ShadowGlo™ HD Log Sets:
SF-HDL-TIMBER, SF-HDL-BIRCH
Models: SF-SC43-BK, SF-SC55-BK, SF-SC78-BK, SF-SCT43-BK, SF-SCT55-BK
Instructions
Leave this instruction with party responsible for
use and operation.
NOTICE! DO NOT discard these instructions. Important
service and maintenance instructions included.
NOTICE! DO NOT discard any hardware while
servicing. It may be reused.
Introduction
SimpliFire(R) ShadowGlo HD log sets are hand-painted
and oer true-to-life look and glow. Areas on some logs
are purposefully left unpainted, creating a stunningly realistic glow in the charred portions of the log when the LED
ember bed lights shine through.
There is no specic placement requirements for media
in the SimpliFire linear replaces. These placement in-
structions serve as a starting point for displaying the logs
included in this kit. If your replace is longer or shorter
than what is shown in this example, the pattern and general
concept can be repeated.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during
installation and service. Sheet metal edges are sharp.
Tools and Supplies Needed
Before beginning and installation be sure that the following
tools - supplies are available.
Gloves
Magnetic Phillips screwdriver
Safety glasses
Ember Media (included with appliance)
SF-HDL-TIMBER Kit includes:
LOG
REFERENCE
LETTER
A 1 H 1
B 1 I 1
C 1 J 1
D 1 K 1
E 1 L 2
F 1 M 2
G 1
LOG
QTY
LOG
REFERENCE
LETTER
LOG
QTY
WARNING! Risk of Shock! Always unplug the cord or
turn o the circuit breaker before moving or servicing.
A
D
B
E
C
Figure 1 SF-HDL-TIMBER Log Set
SimpliFire • SF-HDL-BIRCH, SF-HDL-TIMBER Log Instructions • 2043-950 Rev. B • 9/20
F
H
G
I
K
L
L
M
M
J
1
SF-HDL-BIRCH Kit includes:
Glass Front Removal
LOG
REFERENCE
LETTER
A 1 G 1
B 1 H 1
C 1 I 1
D 1 J 1
E 2 K 2
F 1 L 2
A
B
LOG
QTY
C
LOG
REFERENCE
LETTER
D
E
E
LOG
QTY
G
F
Refer to the appliance Owner’s Manual for instructions
to remove and install glass front.
CAUTION! Two adults recommended for the removal
or installation of glass front. Use caution when han-
dling glass. Failure to do so could result in personal injury
or property damage.
H
I
J
K
K
L
L
Figure 2 SF-HDL-BIRCH Log Set
SF-HDL-TIMBER Log Installation
Note: Log placement examples below are variable and may be changed based on your desired look. The
number of logs needed will vary depending on the length of your replace.
1. Take the logs with signicant char and position them inside the rebox with the unpainted portion facing down (allowing
the fuel bed light to shine through) as shown in Figure 3.
Figure 3. Place Small Logs
SimpliFire • SF-HDL-BIRCH, SF-HDL-TIMBER Log Instructions • 2043-950 Rev. B • 9/202
2. Arrange the remaining logs throughout the rebox so that one end rests on top of another log. Refer to Figure 3 as an
example.
Figure 3. Place Remaining Logs
3. Evenly place the black or clear nishing embers that came with your appliance throughout the fuel bed, lling in the surface
areas between logs. Refer to Figure 4.
Figure 4. Log Placement Reference per Appliance
Glass Front Installation
Refer to the appliance Owner’s Manual for instructions
to replace front glass.
SimpliFire • SF-HDL-BIRCH, SF-HDL-TIMBER Log Instructions • 2043-950 Rev. B • 9/20
3
SF-HDL-BIRCH Log Installation
Note: Log placement examples below are variable and may be changed based on your desired look. The
number of logs needed will vary depending on the length of your replace.
1. Take the logs with signicant char and position them inside the rebox with the unpainted portion facing down (allowing
the fuel bed light to shine through) as shown in Figure 5.
Figure 5. Place Small Logs
2. Arrange the remaining logs throughout the rebox so that one end rests on top of another log. Refer to Figure 6 as an
example.
Figure 6. Place Remaining Logs
3. Evenly place the black or clear nishing embers that came with your appliance throughout the fuel bed, lling in the surface
areas between logs. Refer to Figure 7.
Figure 7. Log Placement Reference per Appliance
Glass Front Installation
Refer to the appliance Owner’s Manual for instructions
to replace front glass.
SimpliFire, a brand of Hearth & Home Technologies
7571 215th Street West, Lakeville, MN 55044
www.hearthnhome.com
SimpliFire • SF-HDL-BIRCH, SF-HDL-TIMBER Log Instructions • 2043-950 Rev. B • 9/204
