Simplicity 843, 1604 User Manual
Specifications and Main Features
‒ Producent: Briggs & Stratton
‒ Modellenummer: 170402
‒ Motortype: 4-taktsmotor med 1 sylinder
‒ Bore Diameter: 3 inches
‒ Stroke: 2 3/8 inches
‒ Motor volum: 12.57 til 16.79 cubic inches
‒ Crankshaft: Crankshaft, horizontal, plain
‒ Starter: Manual rewind up-angle side pull
‒ Choke: Manual
‒ Governor: Remote Controlled Mechanical
‒ Ignition: High Tension Magneto
‒ Lubrication method: Splash
‒ Capacity: Crankcase 2 2/4 pints
‒ Capacity: Fuel tank, 4 quarts
‒ Muffler: Whistle Quiet, Low Back Pressure
‒ Housing: Simplicity Winterized
‒ Kinematic Configuration: All Gear
‒ Speeds: 2 forward 1 reverse
‒ Clutch: Touch-O-Matic v-belt type
‒ Traction differential: With free turn lock
‒ Drive: Solid axle drive
‒ Tire dimensions: 3.50 x 6 (zero pressure, keyed)
‒ Tire type: Pneumatic tire
‒ Wheel diameter: 14 inches
‒ Auger Drive Type: Belt and roller chain
‒ Auger Construction: SAW, Solid flite welded steel
‒ Effective Width: 28 inches
‒ Opening Height: 19 inches
‒ Skid Shoes: Adjustable Harderned large area
‒ Scraper Bar: Full Width High Carbon Steel
‒ Overall Length: 58 7/8 inches (Operating Position)
‒ Overall Width: 23 1/2 inches (Operating Position)
Frequently Asked Questions
Q: How many inches high can I expect the deflector on the Simplicity Sno Away to be?
A: Depending on the height of the user, the deflector could be estimated to be 40 inches operating.
Q: What type of engine does Simplicity Sno Away use?
A: Simplicity Sno-Away is equipped with a 4-cycle, single cylinder Briggs & Stratton engine.
Q: The length of the device in a storage position?
A: A rough estimate suggests storage of the device could require around 38 inches of length.
Q: While operating how high can the handles be?
A : The handles should operate at a maximum height of 35 inches from the users perspective.
Q: How many pounds does the Simplicity weigh?
A: The Simplicity weighs around 263 pounds when dismantled however requires around 285 pounds of shipping weight.
Q: Are there any warranty options available for the device?
A: Simplicity does provide its customers warranty options ranging upto an year however the device needs to be used under normal circumstances.
Q: What are the steps to begin the engine?
A: For turning on the engine, place the engine speed control lever to the middle position, put the transmission control lever to the neutral position, push the auger drive control down, pull the choke if necessary, and then recoil and pull the starter handle towards you.
Q: Is there anything I can do if the engine doesn't start up?
A: In the event that the engine does not start, check and ensure that the throttle is not closed, choke lever has moved to the proper position, shift lever is set to neutral, and also check if the spark plug cable is well fitted.
