these terms and conditions, repair or replace any parts which it considers to be defective.
You agree that any replaced Appliances or parts become the proper ty of Electrolux. This
warranty does not apply to light globes, batteries, filters or similar perishable parts.
5. Parts and Appliances not supplied by Electrolux are not covered by this warranty.
6. Where you are within an Electrolux service area, this warranty covers the cost of
transport of the Appliance to and from Authorised Ser vice Centres of Electrolux and
travelling costs for representatives of the Authorised Service Centre to and from your
home or business. If you are outside an Electrolux ser vice area, you will bear these costs.
For information about whether you are within an Electrolux service area, please phone
13 13 49 in Australia, or 0800 10 66 10 in
New Zealand.
7. Proof of purchase is required before you can make a claim under this warranty.
8. You may not make a claim under this warranty unless the defect claimed is due to faulty
or defective parts or workmanship. Electrolux is not liable in the following situations
(which are not exhaustive):
(a) The Appliance is damaged by:
(i) accident
(ii) misuse or abuse, including failure to properly maintain or service
(iii) normal wear and tear
(iv) power surges, electrical storm damage or incorrect power supply
(v) incomplete or improper installation
(vi) incorrect, improper or inappropriate operation
(vii) insect or vermin infestation.
(b) The Appliance is modified without authority from Electrolux in writing.
(c) The Appliance’s serial number or warranty seal has been removed
or defaced.
(d) The Appliance was serviced or repaired by anyone other than Electrolux or its
Authorised Service Centres.
9. This warranty, the contract to which it relates and the relationship between you and
Electrolux are governed by the law applicable in the Australian State where the Appliance
was purchased or the law applicable in New Zealand if the Appliance was purchased in
New Zealand. Where the Appliance was purchased in New Zealand for business purposes
the Consumer Guarantee Act does not apply.
Limitation of Liability
10. To the extent permitted by law:
(a) Electrolux excludes all warranties other than as contained in this document;
(b) Electrolux shall not be liable for any loss or damage whether direct or indirect or
consequential arising from your purchase, use or non-use of
the Appliance.
11. Provisions of the Trade Practices Act and State consumer legislation in Australia, and the
Consumer Guarantees Act, the Sale of Goods Act and the Fair Trading Act in New Zealand,
imply warranties or conditions, or impose obligations, upon Electrolux which cannot be
excluded, restricted or modified. To the extent permitted by law, the liability of Electrolux (if
any) arising out of or in relation to the Appliance or any services supplied by Electrolux shall
be limited (where it is fair and reasonable to do so),:
(a) in the case of Appliances, at its option, to the replacement or repair of the Appliances
or the supply of equivalent products or the payment of the cost of replacing the
Appliances or having the Appliances repaired or of acquiring equivalent Appliances.
Upon being replaced, parts and Appliances become the property of Electrolux; or
(b) in the case of services, at its option, to the supply of the services again or the
payment of the cost of having the services re-supplied; and in the case of Appliances
or services supplied in New Zealand, loss or damage whether direct or indirect or
consequential that is reasonably foreseeable.
Privacy
You acknowledge that in the event that you make a warranty claim it will be necessary for
Electrolux and its Authorised Service Centres to exchange information in relation to you to
enable Electrolux to meet its obligations under this warranty.
EXTENDED WARRANTIES AND INDEMNITY
Sealed Refrigeration System Warranty
For a further period of three years following the expiry of the Warranty period,
Electrolux or its agent will supply replacements for, or at the sole option of Electrolux,
repair, all parts it finds defective in the Sealed Refrigeration System which comprises:
compressor, condenser, evaporator, dryer and tubing. During this three year period
you will pay for the costs of labour (including any call out or service fees), and freight
if necessary in replacing defective par ts in the Sealed Refrigeration System. You will
pay for the costs of transport of the Appliance if further service is required and the
costs of parts or repair s to parts other than those included in the Sealed Refrigeration
System
Frozen Food indemnity
Subject to the following exclusions, Electrolux will indemnify you for a period of 24
months from the date of purchase of the Appliance against any loss or damage to
frozen foodstuffs due to a Sealed Refrigeration System breakdown. This indemnity will
be limited to:
(a) in the case of freezers with a capacity of less than 400 litres – AU$150
(b) in the case of freezers with a capacity of 400 litres or more – AU$300
This indemnity does not cover loss or damage to frozen foodstuffs occasioned by:
(a) failure to plug in the freezer to a properly connected power supply or failure to
switch on the power point
(b) accidental removal of the plug from the power point or switching off the power
supply;
(c) failure to keep the door or lid of the freezer closed
(d) the introduction of abnormal heat loads to the freezer;
(e) failure to observe the operating and installation instr uctions supplied with the
freezer; and
(f) failure to defrost the freezer at recommended intervals on chest freezers or non
frost free models
Important Notice
Before Calling a Service Technician please check carefully the operating instructions, service booklet and the warranty terms and conditions.
FOR SERVICE
or to find the address of your nearest state
service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call (Australia only)
SERVICE AUSTRALIA
ELECTROLUX HOME PRODUCTS
www.electrolux.com.au
FOR SPARE PARTS
or to find the address of your nearest state
spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call (Australia only)
FOR SERVICE
or to find the address of your nearest
authorised service centre in New Zealand
FREE CALL 0800 10 66 10
(New Zealand only)
SERVICE NEW ZEALAND
ELECTROLUX HOME PRODUCTS
www.electrolux.co.nz
FOR SPARE PARTS
or to find the address of your nearest state
spare parts centre in New Zealand
FREE CALL 0800 10 66 20
(New Zealand only)
NEEDS TO BE NZ ONLY???
Page 16
For further information please visit your
retailer, call 09 573 2384 or visit our
website at www.simpson.co.nz
Simpson. We are a part of the Electrolux family.
Share more of our thinking at www.electrolux.com
P/No. 2432853
© Copyright 2007 Electrolux Home Products Pty Ltd ABN 51 004 762 341
Print code: SMANXXXX
Issue date: Oct 08
Loading...
