Owner’s Manual
HEAVY DUTY
SHD-1T
www.SimplicityVac.com
Index
1
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Two-Wire Polarization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
State of California Proposition 65 Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Parts Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Replacement Bags/Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
How to Assemble and Operate the Vacuum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
How to Change the Vacuum Bag. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Handle Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
How to Change the Filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Edge Cleaning Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Automatic Self-Adjusting Nozzle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Optional Cleaning Tools/Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
How to Replace the Vacuum Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
How to Clean the Nozzle Hose. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Thermal Motor Protection . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
How to Contact your Authorized Retailer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Visit Simplicity Vacuums Online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Customer's Record
The model and serial numbers of this product may be found on the back side of the unit. You should register
your warranty online at SimplicityVac.com as soon as possible for your protection. Also, note the model and serial
numbers of your unit in the spaces provided below, and retain this book as a permanent record of your purchase.
Model Number: ____________________________________________________________________________________
Serial Number: ____________________________________________________________________________________
Date Purchased: ____________________________________________________________________________________
Your Simplicity vacuum cleaner is a product of high quality materials and superior workmanship. We urge you to
read these operating instructions carefully before you use this vacuum cleaner, in order to obtain the
full performance and satisfaction it can offer you.
Save These Instructions
Before you plug in your Simplicity vacuum cleaner, make sure the voltage indicated on the rating plate located
on the backside of the vacuum cleaner is the same as your local supply.
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE.
This machine is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the machine by a person responsible for their safety. When using an
electrical appliance, basic precautions should always be followed, including the following:
SAVE THESE INSTRUCTIONS.
WARNING! To reduce the risk of fire, electric shock, or injury:
1. Do not leave appliance unattended when plugged in. Unplug from outlet when not in use and before servicing.
2. WARNING: ELECTRIC SHOCK COULD OCCUR IF USED OUTDOORS OR ON WET SURFACES.
3. Do not allow to be used as a toy. Keep children and unauthorized persons away from the machine when in use.
4. Use only as described in this manual. Use only manufacturer’s recommended attachments.
5. Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left
outdoors, or dropped into water, return it to a service center.
6. WARNING - The replacement or repair of damaged wiring should only be performed by a qualified electrician or
service engineer from the original distributor or authorized service agent.
7. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or
corners. Do not run appliance over cord. Keep cord away from heated surfaces.
8. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
9. Do not handle plug or appliance with wet hands.
10. Turn off all controls before unplugging.
11. Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair and
anything that may reduce air flow.
12. Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts.
13. Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes.
14. Do not use without vacuum bag and/or filters in place.
15. Use extra care when cleaning on stairs.
16. Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where they may
be present.
17. Do not attempt to service the unit while appliance is plugged in.
18. This machine is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the machine by a person responsible for their safety.
Keep children and unauthorized persons away from the machine when in use.
Two-Wire Polarized Cord
MODELS CPU-1 and CPU-1T
This product is equipped with a polarized alternating current
line plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way. This is a
safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the plug. If the plug should still fail to
fit, contact an electrician to replace the obsolete outlet. Do
not defeat the safety purpose of the polarized plug.
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to
cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to
cause birth defects or other reproductive harm.
MODELS CPU-2 and CPU-2T
This appliance must be grounded. If it should malfunction or break down, grounding provides a path of least
resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an
equipment-grounding conductor and grounding plug. The plug must be plugged into an appropriate outlet that is
properly installed and grounded in accordance with all local codes and ordinances.
This appliance is for use on a nominal 120 volt circuit
and has a grounding attachment plug that looks like the plug
illustrated in Fig. 1. Make sure that the appliance is connected
to an outlet having the same configuration as the plug.
No adapter should be used with this appliance.
WARNING - Improper connection of the equipment-grounding
conductor can result in a risk of electric shock. Check with a
qualified electrician or service person if you are in doubt as to
whether the outlet is properly grounded. Do not modify the
plug provided with the appliance. If it will not fit the outlet,
have a proper outlet installed by a qualified electrician.
The replacement or repair of damaged wiring should only be
performed by a qualified electrician or service engineer from
the original distributor or authorized service agent
Grounding Instructions
Fig. 1
3
Parts Identification
Handle grip
Quick cord release
Handle tube
Nozzle hose
On/Off switch
Bag compartment
cover latch
Bag compartment
Dusting Brush
Cord storage hooks
Wand
Crevice Tool
Power cord
Accessory attachment
opening
Nozzle hose
Furniture guard
4
Self-adjusting nozzle
Replacement Bags/Filters
• Genuine Simplicity Paper Bags
Part # S6-3 (3 pk.)
Part # S6-12 (12 pk.)
Foot pedal release
Thermal reset button
• Genuine Simplicity Filter Set
Part # SF-HD
Genuine Simplicity Vacuum Belts
Part # SB6-2
Model specification plate
Thermal reset instructions
(1 pk.)
(2 pk.)
How to Assemble and Operate the Vacuum
How to Attach the Handle to the Vacuum Cleaner
The vacuum cleaner and the handle are packed separately.
1. After first removing the handle screw, insert handle into the hole
on top of the vacuum cleaner. Make sure that the cord hooks on
the handle are positioned to the back of the vacuum cleaner
(Fig. 1).
2. Line up the small hole on the handle with the small hole on the
vacuum cleaner and insert the screw. Make sure the screw is
tightened securely.
3. Turn the upper cord storage hook to the upright position and wind the
power cord around the cord storage hooks when storing the
vacuum cleaner (Fig. 2).
How to Release the Power Cord
1. The upper cord storage hook has a quick-release action.
To release the cord, rotate the hook downward and the cord will
drop off the handle for immediate use (Fig. 3).
2. Return the hook to the upright position before attempting to
rewind the cord.
Fig. 1
Fig. 2
On/Off Switch (Fig. 4)
1. To turn the vacuum on, push the switch located on the dust
compartment to the ( I ) position.
2. T
o turn the vacuum off, push the switch located on the dust
compartment on the ( 0 ) position.
How to Change the Vacuum Bag
Always operate the vacuum cleaner with a vacuum bag installed.
How to Change the Vacuum Bag
1. Unplug the vacuum cleaner. Remove the bag compartment cover
and remove the used bag from the bag holder (Fig.1).
2. Attach the new vacuum bag onto the bag holder (Fig. 2).
3. Pull the bottom corners of the new vacuum bag (Fig. 3).
4. Reinsert the tab on the end of the bag compartment cover into the
groove on the bag compartment housing. Press it into place and
fasten the bag compartment cover latch tightly (Fig. 4).
Fig. 1
Fig. 3
Fig. 4
Fig. 2
Fig. 3
Fig. 4
5
Handle Adjustments
The handle on this vacuum cleaner can be set to one of three positions – upright, middle or low.
How to Adjust the Handle
1. To release the handle, step on the pedal at the left rear corner of the
vacuum cleaner (Fig.1).
2. Upright position – for when cleaning tools are being used or for storage (Fig 2).
Handle locks in this position.
3. Middle position – for normal cleaning (Fig. 3).
4. Low position – for cleaning under furniture (Fig. 4).
*Once in the middle postion, press the release pedal again to place the
vacuum to the low position.
Fig. 1
Fig. 2
Fig. 3
Filters
Your Simplicity vacuum cleaner is equipped with a secondary filter and a post filter.
These filters capture fine dust particles and protect the motor from dirt. It is important
to change the filters regularly — approximately once a year, or as needed.
To Change the Secondary Filter
1. Unplug the vacuum cleaner. Remove the bag compartment cover and the bag.
2. Remove the secondary filter and replace with a new filter (Fig. 5).
3. Replace the bag and bag compartment cover.
NOTE: Filters cannot be washed and used again.
To Change the Post Filter
1. Unplug the vacuum cleaner. Remove the bag compartment cover.
2. Remove the foam filter from the front of the bag compartment (Fig. 6).
3. DO NOT THROW AWAY THE FILTER HOLDER.
4. Insert a new filter into the holder and replace the bag compartment cover.
Fig. 4
Fig. 5
Fig. 6
Edge Cleaning Feature
The edge cleaning feature provides improved cleaning of carpets near walls and stationary furniture. For maximum edge
6
cleaning, use the left side of the vacuum near walls or stationary furniture.
Automatic Self-Adjusting Nozzle
7
Your Simplicity upright vacuum cleaner is designed with an Automatic Self-Adjusting Nozzle. No manual
adjustments are required. The height of the nozzle is instantly and automatically adjusted to carpet pile height.
This self-adjusting feature allows the nozzle to float evenly over all carpet pile surfaces.
Optional Cleaning Tools/Accessories
TDK-15
Deluxe Attachment Set (Fig. 1)
12-foot wire hose
Extension wand (2 pieces)
Dusting brush
Crevice tool
Upholstery tool with brush
Deluxe floor brush
TWK-15
Standard Attachment Set (Fig. 2)
15-foot hose
Extension wand (2 pieces)
Deluxe floor brush
Fig. 1
Connecting the hose assembly to the vacuum cleaner
Open the lid located on the back side of the vacuum cleaner and
insert the plastic end of the hose assembly into the cleaning
attachment opening (Fig. 3). Then connect a tool to the curved
wand end of the hose assembly.
On-Board Tool Cleaning
Your vacuum is equipped with on-board
cleaning tools including a two-piece extension wand,
stretch hose, dusting brush and a crevice tool.
1. Remove the extension wand from the body of the vacuum
cleaner. Insert one end of the wand into the other and
twist to tighten.
2. Insert any of the tools onto the end of the wand.
Fig. 2
Fig. 3
How to Replace the Vacuum Belt
8
CAUTION: Unplug the vacuum cleaner before performing any of
these steps.
How to Remove the Bottom Plate
1. Place the vacuum cleaner in the low position by pressing the handle
release pedal twice. Turn the vacuum over.
2. Remove the two screws holding the bottom plate in place (Fig. 1).
3. Remove the bottom plate.
How to Replace the Belt
1. Turn the unit over and remove the bottom plate as described in the
above section.
2. Remove the belt guard (Fig. 2). Remove the agitator by pulling it
straight out (Fig. 3).
3. Remove the belt from the agitator.
4. Loop a new belt over the motor pulley (Fig. 4) and over the end of
the agitator.
5. Stretch the belt over the agitator while inserting it back into the
nozzle housing.
6. Reinsert the belt guard.
7. Replace the bottom plate by hooking the front end of the plate into the
two ribs on the front end of the nozzle housing. Press the bottom plate
into place and fasten it with the two screws.
Fig. 1
Fig. 2
NOTE: To ensure maximum cleaning efficiency, check the belt regularly to
ensure it is in good condition. Replace the
cracked or if excessive slipping is occurring.
belt if it is stretched,
Fig. 3
Fig. 4
How to Clean the Nozzle Hose
CAUTION:
Unplug the vacuum cleaner.
The nozzle hose, located on the back of the vacuum cleaner, carries the dirt
from the nozzle to the vacuum bag. The hose also functions as the attachment
cleaning hose (on CPU-1T and CPU-2T models only).
If the hose should become clogged
1. Pull out and turn the lid of the cleaning attachment opening. Remove the
clog or blockage (Fig.1).
2. If the above step is not enough, remove hose cuff from the attachment port
inlet (Fig. 2). Turn the unit over and unscrew and remove the bottom plate
(see "How To Remove Bottom Plate."). Check nozzle inlet tube for
obstructions (Fig. 3). Clear tube and reinstall the bottom plate.
.
Fig. 1
Fig. 2
Fig. 3
9
Thermal Fuse Protection
Your Simplicity vacuum cleaner comes equipped with a Manual Reset Thermal Motor Protector. This thermal
protector is designed to protect your vacuum cleaner from overheating due to a cutoff in airflow (i.e. clogged
hose, operating the vacuum without a bag). Should this situation occur, the thermal motor protector will safely shut
off your vacuum cleaner to avoid any potential damage.
To reset the thermal fuse
1. Unplug the vacuum cleaner.
2. Check for problem (over-filled bag, clog in hose, clogged filters, etc.).
3. Correct problem.
4. Locate the Thermal Motor Reset button on the back of the vacuum.
5. Push the reset button.
6. Plug vacuum cleaner in and begin using.
If problem continues, contact your Authorized Simplicity Retailer.
10
Troubleshooting
PROBLEM
Vacuum won’t turn on
Vacuum won’t pick up or low
suction
Dust escaping from vacuum
POSSIBLE REASON
• Power cord not rmly
plugged in
• Blown fuse or tripped
breaker
• Needs service
• Vacuum bag full
• Clogged lter
• Hose clogged
• Broken belt
• Dust cover not installed
properly
• Filter not installed
correctly
• Vacuum bag not installed
correctly
POSSIBLE SOLUTION
• Plug unit in rmly
• Check house fuse or
breaker. Replace fuse /
reset breaker.
• Take to Authorized
Retailer (1-888-9-SIMPLY)
• Install new bag
• Install new lter
• Remove obstacle
• Replace belt
• Reinstall the dust cover
• Review lter installation
(page 6)
• Review bag installation
(page 5)
Any other service should be performed by an Authorized Simplicity Retailer.
To locate your nearest Authorized Simplicity Retailer visit our website
at www.SimplicityVac.com or call 888-9-SIMPLY.
Key Replacement Parts
• Genuine Paper Vacuum Bags: S6-3 and S6-12
• Genuine Vacuum Belts: SB6-2
• Genuine Filters: SF-HD
For Best Performance
• Keep your vacuum clean and in good operating condition.
• Change vacuum bags once a month or when the bag is 2/3 full to maximize cleaning performance.
• Always use genuine Simplicity vacuum bags and replacement parts. Use of other products may
result in poor cleaning performance, potential vacuum cleaner damage and may void vacuum warranty.
Genuine products are designed for maximum cleaning performance.
• Have your vacuum checked annually by your Authorized Simplicity Retailer.
• Store your vacuum carefully in a dry area.
• For optimum cleaning performance and safety, follow your owner’s manual instructions.
11
Warranty
Warranty
What is Covered:
This warranty covers any defects in material and workmanship in your new Simplicity Heavy Duty vacuum.
How Long Coverage Lasts:
Warranty coverage for Simplicity Heavy Duty lasts two years. Household models used commercially are only
warranted for 90 days.
What is Not Covered:
• Damage to the vacuum which occurs from neglect, abuse, alterations, accident, misuse or improper
maintenance.
• Normal replacement items: belts, disposable bags and disposable filters.
What Simplicity Vacuums Will Do:
This warranty provides, at no cost to you, all labor and parts to keep this vacuum in correct operating condition
during the warranted period.
How to Get Service:
Warranty service can only be obtained by presenting the vacuum to an Authorized
Simplicity Retailer. A proof-of-purchase and product serial number will be required before service is rendered. To locate your nearest Simplicity Retailer, please call 1-888-9-SIMPLY or visit the
Simplicity website at www.SimplicityVac.com.
THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ANY AND ALL OTHER WARRANTIES WHETHER
WRITTEN, ORAL, EXPRESSED OR IMPLIED, (INCLUDING ANY WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE). THIS WARRANTY DISCLAIMS LIABILITY FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
How State Law Applies:
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
12
Register your warranty online at www.SimplicityVac.com
Date of purchase
Serial number
Model number
Owner’s Warranty Information
keep this for your records…
Purchased from:
Store name
Address
City, State, Zip
Telephone
13
1-888-9-SIMPLY
www.SimplicityVac.com
www.SimplicityVac.com
LVO M-SHD 5.15©2015 Tacony Corporation
Loading...
