IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
SAFETY INFORMATION
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required. Hardware
package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
CARE and MAINTENANCE
To clean, use a soft or slightly damp cloth, then wipe with a clean, dry cloth.
Dust with soft dry cloth.
Do not use ammonia-based cleaning products, as they will damage the finish.
Do not leave liquids or damp cloths on this furniture.
To avoid dulling of the finish, do not place furniture in direct sunlight.
Please inspect and tighten all screws or bolts on a regular basis to ensure proper
performance and safety of your item.
EASTWOOD / COLBURN / HALSTEAD
54 INCH SQUARE DINING TABLE
MODEL # 3AXCDNT-002
5/11
PRE-ASSEMBLY INFORMATION
PARTS DESCRIPTION
MODEL # 3AXCDNT-002
A
TOP
QTY 1
B
LEG
QTY 4
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
6/11
PRE-ASSEMBLY INFORMATION
HARDWARE DESCRIPTION
MODEL # 3AXCDNT-002
1
ALLEN KEY BOLT
M8 X 70 mm
QTY 8 SETS
2
ALLEN KEY
QTY 1
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
7/11
COMPONENTS – KEY DIAGRAM
MODEL # 3AXCDNT-002
B
B
B
B
A
8/11
ASSEMBLY
STEP 1
MODEL # 3AXCDNT-002
1
2
B
B
B
B
A
1. Attach Legs B to Top A .
2. Use 8 Allen Key Bolts 1 to secure part A and B .
3. Use Allen Key 2 to tighten Allen Key Bolts. Do not over-tighten.
9/11
ASSEMBLY
STEP 2
MODEL # 3AXCDNT-002
Note: Levelers on bottom of legs can be adjusted if floor is uneven.
10/11
EZRA / HAWTHORNE / KENTVILLE
DINING CHAIR
MODEL #
AXCDCHR-003-GL
PRE-ASSEMBLY INFORMATION
PARTS DESCRIPTION
1
3
CHAIR BACK
QTY 1
2
SEAT CUSHION
QTY 1
4
STRETCHER
QTY 2
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
FRONT LEG
QTY 2
PRE-ASSE
MBLY INFORMATION
HARDWARE DESCRIPTION
A
B
ALLEN KEY SCREW
M8 X 45 mm
QTY 1
D E
ALLEN
KEY SCREW
M8 X 60 mm
QTY 4
C
ALLEN KEY SCREW
M8 X 90 mm
QTY 4
F
ALLEN KEY SCREW
WASHER
QTY 9
M3.5 X 40 mm
QTY 4
ALLEN KEY
QTY 1
G
LOCK WASHER
QTY 9
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
ASSEMBLY
STEP 1
F
G
D
1
ůŝŐŶ^ĞĂƚƵƐŚŝŽŶ;ϮͿŝŶƚŽƉƌĞ-ĚƌŝůůĞĚŚŽůĞƐŽŶŚĂŝƌĂĐŬ;ϭͿ
ƚƚĂĐŚ^ĞĂƚƵƐŚŝŽŶ;ϮͿƚŽŚĂŝƌĂĐŬ;ϭͿƵƐŝŶŐůůĞŶ<ĞLJ^ĐƌĞǁ;Ϳ
and one Washer each of
hƐĞůůĞŶ<ĞLJ;&ͿƚŽƚŝŐŚƚĞŶŽŶŽƚŽǀĞƌͲƚŝŐŚƚĞŶ
;Ϳ
and (G).
ASSEMBLY
STEP 2
F
C
G
D
1
Attach Seat Cushion (2) to Chair Back (1) using Allen Key Screws (C)
and four Washers each of (D)
Use Allen Key (F) to tighten. Do not over-tighten.
and (G).
ASSEMBLY
STEP 3
1
F
E
B
G
D
Insert Front Legs (4) into Seat Cushion (2) slots.
Align the Stretcher (3) into Chair Back (1) and Front Leg (4).
Attach Front Legs (4) using Allen Key Screws (B) and four Washers
each of (D) and (G).
Use Allen Key (F) to tighten. Do not over-tighten.
Attach Stretcher (3) using Allen Key Screws (E) to Front Leg (4) and
Chair Back leg (1).
Use Allen Key (F) to tighten. Do not over-tighten.
ASSEMBLY
STEP 4
Use the zipper to close the fabric
on the bottom of the Chair.
ASSEMBLY
STEP 5
Turn Chair right side up.
WARRANTY
Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max
product. These products have been made to demanding, high-quality
standards and are guaranteed for domestic use against manufacturing
faults for a period of 12 months from the date of purchase. This warranty
does not affect your statutory rights.
In case of any malfunction of your product (failure, missing parts, etc.)
please contact us at our toll free service line at 1-866-518-0120 ext. 262
from 9 am to 4 pm, Monday to Friday, Eastern Standard Time or by email at
simpli-home.com/customer-support.
We reserve the right to repair or replace the defective product, at its
discretion.
This product is guaranteed for 12 months if used for normal purposes.
Any warranty is invalid if the product has been overloaded or subject to
neglect, improper use or an attempted repair by other than an authorized
agent. Heavy-duty or daily professional/commercial usage are not guaranteed.
Due to continuous product improvement, we reserve the right to change
the product specifications without prior notice.
Questions, problems, missing parts?
Before returning your product
please email Customer Support at
simpli-home.com/customer-support
or call
Customer Support at 1-866-518 - 0120 ext. 262
Monday to Friday between 9 am – 4 pm EST
For more information visit us on our website
www.simpli-home.com
Like us on facebook
www.facebook.com/simplihomefurnishings
