Simplicity 1977, 1967, 1975, 1979, 1969 User Manual
...Specifications and Main Features
- Models Included: 1967 — 1979
- Engine Options:
- 4 H.P. Single Stage
- 5 H.P. Single Stage
- 5 H.P. 2 Stage
- 6 H.P. Single Stage
- 6 H.P. 2 Stage
- 7 H.P. 2 Stage
- 8 H.P. 2 Stage
- Stages: One and Two stage and Supercharged Models Offered.
- Widths Available:
- Single Stage: 22”, 30”, 40”, 50”, 62”, 66”
- 2 Stage: 18” 24” 26” 38” 42” 48” 52” 58” 60” 66” 74”
- Transmission Groups: Groups detailed under specific models.
- Drive System: Combination housed including gear head, drive belts and pulleys.
- Key Components: Multiple including gear sets, axles, and bearing assemblies and scrapers.
- Maintenance Features: Grease fittings implemented for lubrication.
- Additional Parts: Washers, nuts, bolts, and spacers are supplied as standard.
- Special Equipment: Idler assemblies, various clutches and brake systems.
Frequently Asked Questions
Q: What is the horsepower range of the snow throwers?
A: The snow throwers are fitted with engines ranging from 4 H.P. to 8 H.P.
Q: Are the snow throwers available in single stage and two stage configurations?
A: Yes. The snow throwers are available in single stage as well as two stage.
Q: What Are the Usual Width Specifications for These Snow Throwers?
A: As per configurations and models, the width ranges from 18 inches up to 74 inches.
Q: what are the maintenance procedures that I need to follow for my snow thrower?
A: Maintenance procedures include checking some grease fitting, lubricating components, replacing worn out parts and ensuring proper functioning of the drive components.
Q: More clarity regarding the engine types of these models is required as there is not much information?
A: Gasoline powered four to eight horsepower engines are installed on these snow thrower.
Q: These models require parts to be replaced do they? Specifically do they require parts to be replaces what does the market say?
A: Indeed while repairing the snow throwers needed up components many gears set bearings and driving belts have been easily supplied among the market enabling asagood maintaninnee routine
Q: What factors should I consider while buying a model? I need to better understand it
A: Try to assess the area that needs to be cleared the average snowfall in winters and if you want a one or a two stage snow thrower.
